Clarion UNGO ProSecurity SR5000 User manual

Model SR5000
Installation Guide
NOTE: This product is intended for installation by a professional installer only!
Any attempt to install this product by any person other than a trained professional
may result in severe damage to a vehicle’s electrical system and components.

. 3
WWaarrnniinngg!!SSaaffeettyyFFiirrsstt..................................................................44
IInnssttaallllaattiioonnPPooiinnttssttooRReemmeemmbbeerr................................55
Before Beginning the Installation...........5
Finding the Tachometer Wire ................5
Finding the WAIT-TO-START Bulb Wire
for Diesels..............................................6
After the Installation..............................6
Vehicle Anti-Theft Systems (Immobilizers)
6
PPrriimmaarryyHHaarrnneessss((HH11)),,WWiirreeCCoonnnneeccttiioonn
GGuuiiddee..................................................................................................................77
Primary Harness (H1) Wiring Diagram.7
Primary Harness Wire Descriptions .......7
SSeeccoonnddaarryyHHaarrnneessss((HH22)),,WWiirreeCCoonnnneeccttiioonn
GGuuiiddee..............................................................................................................1122
Secondary Harness (H2) Wiring Diagram
12
Secondary Harness Wire Descriptions .12
RReellaayySSaatteelllliitteeKKeeyySSwwiittcchhIInntteerrffaacceeWWiirree
CCoonnnneeccttiioonnGGuuiiddee......................................................................1144
Heavy Gauge Relay Satellite Wiring
Diagram...............................................14
Heavy Gauge Relay Satellite Wire
Descriptions.........................................14
Remote Start Ribbon Harness Wiring
Diagram...............................................15
RReemmootteeSSttaarrttHHaarrnneessss((HH33)),,WWiirreeCCoonnnneeccttiioonn
GGuuiiddee..............................................................................................................1155
Remote Start Harness (H3) Wiring
Diagram...............................................15
Remote Start Harness Wire Descriptions15
NNeeuuttrraallSSaaffeettyySSwwiittcchhIInntteerrffaaccee................................1188
Testing the Neutral Safety Switch ........18
DDoooorrLLoocckkHHaarrnneessss((HH44)),,WWiirreeCCoonnnneeccttiioonn
GGuuiiddee..............................................................................................................1199
PPeerriipphheerraallPPlluugg--IInnHHaarrnneessss............................................1199
LED, 2-Pin WHITE Plug ...................19
Override Switch, 2-Pin BLUE Plug .....19
Programmer Interface, 3-Pin Port ........20
Shock Sensor Harness, 4-Pin Connector20
Mounting the Receiver/Antenna..........21
PPrrooggrraammmmiinnggJJuummppeerrss..........................................................2222
Light Flash Jumper ..............................22
Tach Threshold On/Off.......................22
MMoodduulleePPrrooggrraammmmiinngg............................................................2233
SSyysstteemmFFeeaattuurreessMMeennuuss........................................................2255
Menu #1 - Basic Features.....................25
Menu #2 - Advanced Features..............25
Menu #3 - Remote Start Features ........26
FFeeaattuurreeDDeessccrriippttiioonnss................................................................2266
Menu #1 - Basic Features.....................26
Menu #2 - Advanced Features..............28
Menu #3 - Revote Start Features..........29
RReemmootteeCCooddiinnggRRoouuttiinnee....................................................3300
RReemmootteeCCoonnffiigguurraattiioonnss........................................................3322
Standard Configuration .......................32
Single Button Arm/Disarm Configuration
33
TTaacchhLLeeaarrnniinngg....................................................................................3344
RReemmootteeSSttaarrttDDiiaaggnnoossttiiccss..................................................3344
RReemmootteeSSeennssoorrBByyppaassss..........................................................3355
FFaallsseeAAllaarrmmPPrreevveennttiioonnCCiirrccuuiittrryy..........................3366
PPoowweerr--UUpp................................................................................................3366
2244--HHoouurrTTiimmeerrMMooddee..........................................................3366
DDiiaaggnnoossttiiccss............................................................................................3366
Arm/Disarm Diagnostics .....................36
System Status Chirps ...........................37
Table of Zones .....................................37
SSeeccuurriittyyDDiiaaggnnoossttiiccss..................................................................3377
SSaaffeettyyCChheecckk........................................................................................3388
TTrroouubblleesshhoooottiinngg............................................................................3399
Alarm Troubleshooting ........................39
Remote Start Troubleshooting..............40
WWiirriinnggQQuuiicckkRReeffeerreenncceeGGuuiiddee..............................4422
