CleanMax Zoom User manual

Owner’s Manual
f o r t h e C o r d l e s s
Model ZM-800
Cordless

Congratulations!
You have purchased a vacuum cleaner that will provide efcient,
dependable service. Your CleanMax vacuum cleaner is made
using high quality materials and superior workmanship. Please
read these operating instructions carefully before you use your
vacuum.
IMPORTANT:
To activate your warranty, within 30 days of purchase, please
register your warranty online at cleanmaxvacuums.com.
Please ll out warranty information located on the Owner’s
Information Section and keep it for your records.
Key Replacement Parts
Genuine Zoom HEPA Media Vacuum Bags: CLH-6
Genuine Zoom Paper Vacuum Bags: B211-8800
Genuine Zoom Vacuum Belts: CMZM-B2

1
CONTENTS
Getting Started
Important Safety Instructions 2
Polarization Instructions 3
Description of the Vacuum 4
Assembling the Vacuum 5
Operation
Battery Charging 6
Battery Life Display 6
Reclining the Handle 6
On/Off Switch 7
Edge Cleaning 7
Automatic Carpet Height Adjustment 7
Bare Floor Cleaning 8
Vacuuming Under Furniture 8
Maintenance and Care
Replacing the Vacuum Bag 9
Removing and Reinstalling the Battery 10
Removing and Reinstalling the Bottom Plate 11
Replacing the Vacuum Belt 12
Replacing the Squeegee 13
For Best Performance 14
Warranty 15

2
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should always be followed, including
the following:
READ ALL INSTRUCTIONS BEFORE USING THIS
APPLIANCE. FOR COMMERCIAL USE ONLY.
The manufacturer cannot accept responsibility for damage
caused when the appliance is not used according to the
instructions, or for uses other than those for which it
was intended.
WARNING: To reduce the risk of fire, electric shock, damage or injury:
SAVE THESE INSTRUCTIONS.
IMPORTANT:
• Fully assemble vacuum before operating.
• Use and store in a dry location.
• Do not use outdoors or on wet surfaces.
• Do not allow to be used as a toy. Close attention
is necessary when used by or near children.
• Use only as described in this manual.
• Do not use charger with damaged cord or plug.
If appliance or charger is not working as it
should, has been dropped, damaged, left
outdoors, or dropped into water, return it to your
Authorized CleanMax Retailer for service.
• Do not pull or carry charger by cord, use cord
as a handle, close a door on the cord, or pull
cord around sharp edges or corners. Do not
run appliance over cord. Keep cord away from
heated surfaces.
• Do not unplug charger by pulling on cord. To
unplug charger, grasp the plug, not the cord.
• Do not handle charger, including charger plug,
and charger terminals with wet hands.
• Do not put any object into openings. Do not use
with any opening blocked; keep free of dust, lint,
hair and anything that may reduce air flow.
• Keep hair, loose clothing, fingers and all parts of
the body away from openings and moving parts.
• Do not pick up anything that is burning or
smoking, such as cigarettes, matches or
hot ashes.
• Do not use without vacuum bag in place.
• Use extra care when cleaning on stairs.
• Do not use to pick up flammable or combustible
liquids such as gasoline or use in areas where
they may be present.
• Do not attempt to service the unit while charger
is plugged in.
• Do not charge the unit outdoors.
• Only charge in temperatures between 0-45ºC
(32-113ºF).
• Do not open, crush, expose to heat above
100ºC (212ºF) or incinerate the battery even if it
is severely damaged. The battery can explode in
a fire.
• Use only with the Cordless Battery Vacuum
Charger supplied - P/N 10201026 Winkind.
(C223-2000)
• The battery and charger have no user
serviceable parts.
• Batteries must be disposed of responsibly.
• Remove the battery before removing the bottom
plate.

3
POLARIZATION INSTRUCTIONS
Power Cord, 2-Wire Polarized Cord
This product is equipped with a polarized alternating current line plug (a plug having one
blade wider than the other). This plug fits into the power outlet only one way. This is a
safety feature. If you are unable to insert the plug fully into the outlet, try reversing the
plug. If the plug should still fail to fit, contact an electrician to replace the obsolete outlet.
Do not defeat the safety purpose of the polarized plug.
State of California Proposition 65 Warnings:
WARNING: This product contains one or more chemicals known to the State of California to
cause cancer.
WARNING: This product contains one or more chemicals known to the State of California to
cause birth defects or other reproductive harm.

4
MATERIAL
DRAWN
ISSUED
SCALE
FINISH
DATE
DATE
DO NOT SCALE
UNLESS OTHERWISE SPECIFIED
DESCRIPTION
DRAWING SIZE:C
PART NUMBER
SHEET 1 OF 4
TACONY CORPORATION CLAIMS PROPRIETARY
RIGHTS IN THE MATERIAL DISCLOSED HERE IN.
THIS DRAWING IS ISSUED FOR ENGINEERING
INFORMATION ONLY. IT MAY NOT BE REPRO-
DUCED, NOR MAY THE INFORMATION HERE IN
BE USED FOR MANUFACTURING PURPOSES
WITHOUT WRITTEN PERMISSION FROM TACONY
CORPORATION.
0.250
TACONY CORPORATION
1760 Gilsinn Lane, Fenton, MO 63026
DESCRIPTION OF CHANGE
REV
PART NUMBER
SHEET
1 OF 4
X.X .5 mm RADII X.X .5mm
X.XX .25mm X.XX .25mm
X.XXX .12mm MACHINE SURFACE
X.XXXX .012mm BREAK SHARP CORNERS TO .25mm MAX
0 30" COMMON TO BE CONCETRIC TO .05mm
BYECN NODATEREV
DESCRIPTION OF THE VACUUM
1 Ergonomic Handle
2 On/Off Power Switch
3 Bag Compartment
4 Vacuum Nozzle
5 Headlight
6 Furniture Guard
7 Handle Release Pedal
8 Battery Pack
9 Charge Point
10 Battery Life Display
11 Battery Release Button
12 Carry Handle
13 Charger
4
3
1
2
5
6
8
9
7
13
MATERIAL
DRAWN
ISSUED
SCALE
FINISH
DATE
DATE
DO NOT SCALE
UNLESS OTHERWISE SPECIFIED
DESCRIPTION
DRAWING SIZE:C
PART NUMBER
SHEET 1 OF 1
TACONY CORPORATION CLAIMS PROPRIETARY
RIGHTS IN THE MATERIAL DISCLOSED HERE IN.
THIS DRAWING IS ISSUED FOR ENGINEERING
INFORMATION ONLY. IT MAY NOT BE REPRO-
DUCED, NOR MAY THE INFORMATION HERE IN
BE USED FOR MANUFACTURING PURPOSES
WITHOUT WRITTEN PERMISSION FROM TACONY
CORPORATION.
1.000
TACONY CORPORATION
1760 Gilsinn Lane, Fenton, MO 63026
DESCRIPTION OF CHANGE
REV
PART NUMBER
SHEET
1 OF 1
X.X .5 mm RADII X.X .5mm
X.XX .25mm X.XX .25mm
X.XXX .12mm MACHINE SURFACE
X.XXXX .012mm BREAK SHARP CORNERS TO .25mm MAX
0 30" COMMON TO BE CONCETRIC TO .05mm
BYECN NODATEREV
AS 20MAY15
SEE NOTES SEE NOTES
C223-2000
C223-2000
BATTERY CHARGER 50.4V DC
NOTES:
1. OUTPUT 50.4V DC, 1.5A
2. DC POWER CONNECTOR PLUG 2.5MM AND CABLE 47" LONG.
3 INPUT = AC 100-240V, 50/60Hz, 100VA.
4. AC CABLE 71" LONG W/ 2 PIN POLARIZED AMERICAN PLUG
5. PLUGS AND CABLES UL CERTIFIED.
6. CHARGER - UL1310 CERTIFIED
12
11
10

5
ASSEMBLING THE VACUUM
Attaching the Handle to the Vacuum
NOTE: Do not turn on the vacuum until it is
completely assembled.
The vacuum cleaner and the handle are
packed separately and require assembly.
• Remove the handle bracket by removing the
two screws (Fig. 1).
• Place handle onto the back of the vacuum,
aligning holes with pegs (Fig. 2).
• Place the handle bracket back into position
(Fig. 3).
• Secure with two screws removed in Fig. 1.
Tuck the cord into the space to the left of
the handle.
• Open the bag compartment to ensure a
vacuum bag is in place.
• Your vacuum is now ready for use.
Pre-Charged Battery
The battery is partially charged and will run for
a short time. To fully charge the battery see
Battery Charging (page 6).
Fig. 1 Fig. 2
Fig. 3

6
OPERATION
Battery Charging
• The battery is located on the back of
the vacuum. It can be charged while installed on
the vacuum, or the battery can be removed from
the vacuum and charged independently (see
Removing and Reinstalling the Battery (page 10).
• Plug the AC cable into the charger and into a
wall socket (Fig. 1).
• Plug the charger DC cable into the Charge Point
on the battery. (Fig. 2).
• The Charger LED light will be red during
charging and will turn green when the battery
pack is fully charged.
Battery Life Display
• Press the white button on the battery to illuminate
the LED lights.
• When the battery is fully charged there will be
four (4) green lights and one (1) red light showing
(Fig. 3).
• As the battery is discharged during use, the
number of green lights showing will reduce from
four (4) to none (0).
• When all of the green lights are off and only the
red light is showing, there is a small amount of
time remaining before the battery will be fully
discharged and will require recharging.
Reclining the Handle
• Press the Handle Release Pedal located on the
back of the vacuum with your foot to recline the
handle (Fig. 4).
Fig. 2
Fig. 1
Fig. 4
MATERIAL
DRAWN
ISSUED
SCALE
FINISH
DATE
DATE
DO NOT SCALE
UNLESS OTHERWISE SPECIFIED
DESCRIPTION
DRAWING SIZE:C
PART NUMBER
SHEET 3 OF 8
TACONY CORPORATION CLAIMS PROPRIETARY
RIGHTS IN THE MATERIAL DISCLOSED HERE IN.
THIS DRAWING IS ISSUED FOR ENGINEERING
INFORMATION ONLY. IT MAY NOT BE REPRO-
DUCED, NOR MAY THE INFORMATION HERE IN
BE USED FOR MANUFACTURING PURPOSES
WITHOUT WRITTEN PERMISSION FROM TACONY
CORPORATION.
0.250
TACONY CORPORATION
1760 Gilsinn Lane, Fenton, MO 63026
DESCRIPTION OF CHANGE
REV
PART NUMBER
SHEET
3 OF 8
X.X .5 mm RADII X.X .5mm
X.XX .25mm X.XX .25mm
X.XXX .12mm MACHINE SURFACE
X.XXXX .012mm BREAK SHARP CORNERS TO .25mm MAX
0 30" COMMON TO BE CONCETRIC TO .05mm
BYECN NODATEREV
Fig. 3
MATERIAL DRAWN
ISSUED
SCALE
FINISH DATE
DATE
DO NOT SCALE
UNLESS OTHERWISE SPECIFIED
DESCRIPTION
DRAWING SIZE:C
PART NUMBER
SHEET 1 OF 1
TACONY CORPORATION CLAIMS PROPRIETARY RIGHTS IN THE MATERIAL DISCLOSED HERE IN. THIS DRAWING IS ISSUED FOR ENGINEERING INFORMATION ONLY. IT MAY NOT BE REPRO- DUCED, NOR MAY THE INFORMATION HERE IN BE USED FOR MANUFACTURING PURPOSES WITHOUT WRITTEN PERMISSION FROM TACONY CORPORATION.
1.000
TACONY CORPORATION 1760 Gilsinn Lane, Fenton, MO 63026
DESCRIPTION OF CHANGE
REV
PART NUMBER
SHEET
1 OF 1
X.X .5 mm RADII X.X .5mm
X.XX .25mm X.XX .25mm
X.XXX .12mm MACHINE SURFACE X.XXXX .012mm BREAK SHARP CORNERS TO .25mm MAX
0 30" COMMON TO BE CONCETRIC TO .05mm
BYECN NODATEREV
AS 20MAY15
SEE NOTES SEE NOTES
C223-2000
C223-2000
BATTERY CHARGER 50.4V DC
NOTES: 1. OUTPUT 50.4V DC, 1.5A 2. DC POWER CONNECTOR PLUG 2.5MM AND CABLE 47" LONG. 3 INPUT = AC 100-240V, 50/60Hz, 100VA. 4. AC CABLE 71" LONG W/ 2 PIN POLARIZED AMERICAN PLUG 5. PLUGS AND CABLES UL CERTIFIED. 6. CHARGER - UL1310 CERTIFIED
MATERIAL DRAWN
ISSUED
SCALE
FINISH DATE
DATE
DO NOT SCALE
UNLESS OTHERWISE SPECIFIED
DESCRIPTION
DRAWING SIZE:C
PART NUMBER
SHEET 1 OF 1
TACONY CORPORATION CLAIMS PROPRIETARY RIGHTS IN THE MATERIAL DISCLOSED HERE IN. THIS DRAWING IS ISSUED FOR ENGINEERING INFORMATION ONLY. IT MAY NOT BE REPRO- DUCED, NOR MAY THE INFORMATION HERE IN BE USED FOR MANUFACTURING PURPOSES WITHOUT WRITTEN PERMISSION FROM TACONY CORPORATION.
1.000
TACONY CORPORATION 1760 Gilsinn Lane, Fenton, MO 63026
DESCRIPTION OF CHANGE
REV
PART NUMBER
SHEET
1 OF 1
X.X .5 mm RADII X.X .5mm
X.XX .25mm X.XX .25mm
X.XXX .12mm MACHINE SURFACE X.XXXX .012mm BREAK SHARP CORNERS TO .25mm MAX
0 30" COMMON TO BE CONCETRIC TO .05mm
BYECN NODATEREV
AS 20MAY15
SEE NOTES SEE NOTES
C223-2000
C223-2000
BATTERY CHARGER 50.4V DC
NOTES: 1. OUTPUT 50.4V DC, 1.5A 2. DC POWER CONNECTOR PLUG 2.5MM AND CABLE 47" LONG. 3 INPUT = AC 100-240V, 50/60Hz, 100VA. 4. AC CABLE 71" LONG W/ 2 PIN POLARIZED AMERICAN PLUG 5. PLUGS AND CABLES UL CERTIFIED. 6. CHARGER - UL1310 CERTIFIED

7
On/Off Switch
• Turn the switch On to use the vacuum. If
the vacuum doesn’t turn on, check that the
battery is charged (see page 6).
• Always unplug the charger from the Charge
Point before use.
Edge Cleaning
The edge cleaning feature provides improved
cleaning near walls and stationary furniture.
For maximum edge cleaning, place the
left side of the nozzle, from the user’s
perspective, against the wall or stationary
furniture (Fig. 2).
Automatic Carpet Height Adjustment
Your vacuum is designed with an automatic
self-adjusting nozzle. No manual adjustments
are required. The height of the nozzle
automatically adjusts to the flooring surface.
This self-adjusting feature allows the nozzle
to float evenly over all flooring surfaces.
OPERATION
Fig. 1
Fig. 2
MATERIAL
DRAWN
ISSUED
SCALE
FINISH
DATE
DATE
DO NOT SCALE
UNLESS OTHERWISE SPECIFIED
DESCRIPTION
DRAWING SIZE:C
PART NUMBER
SHEET 2 OF 8
TACONY CORPORATION CLAIMS PROPRIETARY
RIGHTS IN THE MATERIAL DISCLOSED HERE IN.
THIS DRAWING IS ISSUED FOR ENGINEERING
INFORMATION ONLY. IT MAY NOT BE REPRO-
DUCED, NOR MAY THE INFORMATION HERE IN
BE USED FOR MANUFACTURING PURPOSES
WITHOUT WRITTEN PERMISSION FROM TACONY
CORPORATION.
0.250
TACONY CORPORATION
1760 Gilsinn Lane, Fenton, MO 63026
DESCRIPTION OF CHANGE
REV
PART NUMBER
SHEET
2 OF 8
X.X .5 mm RADII X.X .5mm
X.XX .25mm X.XX .25mm
X.XXX .12mm MACHINE SURFACE
X.XXXX .012mm BREAK SHARP CORNERS TO .25mm MAX
0 30" COMMON TO BE CONCETRIC TO .05mm
BYECN NODATEREV
SEE DETAIL A
SCALE 0.500
DETAIL A

8
OPERATION
Fig. 3
Bare Floor Cleaning
Your vacuum is equipped with a squeegee to
improve its effectiveness in cleaning bare floors
(Fig. 1).
Vacuuming Under Furniture
Your vacuum will lay flat on the floor for effective
cleaning under beds and tables.
• Press the Handle Release Pedal once for
routine vacuuming (Fig. 2).
• Continue to lower the handle to enable the
vacuum to lay flat on the floor for cleaning
under furniture (Fig. 3).
Fig. 1
Fig. 2
MATERIAL
DRAWN
ISSUED
SCALE
FINISH
DATE
DATE
DO NOT SCALE
UNLESS OTHERWISE SPECIFIED
DESCRIPTION
DRAWING SIZE:C
PART NUMBER
SHEET 4 OF 8
TACONY CORPORATION CLAIMS PROPRIETARY
RIGHTS IN THE MATERIAL DISCLOSED HERE IN.
THIS DRAWING IS ISSUED FOR ENGINEERING
INFORMATION ONLY. IT MAY NOT BE REPRO-
DUCED, NOR MAY THE INFORMATION HERE IN
BE USED FOR MANUFACTURING PURPOSES
WITHOUT WRITTEN PERMISSION FROM TACONY
CORPORATION.
0.250
TACONY CORPORATION
1760 Gilsinn Lane, Fenton, MO 63026
DESCRIPTION OF CHANGE
REV
PART NUMBER
SHEET
4 OF 8
X.X .5 mm RADII X.X .5mm
X.XX .25mm X.XX .25mm
X.XXX .12mm MACHINE SURFACE
X.XXXX .012mm BREAK SHARP CORNERS TO .25mm MAX
0 30" COMMON TO BE CONCETRIC TO .05mm
BYECN NODATEREV
MATERIAL
DRAWN
ISSUED
SCALE
FINISH
DATE
DATE
DO NOT SCALE
UNLESS OTHERWISE SPECIFIED
DESCRIPTION
DRAWING SIZE:C
PART NUMBER
SHEET 3 OF 8
TACONY CORPORATION CLAIMS PROPRIETARY
RIGHTS IN THE MATERIAL DISCLOSED HERE IN.
THIS DRAWING IS ISSUED FOR ENGINEERING
INFORMATION ONLY. IT MAY NOT BE REPRO-
DUCED, NOR MAY THE INFORMATION HERE IN
BE USED FOR MANUFACTURING PURPOSES
WITHOUT WRITTEN PERMISSION FROM TACONY
CORPORATION.
0.250
TACONY CORPORATION
1760 Gilsinn Lane, Fenton, MO 63026
DESCRIPTION OF CHANGE
REV
PART NUMBER
SHEET
3 OF 8
X.X .5 mm RADII X.X .5mm
X.XX .25mm X.XX .25mm
X.XXX .12mm MACHINE SURFACE
X.XXXX .012mm BREAK SHARP CORNERS TO .25mm MAX
0 30" COMMON TO BE CONCETRIC TO .05mm
BYECN NODATEREV

9
MAINTENANCE AND CARE
Replacing the Vacuum Bag
NOTE: Turn the vacuum off and remove
the battery.
• Unzip the bag compartment.
• Remove the used vacuum bag by
pulling the green bag collar tab away
from the vacuum (Fig. 1). Slide the
used bag out of the bag holder which
automatically seals the bag opening
(Fig. 2). Discard the used bag.
• To install a new bag, slide the bottom of
the green bag collar into the bag holder
until it “snaps” into place (Fig. 3).
• Push the top of the bag collar upward
until the collar “snaps” into place on
the vacuum (Fig. 4).
• Tuck the bag corners into the bag
compartment, then zip the bag
compartment closed.
MATERIAL
DRAWN
ISSUED
SCALE
FINISH
DATE
DATE
DESCRIPTION
DRAWING SIZE:D
PART NUMBER
SHEET 1 OF 1
.02 IN RADIIX.X ± .02
.01 IN X,XX ± .01
.005 IN MACHINE SURFACE
.0005 IN BREAK SHARP CORNERS TO .010 MAX
0 ° 30" COMMON TOBE CONCETRIC TO .002
TACONY CORPORATION CLAIMS PROPRIETARY
RIGHTS IN THE MATERIAL DISCLOSED HERE IN.
THIS DRAWING IS ISSUED FOR ENGINEERING
INFORMATION ONLY. IT MAY NOT BE REPRO-
DUCED, NOR MAY THE INFORMATION HERE IN
BE USED FOR MANUFACTURING PURPOSES
WITHOUT WRITTEN PERMISSION FROM TACONY
CORPORATION.
1.000
A
678
Fig. 1
Fig. 2
MATERIAL
DRAWN
ISSUED
SCALE
FINISH
DATE
DATE
DESCRIPTION
DRAWING SIZE:D
PART NUMBER
SHEET 1 OF 1
.02 IN RADIIX.X ± .02
.01 IN X,XX ± .01
.005 IN MACHINE SURFACE
.0005 IN BREAK SHARP CORNERS TO .010 MAX
0 ° 30" COMMON TO BE CONCETRIC TO .002
TACONY CORPORATION CLAIMS PROPRIETARY
RIGHTS IN THE MATERIAL DISCLOSED HERE IN.
THIS DRAWING IS ISSUED FOR ENGINEERING
INFORMATION ONLY. IT MAY NOT BE REPRO-
DUCED, NOR MAY THE INFORMATION HERE IN
BE USED FOR MANUFACTURING PURPOSES
WITHOUT WRITTEN PERMISSION FROM TACONY
CORPORATION.
1.000
A
678
Fig. 3
MATERIAL
DRAWN
ISSUED
SCALE
FINISH
DATE
DATE
DESCRIPTION
DRAWING SIZE:D
PART NUMBER
SHEET 1 OF 1
.02 IN RADIIX.X ± .02
.01 IN X,XX ± .01
.005 IN MACHINE SURFACE
.0005 IN BREAK SHARP CORNERS TO .010 MAX
0 ° 30" COMMON TO BE CONCETRIC TO .002
TACONY CORPORATION CLAIMS PROPRIETARY
RIGHTS IN THE MATERIAL DISCLOSED HERE IN.
THIS DRAWING IS ISSUED FOR ENGINEERING
INFORMATION ONLY. IT MAY NOT BE REPRO-
DUCED, NOR MAY THE INFORMATION HERE IN
BE USED FOR MANUFACTURING PURPOSES
WITHOUT WRITTEN PERMISSION FROM TACONY
CORPORATION.
1.000
A
678
Fig. 4
MATERIAL
DRAWN
ISSUED
SCALE
FINISH
DATE
DATE
DESCRIPTION
DRAWING SIZE:D
PART NUMBER
SHEET 1 OF 1
.02 IN RADIIX.X ± .02
.01 IN X,XX ± .01
.005 IN MACHINE SURFACE
.0005 IN BREAK SHARP CORNERS TO .010 MAX
0 ° 30" COMMON TO BE CONCETRIC TO .002
TACONY CORPORATION CLAIMS PROPRIETARY
RIGHTS IN THE MATERIAL DISCLOSED HERE IN.
THIS DRAWING IS ISSUED FOR ENGINEERING
INFORMATION ONLY. IT MAY NOT BE REPRO-
DUCED, NOR MAY THE INFORMATION HERE IN
BE USED FOR MANUFACTURING PURPOSES
WITHOUT WRITTEN PERMISSION FROM TACONY
CORPORATION.
1.000
A
678

10
Removing and Reinstalling the Battery
NOTE: Turn the vacuum off. If the battery charger
is plugged into the charge point on the vacuum,
remove the charger from the charge point before
removing the battery.
The battery can be removed and charged
independently from the vacuum.
• To remove the battery push up on the release
button and lift the battery off (Fig. 1).
• To replace the battery, line up the bottom of the
battery with the posts at the base of the battery
mount. Push the battery in until it clicks (Fig. 2).
Fig. 1
Fig. 2
MATERIAL
DRAWN
ISSUED
SCALE
FINISH
DATE
DATE
DO NOT SCALE
UNLESS OTHERWISE SPECIFIED
DESCRIPTION
DRAWING SIZE:C
PART NUMBER
SHEET 9 OF 9
TACONY CORPORATION CLAIMS PROPRIETARY
RIGHTS IN THE MATERIAL DISCLOSED HERE IN.
THIS DRAWING IS ISSUED FOR ENGINEERING
INFORMATION ONLY. IT MAY NOT BE REPRO-
DUCED, NOR MAY THE INFORMATION HERE IN
BE USED FOR MANUFACTURING PURPOSES
WITHOUT WRITTEN PERMISSION FROM TACONY
CORPORATION.
0.250
TACONY CORPORATION
1760 Gilsinn Lane, Fenton, MO 63026
DESCRIPTION OF CHANGE
REV
PART NUMBER
SHEET
9 OF 9
X.X .5 mm RADII X.X .5mm
X.XX .25mm X.XX .25mm
X.XXX .12mm MACHINE SURFACE
X.XXXX .012mm BREAK SHARP CORNERS TO .25mm MAX
0 30" COMMON TO BE CONCENTRIC TO .05mm
BYECN NODATEREV
MAINTENANCE AND CARE

11
MAINTENANCE AND CARE
MATERIAL
DRAWN
ISSUED
SCALE
FINISH
DATE
DATE
DO NOT SCALE
UNLESS OTHERWISE SPECIFIED
DESCRIPTION
DRAWING SIZE:C
PART NUMBER
SHEET 6 OF 8
TACONY CORPORATION CLAIMS PROPRIETARY
RIGHTS IN THE MATERIAL DISCLOSED HERE IN.
THIS DRAWING IS ISSUED FOR ENGINEERING
INFORMATION ONLY. IT MAY NOT BE REPRO-
DUCED, NOR MAY THE INFORMATION HERE IN
BE USED FOR MANUFACTURING PURPOSES
WITHOUT WRITTEN PERMISSION FROM TACONY
CORPORATION.
0.250
TACONY CORPORATION
1760 Gilsinn Lane, Fenton, MO 63026
DESCRIPTION OF CHANGE
REV
PART NUMBER
SHEET
6 OF 8
X.X .5 mm RADII X.X .5mm
X.XX .25mm X.XX .25mm
X.XXX .12mm MACHINE SURFACE
X.XXXX .012mm BREAK SHARP CORNERS TO .25mm MAX
0 30" COMMON TO BE CONCETRIC TO .05mm
BYECN NODATEREV
Fig. 1
Fig. 2
Removing and Reinstalling the
Bottom Plate
WARNING! To Reduce the Risk of Electrical
Shock or Injury from Moving Parts, Turn the
Vacuum Off and Remove the Battery Before
Servicing or Cleaning the Vacuum.
To Remove the Bottom Plate:
• Make sure the vacuum is turned Off.
• Remove the battery (see Removing and
Reinstalling the Battery, page 10).
• Press the handle release pedal to place the
vacuum cleaner in the flat position.
• Turn the vacuum cleaner over, exposing the
bottom plate.
• Turn the two screws a quarter turn to release
the bottom plate (Fig. 1). Remove the bottom
plate.
To Reinstall the Bottom Plate:
• Align the front edge of the bottom plate into the
notches inside the nozzle (Fig. 2).
• Press the bottom plate into position until the
plate “clicks” on both sides. Tighten the two
screws a quarter turn to secure the bottom
plate.
• Replace the Battery (see Removing and
Reinstalling the Battery, page 10).

12
Fig. 1
Fig. 2
Replacing the Vacuum Belt
WARNING! To Reduce the Risk of Electrical Shock
or Injury from Moving Parts, Turn the Vacuum
Off and Remove the Battery Before Servicing or
Cleaning the Vacuum.
NOTE: To ensure maximum cleaning efficiency,
the belt should be checked regularly to be sure
it is in good condition. Check to see if the belt
is stretched, cracked, or if excessive slipping is
occurring. Replace if needed.
• Turn the vacuum off and unplug the charger from
the Charge Point.
• Remove the battery (see Removing and Reinstalling
the Battery, page 10).
• Remove the bottom plate (see Removing and
Reinstalling the Bottom Plate, page 11).
• Remove the brushroll and the worn or broken
belt from the brushroll pulley and the motor drive
shaft.
• Loop the new belt around the motor drive shaft
and the brushroll (Fig. 1).
• Reinstall the brushroll into the nozzle. Turn
the brushroll by hand, making sure the belt is
not twisted and all rotating parts move smoothly
(Fig. 2).
• Reinstall the bottom plate (see Removing and
Reinstalling the Bottom Plate, page 11).
• Replace the battery (see Removing and Reinstalling
the Battery, page 10).
MAINTENANCE AND CARE
MATERIAL
DRAWN
ISSUED
SCALE
FINISH
DATE
DATE
DO NOT SCALE
UNLESS OTHERWISE SPECIFIED
DESCRIPTION
DRAWING SIZE:C
PART NUMBER
SHEET 8 OF 8
TACONY CORPORATION CLAIMS PROPRIETARY
RIGHTS IN THE MATERIAL DISCLOSED HERE IN.
THIS DRAWING IS ISSUED FOR ENGINEERING
INFORMATION ONLY. IT MAY NOT BE REPRO-
DUCED, NOR MAY THE INFORMATION HERE IN
BE USED FOR MANUFACTURING PURPOSES
WITHOUT WRITTEN PERMISSION FROM TACONY
CORPORATION.
0.250
TACONY CORPORATION
1760 Gilsinn Lane, Fenton, MO 63026
DESCRIPTION OF CHANGE
REV
PART NUMBER
SHEET
8 OF 8
X.X .5 mm RADII X.X .5mm
X.XX .25mm X.XX .25mm
X.XXX .12mm MACHINE SURFACE
X.XXXX .012mm BREAK SHARP CORNERS TO .25mm MAX
0 30" COMMON TO BE CONCETRIC TO .05mm
BYECN NODATEREV
SCALE 0.400
SCALE 0.400
MATERIAL
DRAWN
ISSUED
SCALE
FINISH
DATE
DATE
DO NOT SCALE
UNLESS OTHERWISE SPECIFIED
DESCRIPTION
DRAWING SIZE:C
PART NUMBER
SHEET 8 OF 8
TACONY CORPORATION CLAIMS PROPRIETARY
RIGHTS IN THE MATERIAL DISCLOSED HERE IN.
THIS DRAWING IS ISSUED FOR ENGINEERING
INFORMATION ONLY. IT MAY NOT BE REPRO-
DUCED, NOR MAY THE INFORMATION HERE IN
BE USED FOR MANUFACTURING PURPOSES
WITHOUT WRITTEN PERMISSION FROM TACONY
CORPORATION.
0.250
TACONY CORPORATION
1760 Gilsinn Lane, Fenton, MO 63026
DESCRIPTION OF CHANGE
REV
PART NUMBER
SHEET
8 OF 8
X.X .5 mm RADII X.X .5mm
X.XX .25mm X.XX .25mm
X.XXX .12mm MACHINE SURFACE
X.XXXX .012mm BREAK SHARP CORNERS TO .25mm MAX
0 30" COMMON TO BE CONCETRIC TO .05mm
BYECN NODATEREV
SCALE 0.400
SCALE 0.400

13
Replacing the Squeegee
WARNING! To Reduce the Risk of Electrical
Shock or Injury from Moving Parts, Turn the
Vacuum Off and Remove the Battery Before
Servicing or Cleaning the Vacuum.
If your squeegee splits or begins to look worn,
simply slide the worn squeegee from its track
and slide a new one into the track. If you have
trouble installing the new squeegee, please
visit an Authorized CleanMax Retailer for help.
MAINTENANCE AND CARE
MATERIAL
DRAWN
ISSUED
SCALE
FINISH
DATE
DATE
DO NOT SCALE
UNLESS OTHERWISE SPECIFIED
DESCRIPTION
DRAWING SIZE:C
PART NUMBER
SHEET 4 OF 8
TACONY CORPORATION CLAIMS PROPRIETARY
RIGHTS IN THE MATERIAL DISCLOSED HERE IN.
THIS DRAWING IS ISSUED FOR ENGINEERING
INFORMATION ONLY. IT MAY NOT BE REPRO-
DUCED, NOR MAY THE INFORMATION HERE IN
BE USED FOR MANUFACTURING PURPOSES
WITHOUT WRITTEN PERMISSION FROM TACONY
CORPORATION.
0.250
TACONY CORPORATION
1760 Gilsinn Lane, Fenton, MO 63026
DESCRIPTION OF CHANGE
REV
PART NUMBER
SHEET
4 OF 8
X.X .5 mm RADII X.X .5mm
X.XX .25mm X.XX .25mm
X.XXX .12mm MACHINE SURFACE
X.XXXX .012mm BREAK SHARP CORNERS TO .25mm MAX
0 30" COMMON TO BE CONCETRIC TO .05mm
BYECN NODATEREV

14
The model and serial number of this product may be found on the bottom of the unit.
You should note the model and serial number of your unit in the spaces provided below,
and retain this book as a permanent record of your purchase.
Date of purchase ____________________________________________________
Serial number _______________________________________________________
Model number ______________________________________________________
Purchased from:
Store Name _______________________________________________________
Address _______________________________________________________
City, State, Zip ______________________________________________________
Telephone _______________________________________________________
For Best Performance
• Keep your vacuum clean and in good operating condition.
• Change vacuum bag when the bag is 2/3 full to maximize cleaning performance.
• Always use genuine vacuum bags and replacement parts. Use of other products may
result in poor cleaning performance, potential vacuum cleaner damage and may void
vacuum warranty. Genuine products are designed for maximum cleaning performance.
• Store your machine carefully in a dry area.
• For optimum cleaning performance and safety, follow your owner’s manual instructions.
Owner’s information (keep this for your records)

15
Warranty
What is Covered:
This warranty covers any defects in material and workmanship in your new
CleanMax vacuum.
How Long Coverage Lasts:
Warranty coverage for your CleanMax vacuum lasts one year.
What is Not Covered:
• Damage to the vacuum which occurs from neglect, abuse, alterations, accident,
misuse or improper maintenance.
• Normal replacement items: belts, squeegees, agitator brush strips and
disposable bags.
What CleanMax Will Do:
This warranty provides, at no cost to you, all labor and parts to place this vacuum in
correct operating condition during the warranted period.
How to Get Service:
Warranty service can only be obtained by presenting the vacuum to the retailer where
original purchase was made. A proof-of-purchase and product serial number will be
required before service is rendered.
THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF ANY AND ALL OTHER
WARRANTIES WHETHER WRITTEN, ORAL, EXPRESSED OR IMPLIED, (INCLUDING
ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE). THIS WARRANTY DISCLAIMS LIABILITY FOR INCIDENTAL, OR
CONSEQUENTIAL DAMAGES.
How State Law Applies:
This warranty gives you specic legal rights, and you may also have other rights
which vary from state to state.

B503-0300
CleanMax Vacuum Cleaners
PO Box 730
Fenton, MO 63026
