Clever AirPro X1 User manual

1 PERSON KAYAK INSTRUCTIONS

SAFETY INSTRUCTIONS - READ CAREFULLY!
1. Maximum operating pressure: 0.05 bar (0.725psi).
2. Over inflation will increase the risk of bursting.
3. Not intended for mechanical propulsion.
4. This Kayak does not contain flotation material and may sink when flooded.
5. Area of use: protected coastal zones to 300m.
6. Warning: in offshore winds and currents, do not use in high wind speeds or wave heights greater than 0.5m
Paddlesports can be very dangerous and physically demanding. The user of this product should understand
that participating in paddlesports may involve serious injury or death. Observe the following safety standards
whenever using this product:
• Read the instruction manual carefully before use.
• Obtain certified first aid training and carry first aid and safety/rescue equipment.
• It is recommended to always use a nationally approved personal flotation device.
• Always wear a helmet where appropriate.
• Dress appropriately for weather conditions, cold water and/or cold weather can result in hypothermia.
• Never paddle alone. Make sure you are accompanied at all times.
• Do not paddle in flood conditions.
• Be aware of appropriate river water levels, tidal changes, dangerous currents and weather changes.
• Scout unfamiliar waters and places to port at shore where appropriate.
• Do not exceed your paddling ability.
• Consult a doctor prior to beginning your paddle sports training.
• You must not use alcohol or mind altering medication prior to, or during use of this product.
• Follow the manufacturer’s recommendations for the use of this product.
• If additional outfitting is added to this craft, use manufacturer’s approved material only; do not impair
entry or exit access.
Safety Instructions 3
Parts list 4
How to attach the stabilising fins 5
How to assemble the Kayak paddle 6
Setting up your Airpro® X1 Kayak 7
How to fit the inflatable backrest 8
Care / Repair / Disposal 9
Returns 10
Warranty 1 1
Use / Contact Us 12
CONTENTS
3

4
Part No. Description Quantity
A Airpro® X1 Inflatable Kayak 1
B Cargo Net (Installed) 1
C Inflatable Back Rest & Tie Cord 1
D Clip on Stabilising Fins 2
E Paddle Fins 2
F Paddle Poles 3
G Paddle Grips 2
H Paddle Locking Screws 6
I 3L Foot Pump 1
J Foot Pump Inflation Hose 1
Airpro® X1 Inflatable Kayak Part List.
Please check all parts are present in your box before first use.
B
J
G
A
I
F
C D
E H
PARTS LIST

5
5
6
FRONT
4
Fitting the stabilising fins
Turn the Kayak (A) over and lay
top down on a flat even surface,
making sure it is clear of any
sharp objects.
Locate the fin locking positions
fixed to the underside of the
hull (2/3).
(4) Align the fin (1) as shown so
the arc faces toward the front
of the Kayak.
(5) Clip one of the fins into the
slotted fitting of the front
locking clip.
(6) Fix the back of the fin into
the rear locking slot.
Repeat these steps for the 2nd fin.
2
3
1
A
HOW TO ATTACH THE STABILISING FINS
Note: We recommend installing
the fins before inflating the Kayak.
D

6
Paddles
Slide locking screw (H) over end
of pole (F). Push paddle fin (E)
onto end of pole (F) and tighten,
screw (H).
Handles
Slide locking screw (H) over
opposite end of paddle pole (F),
push fit paddle grip (G) and tighten
locking screw (H).
Repeat these steps to assemble the
opposite end of the paddle.
Slide on x2 locking screws (H) on
to the remaining paddle pole (F),
push fit into open end of paddle
grip (G) and tighten.
Airpro® X1 Kayak Features
E
F
H
H
H
G
F
E
H
1
2
3
1
1
2
2
F
F
G
H
H
3
3
1 2 3
4
Once assembled the paddle can be
stored in the clips on the side of the
inflated Kayak for easy access (5).
5
B
The Airpro® X1 is equipped with a
cargo net to the front of the Kayak
for easy storage of items (B).
The Airpro® X1 has 3x inflation valves
for the base (1), Sides (2) & Top (3).
The Airpro® X1 backrest will be fixed
to the eyelet (4)
HOW TO ASSEMBLE THE KAYAK PADDLE

7
Inflating Kayak Sides (2) & Top (3)
Inflating Kayak Base (1)
Deflate: Unscrew the lower
part of the inflation valve
to release the air.
Inflate: Insert the pump hose (I) into
the valve and inflate as shown below.
Screw the top cap on once finished
Locate the inflation valve for
the side/top of the Kayak (2/3).
Unscrew the upper valve cap.
Once inflated press the cap back
in place and push firmly to recess
the valve into the base.
Locate the inflation valve
for the Kayak base (1)
and remove the cap.
Inflating the Kayak
• Maximum operating pressure: 0.05 bar (0.725psi).
• Avoid excessive inflation of the air chambers to prevent danger of the material stretching or the seams tearing.
• Please use the foot pump provided with this purchase. Use of a high pressure pump may damage the product and void your warranty.
• Do not use a compressor or a compressed air bottle to inflate the article as this can cause over inflation.
• Completely inflate all of the air chambers.
• The PVC material will stretch a little following initial inflation and will never return to its original size.
• Pump up the air chambers so that they feel firm to the touch and no wrinkles can be seen in the material. Press on each air
chamber with your thumb – the chambers should be firm to the touch.
Note: We recommend inflating the Kayak in the order listed below. Lay out the Kayak (A) on a flat even surface, making sure it is clear
of any sharp objects.
1. Inflate base of the Kayak using the clear inflation valve.
2. Inflate the Kayak sides using the rapid inflate valve.
3. Inflate the Kayak top using the rapid inflate valve.
Insert the pump hose (I)
into the valve and inflate
as shown.
SETTING UP YOUR AIRPRO® X1 KAYAK
Using the Foot Pump
Use the foot pump (H) to inflate
the Kayak (A) until firm,
being careful not to over inflate.
Firmly push the end of the hose (H)
into the desired inflation valve.
Push the inflation hose (J) into the
‘inflate’ valve on the foot pump (I)
and twist clockwise to lock.

8
Inflating the backrest
Lay out the Kayak backrest (C) on a flat even surface, making
sure it is clear of any sharp objects. Locate the inflation valve (1)
on the lower rear of the backrest (C) and remove the valve cap.
Inflate the Kayak backrest using the foot pump as directed.
Fitting the Backrest
Insert the backrest (C) into the rear of the Kayak seating area
with the backrest “arms” against the Kayak floor.
Locate the eyelet on the rear of the backrest (2) and
corresponding one on the Kayak top (3). Using the backrest
tie cord, loop it through both eyelets and securely tie a knot
to secure the backrest.
HOW TO FIT THE INFLATABLE BACKREST
1
2
3
C

CARE / MAINTENANCE / STORAGE
Only use care products that do not contain traces of acids or petroleum and never use silicone-based products.
• Clean your Kayak thoroughly after every use with fresh water and mild soap to remove salt crystals, sandy granules and
other small dirt particles. Leave it to dry completely.
• Deflate the parts of the Kayak by removing the stoppers from the relevant valves and remove all of the air.
• Lay both of the upper side pipes into the inside of the Kayak and fold them together carefully.
• Store your Kayak in a clean and dry place away from direct sunlight and somewhere where there are no great temperature
fluctuations. Pay attention to the fact, that the Kayak is not wrinkled but lays flat, and keep well out of the reach of rodents.
• All inflatables are sensitive to cold. The Kayak should never be unfolded and inflated at a temperature under 10°C!
• If the atmospheric pressure increases under the blazing sun, this must be compensated by releasing some air from the craft.
• Try to ensure that the Kayak (particularly when inflated) does not come into contact with stones, gravel or sharp objects,
and that it is not dragged or pulled along the ground because this can damage the Kayak‘s skin.
• Only insert suitable pump adaptors into the valve. The wrong type of pump adaptor can damage the valve.
REPAIRING YOUR KAYAK
You should not attempt to repair large damaged sections by yourself. You can repair small areas with the enclosed repair kit.
1. Deflate the Kayak completely and clean the area to be repaired with an alcohol-based solution. Roughen up the damaged area
surrounding the hole or tear with a fine sand paper.
2. Cut a patch to cover the damaged area. The patch should overlap the damaged area by at least 1.25cm on all sides.
3. Apply the glue to the Kayak as well as to the patch. Allow to dry for approx. 3 minutes.
4. Press the patch down firmly using a soft object. Make sure that you are working on a flat, even surface. Remove any air bubbles
with a rounded object, gently pushing the bubbles in an outward direction.
5. Always wait at least 12 hours after a repair before pumping up the Kayak once again.
DISPOSING OF YOUR KAYAK
Please dispose of the product and packaging in an environmentally friendly manner, separating different materials for recycling
as required! Dispose of this item through an authorised disposal company or through your local waste disposal facilities - ask your
local authority for information if further guidance is required. Ensure that you comply with all regulations currently in force.
9
CARE / REPAIR / DISPOSAL
100kg1
MAXIMUM USER & WEIGHT

10
CHANGED YOUR MIND AND NEED TO RETURN YOUR KAYAK? FOLLOW THE BELOW INSTRUCTIONS:
• Purchased from a UK retailer: If you have purchased an Airpro® Kayak from a UK retailer and have
simply changed your mind, follow the retailers instructions for returns. This will normally require
proof of purchase.
• Purchased from Clever Company: If you have purchased directly from our website, then please contact
us and we will email you instructions for the return of the product. Contact can be made by email or
telephone as detailed in the ‘Warranty Claims’ section.
When posting your items back to us, it’s important you clearly mark your parcel with your order number
and full name. Ship your unused product, in its original packaging, to the address identified in our email.
Again, we recommend that you keep your receipt or order number in a safe place, as you will need it as
proof of purchase in the event of any after-sales query.
POINTS TO NOTE:
• Under the Distance Selling Regulations, as a consumer you have the right to cancel your order
and return the goods if we are notified within a period of 14 days after delivery of the goods.
• You are responsible for shipping the products back to us. We recommend using a traceable
shipping method.
• If you choose to cancel your order, we require you, the consumer, to pay the cost of returning
the item to us.
• Individual products may be excluded from this guarantee. Check the product description before
you place your order.
• We can’t take responsibility for any missing or damaged parcels, so take care when returning
your order to us.
If the return is due to any form of product defect, call [phone] to initiate the return.
In these cases, you may be compensated for the cost of returning the item.
REFUNDS ON ITEMS PURCHASED THROUGH CLEVERCOMPANY.COM
Once the items are received by our warehouse, they will be processed and a refund initiated. Your account
should be credited within a maximum of 10 business days from the time that the return is received.
DEFECTIVE ITEMS
If your item is defective in any way, i.e. it doesn’t work but you can’t identify why, in the first instance
please consult our FAQ section at clevercompany.com as there may be a simple solution to the issue,
if this does not help to resolve the issue, please call us on [phone] or email:
[e-mail] for assistance.
DAMAGED ITEMS
Purchased from a UK Retailer: If you receive an order with obvious shipping damage from the retailer,
then we suggest the delivery is refused. If the delivery has been accepted and then shipping damage
is found, please follow the specific instructions advised by the retailer.
Purchased from clevercompany.com: If you receive an order with obvious shipping damage please
refuse the delivery. If you have accepted delivery and then find shipping damage, please call the fulfiller
immediately using the contact information included with the order.
In all circumstances please save all packaging material and paperwork for the order. Please be aware that
if you dispose of packaging material or attempt to return the merchandise without contacting the fulfiller,
you jeopardise your chances of making a claim, and you may not receive a credit for the return.
LIMITS OF RESPONSIBILITY
Clever Company accept no responsibility for misuse or user damage and/or loss of parts incurred during
operation or use of the Airpro® Kayak Range.
RETURNS

11
This warranty relates to all Airpro® Kayaks bought in the UK and covers the following areas:
• 6 months from the date of purchase
This warranty is not transferable if the goods are resold after the original purchase.
Your Airpro® Kayak is designed and manufactured for domestic use only. The Airpro® Kayak Warranty
does not extend to any commercial businesses operating in the rental of Kayaks.
REGISTERING YOUR WARRANTY
To register your warranty, visit clevercompany.com and complete the form within 28 days of purchase.
The warranty will start from the date of purchase which must be verified by proof of purchase.
For up-to-date troubleshooting advice, technical information and FAQs please visit our online help
centre at clevercompany.com.
WARRANTY CLAIMS
Before making a claim, we may be able to answer your query to common questions, simply visit
clevercompany.com for further information.
If the FAQs don’t solve the issue and you need to make a claim, please visit our website under the
warranty section for further instructions. Alternatively, please contact our dedicated Aftersales Team by
email at: [e-mail] - we will endeavour to answer all email messages within 48 hours.
If you need to make immediate contact our Aftersales Team are available on
[phone].
Monday – Thursday: 9.00am to 5.00pm
Friday: 9.00am to 4.00pm
WARRANTY

INTENDED USE
The Kayak has been designed for private use.
Area of use: Protected shoreline up to 300m – for journeys in protected coastal waters, small bays, on small lakes, narrow rivers
and canals. Do not use in windy conditions above Beaufort Scale 4 or with a wave height of over 0.5m.
CODE OF CONDUCT / SAFETY NOTICE
This Kayak is a tested and safe piece of water sports equipment. We urgently ask you to comply with the following rules and
regulations:
WARNING!
• Your care and self-assessment on the water is extremely important. Never over-estimate your power and steering skills!
Remain close to the shore! Keep a constant eye on the weather, storm warnings and possible flare signals!
• Please always follow the safety regulations and laws applicable to lakes and open water, and for your own safety, always wear
a tested life-jacket.
• Never allow children to play unsupervised with the packaging materials, or the article itself.
• If a person happens to have fallen overboard, their rescue must take place via the front or rear of the craft. Re-entry at the side
can cause the craft to capsize.
• Be cautious in offshore winds and currents!
• Please note that the weight of the occupants of the craft as well as the luggage must be uniformly distributed otherwise the
Kayak can capsize.
• Follow the information on the type plate regarding the permitted weight allowance and number of occupants as well as the
warning information.
• Always keep to the local navigation regulations.
• Do not carry any sharp or pointed objects.
• The Kayak should be protected against contact with dubious liquids or acids to avoid irreparable damage.
• Protect the Kayak against heat and fire! Take care with lit cigarettes!
• Make sure you do not run aground on stony subsoil to avoid damage to the underside of the Kayak.
• Should damage to one of the five inner chambers occur whilst afloat, do not abandon the Kayak. The floatation force of the
four intact inner chambers is sufficient to maintain the Kayak safely on the water.
• Never transport the Kayak in vehicles when inflated.
• Never leave your unoccupied Kayak on the water. It can be swept away faster than you can swim after it.
• Always carry the paddle with you when using the Kayak otherwise you will not be able to manoeuvre it.
• Do not attempt to make any technical changes to your Kayak. Changes of any kind endanger the operation of this device.
• Never use your Kayak under the influence of alcohol, drugs or medicinal products.
• Never overestimate your own strength and divide your muscular strength with the paddle in such a way that the distance you
have paddled away from the shore can be easily paddled back again. Stay in protected coastal areas, no more than 300m
away, and pay attention to varying winds and currents which can complicate your movement.
Clever Company: Oldgate, St.Michael’s Industrial Estate, Widnes, Cheshire, WA8 8TL
USE / CONTACT US
For General Enquiries, Returns, Spare Parts, Repairs
Contact us on freephone:
[phone] or visit: clevercompany.com
