Clarke WIZ - MINI Manual

WIZ - MINI
AIR COMPRESSOR
OPERATING & MAINTENANCE
INSTRUCTIONS
0206

CONTENTS
Safety Precautions ..................................................................... 4
Electrical Connections .............................................................. 5
Operation ................................................................................... 6
Shutting Down ............................................................................ 6
Maintenance ............................................................................. 6
Fault Finding ............................................................................... 7
Specifications ............................................................................. 7
Parts List and Diagram ......................................................... 8 - 9
Thank you for purchasing your new Clarke WIZ Mini Air Compressor, which is not
intended for general outdoor use. If it is used outdoors, it must be protected for
the elements at all times.
Before attempting to operate the compressor, please read this instruction manual
thoroughly and carefully follow all directions given. This is for your own safety and
that of others around you, and to help you achieve long and trouble free service
from your compressor.
GUARANTEE
This product is guaranteed against faults in manufacture for 12 months from pur-
chase date. Please keep your receipt as proof of purchase.
This guarantee is invalid if the product has been abused or tampered with in any
way, or not used for the purpose for which it is intended.
The reason for return must be clearly stated.
This guarantee does not affect your statutory rights
3
For Spare Parts and Service, please contact your nearest dealer,
or CLARKE International, on one of the following numbers.
PARTS & SERVICE TEL: [phone]
PARTS & SERVICE FAX: [phone]
or e-mail as follows:
PARTS: [e-mail]
SERVICE: [email protected]
PARTS & SERVICE CONTACTS

SAFETY PRECAUTIONS
1. COMPRESSED AIR IS DANGEROUS, NEVER direct a jet of air at people or
animals, and NEVER discharge compressed air against the skin.
2. Electrical or mechanical repairs should only be carried out by a qualified
engineer. If problems occur, contact your Clarke dealer.
3. Before carrying out any maintenance, ensure the compressor is disconnected
from the mains supply
4. DO NOT operate in wet or damp conditions. Keep the machine dry at all
times. Similarly, a clean atmosphere will ensure efficient operation. Do not
use in dusty or otherwise dirty locations.
5. Some of the metal parts can become quite hot during operation. Take care
not to touch these until the machine has cooled down.
6. ALWAYS ensure that there is adequate ventilation when spraying and keep
clear of any possible source of ignition.
7. Protect yourself. Think carefully about any potential hazards which may be
created by using the compressor and use the appropriate protection. e.g.
goggles will protect your eyes from flying particles. Face masks will protect
you against paint spray and/or fumes.
8. Before spraying any material always consult paint manufacturers instructions
for safety and usage.
9. Do not exert any strain on electrical cables and ensure that air hoses are not
tangled or wrapped around machinery etc.
10. Before disconnecting air hoses or other equipment from your compressor
ensure that the compressor is switched off.
11. Make sure that children and animals are kept well away from the compressor
and any equipment attached to it.
12. Always ensure that all individuals using the compressor have read and fully
understand the Operating Instructions supplied.
13. Ensure that any equipment or tool used in conjunction with your compressor,
has a safety working pressure exceeding that of the machine.
14. Always place the compressor on a level surfacer wherever possible.
15. It is not advisable to carry the compressor when spraying.
16. DO NOT allow the compressor to run unnecessarily .. .switch it OFF when the
spraying tool is not being used.. .even for a short time.
WARNING!
As with all machinery, there are certain hazards involved with their operation
and use. Exercising respect and caution will considerably lessen the risk of
personal injury. However, if normal safety precautions are overlooked, or
ignored, personal injury to the operator, or damage to property may result. It is
in your own interest to read and pay attention to the following rules:
4

ELECTRICAL CONNECTIONS
Connect the mains lead to a standard, 230 Volt (50Hz) electrical supply through
an approved 13 amp BS 1363 plug, or a suitably fused isolator switch.
WARNING! THIS APPLIANCE MUST BE EARTHED
IMPORTANT: The wires in the mains lead are coloured in accordance with the
following code:
Green & Yellow - Earth
Blue - Neutral
Brown - Live
As the colours of the flexible lead of this appliance may not correspond with the
coloured markings identifying terminals in your plug proceed as follows:
• Connect GREEN & YELLOW cord to terminal marked with a letter “E” or Earth
symbol “ ” or coloured GREEN or GREEN & YELLOW.
• Connect BROWN cord to terminal marked with a letter “L” or coloured RED.
• Connect BLUE cord to terminal marked with a letter “N” or coloured BLACK.
If this appliance is fitted with a plug which is moulded onto the electric cable
(i.e. non-rewireable) please note:
1. The plug must be thrown away if it is cut from the electric cable. There is a
danger of electric shock if it is subsequently inserted into a socket outlet.
2. Never use the plug without the fuse cover fitted.
3. Should you wish to replace a detachable fuse carrier ensure that the correct
replacement is used (as indicated by marking or colour code).
4. Replacement fuse covers can be obtained from your local dealer or most
electrical stockists
FUSE RATING
The fuse in the plug must be replaced with one of the same rating (13 amps) and
this replacement must be approved to BS1362.
We recommend that this machine is connected to the mains supply via a Residual
Current Device (RCD)
If in any doubt, DO NOT attempt any connections or repairs yourself. Consult a
qualified electrician, your Clarke dealer, or CLARKE International Service Dep’t
on
020 8988 7400 or e-mail: Service@clarkeinternational corn
5

OPERATION
NOTE: This machine is designed for use with air bushes or other devices that
require a low volume, low pressure air supply.
1. Check that the mains voltage corresponds with that shown on the data
label on the crankcase cover of the machine.
Ensure that the ON/OFF switch (see fig. 1) is in the ‘OFF’ (O) position. Attach
the air hose to the outlet on the handle, using either the 1/8"BSP thread, the
1/8" BSP adapter. Attach the air tool.
3. To start the compressor, plug in and switch on at the mains supply then switch
the motor switch to the ‘ON’ (I) position - the motor should start immediately.
If it does not.. .refer to ‘Fault Finding’ on p.7.
SHUTTING DOWN THE COMPRESSOR
1. To shut off the compressor, simply switch the ON/OFF switch to the OFF (O)
position. Always use this switch to shut down the compressor. NEVER USE THE
MAINS SWITCH TO STOP MOTOR.
2. Trigger the equipment (spray gun, air tool etc.) to release air from the air
hose before disconnecting the hose from the machine.
WARNING!
NEVER UNSCREW A CONNECTION WHILST THE AIR LINE IS UNDER PRESSURE.
ALWAYS MAKE CERTAIN THAT THE AIR TOOL HAS BEEN TRIGGERED
MAINTENANCE
1. After the first 5 hours of running the compressor, check the cylinder head
screws and retighten - equally to 10 lbs ft. if any have worked loose.
2. Every 50 hours (more frequently if
used in a dusty environment), clean
the air intake filter, by unscrewing
the two screws securing the plastic
end cover prising off the cover then
removing the two screws securing
the air filter.
The filter may be gently washed in
warm soapy water rinsed and
allowed to dry thoroughly before
refitting. It should be renewed if
badly soiled or contaminated with
paint, and if it has been washed
two or three times.
6

FAULT FINDING
Air Valve Plate (item
33) or Air Valve (item
38) damaged.
Diaphragm (item 31)
damaged
Cyl Head screws loose
(item 42)
Air hose leaking
Cyl Head Screws too
tight.
Bearing Fault
Cyl Head Screws too
tight.
Armature faulty
Armature faulty
Thermal cut-out has
operated
Renew defective Air Valve
Plate or Air Valve.
Renew Diaphragm
Tighten screws to 10 lbf ft
Check seal or renew Air
Hose
Back off all screws and
tighten equally.. .to 10 lbf ft
Consult your Clarke dealer
Back off all screws and
tighten equally.. .to 10 lbf ft
Consult your Clarke dealer
Consult your Clarke dealer
Switch OFF and
disconnect. Wait for 15-20
mins and try again.
Low air flow
Noisy operation
Compressor
hums but does
not work.
Compressor
does not work.
PROBLEM PROBABLE CAUSE REMEDY
SPECIFICATIONS
Motor ............................................................... 230V 50Hz 1 Ph
Power Rating .................................................. 1/8HP
Rotational Speed ........................................... 1500RPM
Max Pressure ................................................... 40psi
Air Displacement ............................................ 1.58 cuft/min
Fuse Rating ...................................................... 13amps
Cyl. Head Bolt torque setting ....................... 10 lbf ft
Weight ............................................................. 4.3kg
7

PARTS DIAGRAM
8

No. Description Part No. No. Description Part No.
1 Housing KLWIZ01 33 Air Valve KLWIZ33
2 Gasket KLWIZ02 34 Screw KLWIZ34
3 Armature KLWIZ03 35 Screw KLWIZ35
4 Front Body Cover KLWIZ04 36 Screw KLWIZ36
5 Bearing KLWIZ05 37 Air Valve Plate KLWIZ37
6 Air tank KLWIZ06 38 Air Valve KLWIZ38
7 Washer KLWIZ07 39 Spring KLWIZ39
8 Screw KLWIZ08 40 Air outlet KLWIZ40
9 Nut KLWIZ09 41 Washer KLWIZ41
10 Air Filter Cap KLWIZ10 42 Screw KLWIZ42
11 Air Filter KLWIZ11 43 Handle KLWIZ43
12 End Cover KLWIZ12 44 Outlet Connector KLWIZ44
13 Screw KLWIZ13 45 Washer KLWIZ45
14 Screw KLWIZ14 46 Nut KLWIZ46
15 Washer KLWIZ15 47 Bearing KLWIZ47
16 Screw KLWIZ16 48 Rear Body Cover KLWIZ48
17 Plate w/Con-Rod KLWIZ17 49 Washer KLWIZ49
18 Washer KLWIZ18 50 Screw KLWIZ50
19 Nut KLWIZ19 51 Fan KLWIZ51
20 Bearing KLWIZ20 52 Fan Housing KLWIZ52
21 Screw KLWIZ21 53 Screw KLWIZ53
22 Eccentric Bushing KLWIZ22 54 Washer KLWIZ54
23 Nut KLWIZ23 55 Screw KLWIZ55
24 Washer KLWIZ24 56 Washer KLWIZ56
25 Washer KLWIZ25 57 Nut KLWIZ57
26 Set Plate KLWIZ26 58 Switch Assembly KLWIZ58
27 Washer KLWIZ27 59 Base KLWIZ59
28 Screw KLWIZ28 60 Mounting Pad KLWIZ60
29 Washer KLWIZ29 61 Screw KLWIZ61
30 Screw KLWIZ30 62 Air Brush Adapter KLWIZ62
31 Diaphragm KLWIZ31 63 1/8 BSP Adapt. KLWIZ63
32 Set Plate KLWIZ32
PARTS LIST
9
