Ownerʼsmanual&Installationmanual
7”WATERPROOFWIDESCREENDIGITALQUADCOLORMONITOR

2
CONTENTS
１．SAFETYINSTRUCTIONS
２．BEFOREUSE
３．FEATURES
４．CONTENTS
５．BUTTONFUNCTIONS
６．FUNCTIONS
[1]POWERON/STAND-BY
[2]VOLUMECONTROL
[3]SCREENSWITCH
[4]SELECTSPLITMODE
[5]CAMERASELECTION
[6]CAMERAMIRROR/NORMALMODESETTING
[7]ONSCREENDISTANCEMARKERSETTING
[8]SCREENSWITCHINGUSINGTRIGGERINPUTS
７．SETTINGS
[1]VIDEOSTANDARDSYSTEM,NTSC/PALSELECTION
[2]DIMMERSENSORSETTING
[3]PICTURESETUP
[4]LANGUAGESETTING
[5]INITIALIZATION
８．INSTALLATION
９．CONNECTIONS
１０．TROUBLESHOOTING
１１．SPECIFICATIONS
.......................................................................................................3~4
.....................................................................................................................................5
.........................................................................................................................................6
........................................................................................................................................6
...................................................................................................................7
............................................................................................................................8~15
.........................................................................................................8
.................................................................................................................8
......................................................................................................................8
...............................................................................................................9
.....................................................................................................9~10
............................................................11
.........................................................12~13
..................................................13~15
..............................................................................................................................16~17
.................................................16
................................................................................................16
.......................................................................................................................16
............................................................................................................17
......................................................................................................................17
.............................................................................................................................18
..............................................................................................................................19
...............................................................................................................20
.......................................................................................................................20
Thisunithasbeentestedandfoundtocomplywith
thelimitsforaClassBdigitaldevice,pursuanttoPart
15oftheFCCRules.
Theselimitsaredesignedtoprovidereasonablepro-
tectionagainst harmfulinterference ina residential
installation.
Thisunitgenerates,uses,andcanradiateradiofre-
quencyenergy,and,ifnotinstalledandusedinac-
cordance with the instructions, may cause harmful
interferencetoradiocommunications.
However,thereisnoguaranteethatinterferencewill
notoccurinaparticularinstallation.
Ifthisunitdoescauseharmfulinterferencetoradio
ortelevisionreception,whichcanbedeterminedby
turningtheequipmentoffandon,theuserisencour-
agedtoconsultthedealeroranexperiencedradio/
TVtechnicianforhelp.
■INFORMATIONFORUSERS:
CHANGESORMODIFICATIONSTOTHIS
PRODUCTNOTAPPROVEDBYTHE
MANUFACTURERWILLVOIDTHE
WARRANTYANDWILLVIOLATEFCC
APPROVAL.
■Declarationofconformity
WeClariondeclaresthattheproductCJ-7500is
followingtheprovisionofDirective2004/108/EC
andDirective2011/65/EUwiththeessentialre-
quirementsandtheotherrelevantregulations.
ClarionEuropeSAS
Z.I.duPréàVarois-RoutedePompey,54670
Custines,France
telephone:+33(0)383494400
facsimile:+33(0)383494599

3
WARNING
Itmaycausemalfunctionofairbagorinjuryintheeventofanaccidentdeploying
theairbag.
●Donotinstallthemonitorineffectiverangeofairbags.
Itmaycausefire.Discontinueuseandcontactplaceofpurchase.
●Donotuseifsmokeisseenorunitemitsburningsmell.
WARNING This information is for preventing bodily harm or even death and user should follow
these safety rules.
SAFETY INSTRUCTIONS
1.
Please read the “Safety Rules” carefully before using this product. Following the safety rules prevents
users from damages related with the misuse of the product. It is very important to follow these safety
rules. We state “Caution” and “Warning” to clarify any potential risk of damage associated with the mis-
use of the product.
This information is for preventing damage or shortening the life time of the prod-
ucts.
Itmaycausemalfunctionorinjuryandmayvoidwarranty.
Makeinquiriestoplaceofpurchaseforrepairandcheckup.
●Donotdisassemble,repairormodify.
●Donotreversevehiclewhilerelyingonlyonthemonitorimage.
●Driveslowlywhenreversing.
ATTENTION
CAUTION
This information is for user’s reference for better usability.

4
CAUTION
Preventselectricshockorshortcircuit.
●Disconnectbatterybeforeinstallation.Re-connectonceinstallationis
complete.
Itmaycausebatterytogoflat.
●Donotuseforlongperiodswithoutenginerunning.
Itmaycauseunexpectedoverheating,fireandmalfunction.
●Donotusemultisocketorextendedadaptor.
Itmaycausefirebyshortcircuitduetooverheating.
●Unplugproductwhennotinuseforalongtime.
Itmaycausemalfunctionorpicturedistortion.
●Donotplacenearmagnet.
●Therear-viewmonitorimagehasthesameright-leftinversionasyour
vehicleʼsrearviewmirrors.Dependingonthevehicle,thefieldand
angleofviewmaydiffer.

5
BEFORE USE
２.
Precautions (when you use the monitor)
●Usetheproductatthetemperaturerangeof-10℃~60℃.
●Screenmaybealittledarkwhentheproductisoperatedinlowtemperatureareas.Screenwillshow
normalluminosityafterafewminutes.
●Donotdisassembleandmodifytheproductinanyway.Thismaycausefireand/orelectricshock.
●Whenyouinstalltheproductinavehicleandwatchthemonitor,thecarengineshouldberunning
toavoidflatteningthebattery.
Precautions (when you use the product in a vehicle)
●Thedrivershouldnotusetheproductwhilehe/sheisdriving.
●Becautiousofshockwhenyouusetheproductinavehicle.
●Covertheproductwhenexposedtodirectraysofthesunforalongperiodoftime.(Youshouldkeep
theproductatatemperaturerangeof-20℃~70℃.)

6
FEATURES
３.
・7”WVGA(800x480)LCDpanel
・Waterresistant(IP67),Aluminumhousing
・8languagedisplayselection(English-French-German-Italian-Spanish-Swedish-Chinese-Japanese)
・DC12〜24V
・Max.4camerainput
・Camerainputscreeninversion(Normal/Mirrormode)
・Usercanchoosesplitscreen(2/3/4Splitscreen)
・Dimmersensorisbuilt-in
CONTENTS
４.
* When opening the gift box, please check the contents listed below. If you find parts are missing,
please contact place of purchase.
・SunVisor(1)
・Screw(4)
・Adhesivetape(1)Monitor(1)
Manual(1)
・U-Bracket(1)
・Screw(4)Monitorcable(1)

7
BUTTON FUNCTIONS
５.
[Monitor]
1. DIMMER SENSOR
2. DIM
3. MODE
4.
5. MENU
6. POWER
Automatic brightness control sensor
DIMMER
Switch Screen / Select SUB-MENU
DOWN/UP/LEFT/RIGHT
Switch Main Menu
Power ON/Stand-by
②①③ ④ ⑤⑥

8
FUNCTIONS
６.
CAM1 CAM4
CAM3CAM2
VOLUME 30
Full Screen
3 split screen4 split screen
2 split screen
Press [ ] button to control volume(0~100).
Volume control works only in CAM1 screen.
* Factory default Volume setting is 30.
POWER ON/OFF
1
Press [ ] button then the picture from the cameras will be shown
on the monitor.
Press [ ] button again to switch off.
* If there is no camera video input, the screen will remain Black.
* Factory default setting shows 4 way split screen.
SCREEN SWITCH
3
VOLUME CONTROL
2
Press [MODE] button on monitor, then the screen switches in the following order.

9
CAM 4
CAM 2
CAM 3
CAM 1
2 split screen
2 split screen
4 split screen
4 split screen
3 split screen
3 split screen
SELECT SPLIT MODE
4
Each split screen has two options. In split mode, press [ ] button then the screen switches between both
options.
CAMERA SELECTION
5
In full screen mode, press [ ] button then the screen switches in the following order.
1) FULL SCREEN MODE
Press [MENU] button, then it displays screen information (Input mode / Volume).

10
Press [MENU] button to go to「SPLIT SCREEN SETUP」.
Press [MENU] button to go to「TRIPLE SCREEN SETUP」.
Repeat these steps to set each camera’s position.
Press [MENU] button to go to「QUAD SCREEN SETUP」.
2) 2 SPLIT SCREEN MODE
CAM2
SPLIT SCREEN SETUP
SET LEFT
SET RIGHT
SELECT INPUT
CAM 1
CAM 2
CAM 3
CAM 4
3) TRIPLE SPLIT SCREEN MODE
TRIPLE SPLIT SETUP
SET LEFT
SET TOP
SET BOTTOM
SELECT INPUT
CAM 1
CAM 2
CAM 3
CAM 4
CAM2
CAM2
4) QUAD SCREEN MODE
QUAD SPLIT SETUP
SET TOP LEFT
SET TOP RIGHT
SET BOTTOM LEFT
SET BOTTOM RIGHT
SELECT INPUT
CAM 1
CAM 2
CAM 3
CAM 4
Please select the camera position (left
or right) by using [ ] button.
Please select the camera position (left
or right) by using [ ] button.
Please select the camera position
(Upper left, Upper right, Lower left,
Lower right) by using [ ] button.
Then press [ ] button to go to
「SELECT INPUT」. Please select the
camera by using [ ] button.
Then press [ ] button to go to
「SELECT INPUT」. Please select the
camera by using [ ] button.
Then press [ ] button to go to
「SELECT INPUT」. Please select the
camera by using [ ] button.
Then press [ ] button to save
your selection.
Then press [ ] button to save
your selection.
Then press [ ] button to save
your selection.

11
CAMERA MIRROR/NORMAL MODE SETTING
6
1) CAM1 full screen
MARKER SETUP
ON
OFF
CAM1
Press [MENU] button.
Press [MENU] button.
Press [MENU] button.
Press [MENU] button.
Press [MENU] button.
Press [MENU] button.
Press [MENU] button.
MIRROR SET
CAM1 MIRROR
CAM2 MIRROR
CAM3 NORMAL
CAM4 MIRROR
Select camera with [ ] button
and then press [ ] button to select
Normal / Mirror view.
2) CAM2 or CAM3 full screen
CAM2 TRIGGER SETUP
FULL SCREEN
SPLIT SCREEN
CAM2 MIRROR SET
CAM1 MIRROR
CAM2 MIRROR
CAM3 NORMAL
CAM4 MIRROR
3) CAM4 full screen
CAM4
4) Split screen (2/3/4)
CAM1 CAM2 SPLIT SCREEN SETUP
SET LEFT
SET RIGHT
MIRROR SET
CAM1 MIRROR
CAM2 MIRROR
CAM3 NORMAL
CAM4 MIRROR
MIRROR SET
CAM1 MIRROR
CAM2 MIRROR
CAM3 NORMAL
CAM4 MIRROR
Select camera with [ ] button
and then press [ ] button to select
Normal / Mirror view.
Select camera with [ ] button
and then press [ ] button to select
Normal / Mirror view.
Select camera with [ ] button
and then press [ ] button to select
Normal / Mirror view.

12
MarkerNo.
(Pattern)
CameraInstall
Height
Vehicle
Width
Ｐ１
Ｐ２
Ｐ３
Ｐ４
Ｐ５
Ｐ６
Ｐ７
２，０００
２，２５０
２，５００
２，７５０
３，０００
３，２５０
３，５００
２，５００
２，３００
２，５００
- Press [MENU] button four times, and select MARKER SETUP menu.
- Press [ ] button, and switch marker pattern.
* Distance marker function setting is only possible when MARKER SETUP ON is selected on CAM1, full
screen mode.
ON SCREEN DISTANCE MARKER SETTING
7
MARKER SETUP
ON
OFF
CAM1
In CAM1 full screen,
press [MENU] button.
Select ON/OFF with [ ] button
and then press [ ] button.
• The onscreen distance markers should be considered as a general reference to assist the driver in assessing
the distances depicted on the screen. The distance markers have been designed based on the “CCD camera
installation conditions”listed in the next section, but differences in vehicle design and construction may result
in the actual installation condition or location being different from the conditions listed. In such cases, the
display location should be set at the closest marker No.
• Distance markers cannot be set if non Clarion cameras are used.
Warning
• The markers may not indicate the exact position of the bumper, the vehicle’s width or the distance to the rear.
Use as a reference only.
Caution
MARKER
SELECT
Ｐ１
7m
5m
3m
1m
Bumper position
(Frombumpertowardrear)
Vehiclewidth
(Unit：mm)
■CCDcamerainstallationconditions
(distancemarkerinputconditions)
1) MARKER SELECTION

13
CAM1 CAM2 CAM3
Automatic Screen switching using Trigger inputs
8
<Trigger input> or <Trigger signal> is when camera priority is selected by a signal, for example if driver uses
right/left turn signal or reverse gear, the monitor shows connected camera in driving mode.
* Below example is set with TRG1(Reverse gear)=CAM1 / TRG2(Left turn signal)=CAM2 / TRG3(Right turn
signal)=CAM3.
1) If there is a trigger signal input, the connected camera is displayed as full screen and switches back when the
signal switches off.
2) MARKER ADJUSTMENT (Adjusting the bumper position)
- Press [MENU] button five times, and select MARKER ADJUST menu.
- Press [ ] button, and select H / V. (H: horizontal / V: vertical )
- Press [ ] button, and switch marker pattern.
(H = -12 ~ +12, V = -12 ~ +12, Default setting: H = 0, V = 0)
- After 10 seconds, set up screen disappears, and set up finishes.
* If there is no button operation, set up screen disappears even during set up process.

14
[ ] button
[ ] button
3) When there is the TRG1(Reverse gear) input, CAM1 video will be shown on the screen. Using [ ] button,
the 2 split screen of CAM2/CAM1 or CAM1/CAM3 can be displayed.
In CAM2 full screen, press [MENU] button to see OSD. Select split screen with [ ] button and then press
[ ] button. If there is left signal input(TRG2), then CAM2(Left) in left side and CAM1(Rear) in right side will be
shown on the screen.
2) In case of TRG2 (Left turn signal) or TRG3 (Right turn signal), you can choose full screen or split screen by OSD
setting.
* This function is for showing not only Left(Right) but also rear view together at the same time, regardless of
former screen status. It displays CAM2(3) and CAM1 as split screen when TRG2(3) signal input is on.
CAM2
CAM2 TRIGGER SETUP
FULL SCREEN
SPLIT SCREEN
CAM2 CAM1
CAM1
CAM3 TRIGGER SETUP
FULL SCREEN
SPLIT SCREEN
CAM3 CAM3
In CAM3 full screen, press [MENU] button to see OSD. Select split screen with [ ] button and then press
[ ] button. If there is right signal input(TRG3), then CAM1(Rear) in left side and CAM3(Right) in right side will
be shown on the screen.
CAM1
CAM2 CAM1
CAM1 CAM3

15
CAM1 CAM4
CAM2 CAM3
CAM1 CAM2
4) In case of a hazard flasher trigger(TRG2+TRG3), the monitor displays CAM1~CAM4 as quad split screen. The
screen switches back when the hazard flasher trigger is switched off.
The example is set with TRG1(Reverse gear)=CAM1 / TRG2(Left turn signal)=CAM2 /
TRG3(Right turn signal)=CAM3
CAM1 CAM4 CAM3
CAM1
Screen in use TRG1 signal removed
* During the time that trigger is activated, [ ] buttons don’t work.
* In standby status if the trigger wire is activated the monitor will turn on. The screen will turn off once the
power is de-activated to the trigger wire. And the screens turns off when the trigger signal switches off.
Input TRG1 and TRG3
(trigger 1 has priority)
5) When more than two trigger signals are received at once, the monitor will display the highest priority trigger.
As triggers are removed, screen will show next highest priority trigger (see priority order below).
TRIGGER PRIORITY ORDER
TRG1(Reverse gear) > TRG2+3(Hazard flasher) > TRG2(Left turn signal) > TRG3(Right turn
signal)
NOTICE
NOTICE

DIMMER AUTO
CONTRAST 50
BRIGHTNESS 50
COLOR 50
TINT 50
LANGUAGE ENGLISH
VIDEOSYSTEMNTSC
RESET ▶
PICTURESETUP
DIMMER AUTO
CONTRAST 50
BRIGHTNESS 50
COLOR 50
TINT 50
LANGUAGE ENGLISH
VIDEOSYSTEMNTSC
RESET ▶
PICTURESETUP
DIMMER AUTO
CONTRAST 50
BRIGHTNESS 50
COLOR 50
TINT 50
LANGUAGE ENGLISH
VIDEOSYSTEMNTSC
RESET ▶
PICTURESETUP
16
DIMMER SENSOR SETTING
2
SETTINGS
７.
VIDEO STANDARD SYSTEM NTSC/PAL SELECTION
1
Press [DIM] button to switch DAY -» NIGHT -» AUTO -» DAY.
* Factory default setting is AUTO.
PICTURE SETUP
3
* Factory default setting value is 50.
1) Press [MENU] button until OSD menu [PICTURE SETUP]
appears.
2) Press [ ] button to move a to VIDEO SYSTEM and
choose video system by pressing [ ] button.
1) Press [MENU] button until OSD menu [PICTURE SETUP]
appears.
2) Press [ ] button to move to each menu and choose
proper value by pressing [ ] button.
1) Press [MENU] button until OSD menu [PICTURE SETUP]
appears.
2) Press [ ] button to move to DIMMER and
choose proper value, DAY(brighter)/ NIGHT(Darker)/
AUTO(Sensor) by pressing [ ] button.
Please select NTSC for video system as Clarion cameras are compatible with NTSC
video system.
NOTICE

DIMMER AUTO
CONTRAST 50
BRIGHTNESS 50
COLOR 50
TINT 50
LANGUAGE ENGLISH
VIDEOSYSTEMNTSC
RESET ▶
PICTURESETUP
DIMMER AUTO
CONTRAST 50
BRIGHTNESS 50
COLOR 50
TINT 50
LANGUAGE ENGLISH
VIDEOSYSTEMNTSC
RESET ▶
PICTURESETUP
17
LANGUAGE SETTING
4
* Factory default setting is English (8 languages available).
* Returns the Monitor to factory default settings except for video input (NTSC or PAL).
1) Press [MENU] button until OSD menu [PICTURE SETUP]
appears.
2) Press [ ] button to move to language and choose
proper value by pressing [ ] button.
1) Press [MENU] button until OSD menu [PICTURE SETUP]
appears.
2) Press [ ] button to move to RESET and then press
[ ] button.
INITIALIZATION
5

18
INSTALLATION
８.
3. Sun Visor should be installed with 4 screws.
1. Please ensure that the monitor is installed with
enough room for heat to dissipate. Install the
monitor stand with enclosed screws and double
side adhesive tape as per the picture.
2. Fix the monitor to the monitor stand firmly.
Standard Installation
Ceiling Installation
Double side
adhesive tape
Screw hole
Double side adhesive tape
INSTALLATION (U-Bracket)

ORANGE
(CAM1)
BLACK
(CAM3)
GREEN
(CAM2)
BLACK
GROUND
RED
ACCESSORY(ACC)
DC12V/24V
CAM3CAM2CAM1 CAM4
*１
*１
*１
*１
*２
*２
*２
*２
Cameraconnectingcable
*１UseClarionCamerasonly.
*２Acameraconnectingcable,soldseparately,
isrequiredforconnectingthecamera.
MONITOR CABLE
* Make sure that the connector cable with
the correct pin conguration is used.
19
CONNECTIONS
9.
■Pleaseensurethatthecorrecttriggerwiresareconnectedtothecorrespondingcameras.
ORANGE(CAM1,priority)
GREEN,BLACK(CAM2,CAM3)
Standby+(forrear-view)
*Connectthiscabletothe“+”sideoftheReversegearglobe.
Standby+(forside-view)
*ConnectGreencabletothe“+”sideoftheLeftturnsignalglobe
-ConnectBlackcabletothe“+”sideoftheRightturnsignalglobe.

20
Problem
Check the wiring to the camera and the camera
connection.
Checkthewiring.
Replacewithafuseofthesameamperage(5A)
Temperatureinthevehicleisbelow-10°Corover
60°C.Checktoseethatthetemperatureintheve-
hicleisappropriate(around25°C).
Noimageisdisplayed.
Powerdoesnotturnon.
Coloriswashed-out.
Cause
Iscameraconnected
properly?
Ispowercableconnected
properly?
Isafuseblownout?
Operatingenvironmentis
inappropriate.
Measure
SPECIFICATIONS
11.
* The design and specication are subject to change without notice.
TROUBLESHOOTING
10.
LCDpanel
Screensize
Resolution
Brightness
7inch
800(W)x3(RGB)x480(H)
400cd/m2
Contrastratio 500:1
Voltage
Current
Powersupply DC12V~24V(10.8V~31.2V)
Approx.900mA(DC12V,incaseofconnectingfoursetsofcamera(CC-2000)).)
Speaker
Languagedisplayselection
Operatingtemperature
Storagetemperature
Dimension(WxDxH)
0.5Wattmax.
8Language
-10℃~+60℃/-14℉~+140℉
-20℃~+70℃/-4℉~+158℉
190x141x29mm/7.48x5.55x1.14inch
Weight 879g/31oz（monitoronly）
