Clarion UNGO ProSecurity S660 User manual

MMooddeellSS666600
➤
OOwwnneerr’’ssGGuuiiddee

i
© 2005 directed electronics, inc.
lliimmiitteeddlliiffeettiimmeeccoonnssuummeerrwwaarrrraannttyy
This Ungo Pro Security system is warranted against defects in material and workmanship.
The main unit is covered by this limited lifetime warranty. This Limited Lifetime
Warranty applies to Ungo Pro Security systems that have been installed by an authorized
Ungo Pro Security dealer. This warranty is to the Original Purchaser ("Owner") and to
the original vehicle in which it was installed into. This warranty is not transferable to any
subsequent owner(s) of the product(s).
WWaarrrraannttyyPPrrooggrraamm::
Main Unit Limited Lifetime
Remote Controls One year from date of purchase
Siren One year from date of purchase
Shock Sensor One year from date of purchase
LED One year from date of purchase
Override Switch One year from date of purchase
The Warranty does not cover batteries or products deemed damaged through alterations
or installation. It also does not cover products mishandled, misused, neglected, abused,
water damaged, or with removed/altered serial numbers.
PROOF OF PURCHASE WILL BE REQUIRED FOR WARRANTY SERVICE OF
THIS PRODUCT.
This warranty does not cover the costs incurred for removal or reinstallation of the main
unit and/or any damage to the vehicle or the vehicle's electrical system.
The sole responsibility of Clarion Corporation of America ("Clarion") under this
Warranty shall be limited to the repair or replacement of the product, at the sole discre-
tion of Clarion.
If it becomes necessary to send the product or any defective part to Clarion, the product
must be shipped in its original carton or equivalent carton, fully insured, with shipping
charges prepaid. Clarion will not assume any responsibility for any loss or damage
incurred in shipping.
ALL IMPLIED WARRANTIES EXCEPT TO THE EXTENT PROHIBITED BY
APPLICABLE LAW SHALL HAVE NO GREATER DURATION THAN THE
WARRANTY PERIOD SET FORTH ABOVE. UNDER NO CIRCUMSTANCES
SHALL CLARION CORPORATION BE LIABLE FOR ANY LOSS OR DAMAGE,
DIRECT OR CONSEQUENTIAL, ARISING OUT OF THE USE OR INABILITY
TO USE OF THE PRODUCT. BECAUSE SOME STATES DO NOT ALLOW LIMI-

ii © 2005 directed electronics, inc.
TATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS OR EXCLUSIONS
OR LIMITATIONS OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, THE
ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY
ALSO HAVE THE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE.
Should you have any difficulties with the performance of this product during warranty,
please call: 1-800-GO-CLARION or visit your local Ungo Pro Security dealer. You may
also contact the National Service Manager at the following address below for additional
service help you may need.
Clarion Corporation of America
Attn: National Service Manager
661 W. Redondo Beach Blvd.
Gardena, Ca 90247

1
© 2005 directed electronics, inc.
ttaabblleeooffccoonntteennttss
lliimmiitteeddlliiffeettiimmeeccoonnssuummeerrwwaarrrraannttyy...................................................................
.............ii
rreemmootteeccoonnffiigguurraattiioonnss................................................................
..................................33
LCD 2-way configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
standard 4-button configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
wwhhaattiissiinncclluuddeedd..............................................
..............................................................66
iimmppoorrttaannttiinnffoorrmmaattiioonn...............
...................................................................................66
system maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
fcc/id notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
rreemmootteeffuunncctti
ioonnss..........................................................................................................99
LCD 2-way remote standard configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Standard LCD 2-way icon configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4-button remote standard configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
LLCCDD22--wwaayyrreemmootteeooppeerraattiioonn.............................................................
.......................1177
system signal paging features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
uussiinnggyyoouurrssyysstteemm.......................................................
...............................................1199
warning! safety first . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
active arming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
passive arming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
warn away®response description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
triggered response description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
multi-level security arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
arming while driving. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
disarming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
disarming while driving. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
high security disarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
disarming without a remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
silent mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
panic mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
valet®mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
temperature check mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
nuisance prevention circuitry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
ddiiaaggnnoossttiiccss.......................................................................................
...........................3300
arming diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
disarming diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
system status chirps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
table of zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
interpreting zone diagnostics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

2© 2005 directed electronics, inc.
ccooddeehhooppppiinngg..............................................................................................................3344
hhiigghhffrreeqquueennccyy.............................................................
...............................................3355
oowwnneerrrreeccooggnniittiioonn................................
......................................................................3355
rraappiiddrreessuummeellooggiicc.........
.............................................................................................3366
ppoowwe
errssaavveerrmmooddee......................................................................................................3366
pprrooggrraammmmiinnggooppttiioonnss..............................................................
..................................3377
sseeccuurriittyy&&ccoonnvveenniieenncceeeexxppaannssiioonnss..............................
..............................................3399
gglloossssaarryyoofftteerrmmss..................................
......................................................................4411

3
© 2005 directed electronics, inc.
rreemmootteeccoonnffiigguurraattiioonnss
LCD 2-way configuration
1234
5
6
7
8
9
10
11
12
13
14
15
16
17 18
19
20
21
22
23
24
25
26
27
28
29
30
31
➜

4© 2005 directed electronics, inc.
1 Vehicle Interior Temperature Indicator
2 Numeric Display
3 AM/PM Indicator
4 Alarm Clock Mode Indicator
5 Timer Function Indicator
6 Transmit Range Indicator
7 Transmission Indication
8 Vibrate/Beep Mode Indicator
9 Power Saver Mode Indicator
10 Remote Start Timer Mode Indicator
11 No Function
12 Vehicle Page Mode Indicator
13 Full Trigger Shock Sensor Indicator
14 Hood/Trunk Open or Trigger Indicator
15 Parking Light Indicator
16 Door Open or Trigger Indicator
17 Arm/Lock Button
18 Disarm/Unlock Button
19 Remote Start Indicator
20 Hood/Trunk Open or Trigger Indicator
21 Remote Start Button
22 Valet®Mode Indicator
23 Remote Start Safety Shutdown Indicator
24 Battery Level Indicator
25 Auxiliary Button
26 Temperature-Controlled Remote Start Indicator
27 Silent Arm/Disarm Mode Indicator
28 Full Trigger Alert Indicator
29 Arm/Disarm Indicator
30 Function Button
31 Celsius/Fahrenheit Indicator

5
© 2005 directed electronics, inc.
standard 4-button configuration
controls the AArrmmand PPaanniiccOn/Off function.
controls the DDiissaarrmmand PPaanniiccOff function.
controls SSiilleennttMMooddee™™and AAuuxxiilliiaarryychannel 22output.
no function.
and pressed together control channel 44output.
and pressed together control channel 55output
➜

6© 2005 directed electronics, inc.
wwhhaattiissiinncclluuddeedd
➤Control module
➤ASK transceiver/antenna
➤One 4-button remote
➤One 2-way LCD remote
➤Stinger™ DoubleGuard®2-stage shock sensor
➤Revenger™ Soft Chirp™ 6-tone programmable siren
➤Status LED indicator light
➤Push-button Valet®switch
iimmppoorrttaannttiinnffoorrmmaattiioonn
Congratulations on the purchase of your remote alarm system.
Due to the complexity of this system, it must be installed by an
authorized dealer only. Installation of this product by anyone
other than an authorized dealer voids the warranty. All dealers
are provided with a preprinted dealer certificate to verify autho-
rization.
By carefully reading this Owner's Guide prior to using your
system, you will maximize the use of this system and its features.
You can print additional or replacement copies of this manual by
accessing our web site at www.clarion.com.

7
© 2005 directed electronics, inc.
system maintenance
The system requires no specific maintenance other than battery
replacement for the remotes.
LCD 2-Way Remote Battery Replacement
The 2-way remote is powered by a 1.5V AAA battery. The
Battery Level indicator has three level indicators that serve as a
visual indication of battery charge. When the battery reaches a
low charge level that requires replacement, the transceiver will
generate a single notification chirp, and the Battery Level indi-
cator will flash continuously.
To replace the battery, gently pull the battery cover release tab, then
slide the door down to expose the battery and remove the expired
battery. Place the new battery into the transceiver observing the
correct polarity. When power is returned the transceiver will light
all icons in the LCD and generate all beeper tones once.
4-Button Remote Battery Replacement
Your remote is powered by a small, lightweight 3-volt lithium
battery (CR2032) that will last approximately one year under
normal use. When the battery begins to weaken, operating range
will be reduced and the LED on the remote will dim.
➜

8© 2005 directed electronics, inc.
fcc/id notice
This device complies with Part 15 of FCC rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause
undesirable operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate this device.
Tested to Comply
with FCC Standards
Directed Electronics, Inc. 474V/P/S Series
Tested to Comply
with FCC Standards
Directed Electronics, Inc. 477T Series
Tested to Comply
with FCC Standards
Directed Electronics, Inc. 44 Series
➜

9
© 2005 directed electronics, inc.
rreemmootteeffuunnccttiioonnss
The remote buttons are used to send commands to the system.
The descriptions below reflect the standard configuration for this
system. The buttons can be custom configured for the user’s
specific needs by the installer.
LCD 2-way remote standard configuration
LCD 2-way button configuration
Button
The System Arm/Lock and Multi-Level Security Arming func-
tions are controlled by pressing this button.
Button
The System Disarm/Unlock and High Security Disarm functions
are controlled by pressing this button.
Button
Channel 2 output is controlled by pressing and holding this
button for two seconds.
Button
The panic feature is controlled by pressing and holding this
button for three seconds. Press again to disable panic mode.
Button
The LCD backlighting will turn on when pressed for less than one
second; when held for more than five seconds the transceiver will
enter adjustment mode allowing the setting of the clock, timer
mode, and audible melody selection. For more information, please
refer to the
Function Button Configurations section of this guide.
➜

10 © 2005 directed electronics, inc.
Button
When pressed and held this button activates the second unlock
or other accessory.
and Buttons
The numeric display toggles between the time of the day and the
alarm clock when these buttons are pressed simultaneously.
and Buttons
Press these buttons simultaneously to activate the parking timer.
Each additional press will toggle through the available options
(10 min., 20 min., 30 min., 1 hour, 1.5 hours, 2 hours, and off).
and Buttons
When pressed simultaneously these buttons toggle between beep
notification and vibrate notification.

11
© 2005 directed electronics, inc.
and Buttons
When pressed simultaneously these buttons activate battery saver
mode, which will drop power consumption on the transceiver
battery to zero when the alarm is inactive or disarmed.
Standard LCD 2-way icon configuration
Icon
The numeric display icon will show the hours and minutes.
Icon
The AM/PM icon indicates the time before or after noon.
Icon
The alarm clock mode icon indicates that the alarm clock mode
is active.
Icon
The timer function icon flashes during timed functions including
parking timer.
Icon
The transmit range indicator icon stays visible as long as the
system is within operating range.
➜

12 © 2005 directed electronics, inc.
Icon
The remote transmission indicator icon displays when the trans-
ceiver is transmitting a signal.
Icon
The vibrate/beep mode icon appears when the transceiver is set
to vibrate mode.
Icon
The power saver mode can be turned on or off with the trans-
ceiver. This icon displays the status.
Icon
No function.
Icon
The vehicle page mode icon displays when the alarm module is
paging the transceiver.
Icon
The full trigger shock sensor icon indicates that the shock sensor
has been triggered by a hard shock.
and Icons
The hood/trunk open or trigger icon illuminates when the hood
or trunk trigger has been activated or the hood or trunk is open,
and bypasses those zones until it is closed.

13
© 2005 directed electronics, inc.
Icon
The parking light icon will flash twice when armed or disarmed.
The icon also flashes during WarnAway and at the beginning and
end of remote start cycles.
Icon
The door open or trigger icon illuminates when the door trigger
has been activated or the door is open, and bypasses that zone
until it is closed.
Icon
No function.
Icon
The Valet®mode icon appears when the system is in Valet®mode.
Icon
The remote start safety shut down icon indicates the vehicle may be
in gear or other unsafe condition inhibiting remote start operation.
Icon
The battery level icon indicates the level of power remaining in
the battery.
Icon
The silent arm/disarm icon appears when the system has been
armed or disarmed in the silent mode.
Icon
The full trigger alert icon illuminates when the security system
has been triggered by a heavy impact, door trigger violation,

14 © 2005 directed electronics, inc.
optional sensor violation, or a hood/trunk trigger.
Icon
The arm icon appears when the vehicle is armed and locked. The
disarm icon appears when the vehicle is disarmed and unlocked.
Standard LCD 2-way button functions
AAuuddiibbllee
FFuunnccttiioonnBBuuttttoonnIIccoonnIInnddiiccaattiioonn
Lamp On
(10 sec)
Power-Saver Mode* +Melody
Beep/Vibrate Mode +4 Vibrations/
1 Beep
Time Adjust for 5 Seconds 2 Beeps
Mode (hour)**
Time Adjust 1 Time***
Mode (min)**
Alarm Clock 2 Times***
Set Mode (hour)**
Alarm Clock 3 Times***
Set Mode (min)**
Alarm Clock Music 4 Times*** 5 Selections
or Power on Music 1/2/3/4/5
Selection**
Alarm Clock Adjust 5 Times***
Mode (on/off)**
Timer Count Down 6 Times***
Adjust Mode
(hour)**
Timer Count Down 7 Times***
Adjust Mode
(min)**

15
© 2005 directed electronics, inc.
Timer Count 8 Times*** 5 Selections
Down Ending Melody 1/2/3/4/5
Selection 1**
RS Timer Count 9 Times***
Down Mode (on/off)*
Remote Start On 10 times*** 5 Selections
Melody Selection 2 1/2/3/4/5
10 Min Parking + 1 Time Melody
Count Down Mode
20 Min Parking + 2 Times Melody
Count Down Mode
30 Min Parking + 3 Times Melody
Count Down Mode
60 Min Parking + 4 Times Melody
Count Down Mode
90 Min Parking + 5 Times Melody
Count Down Mode
120 Min Parking + 6 Times Melody
Count Down Mode
Parking Count Down + 7 Times Melody
Off Mode
Alarm Clock Mode + Melody
On/Off****
Celsius/Fahrenheit + +
or
Melody
Select Mode
* This function will operate in the disarmed state only.
** The button will advance the selection upward. The
button will advance the selection downward or select the off set-
ting.
*** Be sure to hold down for five seconds prior to entering
timer clock adjust mode operation.
**** Press once to have the alarm clock on. Press twice to have the

16 © 2005 directed electronics, inc.
alarm clock off.
The remote will revert to normal operation from the set mode
when 15-seconds has elapsed without a button entry.
4-button remote standard configuration
Button
The arming is controlled by pressing this button. The panic
alarm is triggered by pressing and holding this button. Press this
button again to cancel the panic alarm.
Button
The disarming function is controlled by pressing this button.
Button
Silent Mode™ and an optional auxiliary function are controlled
by this button. (Silent Mode works by pressing this button for
less than one second before arming or disarming. An optional
auxiliary function, such as trunk release, can be controlled by
pressing and holding this button for 1.5 seconds.)
The auxiliary output controls __________________________.
➜

17
© 2005 directed electronics, inc.
and Buttons
An optional auxiliary convenience or expansion function that
you have added to your system can be activated by pressing these
buttons simultaneously.
The auxiliary output controls __________________________.
and Buttons
An optional auxiliary convenience or expansion function that
you have added to your system can be activated by pressing these
buttons simultaneously.
The auxiliary output controls __________________________.
and Buttons
No function.
LLCCDD22--wwaayyrreemmootteeooppeerraattiioonn
The remote start system operates at 434 MHz and incorporates
Directed’s proprietary A.S.K. out-board two-way transceiver. The
high frequency combined with Binary Data communication
achieves superior range with two-way communication.
system signal paging features
A page is the signal the control module sends to the transceiver as
confirmation of receipt of a command or alarm system status.
When the transceiver receives a page it will generate a page notifi-
➜
