Clarion PN-2955H-A User manual

PN-2955H-A
-1-
Service Manual
Published by Service Dept.
Printed in Japan
ClarionCo.,Ltd.
7-2,Shintoshin,Chuo-ku,Saitama-shi, Saitama 330-0081Japan
ServiceDept.: 7-2,Shintoshin,Chuo-ku, Saitama-shi, Saitama330-0081Japan
Tel:[phone] FAX:[phone]
298-6542-00 Feb.2008
Model
NISSAN Motor Genuine
6CD AM/FM Radio Combination
PN-2955H-A
(Genuine No.28185 1AA0A)
(ID No. CY25D)
NOTES
* The tuner of this unit is BUS-TUNER type. When the
tuner pack(BL101) is exchanged, it is necessary to ad-
just for S-meter etc. with special JIG.
* Individual data of each unit is recorded in EEPROM
IC(IC401). When EEPROM IC is replaced, it is neces-
sary to write the data.
* DSP IC(IC301) is fixed with solder. Special JIG is nec-
essary for removing it.
* This product includes technology owned by Microsoft
Corporation and cannot be used or distributed without a
license from MSLGP.
* We cannot supply PWB with component parts in prin-
ciple. When a circuit on PWB has failure, please repair it
by component parts base. Parts which are not mentioned
in service manual are not supplied.
* Specifications and design are subject to change without
notice for further improvement.
CD Player section
Mechanism: 6Disc CD Auto Changer
Disc: 12cm Disc
Format: CD-DA,MP3,WMA
Distortion: Less than 0.2%(1kHz,20kHz L.P.F.)
MP3 sampling rate: 8kHz to 48kHz
MP3 bit rate: 8kbps to 320kBps/VBR
WMA bit rate: 32kbps to 192kBps/VBR
Logical format: ISO9660 Level 1,2
Romeo or Joliet
S/N ratio: More than 74dB
(1kHz,0dB=4.5V,20kHz L.P.F)
Separation: More than 50dB
(1kHz,20kHz L.P.F)
AUX section
Distortion: Less than 0.4%(Input 1kHz 300mV,
Output 2.45V=0dB)
S/N ratio: More than 65dB(Input 1kHz 300mV,
Output 4.5V=0dB)
Separation: More than 52dB(Input 1kHz
300mV[L or R],Output 2.45V=0dB)
General
Load impedance: 2ohm/4CH
Power output: 45W x 4 Type
Power supply voltage: DC13.2V(10.8 to 15.6V)
Negative ground
Back-up consumption: Less than 1.0mA
Dimensions(mm): 242(W) x 145(H) x 190(D)
Weight: 2.4kg
COMPONENT
PN-2955H-A
1. Main unit ---------- 1
SPECIFICATIONS
Radio section
Tuning system: PLL Frequeency synthesizer system
Receive range: AM 530kHz to 1,710kHz
FM 87.75MHz to 107.9MHz
Quieting sensitivity: AM Less than 37dBuV(S/N=20dB)
FM Less than 15dBuV(at 30dB S/N)
Separation: FM More than 25dB
(ANT IN 65dBuV,1kHz)
More than 20dB
(ANT IN 65dBuV,7kHz)
S/N ratio: AM More than 40dB
(ANT IN 74dBuV,0dB=1.4V)
FM More than 50dB
(ANT IN 55dBuV,0dB=1.4V)
Auto tuning stop sensitivity:
AM 39 +6/-6dBuV
FM 32 +6/-6dBuV

PN-2955H-A -2-
To engineers in charge of repair or
inspection of our products.
Before repair or inspection, make sure to follow the
instructions so that customers and Engineers in charge
of repair or inspection can avoid suffering any risk or
injury.
1. Use specified parts.
The system uses parts with special safety features against fire
and voltage. Use only parts with equivalent characteristics
when replacing them.
The use of unspecified parts shall be regarded as remodeling
for which we shall not be liable. The onus of product liability
(PL) shall not be our responsibility in cases where an accident
or failure is as a result of unspecified parts being used.
2. Place the parts and wiring back in their original positions after
replacement or re-wiring.
For proper circuit construction, use of insulation tubes, bond-
ing, gaps to PWB, etc, is involved. The wiring connection and
routing to the PWB are specially planned using clamps to keep
away from heated and high voltage parts. Ensure that they are
placed back in their original positions after repair or inspec-
tion.
If extended damage is caused due to negligence during re-
pair, the legal responsibility shall be with the repairing com-
pany.
3. Check for safety after repair.
Check that the screws, parts and wires are put back securely
in their original position after repair. Ensure for safety reasons
there is no possibility of secondary ploblems around the re-
paired spots.
If extended damage is caused due to negligence of repair, the
legal responsibility shall be with the repairing company.
4. Caution in removal and making wiring connection to the parts
for the automobile.
Disconnect the battery terminal after turning the ignition key
off. If wrong wiring connections are made with the battery con-
nected, a short circuit and/or fire may occur. If extensive dam-
age is caused due to negligence of repair, the legal responsi-
bility shall be with the repairing company.
5. Cautions in soldering
Please do not spread liquid flux in soldering.
Please do not wash the soldering point after soldering.
6. Cautions in soldering for chip capacitors
Please solder the chip capacitors after pre-heating for replace-
ment because they are very weak to heat.
Please do not heat the chip capacitors with a soldering iron
directly.
7. Cautions in handling for chip parts.
Do not reuse removed chips even when no abnormality is ob-
served in their appearance. Always replace them with new
ones. (The chip parts include resistors, capacitors, diodes, tran-
sistors, etc).
Please make an operation test after replacement.
8. Cautions in handling flexible PWB
Before working with a soldering iron, make sure that the iron
tip temperature is around 270 . Take care not to apply the
iron tip repeatedly(more than three times)to the same patterns.
Also take care not to apply the tip with force.
9. Turn the unit OFF during disassembly and parts replacement.
Recheck all work before you apply power to the unit.
10.Cautions in checking that the optical pickup lights up.
The laser is focused on the disc reflection surface through the
lens of the optical pickup. When checking that the laser opti-
cal diode lights up, keep your eyes more than 30cms away
from the lens. Prolonged viewing of the laser within 30cms
may damage your eyesight.
11.Cautions in handling the optical pickup
The laser diode of the optical pickup can be damaged by elec-
trostatic charge caused by your clothes and body. Make sure
to avoid electrostatic charges on your clothes or body, or dis-
charge static electricity before handling the optical pickup.
11-1. Laser diode
The laser diode terminals are shorted for transportation in or-
der to prevent electrostatic damage. After replacement, open
the shorted circuit. When removing the pickup from the mecha-
nism, short the terminals by soldering them to prevent this
damage.
11-2. Actuator
The actuator has a powerful magnetic circuit. If a magnetic
material is put close to it. Its characteristics will change. En-
sure that no foreign substances enter through the ventilation
slots in the cover.
11-3. Cleaning the lens
Dust on the optical lens affects performance.
To clean the lens, apply a small amount of isopropyl alcohol to
lens paper and wipe the lens gently.
CAUTION
Use of controls, adjustment, or performance of procedures
other than those specified herein, may result in hazardous
radiation exposure. The compact disc player should not be
adjusted or repaired by anyone except properly qualified
service personnel.
SERIAL NO.
MANUFACTURED
AM:
PART No.
FM:
FREQUENCY RANGE
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC
RULES. OPERATION IS SUBJECT TO THE FOLLOWING
TWO CONDITOINS:(1) THIS DEVICE MAY NOT CAUSE
HARMFUL INTERFERENCE,AND(2) THIS DEVICE MUST
ACCEPT ANY INTERFERENCE RECEIVED,INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATION.
THIS PRODUCTION COMPLIES WITH DHHS RULES 21 CFR
SUBCHAPTER J APPLICABLE AT DATE OF MANUFACTURE.
MODEL NO.
12V(-)GROUND
This product includes technology oned by
Microsoft Corporation and cannot be used or distributed
without a license from MSLGP.
ongguan Clarion Orient Electronics Co.,Ltd.
Junda Industrial Zone,Dong Keng Industrial Road,Dong Keng
Town Dongguan,Guangdong Province 511734,The People's
Republic of China
MADE IN CHINA
MOUNT SCREW
M5X8 mm MAX
ISO
Setplate
Top of view

PN-2955H-A
-3-
CONNECTIONS
ANT101 (GT13)
ANT Connector
Rear View
CBAh11 h12 h13 h14 h15h16
h17 h18 h19 h20 h21h22
J602 (TH12)
M-CAN Connector
(for Display unit)
J601 (A12)
N-BUS Connector
(for Satellite radio)
V02 V04 V10 V12
V01
V03V05 V06V07 V08V09V11
123456789
19 10 111213141516 17 18 20
J501 (TH18 )
Main Connector
No. Pin Name
A
B
C
ANT+B
MAIN ANT
SUB ANT
No. Pin Name
h11
h12
h13
h14
h15
h16
h17
h18
h19
h20
h21
h22
M CAN (-)
M CAN (+)
N.C.
N.C.
N.C.
N.C.
M CAN SHIELD
GND
N.C.
N.C.
N.C.
GND
No. Pin Name
V1
V2
V3
V4
V5
V6
V7
V8
V9
V10
V11
V12
SAT LCH (-)
SAT LCH (+)
SAT RCH (-)
SAT RCH (+)
GND
SHIELD GND
N.C.
REQ(SAT->COMBI)
RXD(SAT->COMBI)
TXD(COMBI->SAT)
N.C.
N.C.
No. Pin Name
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
N.C.
FRONT LCH (+)
FRONT LCH (-)
REAR LCH (+)
REAR LCH (-)
STRG SW A
ACC
ILL CONT
ILL (+)
B/U
GND
FRONT RCH (+)
FRONT RCH (-)
REAR RCH (+)
REAR RCH (-)
STRG GND
STRG SW B
N.C.
N.C.
GND
J501
J601
J602
ANT101

PN-2955H-A -4-
DIAGNOSIS
Power off
Self-diagnosis mode
(Mode release: Acc-off)
Self-diagnosis mode
(Mode release: Acc-off)
Click the VOL key 30 times right and left while pressing "1" key.
(1-1) Version check mode
(1-2) Channel check mode
AUDIO key
AUDIO key(for several seconds)
AUDIO key(for several seconds)
or Time out(1second)
AUDIO key
AUDIO key
AUDIO key
AUDIO key
AUDIO key
AUDIO key
AUDIO key
AUDIO key
Version check mode
(1-1) Version check mode
(1) Self-diagnosis mode
Software version
Software version display
Item
Hardware version
CD mech. software version
EEP version
Display software version
Display hardware version
Satellite radio version
(1-2) Channel check mode
Channel check mode
Front Left (Beep 1.0kHz/1sec.)
Front Right (Beep 1.0kHz/1sec.)
Rear Right (Beep 1.0kHz/1sec.)
Rear Left (Beep 1.0kHz/1sec.)
Version
"VFFFFFF" : Unconnection
Front Left check display
*In the button check mode, when each key is operated, the key name is displayed.
The beep sound(3.5kHz) rings when the key is operated.
(1-3) Button check mode
TUNE/FOLDER down check display
Turn TUNE/FOLDER key right
(1-3) Botton check mode
AUDIO key(for several seconds)
Turn TUNE/FOLDER key left

PN-2955H-A
-5-
Click the VOL key 30 times right and left while pressing "6" key.
AUDIO key
AUDIO key
AUDIO key
AUDIO key
AUDIO key
AUDIO key
Error record display mode
Error record reset mode
"AV TROUBLE DEL"
M-CAN transmission count display
"TRANSMIT $$ ##"
M-CAN transmission count display
TRANSMIT $$ ##
CMF reception error from Display
"DISP $$ ##"
MPDT error from display
"DISP MPDT $$ ##"
TRACK >>| key After 6 sec.
TRACK >>| key |<< SEEK key
(The record is cleared)
"RECORD DEL-NO?"
"RECORD DEL-YES?#"
CMF reception error from BTHF
"BTHF $$ ##"
MPDT error from BTHF
"BTHF MPDT $$ ##"
Error record rest mode (2-2)
"NO HISTORY BTHF"
(at BT unconnection)
"##"
Past diagnosis result:
"OK" / "0" - "39" (NG counter)
"$$"
Current diagnosis result: "OK" / "UN"
Error record reset display
RECORD EDL Y ?#-ES
"#"
Countdown time: "6" - "0"
Power off
Communication
diagnosis mode
(Mode release: Acc-off)
(2-1) Error record display mode
(2-2) Error record reset mode
AUDIO key
AUDIO key AUDIO key
(2-1) Error record display mode
(2) Communication diagnosis mode
(2-2) Error record reset mode

PN-2955H-A -6-
*SEEK/TRACK UP key (Type number 01>02...)
SEEK/TRACK DOWN key (Type number 20>19...)
SEEK/TRACK UP key
or SEEK/TRACK DOUN key
SEEK/TRACK UP key
or SEEK/TRACK DOUN key
(3-2) Counter display mode
(3-3) Record deletion mode
Count display
Counter display mode T## $$$$ $
Record deletion mode
"$$$$$$" : Counter
00000 - 65535(Max)
"T##" : Type number
00: Rest
01: Disck check
02: Disc chuking
03: Store
04: Eject
05: Total storage
06: Total exhaust
07: CD error
08: Mech error
09: Communication error
10: Other error
11: Store failure
12: Detection of disk on the back
13: interrupt of sound
14: (Reserve)
15: (Reserve)
Push AM-FM key, "1" key and "5" key
at the same time for three seconds.
Record deletion display
EEP CL #
Record deletion display "#" : Time until deleting record
3: 3sec.
2: 2sec.
1: 1sec
-: Deletion end
"EEP" : EEPROM(fix)
Turn on power while pushing the DISC key, "1" key and "6" key at the same time.
(3-1) Error record display mode
Error record display
*Recorded data is 20 or less. The old data is deleted.
H## A! $$$
"$$$" : Error code
1xx: CD error
2xx: Communication error
3xx: Mechanism error
4xx: Other error
---: No error record
"A"
First error after B/U-ON
and ACC-ON
"!"
Disc number when
error occurs (1 - 6)
"H##" : Error No.
H01(new) - H20(old)
Power off
(3-1) Error record display
mode
(3-2) Counter display
mode
(3-3) Record deletion
mode
(3-4) Last mode "2" key
(for two seconds)
DISC key (for two seconds)
DISC key (for two seconds)
"3" key
(for two seconds)
Time out (after three seconds)
Time out (after three seconds)
Time out
(after 30 seconds)
Time out
(after 30 seconds)
POWER key
(3) CD mechanism error record mode
Counter display
*SEEK/TRACK UP key (Error No. 01>02...)
SEEK/TRACK DOWN key (Error No. 20>19...)
Error record display mode
Error record display

PN-2955H-A
-7-
Push a key for two minutes.
The key locks.
The error counter of the key is displayed.
When the VOL key is clicked to the right,
it moves to the next item(key).
When the VOL key is clicked to the left,
it moves to the previous item(key).
The detection result of the message to
exceed the message buffer is displayed.
(4-2) Key error record mode
(4-3) Record deletion mode
Key error record display
Key error record mode @@@@@@@@@@@@ L##
Record deletion mode
"L##" : Key lock counter
00 - FF (hexadecimal number)
"@@@@...." : Selected key name
"YES" displays to click the VOL key
to the right.
"NO" displays to click the VOL key
to the left.
Record deletion display
ALL EDL? ><@@@
Record deletion display
"@@@"
YES: The record is deleted at the time ofACC-OFF.
NO: The record is not deleted.
(4-1) Software error record mode
Software error record display
M-BUFF ####
"####" : Error counter
0000 - FFFF (hexadecimal number)
"M-BUFF" : Menu name (fix)
Power off
(4-1) Software error record mode
(4-2) Key error record mode
(4-3) Record deletion mode
AUDIO AUDIO
AUDIO
AUDIO key (for two seconds)
AUDIO key (for two seconds)
(4) Software error record mode
Key error record display
Click the VOL key 30 times right and left while pressing AUDIO key.

PN-2955H-A -8-
(5-2) Clock signal mode
(5-3) Illumination signal mode
Clock signal mode display
CLOCK @@ : # :$#$
"@@" : Hour (0 - 12)
"##" : Minute (00 - 59)
"$$" : Second (00 - 58) * two sec step
Illumination signal display
ILL %
###@@@
"@@@"
YES: Illumination signal detection
NO: Illumination signal undetection
"###"
Illumination pulse (0 - 100)
(5-4) Speed information mode
Speed information display
SPE ED H/MK###
"###"
Speed (0 - 250)
(5-5) External output diagnosis
RAM situation mode
RAM situation display
AD ####
####
@@
"####" : Address (0000 - FFFF)
*hexadecimal number "@@" : ARAM value (00 - FF) *hexadecimal number
(5-1)External Input diagnosis/
Mini Jack signal mode
Mini Jack signal display
MINI JACK @@
"@@"
OK (Connected) / NG (Unconnected)
Power off
(5-1) External Input diagnosis/
Mini Jack signal mode
(5-2) Clock signal mode
AUDIO
(5-3) Illumination signal mode
AUDIO
(5-4) Speed information mode
AUDIO
(5-5) External output diagnosis
RAM situation mode
AUDIO
AUDIO
(5) External input/output diagnosis
Turn on power while pushing the "1" key, "3" key and "5" key at the same time.
*Mode release: Acc-off
RAM situation of the specified address
(value) is displayed.
When the AUDIO key is pushed, the digit of the address is switched.
When the VOL key is clicked to the right, it moves to the next address.
When the VOL key is clicked to the left, it moves to the previous address.
RAM situation mode
RAM situation display
Push AUDIO key
##0# ##1#
Click VOL key to the right
##0# ##1#
Click VOL key to the left

PN-2955H-A
-9-
TROUBLESHOOTING
B/U 5V line(IC505)
ACC DET line(Q513)
Power does not turn on
B/U,ACC
Power Supply
1CHECK ITEM CHECK POINT
B/U DET line(IC506)
RESET IC(IC404)
System
Reset
2
X401:10MHz
Microcomputer
Clock
3
SYS-ON signal of IC402 (pin 9)
SYS 5V line(Q508)
System
Power Supply
4
Output wave form of pins 17(M-CAN RX) and
18(M-CAN TX) of IC 402
IC403
Display line5
M-CAN
Trancever
6
TUN 9V(Q105)
TUN 5V(IC101)
Radio does not work
CD player does not work
Tuner
Power Supply
1CHECK ITEM CHECK POINT
Pins 5-11 of BL101
DSP Line2
Pins 13,14,28 and 29 of BL101
Output
of Tuner
3
Parameter adjustment
(with special jig)
Parameter
of DSP
4
Pins 38,39,43 and 44 of IC301
Output
Wave Form
5
Pins 11,12,14 and 15 of IC504
Input of
power IC
6
Power-IC IC504
Output of
power IC
7
Around power IC(IC504)
8
Pins 11,12,14 and 15 of IC504
Input of
power IC
Power-IC IC504
Output of
power IC
Around power IC(IC504)
Pins 33 and 34 of IC301
CD mechanism
line
2
CHECK ITEM CHECK POINT
Pin 8 of J201
CD-SPDIF
Output
3
CD 9V line(IC202)
CD 3.3V line(IC201)
CD mechanism
Power Spply
1
Pins 38,39,43 and 44 of IC301
Output
wave form
of DSP
4
5
6
7
(9) Audio ON mode
Power off
Turn on power while pushing the "2" key and "4" key
at the same time.
(6) Fail safe mode
Acc on
Fail safe mode (Key lock)
When a key is pressed for two minutes or more,
it becomes the key lock.
*The key lock is recorded (4-2 Key error record mode)
*The steering wheel remote control key also
(7) Changer mode
Changer mode
*Mode release: Acc-off
Power off
Audio ON mode
*Audio operates normally even if the indicator is removed.
*Mode release: Acc-off
Power on
Push the AUDIO key for ten seconds.
(8) Loud flat mode
Loud flat mode
*Mode release: Acc-off
Click the VOL key 30 times right and left while pressing
"3" key.

PN-2955H-A -10-
BLOCKDIAGRAM
ANT-ON
䌍䌁IN ANT 䌍䌁IN
㪪㪬㪙
SUB ANT
ESCUTCHEON
IF
N-BUS
FR-L
FR-R
RR-L
RR-R
Digital
B/U
ACC
ILL+
ILL-
J602 J501 J701
SAT L/R
GND
SHIELD GND
REQ,RXD,TXD
J601
ILL+
STRG SW A STRG SW B
STRG GND
2 3 11 12 4 5 14 13
19
7 9 8 6
V01, 2,3,4 V05
16
V08 V09 V10 V06
Q505
SYS 12V
POWER SUPPLY
20
GND 10 SHIELD
CD-3.3V CD-9V
+B
IC202
CD 9V
ILL- 15
L S-GND R AUX-ON
3.5mm Mini-Jack
AUX
ANT101 ANT RECEPT
DSP-3.3V
Q503
SYS 9V
IC505
VDD 5V
SW-REG
IC501
DSP 3.3V
B/U
FIL
Q508
SYS 5V
Q105
TUNER 9V
IC503
1/2SYS 9V
IC101
TUNER 5V
IC201
CD 3.3V
Q301
DSP 1.8V
IC504
POWER IC
IC502
20K
LPF
h12 h11
M CAN - M CAN + M CAN SHIELD h17
IC405
AUX IN
Q513 ACC-DET
Q512 ILL+
ILL-
REMOCOM
IC402
AUDIO-CPU
IC401
EEPROM
IC404
RESET
CD-EJ
LOAD
PWR-SW
VOL KEY
N-BUS-I/F
GUIDE-ILL
IC406
CLOCK
BL101
AM/FM
TUNER
Q101
ANT-ON
6CD
MECH
MODULE
IC301
DSP
VOLUME, BASS,TREBLE
BALANCE,FADER
LOUDNESS,EQ
DSP-1.8V
IC403
CAN
TRANCEVER
CD-INDICATOR

PN-2955H-A
-11-
EXPLANATION OF IC
052-3205-10 M30873MHA-C10GP System Controller
Terminal Description
pin 1: ILL PULSE :IN: Illumination control signal input.
pin 2: NU : - : Not in use.
pin 3: ST SDO : O : Sub-tuner serial data output.
pin 4: ST SCL : O : Sub-tuner serial clock output.
pin 5: BU DET :IN: Backup detection signal input.
pin 6: GND : - : Ground.
pin 7: CN VSS :IN: Connect to VSS via a resistor.
pin 8: ILL ON :IN: Illumination ON signal input.
pin 9: SYS ON : O : System ON signal output.
pin 10: RESET :IN: Reset signal input.
pin 11: X out : O : Crystal connection.
pin 12: VSS : - : Negative voltage supply.
pin 13: X in :IN: Crystal connection.
pin 14: VDD : - : Positive voltage supply.
pin 15: NMI :IN: Nonmaskable interrupt. Connect to VDD
via a resistor.
pin 16: ACC IN :IN: ACC ON flag input.
pin 17: M CAN RX :IN: M-CAN serial data input.
pin 18: M CAN TX : O : M-CAN serial data output.
pin 19: PLL DO : O : PLL serial data output.
pin 20: NU : - : Not in use.
pin 21: TIME BASE :IN: Time base pulse input.
pin 22: NU : - : Not in use.
pin 23: PLL CE : O : PLL chip enable signal output.
pin 24: DIMMER/6CD-SL:O : 6CD SLOT LED control.
pin 25: PLL CK : O : PLL clock pulse output.
pin 26: DISPLAY ON : O : Display on signal output.
pin 27: DSP SCL : O : Clock pulse output to the DSP IC.
pin 28: DSP SDA :I/O:Serial data input/output for the digital sig-
nal processor.
pin 29: NDS/FLASH TX : O : NDS serial data output for NDS and Flash
memory.
pin 30: NDS/FLASH RX :IN: NDS serial data input for NDS and Flash
memory.
pin 31: NDS-Req1/FLCK:IN: NDS request input / Flash clock input.
pin 32: FLASH BUSY : O : Flash memory busy signal output.
pin 33: 6CD SDA :I/O:Serial data input/output.
pin 34: 6CD SCL : O : Serial clock output.
pin 35: NU : - : Not in use.
pin 36: NU : - : Not in use.
pin 37: NU : - : Not in use.
pin 38: 6CD RESET : O : Reset pulse output.
pin 39: 6CD-RQ/F-EPM :IN: 6CD request input / Flash EPM.
pin 40: GIX SYS ACC : O : 6CD-mechanism system ACC control.
pin 41: NU : - : Not in use.
pin 42: NU : - : Not in use.
pin 43: MAIN FIX : O : Main fix signal output for Diversity system.
pin 44: FLASH CE : O : Flash memory Chip enable.
pin 45: KS 3 : O : Key scan output.
pin 46: KS 2 : O : Key scan output.
pin 47: KS 1 : O : Key scan output.
pin 48: KS 0 : O : Key scan output.
pin 49: KS in 3 :IN: Key scan input.
pin 50: KS in 2 :IN: Key scan input.
pin 51: KS in 1 :IN: Key scan input.
pin 52: KS in 0 :IN: Key scan input.
pin 53: Power IC Stndb : O : The standby signal output to the power IC.
pin 54: NU : - : Not in use.
pin 55: NU : - : Not in use.
pin 56: M-VOL 2 :IN: Main volume control pulse input.
pin 57: M-VOL 1 :IN: Main volume control pulse input.
pin 58: A-VOL 2 :IN: Audio volume control pulse input.
pin 59: A-VOL 1 :IN: Audio volume control pulse input.
pin 60: VDD : - : Positive voltage supply.
pin 61: POWER ON :IN: Power ON signal input.
pin 62: GND : - : Ground.
pin 63: NU : - : Not in use.
pin 64: MINI J ON :IN: AUX mini jack detection.
pin 65: NU : - : Not in use.
pin 66: MT SCK : O : Main-tuner control clock.
pin 67: MT SDO : O : Main-tuner control data.
pin 68: FAN ON : O : The fan on signal output.
pin 69: AMP ON : O : Audio power amplifier ON signal output.
pin 70: Speed Pulse :IN: Speed pulse input.
pin 71: NU : - : Not in use.
pin 72: RDS CK 1 :IN: RDS clock input from Main-tuner.
pin 73: RDS DA 1 :IN: RDS 1 serial data input. (Main-tuner)
pin 74: NU : - : Not in use.
pin 75: AF MUTE : O : Audio frequency signal muting.
pin 76: MT AGC :IN: Main tuner AGC.
pin 77: ST AGC :IN: Sub tuner AGC.
pin 78: DSP RESET : O : Reset signal output to the DSP IC.
pin 79: MT S METER :IN: Input of internal A/D converter to monitor
the radio field strength for the Main-tun-
er.
pin 80: ST S METER :IN: Input of internal A/D converter to monitor
the radio field strength for the Sub-tuner.
pin 81: MT MUTE : O : Main-tuner mute output.
pin 82: ST MUTE : O : Sub-tuner mute output.
pin 83: PHONE ON : O : Phone ON signal output.
pin 84: PHONE OFF : O : Phone OFF signal output.
pin 85: NU : - : Not in use.
pin 86: TEL ON :IN: Telephone ON signal input.
pin 87: CD EJECT :IN: CD eject signal input.
pin 88: LOAD SW :IN: LOAD switch signal input.
pin 89: MT HOLD :IN: AF-hold-signal input from the Main-tuner.
And S-hold signal input from the DSP.
pin 90: ST HOLD :IN: AF-hold-signal input from the Sub-tuner.
And M-hold signal input from the DSP.
pin 91: MT SAMPLE :IN: Main-tuner sample input.
pin 92: ST SAMPLE :IN: Sub-tuner sample input.
pin 93: REMO B :IN: Steering wheel remote controller signal
input.
pin 94: A GND : - : Analog ground.
pin 95: REMO A :IN: Steering wheel remote controller signal
input.
pin 96: VREFI :IN: Reference voltage input.
pin 97:A VCC : - : Positive voltage supply for the internal
analog section.
pin 98: EEP CK : O : EEP-ROM clock pulse out.
pin 99: EEP DO : O : Serial data output to EEP-ROM.
pin100: DSP PAUSE :IN: DSP automatic mute control.

PN-2955H-A -12-
051-3396-90 NJM2386ADL3-33-TE1
Positive Voltage Regulator 3.3V
051-3516-90 S-1132B33-U5T1G
Positive Voltage Regurator 3.3V
051-3517-90 impossible of exchange (LT3481EMSE#TRPBF)
Step-Down Switching Regulator
Terminal Description
BD (Pin 1):
This pin connects to the anode of the boost Schottky diode.
BOOST (Pin 2):
This pin is used to provide a drive voltage, higher than the input
voltage, to the internal bipolar NPN power switch.
SW (Pin 3):
The SW pin is the output of the internal power switch. Connect this
pin to the inductor, catch diode and boost capacitor.
VIN (Pin 4):
The VIN pin supplies current to the LT3481's internal regulator and
to the internal power switch. This pin must be locally bypassed.
RUN/SS (Pin 5):
The RUN/SS pin is used to put the LT3481 in shutdown mode. Tie
to ground to shut down the LT3481. Tie to 2.3V or more for nor-
mal operation. If the shutdown feature is not used, tie this pin to
the VIN pin.
PG (Pin 6):
The PG pin is the open collector output of an internal comparator.
PG remains low until the FB pin is within 10% of the final regula-
tion voltage. PG output is valid when VIN is above 3.5V and RUN/
SS is high.
BIAS (Pin 7):
The BIAS pin supplies the current to the LT3481's internal regula-
tor. Tie this pin to the lowest available voltage source above 3V
(typically VOUT). This architecture increases efficiency especially
when the input voltage is much higher than the output.
FB (Pin 8):
The LT3481 regulates the FB pin to 1.265V. Connect the feedback
resistor divider tap to this pin.
VC (Pin 9):
The VC pin is the output of the internal error amplifier. The volt-
age on this pin controls the peak switch current. Tie an RC net-
work from this pin to ground to compensate the control loop.
RT (Pin 10):
Oscillator Resistor Input. Connecting a resistor to ground from this
pin sets the switching frequency.
Exposed Pad (Pin 11):
Ground. The Exposed Pad must be soldered to PCB.
051-5417-38 R3112N271A-TR-FA
Precision Vlotage Down Detector 2.7V
Terminal description
pin 1: OUTPUT : N channel open drain output.
This terminal will output L, if the voltage of
VDD becomes lower than the setting voltage.
pin 2: VDD : Positive supply voltage.
pin 3: GND : Ground.
pin 4: N.C. : Not in use.
pin 5: CD : Delay time capacitor.
5
4
3
2
1
Ground
N.C.
Power Outut
Control in, H = ON.
VCC
3
1
2
3
5
4
Vin
Ground
Control (H= On)
Vout
Ground
No Connectin
RT
VC
FB
BIAS
PG
10
9
8
7
6
BD
BOOST
SW
VIN
RUN/SS
1
2
3
4
5
TOP VIEW
11
1
2
3
5
4
CD
N.C.
OUTPUT
VDD
GND
+
-
Vref
OUTPUT1
GND3
VDD2
CD5N.C.4

PN-2955H-A
-13-
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
2
1
3
9
9
7
8
5
6
10
4
9
EXPLODED VIEW/PARTS LIST
Escutcheon section
1 947-0695-01 BACK PLATE-ASSY 1
2 370-6291-00 ESCUTCHEON 1
3 380-5705-00 KNOB 2
4 ----------- SWITCH PWB 1
5 016-0018-23 VR W/SHAFT(VOL) 1
6 016-0024-07 VR W/SHAFT(TUN/FOL) 1
7 074-3013-74 OUTLET SOCKET 1
8 075-0390-00 JACK 1
9 716-0778-52 SCREW(M2x8) 15
10 345-6126-00 CUSHION RUBBER 1

PN-2955H-A -14-
11
14
14
16
7
6
8
9
10 9
3
14
21
18
4
19
19
19
24
26 20
17 21 22
23
19
28 24
4
27
25
29
4
4
4
14
14 15
15
14
5
14
14
14
12 13
Main section
1 ----------- MAIN PWB 1
2 074-1237-69 OUTLET SOCKET 1
3 311-1914-00 LOWER CASE 1
4 716-0878-50 SCREW(M2.6x5) 5
5 309-0846-00 ES PLATE 1
6 929-0390-81 CD-CHANG-MODULE 1
7 331-4091-10 6CD BRKT(L) 1
8 331-4092-10 6CD BRKT(R) 1
9 716-3552-00 SCREW(M2.3x2.5) 6
10 816-4024-50 FLAT WIRE 1
11 310-1823-10 UPPER CASE 1
12 313-1968-00 HEAT SINK 1
13 735-2614-1B D-SEMS SCREW(M2.6x14) 2
14 714-2606-8B MACHINE SCREW(M2.6x6) 17
15 716-1553-50 SCREW(M3x8) 4
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
16 276-0066-04 SETPLATE 1
17 076-0478-59 PLUG 1
18 076-3011-74 PLUG 1
19 073-0762-90 TERMINAL 5
20 074-4009-20 OUTLET SOCKET 1
21 074-1013-00 OUTLET SOCKET(A12) 1
22 074-1302-12 OUTLET SOCKET(TH12) 1
23 092-2210-00 ANT-RECEPT 1
24 778-3006-00 TAP-SCREW(3x6) 4
25 307-0731-00 REAR PLATE 1
26 331-4454-00 TR-HOLDER 1
27 716-1494-50 IT SCREW(M2.6x6) 1
28 880-2026L TUNER PACK 1
29 345-5805-01 GASKET 1

PN-2955H-A
-15-
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
ELECTRICAL PARTS LIST
Main PWB(B1) section
ANT101 092-2210-00 ANTENNA RECEPT
BL101 880-2026L TUNER PACK
C101 168-2222-55 2200pF K
C103 166-1511-50 150pF CH
C105 163-1063-35 16V 10uF
C106 166-2201-50 22pF CH
C107 043-0319-51 200P
C108 168-2222-55 2200pF K
C109 168-1022-55 1000pF K
C110 168-1022-55 1000pF K
C111 168-1022-55 1000pF K
C112 168-1022-55 1000pF K
C113 163-1073-35 16V 100uF
C114 168-2222-55 2200pF K
C115 168-1022-55 1000pF K
C116 168-1022-55 1000pF K
C117 168-1022-55 1000pF K
C118 163-1073-35 16V 100uF
C119 163-4763-35 16V 47uF
C120 168-1042-78 16V 0.1uF
C121 168-1042-78 16V 0.1uF
C123 163-1073-35 16V 100uF
C124 163-1063-35 16V 10uF
C202 178-1052-78 1uF
C203 178-3342-78 0.33uF
C205 163-2273-25 10V 220uF
C206 168-1042-78 16V 0.1uF
C207 042-0579-51 16V 10uF
C208 042-0579-51 16V 10uF
C209 168-1042-78 16V 0.1uF
C210 163-3373-15 6.3V 330uF
C301 166-1811-50 180pF CH
C302 168-1042-78 16V 0.1uF
C303 163-4753-65 50V 4.7uF
C306 168-1042-78 16V 0.1uF
C307 168-1042-78 16V 0.1uF
C308 166-8097-50 8pF C CH
C309 166-8097-50 8pF C CH
C310 168-1022-55 1000pF K
C311 168-1022-55 1000pF K
C312 168-1022-55 1000pF K
C313 168-1022-55 1000pF K
C316 168-1022-55 1000pF K
C317 168-1022-55 1000pF K
C318 168-1042-78 16V 0.1uF
C319 163-4753-65 50V 4.7uF
C320 168-1042-78 16V 0.1uF
C321 163-4753-65 50V 4.7uF
C324 168-1022-55 1000pF K
C325 168-2222-55 2200pF K
C326 163-2273-25 10V 220uF
C327 168-4732-78 0.047uF K
C328 163-2263-35 16V 22uF
C329 168-1042-78 16V 0.1uF
C330 163-3373-15 6.3V 330uF
C331 168-1042-78 16V 0.1uF
C332 168-1022-55 1000pF K
C333 168-1042-78 16V 0.1uF
C334 163-1063-35 16V 10uF
C335 168-1022-55 1000pF K
C336 178-1052-78 1uF
C337 168-3332-78 0.033uF K
C338 168-1022-55 1000pF K
C340 168-1022-55 1000pF K
C343 168-4712-55 470pF K
C344 168-1022-55 1000pF K
C345 163-2263-35 16V 22uF
C346 163-1073-15 6.3V 100uF
C348 168-3322-55 3300pF K
C349 168-3322-55 3300pF K
C350 168-3322-55 3300pF K
C351 168-3322-55 3300pF K
C352 168-1042-78 16V 0.1uF
C353 042-0643-58 6.3V 330uF
C355 168-2222-55 2200pF K
C356 168-2222-55 2200pF K
C357 168-2222-55 2200pF K
C358 168-2222-55 2200pF K
C359 163-1073-15 6.3V 100uF
C401 168-1042-78 16V 0.1uF
C402 168-1042-78 16V 0.1uF
C403 166-2201-50 22pF CH
C404 166-2201-50 22pF CH
C405 168-4722-55 4700pF K
C406 166-1201-50 12pF CH
C407 166-1201-50 12pF CH
C408 168-1042-78 16V 0.1uF
C409 163-4763-15 6.3V 47uF
C410 168-1042-78 16V 0.1uF
C411 168-1042-78 16V 0.1uF
C412 168-1032-55 0.01uF K
C413 166-1011-50 100pF CH
C414 166-1011-50 100pF CH
C415 163-4763-35 16V 47uF
C416 043-0548-50 2.2uF
C417 043-0548-50 2.2uF
C418 166-2201-50 22pF CH
C419 166-2201-50 22pF CH
C420 166-2201-50 22pF CH
C421 166-2201-50 22pF CH
C422 166-2201-50 22pF CH
C423 166-2201-50 22pF CH
C424 166-1801-50 18pF CH
C425 043-0548-50 2.2uF
C426 043-0548-50 2.2uF
C427 043-0548-50 2.2uF
C428 043-0548-50 2.2uF
C429 168-1032-55 0.01uF K
C501 168-1042-78 16V 0.1uF
C502 168-1042-78 16V 0.1uF
C503 168-1042-78 16V 0.1uF
C504 168-1042-78 16V 0.1uF
C505 166-5611-50 560pF CH
C506 166-5611-50 560pF CH
C507 166-5611-50 560pF CH
C508 178-3342-78 0.33uF
C509 166-5611-50 560pF CH
C510 163-1073-15 6.3V 100uF
C511 166-2201-50 22pF CH
C512 166-2201-50 22pF CH
C513 168-1042-78 16V 0.1uF
C514 168-1022-55 1000pF K
C515 166-2201-50 22pF CH
C516 166-2201-50 22pF CH
C517 166-5611-50 560pF CH
C518 166-5611-50 560pF CH
C519 166-5611-50 560pF CH
C520 166-5611-50 560pF CH
C521 163-4763-35 16V 47uF
C522 163-1073-35 16V 100uF
C523 166-2201-50 22pF CH
C524 168-2212-55 220pF K
C525 163-1073-35 16V 100uF
C526 042-0592-61 16V 47uF
C527 042-0592-61 16V 47uF
C528 163-4763-35 16V 47uF
C529 178-1242-78 0.12uF
C530 178-1242-78 0.12uF
C531 178-1242-78 0.12uF
C532 178-1242-78 0.12uF
C533 178-1052-78 1uF
C534 178-1242-78 0.12uF
C535 178-1242-78 0.12uF
C536 178-1242-78 0.12uF
C537 178-1242-78 0.12uF
C538 042-0579-51 16V 10uF
C539 166-2201-50 22pF CH
C540 166-2201-50 22pF CH
C541 166-2201-50 22pF CH
C542 166-2201-50 22pF CH
C543 168-1042-78 16V 0.1uF
C544 178-1042-78 0.1uF
C545 043-0566-90 50V 2.2uF K
C546 043-0604-90 25V 10uF B
C547 189-4783-31 16V 4700uF
C549 043-0499-51 0.1uF
C550 178-4742-78 0.47uF
C551 168-1042-38 50V 0.1uF
C553 168-6822-55 6800pF K
C554 168-6822-55 6800pF K
C556 168-6822-55 6800pF K
C557 168-6822-55 6800pF K
C558 168-6822-55 6800pF K
C559 168-6822-55 6800pF K
C560 168-1522-55 1500pF K
C561 168-6822-55 6800pF K
C562 168-6822-55 6800pF K
C563 168-6822-55 6800pF K
C564 166-2201-50 22pF CH
C565 178-1052-78 1uF
C566 168-1042-78 16V 0.1uF
C567 163-1063-35 16V 10uF
C568 168-2232-55 0.022uF K
C569 163-3373-15 6.3V 330uF
C570 168-1022-55 1000pF K
C601 163-1063-35 16V 10uF
C602 163-1063-35 16V 10uF
C603 163-1063-35 16V 10uF
C604 163-1063-35 16V 10uF
C607 168-2232-55 0.022uF K
C611 168-1022-55 1000pF K
C612 168-1022-55 1000pF K
C613 168-1022-55 1000pF K
CCT401 050-0145-52 1/16W 1k ohm x4
CCT402 050-0145-52 1/16W 1k ohm x4
CCT403 050-0145-52 1/16W 1k ohm x4
D101 001-0580-90 1SS352
D102 001-0580-90 1SS352
D103 001-0529-47 MA8091-M
D201 001-2412-90 RR264M-400
D502 001-0529-48 MA8091-H
D503 001-0580-90 1SS352
D504 001-0580-90 1SS352
D505 001-0580-90 1SS352
D506 001-2640-90 D1FJ4
D508 001-2015-00 RL253
D510 001-0529-48 MA8091-H
D511 001-4301-68 HZU18B1
D512 001-0580-90 1SS352
D513 001-4301-68 HZU18B1
D515 001-0529-34 MA8062-L
D517 001-0580-90 1SS352
D602 001-0529-44 MA8082-M
D605 001-4305-39 UDZSTE-17 36B
D606 001-0580-90 1SS352
D607 001-0580-90 1SS352
IC101 051-3341-90 BD3931FP
IC201 051-3516-90 S-1132B33-U5T1G
IC202 051-3340-00 LD1085P
IC301 ----------- SAF7730HV/N317
IC401 051-9424-90 BR24L16FVM-WTR
IC402 052-3205-10 M30873MHA-C10GP
IC403 051-6607-08 PCA82C250T-T

PN-2955H-A -16-
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
IC404 051-5417-38 R3112N271A-TR-FA
IC405 051-3020-90 NJM4565V
IC406 051-6212-08 LC72191JM-TLM
IC501 051-3396-90 NJM2386ADL3-33-T
E1
IC502 051-3019-90 NJM2060V
IC503 051-3034-90 NJM4558V
IC504 051-2037-00 TDA7560
IC505 051-3517-90 LT3481EMSE#TRPB
F
IC506 051-5441-08 BD4828G-TR
J201 074-1237-69 19PIN
J501 074-4009-20 SOCKET(20P)
J601 074-1013-00 12P
J602 074-1302-12 TH12P-SOCKET
L101 010-2003-04 30uH
L102 010-4011-20 2.5mH +3/-3%
L301 010-3104-54 600 ohm/100MHz
L302 010-3104-54 600 ohm/100MHz
L303 010-3104-54 600 ohm/100MHz
L304 010-3104-54 600 ohm/100MHz
L305 010-3104-54 600 ohm/100MHz
L306 010-3104-54 600 ohm/100MHz
L307 010-3104-54 600 ohm/100MHz
L308 010-3104-54 600 ohm/100MHz
L309 010-3104-54 600 ohm/100MHz
L310 010-3104-54 600 ohm/100MHz
L311 010-3104-54 600 ohm/100MHz
L312 010-3104-54 600 ohm/100MHz
L313 010-3104-54 600 ohm/100MHz
L402 010-3406-66 22uH J
L403 010-3406-54 2.2uH J
L404 010-3601-50 600 ohm/100MHz
L501 010-3104-54 600 ohm/100MHz
L502 010-3104-54 600 ohm/100MHz
L503 010-3414-90 6.8uH
L505 010-8048-00 COIL DN-CL1246
P401 076-0478-59 PLUG (9P)
P402 076-3011-74 24P PLUG
Q101 190-2060-00 2SA2060
Q102 125-2026-95 UN521N
Q105 192-5886-00 2SC5886
Q201 192-4081-00 2SC4081
Q202 125-0021-91 DTA114EUA
Q203 125-2027-91 DTC114EUA
Q204 198-3018-00 2SK3018
Q205 198-3018-00 2SK3018
Q206 125-9017-92 UMD3N-TR
Q301 125-7007-90 Si5441BDC-TI-E3
Q302 125-2027-91 DTC114EUA
Q305 125-2027-91 DTC114EUA
Q308 125-2027-91 DTC114EUA
Q501 190-1586-00 2SA1586 O,Y,G
Q502 125-2027-91 DTC114EUA
Q503 193-1664-00 2SD1664 P,Q,R
Q504 192-4116-51 2SC4116 G,L
Q505 191-1204-61 2SB1204 R,S,T
Q507 125-2027-91 DTC114EUA
Q508 191-1197-50 2SB1197K Q,R
Q509 125-2027-91 DTC114EUA
Q512 192-4081-00 2SC4081
Q513 192-4081-00 2SC4081
Q515 125-2027-91 DTC114EUA
Q516 192-4081-00 2SC4081
Q603 192-4081-00 2SC4081
Q604 192-4081-00 2SC4081
Q605 192-4081-00 2SC4081
Q607 125-0021-91 DTA114EUA
Q610 125-2027-91 DTC114EUA
R102 116-1091-15 1/4W 1 ohm
R104 116-1221-15 1/4W 1.2k ohm
R105 119-1031-15 1/10W 10k ohm
R106 119-0000-05 1/10W 0 ohm JW
R107 119-0000-05 1/10W 0 ohm JW
R110 119-1011-15 1/10W 100 ohm
R111 119-1011-15 1/10W 100 ohm
R112 119-1011-15 1/10W 100 ohm
R115 119-1011-15 1/10W 100 ohm
R116 119-1011-15 1/10W 100 ohm
R117 119-1011-15 1/10W 100 ohm
R118 116-1091-15 1/4W 1 ohm
R119 116-3911-15 1/4W 390 ohm
R206 119-1021-15 1/10W 1k ohm
R207 119-3331-15 1/10W 33k ohm
R208 119-4731-15 1/10W 47k ohm
R209 119-1041-15 1/10W 100k ohm
R210 119-4721-15 1/10W 4.7k ohm
R212 119-4721-15 1/10W 4.7k ohm
R213 119-4721-15 1/10W 4.7k ohm
R214 119-4721-15 1/10W 4.7k ohm
R216 032-0140-98 1/10W 330 ohm F
R217 032-0140-93 1/10W 2k ohm F
R301 119-1031-15 1/10W 10k ohm
R302 119-2201-15 1/10W 22 ohm
R303 119-1031-15 1/10W 10k ohm
R306 119-0000-05 1/10W 0 ohm JW
R307 119-0000-05 1/10W 0 ohm JW
R308 032-0140-80 1/10W 18k ohm F
R309 032-0140-80 1/10W 18k ohm F
R310 032-0140-80 1/10W 18k ohm F
R311 032-0140-80 1/10W 18k ohm F
R312 119-1011-15 1/10W 100 ohm
R313 119-1031-15 1/10W 10k ohm
R314 119-1021-15 1/10W 1k ohm
R315 119-1021-15 1/10W 1k ohm
R316 119-3921-15 1/10W 3.9k ohm
R317 119-1041-15 1/10W 100k ohm
R318 119-3921-15 1/10W 3.9k ohm
R319 119-1041-15 1/10W 100k ohm
R320 119-0000-05 1/10W 0 ohm JW
R321 119-1041-15 1/10W 100k ohm
R322 119-1041-15 1/10W 100k ohm
R323 119-1041-15 1/10W 100k ohm
R324 119-1041-15 1/10W 100k ohm
R325 119-3921-15 1/10W 3.9k ohm
R326 119-1001-15 1/10W 10 ohm
R327 119-3921-15 1/10W 3.9k ohm
R328 119-1021-15 1/10W 1k ohm
R329 119-0000-05 1/10W 0 ohm JW
R330 119-0000-05 1/10W 0 ohm JW
R331 032-0140-50 1/10W 10k ohm F
R332 032-0140-50 1/10W 10k ohm F
R333 032-0140-50 1/10W 10k ohm F
R334 032-0140-50 1/10W 10k ohm F
R335 032-0140-50 1/10W 10k ohm F
R336 032-0140-50 1/10W 10k ohm F
R337 119-1041-15 1/10W 100k ohm
R338 119-1041-15 1/10W 100k ohm
R339 119-1031-15 1/10W 10k ohm
R340 119-1031-15 1/10W 10k ohm
R341 119-1011-15 1/10W 100 ohm
R342 119-1011-15 1/10W 100 ohm
R343 119-0000-05 1/10W 0 ohm JW
R344 119-0000-05 1/10W 0 ohm JW
R345 119-0000-05 1/10W 0 ohm JW
R347 119-0000-05 1/10W 0 ohm JW
R348 119-4731-15 1/10W 47k ohm
R349 119-1031-15 1/10W 10k ohm
R350 119-0000-05 1/10W 0 ohm JW
R351 119-4731-15 1/10W 47k ohm
R352 119-1021-15 1/10W 1k ohm
R353 119-1021-15 1/10W 1k ohm
R354 119-1021-15 1/10W 1k ohm
R355 119-1021-15 1/10W 1k ohm
R356 119-4731-15 1/10W 47k ohm
R357 119-4731-15 1/10W 47k ohm
R358 119-1001-15 1/10W 10 ohm
R359 119-4731-15 1/10W 47k ohm
R360 119-4731-15 1/10W 47k ohm
R361 119-4731-15 1/10W 47k ohm
R362 119-4731-15 1/10W 47k ohm
R401 119-1021-15 1/10W 1k ohm
R402 119-1021-15 1/10W 1k ohm
R403 119-1021-15 1/10W 1k ohm
R404 119-1021-15 1/10W 1k ohm
R405 119-0000-05 1/10W 0 ohm JW
R406 119-1021-15 1/10W 1k ohm
R407 119-1021-15 1/10W 1k ohm
R408 119-1021-15 1/10W 1k ohm
R409 119-4731-15 1/10W 47k ohm
R410 119-4731-15 1/10W 47k ohm
R411 119-4721-15 1/10W 4.7k ohm
R412 119-4731-15 1/10W 47k ohm
R413 119-4731-15 1/10W 47k ohm
R414 119-4711-15 1/10W 470 ohm
R415 119-4711-15 1/10W 470 ohm
R416 119-4721-15 1/10W 4.7k ohm
R417 119-4721-15 1/10W 4.7k ohm
R418 119-4721-15 1/10W 4.7k ohm
R419 119-4721-15 1/10W 4.7k ohm
R420 119-1041-15 1/10W 100k ohm
R421 119-1041-15 1/10W 100k ohm
R424 119-1011-15 1/10W 100 ohm
R425 119-1011-15 1/10W 100 ohm
R426 119-1011-15 1/10W 100 ohm
R427 119-1011-15 1/10W 100 ohm
R428 119-1031-15 1/10W 10k ohm
R429 119-1031-15 1/10W 10k ohm
R430 119-4721-15 1/10W 4.7k ohm
R431 119-1021-15 1/10W 1k ohm
R432 119-1021-15 1/10W 1k ohm
R433 119-4721-15 1/10W 4.7k ohm
R434 119-1021-15 1/10W 1k ohm
R435 116-6201-15 1/4W 62 ohm
R436 119-1031-15 1/10W 10k ohm
R437 116-6201-15 1/4W 62 ohm
R438 119-4731-15 1/10W 47k ohm
R440 119-1021-15 1/10W 1k ohm
R441 119-0000-05 1/10W 0 ohm JW
R443 119-1031-15 1/10W 10k ohm
R444 119-4731-15 1/10W 47k ohm
R445 119-1031-15 1/10W 10k ohm
R446 119-4731-15 1/10W 47k ohm
R447 119-1021-15 1/10W 1k ohm
R448 119-4731-15 1/10W 47k ohm
R449 119-4731-15 1/10W 47k ohm
R450 119-4731-15 1/10W 47k ohm
R451 119-4731-15 1/10W 47k ohm
R452 119-4731-15 1/10W 47k ohm
R453 119-1011-15 1/10W 100 ohm
R454 119-1011-15 1/10W 100 ohm
R455 119-1021-15 1/10W 1k ohm
R456 119-4721-15 1/10W 4.7k ohm
R457 119-4721-15 1/10W 4.7k ohm
R458 119-1041-15 1/10W 100k ohm
R459 119-1011-15 1/10W 100 ohm
R461 119-2231-15 1/10W 22k ohm
R462 119-1041-15 1/10W 100k ohm
R466 119-1531-15 1/10W 15k ohm
R467 119-1531-15 1/10W 15k ohm
R468 119-4731-15 1/10W 47k ohm
R469 119-1531-15 1/10W 15k ohm
R470 119-1531-15 1/10W 15k ohm
R471 119-1031-15 1/10W 10k ohm
R472 119-1031-15 1/10W 10k ohm
R473 119-1031-15 1/10W 10k ohm
R474 119-1031-15 1/10W 10k ohm
R475 119-1031-15 1/10W 10k ohm
R476 119-1031-15 1/10W 10k ohm

- 17 - PN-2955H-A
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
R495 119-4731-15 1/10W 47k ohm
R496 119-4731-15 1/10W 47k ohm
R497 119-4731-15 1/10W 47k ohm
R498 119-4731-15 1/10W 47k ohm
R499 119-1011-15 1/10W 100 ohm
R501 119-1031-15 1/10W 10k ohm
R502 119-1031-15 1/10W 10k ohm
R503 119-1031-15 1/10W 10k ohm
R504 119-1031-15 1/10W 10k ohm
R505 119-1031-15 1/10W 10k ohm
R506 119-1031-15 1/10W 10k ohm
R507 119-1031-15 1/10W 10k ohm
R508 119-1031-15 1/10W 10k ohm
R509 119-1031-15 1/10W 10k ohm
R510 119-1031-15 1/10W 10k ohm
R511 119-1051-15 1/10W 1M ohm
R512 119-1051-15 1/10W 1M ohm
R513 119-1051-15 1/10W 1M ohm
R514 119-1051-15 1/10W 1M ohm
R515 119-1031-15 1/10W 10k ohm
R516 119-1031-15 1/10W 10k ohm
R517 119-1031-15 1/10W 10k ohm
R518 119-1031-15 1/10W 10k ohm
R519 119-1031-15 1/10W 10k ohm
R520 119-1031-15 1/10W 10k ohm
R521 119-4721-15 1/10W 4.7k ohm
R522 119-4721-15 1/10W 4.7k ohm
R523 119-1031-15 1/10W 10k ohm
R524 119-1031-15 1/10W 10k ohm
R525 119-1031-15 1/10W 10k ohm
R526 116-3911-15 1/4W 390 ohm
R527 116-1221-15 1/4W 1.2k ohm
R529 116-1221-15 1/4W 1.2k ohm
R530 116-1221-15 1/4W 1.2k ohm
R531 119-1031-15 1/10W 10k ohm
R533 119-1031-15 1/10W 10k ohm
R534 116-1221-15 1/4W 1.2k ohm
R535 119-4721-15 1/10W 4.7k ohm
R536 119-4731-15 1/10W 47k ohm
R537 116-4721-15 1/4W 4.7k ohm
R538 119-2731-15 1/10W 27k ohm
R539 119-4721-15 1/10W 4.7k ohm
R540 119-1521-15 1/10W 1.5k ohm
R541 119-1031-15 1/10W 10k ohm
R542 032-0140-03 1/10W 220k ohm F
R543 032-0140-19 1/10W 75k ohm F
R548 119-2241-15 1/10W 220k ohm
R551 119-1031-15 1/10W 10k ohm
R552 032-0140-16 1/10W 180k ohm F
R553 032-0148-50 1/10W 100k ohm
R554 032-0140-51 1/10W 15k ohm F
R555 116-2721-15 1/4W 2.7k ohm
R556 116-1531-15 1/4W 15k ohm
R558 119-2221-15 1/10W 2.2k ohm
R559 116-1531-15 1/4W 15k ohm
R560 116-4791-15 1/4W 4.7 ohm
R561 116-4791-15 1/4W 4.7 ohm
R562 119-1031-15 1/10W 10k ohm
R564 119-5611-15 1/10W 560 ohm
R565 119-1031-15 1/10W 10k ohm
R569 119-0000-05 1/10W 0 ohm JW
R571 119-0000-05 1/10W 0 ohm JW
R572 119-0000-05 1/10W 0 ohm JW
R573 119-0000-05 1/10W 0 ohm JW
R574 119-0000-05 1/10W 0 ohm JW
R575 119-0000-05 1/10W 0 ohm JW
R576 119-7531-15 1/10W 75k ohm
R577 119-4731-15 1/10W 47k ohm
R601 119-3011-15 1/10W 300 ohm
R602 119-3011-15 1/10W 300 ohm
R607 119-1021-15 1/10W 1k ohm
R609 119-5621-15 1/10W 5.6k ohm
R610 119-5621-15 1/10W 5.6k ohm
R612 119-5631-15 1/10W 56k ohm
R613 119-5631-15 1/10W 56k ohm
R615 119-4731-15 1/10W 47k ohm
R616 119-1031-15 1/10W 10k ohm
R617 119-1031-15 1/10W 10k ohm
R623 119-5631-15 1/10W 56k ohm
R624 119-1031-15 1/10W 10k ohm
R625 119-2231-15 1/10W 22k ohm
R626 119-4731-15 1/10W 47k ohm
SUP101 060-0122-91 DSP-141N-S00B
SUP102 060-0122-91 DSP-141N-S00B
TC401 004-1580-10 30pF GRN
TH101 002-0229-00 PTH8L05BAIR8M1B
TM101 073-0762-90 TERMINAL
TM102 073-0762-90 TERMINAL
TM501 073-0762-90 TERMINAL
TM502 073-0762-90 TERMINAL
TM601 073-0762-90 TERMINAL
X301 061-3537-90 41.6MHz
X401 061-3541-90 CRYSTAL 10MHz
X402 061-1066-00 7.2MHz
PWB 039-3155-00 PWB(WITHOUT CO
MPONENT)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
Switch PWB(B2) section
D701 001-9210-50 AVR-M1608C270MT
AAD
D702 001-9210-50 AVR-M1608C270MT
AAD
D703 001-9210-50 AVR-M1608C270MT
AAD
D704 001-9210-50 AVR-M1608C270MT
AAD
D705 001-0516-90 MA111
D706 001-0516-90 MA111
D707 001-0516-90 MA111
D708 001-0516-90 MA111
D709 001-0516-90 MA111
D710 001-0516-90 MA111
D711 001-0516-90 MA111
D712 001-0516-90 MA111
D713 001-7109-90 SML-311DTT86 OR
G
D714 001-7109-90 SML-311DTT86 OR
G
D715 001-7109-90 SML-311DTT86 OR
G
D716 001-7109-90 SML-311DTT86 OR
G
D717 001-7109-90 SML-311DTT86 OR
G
D720 001-7109-90 SML-311DTT86 OR
G
D721 001-7109-90 SML-311DTT86 OR
G
D722 001-7109-90 SML-311DTT86 OR
G
D723 001-7109-90 SML-311DTT86 OR
G
D724 001-7109-90 SML-311DTT86 OR
G
D725 001-7109-90 SML-311DTT86 OR
G
D728 001-7109-90 SML-311DTT86 OR
G
D729 001-7109-90 SML-311DTT86 OR
G
D730 001-7109-90 SML-311DTT86 OR
G
D731 001-7109-90 SML-311DTT86 OR
G
D736 001-7109-90 SML-311DTT86 OR
G
D737 001-7109-90 SML-311DTT86 OR
G
D738 001-7109-90 SML-311DTT86 OR
G
D739 001-7109-90 SML-311DTT86 OR
G
D740 001-7109-90 SML-311DTT86 OR
G
D741 001-7109-90 SML-311DTT86 OR
G
D743 001-7109-90 SML-311DTT86 OR
G
D744 001-7109-90 SML-311DTT86 OR
G
D745 001-7109-90 SML-311DTT86 OR
G
D746 001-7109-90 SML-311DTT86 OR
G
D748 001-7109-90 SML-311DTT86 OR
G
D749 001-7109-90 SML-311DTT86 OR
G
D750 001-7109-90 SML-311DTT86 OR
G
D751 001-7109-90 SML-311DTT86 OR
G
D753 001-7109-90 SML-311DTT86 OR
G
D754 001-7109-90 SML-311DTT86 OR
G
D756 001-7109-90 SML-311DTT86 OR
G
D757 001-7109-90 SML-311DTT86 OR
G
D758 001-7109-90 SML-311DTT86 OR
G
D759 001-7109-90 SML-311DTT86 OR
G
D760 001-0516-90 MA111
D761 001-0516-90 MA111
D762 001-7109-90 SML-311DTT86 OR
G
J701 075-0390-00 JACK
J702 074-3013-74 24P
R701 116-3321-15 1/4W 3.3k ohm
R705 116-1021-15 1/4W 1k ohm
R706 116-1821-15 1/4W 1.8k ohm
R707 116-2221-15 1/4W 2.2k ohm
R709 116-2721-15 1/4W 2.7k ohm
R710 116-2221-15 1/4W 2.2k ohm
R711 116-4711-15 1/4W 470 ohm
R713 116-2221-15 1/4W 2.2k ohm
R714 116-1521-15 1/4W 1.5k ohm
R715 116-1521-15 1/4W 1.5k ohm
R716 116-1521-15 1/4W 1.5k ohm
R717 116-2721-15 1/4W 2.7k ohm
R718 116-2421-15 1/4W 2.4k ohm
R719 116-2721-15 1/4W 2.7k ohm
R720 116-1221-15 1/4W 1.2k ohm
R721 116-1221-15 1/4W 1.2k ohm
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
R722 116-1221-15 1/4W 1.2k ohm
R723 116-1221-15 1/4W 1.2k ohm
R724 116-1521-15 1/4W 1.5k ohm
S701 013-6202-52 SKPMBJE010
S702 013-6202-52 SKPMBJE010
S703 013-6202-52 SKPMBJE010
S704 013-6202-52 SKPMBJE010
S705 013-6202-52 SKPMBJE010
S706 013-6202-52 SKPMBJE010
S707 013-6202-52 SKPMBJE010
S708 013-6202-52 SKPMBJE010
S709 013-6202-52 SKPMBJE010
S710 013-6202-52 SKPMBJE010
S711 013-6202-52 SKPMBJE010
S712 013-6202-52 SKPMBJE010
S713 013-6202-52 SKPMBJE010
S714 013-6202-52 SKPMBJE010
S715 013-6202-52 SKPMBJE010
S716 013-6202-52 SKPMBJE010
VR701 016-0018-23 VR W/SHAFT
VR702 016-0024-07 VR W/SHAFT
PWB 039-3156-01 PWB(WITHOUT CO
MPONENT)

- 18 - PN-2955H-A
PRINTED WIRING BOARD
Main PWB(B1) section 1/2
Caution:
COMPONENT SIDE:
Parts on the component side seen from
the component side are indicated.
SOLDER SIDE:
Parts on the solder side seen from the
solder side are indicated.
Main PWB(B1)
COMPONENT SIDE
To J702 of Main PWB
(page 25)
To CD mechanism
FLAT WIRE(816-4024-50)
ANT101
R503
CCT401
CCT402
CCT403
R502
D102
R501
D103
R555
D517
R355
R540
R541
R565
Q512
R411
C601 C602
C352
L313
C603
Q503
C532
Q502
C105
Q501
C546
C426
C427
C428
C416
L403
D101
IC501
1
IO
L402
C414
1
IC201
X401
C415
X301
C417
C502
R564
IC402
C504 R504
C510
D506
L503
R615
Q515
R602 R601
R569
C501
Q513
R561
R560
R558
R537
C566
C514
C403
R554
R576
Q516
R577 C563
R553
C560
R548
R551
R542
D515
Q508
R539
C107
Q507
R538
R499
R401
C113
C118
C531
C530
C529
C533
C539
C538
C540
C541
C542
C554
R526
R562
R524
C503
C549
R522
C553
C557
C556
C559
C558
C562
C561
R102
C103
C345
C349
C348
C351
C570
L306
D201
L501
L502
C564
D510
C119
D512
C418
C420
C120
C121
C123
C124
R523
R476
R475
D508
R474 R473 R472 R471
R470
R469
R467
C338
C419
R430
C604
IC405
1
48 5
TM101
IC202
I
O
IC301
IC406
1 5 10 12
24 20 15 13
C424
C202
C106
P402
1 5 10 15 20 24
J201
1 5 10 15 19
J601
R466
Q505
R556
R559
C567
C568
R455
R454
IC404
O
V
R453
R445
C408
R521
C203
C205
C350
R459
R441
R440
Q102
Q101
R435
C405
R434
1
25
10
20
26 30 40 50 51
75
70
60
76
80
90
100
R433
R432
R431
R427
R426
R425
R424
R572
C421
C326 C328
C336
C206
R408
R407
C207
C208
C209
R406
R405 R404
R403 R402
R354
IC101
OUT
VCC
C210
R353
R573
R352
C329
C411
C412
D502
C101
C543
IC506
OUT
VDD
R104
R105
IC505
R525
J602
L101
L102
C422
C513
Q301
R341
R343
L308
R340
C327
R447
R330
1
10
20
30
36
37
405060
72
73
80
90
100
108 109 120 130 140144
R312
C423
C522
C523
C524
C525
C526
C527
C528
R217
R216
R213
L505
R210
R207
R206
R119
R118
R117
R116
R115
R112
R111
R110
R107
R106
C565
R552
Q308
Q305
Q302
C335
Q206
Q205 Q204
Q203
Q202
Q201
Q105
J501
C537
C353
C346
C536
Q509
R452
C332
C535
BL101
1
5
10
14
15
20
25
29
C551
C550
C548
C547
C569
R575
C545
C544
IC504
15 15
210 20
24
25
IC403
L307
R339
L305
C321
TM502
TM501
TM601
TM102
P401
FLASH-WRITE
C330
C334
R342
L304
X402
C429
TH101
TC401
SUP102
SUP101
R443
R571
C413
C409
C407 C406
L404
R437
C404
C359
C320
C425
C319
C508
C318
C303
C534
C309C308
Q512
Q503
Q502
Q501
IC501
IC402
Q515
Q513
Q508
Q507
IC405
IC202
IC301
IC406
Q505
IC404
Q102
Q101
IC101
IC506
IC505
Q301
Q308
Q305
Q304
Q302
Q206
Q205
Q204
Q203
Q202
Q201
Q105
Q509
IC504
ICQ
IC403
IC201
Q516
ANT Connector
C
B
C(SUB)
B(MAIN)
A
A
h11h12h13h14h15h16
h17h18h19h20h21h22
h11h12h13h14h15h16
h17h18h19h20h21h22
M-CAN Connector
N-BUS Connector
V02 V04V10 V12
V02 V04V10 V12
V01
V03
V05
V06
V07
V08
V09
V11
V01 V03 V05 V06 V07 V08 V09 V11
1
2
345
67
89
1
2
345
67
89
19
10
11
12
13
14
15161718
20
19
10
11
12
13
14
15161718
20
Main Connector No. Pin Name
A
B
C
ANT+B
MAIN ANT
SUB ANT
No. Pin Name
h11
h12
h13
h14
h15
h16
h17
M CAN (-)
M CAN (+)
N.C.
N.C.
N.C.
N.C.
M CAN SHIELD
No. Pin Name
h18
h19
h20
h21
h22
GND
N.C.
N.C.
N.C.
GND
No. Pin Name
V8
V9
V10
V11
V12
REQ(SAT->COMBI)
RXD(SAT->COMBI)
TXD(COMBI->SAT)
N.C.
N.C.
No. Pin Name
V1
V2
V3
V4
V5
V6
V7
SAT LCH (-)
SAT LCH (+)
SAT RCH (-)
SAT RCH (+)
GND
SHIELD GND
N.C.
No. Pin Name
1
2
3
4
5
6
7
N.C.
FRONT LCH (+)
FRONT LCH (-)
REAR LCH (+)
REAR LCH (-)
STRG SW A
ACC
No. Pin Name
8
9
10
11
12
13
14
ILL CONT
ILL (+)
B/U
GND
FRONT RCH (+)
FRONT RCH (-)
REAR RCH (+)
No. Pin Name
15
16
17
18
19
20
REAR RCH (-)
STRG GND
STRG SW B
N.C.
N.C.
GND
BU
ACC
12V
3.3V
9V 5V
1.8V
3.3V
5V
3.3V
9V
CD+9V
BU5V
BU-DET
CLK
CD-I/F
ES-I/F
ANT DISP SAT
PWR/SP
CD+3.3V
RESET
SYS+9V
SYS+12V
AUDIO-CPU
DSP
1.8V-REG
TUNER
6CD-SLOT+B
AUX-IN
CAN-TRANCEVER
POWER-IC
POWER-IC-MUTE
DSP-3.3V
ANT-ON
TUN 9V TUN 5V

- 19 - PN-2955H-A
Main PWB(B1) section 2/2
C509
C511
C506
R508
R313
R506
D511
D513
R415
R534
TP427
C512
IC502
17
14 8
TP425 TP424
TP423 TP422
TP421 TP420
TP419 TP418
TP417 TP416
TP415 TP414
TP413 TP412
TP410
TP409 TP408
TP407 TP406
TP405
TP601
TP403
TP402
TP401
TP302 TP301
Q605
Q610
R623
Q603
R613
D606
C613
R616
R607
C612
R519
C108
R438
R531
C109
R530
C110
C111
C115
C116
C117
C112
Q504
R529
R527
D503
R533
C520 C517
C518
C519
R514 R513
R512 R511
TP101
R510
C343
R359
L311
R509
TP428
R468
C515
C505
D505
R461
C516
R457
R456
R458
R451
R450
R449
R462
R444
C607
D602
Q604
R617
IC401
1
R446
R448
R429
C401
R428
R421
R536
R419
R361
R417
R420
R414
R413
C333
R360
R357
R302
L301
Q607
C301
R418
R362
R356
L312
R351
R409
TP102
TP103
TP303
TP426
C114
D504
TP501
R535
R416
TP502
R344
R348
TP503
TP504
L309
C344
TP505
R609
D605
R612
R358
R301
R610
R507
R495
C306
R496
R497
C331
R338
R337
R336
R208
R335
C507
R518
R334
R331
R517
R520
R333
R515
R516
R329 C325
R323
R327
R322
R321
R319
R317
R320
R326
R318
R328
C311 R315
R311
R310
R309
R308
C402
R306
R324
C307 R303
R412
R214
R212
R209
R626
R624
R498
D607
R625
C611
TP411
R332
TP603
R410
TP404
TP602
TP507
C324
R349
R325
R350
L310
R316
R347
C340
R505
C410
R436
C358
C357
C356
C355
L303
TP506
C302
R307
C317
R314
C312
C316
C310
C313 C337
R345
L302
IC502
Q605
Q610
Q603
Q504
Q604
IC401
Q607
Main PWB(B1)
SOLDER SIDE
IC Q
BU+5V
RESET
B/U-DET
E2PROM
SYS+5V
12V
3.3V
TX
RX
REQ
1/2-9V
RDS-DA1
RDS-CL1
T-BASE
MAIN-FIX SCL
SDA
ANT+B
AM/FM5V
AM/FM8.5V
1.8V-REG
ANT101
I
O
J601J602 J501
BL101
1
5
10
14
15
20
21
29
C(SUB) B(MAIN) A
h11h12 h13 h14h15 h16
h17h18h19h20 h21 h22
V01 V03
V04
V02
V12
V10
V05 V06 V07 V08 V09 V11
123456789
19 10111213141516 1718 20
BU
ACC
12V
9V

- 20 - PN-2955H-A
CIRCUIT DIAGRAM
Main PWB(B1) section 1/5
[ Tuner, CD mech. I/F Block ]
C
C C C C
C C
C C C
1234567891011121314 1516171819202122 23 24 25 26 27 28 29
C
C
S
D
G
S
D
G
C
C
GND OUT IN
C C
C C
123
45
C
VCCGVOUT
C103
C101
C105
R104
Q102
R105
C106
R106
R107
R116
R117
R206
R207
Q204
Q205
Q206
C205
C206
R217
C209
R119
C119
C120
C123
C124
D102
D103
Q101
Q105
Q201
Q202
Q203
C108
C109
C115
C116
C117
R208
R209
R210
R212
R213
R214
TP101
TP102
TP103
D101
C207
C208
D201
C210
R110
R111
R112
C111
C110
C112
C113
C114
R115
C118
C121
R216
C203
C202
R118
R102
ANT101
SUP101
SUP102
L101
L102
C107
TH101
BL101
IC101
IC202
IC201
J201
TM102
TM101
150p
100
100
2200p
0
0
22p
10 16V
1.2K 1/4W
10K
UN521N
10 16V
1K
33K
2SK3018
2SK3018
UMD3
2.0K F
0.1
0.1
220 10V
0.1
47 16V
100 16V
390 1/4W
1SS352
MA8091M
2SA2060
2SC5886A
2SC4081
DTA114EUA
DTC114EUA
2200p
1000p
1000p
1000p
1000p
47K
100K
4.7K
4.7K
4.7K
4.7K
ANT+B
8.5V
5V
1SS352
10 16V (105)
10 16V (105)
RR264M-400
220 10V
100
100
100
1000p
1000p
1000p
100 16V
2200p
100
100 16V
0.1
330 F
0.33
1
1 1/4W
1 1/4W
GT13-SHA
200p
0.285A
BD3931FP
5V-REG
LD1085P
S-1132B33U
5T1G
GIX 6CD
EARTH-PLATE
AM
FM-MAIN FM-R MAIN
TUN-DSP
SYS+12V
GND
TUN GND
TUN-CPU
SYS+5V
B/U+5V
B/U-DET
P-ON1
CD-CPU
SPDIF 6CD
M-T SDA
M-T SCL
S-T SCL
S-T SDA
M K-AGC
M SPL
M HLD
M MSB
M LSB
M IF-P
M IF-N
S IF-N
S IF-P
S LSB
S MSB
S HLD
S SPL
S K-AGC
REQ
SYS ACC
SYS ACC
REQ
6CD DA
6CD CL
6CD CL
6CD DA
SYS-ACC
6CD-REQ
6CD-RST
6CD-SDA
6CD-SCL
140kV
MAIN
SUB
ANT+B
1234567
FM ANT
GND
AGC BUF
AM/FM8.5V
AM/FM5V
K AGC
AF SAMPLE
AF HOLD
SDA
SCL
IF AGC MSB
IF AGC LSB
GND
IF OUT1
IF OUT2
AM ANT
FM ANT
GND
AGC BUF
K AGC
GND
AF SAMPLE
AF HOLD
SDA
SCL
IF AGC MSB
IF AGC LSB
IF OUT1
IF OUT2
MAIN SUB
TUNER-2TUNER-1
TUNER 5.0V TUNER 9V
4.7K
47K
ANT-ON
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
14
16
17
18
19
P-GND
D-GND
D-GND
L-CH
A-GND
R-CH
P-GND
VDD
RESET
SPDIF
SDA
A-MUTE
SCL
SYS-ACC
REQ
CD+9V
CD+9V
B/U-DET
P-ON1
CD+3.3V
3
4
4
2
2
4
4
4
3
3
2
CD+9V
123
130mA
50mA
60mA 300mA
To CD mechanism
13.1
9.7
9.0
9.005.0
6.4
6.4
0
0
0
4.9
4.9
3.2
0FM:1.9/AM:0.4
8.7
5.00
0
0
A01-FM:0.18Vp-p(10.7M):SUB
A01-FM:0.18Vp-p(10.7M):SUB
(B05-4.9Vp-p)
(B05-4.9Vp-p)
(C04-4.8Vp-p)
C04-4.4Vp-p(BAND)
6.4
6.4
0
FM:0/AM:3.3
0
4.9
4.9
3.2
0
FM:1.9/AM:0.4 0
0
0
0
A01-AM:0.1
FM:0.18Vp-p(10.7M)
A01-AM:0.1
FM:0.18Vp-p(10.7M)
(C04-3.3Vp-p)
(B05-4.9Vp-p)
(B05-4.9Vp-p)
C04-3.1Vp-p(at non-recept.)
C04-4.4Vp-p(BAND)
* Voltage : When standard input level is received
13.0
0
0
0
0
0
0
13.1/(0)
12.4/(0)
13.1/(0)
0
0
4.9/(0)
(ACC-OFF)
13.1
8.9
7.6
0
3.3
4.1
4.1
0
3.33.3
4.9
0
B05-4.9Vp-p
B05-4.9Vp-p
4.9
3.3
3.3
CD:D03-3.3Vp-p
3.3
4.9
3.3
CD:D03-3.3Vp-p
CD:D03-3.3Vp-p
3.3
3.3
4.8
0
0
CD:D02-
4.9Vp-p
0
00.7
3.3
0
0
CD:A01-2.6Vp-p
0
CD:A01-2.6Vp-p
0
0
3.3
4.8
4.5
CD:C02-3.3Vp-p
CD:D03-3.3Vp-p
0
CD:D03-3.3Vp-p
3.3
CD:D03-2.8Vp-p
8.9
A01 C04
B05 C02 D03
D02
To 1/5 (page 20)
To 2/5 (page 21)
To 3/5 (page 22)
To 4/5 (page 23)
To 5/5 (page 24)
2
1
3
4
5
