ClearStream P20 Series User manual

OWNERS MANUAL
4” SUBMERSIBLE PUMP
Series P20 – Two Wire, ½ HP, 115 Volt, 60Hz
Series P35-2 – Two Wire, 1 HP, 230 Volt, 60Hz
Installation * Operation
LIMITED WARRANTY
Clearstream warrants to the original consumer of the products listed below, that they will be free from defects in material
and workmanship for the Warranty Period from the date of installation as noted.
Product Warranty Period
4” Submersible Pump 2 Year
Our warranty will not apply to any product that has been subject to negligence, misapplication, improper installation or maintenance
Buyers only remedy and Clearstream’s only duty is to repair or replace defective products (at Clearstream’s choice). Buyer agrees to pay
all labor and shipping associated with this warranty and to request warranty service through the installing dealer as soon as a problem is
discovered. If warranty service is requested after the Warranty Period has ended, it will not be honored.
CLEARSTREAM SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL, INCIDENTAL, OR CONTINGENT DAMAGES WHATSOEVER.
THE FOREGOING WARRANTIES ARE EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESS WARRANTIES. IMPIED WARRANTIES,
INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, SHALL NOT EXTEND BEYOND THE WARRANTY PERIOD PROVIDED HERIN.
Certain states do not permit the exclusion of incidental or consequential damages or the placing of limitations on the
duration of an implied warranty, therefore, the limitations or exclusions herein may not apply. This warranty sets forth
specific legal rights and obligations, however, additional rights may exist, which may vary from state to state.
Supersedes all previous publications.
Clearstream, P.O. Box 7568, Beaumont, TX 77726
CLEARSTREAM
P.O. Box 7568, Beaumont, TX 77726
PRINTED IN U.S.A
.
CL370 (Rev. 10/1/10)

TABLE OF CONTENTS
Warranty ------------------------------------------------------ 1
Safety Instructions ---------------------------------------- 2
General ------------------------------------------------------ 2
Electrical ---------------------------------------------------- 2-3
Operation ---------------------------------------------------- 3
Troubleshooting Guide ------------------------------------ 4
Carefully read and follow all safety instructions in this manual
or on pump.
This is the safety alert symbol. When you see this symbol on
your pump or in this manual, look for one of the following
signal words and be alert to the potential for personal injury!
DANGER warns about hazards that will cause
serious personal injury, death or major
property damage if ignored.
WARNING warns about hazards that can cause
serious personal injury, death or major property
damage if ignored.
CAUTION warns about hazards that
will or can cause minor personal injury,
or property damage if ignored.
The word NOTICE indicates special instructions which are important but
not related to hazards.
To avoid serious or fatal personal injury and possible property
damage, carefully read and follow the safety instructions.
Under certain conditions, submersible pumps
1. HAZARDOUScan develop extremely high pressure. Installa pressure
relief valve capable of passing entire
PRESSURE pump flow at 75 psi.
Do not allow pump, piping, or any other system component
containing water to freeze. Freezing may damage system,
leading to injury or flooding. Allowing pump or system components to
freeze will void warranty.
Can shock burn or cause death. To avoid
2.dangerous or fatal electric shock hazard,
use pump only in an effluent system.
DO NOT Install pump in an open body of
water (lake, swimming, etc.).
Install, ground and wire pump according to local and Canadian
Electrical Code or National Electrical Code requirements that
apply.
Disconnect electrical power before installing or servicing pump.
Make sure motor nameplate voltage and frequency match line
voltage and frequency of power supply.
1. Install pump according to all plumbing, pump and well
coderequirements.
2. Install an all leg disconnect switch in the power supply near
thepump.
3. Two-wire motors are equipped with automatic thermal
overloadprotection which will open the circuit and stop the motor
when a thermal overload (excessive heating) exists. When motor
cools, overload will rest and motor will restart automatically. This
can cause the motor to start unexpectedly and without warning!
GENERAL
Inspect pump and motor for delivery damage. Report any damage
Immediately to shipping carrier or to Clearstream immediately.
Have any installation, repair, or service work done by your Clearstream
dealer.
Never run pump dry.
During system operation, pump must be submerged at all times.
Pipe joint compound can cause cracking in plastics. Use only teflon
tape when sealing joints in plastic pipe or connecting pipe to
thermoplastic pumps.
Warranty is void in the following conditions: *
Water is highly corrosive.
*If entrained gas or air present in water being pumped reduce the
flowand cause cavitation (which can damage the pump).
*Pump has been operated with discharge valve closed (severe
internaldamage may result).
ELECTRICAL
WIRING/GROUNDING
Can shock, burn, or cause death. Permanently
Ground pump, motor and control box before
Connecting power supply to motor.
Ground pump and motor in accordance with all codes and ordinances
that apply. All wiring must meet National Electrical Code and Canadian
Electrical Code (whichever applies). Use copper ground wire at least as
large as wires carrying current to motor.
Motor is supplied with copper ground wire. Splice to copper conductor
that matches motor wire size specified in Table 2. Use only copper wire
for connections to pump.
Permanently ground pump and motor before connecting power cable to
power supply. Connect ground wire to approved ground first, then connect
to equipment being installed.
Do not ground to a gas supply line.
Float switches or any other approved motor control must match motor
input to full load amperes.
For more information, contact your local code officials.
INSTALLATION WIRING INSTRUCTIONS
Single Phase, 2 Wire
2-Wire pumps have two power supply wires (Red/Black) and one
ground wire (Green).
1. Fasten power supply wire leads securely to pump discharge
section;leave 4-5” of slack in leads at this point. Securely fasten leads
to plastic pipe within 6” of the pump discharge section.
2. Ground wire must be as large as wires supplying current to
motor.Consult current National Electrical Code or Canadian Electrical
Code (as applicable) and local codes for grounding information.
3. Use only submersible power supply wires supplied by pump
manufacturer. When installing pump, secure supply wires to
discharge pipe with Scotch #33 electrical tape. DO NOT damage
pump wires.
NOTICE: To avoid dropping or damaging wires or splices,
NEVER allow pump wires to support weight of pump.
EFFLUENT APPLICATIONS
Pumps designed and tested for effluent applications must meet the
following:
Risk of electrical shock. Do not remove cord and strain
relief. Do not connect conduit to pipe.
1. Only qualified personnel should install the pump and
associatedcontrol equipment.
2. Vent sewage tank according to local codes.
3. Do not install pump in any location classified as hazardous
byNational Electrical Code, ANSI/FPA 70-1984.
4. These pumps are intended for permanent connection only.Provide
strain relief at control box for power supply cord connection to
box. All control components must be UL listed and suitable for end
use application.
HAZARDOUS
VOLTAGE

PUMP INSTALLATION
1. Make sure that pump and motor are free to rotate by turning
theshaft by hand.
2. To prevent dropping pump, lower it by the drop pipe, not by
thecables. The electrical cables will not hold the pump weight.
3. Discharge outlet is 1-1/4” NPT threaded.
NOTICE: Pump discharge is left-hand thread into pump shell. If
installing external check valve, hold discharge with pipe wrench
to prevent loosening discharge in shell.
4. If pump is to be operated with an open discharge, a discharge
valvemust be installed. * Before startup, open this valve about 1/3
open.
2
Start pump. Slowly open valve until the desired flow rate is reached. Final
setting must be within pump’s recommended operating range.
OPERATION
1. The pump must be submerged at all times during normal
operation.
Do not run pump dry.
2. Make sure that the float switches are set so that the pump stops
before the pump runs dry or breaks suction. If necessary, adjust
float switches to achieve this.
3. The motor bearings are lubricated internally. No maintenance is
required or possible on the pump or the motor.
Table 1: Recommended Fusing Data
60 Hz/1 Phase 2-Wire Cable
Motor Winding Max Locked Fuse Size
Volts/Hz/ Resistance Load Rotor Standard
HP Phase Ohms Amps Amps Dual Element
1/2 115/60/1 1.0-1.3 7.8 21 20/15
1 230/60/1 2.2-2.7 9.8 48.7 25/12
Table 2: Power Supply Wire (Cable) Length in Feet
1 Phase, 2 Wire Cable, 60 Hz (Copper Wire Size – Service to motor)
Volts
HP
14 AWG
12 AWG
10 AWG
8 AWG
6 AWG
4 AWG
3 AWG
2 AWG
1 AWG
0 AWG
115
1/2
100
160
250
390
620
960
1190
1460
1780
2160
230
1
250
400
630
940
1540
2380
2960
3610
4410
5360
1. Maximum wire lengths shown maintain motor voltage at 95% of 2. Sizes given are for copper wire. For aluminum wire go
service entrance voltage, running at maximum nameplate amperes. two sizes larger (i.e., if #12 copper wire, use #10 If service
entrance voltage will be at least motor nameplate voltage aluminum wire. under normal load conditions, 50% additional
length is permissible for all sizes.
Motor Insulation Resistance Readings
Normal Ohm/Megohm readings for all motors, between all leads and ground. Set ohmmeter to 100K scale.
Condition of Motor and Leads Ohm Value Megohm Value
New Motor , without power cable 20,000,000 20.0
Used motor, which can be reinstalled in tank 10,000,000 10.0
Motor in Tank – Readings are Power Cable plus Motor
New Motor 2,000,000 (or more) 2.0 Motor
in reasonably good condition 500,000 t0 2,000,000 0.5-2.0
Motor which may be damaged or have damaged power cable 20,000 to 500,000 0.02-0.5
Do not pull motor for these reasons
Motor definitely damaged or with damaged power cable 10,000 to 20,000 0.01-0.02
Pull motor and repair
Failed motor or power cable-Pull motor and repair Less than 10,000 0-0.1

3
0
5
10
15
20
25
30
35
40
45
10 20 25 30 35 40 45 50 55 60 65 70 75 80
GPM
PSI
P-20 & P-35-2 FLow Curve
P-35-2
P-20
Important Electrical Grounding Information
B. Clamp or weld (or both if necessary) this bonding conductor
to Hazardous voltage. Can shock, burn, the grounding conductor to the equipment-grounding terminal,
or kill.To reduce the risk of electrical the grounding conductor on the pump housing, or an equipment
shock during pump operation, ground and bond the grounding lead. The equipment-grounding lead, when provided pump
and motor as follows: will be the conductor having green insulation; it may also have
A. To reduce risk of electrical shock from metal parts of the one or more yellow stripes.
assembly other than the pump, bond together all metalC. Ground the pump, motor and any metallic conduit that carries parts
accessible at the tank top (including metal discharge power cable conductors. Ground these back to the service by pipe, metal
tank top, and the like). Use a metal bonding connecting a copper conductor from the pump, motor, and
conductor at least as large as the power cable conductors conduit to the grounding screw provided within the
supplyrunning down the wall to the pump’s motor. connection box wiring compartment. This conductor must be at least as
large as the circuit conductors supplying the pump.
SAVE THESE INSTRUCTIONS
HAZARDOUS
VOLTAGE
