Clarion VRX815 User manual

VRX815
VRX815P
- 1 -
Published by Service Dept.
Printed in Japan
Clarion Co., Ltd.
5-35-2, Hakusan, Bunkyouku, Tokyo, 112-8608 Japan
Service Dept.- 50 kamitoda,Toda-shi,Saitama,335-8511 Japan Tel: [phone] FAX:[phone]
298-5950-00 Nov.2001 P
Service Manual
Model
N
V
D
D
I
L
R
AM/FM CD Player/CD Changer
Controller with 7" LC Display
(QC-6800B)
Model
(QC-6800K)
■SPECIFICATIONS
FM tuner section
Frequency range: 87.9MHz to 107.9MHz(VRX815)
87.50MHz to 108.0MHz(VRX815P)
Usable sensitivity: 11dBf
50dB quieting sensitivity: 17dBf
Alternate channel selectivity: 70dB
Stereo separation: 35dB(1kHz)
Frequency response: 30Hz to 15kHz(±3dB)
AM tuner section
Frequency range: 530kHz to 1710kHz(VRX815)
531kHz to 1629kHz(VRX815P)
Usable sensitivity: 25μV
CD player section
System: Compact disc digital audio system
Frequency response: 17Hz to 20kHz(±1dB)
Signal to noise ratio: 98dB(1kHz)IHF-A
Dynamic range: 95dB(1kHz)
Distortion: 0.02％
Audio amplifier section
Rated power output: 17W×4(20Hz to 20kHz,1%,4Ω)
Maximum power output:
180W(45W×4 JEITA)
Speaker impedance: 4Ω(4 to 8Ω)
Input section
Video input: 1.0±0.2Vp-p
(input impedance 75Ω)
Audio input: 130±60mVrms(input impedance
10kΩor greater)
Video output section
Video output: 1.0±0.2Vp-p(output impedance 75
Ω)
LCD monitor section
Screen size: 7-inch wide type
(152mm Width×85mm Height)
Display method: Transmission type TN Liquid
Crystal Display
Drive method: TFT(thin-film transistor) active
matrix driving
Pixels: 336,960(1440×234)
General
Power source voltage: 14.4V DC
(10.8 to 15.6V allowable)
Ground: Negative
Current consumption: 4.0A(1W)
Auto antenna rated current:
500mA less
Dimensions(mm): Main unit
178(W)×50(H)×165(D)
Tuner amp unit
178(W)×37.5(H)×209.5(D)
Remote control unit
44(W)×110(H)×27(D)
Weight: Main unit 2.0kg
Tuner amp unit 1.1kg
Remote control unit 30g
(including battery)
■NOTES
※Use a CeNET extension cable that is less than 20m in
length.(including the Y-adapter CCA-519)
※We cannot supply PWB with component parts in prin-
ciple. When a circuit on PWB has failure , please repair
it by component parts base. Parts which are not men-
tioned in service manual are not supplied.
※Some CDs recorded in CD-R mode may not be usable.
※Even when recorded in CD-RW mode, some CDs not
be usable.
※CD-ROM discs cannot be played in the CD changer.
※This unit can display title data for CD-text CDs and user
titles input with this unit.
※This slide mechanism is used the special adjustment jig
for repair.
※Specifications and design are subject to change without
notice for further improvement.

VRX815
VRX815P - 2 -
■To engineers in charge of repair or
inspection of our products.
Before repair or inspection, make sure to follow
the instructions so that customers and Engineers
in charge of repair or inspection can avoid suf-
fering any risk or injury.
1. Use specified parts.
The system uses parts with special safety features against
fire and voltage. Use only parts with equivalent charac-
teristics when replacing them.
The use of unspecified parts shall be regarded as re-
modeling for which we shall not be liable. The onus of
product liability (PL) shall not be our responsibility in cases
where an accident or failure is as a result of unspecified
parts being used.
2. Place the parts and wiring back in their original positions
after replacement or re-wiring.
For proper circuit construction, use of insulation tubes,
bonding, gaps to PWB, etc, is involved. The wiring con-
nection and routing to the PWB are specially planned
using clamps to keep away from heated and high voltage
parts. Ensure that they are placed back in their original
positions after repair or inspection.
If extended damage is caused due to negligence during
repair, the legal responsibility shall be with the repairing
company.
3. Check for safety after repair.
Check that the screws, parts and wires are put back se-
curely in their original position after repair. Ensure for
safety reasons there is no possibility of secondary
ploblems around the repaired spots.
If extended damage is caused due to negligence of re-
pair, the legal responsibility shall be with the repairing
company.
4. Caution in removal and making wiring connection to the
parts for the automobile.
Disconnect the battery terminal after turning the ignition
key off. If wrong wiring connections are made with the
battery connected, a short circuit and/or fire may occur.
If extensive damage is caused due to negligence of re-
pair, the legal responsibility shall be with the repairing
company.
5. Cautions regarding chips.
Do not reuse removed chips even when no abnormality
is observed in their appearance. Always replace them
with new ones. (The chip parts include resistors, capaci-
tors, diodes, transistors, etc). The negative pole of tanta-
lum capacitors is highly susceptible to heat, so use spe-
cial care when replacing them and check the operation
afterwards.
6. Cautions in handling flexible PWB
Before working with a soldering iron, make sure that the
iron tip temperature is around 270℃. Take care not to
apply the iron tip repeatedly(more than three times)to the
same patterns. Also take care not to apply the tip with
force.
7. Turn the unit OFF during disassembly and parts replace-
ment. Recheck all work before you apply power to the
unit.
8. Cautions in checking that the optical pickup lights up.
The laser is focused on the disc reflection surface through
the lens of the optical pickup. When checking that the
laser optical diode lights up, keep your eyes more than
30cms away from the lens. Prolonged viewing of the la-
ser within 30cms may damage your eyesight.
9. Cautions in handling the optical pickup
The laser diode of the optical pickup can be damaged by
electrostatic charge caused by your clothes and body.
Make sure to avoid electrostatic charges on your clothes
or body, or discharge static electricity before handling the
optical pickup.
9-1. Laser diode
The laser diode terminals are shorted for transpor-
tation in order to prevent electrostatic damage.
After replacement, open the shorted circuit. When
removing the pickup from the mechanism, short
the terminals by soldering them to prevent this
damage.
■COMPONENTS
QC-6800B-B/QC-6800K-A
Main unit −−−−− 1
Remote control unit RCB-155-601 1
Battery(SUM-3) −−−−− 2
Universal mounting bracket 300-9677-00 1
DCP case 335-6707-00 1
Antenna jumper 093-1465-00 1
Power supply lead 854-6388-50 1
Extension lead(13P to 13P) 855-3426-00 1
Outer escutcheon 940-7715-04 1
Parts bag −−−−−
Electro tap 060-0018-00 1
Machine screw(M4×3) 714-4003-87 4
Machine screw(M5×8) 714-5008-41 4
Sems hex. bolt(M5×8) 716-0496-01 5
Parts bag −−−−−
Hook plate 331-0488-20 2
Cord clamp 335-0833-07 1
Spacer 345-3653-20 1
Screw 716-0726-01 1
Parts bag −−−−−
Mounting bracket 300-7362-20 2
Canoe clip 335-2515-00 4
Machine screw(M4×8) 714-4008-81 4
Parts bag(Use only VRX815) −−−−−
DCP lock spacer 335-6747-00 1
■CAUTIONS
Use of controls,adjustment or performance of procedures
other than those specified herein,may result in hazardous
radiation exposure.
The COMPACT DISC player and MINI DISC player should
not be adjusted or repaired by anyone except properly quali-
fied service personnel.

VRX815
VRX815P
- 3 -
9-2. Actuator
The actuator has a powerful magnetic circuit. If a
magnetic material is put close to it. Its characteris-
tics will change. Ensure that no foreign substances
enter through the ventilation slots in the cover.
9-3. Cleaning the lens
Dust on the optical lens affects performance. To
clean the lens, apply a small amount of isopropyl
alcohol to lens paper and wipe the lens gently.
■SYSTEM CHECK
※The confirmation of connected equipment must be per-
formed for this unit only when the wiring connection is
complete and power is turned on to the unit first.When
the power is supplied,"SYSTEM" and "PUSH PWR" ap-
pear alternately in the display.Press the FUNC button,the
system check starts inside the unit.When "COMPLETE"
appears,press once again the FUNC button.
■ERROR DISPLAYS
If an error occurs,one of the following displays is displayed.Take the measures described below to eliminate the problem.
CD
CD
changer
MD
changer
Error display
ERROR 2
ERROR 3
ERROR 6
ERROR 2
ERROR 3
ERROR 6
ERROR H
EEROR 2
ERROR 3
ERROR 6
Cause
A CD is caught inside the CD deck and is not ejected.
A CD cannot be played due to scratches,etc.
A CD is loaded upside-down inside the CD deck and
does not play.
A CD inside the CD changer is not loaded.
A CD inside the CD changer cannot be played due to
scratches,etc.
A CD inside the CD changer cannot be played because
it is loaded upside-down.
Displayed when the temperature in the MD changer is
too high and playback has been stopped automatically.
An MD inside the MD changer is not loaded.
An MD inside the MD changer cannot be played due to
scratches,etc.
An MD inside the MD changer cannot be played because
it is loaded upside-down.
Displayed when a non-recorded MD is loaded in the MD
changer.
Measure
This is a failure of CD deck's mechanism.
Replace with a non-scratched,non-warped disc.
Eject the disc then reload it properly.
This is a failure of CD changer's mechanism.
Replace with a non-scratched,non-warped disc.
Eject the disc then reload it properly.
Lower the surrounding temperature and wait for
a while to cool off MD changer.
This is a failure of MD changer's mechanism.
Replace with a non-scratched,non-warped disc.
Eject the disc then reload it properly.
Load a pre-recorded MD in the MD changer.
Note:If an error display other than the ones described above appears, press the reset button.
■TROUBLESHOOTING
Problem
Nothing happens when
buttons are pressd.
Display is not accurate.
Cause
The microprocessor has mal-
function due to noise,etc.
Measure
Turn off the power,then press the RELEASE lever and re-
move the DCP.Press the Reset button for about 2 seconds
with a thin rod.
Tuner Amp Unit Main Unit
T
he Reset button The Reset butto
n
■CLOCK ADJUSTMENT
1. When the panel is open,press the [ADJ] button to select
the adjustment mode.
2. Touch the [▼] key to select "CLOCK".Touch the [CLOCK]
key to adjust the time.
3. Touch the [▲],[▼],[a.m] or [p.m] key to adjust the time.
※The time is displayed in 12-hour format.
4. Press the [ADJ] button again or touch the [RTN] key two
times.The unit returns to the previous mode.
■CHANGING THE RECEPTION AREA
This unit is initially set to USA(set to outside USA) frequency
intervals of 10kHz(9kHz) for AM and 200kHz(50kHz) for FM.
When using it outside the USA(in the USA),the frequency
reception range can be switched to the intervals below.
NOTE:( )VRX815P
SETTING THE RECEPTION AREA
While pressing [DISP] button, each time you press and hold
the number "6" of the [DIRECT] buttons for 2 seconds or
longer, the reception area switches from inside the USA to
outside the USA or from outside the USA to inside the USA.
※Any station preset memories are lost when the recep-
tion area is changed.

VRX815
VRX815P - 4 -
■BLOCK DIAGRAM
Tuner amp unit section
CCD/M.LOCK

VRX815
VRX815P
- 5 -
Main unit section
Panel switch PWB
Inner switch PWB
LCD PWB
Main PWB-A
Main PWB-C
Main PWB-B
Slide mechanism
NZX0100

VRX815
VRX815P - 6 -
■ADJUSTMENTS
Main unit section
DC-DC converter output voltage / PLL output voltage adjust-
ment
Condition:
Function→VISUAL mode
Tuner amp unit→Input NTSC color bar video signal
1. Adjust VR551 so that the voltage of TP553 is 5.3±0.03V.
2. Adjust VR502 so that the voltage of TP331 is 1.6±0.05V.
LCD PWB section
Power supply voltage confirmation
1. Make sure the voltage has become the following value
at each test point.
TP08 : 5.3±0.5V
TP09 : 7.5±0.5V
TP10 : 13.0±0.5V
TP07 : −16.0±0.5V
PLL adjustment
1. TP17 connect to GND. Confirm that the TP16 voltage is
2.65±0.1V.
2. Adjust VR707 so that the frequency of TP18 is 15.734kHz
±50Hz.
Screen position adjustment
1. Adjust VR708 so that the pulse width of TP18 is 4.6±
0.1μsec.
Voltage confirmation of J702 connector
VGH(pin32) : 13.0±0.5V
VCC(pin24) : -11.0±0.5V
VGL(pin18) : -7.9±0.5V
VSH(pin1,pin3) : 5.3±0.5V
VIDEO signal adjustment
(step1〜7:NTSC, step8:PAL)
Input the visual signal(10step wave,monochrome,APL=50%,
1.0Vp-p)to the VIDEO input.
1. BRIGHT voltage confirmation
Make sure the voltage of TP01 is 2.0±0.1V.
2. γ0 voltage confirmation
Make sure the voltage of TP05 is 1.95±0.1V.
3. γ2 voltage confirmation
Make sure the voltage of TP06 is 2.15±0.1V.
4. RGB-AMP/CONT-G adjustment
Adjust VR705(RBG AMP) so that VBB voltage of TP12
is 4.0±0.05V.
Adjust VR701(CONT) so that VBW voltage of TP12 is
3.8±0.05V.
5. BRT-R Adjustment
Adjust VR703(BRT-R) so that VBB voltage of TP13 is
4.0±0.05V.
6. BRT-B Adjustment
Adjust VR704(BRT-B) so that VBB voltage of TP11 is
4.0±0.05V.
7. COM-AMP adjustment
Adjust VR702(COM-AMP) so that the amplitude of TP14
is 8.0±0.1Vp-p.
8. Burst cleaning adjustment
Input a color bar signal.(PAL)
Adjust L702 so that the wave form of TP11 is in focus.
VCOM DC bias adjustment
1. Adjust VR706(VCOM DC) to obtain the optimum con-
trast.
Voltage/frequency confirmation of inverter section
TP91 : 5.0±0.5V
TP92 : 53±5kHz
■EXPLANATION OF IC
052-6053-10 MR27V1602E-T2TPZ010 16M bit P2 ROM
1.Terminal Description
pin 1: NU : - : Not in use.
pin 2: A 18 : IN : The address input.
pin 3: A 17 : IN : The address input.
pin 4: A 7 : IN : The address input.
pin 5: A 6 : IN : The address input.
pin 6: A 5 : IN : The address input.
pin 7: A 4 : IN : The address input.
pin 8: A 3 : IN : The address input.
pin 9: A 2 : IN : The address input.
pin 10: A 1 : IN : The address input.
pin 11: A 0 : IN : The address input.
pin 12: CE_ : IN : Chip enable signal input.
pin 13: VSS : - : Negative supply voltage.
pin 14: OE_ : IN : Output enable signal input.
pin 15: D 0 : O : The data output terminal.
pin 16: D 8 : O : The data output terminal.
pin 17: D 1 : O : The data output terminal.
pin 18: D 9 : O : The data output terminal.
pin 19: D 2 : O : The data output terminal.
pin 20: D 10 : O : The data output terminal.
pin 21: D 3 : O : The data output terminal.
pin 22: D 11 : O : The data output terminal.
pin 23: VCC : - : Positive supply voltage.
pin 24: D 4 : O : The data output terminal.
pin 25: D 12 : O : The data output terminal.
pin 26: D 5 : O : The data output terminal.
pin 27: D 13 : O : The data output terminal.
pin 28: D 6 : O : The data output terminal.
pin 29: D 14 : O : The data output terminal.
pin 30: D 7 : O : The data output terminal.
pin 31: D 15 / A -1 :I/O: The data output / The address input.
pin 32: VSS : - : Negative supply voltage.
pin 33: BYTE_ : IN : The data length selection(8bit_/16bit).
pin 34: A 16 : IN : The address input.
pin 35: A 15 : IN : The address input.
pin 36: A 14 : IN : The address input.
pin 37: A 13 : IN : The address input.
pin 38: A 12 : IN : The address input.
pin 39: A 11 : IN : The address input.
pin 40: A 10 : IN : The address input.
pin 41: A 9 : IN : The address input.
pin 42: A 8 : IN : The address input.
pin 43: A 19 : IN : The address input.
pin 44: NU : - : Not in use.
052-6054-10 M30620MCA-F19GP System Controller
1.Terminal Description
pin 1: NU : - : Not in use.
pin 2: NU : - : Not in use.
pin 3: NU : - : Not in use.
pin 4: AMP REM : O : AMP Remote output.
pin 5: RDS CLK : IN : Clock pulse input from RDS decoder.
pin 6: BYTE : IN : Connect to the ground.
pin 7: CN VSS : IN : Inputting "L" at single mode operation.
pin 8: XC IN : IN : Sub system clock.
pin 9: XC OUT : O : Sub system clock.
pin 10: RESET_ : IN : Reset signal input.

VRX815
VRX815P
- 7 -
pin 11: X OUT : O : Crystal connection.
pin 12: VSS : - : Negative supply voltage.
pin 13: X IN : IN : Crystal connection.
pin 14: VCC : - : Positive supply voltage.
pin 15: NMI : IN : Pull up.
pin 16: ACC DET : IN : ACC detection signal input.
pin 17: B/U OFF DET_ : IN : Backup voltage OFF signal input.
pin 18: REQUEST : IN : Request signal input.
pin 19: 27pinCONNECT: IN : Connect to pin 27.
pin 20: NU : - : Not in use.
pin 21: 5V ON : O : 5V power supply ON signal output.
pin 22: NU : - : Not in use.
pin 23: SLAVE ON : O : Slave ON signal output.
pin 24: NU : - : Not in use.
pin 25: NU : - : Not in use.
pin 26: NU : - : Not in use.
pin 27: Ce-NET RX : IN : Serial data input.
pin 28: Ce-NET TX : O : Serial data output.
pin 29: NU : - : Not in use.
pin 30: NU : - : Not in use.
pin 31: CLK 1 : O : Clock pulse output.
pin 32: PLL CE : O : Chip enable signal output to the PLL IC.
pin 33: PLL DO : O : Serial data output to the PLL IC.
pin 34: PLL DI : IN : Serial data input from the PLL IC.
pin 35: PLL SCLK : O : Clock pulse output to the PLL IC.
pin 36: FM STEREO_ : IN : FM STEREO ON signal input.
pin 37: NU : - : Not in use.
pin 38: NU : - : Not in use.
pin 39: AV ON : O : Power supply control signal output.
pin 40: NU : - : Not in use.
pin 41: TENTATIVE : - : The tentative terminal.
pin 42: VOL CLOCK : O : Serial data clock output to the electric vol-
ume IC.
pin 43: VOL DO : O : Serial data output to the electric volume IC.
pin 44: DESTINATION : IN : "L"= North America.
pin 45: SUB 1 : O : The non fader volume level setting com-
mand output.
pin 46: SUB 2 : O : The non fader volume level setting com-
mand output.
pin 47: SUB 3 : O : The non fader volume level setting com-
mand output.
pin 48: NU : - : Not in use.
pin 49: NAVI / CCD 1 : IN : NAVI / CCD 8pin signal selection input.
Refer Table 1.
pin 50: NAVI / CCD 2 : IN : NAVI / CCD 8pin signal selection input.
Refer Table 1.
pin 51: CCD SEL 1 : IN : CCD / Video 8pin signal selection input.
Refer Table 2.
pin 52: CCD SEL 2 : IN : CCD / Video 8pin signal selection input.
Refer Table 2.
pin 53: FV 1 : IN : Front image source selection.
Refer Table 3.
pin 54: FV 2 : IN : Front image source selection.
Refer Table 3.
pin 55: FV 3 : IN : Front image source selection.
Refer Table 3.
pin 56: RV 1 : IN : Rear image source selection. Refer Table 4.
pin 57: RV 2 : IN : Rear image source selection. Refer Table 4.
pin 58: RV 3 : IN : Rear image source selection. Refer Table 4.
pin 59: Audio Sel : IN : Audio signal selection.
pin 60: VCC : - : Positive supply voltage.
pin 61: NU : - : Not in use.
pin 62: GND : - : Ground.
pin 63: NU : - : Not in use.
pin 64: PKB : IN : "H"= Parking brake ON
pin 65: NU : - : Not in use.
pin 66: NU : - : Not in use.
pin 67: NU : - : Not in use.
pin 68: AMP MUTE : O : Muting signal output to the internal Power
Amplifier.
pin 69: 8p Navi Mute_ : O : 8p Navi muting.
pin 70: Ce Navi Mute_ : O : Ce-NET Navi muting.
pin 71: ILL DET_ : IN : Illumination ON signal input.
pin 72: NU : - : Not in use.
pin 73: NU : - : Not in use.
pin 74: System mute_ : O : System muting.
pin 75: LINE MUTE_ : O : Muting signal output.
pin 76: BUS A OUT : O : Ce-NET bus input control. "H"= Audio in-
put. "L"= Audio output.
pin 77: SYS ACC : O : ACC detect signal output.
pin 78: NU : - : Not in use.
pin 79: NU : - : Not in use.
pin 80: NU : - : Not in use.
pin 81: PHONE INT : IN : Telephone interrupt signal input.
pin 82: NU : - : Not in use.
pin 83: NU : - : Not in use.
pin 84: FM SD : IN : FM station detect signal input.
pin 85: AM SD : IN : AM station detect signal input.
pin 86: RDS DATA : IN : RDS serial data input.
pin 87: RDS DISCG : O : Discharge signal output of NOISE 1.
pin 88: RDS MUTE : O : RDS mute signal output.
pin 89: S METER : IN : Input terminal of Internal A/D converter to
detect the Voltage of FM S meter.
pin 90: NOISE 1 : IN : RDS noise level detector input.
pin 91: SPE ANA SIG : IN : Spectrum analyzer signal input.
pin 92: NU : - : Not in use.
pin 93: SD speed up_ : O : SD speed up signal output.
pin 94: A VSS : - : Analog ground.
pin 95: NU : - : Not in use.
pin 96: Vref : - : Reference voltage
pin 97: A VCC : - : Positive supply voltage for the internal an-
alog section.
pin 98: SPAN A : O : Spectrum analyzer frequency selectionion
signal output.
pin 99: SPAN B : O : Spectrum analyzer frequency selectionion
signal output.
pin100: SPAN C : O : Spectrum analyzer frequency selectionion
signal output.
Table 1. NAVI / CCD 8pin signal selection input
N.C. N.C. Image Image Audio
NAVI / CCD 2 ( pin 50 ) L L H H
NAVI / CCD 1 ( pin 49 ) L H L H
Table 2. CCD / Video 8pin signal selection input
N.C. N.C. Image Image Audio
CCD SEL 2 ( pin 52 ) L L H H
CCD SEL 1 ( pin 51 ) L H L H
Table 3. Front image source selection
FV 3 ( pin 55 ) FV 2 ( pin 54 ) FV 1 ( pin 53 )
Blank L L L
DVD L L H
Blank L H L
DVD L H H
CCD / Video H L L
Navi / CCD H L H
Video / Tuner Amp H H L
Video / Tuner Amp H H H
Table 4. Rear image source selection
RV 3 ( pin 58 ) RV 2 ( pin 57 ) RV 1 ( pin 56 )
Blank L L L
DVD L L H
Blank L H L
DVD L H H
CCD / Video H L L
Navi / CCD H L H
Video / Tuner Amp H H L
Video / Tuner Amp H H H
052-7055-10 NZX0100-1701L Touch Panel Controller
1.Terminal Description
pin 1: C 1 : - : Not in use.
pin 2: VL 1 : IN : Positive voltage input for the LCD.
pin 3: LCD ON : O : LCD back light ON signal output.
pin 4: GREEN 1 : O : Signal output for the LED.

VRX815
VRX815P - 8 -
pin 5: AMBER 1 : O : Signal output for the LED.
pin 6: ST 1 : IN : Connect to the ground.
pin 7: YR : IN : Analog signal input.
pin 8: XR : IN : Analog signal input.
pin 9: YG : IN : Analog signal input.
pin 10: XG : IN : Analog signal input.
pin 11: KO 2 : O : Key scan output terminal.
pin 12: KO 1 : O : Key scan output terminal.
pin 13: KO 0 : O : Key scan output terminal.
pin 14: DIMMER : O : Dimmer control signal output.
pin 15: KI 3 : IN : Key scan signal input.
pin 16: KI 2 : IN : Key scan signal input.
pin 17: KI 1 : IN : Key scan signal input.
pin 18: KI 0 : IN : Key scan signal input.
pin 19: GREEN 2 : O : Signal output for the LED.
pin 20: AMBER 2 : O : Signal output for the LED.
pin 21: TXD : O : Data output.
pin 22: RXD : IN : Data input.
pin 23: ST 0 : IN : Connect to the ground.
pin 24: TPW : IN : Touch panel control input.
pin 25: PA :I/O: Touch panel control input/output.
pin 26: CHK : O : Touch panel control output.
pin 27: Y- : O : Touch panel control output.
pin 28: X- : O : Touch panel control output.
pin 29: Y+ : O : Touch panel control output.
pin 30: X+ : O : Touch panel control output.
pin 31: REQ : O : Request signal output.
pin 32: BUSY : O : Busy flag output.
pin 33: NU : - : Not in use.
pin 34: NU : - : Not in use.
pin 35: RESET : IN : Reset signal input.
pin 36: ST 3 : IN : Connect to the ground.
pin 37: ST 2 : IN : Connect to the ground.
pin 38: X IN : IN : Crystal connection.
pin 39: X OUT : O : Crystal connection.
pin 40: VSS : - : Negative supply voltage.
pin 41: VIDEO/RGB : O : Output terminal.
pin 42: MODES : O : Output terminal.
pin 43: DATA : O : Output terminal.
pin 44: LOAD : O : Output terminal.
pin 45: CLOCK : O : Output terminal.
pin 46: CLAMP : O : Output terminal.
pin 47: VIDEO MUTE : O : Output terminal.
pin 48: NTSC/PAL : O : Output terminal.
pin 49: MODEN : O : Output terminal.
pin 50: MODEW : O : Output terminal.
pin 51: SEG 39 : O : Segment output terminal.
pin 52: SEG 38 : O : Segment output terminal.
pin 53: SEG 37 : O : Segment output terminal.
pin 54: SEG 36 : O : Segment output terminal.
pin 55: SEG 35 : O : Segment output terminal.
pin 56: SEG 34 : O : Segment output terminal.
pin 57: SEG 33 : O : Segment output terminal.
pin 58: SEG 32 : O : Segment output terminal.
pin 59: SEG 31 : O : Segment output terminal.
pin 60: SEG 30 : O : Segment output terminal.
pin 61: SEG 29 : O : Segment output terminal.
pin 62: SEG 28 : O : Segment output terminal.
pin 63: SEG 27 : O : Segment output terminal.
pin 64: SEG 26 : O : Segment output terminal.
pin 65: SEG 25 : O : Segment output terminal.
pin 66: SEG 24 : O : Segment output terminal.
pin 67: SEG 23 : O : Segment output terminal.
pin 68: SEG 22 : O : Segment output terminal.
pin 69: SEG 21 : O : Segment output terminal.
pin 70: SEG 20 : O : Segment output terminal.
pin 71: SEG 19 : O : Segment output terminal.
pin 72: SEG 18 : O : Segment output terminal.
pin 73: SEG 17 : O : Segment output terminal.
pin 74: SEG 16 : O : Segment output terminal.
pin 75: SEG 15 : O : Segment output terminal.
pin 76: SEG 14 : O : Segment output terminal.
pin 77: SEG 13 : O : Segment output terminal.
pin 78: SEG 12 : O : Segment output terminal.
pin 79: SEG 11 : O : Segment output terminal.
pin 80: SEG 10 : O : Segment output terminal.
pin 81: SEG 9 : O : Segment output terminal.
pin 82: SEG 8 : O : Segment output terminal.
pin 83: SEG 7 : O : Segment output terminal.
pin 84: SEG 6 : O : Segment output terminal.
pin 85: SEG 5 : O : Segment output terminal.
pin 86: SEG 4 : O : Segment output terminal.
pin 87: SEG 3 : O : Segment output terminal.
pin 88: SEG 2 : O : Segment output terminal.
pin 89: SEG 1 : O : Segment output terminal.
pin 90: SEG 0 : O : Segment output terminal.
pin 91: VCC : - : Positive supply voltage.
pin 92: Vref : - : Reference voltage
pin 93: A VSS : - : Analog ground.
pin 94: COM 3 : O : LCD common signal output.
pin 95: COM 2 : O : LCD common signal output.
pin 96: COM 1 : O : LCD common signal output.
pin 97: COM 0 : O : LCD common signal output.
pin 98: VL 3 : IN : Positive voltage input for the LCD.
pin 99: VL 2 : IN : Positive voltage input for the LCD.
pin100: C 2 : - : Not in use.
052-7059-11 M30624MGA-E13GP System Controller
1.Terminal Description
pin 1: CD DQ SY_ : IN : The timing pulse input to read the text data
of the CD.
pin 2: OPEN CLOSE_ : IN : The key signal input of the Open/Close key.
pin 3: IR IN : IN : Signal input from Remote controller.
pin 4: CD DATA :I/O: The serial data communication terminal with
the CD mechanism.
pin 5: CD C2 : IN : The serial data timing pulse input from the
CD mechanism.
pin 6: BYTE : IN : Connect to the ground.
pin 7: CN VSS : IN : Inputting "L" at single mode operation.
pin 8: XC IN : IN : Not in use.
pin 9: XC OUT : O : Not in use.
pin 10: RESET_ : IN : Reset signal input.
pin 11: X OUT : O : Crystal connection.
pin 12: GND : - : Ground.
pin 13: X IN : IN : Crystal connection.
pin 14: VCC : - : Positive supply voltage.
pin 15: NMI : IN : Pull up.
pin 16: SLAVE ON : IN : Slave ON signal input of Ce-NET.
pin 17: B/U DET_ : IN : Backup voltage ON signal input.
pin 18: ILL_ : IN : Illumination ON signal input.
pin 19: 27pinCONNECT: IN : Connect to pin 27.
pin 20: EEP SO : O : EEP ROM data output.
pin 21: 5V ON : O : 5V power supply ON signal output.
pin 22: BEEP : O : Beep out.
pin 23: PANEL ON : O : LCD panel power on signal output.
pin 24: NDS REQ : IN : Request input of NDS.
pin 25: MASTER REQ : O : The request signal output to the master
micro computer.
pin 26: IR OUT : O : The remote control signal output.
pin 27: RX : IN : Serial data input from IE BUS driver IC.
pin 28: TX : O : Serial data output to IE BUS driver IC.
pin 29: DT : O : The data output to the touch panel control-
ler.
pin 30: TD : IN : The data input from the touch panel control-
ler.
pin 31: T REQ : IN: The request signal input from the touch
panel controller.
pin 32: T RST_ : O : The reset pulse output to the touch panel
controller.
pin 33: NDS TX : O : NDS TX
pin 34: NDS RX : IN : NDS RX
pin 35: OSD RD_ : O : The read strobe pulse output to the OSD
IC.
pin 36: OSD CS_ : O : The chip selection signal output to the OSD
IC.
pin 37: OSD PS 2 : O : The input/output port number signal output

VRX815
VRX815P
- 9 -
to the OSD IC.
pin 38: OSD PS 1 : O : The input/output port number signal output
to the OSD IC.
pin 39: OSD PS 0 : O : The input/output port number signal output
to the OSD IC.
pin 40: NU : - : Not in use.
pin 41: FW_ : IN : The tentative terminal.
pin 42: EEP SI : IN : EEP ROM data intput.
pin 43: EEP SCLK : O : EEP ROM clock output.
pin 44: CD ON_ : IN : CD ON signal output.
pin 45: CD C1 : O : The timing pulse output to the CD mecha-
nism controller.
pin 46: CD RST_ : O : The reset pulse output to the CD mecha-
nism controller.
pin 47: CD CONT : O : Unknown.
pin 48: EJECT OUT_ : O : Eject command output.
pin 49: KI 3 : IN : Key scan signal input.
pin 50: KI 2 : IN : Key scan signal input.
pin 51: KI 1 : IN : Key scan signal input.
pin 52: KI 0 : IN : Key scan signal input.
pin 53: GREEN : O : Green key illumination.
pin 54: AMBER : O : Amber key illumination.
pin 55: BLK LED : O : The blnikng LED control.
pin 56: EJECT SW_ : IN : The eject key signal input.
pin 57: BLK : O : The blank signal output.
pin 58: NV ON : O : "H"= Navigation RGB, "L"= OSD RGB.
pin 59: VIDEO_/RGB : O : Image selection signal output. "H"= RGB.
pin 60: VCC : - : Positive supply voltage.
pin 61: CD PWR ON : O : The CD power ON signal output.
pin 62: GND : - : Ground.
pin 63: MOTOR 2F : O : The motor control signal output.
pin 64: MOTOR 2R : O : The motor control signal output.
pin 65: MOTOR 1F : O : The motor control signal output.
pin 66: MOTOR 1R : O : The motor control signal output.
pin 67: MOT ON : O : Motor ON signal output.
pin 68: MT PW chg2 : O : The motor control signal output.
pin 69: MT PW chg1_ : O : The motor control signal output.
pin 70: NU : - : Not in use.
pin 71: POWER SW_ : IN : Power/Func switch pulse input.
pin 72: DCP_ : IN : DCP detect signal input.
pin 73: OSD INT0_ : IN : The vertical timing pulse input from the
OSD IC.
pin 74: NU : - : Not in use.
pin 75: ROM EN_ : O : RAM data port control signal output for the
OSD IC.
pin 76: OSD WR_ : O : The write strobe pulse output to the OSD
IC.
pin 77: OSD RST_ : O : The reset pulse output to the OSD IC.
pin 78: OSD WAIT_ : IN : The wait signal input from the OSD IC.
pin 79: OSD CD 7 :I/O: Data input/output terminal for the OSD IC.
pin 80: OSD CD 6 :I/O: Data input/output terminal for the OSD IC.
pin 81: OSD CD 5 :I/O: Data input/output terminal for the OSD IC.
pin 82: OSD CD 4 :I/O: Data input/output terminal for the OSD IC.
pin 83: OSD CD 3 :I/O: Data input/output terminal for the OSD IC.
pin 84: OSD CD 2 :I/O: Data input/output terminal for the OSD IC.
pin 85: OSD CD 1 :I/O: Data input/output terminal for the OSD IC.
pin 86: OSD CD 0 :I/O: Data input/output terminal for the OSD IC.
pin 87: SW DET_ : IN : Switch detection.
pin 88: KO 2 : O : Key scan output terminal.
pin 89: KO 1 : O : Key scan output terminal.
pin 90: KO 0 : O : Key scan output terminal.
pin 91: IR SEL : O : Remote control signal selection. "H"= Op-
tical input. "L"= Micro computer signal out-
put.
pin 92: AD 2 : IN : The input terminal of the internal ADC.
pin 93: AD 1 : IN : The input terminal of the internal ADC.
pin 94: GND : - : Ground.
pin 95: EEP CE : O : The chip enable signal output to the EEP
ROM.
pin 96: Vref : - : Reference voltage
pin 97: +5V : - : +5V.
pin 98: CD SUBC : IN : The CD text data input.
pin 99: NU : - : Not in use.
pin100: CD SBCK : O : The clock pulse output to read the text data
of the CD.

VRX815
VRX815P - 10 -
■EXPLODED VIEW・PARTS LIST
Main unit 1/2 section
29 38
12
19
30
27
3
36 4
12
17
28
27
23
35
12
14 34
9
9
5
33
9
3
7
9
13
21
37
22
18
8
9
2
9
24 26
32
1
16
10
10
20
10
20
10
1
31
25 26
69
11
7
15
FUSE(3A)
120-0030-0
0
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
1 347-6451-00 DOUBLE FACE 4
2−−−−− SLIDE MECHANISM 1
3 331-3227-00 CONNECTOR PLATE 1
4 331-3231-00 IC-HOLDER 1
5 039-1972-00 FLEXIBLE PWB 1
(WITHOUT COMPONENT)
6 311-1831-00 LOWER CASE 1
7 347-6578-00 INSULATOR(LCD) 1
8 039-1863-00 PWB(FPC) 1
9 714-2605-81 MACHINE SCREW(M2.6×5) 16
10 781-1750-00 SCREW 8
11 347-6579-00 SHADE(LCD) 1
12 039-1973-00 MAIN PWB 1
(WITHOUT COMPONENT)
13 331-3228-00 MECHANISM BRKT(F) 1
14 331-3229-00 MECHANISM BRKT(R) 1
15 948-0629-00 CD MECHANISM 1
16 286-9851-00 SETPLATE(VRX815) 1
286-9853-00 SETPLATE(VRX815P)
17 347-6624-00 SHIELD FILM 1
18 780-2003-20 SCREW((M2×3) 1
19 714-3004-81 MACHINE SCREW(M3×4) 1
20 714-2604-47 MACHINE SCREW(M2.6×4) 2
21 347-6580-00 INSULATOR(CD) 1
Note:Some parts depend on each model.The model name is specified in the description.

VRX815
VRX815P
- 11 -
9-4 382-6098-00 BUTTON(POS/MUT) 1
9-5 382-6099-00 BUTTON(SEARCH) 1
9-6 382-6100-00 BUTTON(1.2.3) 1
9-7 382-6101-00 BUTTON(4.5.6) 1
9-8 382-6102-00 BUTTON(BAND/TOP) 1
9-9 382-6103-00 BUTTON(FNC/POW) 1
9-10 335-6487-00 REAR-CVR(DCP) 1
9-11 716-0872-11 SCREW 5
9-12 750-3494-00 SPRING(RELEASE) 1
9-13 345-8648-00 SPACER(BND/FNC) 1
9-14 345-8649-00 SPACER(PAUSE) 1
9-15 345-8650-00 SPACER(EJECT) 1
9-16 347-6583-00 SPRING HOLDER 1
10 370-5932-01 ESCUTCHEON 1
11 382-6104-01 BUTTON(DSP/ISR) 1
12 335-6651-00 FILTER 1
13 345-8599-00 SLIDER 1
14 335-6490-00 BUTTON GUIDE 1
15 371-5685-00 TRIM PLATE 1
16 750-3495-00 SPRING(PUSH OUT) 1
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
22 345-8651-01 FPC SPACER 1
23 347-6586-00 MOTOR COVER 2
24 750-3137-02 SPRING(L) 1
25 750-3137-03 SPRING(R) 1
26 714-5008-41 MACHINE SCREW(M5×8) 2
27 714-3008-80 MACHINE SCREW(M3×8) 2
28 313-1829-00 HEAT SINK 1
29 854-4537-00 EXTENSION LEAD(6P) 1
30 854-6385-50 EXTENSION LEAD 1
31 335-6492-00 ES-COVER(R) 1
32 335-6491-00 ES-COVER(L) 1
33 816-2544-00 FLAT WIRE(18P) 1
34 816-2545-00 FLAT WIRE(7P) 1
35 816-2546-00 FLAT WIRE(28P) 1
36 816-2547-00 FLAT WIRE(20P) 1
37 331-3371-00 SUPPORT BRKT 2
38 074-1213-01 OUTLET SOCKET(13P) 1
Main unit 2/2 section
26
1
26
2
3
28
35
6
25
8
22
23
22
36 29 30
31 32
7
25
28
33
5
4
27
34
26
27
15
28
28
28
21
17
18
16
24
19
20
10
13
12
24 11 14
38
9-1
9-3 9-2 9-4
9-5
9-6
9-7
9-8
9-9
9-1
0
9-11
9-11
9-11
9-12
9-13
9-1
4
9-15
9-16
9
37
1 940-7978-00 ESCUTCHEON ASSY 1
2 382-6060-02 BUTTON(ADJ/A-M) 1
3 382-6061-02 BUTTON(SCN/RPT/RDM) 1
4 382-6063-01 BUTTON(M.LOCK) 1
5 039-1983-00 PANEL SWITCH PWB 1
(WITHOUT COMPONENT)
6 345-8598-00 CUSHION 1
7 013-9706-00 SWITCH ASSY 1
8 379-0458-01 INDICATOR(7'LCD) 1
9−−−−− DCP ASSY 1
9-1 370-5933-01 ESCUTCHEON(DCP) 1
9-2 382-6096-00 BUTTON(RELEASE) 1
9-3 382-6097-00 BUTTON(EJECT) 1
NO. PART NO. DESCRIPTION Q'TY
NO. PART NO. DESCRIPTION Q'TY

VRX815
VRX815P - 12 -
14 092-0612-03 ANTENNA RECEPTACLE 1
15 074-1030-00 OUTLET SOCKET(NAVI/CCD) 2
16 075-0310-02 JACK(VIDEO OUT) 1
17 075-9001-01 JACK(VISUAL IN) 1
18 051-2025-00 IC(TDA7386) 1
19 074-1238-00 OUTLET SOCKET(16P) 1
20 074-1194-00 OUTLET SOCKET(CE-NET) 1
21 074-1213-01 OUTLET SOCKET(13P) 1
22 075-9002-02 JACK(AUDIO OUT) 1
23 013-3949-00 SWITCH(RESET) 1
24 013-5102-00 SLIDE SWITCH(DSP/NORMAL) 1
25 880-2084C TUNER PACK 1
26 073-0768-90 TERMINAL 1
17 346-0138-00 LEATHER SHEET 1
18 347-6581-00 SHADE(SPRING) 1
19 347-6585-00 SLIDER COVER 1
20 345-8678-00 SLIDER 1
21 716-0872-11 SCREW 1
22 347-6085-00 DOUBLE FACE 4
23 347-6450-00 DOUBLE FACE 1
24 781-2650-00 SCREW 2
25 345-8618-01 CUSHION 2
26 781-1722-00 SCREW 6
27 781-2026-00 SCREW 4
28 716-0872-00 PAD SCREW 14
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
29 331-3230-00 LCD HOLDER 1
30 379-1207-41 INDICATOR 1
31 347-6577-00 FILM(SUB-LCD) 1
32 335-6489-00 ILLUMI PLATE 1
33 335-6488-00 ILLUMI HOLDER 1
34 345-8611-00 SPACER 1
35 347-6680-00 SPACER 1
36 347-6629-00 DOUBLE FACE 1
37 039-1811-00 LCD PWB 1
(WITHOUT COMPONENT)
38 039-1962-00 INNER SWITCH PWB 1
(WITHOUT COMPONENT)
Tuner amp unit section
24
10
23
22
21
19
8
13
2
1
9
4
5
11
12
7
12
10
10
20
18
25
17
1615 14
10 26
38
6
1 039-1961-00 TUNER PWB 1
(WITHOUT COMPONENT)
2 331-3232-00 FRONT PLATE 1
3 331-3235-00 OUTLET HOLDER 1
4 331-2389-01 IC HOLDER 1
5 313-1730-20 HEAT SINK 1
6 311-1741-01 LOWER CASE 1
7 310-1649-02 UPPER CASE 1
8 702-3008-81 TAP SCREW(3×8) 3
9 714-3006-81 MACHINE SCREW(M3×6) 2
10 716-0878-00 IT SCREW(M2.6×5) 4
11 714-2612-81 MACHINE SCREW(M2.6×12) 3
12 714-2605-81 MACHINE SCREW(M2.6×5) 4
13 060-8021-07 AUTO FUSE(15A) 1
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY

VRX815
VRX815P
- 13 -
■How to release the LCD module
1. Remove the screws(No.Ax2) and the springs(No.Bx2).
2. Remove the screws(No.Cx2,Dx2,Ex4) and release the
flexible PWB(No.F).
3. Release the lower case with CD mechanism(No.G).
4. Remove the screws(No.Hx8,Ix6) and release the
escutchen(No.J).
5. Pull out the LCD module(with switch ass'y) and release
32P/8P/4P connectors.
A
B
A
B
C
D
D
E
E
F
G
H
H
H
H
I
I
J
■948-0629-00 CD mechanism
How to disassemble and reassemble
How to prevent electrostatic breakdown of optical pickup
(Figure A-1)
※Remove the FPC at the optical pickup from the PWB,
then short circuit the pin 4 and pin 5 of the FPC using a
conductive clip such as a short pin.
※When assembling, remove the conductive clip (short pin)
that has been used to short circuit the pin 4 and pin 5 of
the FPC, then immediately connect the FPC to the con-
nector (CN1).
※Use a soldering iron that is dead-grounded or has insu-
lation resistance of 10MΩor over (DC500 V) when mea-
sured 5 minutes after being powered.
※Be sure to use a copper sheet or a conductive sheet (1
GΩor less) on the work bench and ground it.
※To discharge static electricity that has charged on the
technician's body, make sure that he/she wears a ground-
ing band that is grounded (100 MΩor less). Also, avoid
any contact between the technician's clothes and the
optical pickup as the grounding band does not discharge
static electricity that has charged on them.
How to remove PWB (Figures A and B)
1. Disconnect the FPC from connectors CN1, CN3, and
CN5. Short circuit the pin 4 and pin 5 of the FPC at the
optical pickup using a conductive clip such as a short
pin.
2. Disconnect the 2P connector. (Figure A)
3. Remove screw No.7. (Figure A)
4. Lift the PWB in the direction indicated with the arrow
(1),then remove the rib. Pull the PWB in the direction
indicated with the arrow (2),then remove the PWB from
the pawl. (Figure B)
5. While paying attention not to damage the FPC, remove
the PWB.
CN5
CN3
CN1
F P C
F P C
F P C
2 P c o n n e c t o r
N o . 7
p i n 4 p i n 5
F i g u r e A
( a t o p t i c a l
p i c k u p )
F i g u r e A - 1
( a t o p t i c a l p i c k u p )
C o n d u c t i v e c l i p
W 2
O K N G
P W B
( 2 )
( 1 )
F i g u r e B
p a w l R i b
p i c k u p
N o t e s f o r R e a s s e m b l i n g
M a k e s u r e t h a t t h e b o s s o f t h e P W B s w i t c h
( W 2 ) d o e s n o t c o m e o n t o t h e o p t i c a l p i c k u p .
Removal of optical pickup (Figures C,D and E)
1. Disconnect the lead cable from the hook. (Figure C)
2. Remove screw No.48. (Figure C)
3. Remove parts No.4 and 50. (Figure D)
4. Lift the lead screw and disconnect it. (Figure E)
5. Remove the optical pickup. (Figure E)
6. Remove screw No.19, then remove holder No.7. (Figure
E)
7. Remove the lead screw from the optical pickup. (Figure
E)
N o . 4 8
F i g u r e C
H o o k
Lead
c a b l e

VRX815
VRX815P - 14 -
N o . 4
N o . 5 0
F i g u r e D
R i b
D r i v e m o t o r
a s s ' y
D r i v e m o t o r
a n g l e
p i n d l e c o v e r
G r o o v e
N o t e s f o r a s s e m b l i n g B e s u r e t o f i t t h e d r i v e m o t o r
a n g l e ( N o . 5 0 ) c o r r e c t l y i n t o
t h e r i b o f t h e s p i n d l e m o t o r
c o v e r .
N o . 1
N o . 1 9
F i g u r e E
H o l d e r
P i c k u p
L e a d s c r e w
Installation of optical pickup (Figures F, G, G-1,
and G2)
1. Apply grease to the area indicated with "xxx" on the lead
screw. (Figure F)
2. Insert the lead screw into the optical pickup. (Figure F)
3. Fasten holder No. 1 using screw No. 19. (Figure F)
4. Fit the optical pickup into the groove of the traverse as-
sembly. (Figures G and G-1)
5. Fit the lead screw into the hole. (Figure G-2)
N o . 1
N o . 1 9
F i g u r e F
H o l d e r
P i c k u p
L e a d s c r e w
N o . 1 7
F i g u r e G
P i c k u p
F i g u r e G - 1
p r i n g
P i c k u p
T r a v e r s e a s s ' y
L e a d s c r e w
H o l e
F i g u r e G - 2
Notes for disassembling and reassembling gears
Disassembly (Figure A-1)
1. Do not remove the parts indicated with circled P-U. (Fig-
ure A-1)
※Do not remove parts S (No.44 R-side arm) and T (No.33
temporary fastening screw for gear fixing plate). Part S
(No.44 R-side arm), once removed, cannot be reused
because its retaining pawl will crack. Using a once re-
moved R-side arm can cause unstable loading. Be sure
to replace it with a new one.
※Replacing the rubber roller is unnecessary. Clean and
reuse it.
Reassembly (Figures A-1 and A-2)
1. Install the parts in the order of A-N. (Figure A-1)
2. Attach part E (No.40 switching lever) at the position in-
dicated with "a", then rotate it counterclockwise until it
comes to the position indicated with "b". (Figure A-2)
3. Insert the boss of part O (No.34 gear fixing plate) into
the support of each gear.
※Make sure that the ribs of parts I (No.41 roller stopping
lever) and J (No.43 loading hook) are fitted into the in-
ner groove of part P (No.57 control slider). (Figure A-1)
※Do not press hard on part T (No.33 temporary fastening
screw for gear fixing plate) as it can cause unstable load-
ing. Do not remove part T (No.33 temporary fastening
screw for gear fixing plate).
AB
C
0 m m
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
T
U
F i g u r e A - 1
T h e p a r t s i n d i c a t e d w i t h c a n n o t b e
r e u s e d o n c e r e m o v e d .

VRX815
VRX815P
- 15 -
Reassembly of floating lock mechanism (Figure
B)
※Do not remove parts W (No.46 L-side link) and X (No.45
L-side arm). Once removed, these parts cannot be re-
used as removing them causes cracks at their lock re-
taining plate and the retaining hook. Using a once-re-
moved L-side link and L-side arm can cause unstable
loading. Be sure to replace each with a new one.
0 m m
C
E
ab
F i g u r e A - 2
VWX
F i g u r e B
T h e p a r t s i n d i c a t e d w i t h c a n n o t b e r e u s e d o n c e r e m o v e d .
p r i n g
When replacement is necessary
1. Install part V (No.31 lock cam).
2. Install new parts W (No.46 L-side link ) and X (No.45 L-
side arm) to part V (No.31 lock cam), then fix it into the
support.
■EXPLODED VIEW・PARTS LIST
CD mechanism section
EXPLODED VIEW on the next page.
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
1 658-0230-01 HOLDER 1
2 658-0230-02 LEADSCREW ASSY 1
3 658-0230-03 SP MOTOR ASSY 1
3-1 658-0230-04 SP MOTOR FPC 1
4 658-0230-05 DRIVE MOTOR ASSY 1
5−−−−− TRAVERSE ASSY 1
6 658-0230-06 ROLLER SHAFT ASSY 1
7 658-0230-07 SCREW 1
8 658-0230-08 FLOAT SPRING F 2
9 658-0230-09 FLOAT SPRING R 1
10 658-0230-10 BALANCE SPRING 2
11 658-0230-11 CLAMPER ARM SPRING 1
12 658-0230-12 INSULATOR R 1
13 658-0230-13 INSULATOR L 2
14 −−−−− MAIN FLAME 1
15 658-0230-14 UPPER FRAME 1
16 658-0230-15 SCREW 2
17 658-0230-16 SPRING 1
18 658-0230-17 PICK UP 1
19 658-0230-18 SCREW 1
20 658-0230-19 TR BEVEL 1
21 658-0230-20 GEAR 1
22 658-0230-21 GEAR 1
23 658-0230-22 LEVER GEAR 1
24 658-0230-23 GEAR A 1
25 658-0230-24 GEAR B 1
26 658-0230-25 GEAR C 1
27 658-0230-26 ROLLER LEVER GEAR 1
28 658-0230-27 ROLLER GEAR A 1
29 658-0230-28 ROLLER GEAR B 1
30 658-0230-29 ROLLER IDLER 1
31 658-0230-30 L LOCK CAM 1
32 658-0230-31 SCREW 2
33 658-0230-32 SCREW 1
34 658-0230-33 GEAR PLATE 1
35 658-0230-34 SLID SPRING 1
36 658-0230-35 LOADING SPRING 1
37 658-0230-36 ROLLER SPRING L 1
38 658-0230-37 ROLLER SPRING R 1
39 658-0230-38 SHAFT PLATE 1
40 658-0230-39 LEVER 1
41 658-0230-40 ROLLER LEVER 1
42 658-0230-41 TRAVERSE HOOK 1
43 658-0230-42 LODING HOOK 1
44 658-0230-43 R SIDE ARM 1
45 658-0230-44 L SIDE ARM 1
46 658-0230-45 L SIDE LINK 1
47 658-0230-46 SHEET 1
48 658-0230-47 SCREW 1
49 658-0230-48 SCREW 2
50 658-0230-49 DRIVE MOTOR PLATE 1
51 658-0230-50 WIRE 1
52 658-0230-51 SENSOR FPC 1
53 658-0230-52 DISC GUIDE 1
54 658-0230-53 DISC LEVER 2
55 658-0230-54 RACK BASE 1
56 658-0230-55 RACK SCREW 1
57 658-0230-56 SLIDER 1
58 658-0230-57 CLAMPER ARM 1
59 658-0230-58 TRIGGER ARM 1
60 658-0230-59 RUBBER 1
61 658-0230-60 CLAMPER 1
62 658-0230-61 CLAMPER PLATE 1

VRX815
VRX815P - 16 -
6 0
5 8
1 6
6 2
4 7
5 4
5 3
5 4 6 1
3
3 - 1
5 9
1 3
8
5
4 6
3 7 3 1
6
4 5
5 2
3 3
3 4 2 5 2 6 3 6
3 2
3 8
4 4
3 0 1 1
5 5
5 6
5 7
3 5
1 0
2 8
2 4
4 3
2 1
4 0 4 2
2 0
5 1
4 8
5 0
2 7
4 1
2 3
2 2
4 9
7
4
1 6
1 5
9
1 2
1 4
81 0
1 3
1 7
1 9
1
1 8
2
3 9
5
2 9
BB
A
A
A
A
A p p l y g r e a s e t o t h e a r e a i n d i c a t e d w i t h " x x x " .
( B o t t o m v i e w )
F o r p a r t s i n d i c a t e d w i t h ( N o s . 4 4 , 4 5 a n d 4 6 ) , d o n o t r e u s e a n y o f t h e m o n c e r e m o v e d ,
b e c a u s e r e m o v a l c a u s e s c r a c k s a t t h e i r r e t a i n i n g h o o k .

VRX815
VRX815P
- 17 -
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
Note) Several different parts of the same reference number are alternative parts.
One of those parts is used in the set.
■ELECTRICAL PARTS LIST
Main PWB section(B1)
C401 168-1022-55 1000pF
C402 168-1022-55 1000pF
C403 042-0600-00 16V1000μF
C404 168-1045-56 0.1μF
C405 163-4763-35 16V47μF
C406 168-1032-55 0.01μF
C407 168-1032-55 0.01μF
C408 168-1032-55 0.01μF
C409 168-1042-78 16V 0.1μF
C410 042-0559-00 5.5V0.1μF
C411 168-1022-55 1000pF
C412 163-1063-35 16V10μF
C413 168-1022-55 1000pF
C414 168-1032-55 0.01μF
C415 163-1063-35 16V10μF
C416 168-1032-55 0.01μF
C417 042-0635-51 16V39μF
C418 168-1042-78 16V 0.1μF
C419 172-1041-11 0.1μF
C420 172-1041-11 0.1μF
C421 042-0627-90 16V100μF
C422 042-0560-62 16V22μF
C423 043-0296-50 0.1μF
C424 043-0296-50 0.1μF
C425 168-1042-78 16V 0.1μF
C426 168-1042-78 16V 0.1μF
C427 163-1073-35 16V100μF
C428 042-0635-51 16V39μF
C429 168-6822-55 6800pF
C441 168-1045-56 0.1μF
C471 184-2273-31 16V220μF
C472 168-1045-56 0.1μF
C501 168-1045-56 0.1μF
C502 042-0416-57 10V47μF
C503 042-0416-51 6.3V10μF TAN
C504 168-1045-56 0.1μF
C505 168-1045-56 0.1μF
C506 168-1045-56 0.1μF
C508 168-1045-56 0.1μF
C509 042-0416-52 10V10μF TAN
C513 168-1045-56 0.1μF
C514 168-1045-56 0.1μF
C516 168-1042-78 16V 0.1μF
C517 168-3322-55 3300pF
C518 166-5601-54 560pF TH
C519 168-1045-56 0.1μF
C523 168-1045-56 0.1μF
C525 168-1045-56 0.1μF
C526 168-1045-56 0.1μF
C528 168-1045-56 0.1μF
C529 168-1032-55 0.01μF
C530 168-1045-56 0.1μF
C537 168-4712-55 470pF
C551 163-4763-35 16V47μF
C552 176-1021-50 1000pF CH
C553 163-4753-55 35V4.7μF
C554 163-1063-55 35V10μF
C555 176-2221-50 2200pF CH
C556 042-0528-50 35V15μF
C557 163-3363-45 25V33μF
C558 184-2273-31 16V220μF
C559 163-3373-15 6.3V330μF
C560 042-0528-50 35V15μF
C561 163-4763-35 16V47μF
C562 042-0528-50 35V15μF
C563 163-1073-35 16V100μF
C571 184-2273-31 16V220μF
C577 168-4712-55 470pF
C586 168-1045-56 0.1μF
CCT421 050-0122-50 1/16W10kΩ×4 J
CCT422 050-0122-50 1/16W10kΩ×4 J
CCT423 050-0122-58 1/16W470Ω×4 J
CCT424 050-0122-58 1/16W470Ω×4 J
CCT501 050-0122-58 1/16W470Ω×4 J
CCT502 050-0122-51 1/16W47kΩ×4 J
CCT503 050-0122-51 1/16W47kΩ×4 J
CCT504 050-0122-58 1/16W470Ω×4 J
CCT505 050-0122-58 1/16W470Ω×4 J
CCT506 050-0122-58 1/16W470Ω×4 J
CCT507 050-0122-58 1/16W470Ω×4 J
CCT508 050-0122-58 1/16W470Ω×4 J
CCT509 050-0122-58 1/16W470Ω×4 J
CCT510 050-0122-51 1/16W47kΩ×4 J
CCT511 050-0122-51 1/16W47kΩ×4 J
CCT512 050-0122-58 1/16W470Ω×4 J
CCT513 050-0122-58 1/16W470Ω×4 J
CCT516 050-0122-58 1/16W470Ω×4 J
CCT517 050-0122-58 1/16W470Ω×4 J
CCT518 050-0122-58 1/16W470Ω×4 J
CCT519 050-0122-58 1/16W470Ω×4 J
CCT520 050-0122-58 1/16W470Ω×4 J
D405 001-0584-32 MA8180
D406 001-0529-38 MA8068-M
D407 001-0537-90 SFPM-62
D408 001-0537-90 SFPM-62
D409 001-0537-90 SFPM-62
D410 001-0347-42 MA4075H
D412 001-0529-39 MA8068-H
D413 001-0529-49 MA8100-L
D414 001-0188-01 1S1885A
D415 001-0584-25 MA8091
D416 001-0516-90 MA111
D417 001-0516-90 MA111
D420 001-0516-90 MA111
D421 001-0525-90 IMN10
D422 001-0525-90 IMN10
D551 001-0516-90 MA111
D552 001-2606-90 M1FS4
D553 001-2606-90 M1FS4
D554 001-0516-90 MA111
F501 060-8023-52 0.75A
IC401 052-7059-11 M30624MGA-E13GP
IC402 051-1822-08 S-80732AN-DW-X
IC403 051-6600-38 CA0008AM
IC404 051-9400-28 BR93LC46F-WE2
IC405 051-1250-08 TC4S66F
IC406 051-3201-00 AN77L06
IC407 051-1014-00 TA7291P
IC408 051-1014-00 TA7291P
IC409 051-3294-90 TA78DS10F
IC410 051-5417-08 S80927ANMP-DDQ-
T2
IC503 051-6437-00 YGV608F
IC504 051-1485-08 MC74HC4046AF
IC506 051-1478-08 TC74HC4053AF
IC507 051-5306-90 MM1117XF
IC508 051-7202-08 TC7S32F
IC509 051-1855-08 TC7W14F
IC515 051-7513-08 HD74LV541A
IC516 051-7513-08 HD74LV541A
IC517 051-7513-08 HD74LV541A
IC518 051-3263-90 NJU7200U33
IC531 052-6053-10 MR27V1602E-
T2TPZ010
IC551 051-3903-90 NJM2368M
J401 074-1201-68 18P
J402 074-1059-76 26P
J403 074-1213-01 OUTLET SOCKET
J404 074-1239-78 28P
J406 074-1100-70
J501 074-1205-00 50P
J502 074-1048-57 7P
J503 074-1201-70 20P
J504 074-1059-78 28P
J505 076-0349-06 6P
J551 074-1048-57 7P
L401 010-2199-62 1μH
L411 010-2279-50 4.7μH
L501 010-2199-71 5.6μH J
L502 010-2199-71 5.6μH J
L505 010-2285-61 BLM21P300
L506 010-2285-51 BLM21A05PT
L507 010-2285-51 BLM21A05PT
L508 010-2285-51 BLM21A05PT
L509 010-2279-50 4.7μH
L551 010-3057-90 100μH
L552 010-2199-86 100μH J
L553 010-3057-90 100μH
L554 010-2174-74 100μH
L555 010-2199-86 100μH J
Q401 125-2017-97 RN1427
Q402 125-2017-97 RN1427
Q403 125-2004-96 RN1406
Q404 125-0021-91 DTA114EU
Q405 192-2712-00 2SC2712
Q406 192-2712-00 2SC2712
Q407 125-0002-92 RN2402
Q408 190-1736-00 2SA1736
Q409 125-2004-93 RN1403
Q410 101-1143-00 2SB1143
Q411 102-3420-00 2SC3420
Q412 190-1162-00 2SA1162
Q413 125-2004-93 RN1403
Q414 125-2004-93 RN1403
Q415 125-2004-96 RN1406
Q416 125-2004-96 RN1406
Q417 125-2004-92 RN1402
Q418 190-1736-00 2SA1736
Q420 190-1428-00 2SA1428
Q421 101-1143-00 2SB1143
Q501 125-2004-92 RN1402
Q502 125-2024-92 RN1602
Q551 192-2873-00 2SC2873
Q570 125-0002-95 RN2405
R406 119-2231-15 1/16W 22kΩ
R407 119-1021-15 1/16W 1kΩ
R408 119-4731-15 1/16W 47kΩ
R409 119-2231-15 1/16W 22kΩ
R410 032-0106-63 1/10W 47kΩ0.5%
R411 032-0106-61 1/10W 22kΩ0.5%
R412 119-4711-15 1/16W 470Ω
R413 119-4711-15 1/16W 470Ω
R414 119-4711-15 1/16W 470Ω
R415 119-4721-15 1/16W 4.7kΩ
R416 119-4721-15 1/16W 4.7kΩ
R417 119-1031-15 1/16W 10kΩ
R418 119-1231-15 1/16W 12kΩ
R419 119-3321-15 1/16W 3.3kΩ
R420 119-4711-15 1/16W 470Ω
R421 119-1031-15 1/16W 10kΩ
R422 119-4721-15 1/16W 4.7kΩ
R423 119-2231-15 1/16W 22kΩ
R424 119-4731-15 1/16W 47kΩ
R425 119-1221-15 1/16W 1.2kΩ
R426 119-4711-15 1/16W 470Ω
R427 119-1031-15 1/16W 10kΩ
R428 032-0104-68 1/4W 22Ω
R429 119-6811-15 1/16W 680Ω
R430 119-3321-15 1/16W 3.3kΩ
R431 119-1031-15 1/16W 10kΩ
R432 032-0104-66 1/4W 470Ω
R433 119-6811-15 1/16W 680Ω
R434 119-2721-15 1/16W 2.7kΩ

VRX815
VRX815P - 18 -
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
R435 119-2721-15 1/16W 2.7kΩ
R436 119-4721-15 1/16W 4.7kΩ
R437 119-1031-15 1/16W 10kΩ
R438 111-6811-81 1/2WS 680Ω
R439 119-1021-15 1/16W 1kΩ
R440 119-1011-15 1/16W 100Ω
R441 119-6811-15 1/16W 680Ω
R442 119-4731-15 1/16W 47kΩ
R443 119-2721-15 1/16W 2.7kΩ
R444 119-2721-15 1/16W 2.7kΩ
R445 119-2701-15 1/16W 27Ω
R446 119-1031-15 1/16W 10kΩ
R447 119-2701-15 1/16W 27Ω
R448 119-2701-15 1/16W 27Ω
R449 119-2721-15 1/16W 2.7kΩ
R466 119-2231-15 1/16W 22kΩ
R467 119-2231-15 1/16W 22kΩ
R468 119-1011-15 1/16W 100Ω
R469 119-1011-15 1/16W 100Ω
R470 119-3301-15 1/16W 33Ω
R472 119-1011-15 1/16W 100Ω
R473 119-4731-15 1/16W 47kΩ
R474 119-4731-15 1/16W 47kΩ
R476 119-1031-15 1/16W 10kΩ
R477 119-4731-15 1/16W 47kΩ
R501 119-3311-15 1/16W 330Ω
R502 119-3311-15 1/16W 330Ω
R503 119-3311-15 1/16W 330Ω
R504 119-1211-15 1/16W 120Ω
R505 119-1211-15 1/16W 120Ω
R506 119-1211-15 1/16W 120Ω
R507 119-4711-15 1/16W 470Ω
R508 119-4711-15 1/16W 470Ω
R509 119-1021-15 1/16W 1kΩ
R510 119-3311-15 1/16W 330Ω
R512 119-2211-15 1/16W 220Ω
R513 119-3321-15 1/16W 3.3kΩ
R514 032-0140-80 1/16W 18kΩ1%
R515 119-1021-15 1/16W 1kΩ
R516 119-1011-15 1/16W 100Ω
R517 119-1011-15 1/16W 100Ω
R518 119-1011-15 1/16W 100Ω
R519 119-1531-15 1/16W 15kΩ
R520 119-1531-15 1/16W 15kΩ
R521 119-1531-15 1/16W 15kΩ
R528 119-1021-15 1/16W 1kΩ
R530 119-1531-15 1/16W 15kΩ
R531 119-1531-15 1/16W 15kΩ
R532 119-1531-15 1/16W 15kΩ
R533 119-1011-15 1/16W 100Ω
R534 119-4711-15 1/16W 470Ω
R538 119-4721-15 1/16W 4.7kΩ
R539 119-1021-15 1/16W 1kΩ
R540 119-1011-15 1/16W 100Ω
R545 119-5131-15 1/16W 51kΩ
R546 119-5131-15 1/16W 51kΩ
R547 119-5131-15 1/16W 51kΩ
R550 119-7501-15 1/16W 75Ω
R551 119-6841-15 1/16W 680kΩ
R552 119-1841-15 1/16W 180kΩ
R553 119-1001-15 1/16W 10Ω
R554 119-3931-15 1/16W 39kΩ
R555 119-6841-15 1/16W 680kΩ
R556 119-3311-15 1/16W 330Ω
R557 119-2221-15 1/16W 2.2kΩ
R558 119-2231-15 1/16W 22kΩ
T551 007-1151-90 OUTPUT TRANS
VR502 012-6009-58 33kΩ
VR551 012-6009-52 1kΩ
X401 060-1505-50 10MHz
X551 060-0100-01 CB13PA-215
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
LCD PWB(B2) section
C701 168-1045-56 0.1μF
C703 168-1045-56 0.1μF
C704 168-1045-56 0.1μF
C705 163-3373-15 6.3V330μF
C707 178-1052-78 1μF
C708 168-1045-56 0.1μF
C709 042-0397-55 6.3V3.3μF TAN
C710 168-2222-55 2200pF
C711 168-2232-55 0.022μF
C712 166-5601-50 56pF CH
C713 042-0416-54 16V10μF
C714 168-1032-55 0.01μF
C715 178-1052-78 1μF
C716 178-1052-78 1μF
C717 042-0397-50 16V1μF TAN
C718 178-4742-78 0.47μF
C719 178-4742-78 0.47μF
C720 178-4742-78 0.47μF
C721 168-1032-55 0.01μF
C722 168-1032-55 0.01μF
C723 178-1052-78 1μF
C724 166-1201-50 12pF CH
C725 178-1052-78 1μF
C726 168-8212-55 820pF
C727 166-2201-50 22pF CH
C728 178-1052-78 1μF
C729 168-1045-56 0.1μF
C730 168-6812-55 680pF
C731 168-1032-55 0.01μF
C732 168-1045-56 0.1μF
C733 168-1032-55 0.01μF
C734 168-4735-56 0.047μF
C735 168-1032-55 0.01μF
C736 168-1032-55 0.01μF
C737 168-1032-55 0.01μF
C738 166-8201-50 82pF CH
C739 178-1052-78 1μF
C740 168-1032-55 0.01μF
C741 178-1052-78 1μF
C742 168-1032-55 0.01μF
C743 168-1032-55 0.01μF
C744 178-1052-78 1μF
C745 178-1052-78 1μF
C746 178-1052-78 1μF
C747 042-0416-57 10V47μF
C748 178-1052-78 1μF
C749 042-0397-53 25V0.47μF TAN
C750 168-1032-55 0.01μF
C753 168-1045-56 0.1μF
C754 168-1045-56 0.1μF
C755 168-1045-56 0.1μF
C756 168-1045-56 0.1μF
C757 168-1045-56 0.1μF
C758 168-1045-56 0.1μF
C759 168-1045-56 0.1μF
C760 042-0416-54 16V10μF
C761 168-1045-56 0.1μF
C762 178-1052-78 1μF
C763 042-0416-54 16V10μF
C764 168-1045-56 0.1μF
C765 042-0416-54 16V10μF
C766 178-1052-78 1μF
C767 168-5612-55 560pF
C768 168-1045-56 0.1μF
C769 168-1045-56 0.1μF
C770 168-1045-56 0.1μF
C771 166-3301-50 33pF CH
C772 166-3301-50 33pF CH
C773 168-1045-56 0.1μF
C774 168-1022-55 1000pF
C775 168-1045-56 0.1μF
C776 168-1045-56 0.1μF
C777 168-1022-55 1000pF
C778 166-1011-50 100pF CH
C779 178-1052-78 1μF
C780 178-2242-78 0.22μF
C781 168-1045-56 0.1μF
C782 168-3912-55 390pF
C783 042-0416-54 16V10μF
C784 166-8201-50 82pF CH
C785 168-2212-55 220pF
C786 168-1045-56 0.1μF
C787 168-1045-56 0.1μF
C788 168-1045-56 0.1μF
C789 163-2263-55 35V22μF
C790 168-1045-56 0.1μF
C791 168-1045-56 0.1μF
C792 168-1045-56 0.1μF
C793 168-1045-56 0.1μF
C794 163-1063-35 16V10μF
C795 166-5601-52 56pF RH
C801 168-1045-56 0.1μF
C802 042-0416-57 10V47μF
C803 042-0416-57 10V47μF
C804 168-1045-56 0.1μF
C805 168-1022-55 1000pF
C806 168-1022-55 1000pF
C807 168-1022-55 1000pF
C808 168-1022-55 1000pF
C809 168-1022-55 1000pF
C810 168-1022-55 1000pF
C811 168-1022-55 1000pF
C812 166-1801-50 18pF CH
C813 166-1801-50 18pF CH
C814 168-1022-55 1000pF
C901 168-1045-56 0.1μF
C902 168-1045-56 0.1μF
C903 168-1045-56 0.1μF
C904 168-1532-55 0.015μF
C905 168-1045-56 0.1μF
C906 042-0416-54 16V10μF
C907 168-4712-55 470pF
C908 043-0504-51 10V 3.3μF
C909 168-1022-55 1000pF
C910 177-2252-78 16V2.2μF
C911 177-2252-78 16V2.2μF
C912 043-0510-50 16V 22μF
C913 168-1032-55 0.01μF
C914 043-0308-90 18pF
C915 168-2232-55 0.022μF
C916 043-0308-90 18pF
C917 043-0308-90 18pF
C918 168-1045-56 0.1μF
C919 168-1045-56 0.1μF
C920 168-1045-56 0.1μF
C921 042-0595-65 16V47μF
C922 042-0595-65 16V47μF
CCT701 050-0122-58 1/16W470Ω×4 J
CCT702 050-0122-58 1/16W470Ω×4 J
CCT703 050-0122-60 1/16W33Ω×4 J
CCT704 050-0122-58 1/16W470Ω×4 J
CCT705 050-0122-60 1/16W33Ω×4 J
CCT801 050-0122-50 1/16W10kΩ×4 J
CCT802 050-0122-53 1/16W1kΩ×4 J
CCT803 050-0122-53 1/16W1kΩ×4 J
CCT804 050-0122-53 1/16W1kΩ×4 J
D701 001-0354-91 MA151WK
D702 001-3211-90 MA335-TX
D703 001-0367-91 1SS226
D704 001-0529-29 MA8051-M
D801 001-7046-01 NSPW310BS-A,RS

VRX815
VRX815P
- 19 -
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
D802 001-7046-01 NSPW310BS-A,RS
D803 001-0516-90 MA111
D804 001-0516-90 MA111
D805 001-0516-90 MA111
D806 001-7045-92 CL-165HR/YG-D-T
D807 001-7045-92 CL-165HR/YG-D-T
D810 001-0516-90 MA111
D811 001-0516-90 MA111
D812 001-0516-90 MA111
D813 001-0516-90 MA111
D814 001-0516-90 MA111
D815 001-0516-90 MA111
D816 001-0516-90 MA111
D817 001-0516-90 MA111
D901 001-0529-29 MA8051-M
D902 001-0413-91 MA153
D903 001-0413-91 MA153
IC701 051-7202-18 TC7S32FU-TE85L
IC702 051-6435-08 M62354FP-70ND
IC703 051-5313-10 IR3Y29BM
IC704 051-1527-08 TC4W53F
IC705 051-1292-90 NJM4565M-D
IC706 051-3025-90 NJM2107F
IC707 051-6042-00 LZ9GJ18
IC801 052-7055-10 NZX0100-1701L
IC901 051-3916-90 OZ965
IC902 051-3040-90 NJM2125F
IC903 125-9018-90 HAT3010
J701 074-1189-85 35P
J702 074-1205-82 32P
J801 074-1189-95 45P
J802 074-1275-58 8P
L701 010-2199-83 56μH J
L702 010-3200-90 T621B
L703 010-2199-80 33μH J
L704 010-2199-74 10μH J
L705 010-2323-70 15μH
L706 010-2323-59 2.7μH
L707 010-2199-66 2.2μH J
L801 010-2199-82 47μH J
L901 010-3059-90 ZJYS51R5-2P-G
P801 076-0645-80 30P
P901 076-0529-04 4P
Q701 190-1738-00 2SA1738
Q702 125-0002-93 RN2403
Q703 192-3326-00 2SC3326
Q704 125-2004-92 RN1402
Q705 192-2712-00 2SC2712
Q706 125-2004-92 RN1402
Q707 190-1738-00 2SA1738
Q708 125-2037-90 XN1211
Q709 125-2004-92 RN1402
Q710 192-2712-00 2SC2712
Q801 125-2004-96 RN1406
Q802 125-2004-96 RN1406
Q803 125-2004-95 RN1405
Q804 125-0002-95 RN2405
Q805 125-0002-95 RN2405
Q806 125-2004-95 RN1405
Q807 125-2004-96 RN1406
Q808 125-2017-97 RN1427
Q809 125-2017-97 RN1427
Q901 190-1461-00 2SA1461
Q902 125-2004-93 RN1403
Q903 192-3734-00 2AC3734
Q904 192-3734-00 2AC3734
Q905 192-3734-00 2AC3734
Q906 190-1461-00 2SA1461
R701 119-4711-15 1/16W 470Ω
R702 119-4721-15 1/16W 4.7kΩ
R703 119-1021-15 1/16W 1kΩ
R704 119-1021-15 1/16W 1kΩ
R705 119-1031-15 1/16W 10kΩ
R706 119-3341-15 1/16W 330kΩ
R707 119-2231-15 1/16W 22kΩ
R708 119-2221-15 1/16W 2.2kΩ
R709 119-3321-15 1/16W 3.3kΩ
R710 119-6821-15 1/16W 6.8kΩ
R711 119-2431-15 1/16W 24kΩ
R712 119-2221-15 1/16W 2.2kΩ
R713 119-3331-15 1/16W 33kΩ
R714 119-2231-15 1/16W 22kΩ
R715 119-2231-15 1/16W 22kΩ
R716 119-2231-15 1/16W 22kΩ
R717 119-2731-15 1/16W 27kΩ
R718 119-2221-15 1/16W 2.2kΩ
R719 119-5631-15 1/16W 56kΩ
R720 119-3931-15 1/16W 39kΩ
R721 032-0098-93 1/10W 18kΩ2%
R722 119-3341-15 1/16W 330kΩ
R723 119-5621-15 1/16W 5.6kΩ
R724 119-1021-15 1/16W 1kΩ
R725 119-5611-15 1/16W 560Ω
R726 119-1021-15 1/16W 1kΩ
R727 117-3351-15 1/10W 3.3MΩ
R728 119-3931-15 1/16W 39kΩ
R729 119-2231-15 1/16W 22kΩ
R730 119-3931-15 1/16W 39kΩ
R731 119-2231-15 1/16W 22kΩ
R732 119-4731-15 1/16W 47kΩ
R733 119-2231-15 1/16W 22kΩ
R734 119-1051-15 1/16W 1MΩ
R735 119-6821-15 1/16W 6.8kΩ
R736 119-4731-15 1/16W 47kΩ
R737 119-2731-15 1/16W 27kΩ
R738 119-5621-15 1/16W 5.6kΩ
R739 119-1521-15 1/16W 1.5kΩ
R740 119-4731-15 1/16W 47kΩ
R741 119-3331-15 1/16W 33kΩ
R742 119-1011-15 1/16W 100Ω
R743 119-1011-15 1/16W 100Ω
R744 119-1011-15 1/16W 100Ω
R745 119-6811-15 1/16W 680Ω
R746 119-5621-15 1/16W 5.6kΩ
R747 119-2221-15 1/16W 2.2kΩ
R748 119-8221-15 1/16W 8.2kΩ
R749 119-1521-15 1/16W 1.5kΩ
R750 119-3311-15 1/16W 330Ω
R751 119-1001-15 1/16W 10Ω
R752 119-1531-15 1/16W 15kΩ
R753 119-1031-15 1/16W 10kΩ
R754 119-1031-15 1/16W 10kΩ
R755 119-3301-15 1/16W 33Ω
R756 119-3301-15 1/16W 33Ω
R757 119-4721-15 1/16W 4.7kΩ
R758 119-2221-15 1/16W 2.2kΩ
R759 119-2731-15 1/16W 27kΩ
R760 119-4731-15 1/16W 47kΩ
R761 032-0092-33 1/10W 3.6kΩ1%
R762 032-0092-58 1/10W 4.7kΩ1%
R763 119-4731-15 1/16W 47kΩ
R764 119-6831-15 1/16W 68kΩ
R765 119-4331-15 1/16W 43kΩ
R766 119-1051-15 1/16W 1MΩ
R767 119-1051-15 1/16W 1MΩ
R768 119-6831-15 1/16W 68kΩ
R769 119-2711-15 1/16W 270Ω
R770 119-2421-15 1/16W 2.4kΩ
R771 119-1031-15 1/16W 10kΩ
R772 119-1031-15 1/16W 10kΩ
R773 119-5641-15 1/16W 560kΩ
R774 119-5641-15 1/16W 560kΩ
R775 119-2721-15 1/16W 2.7kΩ
R776 119-3321-15 1/16W 3.3kΩ
R777 119-2241-15 1/16W 220kΩ
R778 119-1011-15 1/16W 100Ω
R779 119-3311-15 1/16W 330Ω
R780 119-3331-15 1/16W 33kΩ
R781 119-1001-15 1/16W 10Ω
R782 119-1031-15 1/16W 10kΩ
R783 119-2431-15 1/16W 24kΩ
R801 119-7501-15 1/16W 75Ω
R802 119-1021-15 1/16W 1kΩ
R803 119-4721-15 1/16W 4.7kΩ
R804 119-4721-15 1/16W 4.7kΩ
R805 119-4721-15 1/16W 4.7kΩ
R806 119-7501-15 1/16W 75Ω
R807 119-4711-15 1/16W 470Ω
R808 119-4711-15 1/16W 470Ω
R809 119-4731-15 1/16W 47kΩ
R810 119-3321-15 1/16W 3.3kΩ
R811 119-4731-15 1/16W 47kΩ
R812 119-4731-15 1/16W 47kΩ
R813 119-1521-15 1/16W 1.5kΩ
R814 119-4711-15 1/16W 470Ω
R815 119-4711-15 1/16W 470Ω
R816 119-4701-15 1/16W 47Ω
R817 119-4701-15 1/16W 47Ω
R818 119-1031-15 1/16W 10kΩ
R819 119-1031-15 1/16W 10kΩ
R820 119-1031-15 1/16W 10kΩ
R901 119-5631-15 1/16W 56kΩ
R902 119-6831-15 1/16W 68kΩ
R903 119-3331-15 1/16W 33kΩ
R904 119-2731-15 1/16W 27kΩ
R905 119-2731-15 1/16W 27kΩ
R906 119-6831-15 1/16W 68kΩ
R907 119-4731-15 1/16W 47kΩ
R908 119-1231-15 1/16W 12kΩ
R909 119-3021-15 1/16W 3kΩ
R910 032-0104-51 1/4W 820Ω
R911 032-0104-51 1/4W 820Ω
R912 119-8231-15 1/16W 82kΩ
R913 119-5631-15 1/16W 56kΩ
R914 119-1041-15 1/16W 100kΩ
R915 119-5631-15 1/16W 56kΩ
R916 119-1021-15 1/16W 1kΩ
R917 119-3321-15 1/16W 3.3kΩ
R918 119-3301-15 1/16W 33Ω
R919 119-1001-15 1/16W 10Ω
R920 119-1051-15 1/16W 1MΩ
R921 119-3611-15 1/16W 360Ω
S701 013-6521-50 SKQLLC
S702 013-6521-50 SKQLLC
S801 013-6521-50 SKQLLC
S802 013-6521-50 SKQLLC
T901 007-1163-01 OUTPUT TRANS
TM701 073-0768-90 TERMIMAL
TM801 073-0768-90 TERMIMAL
VR701 012-6009-58 33kΩ
VR702 012-6009-58 33kΩ
VR703 012-6009-58 33kΩ
VR704 012-6009-58 33kΩ
VR705 012-6009-58 33kΩ
VR706 012-4997-56 10K-B
VR707 012-6009-56 10kΩ
VR708 012-6009-61 100kΩ
X701 061-3520-95 3.57945MHz
X702 061-3524-90 4.433618MHz
X801 061-3521-90 4.9152MHz

VRX815
VRX815P - 20 -
Tuner PWB section(B3)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
BL1 880-2084C AM/FM TUNER
C1 166-1801-50 18pF CH
C2 163-2263-35 16V22μF
C3 168-2212-55 220pF
C4 168-2222-55 2200pF
C5 168-1022-55 1000pF
C6 168-2232-55 0.022μF
C7 168-2232-55 0.022μF
C8 168-1032-55 0.01μF
C9 168-2232-55 0.022μF
C10 168-3932-78 0.039μF
C11 168-6822-55 6800pF
C12 168-2732-55 16V 0.027μF
C13 168-2732-55 16V 0.027μF
C15 163-2253-65 50V2.2μF
C17 168-1222-55 1200pF
C18 168-8222-55 8200pF
C19 168-2212-55 220pF
C20 168-4735-56 0.047μF
C21 163-4763-35 16V47μF
C22 168-1045-56 0.1μF
C23 163-1053-65 50V1μF
C24 166-1011-50 100pF CH
C25 166-1011-50 100pF CH
C26 166-1011-50 100pF CH
C27 166-1501-50 15pF CH
C28 166-1801-50 18pF CH
C33 163-2263-35 16V22μF
C35 166-1011-50 100pF CH
C43 168-1022-55 1000pF
C48 168-1032-55 0.01μF
C51 178-1052-78 1μF
C52 178-1052-78 1μF
C53 178-1052-78 1μF
C54 178-1052-78 1μF
C55 178-1052-78 1μF
C56 178-1052-78 1μF
C57 178-1052-78 1μF
C58 178-1052-78 1μF
C59 163-4753-55 35V4.7μF
C60 168-1045-56 0.1μF
C61 184-1083-12 6.3V1000μF
C62 166-3096-50 3pF CJ
C63 163-4763-15 6.3V47μF
C65 168-1045-56 0.1μF
C66 163-1073-35 16V100μF
C67 184-1083-12 6.3V1000μF
C68 168-1032-55 0.01μF
C69 168-1032-55 0.01μF
C70 178-1052-78 1μF
C71 178-1052-78 1μF
C72 163-4763-35 16V47μF
C91 166-1011-50 100pF CH
C92 166-1011-50 100pF CH
C93 166-1011-50 100pF CH
C94 166-1011-50 100pF CH
C95 166-1011-50 100pF CH
C96 166-1011-50 100pF CH
C97 166-1011-50 100pF CH
C98 166-1011-50 100pF CH
C101 163-1053-65 50V1μF
C102 168-4745-79 0.47μF
C103 163-1063-35 16V10μF
C105 163-1053-65 50V1μF
C106 166-2201-50 22pF CH
C107 166-2201-50 22pF CH
C110 168-1032-55 0.01μF
C111 163-1063-35 16V10μF
C112 042-0592-58 16V10μF
C113 042-0592-58 16V10μF
C114 042-0592-58 16V10μF
C115 042-0592-58 16V10μF
C116 168-2212-55 220pF
C117 168-2212-55 220pF
C118 168-2212-55 220pF
C119 168-2212-55 220pF
C120 168-1045-56 0.1μF
C121 168-1045-56 0.1μF
C122 042-0592-58 16V10μF
C123 042-0592-58 16V10μF
C124 042-0592-58 16V10μF
C125 042-0592-58 16V10μF
C126 042-0592-58 16V10μF
C127 042-0592-58 16V10μF
C128 166-1201-50 12pF CH
C129 166-1201-50 12pF CH
C130 166-1201-50 12pF CH
C131 042-0592-58 16V10μF
C132 166-1201-50 12pF CH
C133 168-1032-55 0.01μF
C134 166-1011-50 100pF CH
C135 166-1011-50 100pF CH
C136 168-1045-56 0.1μF
C137 042-0592-66 35V 4.7μF
C138 168-2212-55 220pF
C139 042-0592-66 35V 4.7μF
C140 042-0592-59 16V22μF
C141 168-6835-56 0.068μF
C142 042-0592-66 35V 4.7μF
C143 168-6822-55 6800pF
C144 168-1022-55 1000pF
C145 042-0592-58 16V10μF
C146 042-0592-59 16V22μF
C147 168-1045-56 0.1μF
C148 042-0592-66 35V 4.7μF
C149 168-2212-55 220pF
C150 042-0592-66 35V 4.7μF
C151 042-0592-59 16V22μF
C152 168-6835-56 0.068μF
C153 168-6822-55 6800pF
C154 042-0592-66 35V 4.7μF
C155 168-1022-55 1000pF
C156 042-0592-58 16V10μF
C157 042-0592-58 16V10μF
C158 168-1032-55 0.01μF
C159 042-0592-74 50V 2.2μF
C160 168-3312-55 330pF
C161 042-0592-74 50V 2.2μF
C162 168-3312-55 330pF
C163 168-2212-55 220pF
C164 168-2212-55 220pF
C166 042-0592-58 16V10μF
C167 168-1032-55 0.01μF
C169 166-2201-50 22pF CH
C173 166-2201-50 22pF CH
C174 168-1032-55 0.01μF
C176 042-0592-58 16V10μF
C178 166-2201-50 22pF CH
C179 166-2201-50 22pF CH
C180 166-2201-50 22pF CH
C181 166-2201-50 22pF CH
C186 168-1032-55 0.01μF
C187 042-0592-58 16V10μF
C188 168-1032-55 0.01μF
C189 042-0592-66 35V 4.7μF
C190 042-0592-66 35V 4.7μF
C191 042-0592-66 35V 4.7μF
C192 042-0592-66 35V 4.7μF
C193 042-0592-58 16V10μF
C194 042-0592-58 16V10μF
C195 042-0592-58 16V10μF
C196 042-0592-58 16V10μF
C197 042-0592-50 6.3V22μF
C198 042-0592-50 6.3V22μF
C199 042-0592-58 16V10μF
C200 042-0592-58 16V10μF
C201 166-2201-50 22pF CH
C202 166-2201-50 22pF CH
C203 042-0592-50 6.3V22μF
C204 042-0592-50 6.3V22μF
C207 042-0592-58 16V10μF
C208 168-1032-55 0.01μF
C209 042-0595-84 10V100μF
C210 178-1052-78 1μF
C220 163-4753-55 35V4.7μF
C221 168-1045-56 0.1μF
C222 168-1045-56 0.1μF
C223 042-0592-61 16V47μF
C224 042-0595-84 10V100μF
C225 042-0595-84 10V100μF
C226 168-1522-55 1500pF
C227 168-1522-55 1500pF
C247 166-2201-50 22pF CH
C248 166-2201-50 22pF CH
C249 166-2201-50 22pF CH
C250 166-2201-50 22pF CH
C251 042-0592-58 16V10μF
C252 042-0592-61 16V47μF
C253 042-0592-58 16V10μF
C254 042-0592-58 16V10μF
C255 042-0592-61 16V47μF
C256 042-0592-58 16V10μF
C257 042-0595-84 10V100μF
C258 042-0595-84 10V100μF
C259 042-0595-84 10V100μF
C260 042-0595-84 10V100μF
C261 168-1522-55 1500pF
C262 168-1522-55 1500pF
C263 168-1522-55 1500pF
C264 168-1522-55 1500pF
C265 163-2273-25 10V 220μF
C266 042-0592-50 6.3V22μF
C267 042-0592-50 6.3V22μF
C268 042-0592-50 6.3V22μF
C269 042-0592-50 6.3V22μF
C270 168-4735-56 0.047μF
C271 042-0592-58 16V10μF
C272 042-0592-58 16V10μF
C273 042-0592-58 16V10μF
C274 042-0592-58 16V10μF
C275 042-0592-58 16V10μF
C276 042-0592-58 16V10μF
C277 042-0592-58 16V10μF
C278 042-0592-58 16V10μF
C279 043-0296-50 0.1μF
C280 043-0296-50 0.1μF
C281 043-0296-50 0.1μF
C282 043-0296-50 0.1μF
C285 042-0592-61 16V47μF
C286 178-4742-78 0.47μF
C289 163-4753-55 35V4.7μF
C290 163-1063-35 16V10μF
C301 168-1022-55 1000pF
C303 166-2401-50 24pF CH
C304 166-2701-50 27pF CH
C305 042-0595-65 16V47μF
C306 168-1032-55 0.01μF
C307 042-0559-00 5.5V0.1μF
C308 168-1045-56 0.1μF
C309 168-1032-55 0.01μF
C310 168-1032-55 0.01μF
C311 168-1022-55 1000pF
C312 168-2245-79 0.22μF
C313 168-4735-56 0.047μF
C314 168-1022-55 1000pF
C315 163-1063-35 16V10μF
C316 163-1063-35 16V10μF
C317 168-1022-55 1000pF
C318 168-1032-55 0.01μF
