clare CLR-CS-CHT-EXT-10 Assembly instructions
© 04APR19 Clare Controls, LLC. 1 / 2 DOC ID –1854 • Rev 02
Clare Touchpanel Power Extension Kit
CLR-CS-CHT-EXT-10 Installation Sheet
Last modified: 12/08/20
Description
The Clare Touchpanel Power Extension Kit provides a simple
way to extend your touchpanel’s power supply length up to
200ft. Follow the below instructions to extend the reach of your
touchpanel.
Note: This kit replaces the original power supply.
Unpacking the extender kit
Remove all contents from the kit’s packaging and ensure you
have the following items.
•1 ×CC-18v12w - 18 volt 12 watt power supply with a
custom snap wiring connector
•1 ×CC-18v-5v - 5 volt regulator cable assembly
Notes
•You will need a CAT 5 or better cable.
•An RJ-45 connector is not required, the kit is designed to
snap onto the wires.
WARNING: You must follow the instructions below to extend
your touchpanel’s power supply. Failure to do so may result in
bodily injury and/or damage to the equipment.
Installation
Select a location in the home for the touchpanel, and then
install the extender kit.
To install the device:
1. After selecting the mounting location of the panel, ensure
there is a wall opening large enough to insert the
CC-18v-5v cable assembly.
We recommend no less than a ⅞ in. or 22 mm diameter
opening in wall space.
2. Select the desired location for the power supply.
3. Run the CAT 5 cable from the panel mount location to the
power supply.
4. Cut the shielding on the CAT 5 cable by ½ to ¾ in.,
inserting the four wires according to their marked colors
into their power supply.
Figure 1: CAT5 connection at power supply
5. Press the clamps down until the tabs on the side click into
place.
WARNING: Not clamping the connector down properly
could lead to improper/poor charging and damage to the
panel.
6. At the panel mount location, cut the shielding on the CAT
5 by ½ to ¾ in., and then insert the four wires according to
their marked colors into their corresponding connectors on
the cable assembly.
Figure 2: CAT5 connection at cable assembly
2 / 2 DOC ID –1854 • Rev 01
7. Press the clamp down until the tabs on the side click into
place.
WARNING: Not clamping the connector down properly
could lead to improper/poor charging and damage to the
panel.
The charger is now fully functional.
Plug the charger into the wall and the cable assembly into
the touchpanel, verifying that the screen turns on before
making final changes or inserting the cable assembly into
the wall.
Figure 3: Extender kit
(1) CC-18v12w
(2) CAT 5 connection to the
CC-18v12w
(3) Cat 5 cable
(4) Cat 5 connection to the
CC-18v-5v
(5) CC-18v-5v
Specifications
Power Supply (CC-18v12w)
Input
120 to 220 VAC 50/60 HZ
Output
18 VDC up to 12 watts
Power Adapter (CC-18v-5v)
Input
12 to 18 VDC
Output
5 VDC up to 10 watts
Operating environment
Temperature
Relative humidity
Altitude
32 to 95°F (00 to 35°C)
10 to 90% noncondensing
1,500 m
Mechanical characteristics
Power Supply
(CC-18v12w)
White case with clamp on adapter
Power Adapter
(CC-18v-5v)
White case with Phoenix Connector
clamp connectors
Regulatory information
Manufacturer
Clare Controls, Llc.
7519 Pennsylvania Ave, Suite 104
Sarasota, FL 34243
UL rating
UL60950
FCC compliance
This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
EU compliance
Warranty information
Clare Controls offers a two (2) year limited warranty on original
Clare Controls components, from the date of shipment from
Clare Controls. To view complete limited warranty details,
including limitations and exclusions,
www.clarecontrols.com/warranty.
Scan the code
to view product
warranty details.
Contact information
Clare Controls, LLC.
7519 Pennsylvania Ave, Suite 104
Sarasota, FL 34243
General: 941.328.3991
Fax: 941.870.9646
www.clarecontrols.com
Integrator/Dealer Support: 941.404.1072
Homeowner Support (ClareCare): 941.315.2273 (CARE)
