Clarion VRX835 Quick start guide

~NET
lillDO~~
DIGITAL AUDIO
Cf]KD
Owner's manual &Installation manual
Mode d'emploi et manuel d'installation
Manual de instrucciones y de instalacion
VRXB3S
AM/FM CD PLAYER/CD CHANGER CONTROLLER
WITH 7
11
LC DISPLAY
•
•
RADIO DE AM/FM, REPRODUCTOR DE DISCOS
COMPACTOS/CAMBIADOR DE DISCOS
COMPACTOS CONTROLADOR CON
VISUALIZADOR DE CRISTAL LiaUIDO DE 7
11

Thank you for purchasing the Clarion VRX835.
*This owner's manual is for the VRX835.
*Please read this owner's manual in its entirety before operating this equipment.
*After reading this manual, be sure to keep it in ahandy place (e.g., glove compartment).
*Check the contents of the enclosed warranty card and keep it carefully with this manual.
*This manual includes the operating procedures of the CD changer, MD changer, DVD changer, TV
tuner, digital sound processor (DSP) and DVD video deck connected via the CeNET cable. The CD
changer,
MD changer, DVD changer, TV tuner, DSP and DVD video deck have their own manuals,
but no explanations for operating them are described.
Contents
1. FEATURES 2
2. PRECAUTIONS 3
3. CONTROLS 5
4. NOMENCLATURE 6
5. DISPLAY 8
6. OUTLINE OF BUTTON ANDTOUCHKEY OPERATION
WHEN THE DISPLAY IS OPEN 10
7. REMOTE CONTROL 12
8. DCP 14
9. CAUTIONS ON HANDLING 15
10. OPERATIONS 16
Basic Operations 16
Radio Operations ,20
CD Operations
22
Visual Operations 24
CD/MD Changer Operations 25
DVD Changer Operations 28
TV Operations
31
Other Functions 33
DSP Operations
35
DVD Operations 41
11. IN CASE OF DIFFICULTY , , .. " 42
12. ERROR DISPLAYS , ,44
13. SPECIFICATIONS , "
45
•Full-Motorized 7" Widescreen LCD
•Touch Panel
Control
•Single Play CD Mechanism
•6-Channel, 4Volt RCA Line Level
Output
2 VRX835
•2-AV Inputs
• Built-in 48W x 4 Amplifier
•CeNET Control
•IR Remote Control

2. PRECAUTIONS
For your safety, the driver should not watch theTV or operate the controls while driving.
Please note that watching and operating the TV while driving are prohibited by law
in
some countries. Also, while driving, keep the volume to alevel at which external sounds
can be heard.
1. When the inside of the car is very cold and
the player is used soon after switching on the
heater, moisture may form on the disc
(COl
MD) or the optical parts of the player and
proper playback may not be possible. If mois-
ture forms on the disc (CD/MD), wipe it off
with asoft cloth. If moisture forms
on the op-
tical parts of the player, do not use the player
for about one hour. The condensation will dis-
appear naturally allowing normal operation.
2. Driving on extremely bumpy roads which
cause severe vibration may cause the sound
to skip.
3. This unit uses aprecision mechanism. Even
in the event that trouble arises, never open
the case, disassemble the unit, or lubricate
the rotating parts.
4. TV broadcast reception
When receiving the TV broadcasts, the
strength of the signals changes since the car
is moving, so
in some cases it may not be
possible to receive clear pictures.
•TV signals are strongly linear, so reception
is affected
by buildings, mountains and
other obstacles.
•Such external factors such as electric train
lines, ahigh voltage lines, and signal de-
vices may disturb the picture or cause
noise.
"
If the reception is poor, switch to astation with
good reception.
5. This equipment has been tested and found to
comply with the limits for aClass Bdigital de-
vice, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reason-
able protection against harmful interference
in aresidential installation.This equipment
generates, uses, and can radiate radio fre-
quency energy and, if not installed and used
in accordance with the instructions, may
cause harmful interference to radio communi-
cations. However, there is no guarantee that
interference will not occur
in aparticular in-
stallation. If this equipment does cause harm-
ful interference to radio
or television recep-
tion, which can be determined by turning the
equipment off and on, the user is encouraged
to consult the dealer or an experienced radiol
TV technician for help.
IMi·[email protected]'·U'4i#;,.j
CHANGES OR MODIFICATIONSTO THIS
PRODUCT NOT APPROVED BY THE MANU-
FACTURER WILL VOIDTHE WARRANTY AND
WILL VIOLATE FCC APPROVAL.
VRX835 Clalioo
T2V 6GROUND
AM 530·1?10ICHzlfM 87.9·10T.9MHz:
rll'S DntC~ COIoIpues WITH P.tJ\T'~ OF THE. l'CC IlUlfS
Ol'EJt/lTIOIiIS ilt/6..IECrlc."THEFO'LOW"..... lWCt!XlND' .. ONS
(\1 IH~ OE~!CE l,(,t,~i>IOl c.wSE. f<.'.IWf1.JL INTE~.e~foeE ..lNO
Ii') I~," Dr.Vlc::r ~USI Att.PT .-..... .. ~~~e;ll;t...ef: lIIrc::rIYu,.
,f>;(.;LUOoI'>Ci .NTfllll'.lIIelJe. r"/lT ..... ~ CAust I,INtln(~"D
'1<1:> ~lII¢~uCT'''N. oo .... I.E$ ~lTt-I D'1i'>S F\U~ES. 2. C'-'"
51,Jk"'~'f'" J "'~~I.IC-'&\.e III D~T~ Ol' IMNUFM;T\Jf1(
>\lI(.AAllTOO"""TWA-$liIs.o.IT,o,MoO,'K!:N..J.o,'AIi
Caution on Handling
On CDs
•Exercise agood precaution when loading aCD
disc with the panel open.
•Never turn off the power and remove the unit
from the car with aCD loaded.
VRX835 3

Use only compact discs bearing the ~~~ mark.
Handling Compact Discs
Cleaning
• To remove fingermarks and dust, use asoft
cloth and wipe
in astraight line from the cen-
ter of the compact disc to the circumference.
•Do not use any solvents, such as commer-
cially available cleaners, anti-static spray, or
thinner to clean compact discs.
•After using special compact disc cleaner, let
the compact disc dry off well before playing
it.
Storage
•Do not expose compact discs to direct sun-
light orany heat source.
•Do not expose compact discs to excess hu-
midity or dust.
•Do not expose compact discs to direct heat
from heaters.
•Never stick labels on the surface of the com-
pact disc or mark the surface with apencil or
pen.
•Never
playa compact disc with any cello-
phane tape or other glue on it or with peeling
off marks. If
you try to play such acompact
disc, you may not be able to get it back out of
the CD player or it may damage the CD
player.
•Do not use compact discs that have large
scratches, are misshapen, cracked, etc. Use
of such discs may cause misoperation or
damage.
•
To remove acompact disc from its storage
case, press down on the center of the case
and lift the disc out, holding it carefully
by the
edges.
•Do not use commercially available CD protec-
tion sheets or discs equipped with stabilizers,
etc. These may damage the disc or cause
breakdown of the internal mechanism.
Do not play heart-shaped, octagonal, or other specially shaped compact discs.
Some CDs recorded
in CD-R mode may not be usable.
Even when recorded
in CD-RW mode, some CDs not be usable.
Handling
•New discs may have some roughness around
the edges. If such discs are used, the player
may not work orthe sound may skip. Use a
ball-point pen or the like to remove any rough-
ness from the edge of the disc.
8e sure to unfold and read the next page.
Veuiilez deplier et vous referer ala page suivante.
Cerci6rese de desplegaryde leer la pagina siguiente.
VRX835 4

With the Display closed/ Avec faf,ficheur 1f3rme /Con el visualisador cerrado
With the Display open
//
fafficheur ouvert /Con el visualisador abierto
\
i~I, ---~-----_! I
[<~]~-~.-
[~/II]---
[.->]
-----[RDM]
---[RPT]
[seN]
Note: Be sure to unfold this page and refer to the front diagrams as you read each chapter.
Remarque: VeuHiez deplier cette page et vous referer aux schemas quand \lOLlS hsez chaque chap!l! e.
Nota: Cuando lea los capftulos, despliegue esta pagina yconsulte los diagramas.
5 VRX835

Names of Buttons
Note:
•Be sure to read this chapterreferring to the front diagrams of chapter "3. CONTROLS"on page 5(unfold).
4. NOMENCLATURE
[RELEASE] button
•Use this button to remove the DCP from the
main unit.
[SEARCH] button
•Use this button to tune to astation in the ra-
diolTV mode.
•Use this button to select atrack
in the CD/
DVO video mode and CO/MO/OVD changer
mode.
[~] button
•Use this button to eject a CO.
[~/II] button
•Use this button to mute the sound.
•Press and hold this button for 1second or
longer to enter the play pause mode
in the
CO/DVD video mode and CD/MD/OVO
changer mode. Press and hold the button for 1
second or longer again to resume playback.
[BAND] button
•Press this button to switch the receiving bands
for radiolTV mode, etc. Press and hold this
button for 1second or longer to switch the
SEEK/MANUAL tuning modes.
•Use this button to move to the first track
on a
disc
in the CO mode.
•Use this button to switch to the next disc
in the
CD/MD/OVO changer mode.
[DIRECT] button
•Use this button to select apreset channel in
the radiolTV mode.
•Use this button to select adisc
in the CO/MO/
DVD changer mode.
[FUNC] button
•Press this button to turn on the power. Press
and hold this button for 1second or longer to
tu rn off the power.
•Press this button to switch the modes such as
radio.
[SENSOR]
•Remote control infrared sensor
[DISP] button
•Use this button to switch the indications such
as play status on the information panel when
the liquid crystal panel is closed.
•Use this button to call the LCD background
screen setup menu when the liquid crystal
panel is open.
•Press and hold this button for 1second or
longer to turn off the monitor when the liquid
crystal panel is open.
•Use this button to switch the display sizes
while
in the screen where the TV, VISUAL, or
DVO video, OVO changer mode is suspended.
When the display closed
[ISR] button
•Use this button to enter the ISR (Instant sta-
tion recall) standby mode.
[OPEN] button
•Use this button to open/close the liquid crystal
panel.
•Press and hold this button for about 2sec-
onds or longer so that the liquid crystal panel
is positioned horizontally when the liquid crys-
tal panel is open. Press the button again to re-
turn the panel to the original position. Even if
the button is not pressed, the panel returns to
the original position after about 10 seconds.
[VOL] button
•Use this button to increase/decrease the vol-
ume.
[TILT] button
•Use this button to adjust the angle of the liquid
crystal panel
in 5steps.
•Every time this button is pressed and held for
about 2seconds or longer, the liquid crystal
panel moves forward/backward
in 3steps.
6VRX835

When the display open
[A-M] button
•Shows the AUDIO MODE menu for tone ad-
justment, etc. Press and hold this button for 1
second or longer to switch the loudness on or
off (LOUD ON/OFF).
[ADJ] button
•Shows the ADJUST MODE menu to change
the settings.
[ROM] button
•Performs random play while in the CD mode
or CD/MD/DVD changer mode. Also performs
disc random play when the button is pressed
and held while
in the CD/MD/DVD changer
mode.
[RPT] button
•Plays repeatedly while in the CD mode or CDI
MD/DVD changer mode. When this button is
pressed and held while
in the CD/MD/DVD
changer mode, disc repeat play is performed.
[SeN] button
•Performs preset scan while in the radio mode.
When the button is pressed and held, auto
store is performed.
•Performs scan play for 10 seconds for each
track while
in the CD mode and CD/MD/DVD
changer mode. Disc scan play is performed
when the button is pressed and held while
in
the CDI MD/DVD changer mode.
[< ...][M>] button
•Use this button to select atrack in the CDI
DVD video mode and CD/MD/DVD changer
mode.
[.,,/11] button
•Press to enter the play pause mode in the CDI
DVD video mode and CD/MD/DVD changer
mode. Press to resume playback.
[M.LOCK] button
•The display panel can be switched to acom-
posite screen to lock the monitor.
VRX835 7

The Color LCD Display and the Information Panel on the main unit show the following displays, provid-
ing information about the mode and functions operated.
Information Panel
Preset channel indication -' ~ .. ~~,~~-~.,_.""t,
Disc number indication \\
*The disc numbers corresponding to the 0\
discs in the CD or MD or DVD changer
light. \
\,
_----~VOL B :Volume indication \
~c3l~~ tf.1~rJj Mig II~ 1iflI-1Im 1iflI-1iflI tIm Dl i5j
R;i'';~~M !~ ~tCH~ I 111 IlIlIIllI-t1lIll1I1-llIIIlllIl '~L
---L l-;J-/-EI
/ I /7
/' III L~.~, Operation status indication
/ / f/ *The frequency, play time, clock, etc. are
II / / displayed.
;///
///.. .
II / L- ~ SRCH:8J :Search indication
/ ;1
/ L rrwmnJ :Mute indication
1J?#?131!;;J :Z-enhancer indication
CSTJ :Stereo indication
CLDJ :Loudness indication
.- DISC ~ :Disc indication
RPT :Repeat indication
ROM :Random indication
8VRX835

Color LCD Display
-Radio/TV mode
: PROGRAM ~ WEST COAST (User title)
-CD/CD changer mode
: USER 'TITLE ~ SHINE (User title)
-CD TEXT mode
: DISC TITLE ~ SHINE (Disc title)
:TRACK TITLE ~ Time has come (Track title)
:ARTIST ~ Time has come (Artist)
- M0 changer mode
: DISC TITLE ~ SHINE (Disc title)
:TRACK TITLE ~ Time has come (Track title)
-Radio mode : FM1 98.1MHz Pch 1(Band/Frequency/Preset No.)
-CD mode :TRACK 02 04: 07 (Track No./Playback time)
-CD/MD changer mode
:DISC 02 TRACK 02 00: 45 (Disc No./Track No./Playback time)
-TV mode :TV1 28CH Pch 1(Band/Channel/Preset No.)
-VISUAL mode: VISUAL 1(Band)
-DVD mode :CHAPTER 01 (Chapter No.)
-DVD changer mode
DVD-video :
D2 T02 C002 01 :00:45
(Disc No./Title No./Chapter No./Playback time)
Video CD :
02 T02 01 :00:45 (Disc No./Track No./Playback time)
MP3 :
02 F001 T002 00:45
(Disc No./Folder No./Track No./Playback time)
CD :
02 T02 00:45 (Disc No./Track No./Playback time)
FMJ 9a~ I MHz Pchl
MOTION/SPRITE pattern display
-MANU :Seek/Manual indication
eST :Stereo indication
-LO :Loudness indication
-ZEHCR :Z-enhancer indication
VRX835 9

: An example
mode
key to go to the next m;en;u:.

Remote control unit
Operating range: 30° in all directions
Receiver for remote control unit
Inserting the Batteries
1. Turn the remote control unit over, then slide
the rear cover in the direction of the arrow.
2. Insert the AA (SUM-3, IECR-6/1.5V) batter-
ies that came with the remote control unit
facing in the directions shown in the figure;
then close the rear cover.
Notes:
Using batteries improperly can cause them to ex-
plode.
Take note of the following points:
•When replacing batteries, replace both batteries
with new ones.
• 00 not short-circuit, disassemble or heat batter-
ies.
f# 00 not dispose of batteries into fire or flames.
eDispose of spent batteries properly
Rear side
\/
AA (SUM-3, IECR-6/1.5V)
Batteries
Rear cover
12
VRX835

Functions of Remote Control Unit Buttons
Increases and decreases volume (in all modes).
Switches among radio, CD, DVD, CD changer, MD changer, DVD changer, TV and VISUAL.
Power OFF; Press and hold for 1second or longer.
Moves the next disc Switches reception
in increasing order. band.
Plays the first track.
Top play.
Switches reception
band.
[I] BAND
DISC
UP
TOP
[]J VOLUME
[IJ SEARCH Moves preset chan- Moves tracks up
nels up and down. and down.
When pressed and
held for 1second:
Fast-forward/
fast-backward.
Moves tracks up
and down.
When pressed and
held for 1second:
Fast-forward/
fast-backward.
Moves preset chan-
nels
up and down.
[I] PLAY/PAUSE No function. Switches between
playback and
pause.
Switches between
playback and
pause.
No function.
[§] MUTE Turns mute on and off.
[1] ISR Recalls ISR radio station
in memory.
Press and hold for 2seconds or longer: Stores current station into ISR memory (radio
mode only).
[ill DISP
WIDE When the display open, Display mode select. When the display Switches the TV
open and when pressed and held for 1second: Turns
on and off mode.
the monitor. (When the unit is in the DVD changer mode and the
vehicle is moving, operates in the same way on the CD/MD
changer. When the vehicle is stopped, changes the screen size.
When pressed and held: Turns
on and off the monitor.)
When the display close, Switches among main-display, sub-display, clock-display.
[[] PS/AS
SCN Preset scan. Scan
play.
When pressed and
held for 2seconds:
Auto store.
Scan play.
When pressed and
held for 1second:
Disc scan
play.
Preset scan.
When pressed and
held for 2seconds:
Auto store.
[1Q] AF
RPT No function. Repeat
play.
Repeat play.
When pressed and
held for 1second:
Disc repeat
play.
No function.
[TI] PTY
ROM
TV/VTR
No function. Random play.
Random play.
When pressed and
held for 1second:
Disc random play.
Switches between
TV and VTR.
[gj Z-EHCR Switches Z-ENHANCER
1,2,3, OFF
Notes:
•Some
of the corresponding buttons on the main unit and remote control unit have different functions.
•Please use the dedicated remote control unit provided with a
OVO player in the OVO mode or OVO changer
in the
OVO changer mode.
VRX835 13

II.IIIIP
The control panel can be detached to prevent
theft. When detaching the control panel, store it
in the DCP (DETACHABLE CONTROL PANEL)
case to prevent scratches.
We recommend taking the DCP with you when
leaving the
car.
Removing the DCP
1. Turn the power off.
2. Slide the [RELEASE] lever rightward to re-
lease the DCP/Operation Panel.
3. Pull the DCP toward you and remove it.
Attaching the DCP
1. Insert the DCP so that the ®section on the
right side of the DCP catches
on the hook ®
on the unit.
2. Press the left side of the DCP carefully to fit
it
in place.
3. Press the [FUNC] button to turn on the
power.
can easily be darna~led
After removing it, be careful not to
subject it to strong shocks.
•If the Operation Panel is kept open, the DCP
may
drop due to vibration of the car. This re-
sults in damage to the DCP. So close the Op-
eration Panel
or remove the DCP to store into
the case.
•The DCP
is an extremely important part. Be
careful
not to damage it by pressing on it with
fingernails,
screwdrivers, etc.
Note:
• If the DCP is dirty, wipe off the dirt with asoft, dry
cloth only
14
VRX835
AB

For alonger service fife, be sure to read the following cautions.
LCD panel/Generalities
9. CAUTIONS ON HANDLING
~f
•Do not place anything on the display when the
panel is tilted.
•The remote controller may not work if the re-
mote control sensor is exposed to direct sun-
light.
•
In extremely cold weather, the display move-
ment may slow down and the display may
darken, but this is not amalfunction. The dis-
play will work normally when the temperature
increases.
•Small black and shiny spots inside the LCD
panel are normal for LCD products.
•The LCD panel may stop temporarily when it
opens or closes, when the engine stops or
when it is cold.
•The touchkeys on the display operate when
slightly touched. Do not press the touchkey
screen with much force.
•Do not push the case surrounding the
touchkey panel with much force. This may
cause malfunctioning of the touchkeys.
•
Be sure to store the LCD panel inside the
main unit when parking the car outdoors for
long period of time. The LCD panel will oper-
ate properly
in atemperature range of 0to
60'C.
•Don't allow any liquids on the set from drinks,
umbrellas etc. Doing so may damage the
in~
ternal circuitry.
•Do not disassemble or modify the set in any
way. Doing so may result in damage.
•Do not draw the LCD panel out and use it
as a
tray. Also, sUbjecting the LCD panel to shocks
may result
in breakage, deformation or other
damage.
"Do not let cigarettes burn the display. Doing so
may damage or deform the cabinet.
•If aproblem should occur, have the set in-
spected at your store of purchase.
"Do not insert objects or poke in the space be-
tween the LCD panel and the main unit when
the panel is tilted.
Cleaning
•Cleaning the cabinet
Use asoft, dry cloth and gently wipe off the
dirt. For tough dirt, apply some neutral deter-
gent diluted
in water to asoft cloth, wipe off
the dirt gently, then wipe again with adry
cloth.
•Cleaning the LCD panel
The LCD panel tends to collect dust, so wipe
it off occasionally with asoft cloth. The sur-
face is easily scratched, so do not rub it with
hard objects.
Do not use benzene, thinner, car cleaner, etc.,
as these substances may damage the cabinet
or cause the paint to peel. Also, leaving rub-
ber or plastic products in contact with the
cabinet for long periods of time may cause
stains.
VRX835 15

l
MAIN Display
Notes:
(J Once selected, the preferred display becomes the
default display. When afunction adjustment such
as volume is made, the display momentarily
switches to that function's display, then returns
back to the preferred display several seconds af-
ter the adjustment.
• If atitle has been input, it is shown in the SUB
display.
If no title has been input, "NO TITLE"ap-
pears in the display. To input atitle, refer to the
subsection "Entering titles" in "Other Functions"
section.
•For
CD, MD and TV, some special characters of
the title, will not be displayed on the Information
Panel of the DCP. In this case, those characters
will only be left blank.
~
Clock Time Display
- VOL +' I,r- \- -r
«SRCH»;' II\IL -=, t
SUB Display
driving, keep the volume at a
which external sounds can be heard.
Switching the display
When the panel is closed:
Press the [DISP] button to select the desired
display.
Each time you press the [DISP] button, the dis-
play switches in the following order:
MAIN Display
Adjusting the volume
Operate the [VOL] button in the direction of the
+(up) or -(down) to adjust the volume;
+ : Increases the volume.
- : Decreases the volume.
The volume level indicated in the display is in a
range from 0(minimum) to 33 (maximum).
Selecting a mode
1. Press the [FUNC] button to change the mode
of operation.
2. Each time you press the [FUNC] button, the
mode of operation changes in the following
order:
Radio mode ... CD mode ... DVD video
mode'" CD changer mode'" MD changer
mode ... DVD changer mode TV mode ...
VISUAL mode ... Radio mode .
*External equipment not connected with
CeN ET is not selected.
Turning on and off the power
Note:
•Be careful about using this unit for along time
without running the engine.
If you drain the car's
battery too far, you may not be able to start the
engine and this can reduce the service life of the
battery.
1. Press the [FUNC] button.
2. The illumination and display on the unit light
up. The unit automatically remembers its last
operation mode and will automatically switch
to display that mode.
3. Press and hold the [FUNC] button for 1sec-
ond or longer to turn off the power for the
unit.
Note:
• About the "SYSTEM CHECK"
The confirmation of connected equipment must
be performed for this unit only when the wiring
connection is complete
and power is turned on to
the unit first. When the power is supplied, "SYS-
TEM" and "PUSH PWR" appearalternately in the
display. Press the [FUNC] button, the system
check starts inside the unit. When "COMPLETE"
appears, press once again the [FUNC] button.
When the unit is turned on, starting and stop-
ping the engine with its volume raised to the
maximum level may harm your hearings. Be
careful about adjusting the volume.
Note:
•Use this unit afterstarting the engine.
~ ACC or engine
\...?WJ ON position
16 VRX835

Showing a mode display
When the panel is open:
Touch the menu screen switching touchkey
when the main screen is being displayed to
show the menu screen.
Touch the Title List Select key (--- SELECT) on
the menu screen to show the Title List display.
In the Title List display, the titles of items stored
in the [DIRECT] buttons 1to 6are listed.
Opening and turning the display
A. WARNING
•To prevent the battery from going dead,
operate this unit with the engine run-
ning, if possible.
•When the liquid crystal panel is operating,
be careful
not to get your hand or finger
caught between
the panel and main unit
or the instrument panel of the car.
Standing up the liquid crystal panel
Press the [OPEN] button and the liquid crystal
panel comes out and stand up automatically.
II
II
,I
,I
,I
,I
,I
"
II
,I
..... ~:.: .. :~~
'" While the liquid crystal panel is opening or
closing, the LED blinks.
Note:
'" If the liquid crystalpanel stops in the middle of its
operation, press the [OPEN] button
to house the
panel andpress the button again
to stand it up.
The unit enters the same display mode as the dis-
play was turned off
the last time.
Basic Operations
Adjusting the angel, etc. of the
liquid crystal panel
The angle of the liquid crystal panel or protrud-
ing amount of the panel from the mounting sur-
face can be adjusted depending on the mount-
ing angle of the unit or light coming into the
car.
To adjust the angle
Every time the [TILT] button is pressed, the liq-
uid crystal panel tilts forward or backward at up
to about 20 degrees. The adjusted angel is
stored
in memory.
Note:
•Do not move the liquid crystal panel by hand.
To adjust the slide position
Press and hold the [TILT] button and release
when abeep is heard.
The liquid crystal panel slides forward or back-
ward. The adjusted slide position is stored
in
memory.
II
1,1,1
II
;I
! ~
1 I
1 I
I I
Housing the liquid crystal panel
Press the [OPEN] button and the liquid crystal
panel is housed automatically.
Note:
•When leaving this unit unused for along period of
time or leaving your car, be sure to house the liq-
uidcrystalpanel into the main unit.
VRX835 17

Basic Operations
Turning the liquid crystal
panel
horizontal (Air conditioner
operation mode)
When the way the liquid crystal panel is
mounted hinders the operation
of the air condi-
tioner, the position of the panel can be turned
horizontal temporarily.
1. Press and hold the [OPEN] button when the
liquid crystal panel is upright, and release
the button when abeep is heard.
2. The liquid crystal panel turns horizontal.
':' Press the [OPEN] button again when the liquid
crystal panel
is in the horizontal position, and
the panel returns to the original position.
': Even if the button is not operated for about 10
seconds, the panel returns to the original
position with awarning sound.
Turning on and off the monitor
Pressing and holding the [DISP] button for 1
second or longer turns the monitor off.
To return
to the monitor on, press the [DISP] button once
again.
When abutton
is pressed or during security moni-
toring, the monitor-off mode
is canceled.
Mute
Each time you press the ['-/11] button, mute is
turned on and off.
"MUTE" appears when mute is turned on.
Setting the Z-enhancer
This unit comes with 3types of sound tone effect
stored
in memory. Select the one you prefer.
:' The factory default setting is "Z-EHCR OFF".
When aZ-enhancer comes on (1-3), "Z-EHCR"
appears in the display.
c"Z·EHCR 1" (Z-Enhancer 1):
Setting emphasizing bass.
~"Z·EHCR 2" (Z-Enhancer 2):
Setting emphasizing treble.
•"Z-EHCR 3" (Z-Enhancer 3):
Setting emphasizing bass and
treble.
•"Z-EHCR OFF" (Z-Enhancer off):
Neither bass
nor treble are em-
phasized by the Z-enhancer.
Note:
•Incapable of operation when connecting OSP
(OPH910)
and OVO player (DVS9755z).
18 VRX835
When the panel is closed:
Each time you press the [Z-EHCR] button of the
remote control unit, the tone effect changes in
the following order:
"Z-EHCR 1" ~ "Z-EHCR 2" ~ "Z-EHCR 3" ~
"Z-EHCR OFF" ~ "Z-EHCR 1" ...
Note:
•When the panelis closed, operations can only be
made through the remote control unit.
When the panel is open:
1. Press the [A-M] button to change into the
AUDIO-MODE display.
2. Touch the [Z-ENHANCER] key when the AU-
DIO-MODE screen is being displayed to show
the Z-ENHANCER type selection screen.
3. When the Z-ENHANCER type selection
screen is displayed, touch the key for the de-
sirable type to select it.
•'TYPE 1" (Z-Enhancer 1)
•"TYPE 2" (Z-Enhancer 2)
.. 'TYPE 3" (Z-Enhancer 3)
.. "OFF" (Z-Enhancer off)
4. When the setting is finished, touch the [RTN]
key to return to the AUDIO-MODE screen.
Touch the [RTN] key on the AUDIO-MODE
screen to return to the STANDARD display.
To return from the Z-ENHANCER type
selection display
to the STANDARD display,
press the [A-M] button once again.
Adjusting the Z-enhancer
Notes:
~ The Z-enhancercannot be adjusted when it is
turned off.
• This function is enabled only when the panel is open.
1. Press the [A-M] button to change into the
AUDIO-MODE display.
2. Touch the [Z-EHCR LV] key when the AUDIO-
MODE screen
is being displayed to show the
Z-ENHANCER level adjustment screen.
3. Touch the [£.J or [""'] key to adjust to the de-
sirable level.
"When type 1
is selected, you can adjust the
bass in the range of ±2.
"When type 2 is selected, you can adjust the
treble
in the range of ±2.
,When type 3
is selected, you can adjust the
bass and treble in the range of ±2.
4. When adjustment is finished, touch the [RTN]
key on the Z-ENHANCER level adjustment

screen to return to the AUDIO-MODE screen.
Touch the [RTN] key on the AUDIO-MODE
screen to return to the STANDARD display.
* To return from the Z-Enhancer level mode
display to the STANDARD display, press the
[A-M] button once again.
Adjusting the bass and treble
Notes:
•This function is enabled onlywhen the panel is open.
•This function can be adjusted only when the Z-
enhanceris OFF.
1. Press the [A-M] button to change into the
AUDIO-MODE display.
2. Touch the [BASITREB] key when the AUDIO-
MODE screen is being displayed to show the
BASSfTREBLE LEVEL adjustment screen.
3. Touch the [ ... ]or [ ..... ]key to adjust to the
desirable BASSfTREBLE level (adjustment
range: from -6 to 6).
4. When adjustment is finished, touch the [RTN]
key on the BASSfTREBLE LEVEL adjustment
screen to return to the AUDIO-MODE screen.
Touch the [RTN] key on the AUDIO-MODE
screen to return to the STANDARD display.
To return from the BASStTREBLE LEVEL
mode display
to the STANDARD display, press
the [A-M] button once again.
Adjusting the balance and fader
Note:
•This function is enabled only when the panel is open.
1. Press the [A-M] button to change into the
AUDIO-MODE display.
2. Touch the [BAUFAD] key when the AUDIO-
MODE screen is being displayed to show the
BALANCE/FADER adjustment screen.
3. Touch the [ .... ]or [ ... ]key to adjust to the de-
sirable balance.
Adjusting range of the balance: left 13 to right 13
4. Touch the [ ... ]or [ ..... ]key to adjust to the de-
sirable fader.
Adjusting range
of the fader: front 12/ rear 12
5. When adjustment is finished, touch the [RTN]
key on the BALANCE/FADER adjustment
screen to return to the AUDIO-MODE screen.
Touch the [RTN] key on the AUDIO-MODE
screen to return to the STANDARD display.
':' To return from the BALANCE/FADER mode
display
to the STANDARD display, press the
[A-M] button once again.
Basic Operations
Turning
on/off the loudness
The loudness effect emphasizes the bass and
treble to create anatural sound tone. When you
are listening to music at alow volume, it is rec-
ommended to use the loudness effect.
This function is enabled only when the panel is open.
1. Press the [A-M] button for 1second or longer
to select Loudness ON. The "LO" indicator
lights in the display.
2. Press the [A-M] button for 1second or longer
to select Loudness OFF. The "LD" indicator
goes off.
Note:
•When using asoldseparately digital sound pro-
cessor(DPH910)
or OVD player(DVS9755z), a
feature calledauto loudness is selected. This
function is different from the loudness effect. For
further details on the auto loudness feature, refer
to the subsection
"Output adjustment of auto
loudness, subwoofer and playback band".
Changing the setting of the display
background
.. ........ ~ ...
Perform the setting of this function the car
is stopped
with the parking break applied.
1. Press the [DISP] button to show the back-
ground setup menu.
2. Touch the setting key to show the setup dis-
play.
e To set up the pattern and colour of the wall
paper
2-1. Touch the [WALL PAPER] key to select
"PATTERN" or "COLOR".
2-2. Touch the [PATTERN]
or [COLOR] key
to set adesired pattern
or colour.
2-3. Touch adesired [PATTERN] or
[COLOR]
key.
e To set up the motion pattern
2-1. Touch the [MOTION PATTERN] key to
set adesired motion pattern.
2-2. Touch adesired [MOTION PATTERN]
key.
eTa set up the sprite pattern
2-1. Touch the [SPRITE PATTERN] key to
set adesired sprite pattern.
2-2. Touch adesired [SPRITE PATTERN]
key.
3. Press the [DISP] button again or touch the
[RTN] key two times to return to the STAN-
DARD display.
VRX835 19

Radio Operations
FM reception
For enhanced FM pertormance the mRIiI:rUNE~
®tuner includes signal actuated stereo control,
Enhanced Multi AGe, Impulse noise reduction
curcuits and Multipath noise reduction circuits.
Changing the reception area
This unit is initially set to USA frequency inter-
vals of 10kHz for AM and 200kHz for FM. When
using it outside the USA, the frequency recep-
tion range can be switched to the intervals be-
low.
•Setting the reception area
While pressing [DISP] button, each time you
press and hold the number "6" of the [DIRECT]
buttons for 2seconds or longer, the reception
area switches from inside the USA to outside
the USA
or from outside the USA to inside the
USA.
':' Any station preset memories are lost when the re-
ception area is changed.
Listening to the radio
1. Press the [FUNC] button and select the RA-
DIO mode. The frequency is displayed.
2. Press the [BAND] button and select the radio
band. Each time the button is pressed, the
radio reception band changes in the following
order:
FM1 -+ FM2 -+ FM3 -+ AM -+ FM1...
3. Press the right ( .. »or left « .... )side of the
[SEARCH] button to tune
in the desired sta-
tion.
Tuning
There are 3types of tuning mode available,
seek tuning, manual tuning and preset tuning.
Seek tuning
1. Press the [BAND] button and select the de-
sired band. (FM or AM)
2. Tune in to astation.
':' If "MANU" is lit in the display (or when the
panel is closed, if the indication" SRCH" is not
lit) press and hold the [BAND] button for 1
second or longer. "MANU"
in the display goes
off (or
when the panel is close the indication
"SRCH" lights) and seek tuning is now
available.
3. Press the right ( .. >)or left « .... )side of the
[SEARCH] button to automatically seek a
station.
When the right (
.. »side of the [SEARCH]
button is pressed, the station is sought
in the
direction of higher frequencies; when the left
« .... )side of the [SEARCH] button is
pressed, the station is sought in the direction
of lower frequencies.
Manual tuning
There are 2ways available: Quick tuning and
step tuning.
When you are
in the step tuning mode, the fre-
quency changes one step at atime.
In quick tun-
ing mode, you can qUickly tune the desired fre-
quency.
1. Press the [BAND] button and select the de-
sired band. (FM or AM)
':' If "MANU" is not lit in the display (or when the
panel is closed, if the indicator" SRCH " is lit),
press and hold the [BAND] button for 1
second or longer. "MANU" appears
in the
display (or
when the panel is closed, the
indicator"
SRCH "goes off) and manual tuning
is now available.
2. Tune into astation.
• Quick tuning:
Press and hold the right ( .. »or left « .... )
side of the [SEARCH] button for 1second or
longer to tune
in astation.
•Step tuning:
Press the right ( .. »or left « .... )side of the
[SEARCH] button to manually tune
in asta-
tion.
Recalling a preset station
Atotal of 24 preset positions (6-FM1, 6-FM2, 6-
FM3, 6-AM) exists to store individual radio sta-
tions in memory. Pressing the corresponding
[DIRECT] button recalls the stored radio fre-
quency automatically.
1. Press the [BAND] button and select the de-
sired band. (FM or AM)
2. Press the corresponding [DIRECT] button to
recall the stored station.
*Press and hold one of the [DIRECT] buttons
for 2seconds or longer to store that station
into preset
memory.
'" When the panel is open, the same operation
is also available by using the «...]and [~>]
button in the panel.
20 VRX835
