Clementi PULCINELLA Series User manual

TROLLEY
ASSEMBLY INSTRUCTIONS
PULCINELLA LINE

Take 2 pieces (fig.6) and fix them
(with the screws supplied) to the
shelf (fig.4) matching the holes.

Fix the 4 legs (fig. 1and 2)
with the shelf under the trolley
by matching the holes
and using the screws supplied,
like in the illustration above.

Enter the piece of metal (fig. 11)
A
DETAIL A
Always with the screws supplied,
fix 4 front crossbar (fig. 3 and 9)
with the legs (fig. 1 and 2)
by matching the holes.
At the same time, fix 2 pieces of metal (fig. 11)
on left and on the right like in the detail A

Enter the wheels (fig. 7)
and the axis for the wheels (fig. 8)
like illustrated in the image,
then use the metallic piece
to stop the wheels (see detail B)
After entering the axis for the
wheels (fig. 8) put the metallic piece
in the hole and turn the two tabs
(see the picture)
DETAIL B

insert the handles (fig. 10)
on both the sides of the trolley,
like illustrated in the image,
then insert the screw on both the handles
(see DETAIL C)
DETAIL C

always using the screws supplied,
insert the logo (fig. 12)
as illustrated in the images
