Classy Home BW19-02T User manual

Model no : BW19-02T
ASSEMBLY INSTRUCTIONS
Step 1
Attach part 1 and 2 for all four sides and lock it using hardware A, B, C, and D.
M5 ALLEN KEY
JCBC Screw M8 x 60mm
Spring Washer
Read this instruction carefully. Remove all wrapping material, staples and straps from
the carton.
See hardware and furniture part list.
For guidance. Be sure you have all wooden furniture parts on a clean and flat soft
surface, such as a carpet or rug, to prevent from being scratched. Follow the figure to
start assembling.
CAUTION :
1. Do not FULLY - TIGHTEN the nut or screw until all is ready to assemble.
2. Do not OVER - TIGHTEN the nut or screw to avoid causing damages to the thread.
3. Keep all hardware part out reach of children.
1
2
Part List Qty
No
Table Top
Table Leg
1
4
A
Description Qty
No
1
B
C
D
8
8
COMPLETE
ASSEMBLE
Flat Washer 8
A
B
C
D
1
1
2
2

Model no : BW19-56C
ASSEMBLY INSTRUCTIONS
Step 1
Step 3
Step 2
Step 1
Firstly, attach part 1 and 2 for both left and
right side as shown and lock using hardware
A, B, D, and E.
M4 ALLEN KEY
JCBC Screw M6 x 50mm
CSK Screw M4 x 32mm
Wood Dowel 8 x 30mm
Spring Washer
C
C
CC
Wood Button
F
Read this instruction carefully. Remove all wrapping material, staples and straps from
the carton.
See hardware and furniture part list.
For guidance. Be sure you have all wooden furniture parts on a clean and flat soft
surface, such as a carpet or rug, to prevent from being scratched. Follow the figure to
start assembling.
CAUTION :
1. Do not FULLY - TIGHTEN the nut or screw until all is ready to assemble.
2. Do not OVER - TIGHTEN the nut or screw to avoid causing damages to the thread.
3. Keep all hardware part out reach of children.
1
2
3
4
5
Part List Qty
No
Back Rail
4
2
3
1
5
Side Frame
Front Rail
Back Rest
Cushion Seat
1
2
1
1
1
A
Description Qty
No
1
B
C
D
E
F
12
12
4
4
4
Step 2
Attach part 2 and 3 for both left and right side
and repeat as step 1, lock it using hardware A,
B, D, and E.
Step 3
Locate part 4 in between both part 2 as shown,
and fully-tighten it with hardware A, B, and E.
Step 4
Locate part 5 on the assembled seating
frame as shown, and fully tighten it with
hardware C. Lastly, use hardware F to
cover up the holes beside part 4 as shown.
COMPLETE
ASSEMBLE
Step 5
1
2
4
2
3
2
A
B
E
D
A
B
E
D
A
B
E
4
2
