TENNANT F8
POLISHER
OPERATOR MANUAL
Clemas & Co. Unit 5 Ashchurch Business Centre, Alexandra Way, Tewkesbury,
Gloucestershire, GL20 8NB.
Tel: [phone] Fax: [phone]
Email: [email protected] Web: www.clemas.co.uk

MACHINE COMPONENTS

English EN
3
F3/F3+/F8/F129002026 (04ï11)
F3/F3+/F8/F12 Single disc machine
Machine component Accessories Part No.
1 ïHandle bar 9 ïWheels 11 ïScrubbing brush for F8/F3/F3+ low speed 9002236
2 ïBrush motor switch 10 ïMotor head 11 ïPolishing brush for F12/F8 high speed 9002200
3 ïHousing of top shaft element 11 ïBrush 13 ïSolution tank for F8/F3/F3+ low speed 9002256
4 ïSwith lock 12 ïOutlet hose 17 ïDrive plate for F8/F3/F3+ low speed 9002191
5 ïShaft adjustment handle 13 ïSolution tank 17 ïDrive plate for F12/F8 high speed flexible 9002193
6 ïShaft adjustment unit 14 ïTank holder
7 ïBar 15 ïTank lever n/s Spray unit for F12/F8 high speed 9002262
8 ïCable hook 16 ïWater connector Vacuumunit 9002288
Vacuumring 430mm 9002289
8kg extra weight F3/F8 9002304
8kg extra weight F12 9002303
TABLE OF CONTENTS
Machine component 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Accessories 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Instructions 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Machine assembly and operation 4. . . . . . . . . . . . . . . . . . . . . . . .
Service 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trouble Shooting 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Technical specifications 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parts List 121. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PROTECT THE ENVIRONMENT
Please dispose of packaging materials and old
machine components in a safe enviromentally
way according to your local waste disposal regu-
lations.
Always remember to recycle.
Safety Instructions
WARNING: This manual must be read and
understood before operating or servicing machine.
This machine is intended for commercial use. It’s designed
exclusively to burnish hard floors in an indoor environment and
is not constructed for any other use. Only use recommended
pads/brushes and cleaning agents.
These operating instructions are intended for operating staff..
1. Please familiarize yourself with the instructions and
recommendations contained in these operating
instructions before setting up, operating and servicing the
machine.
2. You will then have full control over the machine and use it
efficiently. The care and maintenance described in these
operating instructions are in the interests of your own
safety and preserve the machine’s value.
3. The manufacturer accepts no liability for personal injury
or damage to property due to the incorrect use of this
machine.
This warning alert symbol that is used
throughout this manual is to warn of hazards or unsafe
practices. Failure to follow these may cause electric
shock, fire or explosion which could result in severe
personal injury or death.
Before operating the singleïdisc machine, please read these
instructions carefully and keep them handy at all times. The
singleïdisc machine may only be used by persons trained in its
use and explicitly entrusted with its operation.
WARNING: Fire or Explosion Hazard. Never use
flammable liquids or operate machine in or near
flammable liquids, vapours or combustible dusts.
This machine is not equipped with an explosion proof motor. The
electric motor will spark when powered on which could cause a
flash fire or explosion if machine is used in an area where
flammable vapours/liquids or combustible dusts are present.
WARNING: Electrical Hazard. Never operate
machine with damaged power supply cable. Do not
modify plug. Unplug cable before servicing
machine.
If the power supply cable is damaged or broken, it must be
replaced by the manufacturer or its service agent or a similarly
qualified person in order to avoid a hazard.
This machine is not equipped with an explosion proof motor. The
electric motor will spark when powered on which could cause a
flash fire or explosion if machine is used in an area where
flammable vapours/liquids or combustible dusts are present.
General remarks
The operation of the singleïdisc machine is subject to the
currently valid national regulations. It is essential to observe not
only the operating instructions and the binding regulations on
accident prevention valid in the country of use, but also the
generally acknowledged rules for safe and correct working
procedures. No methods involving safety risks must be used.

EN English
F3/F3+/F8/F129002026 (04ï11)
4
Correct Use
SAll singleïdisc machines are intended exclusively for
use in building interiors.
SAny use beyond this is considered incorrect. The
manufacturer accepts no liability for any resultant
damage; the user alone bears the risk.
SCorrect use also includes adherence to the operating,
servicing and maintenance conditions recommended
by the manufacture.
SThe relevant accident prevention regulations as well
as all the generally acknowledged safety and working
practices must be followed.
SUnauthorized modifications to the machine exclude
the manufacturer’s liability for resultant damage.
SBefore machine use, floorcoverings must be tested for
suitability for this cleaning process.
SPay attention to the area compression of pointïelastic
floors, e.g. in gymnasiums
SThe manufacturer accepts no liability for damage to
equipment and to the floor being cleaned from using
the wrong brushes and cleaning agents.
SMachines may not be used in combination with an
extension cord.
Product Liability
The operator’s attention is drawn explicitly to the fact that the
machines may only be used for their intended purpose. If the
machines are not used for their intended purposes, the user
must accept full responsibility. Any liability of the manufacturer is
thus excluded.
Sources of Risk
WARNING: The singleïdisc machine is not suitable
for cleaning surfaces which release
healthhazardous dusts and liquids. Do not use the
machine on steps.
WARNING: This machine is only intended for use on
level surfaces with a maximum gradient of up to 2
%.
WARNING: This machine is not approved for use on
public paths and roads.
WARNING: Use only the brushes provided with the
appliance or those specified in the instructions. The
use of other brushes may impair safety.
WARNING: When the machine is stationary, the
brush unit must be immediately switched off to
prevent damage to the floorcovering.
WARNING: During transportation in lifts, the
currently valid user instructions and safety
regulations and particularly those concerning
maximum loading must be observed.
Machine operation position
The machine operation position is behind the machine.
Approved maintenance staff
The singleïdisc machine may only be serviced and repaired by
persons with technical and legal authorization.
Cleaning agents
SWhen using cleaning and care agents, the
manufacturer’s danger warnings must be followed and
protective goggles and clothing must be worn.
SOnly use lowïfoaming, nonïcombustible cleaning
agents which do not contain generally
healthïhazardous substances.
Explicit reference is made to the risks of using highly flammable,
combustible, toxic, healthïhazardous, corrosive or irritant
substances.
Machine assembly and operation
Initial operation
SDelivery, instruction on safety procedures, handling
and maintenance and initial operation are generally
carried out by our authorized specialist.
SIf this is not the case, the operator is responsible for
instructing machine users.
SPlease remember that the voltage in the building
being cleaned must concur with that given on the
machine’s type plate.
Assembly instructions
SThe motor head and bar are supplied separately
packed.
SFirst release the hexagon socket screws in the shaft
adjustment unit (6).
SThen feed the bar (7) gently as far as it will go into the
shaft adjustment unit (6).
SAlign the handle bar (1) parallel with the wheels (9),
so that the open side of the housing of the top shaft
element (3) is facing to the rear.
SThen tighten the hexagon socket screws again.
SWind the electric cable around the handle bar (1) and
cable hook (8).
Preparation for use
SGrasp the handle bar (1) with both hands and tip the
machine until it is resting on both wheels (A).
SThen wheel the machine to its place of work and plug
the electric cable into the power supply.
SSet the desired rpm, using the switch mounted at the
motor housing (only for F8 Duo speed)
SLay the accessories (11), i.e. brush or drive plate with
pad, on the floor.
SNow tip the machine back onto the wheels and push it
over the brush (or drive plate) until the drive star and
brush flange are vertically aligned. Lower the machine
onto the brush (B).
SThen squeeze the shaft adjustment lever (5) and
lower the bar (7) into its working position. Both arms
should be extended loosely downwards (C).
SAlign the machine horizontally above the working
element (brush or drive plate), press the switch lock
(4) and press the brush motor switch (2) briefly.
SThe accessory automatically engages.

English EN
5
F3/F3+/F8/F129002026 (04ï11)
Machine operation
SPress the brush motor switch (2) (to the right or left).
The motor starts.
SIf you raise the bar (7) slightly, the machine moves to
the right (D).
SIf you lower the bar, the machine moves to the left (D).
SIf you keep the bar in its central position, the machine
works on the spot.
After use
SSqueeze the shaft adjustment handle (5) and shift the
bar (7) into its vertical position.
SThen tip the machine onto its wheels (9) and press
the brush motor switch (2) briefly. The accessory (11)
disengages.
SRemove the plug from the power socket and wind the
electric cable around the handle bar (1) and cable
hook (8).
Thorough cleaning the easy way
For thorough cleaning, equip your machine with the following
accessories:
SSolution tank (13)
SScrubbing brush (11) or drive plate with pad.
SFasten the tank to the mounting (14).
SSlide the outlet hose (12) onto the water connector
(16).
SFill the tank (13). Then fit the brush or drive plate with
pad.
SControl the flow of liquid with the tank lever (15) by
pulling the lever (15) upwards.
SVacuum the dirty wash solution a section at a time
with a water extractor.
Shampooing thoroughly and efficiently
For shampooing, equip your machine with the following
accessories:
SSolution tank; 0.3 Perlon shampooing brush or pad for
textile floorcoverings.
SThe working procedure is in principle the same as for
thorough cleaning.
SStart the machine with the shampooing brush dry.
SMeter a small amount of liquid until the bristles are
saturated with foam.
SRun the machine with the rotating brush from right to
left or viceversa. Immediately after this, run the
machine in the same way
in the reverse direction, but with an overlap of about a
quarter of the strip already treated (E.)
SOnly then run the machine in a spiral pattern over the
shampooed strips. In doing so, work both strips at
the same time (F.)
SDuring shampooing it is highly advisable to
immediately remove the dirtïladen foam a section at a
time with a water extractor.
Assembly instructions for spray unit
SFit the holder for the spray can to the bar (7) with the
holder pointing upwards and, when viewed from the
operating side, to the left (G).
SHook the spray can’s tongue onto the holder, pivoting
the holder
back until the ball catch engages.
SThen slide the spring clip over the shaft adjustment
unit (7).
SAttach the box on the right or left as desired (H).
SPoint the universalïjointed hose in the desired
direction.
Routine cleaning
For routine cleaning, equip your machine with the following
accessories:
SSpray unit, drive plate for pads, pad for F8/F3 low
speed or Spray unit, drive plate for pads, pad for
F12/F8 high speed
SFill the spray can with the desired product.
SFit the drive plate with the desired pad.
SStart the machine.
SWhen you pull the Spray unit lever a few times the
cleaning agent is sprayed onto the floor. Now start
cleaning immediately until a shine is produced.
SWe advise cleaning the surface in relatively small
areas at a time. The machine is ideal for cleaning with
polymer dispersions. The coating’s resistance to foot
traffic and general wear and tear is preserved.
Streaks and marks are easier to remove.
Polishing with F12/F8 high speed
For polishing, equip your machine with the following
accessories:
SDrive plate for pads, white pad
SFit the drive plate with the pad.
SThen start the machine.

EN English
F3/F3+/F8/F129002026 (04ï11)
6
Service
SFor repairs, please contact your specialist wholesaler
or one of the service shops.
SYou will be expertly and quickly served.
Servicing instructions
The following instructions must always be observed.
SWhen cleaning and servicing the machine, replacing
parts or when changing over to a different function,
switch off the drive and remove the plug.
SThe power supply lead must not be damaged by
driving over it, crushing, tugging etc.
SCheck the power supply lead regularly for signs of
damage.
SThe machine must not be used if the power supply
lead is not in perfect condition.
SWhen using or replacing the power supply or
equipment supply leads, use only those specified by
the manufacturer.
SWhen replacing the plugïandïsocket connectors of
power supply or equipment supply leads, splash
protection and mechanical strength must be assured.
SWhen transporting the machine in lifts, put the
shaft/bar in a vertical position so that it cannot catch
on the lift walls.
SThe shaft/bar is automatically secured against recoil
by the patented shaft/bar adjustment unit.
SOnly the spray and cleaning agents suitable for the
machine’s purpose may be used.
SNever use highly flammable, combustible, toxic,
healthïhazardous, corrosive or irritant substances.
SRepairs, including the fitting of spray agent lines and
hoses, may only be carried out by approved customer
service shops or by specialists in this field who are
familiar with all the relevant safety regulations.
Storage
SRemove brush/pad driver from machine and neatly
coil cord around cord hook and handle.
SStore the machine in a dry place and in normal room
conditions (not below under 0_C)

English EN
7
F3/F3+/F8/F129002026 (04ï11)
Trouble Shooting
Problem Cause Solution
Machine does not operate Faulty power cord. Contact Service Center.
Tripped circuit breaker Wait 10 min. till machine cooled down and
try again.
Faulty machine wiring. Contact Service Center
Faulty motor. Contact Service Center
Capacitor burned out. Contact Service Center
Machine operates with a wobbleor jerky
motion. Soiled Pad. Replace Pad
Improper pad/brush for application. Change to proper pad/brush
Pad driver/brush not installed correctly. Remove and reinstall pad driver/brush
Pad/brush unevenly worn. Replace pad/brush
Pad not properly centered on pad driver Remove and reinstall pad driver
Machine circuit breaker trips continuously. Heavily soiled pad/brush Clean or replace pad/brush
Improper pad/brush for application Change to proper pad/brush
Defective circuit breaker. Contact Service Center
Worn carbon brushes in motor. Contact Service Center
Technical specifications F3 low speed F3+ low speed F8 high speed F12 Duo speed
A.C. motor 230 V: 50 Hz 230 V: 50 Hz 230 V: 50 Hz 230 V: 50 Hz
Rated power 1000 W 1000 W 1100 W 1200/1500 W
Max.amp draw 5,5 A 5,5 A 5,5 A 5,2 / 8,1 A
Brush (rpm) 165 165 400 170/340
Brush (mm) 430 430 430 430
Working height (mm) 250 250 250 250
Working weight 31 kg 43 kg 31 kg 37 kg
Protection class lPx4 lPx4 lPx4 lPx4
Beltïdriven x x x x
Sound pressure level LPA 59db (A) 59db (A) 59db (A) 65db
Weighted acceleration value 1.05 m/sec2 1.05 m/sec2 1.05 m/sec2 1.05 m/sec2
Richard van den Hoogen ï
Safety, Compliance, Documentation & Certification
EC DECLARATION OF CONFORMITY FOR MACHINERY (Annex II, sub A)
TENNANT N.V.
Address: Industrielaan 6 5405 AB
P.O. Box 6 5400 AA UdenïThe Netherlands
Model: F3, F3+, F8, F12
EN
Uden/Netherlands, 25ï1ï2010
Herewith declares, on our own responsibility, that the machinery
ïis in conformity with the provisions of the Machinery Directive (2006/42/EC), as amended
with national implementing legislation
ïis in conformity with the provisions of the E.M.C. Directive 2004/108/EC.
and that
ïthe following (parts/clauses of) harmonized standards have been applied: EN ISO 14121ï1,
EN 1037, EN 60335ï1, EN 60204ï1, EN ISO 13849ï1, EN ISO 13849ï2, EN 60529, EN ISO 4413,
EN 349, EN 61000ï3ï2, EN 61000ï3ï3, EN 61000ï6ï2, EN 61000ï6ï3, EN 55014ï1, EN ISO 11201,
EN ISO 4871, EN ISO 5349ï1, EN ISO 5349ï2, EN 60335ï2ï67.
ïthe following (parts/clauses of) national technical standards and specifications have been used: NA
