Clarke CPPRSS User manual

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
MODEL NO: CPPRSS
PART NO:
PART NO: 6499630
CHEMICAL PLUNGER PUMP
INTRODUCTION
Thank you for purchasing this CLARKE chemical plunger pump,
Suitable for water, alcohol, petroleum, diesel, paraffin, lubricant, water-based chemicals, acid and alkaline solutions.
Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully.
LIST OF CONTENTS
ASSEMBLY
•1xPump •1xOutlettube
• 1 x Handle assembly • 1 x Extension Inlet tube
• 2 x Nuts and Bolts • 1 x 2 piece telescopic extension with filter
FITTING THE OUTLET TUBE
1. Remove the nut from the pump as shown. 2. Place the nut over the outlet tube and back
onto the pump
FITTING THE HANDLE ASSEMBLY FITTING THE TELESCOPIC EXTENSION TUBE
1. Connect the handle as shown and secure at
each point using the small nuts and bolts.
1. Fit the telescopic extension with filter together
as shown

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
FITTING THE PUMP TO A BARREL
1. Fit the telescopic extension with filter to the pump.
• You can fit the extension inlet tube in between if
required.
2. Adjust the telescopic extension tube to the required length.
• The bottom of the telescopic extension should be just off
of the bottom of the barrel when fitted.
3. Screw the pump into the threaded opening of the barrel.
USING THE PUMP
1. Place a suitable container under the outlet tube.
2. Pump the handle to draw fluid from the barrel.
• The first time you use the pump, you may need to pump
the handle a few times to prime the pump.
• Each ‘pump’ of the handle will draw approximately 0.3L
of fluid.
SPECIFICATIONS
GUARANTEE
This product is guaranteed against faulty manufacture for a period of 12 months from the date of
purchase. Please keep your receipt which will be required as proof of purchase.
This guarantee is invalid if the product is found to have been abused or tampered with in any way, or not
used for the purpose for which it was intended.
Faulty goods should be returned to their place of purchase, no product can be returned to us without prior
permission.
This guarantee does not effect your statutory rights.
Container Adaptor Size 2" BSP
Max Flow 0.3 litres per stroke
Inlet Tube Length 300 mm
Inlet Tube Diameter 21.5mm
Outlet Tube Diameter 16.7mm
Maximum Drum Size 205 litres
Min-Max Height (with extension tube fitted) 1130 - 1400 mm
Dims (W x D x H) 485 x 90 x 1400 mm (fully extended)
Product Weight 1.2kg
