Clarke CDS2 Manual

DRILL STAND
Model No. CDS2
Thank you for purchasing this CLARKE Drill Stand
Please read this leaflet to ensure the Stand is assembled correctly in
order that it will provide you with long and satisfacyory service.
GUARANTEE
This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt as proof of
purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product
can be returned without prior permission.
This guarantee does not effect your statutory rights.

Fig.1
Insert the Column into the base and secure
with the two screws using a hex wrench (not
supplied)
Slide the head on to the column and secure
to the column at any convenient position.
IMPORTANT!
Secure the base to a workbench or sturdy
table using M8 bolts (not supplied). Drill the
workbench/table accordingly, using the
two mounting holes as templates.
ASSEMBLY
1
2
3

Fig.2
• An electric drill with a standard 43mm
neck may be secured to the head using
the locking Lever shown in Fig.2.
A 38mm reducing collar, is provided
(shown in Fig.1), allowing a drill with a
38mm collar also to be accommodated.
• The head/drill may be positioned at any
height on the column, by use of the
Head Locking Lever, shown in Fig.2.
Screw IN to secure, screw OUT to release.
• The depth of travel of the drill may be
adjusted using the adjuster shown in
Fig.2. Turn to adjust. A scale with pointer
is also provided so that accurate depths
may be set
A quick release is provided. Press the
button IN and raise or lower the adjuster
as required. Release the button to lock.
A pointer with scale is provided so that
accurate depths may be drilled.
• A quick release is also provided for the
vice jaw adjustment. Press the red
button whilst pushing IN or pulling OUT
the handle.
• Secure the vice to the base using the
two bolts provided.
To position the vice further away from the column, slacken the two securing bolts (do
not undo completely) and manouvre the vice so that the bolts (with nuts attached)
may be withdrawn through the large holes at the end of the slots in the base.
Reposition the vice so that the bolts with nuts enter the holes at the opposite ends of
the slots in the base, and position as required.
Finally, tighten the securing bolts.
