Macnaught C4 User manual

C4, C4 ZINC & C4-51 MODEL MULTI-PURPOSE PUMPS
AG12
0206
Thank you for purchasing either a Macnaught model C4,
C4 Zinc or C4-51 Multi-Purpose Pump.
Please read and retain this instruction sheet to assist
you in the maintenance of this quality product.
Your C4 pump features:
* Adjustable collar with removable bung adaptor to suit
drums with or without plastic spout.
* Fully serviceable, spare parts readily available.
* Delivers approximately 100ml per stroke.
* Fits 18 to 25 litre drums.
* Suitable for Kerosene, two stroke mix, light viscosity oils
and most solvents.
* Model C4-51 is supplied complete with a 1.8m hose and
nozzle.
ORDER FOR REPLACEMENT
I
TEM PART No. No. off PART/SET KIT. REF DESCRIPTION
1 AC42 1 AC42s PUM P ROD ASSEM B LY
2 AC33 1 AC33s GLAND NUT
3 AC34 1 GLAND SEAL
4 AC32 1 AC32s incl BS024 BODY
4 AC32-1 1 AC32s-1 incl BS024 BODY (ZINC)
5AC2 1 ADAPTOR
6AC9 1 ADAPTOR
7 BS024 1 AC24s O'RING
8N71 1 THUMBSCREW
9BS216 1 O'RING
10 AC23 1 ADJUSTABLECOLLAR
11 N 10 3 2 W A SHER
12 AC31 1 PLUNGER SPRING
13 N265 1 AC6s SPRING CLIP
14 N105 1 VALVEPLATE
15 AC6 2 PLUNGER DISC
16 N212 1 STELOCKNUT
17 AC10 1 AC10s PUMPTUBE
18 N412 1 9/16" STEEL BALL
19 KM 58 1 AC5s BALL RETAINER
20 KM 57 1 FOOTV ALVE
21 Z47 2 HOSECLAMP
22 AG87 1 AG87s HOSE
23 AG24 1 HOSE SPRING
24 AG82 1 AG82s OUTLET TUBE
PARTS LIST
1
2
3
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
23
24
22
21
4
20
11
* C4 ZINC Model for use in underground mines.
Before operation ensure that manual non-drip nozzle is
open to prevent pressure build up or hose damage.
INSTRUCTION MANUAL
Macnaught Pty Ltd
POBox90ArncliffeNSW2205Australia
Telephone [phone]
Facsimile [phone]
Email: [email protected]
Web:www.macnaught.com.au
WARRANTY POLICY
MacnaughtPty Ltd(“Macnaught”)warrantsthatallProductsmanufactured byMacnaughtand
purchasedafter 1st of July 1999 willbe freefrom anydefects causedby faultymaterials or
workmanshipforaperiod of (5) yearsfromthedateofpurchaseoftheproduct,provided that
duringtheWarrantyperiod:
1) Macnaughtreceives notice settingout fulldetailsof any defect inanyproduct and
detailsofthetimeand place of purchase.
2) ThePurchaser,attheirowncostreturnstheproducttothenearestauthorized Macnaught
servicecenter.
Forcomponentry contained intheproduct,(suchas o’rings,seals,springsandhoses ) which
aresubjecttowear,thewarrantyperiodwillbe(12)monthsfromthedateofpurchaseofthe
product.
Macnaughtshall,atitsoption repair or replace any product founddefectivebyitsinspection.
Thiswarrantydoesnotcoverfailureofpartsorcomponentswhich,inthejudgmentofMacnaught,
arisesfrommisuse, abrasioncorrosion,negligence,accident,substitutionof non-Macnaught
parts,faultyinstallationortampering.
IfMacnaught inspectiondisclosesnodefectinmaterialor workmanship,repairorreplacement
andreturnwillbemadeat customary charges.
Macnaught’sliabilityandthepurchaser’srightsunderthis Warranty shall be limited to such
repairor replacement andinparticular, shall notextend to any direct,special, indirect or
consequentialdamageorlossesofany nature.
Theforegoingwarrantysupersedes,voidsandisinlieu of all or any other warranties.
“Note:Thiswarrantydoesnotformpartof,nordoesitconstitute,acontractbetweenMacnaught
andtheend-userorpurchaser.Itisadditionaltoanywarrantygivenbytheselleroftheproducts.
Thiswarrantydoes notexclude,limit,restrictormodify the non-excludablerightsorremedies
conferreduponthe end-user orpurchaser,orthenon-excludabledutiesor liabilities imposed
onthe seller orMacnaught, byPartV,Divisions 2 and 2AoftheTradePractices act 1974
(Commonwealth)or otherlegislativeprovisions.Macnaughtotherwise excludes,totheextent
permittedbylaw, any rightsconferredontheend-useror duties orliabilitiesimposeduponit.”
IMPORTANT
0008

Thank you for purchasing either a Macnaught model C7,
C7 Zinc or CF7 Gear Oil Pump.
Please read and retain this instruction sheet to assist
you in the maintenance of this quality product.
C7, C7 ZINC & CF7 MODEL GEAR OIL PUMPS
AG12
0206
0008
Your C7 pump features:
* Adjustable collar with removable bung adaptor to suit
drums with or without plastic spout.
* Fully serviceable, spare parts readily available.
* Pumps on the down stroke, approximately 100ml /
stroke.
* Complete with 1.8m hose and non-drip nozzle.
* Suitable for oils up to SAE 140.
* Optional CF Filter for A.T.F and oils of similar viscosity.
* C7 ZINC Model for use in underground mines.
ORDER FOR REPLACEMENT
I
TEM PART No. No. off PART/SET KIT. REF DESCRIPTION
C7-1K (KIT A) SEAL KIT
1 AC42 1 AC42s PUMP ROD ASSEMBLY
2 AG24 1 AG21s inclBS024 BODY &INNER TUBEASSY
2 AG24-1 1 AG21s-1 incl BS024 BODY &INNER TUBEASSY (ZINC)
3 BS024 1 AC10s A O'RING
4AC10 1 PUMPTUBE
5BS216 1 A O'RING
6 N71 1 AC24s THUM B SCREW
7 AC23 1 ADJUSTABLE COLLAR
8 AC2 1 ADAPTOR
9 AC9 1 ADAPTOR
10 A A 11 1 A TO P STOP SPR ING
11 B S113 1 A O' R IN G
12 BS008 1 A O'RING
13 A G6 1 A PIST ON
14 N212 1 A STA LOCK NUT
15 N 4 12 1 9 / 16 " ST EEL B A LL
16 KM 57 1 AC5s FOOTVALVE
17 KM 58 1 BALL RETAINER
18 KM8 1 KM8s HOSE TAIL
19 N366 2 HOSECLAMP
20 AG87 1 AG88s HOSE
21 AG29 1 HOSE SPRING
22 AG88 1 OUTLET TUBEASSEMBLY
PARTS LIST
1
2
3
4
5
6
7
8
9
10
11 12
13
14 15
16
17
18 19 20
21
22
22
IMPORTANT
Before operation ensure that manual non-drip nozzle is
open to prevent pressure build up or hose damage.
Macnaught Pty Ltd
POBox90ArncliffeNSW2205Australia
Telephone [phone]
Facsimile [phone]
Email: [email protected]
Web:www.macnaught.com.au
WARRANTY POLICY
MacnaughtPty Ltd(“Macnaught”)warrantsthatallProductsmanufactured byMacnaughtand
purchasedafter 1st of July 1999 willbe freefrom anydefects causedby faultymaterials or
workmanshipforaperiod of (5) yearsfromthedateofpurchaseoftheproduct,provided that
duringtheWarrantyperiod:
1) Macnaughtreceives notice settingout fulldetailsof any defect inanyproduct and
detailsofthetimeand place of purchase.
2) ThePurchaser,attheirowncostreturnstheproducttothenearestauthorized Macnaught
servicecenter.
Forcomponentry contained intheproduct,(suchas o’rings,seals,springsandhoses ) which
aresubjecttowear,thewarrantyperiodwillbe(12)monthsfromthedateofpurchaseofthe
product.
Macnaughtshall,atitsoption repair or replace any product founddefectivebyitsinspection.
Thiswarrantydoesnotcoverfailureofpartsorcomponentswhich,inthejudgmentofMacnaught,
arisesfrommisuse, abrasioncorrosion,negligence,accident,substitutionof non-Macnaught
parts,faultyinstallationortampering.
IfMacnaught inspectiondisclosesnodefectinmaterialor workmanship,repairorreplacement
andreturnwillbemadeat customary charges.
Macnaught’sliabilityandthepurchaser’srightsunderthis Warranty shall be limited to such
repairor replacement andinparticular, shall notextend to any direct,special, indirect or
consequentialdamageorlossesofany nature.
Theforegoingwarrantysupersedes,voidsandisinlieu of all or any other warranties.
“Note:Thiswarrantydoesnotformpartof,nordoesitconstitute,acontractbetweenMacnaught
andtheend-userorpurchaser.Itisadditionaltoanywarrantygivenbytheselleroftheproducts.
Thiswarrantydoes notexclude,limit,restrictormodify the non-excludablerightsorremedies
conferreduponthe end-user orpurchaser,orthenon-excludabledutiesor liabilities imposed
onthe seller orMacnaught, byPartV,Divisions 2 and 2AoftheTradePractices act 1974
(Commonwealth)or otherlegislativeprovisions.Macnaughtotherwise excludes,totheextent
permittedbylaw, any rightsconferredontheend-useror duties orliabilitiesimposeduponit.”
INSTRUCTION MANUAL
