MAX668RVD
-1-
Service Manual
Published by Service Dept.
Printed in Japan
ClarionCo.,Ltd.
50Kamitoda,Toda-shi,Saitama 335-8511 Japan
ServiceDept.: 5-66Azuma,Kitamoto-shi, Saitama 364-0007Japan
Tel:[phone] FAX:[phone]
298-6379-00 Sep.2006
Model
MONI
DVD Multimedia Station
With Touch Panel Control
(QZ-6070E-B)
NOTES
* The tuner of this unit is DSP type. When you exchange
the tuner pack(880-2091D), it is necessary to adjust for
S-meter etc. The special JIG is used for an accurate
adjustment.
* This DVD video player can play the following discs.
* Precautions when creating an MP3 disc
When writing an MP3/WMA file on a disc, please select
"ISO9660 level 1 or level 2(without including expansion
format)" as the writing software format. Normal playback
may not be possible if the disc is recorded on another
format.
DVD video discs
Audio CDs
Video CDs CD TEXT
MP3 ID3 TAG WMA
* and logo are trademarks
or registered trademarks of Microsoft Corporation in the
United States and/or other countries.
* is for legal or rightholder-authorized copying only.
Don't steal music.
iPod is a trademark of Apple Computer, Inc., registered
in the U.S. and other countries.
In case of a track recorded at VBR (variable bit rate), the
display for the play time of the track may be slightly dif-
ferent from the actual play time. Also, the recommended
value of VBR ranges from 64 kbps to 320kbps.
* Manufactured under license from Dolby Laboratories.
"Dolby" and the double-D symbol are trademarks of Dolby
Laboratories.
* "DTS" and "DTS Digital Out" are registered trademarks
of Digital Theater Systems, Inc.
* This product includes technology owned by Microsoft
Corporation and cannot be used or distributed without a
license from MSLGP.
This product is a lead free model.
Lead free solder is used in PWB stamped LF mark.
Please keep the following conditions when you repair.
1. Use lead free solder.
* Koki's lead free solder S3X-55M 0.6mm
(CLARION Parts No.642-0231-01)
* Koki's lead free solder S3X-55M 1.0mm
(CLARION Parts No.642-0231-02)
2. Use a nitrogen solder system.
3. Do not use "General solder" and "Lead free solder"
together.
* This product incorporates copyright protection technol-
ogy that is protected by U.S. patents and other intellec-
tual property rights.
Use of this copyright protection technology must be au-
thorized by Macrovision, and is intended for home and
other limited viewing uses only unless otherwise autho-
rized by Macrovision. Reverse engineering or disas-
sembly is prohibited.
* We cannot supply PWB with component parts in
principle. When a circuit on PWB has failure, please
repair it by component parts base.
Parts which are not mentioned in service manual are
not supplied.
* Specifications and design are subject to change without
notice for further improvement.

MAX668RVD -2-
SPECIFICATIONS
Tuner section
Frequency range: FM;87.5MHz to 108.0MHz
MW;531kHz to 1629kHz
LW;153kHz to 279kHz
FM Usable sensitivity: 9dBf
FM 50dB quieting sensitivity: 15dBf
FM Alternate channel selectivity: 70dB
FM Stereo separation(1kHz): 32dB
FM Frequency response(-3/+3dB): 30Hz to 15kHz
DVD section
Usable discs: DVD video disc(Region 2),
DVD+/- R/RW
Frequency response: 20Hz to 20kHz(48kHz)(-1/+1dB)
Distortion: 0.006%
CD section
Wow flutter: Below measurable limit(WRMS)
Signal to noise ratio(1kHz): 100dB
Frequency response: 20Hz to 20kHz(-1/+1dB)
Dynamic range(1kHz): 100dB
Harmonic distortion: 0.006%
Audio amplifier section
Maximum power output: 50Wx4
DIN output power: 27Wx4(DIN45324,+B=14.4V)
Speaker impedance: 4ohm(4 to 8ohm)
Monitor section
Screen size(mm): 154.0(W)x87.0(H) (7-inch)
Display type: Transparent-type TN liquid crys-
tal display
Drive principle: TFT(thin-film transistor) active
matrix display
Number of pixels: 336,960(480x3[RGB]x234)
RAC video input: 1.0+/-0.2Vp-p(input impedance
75ohm)
RCA audio input: 130+/-60mVrms(inputimpedance
10kohm or more)
General section
Power source voltage: 14.4V DC
(10.8 to 15.6V allowable)
Ground: Negative
Current consumption: 4.0A(at 1W)
Dimensions(mm):
Main unit; 178(W)x100(H)x160.0(D)
Remote Control Unit; 54(W)x28.8(H)x155(D)
Weight: Main Unit; 2.4kg
Remote Control Unit; 100g
(including battery)
1 2 3 4
5
8-1 8-2 8-3
6 7
8
COMPONENTS
QZ-6070E-B
1. Main unit ----------- 1
2. Remote controller RCB-177-300 1
3. Battery(SUM-3) ----------- 2
4. Finisher 383-0591-00 1
5. RCA cap 345-3799-20 12
6. Extension lead 854-6432-01 1
(15A Fuse 120-0150-00 1)
7. RCA pin cord 855-5543-50 1
8. Parts bag ----------- 1
8-1. Electro tap 060-0018-00 1
8-2. Hexagonal screw(M5x8) 716-0496-51 8
8-3. Flat head screw(M5x8) 714-5008-4B 8
CAUTION
This appliance contains a laser system and is classified as
a "CLASS 1 LASER PRODUCT".To use this model
properly,read this Owner's Manual carefully and keep this
manual for your future reference.In case of any trouble with
this player,please contact your nearest "AUTHORIZED ser-
vice station".To prevent direct exposure to the laser beam,do
not to open the enclosure.
Top view of the unit

MAX668RVD
-3-
To engineers in charge of repair or
inspection of our products.
Before repair or inspection, make sure to follow the
instructions so that customers and Engineers in charge
of repair or inspection can avoid suffering any risk or
injury.
1. Use specified parts.
The system uses parts with special safety features against fire
and voltage. Use only parts with equivalent characteristics
when replacing them.
The use of unspecified parts shall be regarded as remodeling
for which we shall not be liable. The onus of product liability
(PL) shall not be our responsibility in cases where an accident
or failure is as a result of unspecified parts being used.
2. Place the parts and wiring back in their original positions after
replacement or re-wiring.
For proper circuit construction, use of insulation tubes, bond-
ing, gaps to PWB, etc, is involved. The wiring connection and
routing to the PWB are specially planned using clamps to keep
away from heated and high voltage parts. Ensure that they are
placed back in their original positions after repair or inspec-
tion.
If extended damage is caused due to negligence during re-
pair, the legal responsibility shall be with the repairing com-
pany.
3. Check for safety after repair.
Check that the screws, parts and wires are put back securely
in their original position after repair. Ensure for safety reasons
there is no possibility of secondary ploblems around the re-
paired spots.
If extended damage is caused due to negligence of repair, the
legal responsibility shall be with the repairing company.
4. Caution in removal and making wiring connection to the parts
for the automobile.
Disconnect the battery terminal after turning the ignition key
off. If wrong wiring connections are made with the battery con-
nected, a short circuit and/or fire may occur. If extensive dam-
age is caused due to negligence of repair, the legal responsi-
bility shall be with the repairing company.
5. Cautions in soldering
Please do not spread liquid flux in soldering.
Please do not wash the soldering point after soldering.
6. Cautions in soldering for chip capacitors
Please solder the chip capacitors after pre-heating for replace-
ment because they are very weak to heat.
Please do not heat the chip capacitors with a soldering iron
directly.
7. Cautions in handling for chip parts.
Do not reuse removed chips even when no abnormality is ob-
served in their appearance. Always replace them with new
ones. (The chip parts include resistors, capacitors, diodes, tran-
sistors, etc).
Please make an operation test after replacement.
8. Cautions in handling flexible PWB
Before working with a soldering iron, make sure that the iron
tip temperature is around 270 . Take care not to apply the
iron tip repeatedly(more than three times)to the same patterns.
Also take care not to apply the tip with force.
9. Turn the unit OFF during disassembly and parts replacement.
Recheck all work before you apply power to the unit.
10.Cautions in checking that the optical pickup lights up.
The laser is focused on the disc reflection surface through the
lens of the optical pickup. When checking that the laser opti-
cal diode lights up, keep your eyes more than 30cms away
from the lens. Prolonged viewing of the laser within 30cms
may damage your eyesight.
11.Cautions in handling the optical pickup
The laser diode of the optical pickup can be damaged by elec-
trostatic charge caused by your clothes and body. Make sure
to avoid electrostatic charges on your clothes or body, or dis-
charge static electricity before handling the optical pickup.
11-1. Laser diode
The laser diode terminals are shorted for transportation in or-
der to prevent electrostatic damage. After replacement, open
the shorted circuit. When removing the pickup from the mecha-
nism, short the terminals by soldering them to prevent this
damage.
11-2. Actuator
The actuator has a powerful magnetic circuit. If a magnetic
material is put close to it. Its characteristics will change. En-
sure that no foreign substances enter through the ventilation
slots in the cover.
11-3. Cleaning the lens
Dust on the optical lens affects performance.
To clean the lens, apply a small amount of isopropyl alcohol to
lens paper and wipe the lens gently.

MAX668RVD -4-
1. Set the range of CH1 and CH2 of an oscilloscope to 1V
range.
2. Indicate CH1 and CH2 by GND,adjust GND as follows.
White balance red adjustment
Measurement conditions: the same conditions as the ad-
justment of "Power supply voltage". / Measuring instrument:
oscilloscope(DC range)
1. Display the waveform of TP716 on CH1, and display the
waveform of TP715 on CH2.
2. Adjust VR703 so that the waveform of TP715 will be-
come the same as TP716.
White balance blue adjustment
Measurement conditions: the same conditions as the ad-
justment of "Power supply voltage". / Measuring instrument:
oscilloscope(DC range)
1. Display the waveform of TP716 on CH1, and display the
waveform of TP717 on CH2.
2. Adjust VR704 so that the waveform of TP717 will be-
come the same as TP716.
VCOM AC adjustment
Measurement conditions: the same conditions as the ad-
justment of "Power supply voltage". / Measuring instrument:
oscilloscope
1. Adjust VR701 so that an amplitude of a waveform of
TP705 is 8.0V+0.1/-0.1V, and confirm that there is no
distortion in the waveform.
Display position adjustment
Measurement conditions: the same conditions as the ad-
justment of "Power supply voltage". / Measuring instrument:
oscilloscope
1. Adjust VR402 so that the pulse width of TP42 is "5.4+0.1/
-0.1u sec.".
8.0V+0.1/0.1V
CH1
CH2
ADJUSTMENTS
* Refer to the printed wiring board(page 37) for the ad-
justment points and VRs.
* The NTSC composite output signal of the signal gen-
erators is performed with the following output.(Video in-
put of visual mode)
Video signal: 714 +/-17.5mV
Synchronized signal: 286 +/-7.5mV
Power supply voltage adjustment
Input signal: NTSC / COMP: 10-steps signal / Monochrome
/ DIMMER 100% / Measuring instrument: digital volt meter
1. Adjust VR600 so that the voltage of TP710 is 5.30+0.02/
-0.02V.
2. Confirm the following voltages.
TP709 : -17.0+0.8/-0.8V
TP711 : 7.5V+0.5/-0.5V
TP713 : 15.0V+0.8/-0.8V
Free-run frequency adjustment
Measurement conditions: the same conditions as the ad-
justment of "Power supply voltage". / Measuring instrument:
frequency counter and digital volt meter
1. Connect TP40 to GND, and adjust VR401 so that the
frequency of TP42 will become 15.734kHz+50/-50Hz.
2. Confirm the following voltages.
TP46 : 2.58V+0.15/-0.15V
BRIGHT voltage adjustment
Measurement conditions: the same conditions as the ad-
justment of "Power supply voltage". / Measuring instrument:
digital volt meter
1. Adjust VR705 so that the voltage of TP708 will become
2.00V+0.02/-0.02V.
RGB-AMP adjustment (black-black)
Measurement conditions: the same conditions as the ad-
justment of "Power supply voltage". / Measuring instrument:
oscilloscope
1. Adjust VR707 so that the black-black level of the wave-
form of TP716(G) will become 4.0V+0.1/-0.1V.
Contrast adjustment (black-white)
Input signal: NTSC / COMP: 10-steps signal / Monochrome
/ APL 50% wave form / With composite screen display /
BRT,COL,HUE: Initial setting of touch panel microcomputer
/ Measuring instrument: oscilloscope
1. Adjust VR702 so that the black-white level of the wave-
form of TP716(G) will become 3.8V+0.1/-0.1V.
White balance pre-adjustment
Measurement conditions: the same conditions as the ad-
justment of "Power supply voltage". / Measuring instrument:
oscilloscope(DC range)
Black
Withe
Withe
Black 4.0V+0.1/0.1V
Black
Withe
Withe
Black
3.8V+0.1/0.1V

MAX668RVD
-5-
PAL display adjustment
Input signal: PAL Color bar signal
1. Display the wave form of TP717 on CH1,and adjust L703
to focus.
Voltage confirmation of J710
1. Confirm the following voltages.
Pin32(VGH) : 15.0V+0.8/-0.8V
Pin30(CS) : -5.5V+0.8/-0.8V
Pin24(VCC) : -11.9V+0.8/-0.8V
Pin18(VGL) : -10.0V+0.8/-0.8V
Pin1,3(VSH) : 5.3V+0.5/-0.5V
Pin21(VSS) : -17.0+0.8/-0.8V
VCOM-DC adjustment
Measurement conditions: the same conditions as the ad-
justment of "Power supply voltage".
1. Adjust VR700 so that the flicker of monitor is minimum.
NAVI display position adjustment
Measurement conditions: Navigation display.
1. Adjust VR402 so that the navigation display is center.
Charactor focus adjustment
Measurement conditions: Navigation display.
1. Adjust VR706 so that the characters on the navigation
display is in focus. (In this case, adjust so that non-dis-
play dot is not caused on right and left of the display.)
Display Cause Measure
ERROR 2 A disc is caught inside the DVD deck and is not
ejected.
This is a failure of DVD deck’s mechanism.
ERROR 3 A disc cannot be played due to scratches, etc. Replace with a non-scratched, non-warped disc.
ERROR 6 A disc is loaded up side-down inside the DVD
deck and does not play. Eject the disc then reload it properly.
PARENTAL
VIOLATION Parental level error Set the correct Parental level.
WRONG REGION Region code error Eject the disc,and replace correct region code disc.
DRM WMA files protected by DRM are played.
Perform the operation such as skipping a file.
(Scan, repeat and random playback mode may be
canceled.)
NOT SUPPORT Files not supported by this unit are played.
Display Cause Measure
ERROR 2
CD Changer
DVD Player
A disc inside the CD changer is not loaded. This is a failure of CD changer’s mechanism.
ERROR 3 A disc inside the CD changer cannot be played
due to scratches, etc.
Replace with a non-scratched, nonwarped disc.
ERROR 6 A disc inside the CD changer cannot be played
because it is loaded upside-down.
Eject the disc then reload it properly.
RESET button
If an error display other than the ones described above appears, press the [RESET] button.
When the [RESET] button is pressed, frequencies of TV/radio stations, titles, etc. stored in
memory are cleared.
ERROR DISPLAY

MAX668RVD -6-
WIRE CONNECTION
iPod connector
Steering wheel
remote control
terminal RCB pin cord
(855-5543-50)
Extension lead
(854-6432-01)
Black
R-CH (Red)
L-CH (White)
R-CH (Red)
L-CH (White)
R-CH (Red)
L-CH (White)
R-CH (Red)
L-CH (White)
R-CH (Red)
L-CH (White)
Rear
Front
Non fader
Sub
Visual OUT (Yellow)
Visual IN (Yellow)
Glay
15A Fuse
(120-0150-00)
Back up(Yellow)
Parking(Light green)
Phone(Blown)
Accessory(Red)
Remote(Blue/White)
Purple
Green
Black
Glay
Red
RGB input
connector
(Navigation)
TV tuner input terminal
DVD changer input terminal
Optical output terminal
Radio
antenna jack
CCD connector
CeNET
connector
TV
IN DVD A/C
IN
VTR
81
1
9
6 5
5
6
2
2
3 4
3
4
10
7
7
12
13
36
5
4
710
11 12
9
8
CeNET Connector
RGB Connector
1
2
3
4
5
6
7
8
9
10
11
12
13
GND
BUS B/U
L-CH(+)
NAVI(-)
NAVI(+)
BUS(+)
R-CH(+)
R-CH(-)
SYS-ACC
BUS(-)
L-CH(-)
ILLUMI
N.C.
1098
7654
123
iPod Connector
AV Connector
CCD Connector
1
2
3
4
5
6
7
8
9
10
REAR(L)
REAR(R)
FRONT(L)
FRONT(R)
S-GND
S-GND
NF(L)
NF(R)
S-GND
S-GND
11
12
13
14
15
16
17
18
19
20
SUB(L)
SUB(R)
V-OUT-GND
V-GND
V-OUT
VTR-IN
VTR-SG
VTR-SG
VTR(L)
VTR(R)
1
2
3
4
5
6
7
8
SEL2
N.C.
N.C.
V-IN
N.C.
N.C.
V-GND
N.C.
1
2
3
4
5
6
7
8
9
10
AUDIO-L
AUDIO-R
A RETURN
ACC IDENT
ACC DET
IPOD-AV
AV-IPOD
D/FW GND
3.3V
F/W-PWR
1
2
3
4
5
6
7
8
NAVI-B
NAVI-SYNC
NAVI-R
N.C.
N.C.
NAVI-G
N.C.
N.C.
21 3
8
654
7
2
1
4
3
6
5
8
7
10
9
1214161820
1113151719 ABCDEFGH
IJ
Main connector ISO connector
KLMNOP
Main Connentor
I
J
K
L
M
N
O
P
REAR L-CH(-)
PHONE MUTE
ACC
N.C.
AMP-REM
ILL
PKB
GND
A
B
C
D
E
F
G
H
B-7
B-6
B-5
B-3
B-4
B-1
B-2
A-4
B-8
---
A-7
---
A-5
A-6
---
A-8
GRN
WHT/BLK
WHT
GRY
GRY/BLK
PUR
PUR/BLK
YEL
GRN/BLK
BRN
RED
---
BLU/WHT
ORN/WHT
L.GRN
BLK
REAR L-CH(+)
FRONT L-CH(-)
FRONT L-CH(+)
FRONT R-CH(+)
FRONT R-CH(-)
REAR R-CH(+)
REAR R-CH(-)
BACK UP(15A)
B-2 B-1
B-3B-4A-4
A-5 B-5B-6
A-7A-8 B-8 B-7
A-6
ISO connector
12
345
678

MAX668RVD
-7-
EXPLANATION OF IC
052-7084-00 uPD70F3339GJ-UEN-A System Controller
TerminalDescription
pin 1: A Vref 0 : - : Reference voltage for the internal ADC.
pin 2: A VSS : - : Negative voltage supply for analog section.
pin 3: SYS ACC : O : ACC detect signal output.
pin 4: SYS MUTE : O : System muting signal output.
pin 5: A Vref 1 : - : Reference voltage for the internal DAC.
pin 6: RDS CLK :IN: RDS clock pulse input.
pin 7:AV ON :O :The ON command output to the power
supply section.
pin 8: FLASH :IN: The signal input for the flash memory con-
trol.
pin 9: VDD : - : Positive voltage supply.
pin 10: REG C : - : The capacitor connection.
pin 11: GND : - : Ground.
pin 12: X in :IN: Crystal connection.
pin 13: X out : O : Crystal connection.
pin 14: RESET :IN: Reset signal input.
pin 15: XT I :IN: Oscillation terminal.
pin 16: XT O : O : Oscillation terminal.
pin 17: POWER KEY :IN: Power key input.
pin 18: BU 9V DET :IN: Backup 9V detection.
pin 19: BU 6V DET :IN: Backup 6V detection.
pin 20: NU :IN: Not in use.
pin 21: OSD INT :IN: The interrupt signal input for the on
screen display.
pin 22: TUN SDA :I/O:I2BUS serial data input/output for the tun-
er pack.
pin 23: TUN SCL : O : I2BUS serial clock output for the tuner
pack.
pin 24: TP REQ :IN: The request signal from the touch panel
micro computer.
pin 25: ipod/FLASH O : O : Serial data output to ipod or flash memo-
ry.
pin 26: ipod/FLASH IN :IN: Serial data input from ipod or flash mem-
ory.
pin 27: TP RST : O : The reset pulse output to the touch panel
micro computer.
pin 28: DIMMER : O : PWM output.
pin 29: Motor Pulse :IN: Motor pulse input.
pin 30: NAVI ON : O : NAVI ON signal output.
pin 31: IE BUS TX : O : IE Bus serial data output.
pin 32:IE BUS RX :IN: IE Bus serial data input.
pin 33: GND : - : Ground.
pin 34: E VDD : - : Positive voltage supply.
pin 35: DSP SDA :I/O:The serial data input/output for the digital
signal processor.
pin 36: DSP SCL : O : SCL output to the digital signal processor.
pin 37: MOTOR 1 F : O :The forward command output to the slide
motor.
pin 38: MOTOR 1 R : O : The reverse command output to the slide
motor.
pin 39: NU : O : Not in use.
pin 40: NU : O : Not in use.
pin 41: OFFSET DET :IN: The emergency signal input from the pow-
er IC.
pin 42: Amp Standby : O : Standby signal output to internal amplifi-
er.
pin 43: NU :IN: Not in use.
pin 44: NU :IN: Not in use.
pin 45: NU :IN: Not in use.
pin 46: NU :IN: Not in use.
pin 47: NU :IN: Not in use.
pin 48: NU :IN: Not in use.
pin 49: NU :IN: Not in use.
pin 50: NU :IN: Not in use.
pin 51: NU :IN: Not in use.
pin 52: NU :IN: Not in use.
pin 53: IRI :IN: The remote control signal input.
pin 54: NU :IN: Not in use.
pin 55: NU :IN: Not in use.
pin 56: NU :IN: Not in use.
pin 57: NU :IN: Not in use.
pin 58: OSD RST : O : The reset pulse output for the on screen
display IC.
pin 59: TP RX :IN: The serial data input from the touch pan-
el micro computer.
pin 60: TP TX : O : The serial data output to the touch panel
micro computer.
pin 61: DVD TX : O : The serial data output to the DVD mech-
anism.
pin 62: DVD RX :IN: The serial data input from the DVD mech-
anism.
pin 63: W REMCOM :IN: Wired remote controller signal input.
pin 64: BLKO : O : The blanking signal output.
pin 65: VID / RGB : O :L = Video, H = RGB.
pin 66: FL ON : O : The fluorescent light of the LCD ON sig-
nal output.
pin 67: BEEP : O : Beep out.
pin 68: OSD RX :IN: Serial data input from on-screen-display
IC.
pin 69: OSD TX : O : Serial data output to on-screen-display IC.
pin 70: OSD SCK : O : The clock pulse output to the on screen
display IC.
pin 71: OSD CE : O : Chip enable output to on-screen-display
IC.
pin 72: OSD INH : O : Inhibit pulse output to on-screen-display
IC.
pin 73: Freq Sel : O : Oscillation frequency selection signal out-
put.
pin 74: OPN/CL SW :IN: Open/Close switch signal input.
pin 75: EJECT SW :IN: Eject switch signal input.
pin 76: CATS DET :IN: The backup voltage detection for CATS.
pin 77: ROM EN : O : ROM enable signal output.
pin 78: INES ON : O : Inner escutcheon illumination ON signal
output.
pin 79: NU :IN: Not in use.
pin 80: ipod PWR ON : O : ipod power ON signal output.
pin 81: Panel ON : O : LCD panel ON signal output.
pin 82: FAN ON : O : The fan on signal output.
pin 83: TV/OTHER : O : Horizontal sync select. H = TV.
pin 84: FLASH READY :IN: Ready signal input from flash memory.
pin 85: EEP DO : O : The serial data output to the EEP-ROM.
pin 86: CLK out : O : Clock pulse output.
pin 87: EEP CK : O : The clock pulse output to the EEP-ROM.
pin 88: EEP CEO : O : The chip enable signal output to the EEP-
ROM.
pin 89: EEP DI :IN: The serial data input from the EEP-ROM.
pin 90: NU :IN: Not in use.
pin 91: NU :IN: Not in use.
pin 92: NU :IN: Not in use.
pin 93: NU :IN: Not in use.
pin 94: NU :IN: Not in use.
pin 95: OSD DOT 1 : O : Fine-tuning of the horizontal position.
pin 96: OSD DOT 2 : O : Fine-tuning of the horizontal position.
pin 97: CATS EEP CE : O : Chip enable signal output to CATS-EE-
PROM.
pin 98: D IND : O : H = Disk indicator ON.
pin 99: USA/3rd :IN: L = Asia, H = North America.
pin100: Mechanism :IN: H = Matsushita DVD mechanism.
pin101: NTSC/PAL :IN: NTSC/PAL select signal input.
pin102: FLASH WR :IN: The write flag input for the flash memory.
pin103: B VSS : - : Ground for the bus interface section.
pin104: B VDD : - : Positive voltage supply for the bus inter-
face section.
pin105: ILL DET :IN: Illumination ON signal input.
pin106: BUS ILL : O : Illumination-ON signal output for Ce-NET.
pin107: ILL ON : O : The illumination ON signal output.
pin108: BLINK LED : O : Signal output for the LED.

MAX668RVD -8-
pin109:DVD ON 2 : O : DVD ON signal output.
pin110: NU :IN: Not in use.
pin111: DVD RST : O : The reset signal output to the DVD mech-
anism.
pin112: DSP RST : O : Reset pulse output to the DSP IC.
pin113: DSP INIT :IN: The initial finished signal input from the
Radio-Audio-DSP.
pin114: SAMPLE :IN: Not in use.
pin115: NU : - : Not in use.
pin116: AM/FM 8V ON : O : AM/FM 8V ON signal output.
pin117: RDS DATA :IN: RDS serial data input.
pin118: AM/FM 5V ON : O : AM/FM 5V ON signal output.
pin119: iPod DET :IN: iPod connection detection.
pin120: Frnt V Sel 4 : O : Front image signal selection.
Refer Table 1.
pin121: DAC RESET : O : Reset pulse output to DAC. L = reset.
pin122: SUB MUTE : O : Sub-zone audio mute signal output.
pin123: AMP MUTE : O : Muting signal output to the Audio Power
Amplifier.
pin124: NU :IN: Not in use.
pin125: NU : O : Not in use.
pin126: Photo Sens :IN: Slide door open/close signal input.
pin127: Rear V Sel 4 : O : Rear image signal selection.
Refer Table 2.
pin128: Rear V Sel 3 : O : Rear image signal selection.
Refer Table 2.
pin129: NU :IN: Not in use.
pin130: FAN TEMP :IN: The input terminal of the internal ADC to
detect the temperature.
pin131: Rear V Sel 2 : O : Rear image signal selection.
Refer Table 2.
pin132: Rear V Sel 1 : O : Rear image signal selection.
Refer Table 2.
pin133: Frnt V Sel 3 : O : Front image signal selection.
Refer Table 1.
pin134: Frnt V Sel 2 : O : Front image signal selection.
Refer Table 1.
pin135: Frnt V Sel 1 : O : Front image signal selection.
Refer Table 1.
pin136: SEL 3 :IN: The selection signal input.
pin137: NU :IN: Not in use.
pin138: PKB :IN: The parking brake signal input.
pin139: PHONE INT :IN: The telephone interrupt signal input.
pin140: NU : - : Not in use.
pin141: AMP REM DT :IN: Remote controller wire short detection.
pin142: AMP REM O : O : ON signal output to the amplifier.
pin143: AUTO ANT : O : Motor antenna control signal output.
pin144: ACC IN :IN: ACC ON flag input.
Table 1. Front image signal selection
Visual TV DVD DVD A/C CCD
Frnt V Sel 1 ( pin 135 ) L H L L L
Frnt V Sel 2 ( pin 134 ) L L H L L
Frnt V Sel 3 ( pin 133 ) H H H L L
Frnt V Sel 4 ( pin 120 ) H H H L H
Table 2. Rear image signal selection
Visual TV DVD DVD A/C Rear mute
Rear V Sel 1 ( pin 132 ) L H L L L
Rear V Sel 2 ( pin 131 ) L L H L L
Rear V Sel 3 ( pin 128 ) H H H L L
Rear V Sel 4 ( pin 127 ) L L L L H
EXPLODED VIEW/PARTS LIST
Main section
NO. PART NO. DESCRIPTION Q'TY
1 940-8142-10 INNER-ES-ASSY 1
2 ----------- MAIN PWB 1
3 331-4202-00 CONNECT HOLDE 1
4 331-4203-00 CONNECT HOLDER 1
5 331-4205-00 TR-HOLDER 1
6 313-1973-00 HEAT SINK 1
7 714-3006-8B MACHINE SCREW(M3x6) 1
8 074-1194-00 OUTLET SOCKET 1
9 074-1214-00 OUTLET SOCKET 1
10 074-1171-10 OUTLET SOCKET 1
11 714-2608-8B MACHINE SCREW(M2.6x8) 4
12 ----------- TUNER PWB 1
13 880-2091D DSP TUNER 1
14 092-2208-00 ANT-RECEPT 1
15 076-0714-20 PLUG(20P) 1
16 074-1030-00 OUTLET SOCKET(8P) 1
17 075-0385-00 JACK(OPTICAL) 1
18 076-0312-04 PLUG(RCA) 1
19 331-4206-00 CONNECT HOLDER 1
20 714-2604-8B MACHINE SCREW(M2.6x4) 20
21 855-5544-00 RCA PIN CORD 1
22 347-7283-00 FILM 1
23 929-2506-00 DVD MECH 1
24 948-0674-27 TV-SLIDE-MECH 1
25 312-0469-01 LOWER CHASSIS 1
26 312-0472-01 SIDE CHASSIS-L 1
27 312-0471-01 SIDE CHASSIS-R 1
28 312-0470-02 UPPER CHASSIS 1
29 310-1831-00 UPPER CASE 1
30 313-1972-00 HEAT SINK 1
31 309-0823-01 FRONT PLATE 1
32 331-4204-00 FAN HOLDER 1
33 ----------- JOINT PWB 1
34 345-3799-20 RUBBER PART 2
35 039-2706-05 FPC 1
36 331-4106-00 SHIELD CVR 1
37 347-7062-10 LOWER SHEET 1
38 020-3052-00 DC-MOTOR 1
39 780-2614-50 SCREW(M2.6x14) 2
40 780-2604-50 IT SCREW(M2.6x4) 10
41 731-2608-8A TAPTIGHT(M2.6x4) 4
42 716-3504-10 SCREW(M2.6x4) 6
43 714-2610-8B MACHINE SCREW(M2.6x10) 14
44 716-3504-20 SCREW(M2.6x4) 8
45 716-1886-00 DECORATIVE SCREW(M2x3.4) 2
46 746-0935-00 WASHER 2
47 276-0111-00 SETPLATE 1

MAX668RVD
-9-
43 43
43
34
21
20
20
30
40
47
29
40
40 20
14
43
16 18 17 15 43
19
20
28
20
37 36 41
35
23
41
25
42
33
27
20
20 42
39
40
332
10
40
44
1
44
4433 20
31
42
20 26
20
20
20
44
41
41
44
11
56
89
2
7
4
40
40
33
24
46
45
45 46
38
42
12
13 22

MAX668RVD -10-
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
Escutcheon section
1 370-6230-01 ESCUTCHEON 1
2 013-9711-00 T/P SWITCH 1
3 347-7038-20 SPACER 2
4 347-7423-00 SPACER 2
5 347-7042-20 DOUBLE FACE 2
6 331-4052-01 LCD-HOLDER 1
7 379-0467-00 TFT(LCD) 1
8 948-0767-00 REAR-CVR-ASSY 1
8-1 331-4051-02 REAR-CVR 1
8-2 335-7074-00 ROLLER 2
8-3 750-6746-00 ROLLER SPRING 2
9 716-1851-00 SCREW(M2x3) 2
10 039-1742-00 PWB 1
11 716-1611-50 SCREW(M2.6x4) 4
12 780-2003-03 SCREW(M2x3) 12
13 039-2808-05 FPC 1
14 335-7846-00 IR-FILTER 1
15 382-7966-00 BUTTON(PWR) 1
16 382-7967-00 BUTTON(OP/CL) 1
17 382-7968-01 BUTTON(TA) 1
18 382-7969-00 BUTTON(ADJ) 1
19 382-7970-00 BUTTON(PLAY) 1
20 382-7971-00 BUTTON(SEARCH) 1
21 382-7972-01 BUTTON(BAND) 1
22 382-7973-01 BUTTON(MAP/MENU) 1
23 382-7974-01 BUTTON(SRC) 1
24 382-7975-00 BUTTON(-/+) 1
25 382-7976-01 BUTTON(VOICE) 1
26 778-2004-01 PAD SCREW(M1.7x5) 8
27 347-8071-00 FILM 1
28 371-5859-01 SIDE-TRIM(R) 1
29 371-5860-00 SIDE TRIM(L) 1
30 335-7847-00 ILLUMI PLATE 1
31 039-2809-05 FPC 2
32 ----------- SWTCH PWB 1
33 ----------- LCD PWB 1
34 347-8068-00 DOUBLE FACE 2
35 347-8069-00 DOUBLE FACE 2
36 347-8070-00 DOUBLE FACE 1
37 347-8072-00 FILM 1
38 347-8078-00 EARTH FILM 1
39 347-8084-00 FILM 2
40 331-3672-11 SHIELD CASE 1
2928
12
12 30 39
19
15 32 26
37 6
5
31
26
2726
16
14
17
18
36
12
39
20
21
38
35
22
23
24
25
2
34
7
40
33
12 8-1
8
8-2 8-3 1110 9
13
11
8-2
8-3
12
12
12
34
1
