Clarion DVS970Z User manual

- 1 - DVS9755z/
DVS970Z
Published by Service Dept.
Printed in Japan
Clarion Co., Ltd.
22-3, Shibuya 2-chome, Shibuyaku, Tokyo, 150-8335 Japan
Service Dept.- 50 kamitoda,Toda-shi,Saitama,335-8511 Japan Tel: [phone] FAX:[phone]
298-5899-00 3.2001 B
Service Manual
Model
Model
DVD/CD Player/Multiple Channel
Processor
(PE-2360E)
(PE-2359B)
FOR U.S.A.
(PE-2359K)
FOR OTHER COUNTRIES
■SPECIFICATIONS
DVD player section
System: Digital Versatile Disc System with
CDDA Capable
Usable Discs: DVD Video Disc,Compact Disc
Frequency Response: 20 Hz to 20kHz (±1dB)
S/N Ratio: 100dB
Dynamic Range: 100dB
Distortion: 0.01％THD
Channel Separation: 80dB
Audio section
S/N Ratio: 100dB(digital input)
100dB(analog input)
Frequency characteristics:
20 Hz to 20kHz (±1dB)
Separation: 90dB(digital input)
80dB(analog input)
High frequency distortion:
0.01％(digital input)
0.01％(analog input)
Analog output: 4.0Vrms(Vol Max.)
Analog input: 2.0Vrms(Max.)
Digital input: 44.1kHz sampling,
16-bit digital audio data
DSF: 6 modes
P.EQ: 3 bands ×2(front/rear independent)
Fo;20 Hz to 20kHz
1/3 octava steps
Q;1 to 20
G;±12dB
Preset front; 6types
Rear; 7types
Subwoofer voltage gain;＋12dB
(M.Vol Max.)
LPF Fo;50 Hz,80Hz,120Hz
LPF slope;12,18,24 dB/oct
General
Power supply voltage: DC14.4V(10.8 to 15.6V allowable)
Negative ground
Current consumption: Less than 3A
Dimensions(mm): 178(W)×50(H)×165(D)
Weight: about 1.6kg
Remote control unit
Dimensions(mm): 47(W)×142(H)×32(D)
Weight: 30g(including battery)
※Specifications and design are subject to change without
notice for further improvement.
■COMPONENTS
PE-2359B-A
DVD disc unit −−−−− 1
Control unit −−−−− 1
Control unit cord 855-2464-00 1
Power supply harness 854-6377-50 1
Fuse (3A) 120-0030-00 1
Parts bag(1) 921-9596-00 1
Set screw(M2.6x4) 714-2604-80 1
Cord clamps(small) 321-1024-00 1

- 2 -
DVS9755z/
DVS970Z
c
c
Double sided tape for brackets(30x140)
345-7030-00 1
Lead holder(L99) 335-0833-01 3
Cord holder 321-1026-00 2
Velcro tape(large A) 348-0327-00 2
Velcro tape(small B) 348-0326-00 2
M5 wing nuts 724-6000-11 4
Installation bolt(M5x6) 714-5006-41 4
Double sided tape for remo-con holder(25x50)
347-5559-00 1
Installation bolt(M5x6 counter sunk)
716-1561-01 4
Parts bag(2) 921-9597-00 1
Hook plate 330-8216-01 2
Side spring 750-2796-02 2
Rubber cap 345-3653-20 1
Rear bolt 716-0726-01 1
Machine screw(M5x6) 714-5006-41 2
Bracket with bolt 300-9548-03 2
Main unit bracket 300-9683-01 2
Remote control RCB-037-130 1
Batteries for remote control(AAA) −−−−− 2
Remote control holder 335-6146-00 1
Universal mounting bracket 300-9035-01 1
Strap 300-4976-00 1
Outer escutcheon 370-9006-03 1
PE-2359K-A,B
DVD disc unit −−−−− 1
Control unit −−−−− 1
Control unit cord 855-2464-00 1
Power supply harness 854-6377-50 1
Fuse (3A) 120-0030-00 1
Parts bag(1) −−−−− 1
Set screw(M2.6x4) 714-2604-80 1
Cord clamps(small) 321-1024-00 1
Double sided tape for brackets(30x140)
345-7030-00 1
Lead holder(L99) 335-0833-01 3
Cord holder 321-1026-00 2
Velcro tape(large A) 348-0327-00 2
Velcro tape(small B) 348-0326-00 2
M5 wing nuts 724-6000-11 4
Installation bolt(M5x6) 714-5006-41 4
Double sided tape for remo-con holder(25x50)
347-5559-00 1
Installation bolt(M5x6 counter sunk)
716-1561-01 4
Parts bag(2) −−−−− 1
Hook plate 330-8216-01 2
Side spring 750-2796-02 2
Rubber cap 345-3653-20 1
Rear bolt 716-0726-01 1
Machine screw(M5x6) 714-5006-41 2
Parts bag(3) (only K-A) −−−−− 1
Ferrite core(small) 060-8041-00 1
Ferrite core(large) 060-8042-00 2
Bracket with bolt 300-9548-03 2
Main unit bracket 300-9683-01 2
Remote control RCB-037-400 1
Batteries for remote control(AAA) −−−−− 2
Remote control holder 335-6146-00 1
Universal mounting bracket 300-9035-01 1
Strap 300-4976-00 1
Outer escutcheon 370-9006-03 1
PE-2360E-A
DVD disc unit −−−−− 1
Control unit −−−−− 1
Control unit cord 855-2464-00 1
Power supply harness 854-6377-50 1
Fuse (3A) 120-0030-00 1
Parts bag(1) 921-9600-00 1
Set screw(M2.6x4) 714-2604-80 1
Cord clamps(small) 321-1024-00 1
Double sided tape for brackets(30x140)
345-7030-00 1
Lead holder(L99) 335-0833-01 3
Cord holder 321-1026-00 2
Velcro tape(large A) 348-0327-00 2
Velcro tape(small B) 348-0326-00 2
M5 wing nuts 724-6000-11 4
Installation bolt(M5x6) 714-5006-41 4
Double sided tape for remo-con holder(25x50)
347-5559-00 1
Installation bolt(M5x6 counter sunk)
716-1561-01 4
Parts bag(2) 921-9622-00 1
Ferrite core(small) 060-8041-00 1
Ferrite core(large) 060-8042-00 2
Bracket with bolt 300-9548-03 2
Main unit bracket 300-9683-01 2
Remote control RCB-037-400 1
Batteries for remote control(AAA) −−−−− 2
Remote control holder 335-6146-00 1
Universal mounting bracket 300-9035-01 1
Strap 300-4976-00 1
Outer escutcheon 370-9006-03 1
■NOTE
※We cannot supply PWB with component parts in prin-
ciple. When a circuit on PWB has failure , please repair
it by component parts base. Parts which are not men-
tioned in service manual are not supplied.
※This product incorporates copyrigh protection technol-
ogy that is protected by methon claims of certain
U.S.patents and other intellectual property rights
owners.Use of this copyright protection tecnology must
be authorized by Macrovision Corporation,and is in-
tended for home and other limited viewing uses only
unless otherwise authorized by Macrovision Corporation.
Reverse engineering or disassembly is prohibited.
※Manufactured under license from dolby Laboratories.
"Dolby","Pro Logic"and duble-D symbol are tradmarks
of Dolby Laboratories.
Works.○1992-1997 Dolby Laboratories,Inc.All rights
reserved.
※Manufactured under license from Digital Theater
Systems,Inc.US Pat.5,451,942 5,956,674 5,974,380
5,978,762 and other world-wide patents issusd and pend-
ing.
"DTS"and"DTS Digital surround"are registered tradmarks
of Digital Theater Systems,Inc.○1996,2000 Digital The-
ater Systems,Inc.All Rights Reserved.
※Prevent damage caused by static electricity when re-
pairing the pick-up.
The pattern of the pick-up is short-circuiting for preven-

- 3 - DVS9755z/
DVS970Z
■To engineers in charge of repair or
inspection of our products.
Before repair or inspection, make sure to follow
the instructions so that customers and Engineers
in charge of repair or inspection can avoid suf-
fering any risk or injury.
1. Use specified parts.
The system uses parts with special safety features against
fire and voltage. Use only parts with equivalent charac-
teristics when replacing them.
The use of unspecified parts shall be regarded as re-
modeling for which we shall not be liable. The onus of
product liability (PL) shall not be our responsibility in cases
where an accident or failure is as a result of unspecified
parts being used.
2. Place the parts and wiring back in their original positions
after replacement or re-wiring.
For proper circuit construction, use of insulation tubes,
bonding, gaps to PWB, etc, is involved. The wiring con-
nection and routing to the PWB are specially planned
using clamps to keep away from heated and high voltage
parts. Ensure that they are placed back in their original
positions after repair or inspection.
If extended damage is caused due to negligence during
repair, the legal responsibility shall be with the repairing
company.
3. Check for safety after repair.
Check that the screws, parts and wires are put back se-
curely in their original position after repair. Ensure for
safety reasons there is no possibility of secondary
tion.
Remove the soldering with a solder iron whose insula-
tion resistance is larger than 10MΩ(DC500V) after com-
plete connection to the main PWB
For repair table shall use copper or conductive sheet
(with impedance is lower than 1GΩ)such as a sheet.
Be sure to put on a wrist-strap for prevent electric
static's.(with impedance lower than 100MΩ) The strap
works to drain away the static electricity build-up on the
human body.
And as static electricity build-up on clothes is not drained
away, be careful and not your clothes to touch the pick-
up.
Position of short soldering for pick-up protection posi-
tion is different by model.
Some units have two short soldering points.
Always short LD circuit to open the short circuit and re-
moves by soldering iron.
This appliance contains a laser system and is classified as
a "CLASS 1 LASER PRODUCT".To use this model
properly,read this Owner's Manual carefully and keep this
manual for your future reference.In case of any trouble with
this player,please contact your nearest "AUTHORIZED ser-
vice station".To prevent direct exposure to the laser beam,do
not try to open the enclosure.
■CAUTION
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules.These limits are designed to provide rea-
sonable protection against harmful interference in a resi-
dential installation.This equipment generates,uses,and can
radiate radio frequency energy and,if not installed and used
in accordance with the instructions,may cause harmful in-
terference to radio communications.However,there is no
quarantee that interference will not occur in a particular
installation.If this equipment does cause harmful interfer-
ence to radio or television reception,which can be deter-
mined by turning the equipment off and on,the user is en-
couraged to consult the dealer or an experienced radio/TV
technician for help.
Top View of model
Top View of model

- 4 -
DVS9755z/
DVS970Z
ploblems around the repaired spots.
If extended damage is caused due to negligence of re-
pair, the legal responsibility shall be with the repairing
company.
4. Caution in removal and making wiring connection to the
parts for the automobile.
Disconnect the battery terminal after turning the ignition
key off. If wrong wiring connections are made with the
battery connected, a short circuit and/or fire may occur.
If extensive damage is caused due to negligence of re-
pair, the legal responsibility shall be with the repairing
company.
5. Cautions regarding chips.
Do not reuse removed chips even when no abnormality
is observed in their appearance. Always replace them
with new ones. (The chip parts include resistors, capaci-
tors, diodes, transistors, etc). The negative pole of tanta-
lum capacitors is highly susceptible to heat, so use spe-
cial care when replacing them and check the operation
afterwards.
6. Cautions in handling flexible PWB
Before working with a soldering iron, make sure that the
iron tip temperature is around 270℃. Take care not to
apply the iron tip repeatedly(more than three times)to the
same patterns. Also take care not to apply the tip with
force.
7. Turn the unit OFF during disassembly and parts replace-
ment. Recheck all work before you apply power to the
unit.
8. Cautions in checking that the optical pickup lights up.
The laser is focused on the disc reflection surface through
the lens of the optical pickup. When checking that the
laser optical diode lights up, keep your eyes more than
30cms away from the lens. Prolonged viewing of the la-
ser within 30cms may damage your eyesight.
9. Cautions in handling the optical pickup
The laser diode of the optical pickup can be damaged by
electrostatic charge caused by your clothes and body.
Make sure to avoid electrostatic charges on your clothes
or body, or discharge static electricity before handling the
optical pickup.
9-1. Laser diode
The laser diode terminals are shorted for transpor-
tation in order to prevent electrostatic damage.
After replacement, open the shorted circuit. When
removing the pickup from the mechanism, short
the terminals by soldering them to prevent this
damage.
9-2. Actuator
The actuator has a powerful magnetic circuit. If a
magnetic material is put close to it. its characteris-
tics will change. Ensure that no foreign substances
enter through the ventilation slots in the cover.
9-3. Cleaning the lens
Dust on the optical lens affects performance. To
clean the lens, apply a small amount of isopropylalcohol
to lens paper and wipe the lens gently.
■ERROR DISPLAYS
If an error display other than the ones described above appears,press the reset botton.If the problem
persists,turn off the power.
If an error occurs,one of the following displays is displayed.
Take the measures described below to eliminate the problem.
Error Display Cause Measure
ERROR 2
ERROR 3
ERROR 6
A DVD/CD is caught inside the DVD deck
and is not ejected.
A DVD/CD cannot be played due to
scratches,etc.
A VDV/CD is loaded upside-down inside the
DVD deck and does not play.
This is a failure of DVD deck's mechanism.
Replace with a non-scratched,non-warped-disc.
Eject the disc then reload it properly.
Reset botton.

- 5 - DVS9755z/
DVS970Z
■BLOCK DIAGRAM

- 6 -
DVS9755z/
DVS970Z
■EXPLANATION OF IC pin 65 : DVD/CD : O : Disk distinction signal output.
pin 66 : LAYER : O : DVD type signal output (single layer/
dual layer).
pin 67 : PREVENT : IN : Prevent Japan.
pin 68 : CHUCK SW_ : IN : Chucking switch signal input.
pin 69 : TR A : IN : Photo sensor signal input.
pin 70 : TR B : IN : Photo sensor signal input.
pin 71 : TR C : IN : Photo sensor signal input.
pin 72 : NU : - : Not in use.
pin 73 : NU : - : Not in use.
pin 74 : NU : - : Not in use.
pin 75 : NU : - : Not in use.
pin 76 : MA_ : O : MA.
pin 77 : NU : - : Not in use.
pin 78 : NU : - : Not in use.
pin 79 : A 8 : O : Address output.
pin 80 : A 7 : O : Address output.
pin 81 : A 6 : O : Address output.
pin 82 : A 5 : O : Address output.
pin 83 : A 4 : O : Address output.
pin 84 : A 3 : O : Address output.
pin 85 : A 2 : O : Address output.
pin 86 : A 1 : O : Address output.
pin 87 : A 0 : O : Address output.
pin 88 : READ_ : O : Reading strobe signal output.
pin 89 : WRITE_ : O : Writing Strobe signal output.
pin 90 : NU : - : Not in use.
pin 91 : VSS : - : Negative supply voltage.
pin 92 : TK 0 : IN : Test mode key input.
pin 93 : TK 1 : IN : Test mode key input.
pin 94 : TK 2 : IN : Test mode key input.
pin 95 : TK 3 : IN : Test mode key input.
pin 96 : TM 1 : IN : Test mode selectionion input.
pin 97 : TM 2 : IN : Test mode selectionion input.
pin 98 : LIMIT SW : IN : Inside limit switch signal for the disk.
pin 99 : NU : - : Not in use.
pin100 : Vref : - : Reference voltage
052-5042-00 M30622MCA-E53GP DVD Player controller
1.Terminal Description
pin 1 : NU : - : Not in use.
pin 2 : NU : - : Not in use.
pin 3 : EJECT KEY _ : IN : Eject key switch input. Negative logic.
pin 4 : NU : - : Not in use.
pin 5 : REMOCON : IN : Remote controller signal input terminal.
pin 6 : BYTE_ : IN : Connect to VSS.
pin 7 : CN VSS_ : IN : Connect to VSS.
pin 8 : INIT 1 : IN : Destination setting input. Ref. Table 1.
pin 9 : INIT 2 : IN : Destination setting input. Ref. Table 1.
pin 10 : RESET_ : IN : Reset signal input. Negative logic.
pin 11 : X OUT : O : Crystal connection.
pin 12 : VSS : - : Negative supply voltage.
pin 13 : X IN : IN : Crystal connection.
pin 14 : VCC : - : Positive supply voltage.
pin 15 : NU : - : Not in use.
pin 16 : ACC DET : IN : ACC detect signal input. "H"= ACC
ON.
pin 17 : B/U OFF DET_ : IN : Backup voltage OFF signal input.
pin 18 : POWER KEY_ : IN : Power Key interrupt signal input.
pin 19 : 27pinCONNECT: IN : Connect to pin 27.
pin 20 : DIR SI : IN : Serial data input from the digital-audio-
interface-receiver.
pin 21 : DIR SO : O : Serial data output to the digital-audio-
interface-receiver.
pin 22 : NU : - : Not in use.
pin 23 : DIR CL : O : Clock pulse output to the digital-audio-
interface-receiver.
pin 24 : DIR CE : O : Chip enable pulse output to the digital-
audio-interface-receiver.
pin 25 : A IN SEL : O : RCA= "L", Ce-NET= "H"
pin 26 : V I/O SEL : O : External input = "H"
pin 27 : IE BUS RX : IN : IE Bus communication line.
052-5041-02 TMP95CW64F-3A88(Z) DVD Mechanizm controller
1.Terminal Description
pin 1 : Vref : - : Reference voltage
pin 2 : A VSS : - : Analog ground.
pin 3 : A VCC : - : Positive supply voltage for the internal
analog section.
pin 4 : NU : - : Not in use.
pin 5 : NU : - : Not in use.
pin 6 : NMI_ : IN : Connect to pin-7.
pin 7 : EJECT : IN : Eject signal input. Negative logic.
pin 8 : A MUTE : O : Audio mute signal output.
pin 9 : SYS P 1 : O : Power supply-1 control signal output.
pin 10 : NU : - : Not in use.
pin 11 : RESET OUT_ : O : Reset signal output.
pin 12 : T SCAN 0 : O : Test mode scan output.
pin 13 : T SCAN 1 : O : Test mode scan output.
pin 14 : T SCAN 2 : O : Test mode scan output.
pin 15 : T SCAN 3 : O : Test mode scan output.
pin 16 : MCW : O : Loading motor control output.
pin 17 : MCCW : O : Loading motor control output.
pin 18 : NU : - : Not in use.
pin 19 : NU : - : Not in use.
pin 20 : CS 0_ : O : Chip selection signal output.
pin 21 : CS 1_ : O : Chip selection signal output.
pin 22 : NU : - : Not in use.
pin 23 : M MUTE : O : M MUTE.
pin 24 : NU : - : Not in use.
pin 25 : VCC : - : Positive supply voltage.
pin 26 : VSS : - : Negative supply voltage.
pin 27 : X 1 : - : Crystal connection.
pin 28 : X 2 : - : Crystal connection.
pin 29 : EX ACCESS_ : IN : External access selection.
pin 30 : RESET : IN : Reset signal input. Negative logic.
pin 31 : ACC CONT : IN : ACC control signal input.
pin 32 : NU : - : Not in use.
pin 33 : TIME : O : Loading time & Eject time control out-
put.
pin 34 : FGPULSE : IN : FG pulse input.
pin 35 : S BRAKE : O : Brake command output to the disk-mo-
tor.
pin 36 : NU : - : Not in use.
pin 37 : DSP INT : IN : Interrupt signal input.
pin 38 : NU : - : Not in use.
pin 39 : PLL A : O : PLL control output.
pin 40 : PLL B : O : PLL control output.
pin 41 : M INT_ : IN : Interrupt signal input.
pin 42 : NU : - : Not in use.
pin 43 : AT RESET : O : Reset signal output.
pin 44 : VCC : - : Positive supply voltage.
pin 45 : D 0 : I/O : Data input / output.
pin 46 : D 1 : I/O : Data input / output.
pin 47 : D 2 : I/O : Data input / output.
pin 48 : D 3 : I/O : Data input / output.
pin 49 : D 4 : I/O : Data input / output.
pin 50 : D 5 : I/O : Data input / output.
pin 51 : D 6 : I/O : Data input / output.
pin 52 : D 7 : I/O : Data input / output.
pin 53 : RS : O : Test mode LCD driver control RS.
pin 54 : R/W : O : Test mode LCD driver control R/W.
pin 55 : E : O : Test mode LCD driver control E.
pin 56 : NU : - : Not in use.
pin 57 : DB 4 : I/O : Test mode LCD driver control DB.
pin 58 : DB 5 : I/O : Test mode LCD driver control DB.
pin 59 : DB 6 : I/O : Test mode LCD driver control DB.
pin 60 : DB 7 : I/O : Test mode LCD driver control DB.
pin 61 : AM 8 : O : Connect to VCC.
pin 62 : VSS : - : Negative supply voltage.
pin 63 : VCC : - : Positive supply voltage.
pin 64 : BUSY : O : Busy flag output.

- 7 - DVS9755z/
DVS970Z
pin 33 : DISP DO : O : Serial data output to the LCD driver.
pin 34 : DISP DI : IN : Serial data input from the LCD driver.
pin 35 : DISP CLK : O : Clock pulse output to the LCD driver.
pin 36 : DISP CE : O : Chip enable signal output to the LCD
driver.
pin 37 : NU : - : Not in use.
pin 38 : DIRF 0 : O : Sample frequency select signal output.
pin 39 : DEC P OFF_ : IN : Power off admission signal input from
RISC CPU.
pin 40 : DIRF 1 : O : Sample frequency select signal output.
pin 41 : DEC SYS ACC : O : SYS-ACC output of RISC CPU.
pin 42 : DIRF 2 : O : Sample frequency select signal output.
pin 43 : DEC RST IN_ : IN : Reset request from RISC IC.
pin 44 : DIR RESET_ : O : Reset pulse output to the digital-audio-
interface-receiver.
pin 45 : DIR EMPHA : IN : Pre-emphasis selection.
pin 46 : DIR AUDIO : IN : PCM audio data = "L", Others = "H".
pin 47 : MECH 5V REM: O : 5V and 3.3V power supply control for
the mechanism.
pin 48 : 2.5 V REM : O : ACC 2.5V power supply control.
pin 49 : 3.3 V REM : O : ACC 5V and ACC 3.3V power supply
control.
pin 50 : DAC MC : O : Colck pulse output to the DAC.
pin 51 : DD 15 CONT : O : Power supply control output for the au-
dio sections.
pin 52 : DD 3.3 CONT : O : ACC 5V, ACC 3.3V, ACC 2.5V power
supply control.
pin 53 : DAC ML : O : Latch pulse output to the DAC.
pin 54 : 10 V REM : O : 10V power supply control for DVD
mechanism.
pin 55 : DAC MDI : O : Serial data output to the DAC.
pin 56 : DAC RESET_ : O : Reset pulse output to the DAC.
pin 57 : VOL STB : O : Strobe pulse output to the Electric vol-
ume or the digital-audio-interface-re-
ceiver.
pin 58 : VOL DATA : O : Serial data output to the electric vol-
ume IC.
pin 59 : VOL CLOCK : O : Serial data clock output for the electric
volume IC.
pin 60 : VCC : - : Positive supply voltage.
pin 61 : DIR ERR : IN : digital-audio-interface-receiver error de-
tection.
pin 62 : VSS : - : Negative supply voltage.
pin 63 : DSP RESET_ : O : Reset pulse output to DSP IC.
pin 64 : DSP 0V : IN : Sub DSP over flow detection.
pin 65 : ADC RESET_ : O : Reset pulse output to the ADC.
pin 66 : ADC 0V : IN : ADC over flow detection.
pin 67 : VIDEO MUTE_ : O : Video muting signal output.
pin 68 : AMP REM OUT: O : Amplifier ON signal output terminal.
pin 69 : NU : - : Not in use.
pin 70 : NU : - : Not in use.
pin 71 : DIR X STATE_ : IN : digital-audio-interface-receiver/PLL un-
lock detection.
pin 72 : AMP REM DT_ : IN : Remote controller wire short detection.
pin 73 : Speed pulse_ : IN : Speed pulse input.
pin 74 : SYS MUTE_ : O : System mute signal output. Negative
logic.
pin 75 : LINE MUTE_ : O : Mute signal output for Audio signal of
Ce-NET. Negative logic.
pin 76 : EJECT OUT_ : O : Eject command output.
pin 77 : NU : - : Not in use.
pin 78 : NU : - : Not in use.
pin 79 : DVD RESET_ : O : Reset pulse output to DVD mechanism.
pin 80 : DVD A MUTE_ : IN : Mute request input from DVD mecha-
nism.
pin 81 : DVD ACC CNT : O : DVD mechanism ACC-CONT.
pin 82 : DVD SYS P-1 : IN : From DVD mechanism.
pin 83 : REG 1 : IN : Region code input.
pin 84 : REG 2 : IN : Region code input.
pin 85 : REG 3 : IN : Region code input.
pin 86 : NU : - : Not in use.
pin 87 : KEY A/D : IN : Input terminal of A/D converter for Key
judgment. Ref. Table 2.
pin 88 : NTSC/PAL_ : IN : NTSC = "H", PAL = "L".
pin 89 : DECK BB_ : IN : Initial setting input, DVD deck = "H"
pin 90 : STND ALONE_ : IN : Stand alone = "L", Ce-NET slave =
"H".
pin 91 : PKB : IN : "H"= Parking brake ON
pin 92 : DSP CSB_ : O : Sub DSP chip selection output.
pin 93 : DSP CS_ : O : DSP chip selection output.
pin 94 : A VSS : - : Analog ground.
pin 95 : NU : - : Not in use.
pin 96 : Vref : - : Reference voltage
pin 97 : A VCC : - : Positive supply voltage for the internal
analog section.
pin 98 : DSP SI : IN : Serial data input from the DSP IC.
pin 99 : DSP SO : O : Serial data output to the DSP IC.
pin100 : DSP SCK : O : Clock pulse output to the DSP IC.
Table 1. Destination setting input
North Third
America area Japan Europe
INITIAL 1 ( pin 8 ) H L H L
INITIAL 2 ( pin 9 ) L L H H
Table 2. Input of A/D converter for Key judgment ( pin 87 )
Judgment A/D steps
Power key 0/255 to 25/255
With Controller 205/255 to 238/255
Without Controller 239/255 to 255/255
pin 28 : IE BUS TX : O : IE Bus communication line.
pin 29 : DEC TX : O : Transmit terminal to RISC CPU.
pin 30 : DEC RX : IN : Receive terminal from RISC CPU.
pin 31 : DEC RSTX_ : O : Reset pulse output to RISC CPU.
pin 32 : DEC REQ : IN : Request signal input from RISC CPU.

- 8 -
DVS9755z/
DVS970Z
Note)Several different parts of the same reference number are alternative parts.
One of those parts is used in the set.
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
Note)Some parts depend on each model.The model name is specified in the description.
■EXPLODED VIEW・PARTS LIST
Control unit
1 373-0946-00 DIAL COVER(PE-2359) 1
373-0946-20 DIAL COVER(PE-2360)
2 370-5917-00 ESCUTCHEON 1
3 382-6024-00 BUTTON(POW,ADJ,SOU) 1
4 382-6025-00 BUTTON(DSF,AMOD) 1
5 382-6026-00 BUTTON(VOL-D,L) 1
6 382-6027-00 BUTTON(MUT,ENT) 1
7 382-6028-00 BUTTON(R) 1
8 382-6029-00 BUTTON(VOL-U) 1
9 347-6428-00 FILM 2
10 347-6429-00 FILM 1
11 347-6430-00 FILM 1
12 290-7920-00 LABEL(2359B) 1
290-8007-00 LABEL(2359K)
290-7920-00 LABEL(2360E)
13 378-0516-00 BADGE(clarion) 1
14 335-6420-00 ILLUMI PLATE 1
15 716-0872-01 PAD SCREW(M1.7×6) 3
16 001-7040-01 LED(WHITE) 3
17 379-1191-41 INDICATOR 1
18 001-7046-00 LED(WHITE) 1
19 331-2809-01 LCD COVER 1
20 347-6169-00 SHADE 1
21 347-6480-00 REFLECTOR 1
22 335-6213-00 ILLUMI PLATE 1
23 335-6209-00 LCD HOLDER 1
24 335-6216-00 LED HOLDER 1
25 345-8273-00 RUBBER CONNECTOR 1
26 345-8274-00 RUBBER CONNECTOR 1
27 855-8000-02 MINI DIN CORD 1
28 335-6419-00 REAR COVER 1
29 013-6507-50 SWITCH 11
30 716-0872-11 PAD SCREW(M1.7×6BLK) 4
31 039-1833-00 SWITCH PWB 1
(WITHOUT COMPONENT)
32 345-8605-00 CAP 4
33 347-6475-00 SHADE 1
34 060-4005-02 IR RECEIVER 1

- 9 - DVS9755z/
DVS970Z
DVD disc unit
24
44

- 10 -
DVS9755z/
DVS970Z
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
1 286-9439-00 SET PLATE(2359B) 1
286-9530-00 SET PLATE(2359K-A)
286-9558-00 SET PLATE(2359K-B)
286-9454-00 SET PLATE(2360E)
2 311-1780-20 LOWER CASE 1
3 345-7555-00 SPACER 1
4 331-3038-00 EARTH PLATE 1
5 816-2521-00 FLAT WIRE 1
6 854-4504-30 EXTENTION LEAD 1
7 347-6358-00 INSULATOR 1
8 345-3799-00 PIN CAP 10
9 300-7790-00 MOUNTING BRACKET(L) 1
10 929-2102-00 DVD MECHANISM 1
11 300-7789-00 MOUNTING BRACKET(R) 1
12 310-1688-01 UPPER CASE 1
13 347-6368-00 FILM 1
14 714-2303-81 MACHINE SCREW(M2.3×3) 6
15 714-2604-89 MACHINE SCREW(M2.6×4BLK) 7
16 716-0878-00 IT SCREW(M2.6×5) 6
17 714-2604-80 MACHINE SCREW(M2.6×4) 3
18 347-6516-00 INSULATOR 1
19 013-6100-00 SWITCH 1
20 020-3044-00 FAN MOTOR 1
21 331-3037-00 REAR PLATE 1
22 855-5444-50 4CH PIN CORD 1
23 855-5446-50 6CH PIN CORD 1
24 940-7878-10 ESCUTCHEON ASSY(2359B) 1
940-7878-30 ESCUTCHEON ASSY(2359K)
940-7878-20 ESCUTCHEON ASSY(2360E)
25 714-3006-81 MACHINE SCREW(M3×8) 1
26 780-2615-00 MACHINE SCREW(M2.6×15) 2
27 074-0898-10 OUTLET SOCKET(10P) 1
28 074-0898-14 OUTLET SOCKET(14P) 1
29 331-3036-00 FAN BRACKET 1
30 039-1832-00 DVD DISC UNIT PWB 1
(WITHOUT COMPONENT)
31 076-0349-02 PLUG(2P) 1
32 060-6016-00 DC-DC CONVERTER 1
33 073-0775-00 TERMINAL 2
34 076-0368-10 PLUG(10P) 1
35 074-1194-00 OUTLET SOCKET(Ce-NET) 2
36 074-1270-08 OUTLET SOCKET(DIN 8P) 1
37 013-5111-00 SWITCH 1
38 076-0368-14 PLUG(14P) 1
39 075-0305-01 OPT JACK 1
40 010-8028-00 COIL 1
41 076-0310-04 PLUG(4P) 1
42 313-1612-01 HEAT SINK 1
43 347-6373-00 INSULATOR 1
44 882-0002D DVD MODULE 1
25 629-0074-00 DAMPER 4
26 621-0245-03 GEAR-A 1
27 621-0246-02 GEAR-B 1
28 621-0247-01 GEAR-C 1
29 621-0248-07 RACK GEAR 1
30 621-0249-02 ROLLER GEAR 1
31 621-0258-03 LOADING ROLLER 2
32 621-0557-01 U-DISC GUIDE-F 1
33 622-1072-05 ROLLER SHAFT 1
34 622-1219-01 SHIFT ROLLER 1
35 716-1802-00 SCREW(M2X3.1) 2
36 714-2003-81 MACHINE SCREW(M2X3) 8
37 714-2603-81 MACHINE SCREW(M2.6X3) 5
38 716-1468-00 SCREW(M2×2.5) 2
39 716-1507-00 SCREW(M2×3) 2
40 716-1670-00 SCREW(M2×3) 4
41 716-1677-00 SCREW(M2×5) 1
42 716-1704-00 SCREW(M2×7) 1
43 716-1716-00 SCREW(M2×3) 2
44 716-1742-00 SCREW(M2×5) 1
45 804-4910-60 VINYL COAT WIRE(YEL) 1
46 739-2025-17 PRECISION SCREW
(M2.0×2.5) 1
47 743-1500-10 E-RING 3
48 746-0712-03 WASHER(Φ4×0.04) 1
49 746-0724-00 WASHER(Φ3×0.25) 1
DVD mchanism
1 966-0308-24 CHASSIS ASSY 1
2 966-0310-21 SHIFT-P-CH-ASSY 1
3 966-0311-22 GEAR PLATE ASSY 1
4 966-0358-21 DRIVE-L-PL-ASSY 1
5 966-0498-00 L-DISC-G-ASSY 1
6 966-0499-02 SHIFT PLATE ASSY 1
7 966-0500-01 SIDE-L-PL-ASSY 1
8 HBS-489-100 DRIVE UNIT 1
9 039-1693-00 DVD PWB 1
(WITHOUT CMPONENT)
10 001-0563-00 DIODE 3
11 013-3879-01 CHUCKING SWITCH 1
12 SMA-147-100 LOADING MOTOR ASSY 1
13 039-0586-01 CHUCKING SWTICH PWB 1
(WITHOUT COMPONENT)
14 039-0588-01 SENSOR PWB 1
(WITHOUT COMPONENT)
15 060-0252-01 PHOTO TR (PT4850F) 3
16 345-7514-00 S-PWB-SHEET 1
17 345-8318-01 CLAMPER SHEET 1
18 620-0485-20 FRONT PLATE 1
19 620-0488-20 S-L-LINK PLATE 1
20 620-0489-02 MOTOR PLATE 1
21 620-0492-20 MOTOR BRACKET 1
22 620-0832-00 LOCK PLATE 1
23 620-0833-02 MECHANISM BRACKET 1
24 621-0243-02 ROLLER SLEEVE 2
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY

- 11 - DVS9755z/
DVS970Z
50 746-0761-00 WASHER(Φ3.2×0.25) 1
51 746-0762-00 WASHER(Φ3.2×0.5) 1
52 746-0876-01 WASHER(Φ4.7×0.25) 1
53 746-0877-02 WASHER(Φ4×0.188) 2
54 750-3090-02 RO-SPRING-L 1
55 750-3091-03 RO-SPRING-R 1
56 750-3092-03 SHIFT SPRING 1
57 750-3094-00 S-ARM SPRING 1
58 750-3096-01 DR-SPRING-R 1
59 750-3098-00 L-LINK SPRING 1
60 750-3164-00 DR-SPRING-LR 1
61 750-3189-00 SIDE-L-SPRING 1
62 750-3369-00 DR-SPRING-F 2
63 750-3370-00 CENTER SPRING 1
64 800-4904-60 VINYL COAT WIRE(BLK) 1
65 800-4910-60 VINYL COAT WIRE(BLK) 1
66 801-4910-60 VINYL COAT WIRE(BRN) 1
67 802-4904-60 VINYL COAT WIRE(RED) 1
68 802-4910-60 VINYL COAT WIRE(RED) 1
69 620-0973-00 SIDE SPRING 1
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY

- 12 -
DVS9755z/
DVS970Z
■ELECTRICAL PARTS LIST
DVD Disc. unit section(B1)
C534 163-1063-30 16V10μF
C535 163-1063-30 16V10μF
C536 163-1063-30 16V10μF
C537 163-1063-30 16V10μF
C538 163-1063-30 16V10μF
C539 163-1073-31 16V100μF
C540 163-1073-31 16V100μF
C541 168-1042-78 16V 0.1μF
C542 168-1042-78 16V 0.1μF
C546 163-1063-30 16V10μF
C547 163-1063-30 16V10μF
C548 163-1063-30 16V10μF
C549 163-1063-30 16V10μF
C550 163-1063-30 16V10μF
C551 163-1063-30 16V10μF
C557 168-1042-78 16V 0.1μF
C558 168-1042-78 16V 0.1μF
C559 168-1042-78 16V 0.1μF
C560 163-1073-31 16V100μF
C561 168-1042-78 16V 0.1μF
C562 163-1073-31 16V100μF
C563 042-0619-51 6.3V56μF
C564 042-0619-51 6.3V56μF
C565 042-0619-51 6.3V56μF
C568 166-1201-00 12pF CH
C569 166-1201-00 12pF CH
C570 166-1201-00 12pF CH
C571 166-1201-00 12pF CH
C572 166-1201-00 12pF CH
C573 166-1201-00 12pF CH
C576 163-1063-30 16V10μF
C577 163-1063-30 16V10μF
C578 163-1063-30 16V10μF
C579 163-1063-30 16V10μF
C580 163-1063-30 16V10μF
C581 163-1063-30 16V10μF
C582 043-0264-06 270pF
C583 043-0264-06 270pF
C584 043-0264-06 270pF
C585 043-0264-06 270pF
C586 043-0264-06 270pF
C587 043-0264-06 270pF
C588 166-2701-00 27pF CH
C589 166-2701-00 27pF CH
C590 166-2701-00 27pF CH
C591 166-2701-00 27pF CH
C592 166-2701-00 27pF CH
C593 166-2701-00 27pF CH
C594 168-1042-78 16V 0.1μF
C595 168-1042-78 16V 0.1μF
C596 163-1063-30 16V10μF
C597 163-1063-30 16V10μF
C598 168-1042-78 16V 0.1μF
C599 168-1042-78 16V 0.1μF
C601 168-4735-06 0.047μF
C602 178-2242-78 0.22μF
C603 163-1053-60 50V1μF
C604 163-1063-30 16V10μF
C605 168-1035-06 0.01μF
C606 042-0576-00 5.5V 0.1F
C607 042-0577-00 6.3V100μF
C608 168-1035-06 0.01μF
C609 166-1021-50 1000pF CH
C610 168-1035-06 0.01μF
C611 168-1035-06 0.01μF
C612 168-1042-78 16V 0.1μF
C613 168-1042-78 16V 0.1μF
C614 168-1042-78 16V 0.1μF
C615 166-1021-50 1000pF CH
C616 166-1021-50 1000pF CH
C617 166-1021-50 1000pF CH
C440 042-0416-02 10V10μF TAN
C441 168-1042-78 16V 0.1μF
C442 042-0416-02 10V10μF TAN
C445 042-0416-02 10V10μF TAN
C446 168-1042-78 16V 0.1μF
C447 168-1042-78 16V 0.1μF
C448 042-0416-02 10V10μF TAN
C449 168-1042-78 16V 0.1μF
C450 168-1042-78 16V 0.1μF
C451 042-0416-02 10V10μF TAN
C452 168-1042-78 16V 0.1μF
C453 168-1042-78 16V 0.1μF
C454 042-0416-02 10V10μF TAN
C455 168-1042-78 16V 0.1μF
C456 042-0416-02 10V10μF TAN
C457 168-1035-06 0.01μF
C458 168-1035-06 0.01μF
C459 168-1042-78 16V 0.1μF
C460 042-0416-02 10V10μF TAN
C461 168-1042-78 16V 0.1μF
C462 168-1042-78 16V 0.1μF
C463 042-0416-02 10V10μF TAN
C464 168-1042-78 16V 0.1μF
C465 042-0416-02 10V10μF TAN
C466 166-2701-00 27pF CH
C467 166-2701-00 27pF CH
C468 166-2701-00 27pF CH
C469 168-1042-78 16V 0.1μF
C470 166-2701-00 27pF CH
C471 168-1042-78 16V 0.1μF
C472 168-1042-78 16V 0.1μF
C473 042-0416-02 10V10μF TAN
C474 042-0619-51 6.3V56μF
C475 042-0619-51 6.3V56μF
C476 166-2701-00 27pF CH
C477 166-2701-00 27pF CH
C478 166-2701-00 27pF CH
C480 168-1042-78 16V 0.1μF
C481 168-1042-78 16V 0.1μF
C482 166-2701-00 27pF CH
C483 166-2701-00 27pF CH
C484 166-1021-50 1000pF CH
C501 168-1042-78 16V 0.1μF
C502 042-0416-02 10V10μF TAN
C503 042-0416-02 10V10μF TAN
C504 042-0416-02 10V10μF TAN
C505 168-1042-78 16V 0.1μF
C506 168-1042-78 16V 0.1μF
C507 042-0416-02 10V10μF TAN
C508 042-0416-02 10V10μF TAN
C509 163-1063-30 16V10μF
C510 163-1063-30 16V10μF
C511 163-1063-30 16V10μF
C512 163-1063-30 16V10μF
C513 163-1063-30 16V10μF
C514 163-1063-30 16V10μF
C515 168-1042-78 16V 0.1μF
C516 043-0296-00 0.1μF
C521 043-0264-09 2700pF
C522 043-0264-09 2700pF
C523 043-0264-01 2200pF
C524 043-0264-01 2200pF
C525 043-0264-01 2200pF
C526 043-0264-13 0.01μF
C527 043-0264-04 100pＦ
C528 043-0264-05 220pF
C529 043-0264-07 390pF
C530 043-0264-04 100pＦ
C531 043-0264-05 220pF
C532 043-0264-05 220pF
C533 163-1063-30 16V10μF
BL901 882-0002A VDV MODUL
C201 163-1063-30 16V10μF
C202 163-2273-25 10V 220μF
C203 172-1041-11 0.1μF
C204 184-1083-32 16V1000μF
C205 163-2273-25 10V 220μF
C206 163-4763-30 16V47μF
C207 168-1042-78 16V 0.1μF
C208 163-1073-31 16V100μF
C209 168-1042-78 16V 0.1μF
C210 043-0296-00 0.1μF
C211 168-4735-06 0.047μF
C212 163-1073-31 16V100μF
C213 163-1063-30 16V10μF
C214 168-1042-78 16V 0.1μF
C215 168-1042-78 16V 0.1μF
C218 043-0296-00 0.1μF
C219 163-1073-31 16V100μF
C221 168-1042-78 16V 0.1μF
C222 168-1042-78 16V 0.1μF
C231 042-0505-01 10V22μF
C232 168-1042-78 16V 0.1μF
C233 178-2212-78 220pF
C234 163-2273-25 10V 220μF
C235 168-1042-78 16V 0.1μF
C236 163-2263-30 16V22μF
C237 163-2263-30 16V22μF
C250 043-0296-00 0.1μF
C251 043-0296-00 0.1μF
C252 042-0416-02 10V10μF TAN
C253 043-0296-00 0.1μF
C254 042-0416-02 10V10μF TAN
C401 163-1063-30 16V10μF
C402 163-1063-30 16V10μF
C403 163-1063-30 16V10μF
C404 163-1063-30 16V10μF
C405 168-1042-78 16V 0.1μF
C406 166-1201-00 12pF CH
C407 166-1201-00 12pF CH
C408 163-1063-30 16V10μF
C409 163-1063-30 16V10μF
C410 043-0264-01 2200pF
C411 168-1042-78 16V 0.1μF
C412 042-0416-02 10V10μF TAN
C413 166-1201-00 12pF CH
C414 163-1063-30 16V10μF
C415 166-1201-00 12pF CH
C416 042-0416-02 10V10μF TAN
C417 042-0416-02 10V10μF TAN
C418 166-1201-00 12pF CH
C419 163-1063-30 16V10μF
C420 166-1201-00 12pF CH
C421 163-1063-30 16V10μF
C422 163-1063-30 16V10μF
C423 168-1042-78 16V 0.1μF
C424 043-0264-01 2200pF
C425 166-2201-00 22pF CH
C426 042-0416-02 10V10μF TAN
C427 166-2201-00 22pF CH
C428 166-1201-00 12pF CH
C429 166-1201-00 12pF CH
C430 168-1042-78 16V 0.1μF
C431 168-1042-78 16V 0.1μF
C432 168-1042-78 16V 0.1μF
C433 168-1042-78 16V 0.1μF
C434 163-1063-30 16V10μF
C435 163-1063-30 16V10μF
C436 163-1063-30 16V10μF
C437 163-1063-30 16V10μF
C438 168-1042-78 16V 0.1μF
C439 178-4712-78 470pF
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
Note)Some parts depend on each model.The model name is specified in the description.

- 13 - DVS9755z/
DVS970Z
J901 074-1189-00 50P
L200 010-8028-00 520μH
L201 010-2290-00 22μH
L202 010-2200-02 270μH J
L203 010-2290-00 22μH
L204 010-2279-00 4.7μH
L402 010-2199-82 47μH J
L403 010-2285-08 BLM21A102FPB
L404 010-2285-08 BLM21A102FPB
L405 010-2285-08 BLM21A102FPB
L406 010-2285-08 BLM21A102FPB
L407 010-2285-08 BLM21A102FPB
L408 010-2285-08 BLM21A102FPB
L409 010-2285-08 BLM21A102FPB
L410 010-2285-08 BLM21A102FPB
L412 010-2285-08 BLM21A102FPB
L501 010-2285-08 BLM21A102FPB
L502 010-2285-08 BLM21A102FPB
L503 010-2285-08 BLM21A102FPB
L504 010-2285-08 BLM21A102FPB
L505 010-2285-08 BLM21A102FPB
L506 010-2285-08 BLM21A102FPB
L507 010-2285-08 BLM21A102FPB
L508 010-2285-08 BLM21A102FPB
L951 010-2285-21 BLM41A800SPB
L952 010-2279-00 4.7μH
L980 010-2279-00 4.7μH
L998 010-2285-08 BLM21A102FPB
L999 010-2285-08 BLM21A102FPB
P201 076-0310-04 4P
P202 076-0478-12 12P
P203 076-0368-14 14P
P204 076-0349-02 2P
P402 075-0305-01 OPT-DIGITAL
P501 076-0368-10 10P
P951 076-0636-90 70P
Q201 100-1162-00 2SA1162
Q202 125-2004-03 RN1403
Q203 103-1683-00 2SD1683
Q204 100-1431-00 2SA1431
Q205 191-1295-00 2SB1295
Q206 191-1295-00 2SB1295
Q207 100-1298-00 2SA1298
Q208 125-2004-03 RN1403
Q209 125-2004-03 RN1403
Q210 125-2004-03 RN1403
Q211 100-1359-00 2SA1359
Q212 100-1416-00 2SA1416
Q213 100-1162-00 2SA1162
Q214 102-2712-00 2SC2712
Q215 103-1683-00 2SD1683
Q216 100-1162-00 2SA1162
Q217 125-2004-03 RN1403
Q218 125-2004-03 RN1403
Q220 125-2004-03 RN1403
Q221 125-2004-03 RN1403
Q250 108-0302-50 2SK302Y.GR
Q251 103-2118-00 2SD2118
Q401 125-2004-02 RN1402
Q505 125-2004-06 RN1406
Q506 102-2712-00 2SC2712
Q508 125-0002-06 RN2406
Q512 103-1306-00 2SD1306
Q513 103-1306-00 2SD1306
Q514 103-1306-00 2SD1306
Q515 103-1306-00 2SD1306
Q516 103-1306-00 2SD1306
Q517 103-1306-00 2SD1306
Q518 125-2004-03 RN1403
Q519 125-2004-03 RN1403
Q601 125-2004-03 RN1403
Q980 125-2004-03 RN1403
R201 117-1031-10 1/10W 10kΩ
R202 117-1021-10 1/10W 1kΩ
D505 001-0516-00 MA111
D506 001-0516-00 MA111
D511 001-0583-21 MA8062
D601 001-0516-00 MA111
D602 001-0516-00 MA111
D603 001-0516-00 MA111
D604 001-0583-21 MA8062
D980 001-0367-00 1SS226
FIL202 060-3104-00 NFM41P11C204
FIL203 060-3104-00 NFM41P11C204
FIL402 060-3104-00 NFM41P11C204
FIL403 060-3104-00 NFM41P11C204
FIL404 060-3102-92 NFM51R00P506
FIL405 060-3102-91 NFM51R00P206
FIL406 060-3102-91 NFM51R00P206
FIL501 060-3102-91 NFM51R00P206
FIL502 060-3102-91 NFM51R00P206
FIL503 060-3102-91 NFM51R00P206
FIL504 060-3102-91 NFM51R00P206
FIL505 060-3102-91 NFM51R00P206
FIL506 060-3102-91 NFM51R00P206
FIL601 060-3113-95 NFM2012R13C102R
FIL602 060-3103-00 NFM839R02G101B1
FIL603 060-3103-00 NFM839R02G101B1
FIL604 060-3103-00 NFM839R02G101B1
FIL605 060-3103-00 NFM839R02G101B1
FIL606 060-3113-95 NFM2012R13C102R
FIL607 060-3103-00 NFM839R02G101B1
FIL608 060-3103-00 NFM839R02G101B1
FIL609 060-3103-00 NFM839R02G101B1
FIL610 060-3103-00 NFM839R02G101B1
FIL980 060-3102-91 NFM51R00P206
FIL981 060-3102-91 NFM51R00P206
IC201 051-3263-90 NJU7200U33
IC202 051-1905-03 AN77L06M
IC203 051-3605-00 NJM2360AM
IC204 051-3274-90 BA178M05F
IC205 051-3263-90 NJU7200U33
IC401 051-3015-00 NJM4580M
IC402 051-3015-00 NJM4580M
IC403 051-6364-00 YSS912C-F
IC404 051-1811-00 BA3129F
IC405 051-6362-08 CS5360-BSR
IC406 051-6361-00 LC89055W-RA8
IC407 051-7268-08 TC7SHU04F
IC408 051-9119-08 TC558128BJ-12EL
IC409 051-7268-08 TC7SHU04F
IC502 051-6363-08 PCM1600Y/2K
IC503 051-3012-00 OP275GS
IC504 051-3012-00 OP275GS
IC505 051-3012-00 OP275GS
IC506 051-5017-00 TC9482F
IC506 051-5017-00 TC9482F
IC510 051-3015-00 NJM4580M
IC511 051-3015-00 NJM4580M
IC512 051-3015-00 NJM4580M
IC513 060-6016-00 DC-CD CON
IC601 052-5042-00 M30622MCA-E53GP
(PE-2359B,PE-
2360E)
IC601 052-5042-10 M30622MCA-E66GP
(PE-2359K)
IC602 051-6600-38 CA0008AM
IC603 051-0869-55 NJM2103M
IC604 051-5407-08 S-80721AN-DJ
IC920 051-7241-08 TC74VHCT245FT
IC921 051-7507-08 SN74LV125APWR
IC922 051-7222-38 SN74AHC1G08DBVR
IC980 051-5331-90 MM1228XFBE
J501 074-0898-10 10P
J503 074-0898-14 14P
J601 074-1194-00 13P CE-NET
J602 074-1194-00 13P CE-NET
J603 074-1270-08 8P DIN
C650 163-1063-30 16V10μF
C651 042-0416-02 10V10μF TAN
C903 168-1042-78 16V 0.1μF
C918 168-2212-05 220pF
C920 168-1042-78 16V 0.1μF
C921 168-1042-78 16V 0.1μF
C931 168-2212-05 220pF
C951 168-1042-78 16V 0.1μF
C952 168-1042-78 16V 0.1μF
C953 042-0472-00 10V47μF
C954 168-1042-78 16V 0.1μF
C955 168-1042-78 16V 0.1μF
C956 042-0472-00 10V47μF
C957 168-1042-78 16V 0.1μF
C958 163-2263-10 6.3V22μF
C959 168-1042-78 16V 0.1μF
C960 163-2263-10 6.3V22μF
C980 168-1042-78 16V 0.1μF
C981 163-1053-60 50V1μF
C982 163-1053-60 50V1μF
C983 168-1042-78 16V 0.1μF
C984 042-0472-00 10V47μF
C986 168-1042-78 16V 0.1μF
C987 168-1035-06 0.01μF
C989 184-1083-32 16V1000μF
CCT401 050-0122-03 1/16W1kΩ×4 J
CCT402 050-0122-03 1/16W1kΩ×4 J
CCT403 050-0122-03 1/16W1kΩ×4 J
CCT404 050-0122-65 1/16W270Ω×4 J
CCT405 050-0122-63 1/16W150Ω×4 J
CCT406 050-0122-63 1/16W150Ω×4 J
CCT407 050-0122-63 1/16W150Ω×4 J
CCT408 050-0122-63 1/16W150Ω×4 J
CCT409 050-0122-63 1/16W150Ω×4 J
CCT410 050-0122-63 1/16W150Ω×4 J
CCT411 050-0122-63 1/16W150Ω×4 J
CCT412 050-0122-63 1/16W150Ω×4 J
CCT414 050-0122-65 1/16W270Ω×4 J
CCT415 050-0122-03 1/16W1kΩ×4 J
CCT416 050-0122-03 1/16W1kΩ×4 J
CCT501 050-0122-03 1/16W1kΩ×4 J
CCT502 050-0122-03 1/16W1kΩ×4 J
CCT909 050-0122-00 1/16W10kΩ×4 J
CCT910 050-0122-00 1/16W10kΩ×4 J
CCT920 050-0122-00 1/16W10kΩ×4 J
CCT951 050-0122-00 1/16W10kΩ×4 J
CCT952 050-0122-00 1/16W10kΩ×4 J
CCT953 050-0122-00 1/16W10kΩ×4 J
CCT954 050-0122-00 1/16W10kΩ×4 J
CCT956 050-0122-62 1/16W22Ω×4 J
CCT957 050-0122-62 1/16W22Ω×4 J
CCT958 050-0122-62 1/16W22Ω×4 J
CCT959 050-0122-07 1/16W100Ω×4 J
CCT960 050-0122-62 1/16W22Ω×4 J
CCT961 050-0122-62 1/16W22Ω×4 J
CCT962 050-0122-62 1/16W22Ω×4 J
D201 001-0334-00 DSA17B
D202 001-0627-00 U1BC44
D203 001-0516-00 MA111
D204 001-0627-00 U1BC44
D205 001-0627-00 U1BC44
D206 001-0516-00 MA111
D207 001-0528-50 MA8100-M
D208 001-0503-46 HZS9B2L
D209 001-2606-90 M1FS4
D210 001-0627-00 U1BC44
D252 001-0595-24 MA5180
D403 001-0516-00 MA111
D404 001-0516-00 MA111
D407 001-0528-44 MA8082-M
D501 001-0516-00 MA111
D502 001-0516-00 MA111
D503 001-0528-44 MA8082-M
D504 001-0516-00 MA111
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION

- 14 -
DVS9755z/
DVS970Z
R450 119-8211-10 1/16W 820Ω
R451 119-5121-15 1/16W 5.1kΩ
R452 119-4701-10 1/16W 47Ω
R453 119-7501-15 1/16W 75Ω
R454 119-1511-10 1/16W 150Ω
R459 119-8211-10 1/16W 820Ω
R466 119-1041-10 1/16W 100kΩ
R467 119-1041-10 1/16W 100kΩ
R487 119-1031-10 1/16W 10kΩ
R493 119-4731-10 1/16W 47kΩ
R494 119-1021-10 1/16W 1kΩ
R501 119-1031-10 1/16W 10kΩ
R509 119-8221-10 1/16W 8.2kΩ
R511 032-0104-69 1/4W 1.5kΩ
R515 119-1021-10 1/16W 1kΩ
R516 119-2231-10 1/16W 22kΩ
R526 119-1031-10 1/16W 10kΩ
R527 119-1031-10 1/16W 10kΩ
R528 119-1031-10 1/16W 10kΩ
R529 119-1031-10 1/16W 10kΩ
R530 119-1031-10 1/16W 10kΩ
R531 119-1031-10 1/16W 10kΩ
R532 119-1521-10 1/16W 1.5kΩ
R533 119-1521-10 1/16W 1.5kΩ
R534 119-2721-10 1/16W 2.7kΩ
R535 119-2721-10 1/16W 2.7kΩ
R536 119-2721-10 1/16W 2.7kΩ
R537 119-1821-10 1/16W 1.8kΩ
R538 119-5131-15 1/16W 51kΩ
R539 119-5131-15 1/16W 51kΩ
R540 119-2031-10 1/16W 20kΩ
R541 119-2031-10 1/16W 20kΩ
R542 119-2031-10 1/16W 20kΩ
R543 119-6231-10 1/16W 62kΩ
R544 119-1041-10 1/16W 100kΩ
R545 119-1041-10 1/16W 100kΩ
R546 119-1041-10 1/16W 100kΩ
R547 119-1041-10 1/16W 100kΩ
R548 119-1041-10 1/16W 100kΩ
R549 119-1041-10 1/16W 100kΩ
R550 119-1041-10 1/16W 100kΩ
R551 119-1041-10 1/16W 100kΩ
R552 119-1041-10 1/16W 100kΩ
R553 119-1041-10 1/16W 100kΩ
R554 119-1041-10 1/16W 100kΩ
R555 119-1041-10 1/16W 100kΩ
R556 119-1041-10 1/16W 100kΩ
R557 119-1041-10 1/16W 100kΩ
R558 119-1041-10 1/16W 100kΩ
R559 119-1041-10 1/16W 100kΩ
R560 119-1041-10 1/16W 100kΩ
R561 119-1041-10 1/16W 100kΩ
R562 119-2041-15 1/16W 200kΩ
R563 119-2041-15 1/16W 200kΩ
R564 119-2041-15 1/16W 200kΩ
R567 119-2041-15 1/16W 200kΩ
R568 119-2041-15 1/16W 200kΩ
R569 119-2041-15 1/16W 200kΩ
R570 119-1021-10 1/16W 1kΩ
R571 119-1021-10 1/16W 1kΩ
R572 119-1021-10 1/16W 1kΩ
R573 119-3311-10 1/16W 330Ω
R574 119-3311-10 1/16W 330Ω
R575 119-3311-10 1/16W 330Ω
R576 119-3311-10 1/16W 330Ω
R577 119-3311-10 1/16W 330Ω
R578 119-3311-10 1/16W 330Ω
R579 119-2231-10 1/16W 22kΩ
R580 119-2231-10 1/16W 22kΩ
R581 119-2231-10 1/16W 22kΩ
R582 119-2231-10 1/16W 22kΩ
R583 119-2231-10 1/16W 22kΩ
R584 119-2231-10 1/16W 22kΩ
R585 032-0104-69 1/4W 1.5kΩ
R203 032-0104-60 1/4W 220Ω
R208 117-1221-10 1/10W 1.2kΩ
R209 119-1031-10 1/16W 10kΩ
R210 119-1031-10 1/16W 10kΩ
R211 119-1031-10 1/16W 10kΩ
R212 117-1021-10 1/10W 1kΩ
R213 032-0104-67 1/4W 1.2kΩ
R214 119-4731-10 1/16W 47kΩ
R215 117-6811-10 1/10W 680Ω
R216 032-0104-63 1/4W 1.5Ω
R217 032-0104-63 1/4W 1.5Ω
R218 119-2201-10 1/16W 22Ω
R219 119-1031-10 1/16W 10kΩ
R220 032-0104-63 1/4W 1.5Ω
R221 032-0104-63 1/4W 1.5Ω
R222 119-1031-10 1/16W 10kΩ
R223 119-3321-10 1/16W 3.3kΩ
R224 032-0104-69 1/4W 1.5kΩ
R225 032-0104-67 1/4W 1.2kΩ
R226 119-3321-10 1/16W 3.3kΩ
R227 119-2231-10 1/16W 22kΩ
R228 032-0104-60 1/4W 220Ω
R229 119-1031-10 1/16W 10kΩ
R230 117-3321-10 1/10W 3.3kΩ
R231 119-2291-15 1/16W2.2Ω
R232 119-2291-15 1/16W2.2Ω
R233 119-1531-10 1/16W 15kΩ
R234 119-2721-10 1/16W 2.7kΩ
R235 119-1031-10 1/16W 10kΩ
R240 032-0104-63 1/4W 1.5Ω
R250 117-1011-10 1/10W 100Ω
R252 032-0104-72 1/4W 33Ω
R253 032-0104-67 1/4W 1.2kΩ
R298 119-0000-00 1/16W 0ΩJW
R299 119-0000-00 1/16W 0ΩJW
R401 119-1051-10 1/16W 1MΩ
R403 119-3311-10 1/16W 330Ω
R404 119-4731-10 1/16W 47kΩ
R405 119-4731-10 1/16W 47kΩ
R406 119-3311-10 1/16W 330Ω
R409 119-3631-10 1/16W 36kΩ
R410 119-3631-10 1/16W 36kΩ
R411 119-1021-10 1/16W 1kΩ
R412 119-1831-10 1/16W 18kΩ
R413 119-1831-10 1/16W 18kΩ
R414 119-1511-10 1/16W 150Ω
R415 032-0140-89 1/4W 47kΩF
R416 032-0140-51 1/16W 15kΩ±1%
R417 119-1031-10 1/16W 10kΩ
R418 119-1031-10 1/16W 10kΩ
R419 032-0140-89 1/4W 47kΩF
R420 119-2711-10 1/16W 270Ω
R421 119-1511-10 1/16W 150Ω
R422 032-0140-51 1/16W 15kΩ±1%
R424 032-0140-51 1/16W 15kΩ±1%
R425 032-0140-89 1/4W 47kΩF
R426 119-1511-10 1/16W 150Ω
R427 032-0140-89 1/4W 47kΩF
R428 032-0140-51 1/16W 15kΩ±1%
R429 119-1031-10 1/16W 10kΩ
R430 119-1031-10 1/16W 10kΩ
R431 119-4731-10 1/16W 47kΩ
R432 119-1051-10 1/16W 1MΩ
R433 119-1511-10 1/16W 150Ω
R434 119-1831-10 1/16W 18kΩ
R435 119-1831-10 1/16W 18kΩ
R436 119-4731-10 1/16W 47kΩ
R437 119-3631-10 1/16W 36kΩ
R438 119-3631-10 1/16W 36kΩ
R440 119-1031-10 1/16W 10kΩ
R441 119-3301-10 1/16W 33Ω
R442 119-4711-10 1/16W 470Ω
R448 119-8221-10 1/16W 8.2kΩ
R449 119-5121-15 1/16W 5.1kΩ
R586 032-0104-69 1/4W 1.5kΩ
R587 119-2221-10 1/16W 2.2kΩ
R589 119-1021-10 1/16W 1kΩ
R601 119-1831-10 1/16W 18kΩ
R602 119-9121-15 1/16W 9.1kΩ
R603 119-3921-10 1/16W 3.9kΩ
R604 117-1141-15 1/10W 110kΩ
R605 119-1831-10 1/16W 18kΩ
R606 119-4721-10 1/16W 4.7kΩ
R607 119-4731-10 1/16W 47kΩ
R608 119-1541-10 1/16W 150kΩ
R609 119-1031-10 1/16W 10kΩ
R610 119-5621-10 1/16W 5.6kΩ
R611 119-1011-10 1/16W 100Ω
R612 119-1011-10 1/16W 100Ω
R613 119-3321-10 1/16W 3.3kΩ
R616 119-2231-10 1/16W 22kΩ
R649 119-5611-10 1/16W 560Ω
R651 119-1031-10 1/16W 10kΩ
(2359K-A,2360E)
R652 119-1031-10 1/16W 10kΩ
(2359B/K-A)
R653 119-1031-10 1/16W 10kΩ
(2359B/K-B,2360E)
R654 119-1031-10 1/16W 10kΩ(2359K-
A/K-B,2360E)
R656 119-4731-10 1/16W 47kΩ
R657 119-1031-10 1/16W 10kΩ
(2359B/K-B)
R658 119-1031-10 1/16W 10kΩ
(2359K-B,2360E)
R659 119-1031-10 1/16W10kΩ(2359K-A)
R660 119-1031-10 1/16W 10kΩ
R661 119-1031-10 1/16W 10kΩ(2359B)
R662 119-1031-10 1/16W 10kΩ
R664 119-1031-10 1/16W 10kΩ(2359K-
A/K-B,2360E)
R665 119-1031-10 1/16W 10kΩ(2359B)
R666 119-1031-10 1/16W 10kΩ
(2359B/K-A/K-B)
R667 119-1031-10 1/16W 10kΩ(2360E)
R669 119-1031-10 1/16W 10kΩ
R901 119-4731-10 1/16W 47kΩ
R902 119-5621-10 1/16W 5.6kΩ
R903 119-4731-10 1/16W 47kΩ
R904 119-1021-10 1/16W 1kΩ
R905 119-3301-10 1/16W 33Ω
R913 119-6801-10 1/16W 68Ω
R920 119-1011-10 1/16W 100Ω
R921 119-1011-10 1/16W 100Ω
R922 119-6801-10 1/16W 68Ω
R923 119-1011-10 1/16W 100Ω
R927 119-4721-10 1/16W 4.7kΩ
R950 119-2201-10 1/16W 22Ω
R951 119-2201-10 1/16W 22Ω
R952 119-2201-10 1/16W 22Ω
R954 119-1011-10 1/16W 100Ω
R960 119-1011-10 1/16W 100Ω
R961 119-1011-10 1/16W 100Ω
R962 119-0000-00 1/16W 0ΩJW
R963 119-2201-10 1/16W 22Ω
R964 119-1031-10 1/16W 10kΩ
R965 119-2201-10 1/16W 22Ω
R980 032-0140-72 1/4W 470ΩF
R981 032-0140-72 1/4W 470ΩF
R982 119-4721-10 1/16W 4.7kΩ
R985 032-0106-79 1/10W 78Ω±0.5%
R986 119-4731-10 1/16W 47kΩ
R987 032-0106-79 1/10W 78Ω±0.5%
S601 013-5111-00 00221339TKR
S606 013-6100-00 SKHLLB
S607 013-3945-00 SPVC1
X401 061-3519-90 12.288MHz
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION

- 15 - DVS9755z/
DVS970Z
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
R709 119-4701-10 1/16W 47Ω
R710 119-4701-10 1/16W 47Ω
R711 032-0104-68 1/4W 22Ω
R712 119-1241-10 1/16W 120kΩ
R714 119-2241-10 1/16W 220kΩ
S701 013-6507-50 LS8J2M-T
S702 013-6507-50 LS8J2M-T
S703 013-6507-50 LS8J2M-T
S704 013-6507-50 LS8J2M-T
S705 013-6507-50 LS8J2M-T
S706 013-6507-50 LS8J2M-T
S707 013-6507-50 LS8J2M-T
S708 013-6507-50 LS8J2M-T
S709 013-6507-50 LS8J2M-T
S710 013-6507-50 LS8J2M-T
S711 013-6507-50 LS8J2M-T
D714 001-0583-21 MA8062
D715 001-0583-21 MA8062
D716 001-0583-21 MA8062
D717 001-0516-00 MA111
IC701 051-6047-00 LC75804W
IC702 051-1287-00 NJM78L05UA
IR701 060-4005-02 GP1U27X
LCD701 379-1191-41 LCD
R701 119-2221-10 1/16W 2.2kΩ
R702 119-2221-10 1/16W 2.2kΩ
R703 119-2221-10 1/16W 2.2kΩ
R704 119-3931-10 1/16W 39kΩ
R705 119-8201-10 1/16W 82Ω
R706 119-2231-10 1/16W 22kΩ
R707 119-1501-15 1/16W 15Ω
R708 119-4701-10 1/16W 47Ω
C701 168-4735-06 0.047μF
C702 168-4735-06 0.047μF
C703 168-4735-06 0.047μF
C704 168-1022-05 1000pF
C705 042-0416-02 10V10μF TAN
C706 168-1042-78 16V 0.1μF
C707 042-0416-02 10V10μF TAN
C708 178-2242-78 0.22μF
C709 042-0397-00 16V1μF TAN
D701 001-7046-00 NSPW310BS
D702 001-7040-01 NSCW100
D703 001-7040-01 NSCW100
D704 001-7040-01 NSCW100
D711 001-0516-00 MA111
D712 001-0516-00 MA111
D713 001-0583-21 MA8062
Control unit SW PWB section(B2)
C513 163-1073-10 6.3V 100μF
C515 163-1073-10 6.3V 100μF
C516 163-1073-10 6.3V 100μF
C517 178-1032-78 0.01μF
C518 178-2722-78 2700pF
CCT501 050-0140-59 33Ω×4
CCT502 050-0140-59 33Ω×4
CCT503 050-0140-59 33Ω×4
CCT504 050-0140-59 33Ω×4
CCT505 050-0140-52 100Ω×4
D101 001-0367-00 1SS226
D102 001-0367-00 1SS226
D201 001-0563-00 GL380
D202 001-0563-00 GL380
D203 001-0563-00 GL380
D301 001-0356-05 1SS181
IC101 051-5705-00 TA1254F
IC102 051-3014-00 NJM2115M
IC201 051-6040-08 BA6849FP
IC202 051-6041-08 BA5937AFP
IC301 051-6351-00 TC9453F
IC302 051-9315-00 MSM514265C-50TS
IC401 051-9315-00 MSM514265C-50TS
IC402 051-6352-00 TC9469AF
IC501 052-5041-02 TMP95CW64F-3A88
IC503 051-1738-05 TC7S08F
IC504 051-5419-08 MN1382L
J101 074-1201-16 16P
J102 074-1201-14 14P
J201 074-1138-11 11P
J502 076-0478-62 12P
J504 074-1189-00 50P
L101 010-2155-93 10μH
L102 010-2155-93 10μH
L501 010-2275-52 3.3μH
L502 010-2275-52 3.3μH
Q101 101-1188-50 2SB1188Q,R
Q102 101-1188-50 2SB1188Q,R
R101 117-1001-10 1/10W 10Ω
R102 117-1001-10 1/10W 10Ω
R103 117-1021-10 1/10W 1kΩ
R104 117-1021-10 1/10W 1kΩ
R105 117-5601-10 1/10W 56Ω
R106 117-5601-10 1/10W 56Ω
R107 117-3331-10 1/10W 33kΩ
R108 117-3331-10 1/10W 33kΩ
R109 117-2731-10 1/10W 27kΩ
R110 117-1041-10 1/10W 100kΩ
R112 117-1041-10 1/10W 100kΩ
R113 117-1031-10 1/10W 10kΩ
R201 117-1021-10 1/10W 1kΩ
R202 117-1021-10 1/10W 1kΩ
C309 178-1042-78 0.1μF
C310 178-1042-78 0.1μF
C311 178-6822-78 6800pF
C312 042-0416-02 10V 10μF TAN
C313 178-3312-78 330pF
C314 178-3312-78 330pF
C315 176-1011-00 100pF
C316 178-1042-78 0.1μF
C317 178-4712-78 470pF
C318 178-4722-78 4700pF
C319 178-1222-78 1200pF
C320 178-1042-78 0.1μF
C321 178-1042-78 0.1μF
C322 178-3322-78 3300pF
C327 178-1042-78 0.1μF
C329 042-0416-02 10V 10μF TAN
C332 178-1042-78 0.1μF
C333 178-1042-78 0.1μF
C334 178-1042-78 0.1μF
C335 178-1042-78 0.1μF
C336 178-1022-78 1000pF
C337 178-1532-78 0.015μF
C338 178-1042-78 0.1μF
C339 178-1042-78 0.1μF
C340 178-1042-78 0.1μF
C341 178-1042-78 0.1μF
C342 178-1042-78 0.1μF
C343 178-2222-78 2200pF
C344 178-1042-78 0.1μF
C345 178-1042-78 0.1μF
C346 178-1042-78 0.1μF
C401 178-1042-78 0.1μF
C402 178-1042-78 0.1μF
C403 178-1042-78 0.1μF
C404 178-1042-78 0.1μF
C405 178-1042-78 0.1μF
C406 178-1042-78 0.1μF
C407 178-1042-78 0.1μF
C408 178-1042-78 0.1μF
C409 178-1042-78 0.1μF
C410 178-1042-78 0.1μF
C411 178-1042-78 0.1μF
C412 178-1042-78 0.1μF
C414 176-1007-00 10pF
C502 178-1042-78 0.1μF
C503 178-1042-78 0.1μF
C504 178-1042-78 0.1μF
C506 178-1042-78 0.1μF
C509 178-1042-78 0.1μF
C510 163-1073-10 6.3V 100μF
C511 163-1073-31 16V 100μF
C512 163-1073-10 6.3V 100μF
C101 178-1042-78 0.1μF
C102 178-1042-78 0.1μF
C103 163-1073-10 6.3V 100μF
C104 163-1073-10 6.3V 100μF
C105 042-0397-04 10V 2.2μF TAN
C106 178-1042-78 0.1μF
C107 178-1032-78 0.01μF
C108 178-1032-78 0.01μF
C109 042-0416-02 10V 10μF TAN
C110 042-0397-00 16V 1μF TAN
C111 178-1042-78 0.1μF
C112 178-1042-78 0.1μF
C113 178-1022-78 1000pF
C114 178-1042-78 0.1μF
C115 178-1022-78 1000pF
C116 178-1022-78 1000pF
C117 178-1042-78 0.1μF
C118 042-0416-02 10V 10μF TAN
C119 178-1032-78 0.01μF
C120 178-1032-78 0.01μF
C121 176-1007-00 10pF
C122 178-1032-78 0.01μF
C123 178-4722-78 4700pF
C124 178-4722-78 4700pF
C125 178-1042-78 0.1μF
C126 178-1042-78 0.1μF
C127 042-0416-02 10V 10μF TAN
C128 178-1042-78 0.1μF
C129 178-1042-78 0.1μF
C130 178-4732-78 0.047μF
C131 176-1007-00 10pF
C132 042-0416-02 10V 10μF TAN
C133 178-1042-78 0.1μF
C134 178-3312-78 330pF
C202 178-1042-78 0.1μF
C203 178-1042-78 0.1μF
C204 178-1042-78 0.1μF
C206 178-1042-78 0.1μF
C207 178-1042-78 0.1μF
C208 178-1042-78 0.1μF
C209 178-1042-78 0.1μF
C210 178-1042-78 0.1μF
C211 178-1042-78 0.1μF
C212 178-1042-78 0.1μF
C301 178-3312-78 330pF
C302 178-3312-78 330pF
C303 178-1542-78 0.15μF
C304 178-1042-78 0.1μF
C305 178-1042-78 0.1μF
C306 178-1042-78 0.1μF
C307 178-1042-78 0.1μF
C308 178-1042-78 0.1μF
DVD Mecha PWB部(B3)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION

- 16 -
DVS9755z/
DVS970Z
R505 117-4731-10 1/10W 47kΩ
R506 117-4731-10 1/10W 47kΩ
R507 117-1041-10 1/10W 100kΩ
R508 117-1041-10 1/10W 100kΩ
R509 117-1041-10 1/10W 100kΩ
R512 117-4721-10 1/10W 4.7kΩ
R513 117-4721-10 1/10W 4.7kΩ
R514 117-4731-10 1/10W 47kΩ
R515 117-1041-10 1/10W 100kΩ
R516 117-1031-10 1/10W 10kΩ
R517 117-1031-10 1/10W 10kΩ
R518 117-1031-10 1/10W 10kΩ
R519 117-1031-10 1/10W 10kΩ
R520 117-1031-10 1/10W 10kΩ
R521 117-1031-10 1/10W 10kΩ
R538 117-2201-10 1/10W 22Ω
R539 117-8201-10 1/10W 82Ω
R540 117-8201-10 1/10W 82Ω
R541 117-8201-10 1/10W 82Ω
R542 117-2201-10 1/10W 22Ω
R543 117-8201-10 1/10W 82Ω
R548 117-1041-10 1/10W 100kΩ
R549 117-1021-10 1/10W 1kΩ
R550 117-1041-10 1/10W 100kΩ
X301 060-1516-90 22.58MHz
X401 060-1517-90 50.0MHz
X501 060-1515-90 25.0MHz
R324 117-1021-10 1/10W 1kΩ
R325 117-5631-10 1/10W 56kΩ
R326 117-1021-10 1/10W 1kΩ
R327 117-2731-10 1/10W 27kΩ
R328 117-1021-10 1/10W 1kΩ
R329 117-2211-10 1/10W 220Ω
R331 117-2211-10 1/10W 220Ω
R332 117-1541-10 1/10W 150kΩ
R333 117-1541-10 1/10W 150kΩ
R335 117-1031-10 1/10W 10kΩ
R336 117-1031-10 1/10W 10kΩ
R337 117-1051-10 1/10W 1MΩ
R338 117-1521-10 1/10W 1.5kΩ
R339 117-1031-10 1/10W 10kΩ
R340 117-1031-10 1/10W 10kΩ
R341 117-4741-10 1/10W 470kΩ
R342 117-4721-10 1/10W 4.7kΩ
R343 117-1031-10 1/10W 10kΩ
R344 117-5631-10 1/10W 56kΩ
R345 117-1531-10 1/10W 15kΩ
R346 117-4731-10 1/10W 47kΩ
R347 117-3321-10 1/10W 3.3kΩ
R401 117-1051-10 1/10W 1MΩ
R402 117-1521-10 1/10W 1.5kΩ
R403 117-1031-10 1/10W 10kΩ
R404 117-4731-10 1/10W 47kΩ
R405 117-0000-00 1/10W 0Ω
R501 117-1051-10 1/10W 1MΩ
R504 117-1041-10 1/10W 100kΩ
R203 117-1011-10 1/10W 100Ω
R204 117-1011-10 1/10W 100Ω
R205 117-1031-10 1/10W 10kΩ
R206 117-1031-10 1/10W 10kΩ
R207 117-1031-10 1/10W 10kΩ
R208 032-0104-70 1/4W 1Ω
R209 032-0104-70 1/4W 1Ω
R210 117-2221-10 1/10W 2.2kΩ
R211 117-3321-10 1/10W 3.3kΩ
R303 117-4731-10 1/10W 47kΩ
R304 117-1031-10 1/10W 10kΩ
R305 117-1031-10 1/10W 10kΩ
R307 117-4721-10 1/10W 4.7kΩ
R308 117-1031-10 1/10W 10kΩ
R309 117-4731-10 1/10W 47kΩ
R310 117-1521-10 1/10W 1.5kΩ
R311 117-1031-10 1/10W 10kΩ
R312 117-1031-10 1/10W 10kΩ
R313 117-1031-10 1/10W 10kΩ
R314 117-1031-10 1/10W 10kΩ
R315 117-1031-10 1/10W 10kΩ
R316 117-1031-10 1/10W 10kΩ
R317 117-1041-10 1/10W 100kΩ
R318 117-2211-10 1/10W 220Ω
R319 117-5621-10 1/10W 5.6kΩ
R320 117-0000-00 1/10W 0Ω
R321 117-5631-10 1/10W 56kΩ
R322 117-1021-10 1/10W 1kΩ
R323 117-2731-10 1/10W 27kΩ
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
Sensor PWB section(B4)
Q1 060-0252-01 PT4850F Q2 060-0252-01 PT4850F Q3 060-0252-01 PT4850F
Chucking switch PWB section(B5)
S2 013-3879-01 SWITCH M3 SMA-147-100 MOTOR
Sled motor PWB section(B6)
S1 013-3879-01 SWITCH M2 SMA-146-100 MOTOR
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION

DVD Disc. unit Section 2/5 (B1)

DVD Disc. unit Section 4/5 (B1)
