CITROEN Jumpy Multispace User guide

JUMPY-ATLANTE-VP_EN_CHAP0A_COUV DEBUT_ED01-2014
OWNER'S HANDBOOK

JUMPY-ATLANTE-VP_EN_CHAP0A_COUV DEBUT_ED01-2014
On-line owner's handbook
Referring to the owner's handbook on-line also gives you
access to the latest information available, easily identifi ed by
the bookmark, associated with this symbol:
If the "MyCITROËN" function is not available on the CITROËN public
website for your country, you can fi nd your handbook at the following
address:
http://service.citroen.com/ddb/
Select:
You can fi nd your handbook on the CITROËN website,
under "MyCITROËN".
The Vehicle documentation link in the home page (no registration is
needed),
the language,
the vehicle, its body style,
the print edition of your handbook appropriate for the date of registration
of your vehicle.
You have access to your handbook on line, together with the latest
information, identifi ed by the symbol:
This personal and customisable space allows you to establish direct
and special contact with CITROËN.

The "Familiarisation" section at the start of this
document is intended as a quick way of getting
to know your vehicle. Reading the detailed
sections is essential to make the most of your
vehicle, in complete safety.
Your vehicle is fitted with only some of the
equipment described in this document,
depending on the trim level, version and the
specifications for the country in which it is sold.
The fitting of electrical equipment or accessories
which are not recommended by CITROËN may
result in a failure of your vehicle's electronic
system. Please note this specific warning and
contact a CITROËN dealer to be shown the
recommended equipment and accessories.
CITROËN has a presence on every continent,
a complete product range,
bringing together technology and a permanent spirit of innovation,
for a modern and creative approach to mobility.
We thank you and congratulate you on your choice.
Happy motoring!
We draw your attention to the following...
At the wheel of your new vehicle,
getting to know each system,
each control, each setting,
makes your trips, your journeys
more comfortable and more enjoyable.
For any work on your vehicle, use a qualified
workshop that has the technical information,
competence and equipment required, which a
CITROËN dealer is able to provide.

2
Contents
JUMPY-ATLANTE-VP_EN_CHAP00A_SOMMAIRE_ED01-2014
Remote control 20
Key 21
Alarm 22
Doors 23
Instrument panel 27
Adjusting the time 28
Warning lamps 29
Fuel gauge 35
Coolant 35
Tyre under-inflation detection 36
Service indicator 38
Lighting dimmer 39
5-speed manual gearbox 40
6-speed manual gearbox 40
Automatic gearbox 41
Gear shift indicator 44
Steering wheel adjustment 44
Starting and stopping 45
Controls for 46
lighting 46
wipers 49
Cruise control 51
Fixed speed limiter 53
Speed limiter 54
Heating / air conditioning,
manual 57
digital 59
Demisting and defrosting 63
Rear ventilation 65
Additional heating 66
Seats 69
2-seat front bench 71
Rear seats 73
Seat and bench
configuration 80
Cab fittings 81
Courtesy lamps 84
Toll cards/car park tickets 85
Seating area fittings 85
Rear suspension 88
Mirrors 91
Electric windows 93
Presentation 4
Exterior 6
Sitting comfortably 11
Seeing clearly 13
Driving safely 14
Cab fittings 15
Rear fittings 15
Child safety 16
Ventilation 17
Eco-driving 18
Parking brake 94
Hazard warning lamps 94
Parking sensors 95
Horn 96
Anti-lock braking system
(ABS) 96
Emergency braking
assistance 96
ASR and DSC 97
"Grip control" 98
Seat belts 100
Airbags 103
Lateral airbags 105
Front airbags 106
Child seats 107
Deactivating the passenger's
front airbag 108
ISOFIX mountings 111
Recommended seats 115
2. READY TO GO
20-45
4. SAFETY
94-118
1. FAMILIARISATION
4-19
3. EASE OF USE
and COMFORT 46-93

CONTENTS
Contents
3
JUMPY-ATLANTE-VP_EN_CHAP00A_SOMMAIRE_ED01-2014
The "Technology on board"
section presents the new audio/
navigation systems.
Towing a trailer 119
Other accessories 121
Opening the bonnet 122
Diesel engines 123
Petrol engine 124
Levels 125
Checks 127
Fuel 130
Fuel cut-off 131
Diesel priming pump 131
Battery 133
Puncture repair kit 135
Changing a wheel 137
Removable snow screen 141
Snow chains 142
Changing
a bulb 143
a fuse 148
a wiper blade 152
Towing the vehicle 153
Dimensions 156
Weights 160
Identification markings 162
Exterior 163
Instruments and controls 164
Interior 166
Technical data -
Maintenance 167
9. TECHNOLOGY on
BOARD
5. ACCESSORIES
119-121
6. CHECKS
122-132
7. QUICK HELP
133-154
8. TECHNICAL DATA
155-162
10. VISUAL SEARCH
163-169
The "Visual search" section
assists you in finding the
controls and functions and their
associated page numbers on
the schematic outlines of the
vehicle (visual index).
Emergency or assistance 9.1
eMyWay 9.3
Audio system 9.63

4
JUMPY-ATLANTE-VP_EN_CHAP01_PRISE EN MAIN_ED01-2014
PRESENTATION
Within the chapters, symbols draw your attention to specific
information:
This handbook has been designed to familiarise you with your
new vehicle from the moment you get behind the wheel and to
describe the operating features.
Reading the handbook is made easy with the content consisting
of 10 identified chapters, which can be located by means of a
colour code specific to each one. Its sections cover, by subject, all
of the functions of the vehicle in its most complete specification.
Chapter 8 gives all of the technical data relating to your vehicle.
At the end of the document, diagrams of the outside and inside of
the vehicle will assist you in locating equipment or functions and
page numbers refer you to the relevant section of the handbook.
directs you to the chapter and section which contains detailed
information concerning a function,
indicates important information relating to use of the equipment,
alerts you to the safety of individuals and equipment on board.

5
JUMPY-ATLANTE-VP_EN_CHAP01_PRISE EN MAIN_ED01-2014

2
3
4
7
2a
2b
8
Exterior
6
JUMPY-ATLANTE-VP_EN_CHAP01_PRISE EN MAIN_ED01-2014

7
4
7
8
3
2b
2
2a
7
Exterior
FAMILIARISATION
1
JUMPY-ATLANTE-VP_EN_CHAP01_PRISE EN MAIN_ED01-2014
Key
: section identification
: page identification
135
95
Rear suspension
Repairing a wheel
Parking sensors
137
Changing a wheel
88
26
24
20
Side-hinged rear doors
Key - Remote control
Sliding side door
156
Usable dimensions

6
7
6
6
Exterior
8
JUMPY-ATLANTE-VP_EN_CHAP01_PRISE EN MAIN_ED01-2014
Opening the bonnet
123
Diesel engines Petrol engine
124
153
Towing eye
122
Partially open the bonnet, lift the safety
catch and raise the bonnet.
Secure the stay in one of the two notches,
according to the height required, to hold the
bonnet open.
Lift the cover at the foot of the left-hand
seat and pull the release lever upwards.
At the front, unclip the cover by pressing it
at the bottom.
At the rear, unclip the cover using a coin or
the flat part of the towing eye.
Take care when working under the bonnet.
Refer to "Levels" in section 6 for advice on use of the fluids.

9
Interior
FAMILIARISATION
1
JUMPY-ATLANTE-VP_EN_CHAP01_PRISE EN MAIN_ED01-2014
INSTRUMENTS AND CONTROLS
1. Lighting and direction indicator
control stalk.
2. Instrument panel with screen.
3. Wipers, screenwash, trip computer
control stalk.
4. Gear lever.
5. Ignition.
6. Audio system controls.
7. Driver's airbag, horn.
8. Steering wheel height and reach
adjustment.
9. Headlamp beam adjustment.
10. Cruise control, speed limiter
switches.
11. 12 volt accessory socket (120 W
max) of the cigarette lighter type.
12. Ashtray.
13. Glove box, auxiliary socket,
passenger's airbag deactivation
switch.
14. "Grip control".

Interior
10
JUMPY-ATLANTE-VP_EN_CHAP01_PRISE EN MAIN_ED01-2014
CENTRE CONSOLE AND OVERHEAD STORAGE UNIT
1. Location of controls:
- electric child lock,
- central locking/unlocking.
2. Heating and/or air conditioning
controls.
3. Location of the ticket/card storage or
controls:
- deactivation of the DSC,
- deactivation of the interior
protection alarm, alarm LED,
- deactivation of the parking
sensors.
4. Storage compartment.
5. Audio equipment or storage
compartment.
6. Central adjustable vents.
7. Hazard warning lamps switch.
8. Screen or storage compartment.
9. Courtesy lamp.
10. Passenger's airbag deactivated
warning lamp.
11. Location of the ticket/card storage,
rear ventilation deactivation switch,
heated seat controls.
ADJUSTING THE TIME
- a centre console with screen: refer
to "Adjusting the date and time" in
section 9,
- a centre console without screen: refer to
"Instruments and controls" in section 2.
Depending on the configuration of your
vehicle, you have either:

3
11
Interior
FAMILIARISATION
1
JUMPY-ATLANTE-VP_EN_CHAP01_PRISE EN MAIN_ED01-2014
Driver's seat
SITTING COMFORTABLY
1. Forwards-backwards adjustment.
2. Backrest angle.
3. Cushion height.
4. Lumbar.
5. Head restraint height. 69

2
4
3
3
Interior
12
JUMPY-ATLANTE-VP_EN_CHAP01_PRISE EN MAIN_ED01-2014
Steering wheel Electric windowsMirrors
44
Seat belts
100
93
91
Adjust the steering wheel for height and
reach.
Manual adjustments.
Electric adjustments, electric folding /
unfolding.
Height adjustment.
Fastening.

3
3
7
13
Interior
FAMILIARISATION
1
JUMPY-ATLANTE-VP_EN_CHAP01_PRISE EN MAIN_ED01-2014
SEEING CLEARLY
46
Lighting off.
Sidelamps.
Main beam headlamps (blue).
Dipped beam headlamps (green).
Wiper control stalk
2fast.
1normal.
Iintermittent.
0off.
 single wipe.
AUTO, press the stalk down.
AUTO, automatic illumination
of headlamps.
Lighting control stalk
49
Changing bulbs
143
In bad weather or in winter, check that the
lamps are not covered with mud or snow.

9
9
3
4
9
3
Interior
14
JUMPY-ATLANTE-VP_EN_CHAP01_PRISE EN MAIN_ED01-2014
Emergency or assistance call
DRIVING SAFELY
Cruise control / Speed limiter
51, 54
For the cruise control, he vehicle speed must be
higher than 25 mph (40 km/h) with at least 4th
gear engaged
For the speed limiter, the minimum vehicle speed
that can be programmed is 20 mph (30 km/h).
98
Grip control
This allows the vehicle to make progress in
most conditions of low grip.
This system allows an emergency or
assistance call to be sent to the dedicated
CITROËN centre.
For more information on the use of this
system, refer to section 9, "Technology
on board".
Audio system
This easy to use audio system offers a
map of Europe on SD Card, a Bluetooth
telephone connection and the playing of
MP3 / WMA files.
eMyWay 53
Fixed speed limiter

3 3
3
3
3
15
Interior
FAMILIARISATION
1
JUMPY-ATLANTE-VP_EN_CHAP01_PRISE EN MAIN_ED01-2014
Overhead storage unit
83
CAB FITTINGS
Glove box
81 81
Storage compartment
Rear seats
73
Seating area fittings
85
REAR FITTINGS

3
3 3
2 3
4
Interior
16
JUMPY-ATLANTE-VP_EN_CHAP01_PRISE EN MAIN_ED01-2014
80
Seat and bench configurations
92
Rear windows Safety anti-pinch
93
Electric child lock
25
CHILD SAFETY
Child surveillance mirror
92
Child seats
107

3
33
17
Interior
FAMILIARISATION
1
JUMPY-ATLANTE-VP_EN_CHAP01_PRISE EN MAIN_ED01-2014
Recommended settings
For optimum use of the system, we recommend:
If I require... Air
distribution Temperature Air flow Air recirculation AC
Heating -
Cooling
Demisting
Defrosting
Manual controls
57
Digital controls, with separate driver
and passenger settings
59
At the rear
65
VENTILATION

18
JUMPY-ATLANTE-VP_EN_CHAP01_PRISE EN MAIN_ED01-2014
Eco-driving
Eco-driving is a range of everyday practices that allow the motorist to optimise their fuel
consumption and CO2emissions.
Optimise the use of your
gearbox
With a manual gearbox, move off gently
and change up without waiting. During
acceleration change up early.
With an automatic or electronic gearbox,
give preference to automatic mode and
avoid pressing the accelerator pedal
heavily or suddenly.
Control the use of your
electrical equipment
Before moving off, if the passenger
compartment is too warm, ventilate it by
opening the windows and air vents before
using the air conditioning.
Above 30 mph (50 km/h), close the windows
and leave the air vents open.
Switch off the headlamps and front
foglamps when the level of light does not
require their use.
Avoid running the engine before moving
off, particularly in winter; your vehicle will
warm up much faster while driving.
Drive smoothly
Maintain a safe distance between vehicles,
use engine braking rather than the
brake pedal, and press the accelerator
progressively. These practices contribute
towards a reduction in fuel consumption and
CO2emissions and also helps reduce the
background traffic noise.
If your vehicle has cruise control, make
use of the system at speeds above 25 mph
(40 km/h) when the traffic is flowing well.
As a passenger, if you avoid connecting
your multimedia devices (film, music,
video game...), you will contribute towards
limiting the consumption of electrical
energy, and so of fuel.
Disconnect your portable devices before
leaving the vehicle.
Remember to make use of equipment
that can help keep the temperature in the
passenger compartment down (sunroof
and window blinds...).
Switch off the air conditioning, unless it
has automatic regulation, as soon as the
desired temperature is attained.
Switch off the demisting and defrosting
controls, if not automatic.
Switch off the heated seat as soon as
possible.
The gear shift indicator invites you engage
the most suitable gear: as soon as the
indication is displayed in the instrument
panel, follow it straight away.
For vehicles fitted with an electronic or
automatic gearbox, this indicator appears
only in manual mode.
