WilTec AS29 User manual

Operation Manual
Vacuum Pump AS29
34243
Illustration similar, may vary depending on model
Read and follow the operating instructions and safety information before using for the first time.
Technical changes reserved!
Due to further developments, illustrations, functioning steps and technical data can differ insignific -
antly.
Updating the documentation
If you have suggestions for improvement or have found any irregularities, please contact us.

The information contained in this document may alter at any time without previous notice. It is prohib-
ited to copy or spread any parts of this document in any way without prior written allowance. ll rights
reserved.
The WilTec Wildanger Technik GmbH cannot be held accountable for any possible mistakes in this
operating manual, nor in the diagrams and figures shown.
Even though, the WilTec Wildanger Technik GmbH has undergone biggest possible efforts to ensure
that the operating manual is complete, faultless and up to date, mistakes cannot be entirely avoided.
If you should find a mistake or wish to make a suggestion for improvement, we look forward to hearing
from you.
Send an e-mail to:
[email protected]
or use our contact form:
https://www.wiltec.de/contacts/
The most recent version of this manual in various languages can be found in our online shop via:
https://www.wiltec.de/docsearch
Our postal address is:
WilTec Wildanger Technik GmbH
Königsbenden 12
52249 Eschweiler
Germany
Do you wish to pick goods up? Our pick-up address is:
WilTec Wildanger Technik GmbH
Königsbenden 28
52249 Eschweiler
Germany
To shorten the waiting time and allow for a rapid on-site transaction, we ask you to call us previously
or placing your order via the webshop.
E-mail: [email protected]
Tel:[phone]
Fax: [phone]
To return orders for exchange, repair or for other purposes, please use the following address. tten -
tion! To allow for a smooth execution of your complaint or return, it is important to contact our cus -
tomer service team before returning the goods.
Returns Department
WilTec Wildanger Technik GmbH
Königsbenden 28
52249 Eschweiler
E-mail: [email protected]
Tel:[phone]
Fax: [phone]
© by WilTec Wildanger Technik GmbH Item 34243 Page 2
http://www.WilTec.de
http://www.aoyue.eu 03 2021-1
http://www.teichtip.de

Introduction
Thank you for purchasing this quality product. o minimize the risk of injury we urge that our cli-
ents take some basic safety precautions when using this device. Please read the operation in-
structions carefully and make sure you have understood its content.
Keep these operation instructions safe.
Safety guideline
BEWARE:
The use of this device is allowed only with fault current protection switch with a triggering nominal cur -
rent up to 30<m (according to VDE 0100 rticle 702 and 738).
The device is not intended for use by persons (including children) with impaired or limited physical,
sensory and mental abilities or lack of experience and/or real knowledge, unless they are supervised
by a person responsible for their safety or the follow the instructions, made by this person on how to
use the device correctly. Children should be supervised to make sure that they do not play with the
device.
CAUTION:
he head of the vacuum pump (with cooling fins) can get very hot.
Run a visual inspection of the device before every use. Do not use the device if the safety ap-
pliances are damaged or worn out. Never override safety regulations.
Use the device exclusively according to the intended purpose stated in the manual.
You are responsible for the safety of the working environment.
If the cable or the plug is damaged due to external influences, the cable must not be repaired,
but has to be replaced with a new one. This work can only be carried out by an electrician.
The 230<V alternating voltage indicated on the type plate of the device has to correspond to
the existent mains voltage.
Never lift, carry or fix the device by using the power cable.
Make sure that the electrical plug connection is protected from flood and moisture.
Disconnect the mains plug before starting the maintenance work at the compressor.
The user is responsible for complying with the location specific safety and mounting regula-
tions. sk an electrician, if necessary.
In case of device failure the repairs can only be carried out by an electrician.
SAFETY GUIDELINES:
The user should choose the right vacuum pump with the appropriate air volume and air pres -
sure to correspond to the actual work requirements.
Never expose the device to dust, acid, steam, explosive or flammable gases, or atmospheric
influences (rain, sun, fog, snow).
The vacuum pump can be operated only in an appropriate environment (good ventilation, am-
bient temperature of +5–+40< ).℃
Never use the vacuum pump barefoot or with wet hands or feet.
Never allow children to touch the switched-on vacuum pump or to insert the plug. It may cause
burns or electric shocks.
Do not open or damage any vacuum pump part. If necessary, please contact your seller.
lways release the water by opening the drain valve before not using the vacuum pump for a
long time. Store the vacuum pump in a well ventilated place.
lways wear goggles. Under no circumstances direct the airflow towards your body or other
persons’ bodies or animals.
Never use the device in areas with steam or moisture or close to water.
© by WilTec Wildanger Technik GmbH Item 34243 Page 3
http://www.WilTec.de
http://www.aoyue.eu 03 2021-1
http://www.teichtip.de

Switch off the vacuum pump if you do not use it. Disconnect it from mains before you repair,
recondition, maintain, clean or replace parts. Never use the power cable as handle. Keep the
power cable away from hot objects, oil and sharp edges. Protect it against breakage. Do not
pull the power cable in order to unplug it from the power socket.
If the vacuum pump is used outdoors, only approved extensions may be used. Every wire of
the extension cable must have at least 1.5<mm² cross-section.
Do not store the vacuum pump with the plug inserted into the socket. Do not allow children or
any other people who are not able to handle this device to play or work with it.
Be very careful when you are working with the vacuum pump. Do not use it if you are tired.
Persons under the influence of alcohol, drugs or medication are not allowed to use this device.
When you start working make sure that all screws are tightened.
Do not use the vacuum pump if it is damaged. If the vacuum pump generates unusual noises
and strong vibrations or if other unusual signs occur that indicate some damage you should
turn off the vacuum pump immediately. For repairs please use only original spare parts. Do
not make any technical modifications to the vacuum pump. In case you cannot eliminate the
malfunction hand over the device to an expert.
Properties
Diaphragm vacuum pump
Without oil, no untidy air
Protection against excessive temperature
Very low noise level
© by WilTec Wildanger Technik GmbH Item 34243 Page 4
http://www.WilTec.de
http://www.aoyue.eu 03 2021-1
http://www.teichtip.de

Fields of application
The S29 vacuum pump is among others suitable for the operation in the following areas:
crafts,
hobbies,
modelling,
tattoos and body art,
make-up and nail design,
as a source of air in the medical field,
in food and chemical industries,
in laboratories,
for inflating pneumatic tyres and
for filling balloons.
echnical specifications
ype Oil-free vacuum pump
Power (W) 370 (½<hp)
Rotation speed (rpm) 1450–1700
Noise level ( ㏈( )) ≤55
Suction volume (ℓ⁄min) 128–135
Vacuum (㎜ Hg) 600
Hose connection (㎜) 12.91 (¼”)
Weight (㎏) 8.65
Size (㎜) 415×365×285
Cable length (m) 1.9
Notes:
The vacuum pump has a 12.91<mm outlet (¼”, male thread), which can be effortlessly
changed to ⅛”. The matching adapter is not included in the supply.
When the vacuum pump is connected by the hose to the airbrush gun, the vacuum pump can
be connected to the mains and be switched on.
The maximum pressure is displayed by the pressure gauge, the operating pressure can be
adjusted by the pressure regulator.
The hose included is air-impermeable. If the auto-stop mode is activated (repeatedly switch
on/off) any and all screw fittings and connections should be sealed by a teflon tape.
Leakage control
Switch on the compressor and wait until the maximum pressure has built up and the auto-stop
function has been activated.
If there is no leakage, the pressure gauge should display nearly constantly the same range of
pressure.
 quick decrease of the range of pressure suggests that there is in fact a leakage.
It is of great importance to seal any leak as soon as possible in order to avoid any impact on
the capacity and efficiency of the compressor.
 leak causes the auto-stop and auto-start function to be carried out permanently.
© by WilTec Wildanger Technik GmbH Item 34243 Page 5
http://www.WilTec.de
http://www.aoyue.eu 03 2021-1
http://www.teichtip.de

Difference between maximum and operating pressure
•The maximum pressure is the highest possible pressure a compressor can generate.
•Once the maximum pressure has been reached, the compressor switches off (auto-stop). s
soon as the pressure starts to decrease, it switches on again (auto-start).
•Maximum pressure is the pressure measured inside the compressor.
•There is a lower pressure on the outlet of the compressor. The pressure you actually work
with remains. The operating pressure may vary according to the connected airbrush gun.
roubleshooting
Problem Cause Solution
The motor does not run. 1. Electric cables are defective. 1. Check the electric cables and
replace them if necessary.
2. The internal cable connections
are defective.
2. Open the rear cover, check the
internal cable connections, repair
them.
3. The main switch does not work. 3. Check the main switch, replace
it if necessary.
The motor does not run,
yet emitting noises.
1. The outlet is completely ob-
structed or closed.
1. Open the cap and free the out-
let.
2. Wrong direction of cylinder
valve after users’ first mounting or
dismounting
2. Re-mount the cylinder valve in
the correct direction.
The motor does run, yet
emitting irregular or knock-
ing noises.
1. The bearings are loose or de-
fective.
1. Replace the bearings.
2. Connecting rod screws are
loose.
2. Re-tight or replace the screws.
The airbrush gun does not
work properly; there is not
enough vacuum pressure.
1. The vacuum air connection is
not tight.
1. Seal the air hose with sealing
tape.
2. The air hose is torn. 2. Replace the air hose.
3. Cylinder cover screws are
loose.
3. Re-tighten the screws.
The motor, running regu-
larly, does not produce
enough or any air pres-
sure.
1. Valve and diaphragm screws
are loose or set to the wrong posi-
tion.
1. Open the front cover, re-tighten
the screws and set the diaphragm
screws to the correct position.
2. The valve has been destroyed
because too much pressure has
been applied during work.
2. Replace de intake plate or the
valves.
© by WilTec Wildanger Technik GmbH Item 34243 Page 6
http://www.WilTec.de
http://www.aoyue.eu 03 2021-1
http://www.teichtip.de

Explosion view and parts list
№ Name Qty. № Name Qty.
1Elbow assembly 2 26 Bearing 1
2Cylinder cover 1 27 Rubber feet 4
3djusting valve 1 28 Rotor blade 1
4Slotted screw 8 29 Spindle 1
5Handle 1 30 Main housing 1
6Seal ring 1 31 Rotor assembly 1
7Valve 5 32 Supporter 1
8Separating plate 1 33 Nut 2
11 Screw 6 34 Screw 2
12 Diaphragm fixing plate 1 35 Condenser 2
13 Diaphragm 1 36 Condenser holder 2
14 Connecting rod 1 37 Screw 2
15 Bearing 1 38 Bearing 1
16 Hexagon screw 1 39 Rear cover 1
17 Hexagon nut 1 40 Vacuum gauge 1
18 Cylinder head 1 41 Switch 1
19 Balance rod 1 42 Cable sleeve assembly 1
22 Front cover 1 43 Plug wire 1
23 Slotted screw 4 44 Screw 4
24 Muffle 1 45 Pipe 2
25 Pipe nut 4 46 Three-way adaptor 1
© by WilTec Wildanger Technik GmbH Item 34243 Page 7
http://www.WilTec.de
http://www.aoyue.eu 03 2021-1
http://www.teichtip.de

Disposal regulations
EU guidelines regarding the disposal of scrap electric appliances (WEEE, 2012/19/EU) were imple-
mented in the law related to electrical and electronic equipment and appliances.
ll WilTec electric devices that fall under the WEEE regulations are labelled with the crossed-out
wheeled waste bin logo. This logo indicates that this electric equipment must not be disposed with the
domestic waste.
The company WilTec Technik GmbH has been registrated in the German registry E R under the
WEEE-registration number DE45283704.
Disposal of used electrical and electronic appliances
(intended for use in the countries of the European
Union and other European countries with a separate
collection system for these appliances).
The logo on the article or on its packaging points out
that this article must not be treated as normal house-
hold waste but must be disposed to a recycling collec-
tion point for electronic and electrical waste equip-
ment. By contributing to the correct disposal of this art-
icle you protect the environment and the health of your
fellow men. Environment and health are threatened by
inappropriate disposal.
Material recycling helps reduce the consumption of raw materials.
dditional information on recycling this article can be provided by your local community, municipal
waste disposal facilities or the store where you purchased the article.
ddress:
WilTec Wildanger Technik GmbH
Königsbenden 12 / 28
D-52249 Eschweiler
Important notice:
The reprint or reproduction, even of excerpts, and any commercial use, even in part of this instructions
manual require the written permission of WilTec Wildanger Technik GmbH.
© by WilTec Wildanger Technik GmbH Item 34243 Page 8
http://www.WilTec.de
http://www.aoyue.eu 03 2021-1
http://www.teichtip.de
