Clarity SBS-400 User manual

SBS-400
Issue 4
[phone]
SBS-400
DYNAMIC DESK PAGING MICROPHONE
INTRODUCTION
These instructions contain the specifications and
information necessary to install, operate, and maintain
the SBS-400, Dynamic Desk Paging Microphone.
SPECIFICATIONS
Applications
•Clarity Paging Systems
Features
•Dynamic element
•Omni-directional pickup pattern
•Cycolac housing with die cast base
•Push-to-Talk push bar with lock
•Heavy duty four-conductor shielded cable
Dimensions
•9.375" H x 4.375"W x 5.875"D
(23.8cm H x 11.1cm W x 14.9cm D)
Specifications
Element Dynamic
Pattern Omni-directional
Frequency Response 50K to 12K Hz
Output Impedance Lo Z 400 ohms
Output Level Lo Z -58db (0db = 1 mw/
10 microbars)
INSTALLATION
Figure 1 (on reverse) depicts the SBS-400 with
appropriate connections when used with a Clarity
Mixer-Amplifier.
TECHNICAL ASSISTANCE
When trouble is reported, verify the unit is turned on
and there are no broken connections leading to this
unit.
Assistance in troubleshooting is available from the
factory. When calling, you should have a VOM
available and be calling from the job site. Call (540)
427-3505 and ask for Technical Support or call (540)
427-6000 for Clarity 24-hour Automated Support.
CLARITY equipment is not field repairable.
CLARITY maintains service facilities in Roanoke, VA.
Should repairs be necessary, attach a tag to the unit
clearly stating company name, address, phone number,
contact person, and the nature of the problem. Send the
unit to: Clarity
Repair and Return Dept.
5614 Hollins Road
Roanoke, VA 24019-5056
947415

SBS-400 Connecting Arrangement
MIC INPUT
GND
SHIELD
CLARITY MIXER-AMPLIFIER
SBS-400
RED
BLACK
LIMITED WARRANTY
Clarity warrants its products to be free from defects in materials and workmanship under conditions of normal use and service for a
period of one year from the date of shipment. The obligation under this warranty shall be limited to the replacement, repair or refund of
any such defective device within the warranty period, provided that:
1. Inspection by Clarity indicates the validity of the claim;
2. The defect is not the result of damage, misuse, or negligence after the original shipment;
3. The product has not been in any way repaired by others and that factory sealed units are unopened (A service charge plus parts
and labor will be applied to units defaced or physically damaged);
4. Freight charges for the return of products to Clarity are prepaid,
5. All units “out of warranty” are subject to a service charge. The service charge will cover minor repairs (Major repairs will be subject
to additional charges for parts and labor).
This warranty is in lieu of and excludes all other warranties, expressed or implied, and in no event shall Clarity be liable for
any anticipated profits, consequential damages, loss of time or other losses incurred by the buyer in connection with the
purchase, operation, or use of the product.
This warranty specifically excludes damage incurred in shipment. In the event a product is received in damaged condition, the carrier
should be notified immediately. Claims for such damage should be filed with the carrier involved in accordance with the F.O.B. point.
