EMERGENCY LIGHTS Commercial
617
COOPER LIGHTING
COOPER LIGHTING - SURE-LITES®
CC7
Contractor’s Choice
EMERGENCY LIGHT
DESCRIPTION
The CC7 Contractor’s Choice FasTest™
High Capacity Emergency Lighting Units
are an affordable, yet attractive,
alternative to standard white two-
headed emergency lighting units. All
components snap together to facilitate
installation in 5 minutes or less. Field
versatility is not sacrificed for cost, both
lighting heads offer full horizontal and
vertical adjustability. Moreover, proper
operation of the transfer circuit and
emergency lamps can be quickly and
safely verified by using a convenient
laser pointer (sold as an accessory). In
addition, Watchguard EMS self
diagnostic system is standard
(CC7NCSD only).
The CC7 FasTest™ is ideal for
applications that demand the minimum
cost but also require maximum
flexibility, reliability and convenience in
an attractive unit. • Dual-Voltage Input 120/277
VAC, 60 Hz
• Injection-Molded, Color-
Stable, High-Impact
UL 94-5V Rated
Polycarbonate Housing and
Mounting Plate
• Designer white textured
finish
• Maintenance Free Sealed
Lead Calcium Battery or
Premium Nickel Cadmium
battery (CC7NCSD version
only)
• Housing Has (8) Locations
for Mounting of Heads;
Consult Factory (3 optional
bottom-mount and 3
optional top- mount
locations)
• Knockouts/Cutouts
Provided in Housing for
Surface Conduit
Attachment
• Watchguard EMS self
diagnostic system
(CC7NCSD only)
• Remote Photocell Test
Switch with Automatic
30-Sec. Test Upon Switch
Activation
• Line-Latching, Solid-State
Voltage Limited Charger,
Solid-State Switching, Low-
Voltage Disconnect,
Brownout Circuit,
Overload/Short Circuit
Protection, Push-Button
Test Switch/Power Indicator
Light
• UL 924, Life Safety NFPA
101, CSA Certified,
NEC/OSHA, Most State and
Local Codes
Verify proper operation of the
transfer circuit and emergency
lamps with convenient laser
pointer (sold as an accessory).
ELECTRICAL RATINGS
Model DC Voltage 1 1/2 Hours Remote Wattage*
CC7 12 60 36
CC7NCSD 12 50 26
Rated Wattage to 87 1/2% of Rated D.C. Voltage Lamp Information
Type Wattage Number
Incandescent 12W ea. 029-132
Incandescent 12W ea. 029-132
Accessories
(Order separately)
LASER=Key Chain, Red Laser Pointer
(activation tested at 50 feet)
VS1=Polycarbonate Vandal Shield
VS1WP=Polycarbonate Vandal Shield
Weather Resistant
WG3=Wire Guard
2MS=Mounting Shelf (Specify Color)
ORDERING INFORMATION *See Remote Section Pages 494-499.
Model Number
CC7
CC7NCSD
SAMPLE NUMBER: CC7208BMTDM
Options
(Add as suffix)
SQ=Square Head (12W
Standard)
MRT=MR16 Heads (12W
Standard)
A=Ammeter
V=Voltmeter
SD=Self-Diagnostics (CC7NC
Only)
TDM=Time Delay Monitor
Cord Set=CSK-120, CSK-277
SM=Side Mount Heads
TM=Top Mount Heads
BM=Bottom Mount Heads
Alternate Lamps, Head Types,
No Head, Multiple Heads(1)
Other Options(1)
Energy Data
Input Power Input Current (Max.) Power Factor T.H.D.
Model No. 120V 277V 120V 277V 120V 277V 120V 277V
Charge Mode (Fully Discharged Battery) Sealed Lead Calcium Battery
CC7 28W 28W .26A .11A >.91 >.91 <35% <39%
Standby Mode (Fully Charged Battery) Sealed Lead Calcium Battery
CC7 3.8W 3.7W .07A .03A >.50 >.50 <94% <99%
Standby Mode
CC7NCSD 7.8W 7.1W .08A .04A >.77 >.77 <53% <58%
TABLE OF CONTENTS
DIMENSIONS
7 15/16” MAX
[202mm]
13” [330mm]
5 3/4”
[146mm]
4 7/8”
[124mm]
19 1/4” MAX
[489mm]
(1)Consult your Cooper Lighting Representative.
Self-Diagnostics
The self-diagnostic unit will
automatically perform all tests
required by UL924, and NFPA
101. The system indicates the
status of the exit at all times
using the LED indicator near the
test switch on the side of the
unit. A 90 minute battery power
(emergency mode) simulation
test will occur randomly once
every six months.
