Clarion AUTOPC 310C User manual

CLARION CO. LTD. 1998
All Rights Reserved
Clarion AutoPC 310C
Owner’s Manual

Clarion AutoPC Owner’s Manual
ii
Precautions
IMPORTANT: READ THE
INSTRUCTIONS CONTAINED IN
THIS MANUAL BEFORE USING THE
CLARION AUTOPC SYSTEM.
SAFETY WARNING! When you see
this symbol !, it means, for your
safety, the vehicle must be stopped to
set or use the Auto PC. Pull over in a
safe and legal manner before
attempting to manually access a
function of the system.
Read and follow instructions
Before using your Windows® CE for
the Auto PC system, read and follow
all instructions and safety information
provided in this Owner’s Manual. Not
following precautions found in this
Owner’s Manual can lead to an
accident or other serious
consequences.
Keep Owner’s Manual in vehicle
When kept in the vehicle, the Owner’s
Manual will be a ready reference for
you and other users unfamiliar with the
Windows CE for the Auto PC system.
Please make certain that before using
the system for the first time, all
persons have access to the Owner’s
Manual and read its instructions and
safety information carefully.
Warning
Operating certain parts of this
system while driving can distract
your attention away from the road,
and possibly cause an accident or
other serious consequences. Do
not change system settings or enter
data non-verbally (using your
hands) while driving. Stop the
vehicle in a safe and legal manner
before attempting these operations.
This is important since while setting
up or changing some functions you
might be required to distract your
attention away from the road and
remove your hands from the wheel.
Voice command control
Many of the functions of the Windows
CE for the Auto PC system can be
accomplished using only voice
commands.
Prolonged views of screen
Do not access any function requiring a
prolonged view of the screen while you
are driving. Pull over in a safe and
legal manner before attempting to
access a function of the system
requiring prolonged attention. Even
occasional short scans to the screen
may be hazardous if your attention has
been diverted away from your driving
task at a critical time.
Volume setting
Do not raise the volume excessively.
Keep the volume at a level where you
can still hear outside traffic and
emergency signals while driving.
Driving while unable to hear these
sounds could cause an accident.

Clarion AutoPC Owner’s Manual
iii
Precautions continued
Care in handling
The Clarion AutoPC system is a
sensitive electronic device. As with all
electronic devices, care should be
taken to avoid contact with extreme
heat, cold, or humidity.
Operating at very cold temperatures
At extremely cold temperatures, the
display screen speed may be reduced,
and the display may dim. Also, the
colors on the display may vary
depending on the thermal condition of
the unit itself or the temperature in a
vehicle. These phenomena are the
characteristics of the liquid crystal
display and are not malfunctions.
Handling Detachable Control Panel
Also, special care should be taken
when handling and storing the
Detachable Control Panel (DCP).
Note: The terms “control panel” and
“DCP” are used interchangeably in this
document to refer to the same thing.
Fully close DCP holder after DCP
removal
It is dangerous to keep the DCP holder
at an angle once the DCP is removed.
Be sure that the DCP holder is fully
closed (in the vertical position).
Operating switches and knobs
The slanted control panel may not
maintain its adjusted angle if a button
is pushed too hard.
Cleaning display cover
Turn power off. Clean the display
cover with a lightly damp soft cloth.
Do not pour or spray liquid on the
display as this will damage the unit.

Clarion AutoPC Owner’s Manual
iv
Precautions continued
CompactFlashTM 1(CF) Card
Insertion Slot Cover
The CF Card insertion slot is equipped
with a slot cover in order to prevent the
exposure to debris and to protect
terminals. Be sure to cover the CF
Card insertion slot with the cover when
the slot is not being used.
Inserting the CF Card
The Clarion AutoPC System will
accept CF Cards from most
manufacturers. Warning: CF Card
can be inserted one way only. Make
sure to insert the CF Card with the
manufacturer’s label and arrow
FACING RIGHT of the unit as shown
to the right.
1CompactFlash is a trademark of
SanDisk Corporation.
Make sure label and
arrow are facing right

Clarion AutoPC Owner’s Manual
v
Precautions continued
Opening the DCP
Grip the control panel as shown in the
illustration which follows, and pull it
outward and downward in one
continuous motion.
Closing the DCP
Place your index finger immediately
below the Start button, pressing inward
and upward as shown below.
Proper clearance to eject CD
Open the control panel to the lowest
position to allow the CD to be ejected
without causing damage.
Before pressing the eject button, look
to see that the CD will clear the top of
the control panel as illustrated below.
Note: If the CD is not manually
removed within approximately 10
seconds after the eject button is
pressed, the CD will be automatically
loaded back into the CD Player.
CD ROM Installation
The vehicle should be parked at a
level location when a higher version of
OS or CD ROM software is installed.
Note: If a vehicle starts up or cranks
up, or if the ACC (accessory) is turned
on or off during the installation, voltage
fluctuation harmful to this unit may
occur. This could result in an
abnormal installation or a malfunction
in the unit.
Power On at time of initial operation
It may take up to 15 seconds to see an
actual display on the unit when it is
initially powered up. This is not a
malfunction.
Correct
clearance

Clarion AutoPC Owner’s Manual
vi
Copyright Information
CLARION CO. LTD.1998
All Rights Reserved
Reproduction, adaptation, or
translation without prior written
authorization is prohibited, except as
allowed under applicable copyright
laws.
Trademarks
Microsoft® and Windows® are either
registered trademarks or trademarks of
Microsoft Corporation in the United
States and/or other countries.
Microsoft products are licensed to
OEMs by Microsoft Licensing, Inc., a
wholly owned subsidiary of Microsoft
Corporation.
CompactFlashTM (CF) Card:
CompactFlash is a trademark of
SanDisk Corporation.
Warranty
This Owner’s Manual creates no
warranties nor does it make any
representations regarding the Auto PC
system on behalf of Clarion. The only
warranty provided by Clarion to the
purchaser is that contained in Clarion’s
published limited warranty for the Auto
PC system. All other purported
warranties and representations
regarding the quality, performance or
the suitability of the Auto PC system
are disclaimed.
Serial Number
Place the serial number sticker for
your Clarion AutoPC system here:
FCC Radio Interference Statement
Operation of the Clarion AutoPC
system is subject to the following two
conditions imposed by the Federal
Communications Commission: (1) this
system may not cause harmful
interference, and (2) this system must
accept any interference received,
including interference that may cause
undesired operation. Changes or
modifications to the equipment without
the express permission of Clarion may
void the authority to use the Clarion
AutoPC system.

Clarion AutoPC Owner’s Manual
vii
Contents
Chapter 1 – Introduction.............................................................................................1
Locating the controls.................................................................................................2
Detachable Control Panel (DCP) ..............................................................................6
General Operations.................................................................................................10
Chapter 2 – Using Speech Commands .....................................................................15
Getting help with speech commands ........................................................................17
Chapter 3 - Getting Ready ........................................................................................19
Display layout.........................................................................................................20
Using Speech to go to a program.............................................................................21
Using keys to go to a program.................................................................................22
Navigating within programs....................................................................................24

Clarion AutoPC Owner’s Manual
viii
Clock, date, time, and regional setup.......................................................................26
Using Global Speech Commands.............................................................................29
Using Program Speech Commands..........................................................................31
Chapter 4 – Using the Radio .....................................................................................35
Chapter 5 – Using the CD Player..............................................................................43
Chapter 6 – Audio Adjustments................................................................................51
Chapter 7 - Using Address Book...............................................................................55
Address Book command words and keys..................................................................56
Add, edit or delete a contact....................................................................................61
Transfer a contact...................................................................................................66
Browsing Contacts..................................................................................................67
Protecting Address Book information ......................................................................68
Chapter 8 - Using Directions.....................................................................................69

Clarion AutoPC Owner’s Manual
ix
Directions command words and keys.......................................................................72
Ways to select a start and destination points............................................................73
Commands to enter a start point..............................................................................74
Commands to enter a destination point....................................................................82
Calculating the route...............................................................................................87
Driving the route.....................................................................................................90
Chapter 9 - Using Messages ......................................................................................93
Messages command words and keys ........................................................................94
Reviewing Messages................................................................................................96
Saving Messages.....................................................................................................99
Changing message storage options........................................................................100
Chapter 10 – Using Voice Memo.............................................................................103
Recording voice memos.........................................................................................104
Deleting voice memos............................................................................................109
Chapter 11 – Customizing Your Auto PC...............................................................117

Clarion AutoPC Owner’s Manual
x
Add or Change a Password ...................................................................................120
ASSIST..................................................................................................................124
Changing Auto PC Sounds ....................................................................................125
Speech Command options......................................................................................129
Speech factors you can change..............................................................................130
To disable or enable the Wakeup word...................................................................133
Changing Timeouts ...............................................................................................136
Chapter 12 – Backup/Restore .................................................................................139
Using the CF Card for backup and restore ............................................................140
Chapter 13 – Adding/Removing Software and Hardware......................................143
Chapter 14 – Tips and Troubleshooting..................................................................145
Tips.......................................................................................................................145
Troubleshooting....................................................................................................151
Specifications...........................................................................................................157

Clarion AutoPC Owner’s Manual
xi
Glossary...................................................................................................................159
Index........................................................................................................................163

Clarion AutoPC Owner’s Manual
xii

Clarion AutoPC Owner’s Manual
1
Chapter 1 – Introduction
Congratulations on purchasing the Clarion AutoPC system, powered by
the Microsoft® Windows® CE operating system. Auto PC makes the
most of your driving experience by combining many features into a device
that fits into the same space normally occupied by your car stereo. Auto
PC is an information and entertainment system for people on the go, and
integrates a compelling graphical user interface with voice control that
keeps your hands on the wheel and eyes on the road.
CAUTION! OPERATE THIS SYSTEM ONLY WHEN SAFE. Taking your
attention away from the road while driving can cause a serious accident.
This manual is designed to be used in two ways:
1. As a general learning tool for you as you begin to operate the Clarion
AutoPC system.
2. As a reference tool for you as you actively expand your uses of the
Clarion AutoPC system.
Welcome
Caution
How to use this
manual

Clarion AutoPC Owner’s Manual
2
Locating the controls
Detachable Control Panel (DCP)
α-Selector
DCP release MUTE Display
Keys
Volume
up
Volume
down
IrDA
(Infrared)
Port
BACK POWER
HELP
MENU
Start Key
Voice
Memo
ASSIST CompactFlashTM (CF)
Card insertion slot

Clarion AutoPC Owner’s Manual
3
DCP release - Press to remove control
panel. Start Key - Display start menu (main
menu).
αα-Selector - Navigate programs and
options with a single finger. MENU - Press to get to extra options that
are available with some programs.
MUTE – Press to silence audio. HELP – For tips about current screen.
Display - Shows information in color on
the screen. POWER – Press to power the unit on and off.
Detachable Control Panel (DCP) -
Removable for security. BACK - Closes the currently displayed option.
Keys - Use for dialing, entering letters,
numbers, and radio presets. IrDA (Infrared) Port - Transfer data between Windows CE-based devices.
CompactFlashTM (CF) card insertion
slot - Use CF card to backup and restore
data.
Volume down - Touch once to decrease
by 1 step. Press and hold for greater
decreases.
ASSIST - Press to receive location-
based services (optional). Example:
roadside assistance services.
Volume up - Touch once to increase by
1 step. Press and hold for greater
increases.
Voice Memo - Record/playback a voice
memo.
DCP Legend

Clarion AutoPC Owner’s Manual
4
First, become familiar with the Controls and General Operation of the
Clarion AutoPC system as described in this chapter.
Second, spend 10 minutes previewing this Owner’s Manual:
•Scan the Table of Contents, it shows you the breadth of information
on your Auto PC.
•Glance at the first few chapters, noticing key words in the bolded
headings.
•Peruse the Index, as that will be your primary reference when you
need to find specific information on a topic.
Third, study the Using Speech Commands and Getting Started chapters,
then move into using the Radio and CD Player to learn the basics of Auto
PC.
Fast track to
learning and using
your Auto PC
The Index will become
your primary reference

Clarion AutoPC Owner’s Manual
5
The α-Selector enables you to navigate through various Auto PC
functions with a single finger. This is how you do it:
1. Put your index finger on the
raised center element (has a
white dot) of the α-selector as
shown in the figure. CAUTION!
DO NOT TAKE YOUR EYES
OFF THE ROAD UNLESS IT IS
SAFE TO DO SO.
2. To select the up/down direction
() or the left/right direction ( )
tilt the α-selector in the
corresponding direction.
3. To select “enter” push directly
inward on the middle element
with the white dot ( ).
αα
-Selector
Operation
Manually manipulating
this selector should only
be carried out for so
long as it can be done
safely.

Clarion AutoPC Owner’s Manual
6
Detachable Control Panel (DCP)
The control panel (Detachable Control Panel) can be detached to prevent
theft. After detaching the control panel, store it in the protective case
provided. We recommend taking it with you when leaving the vehicle.
1. Turn the power off.
2. Be sure that the control panel is
fully closed. Press the DCP
release button as illustrated on
the right.
3. Pull the DCP toward you and to
the left to remove it as shown
on the right.
NOTE: Using force to remove the
DCP will damage the unit.
Removing the DCP

Clarion AutoPC Owner’s Manual
7
You can also detach the DCP in its lowered position. The procedure is as
follows:
1. Turn power off.
2. Lower the DCP to its fully open
position
3. With your left index finger, find
the release button as shown in
the drawing. Push upward on
the release button, and pull the
DCP toward you and to the left.
4. For your safety, return the DCP
holder to the fully closed
position (the vertical position).
Detaching the DCP
in lowered position
Release button

Clarion AutoPC Owner’s Manual
8
The DCP has three lowered positions, each of which is reinforced by a
clicking sound:
•60 degrees (partially open)
•45 degrees
•30 degrees (fully lowered)
Warnings!
1. The DCP can easily be damaged by shock. After removing it, be
careful not to drop it or subject it to strong shock. After detaching the
control panel, store it in the protective case provided.
2. The connector connecting the source unit and the DCP is extremely
important. Do not press on it with fingernails, screwdrivers, etc.
Doing so may result in unit malfunction or damage.
DCP lowered
positions
