Clevo P150EM User manual

I
Introduction (English)
This Concise User’s Guide introduces the main features
of your computer. The English version of this guide be-
gins on page 1. The expanded User’s Manual is on the
Device Drivers & Utilities + User’s Manual disc.
Einführung (Deutsch)
Dieses Ausführliche Benutzerhandbuch führt Sie in die
Hauptfunktionen des Computers ein. Die deutsche Ver-
sion des Handbuchs beginnt auf Seite 39. Das erweiterte
Benutzerhandbuch finden Sie auf der Disc für die Gerä-
tetreiber und Hilfsprogramme (Disc Device Drivers &
Utilities + User's Manual).
Présentation (Français)
Ce Guide Utilisateur Concis présente les fonctionnalités
principales de votre ordinateur. La version française de
ce guide commence à la page 77. Le Manuel de l'Utilisa-
teur étendu se trouve sur le disque de Pilotes & Utili-
taires + Manuel de l'Utilisateur (disque Device Drivers
& Utilities + User's Manual).
Introducción (Español)
Esta Guía del Usuario Concisa le presenta las caracterís-
ticas principales de su ordenador. La versión española de
esta guía comienza en la página 115. El Manual del usua-
rio completo se encuentra en el disco de Controladores
del dispositivo y Utilidades + Manual del usuario (disco
Device Drivers & Utilities + User's Manual).
Introduzione (Italiano)
La presente Guida Rapida per l'Utente introduce le carat-
teristiche principali del computer. La versione italiana di
questa guida inizia da pagina 153. Il Manuale utente
completo si trova nel disco contenente driver e utilità +
Manuale utente (disco Device Drivers & Utilities +
User's Manual).

II
Contents
About this Concise User Guide .........................................................1
System Startup ..................................................................................4
System Software ...............................................................................5
RAID Setup for Windows 7 (Model C Only) ...................................5
System Map: Front View with LCD Panel Open .............................7
LED Indicators ..................................................................................8
Keyboard & Function Keys ..............................................................9
Control Center .................................................................................11
System Map: Front, Left, Right & Rear Views (Models A & B) ...13
System Map: Front, Left, Right & Rear Views (Model C) ............14
System Map: Bottom Views ...........................................................15
Windows Control Panel & Desktop ................................................16
Video Features ................................................................................17
Power Options .................................................................................19
Audio Features ................................................................................19
Driver Installation ...........................................................................22
PC Camera (Option) .......................................................................24
Wireless LAN Module (Option) ....................................................26
Intel® Wireless Display Application ..............................................28
Fingerprint Reader (Option) ...........................................................29
Bluetooth Module (Option) .............................................................30
Intel® Rapid Storage Technology ..................................................32
Intel® Rapid Start Technology .......................................................33
Troubleshooting ..............................................................................35
Specifications ..................................................................................36
Inhalt
Über das Ausführliche Benutzerhandbuch ......................................39
Schnellstart ......................................................................................42
RAID Setup für Windows 7
(Nur Modell C) ................................................................................43
Systemübersicht: Ansicht von vorne mit geöffnetem
LCD-Bildschirm ..............................................................................45
LED-Anzeigen ................................................................................46
Tastatur & Funktionstasten .............................................................47
Control Center (Steuerzentrum) ......................................................49
Systemübersicht: Ansicht von vorne, links, rechts und hinten
(Modelle A & B) .............................................................................51
Systemübersicht: Ansicht von vorne, links, rechts und hinten
(Modell C) .......................................................................................52
Systemübersicht: Ansicht von unten ...............................................53
Windows Systemsteuerung und Arbeitsplatz ..................................54
Grafikfunktionen .............................................................................55
Energieoptionen ..............................................................................57
Audiofunktionen ..............................................................................57
Installation der Treiber ....................................................................60
PC-Kamera (Option) .......................................................................62
Wireless-LAN-Modul (Option) .......................................................64
Intel® Wireless Display Application ..............................................66
Fingerabdruckleser (Option) ...........................................................67
Bluetooth-Modul (Option) ..............................................................68
Intel® Rapid Storage Technology ...................................................70
Intel® Rapid Start Technology .......................................................71
Fehlerbehebung ...............................................................................73
Technische Daten ............................................................................74

III
Sommaire
A propos de ce Guide Utilisateur Concis ........................................77
Guide de démarrage rapide .............................................................80
Logiciel système .............................................................................81
Configuration RAID pour Windows 7 (Modèle C seulement) .......81
Carte du système: Vue de face avec l’écran LCD ouvert ...............83
Indicateurs LED ..............................................................................84
Clavier & touches fonction .............................................................85
Control Center (Centre de contrôle) ...............................................87
Carte du système: Vues de face, gauche, droite & arrière
(Modèles A & B) ............................................................................89
Carte du système: Vues de face, gauche, droite & arrière
(Modèle C) ......................................................................................90
Carte du système: Vues du dessous ................................................91
Windows Control Panel & Desktop ................................................92
Caractéristiques vidéo .....................................................................93
Options d’alimentation ....................................................................95
Caractéristiques audio .....................................................................95
Installation du pilote .......................................................................98
Caméra PC (Option) .....................................................................100
Module LAN sans fil (Option) ......................................................102
Application Intel® Wireless Display ............................................104
Lecteur d'empreintes digitales (Option) ........................................105
Module Bluetooth (Option) ...........................................................106
Intel® Rapid Storage Technology ................................................108
Intel® Rapid Start Technology .....................................................109
Dépannage .....................................................................................111
Spécifications ................................................................................112
Contenidos
Acerca de esta Guía del Usuario Concisa .....................................115
Guía rápida para empezar ..............................................................118
Configuración RAID para Windows 7 (sólo Modelo C) .............119
Mapa del sistema: Vista frontal con panel LCD abierto ...............121
Indicadores LED ...........................................................................122
Teclado & teclas de función ..........................................................123
Control Center (Centro de control) ...............................................125
Mapa del sistema: Vistas frontal, izquierda, derecha, y posterior
(Modelos A & B) ...........................................................................127
Mapa del sistema: Vistas frontal, izquierda, derecha, y posterior
(Modelo C) ....................................................................................128
Mapa del sistema: Vistas inferior ..................................................129
Panel de Control y escritorio de Windows ....................................130
Parámetros de vídeo ......................................................................131
Opciones de energía ......................................................................133
Características de audio .................................................................133
Instalación de controladores ..........................................................136
Cámara PC (Opción) .....................................................................138
Módulo LAN Wireless (Opción) ...................................................140
Intel® Wireless Display Application ............................................142
Lector de huellas digitales .............................................................143
Módulo Bluetooth (Opción) ..........................................................144
Intel® Rapid Storage Technology .................................................146
Intel® Rapid Start Technology .....................................................147
Solución de problemas ..................................................................149
Especificaciones ............................................................................150

IV
Sommario
Informazioni sulla Guida Rapida per l'Utente ..............................153
Guida di avvio rapido ....................................................................156
Software del sistema .....................................................................157
Configurazione RAID per Windows 7 (solo Modello C) .............157
Descrizione del sistema: Vista anteriore con pannello
LCD aperto ....................................................................................159
Indicatori LED ..............................................................................160
Tastiera & tasti funzione ...............................................................161
Control Center (Centro di controllo) .............................................163
Descrizione del sistema: Vista anteriore, sinistra, destra e posteriore
(Modelli A & B) ............................................................................165
Descrizione del sistema: Vista anteriore, sinistra, destra e posteriore
(Modello C) ...................................................................................166
Descrizione del sistema: Vista inferiore .......................................167
Pannello di controllo e Desktop di Windows ...............................168
Funzioni video ..............................................................................169
Opzioni risparmio energia .............................................................171
Funzionalità audio .........................................................................171
Installazione driver ........................................................................174
Camera PC (Opzione) ...................................................................176
Modulo LAN Wireless (Opzione) ................................................178
Intel® Wireless Display Application ............................................180
Lettore d’impronte digitali (Opzione) ...........................................181
Modulo Bluetooth (Opzione) ........................................................182
Intel® Rapid Storage Technology ................................................184
Intel® Rapid Start Technology .....................................................185
Risoluzione dei problemi ..............................................................187
Specifiche tecniche .......................................................................188

1
English
About this Concise User Guide
This quick guide is a brief introduction to getting your system started. This is a supplement, and not a substitute for the
expanded English language User’s Manual in Adobe Acrobat format on the Device Drivers & Utilities + User’sManual
disc supplied with your computer. This disc also contains the drivers and utilities necessary for the proper operation of
the computer (Note: The company reserves the right to revise this publication or to change its contents without notice).
Some or all of the computer’s features may already have been setup. If they aren’t, or you are planning to re-configure
(or re-install) portions of the system, refer to the expanded User’s Manual. The Device Drivers & Utilities + User’s
Manual disc does not contain an operating system.
Regulatory and Safety Information
Please pay careful attention to the full regulatory notices and safety information
contained in the expanded User’s Manual on the Device Drivers & Utilities + Us-
er’s Manual disc.
© October 2012
Trademarks
Intel and Intel Core are trademarks/registered trademarks of Intel Corporation.

FCC Statement
This device complies with Part
15 of the FCC Rules. Operation
is subject to the following two
conditions:
1.This device may not cause
harmful interference.
2.This device must accept any
interference received, includ-
ing interference that may
cause undesired operation.

2
English
Instructions for Care and Opera-
tion
The computer is quite rugged, but it can be damaged. To
prevent this, follow these suggestions:
•Don’t drop it, or expose it to shock. If the computer falls, the
case and the components could be damaged.
•Keep it dry, and don’t overheat it. Keep the computer and
power supply away from any kind of heating element. This is an
electrical appliance. If water or any other liquid gets into it, the
computer could be badly damaged.
•Avoid interference. Keep the computer away from high capacity
transformers, electric motors, and other strong magnetic fields.
These can hinder proper performance and damage your data.
•Follow the proper working procedures for the computer. Shut
the computer down properly and don’t forget to save your work.
Remember to periodically save your data as data may be lost.
• Note that in computer’s featuring a raised LCD electro-plated
logo, the logo is covered by a protective adhesive. Due to general
wear and tear, this adhesive may deteriorate over time and the
exposed logo may develop sharp edges. Be careful when handling
the computer in this case, and avoid touching the raised LCD
electro-plated logo. Avoid placing any other items in the carrying
bag which may rub against the top of the computer during trans-
port. If any such wear and tear develops contact your service cen-
ter.
Power & Battery Safety
• Only use an AC/DC adapter approved for use with this computer.
• Use only the power cord and batteries indicated in this manual.
• Your AC/DC adapter may be designed for international travel but
it still requires a steady, uninterrupted power supply. If you are
unsure of your local power specifications, consult your service
representative or local power company.
• The AC/DC adapter may have either a 2-prong or a 3-prong
grounded plug. The third prong is an important safety feature; do
not defeat its purpose. If you do not have access to a compatible
outlet, have a qualified electrician install one.
• When you want to unplug the power cord, be sure to disconnect it
by the plug head, not by its wire.
• Make sure the socket and any extension cord(s) you use can sup-
port the total current load of all the connected devices.
• Make sure that your computer is completely powered off before
putting it into a travel bag (or any such container).
• Only use batteries designed for this computer. The wrong battery
type may explode, leak or damage the computer.
• Do not continue to use a battery that has been dropped, or that
appears damaged (e.g. bent or twisted) in any way. Even if the
computer continues to work with a damaged battery in place, it
may cause circuit damage, which may possibly result in fire.
• Recharge the batteries using the computer’s system. Incorrect
recharging may make the battery explode.
• Do not try to repair a battery pack. Refer any battery pack repair
or replacement to your service representative or qualified service
personnel.
• Keep children away from, and promptly dispose of a damaged
battery. Always dispose of batteries carefully. Batteries may
explode or leak if exposed to fire, or improperly handled or dis-
carded.
• Keep the battery away from metal appliances.
• Affix tape to the battery contacts before disposing of the battery.
• Do not dispose of batteries in a fire. They may explode. Check
with local codes for possible special disposal instructions.
• Do not touch the battery contacts with your hands or metal
objects.

3
English
Polymer Battery Precautions
Note the following information which is specific to poly-
mer batteries only, and where applicable, this overrides
the general battery precaution information.
• Polymer batteries may experience a slight expansion or swelling,
however this is part of the battery’s safety mechanism and is not a
cause for concern.
• Use proper handling procedures when using polymer batteries.
Do not use polymer batteries in high ambient temperature envi-
ronments, and do not store unused batteries for extended periods.
Cleaning
• Use a soft clean cloth to clean the computer, but do not apply
cleaner directly to the computer.
• Do not use volatile (petroleum distillates) or abrasive cleaners on
any part of the computer.
• Before cleaning the computer remove the battery and make sure
the computer is disconnected from any external power supplies,
peripherals and cables (including telephone lines).
Servicing
Attempting to service the computer yourself may violate
your warranty and expose you and the computer to electric
shock. Refer all servicing to qualified service personnel,
particularly under any of the following conditions:
• When the power cord or AC/DC adapter is damaged or frayed.
• If the computer has been exposed to any liquids.
• If the computer does not work normally when you follow the
operating instructions.
• If the computer has been dropped or damaged (do not touch the
poisonous liquid if the LCD panel breaks).
• If there is an unusual odor, heat or smoke coming from your com-
puter.

Battery Disposal & Caution
The product that you have purchased contains a recharge-
able battery. The battery is recyclable. At the end of its use-
ful life, under various state and local laws, it may be illegal
to dispose of this battery into the municipal waste stream.
Check with your local solid waste officials for details in your
area for recycling options or proper disposal.
Danger of explosion if battery is incorrectly replaced. Re-
place only with the same or equivalent type recommended
by the manufacturer. Discard used battery according to the
manufacturer’s instructions.

4
English
System Startup
1. Remove all packing materials.
2. Place the computer on a stable surface.
3. Insert the battery and make sure it is locked in position.
4. Securely attach any peripherals you want to use with the
computer (e.g. keyboard and mouse) to their ports.
5. Attach the AC/DC adapter to the DC-In jack at the rear of the
computer, then plug the AC power cord into an outlet, and
connect the AC power cord to the AC/DC adapter.
6. Use one hand to raise the lid/LCD to a comfortable viewing
angle (do not to exceed 135 degrees);
use the other hand (as
illustrated in Figure 1) to support the base of the computer
(Note: Never lift the computer by the lid/LCD).
7. Press the power button to turn the computer “on”.
Model Differences
This notebook series includes three different model types
that mainly differ as indicated in the table below.
Table 1 - Model Differences Figure 1 - Opening the Lid/LCD/Computer with AC/DC
Adapter Plugged-In
Feature Model A Model B Model C
Video Adapt-
ers Supported See Specifications on page 36 for a full list of
video adapters supported by each model.
Display Type 15.6" (39.62cm) FHD 17.3"
(43.94cm) FHD
Illuminated
Keyboard Yes No Yes
RAID Not Supported Supported
AC/DCAdapter 19V, 9.47A
(180W)19V, 6.3A (120W)19V, 11.57A (220W)
135 ﾟ

Shut Down
Windows 7
Note that you should always shut your computer down by
choosing Shut Down from the Start menu.
Windows 8
Note that you should always shut your computer down by
clicking Settings in the Charms Bar (use the Windows
Logo Key + Ckey combination to access the Charms
Bar) and choosing Shut down from the Power menu.
This will help prevent hard disk or system problems.

5
English
System Software
Your computer may already come with system software
pre-installed. Where this is not the case, or where you are
re-configuring your computer for a different system, you
will find this manual refers to Microsoft Windows 7 and
8.
HDD RAID Support (Model C Only)
Your hard disk(s) can be set up in AHCI mode or RAID
mode (for increased performance or protection). Note that
setting up your hard disk(s) in RAID mode needs to be
done prior to installing the Windows OS.
RAID Setup for Windows 7
See RAID Setup for Windows 7 (Model C Only) on
page 5.
RAID Setup for Windows 8
Refer to the expanded User’s Manual on the Device Driv-
ers & Utilities + User’s Manual disc.
RAID Setup for Windows 7
(Model C Only)
You may use your hard disks incombination with Striping
(RAID 0), Mirroring (RAID 1), or Recovery for either
fault tolerance or performance.
Table 2 - RAID Description
RAID Level Description
RAID 0
(at lease two
hard disks
needed)
Identical drives reading and writing data in parallel
to increase performance. RAID 0 implements a
striped disk array and the data is broken into
blocks and each block is written to a separate disk
drive.
RAID 0 (a striped array) is not fault-tolerant. The
failure of one drive will result in the loss of all data
in the array.
RAID 1
(at lease two
hard disks
needed)
Identical drives in a mirrored configuration used to
protect data. Should a drive that is part of a mir-
rored array fail, the mirrored drive (which contains
identical data) will handle all the data. When a new
replacement drive is installed, data to the new
drive is rebuilt from the mirrored drive to restore
fault tolerance.
RAID 1 (mirrored array) provides full data protec-
tion, as data can simply be copied from a healthy
disk to a replacement for any failed disk.
Recovery
(at lease two
hard disks
needed)
Two identical drives copying data between a mas-
ter and a recovery disk. This provides more control
over how data is copied between the master and
recovery drives, fast volume updates and the abil-
ity to view the data in Windows Explorer.

6
English
Prepare the following before setting up your serial ATA
hard disks in RAID mode:
• The Microsoft Windows 7 OS disc.
• The Device Drivers & Utilities + User’s Manual disc.
Note: All hard disks in a RAID should be identical (the
same size and brand) in order to prevent unexpected sys-
tem behavior.
RAID Setup Procedure
Part I: BIOS
1. Start-up your computer and press F2 to enter the BIOS.
2. Go to the Advanced menu, select SATA Mode and press
Enter.
3. Select RAID Mode.
4. Press Esc and go to the Boot menu.
5. Set the CD/DVD-ROM Drive (make sure the Microsoft
Windows OS disc is inserted) as the first device in the boot
order from the Boot menu.
6. Select Save Changes and Reset from the Exit menu (or press
F4) and press Enter to exit the BIOS and reboot the computer.
Part II: Intel Matrix
1. Press Ctrl + i to enter RAID configuration menu.
2. Select 1.Create RAID Volume and press Enter.
3. Type the RAID volume name and then press Tab or Enter to
advance to the next field.
4. Specify (use the up and down arrow keys) the RAID level
(RAID 0 or RAID 1 or Recovery - see Table 2 on page 5) and
then press Tab or Enter to advance to the next field.
5. Press Enter and the system will select the physical disks to use.
6. Press Enter and select (if applicable) the Strip Size (best set to
default).
7. Press Enter and select the Capacity size (best set to default).
8. Press Enter to select Create Volume.
9. Press Enter to create the volume, and confirm the selection by
pressing Y.
10. This will now return to the main menu.
11. Select 6.Exit and press Enter, then press Y to exit the RAID
configuration menu.
12. Make sure the Windows 7 OS DVD is in the DVD drive and as
the computer starts up it will automatically boot from the
Windows 7 OS DVD (you will be prompted to press a key to
boot from the DVD).
13. Press Enter to continue installing the operating system as
normal (see your Windows documentation if you need help on
installing the Windows OS).
14. Install the Windows drivers as per Table 8 on page 22. Make
sure you install the Intel Rapid Storage Technology (IRST)
driver (see page 32).
Figure 2
RAID
Created

7
English
System Map: Front View with LCD Panel Open
21
98
4
7
54
6
Note that the Touchpad and
Buttons valid operational
area is that indicated within
the red dotted lines above.
9
Figure 3
Front View with LCD
Panel Open
1. PC Camera (Optional)
2. *PC Camera LED
*When the PC camera
is in use, the LED will
be illuminated in red.
3. LCD
4. LED Indicators
5. Power Button
6. Speakers
7. Keyboard
8. Built-In Microphone
9. Touchpad and Buttons
10. Fingerprint Reader
(Optional)
3
21
8
9
7
645
Models A & B
15.6” (39.62cm)
17.3” (43.94cm)
Model C

Wireless Device
Operation Aboard Aircraft
The use of any portable electronic transmission devices aboard air-
craft is usually prohibited.
Make sure the wireless modules are OFF or in Airplane mode (for
Windows 8 only) if you are using the computer aboard aircraft.
6
10
3
6
10

8
English
LED Indicators
The LED indicators on the computer display helpful infor-
mation about the current status of the computer.
Table 3 - LED Status Indicators
Table 4 - LED Power Indicators
*The powered USB 3.0 port may be toggled on /off by
means of the Fn + Power Button key combination. When
the powered USB port is on it will supply power when the
system is off but still powered by the AC/DC adapter
plugged into a working outlet (this may not work with cer-
tain devices - see page 35).
Icon Color (Models A
& B)
Color
(Model C) Description
Blue White Number Lock (Numeric Key-
pad) Activated
Blue White Caps Lock Activated
Blue White Scroll Lock Activated
Blue White Hard Disk Activity
Blue White Wireless LAN Module Power
Toggle
Blue Orange
Win 7 - The Bluetooth Mod-
ule is Powered On
Win 8 - The Bluetooth Mod-
ule is Installed (this is not a
power on/off indicator in Win
Models A & B Model C
Icon Color Description
Orange The AC/DC Adapter is Plugged In
Blinking
Orange* The AC/DC adapter is plugged in and the powered USB Port is on*
Green The Computer is On
Blinking
Green The Computer is in Sleep Mode
Orange The Battery is Charging
Green The Battery is Fully Charged
Blinking
Orange The Battery Has Reached Critically Low Power Status

9
English
Keyboard & Function Keys
The keyboard includes a numeric keypad for easy numeric data input. Pressing Fn + NumLk turns on/off the numeric
keypad. It also features function keys to allow you to change operational features instantly. The function keys (F1 -
F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key com-
binations, visual indicators (Windows 7 or Windows 8 Desktop only) are available when the hot key driver is installed.
Keys Function/Visual Indicators Keys Function/Visual Indicators
Fn + ~ Play/Pause (in Audio/Video Programs) Fn + F11 WLAN Module Power
Toggle
Fn + F1 Touchpad Toggle Fn + F12 Bluetooth Module
Power Toggle
Fn + F2 Turn LCD Backlight Off
(Press a key to or use Touchpad to turn on) Fn + NumLk Number Lock Toggle
Fn + F3 Mute Toggle Fn + ScrLk Scroll Lock Toggle
Fn + F4 Sleep Toggle Caps Lock Caps Lock Toggle
Fn + F5/F6 Volume Decrease/
Increase Fn + Power But- ton Powered USB Port Power Toggle (see page 13)
Fn + F7 Display Toggle Fn + Esc Control Center Toggle (see page 11)
Fn + F8/F9 Brightness Decrease/
Increase Fn + Keyboard LED Toggle (see page 10)
Fn + F10 PC Camera Power
Toggle Table 5 - Function Keys & Visual Indicators
Function Keys
Numeric
Keypad
Fn Key
ScrLk &
NumLk
Figure 4 - Keyboard
Models A & C Model B
Function Keys
Numeric
Keypad
Fn Key
ScrLk &
NumLk

10
English
Keyboard LED (Models A & C Only)
Press Fn plus the key to toggle the keyboard LED on/
off. The keyboard LED may be configured using the Fn +
key combination outlined in the table below. In addition
press Fnplus the key to launch the keyboard backlight
application to configure the settings.
Table 6 - Keyboard LEDs
Keyboard Backlight Application
The Keyboard Backlight application can be accessed by
pressing the Fn plus key. Click the Help button in
the application to display the configuration keys.
• Click the Custom button to display the three sections
of the keyboard which may be configured.
• Click a section of the keyboard and the color buttons will
be displayed.
• Click a color swatch to apply the color to the selected sec-
tion when not overidden by any effect applied.
• Click on any of the effect buttons to apply random colors,
wave or flashing effects etc.
Figure 5 - Keyboard Backlight Application
Effects Buttons & Help
Table 7 - LED Effects Buttons
Keyboard LED Function key Combinations
Fn + Launch the Key-
board Backlight
Application
Fn + Toggle the Key-
board LED On/
Off
Fn + *Keyboard LED
Illumination
Decrease
Fn + *Keyboard LED
Illumination
Increase

*Illumination Keys
Note that the keyboard il-
lumination (increase/de-
crease) keys may be
used to configure the key-
board LED in Custom
Mode only.
LED Effects Buttons
Random Color Up/Down Wave
Dancing Effect Breathing (All Colors)
Tempo Beat Cycle (Colors as Selected in
RGB)
Flashing Custom - Display & Configure
Keyboard Sections & Colors
Help Button
Keyboard Sections
Effects Buttons
Color Swatches

11
English
Control Center
Press the Fn + Esc key combination, or double-click the icon in the notification area of the taskbar to toggle the
Control Center on/off. The Control Center gives quick access to frequently used controls, and enables you to quickly
turn modules on/off. The Control Center is only accessible fromthe Windows Desktop (use the Windows Logo Key
+ D key combination) in Windows 8 and not from the Start Screen in the Metro UI.
Figure 6 - Control Center
Click on any button to turn any of the modules (e.g. Touchpad, Camera) on/off. Click on Power Conservationto switch
between Performance, Balanced or Energy Star modes. Click on the buttons (or just click and hold the mouse button)
to adjust the slider for Brightness/Volume. Click on Display Switch/Time Zone/ Desktop Background to bring up
the appropriate Windows control panel. Click on the Sleep button to put the computer into Hibernate or Sleep modes.
Windows 7 Windows 8

12
English
Power Status
The Power Status icon will show
whether you are currently powered by
the battery, or by the AC/DC adapter
plugged in to a working power outlet.
The power status bar will show the
current battery charge state.
Brightness
The Brightness icon will show the
current screen brightness level. You
can use the slider to adjust the screen
brightness or the Fn+ F8/F9key com-
binations, or use the Fn + F2 key com-
bination to turn off the LED backlight
(press any key to turn it on again).
Note that screen brightness is also ef-
fected by the Power Mode selected.
Volume
The Volume icon will show the cur-
rent volume level. You can use the
slider to adjust the Volume or the Fn +
F5/F6 key combinations, or use the
Fn + F3 key combination to mute the
volume.
Power Conservation
This system supports Energy Star
power management features that place
computers (CPU, hard drive, etc.) into
a low-power sleep mode after a desig-
nated period of inactivity. Click either
the Performance, Balanced or Ener-
gy Star button.
Sleep
Click the Sleep button to bring up the
Hibernate or Sleep buttons,
and click either button to have the
computer enter the appropriate power-
saving mode.
Display Switch
Click the Display Switch button to ac-
cess the menu (or use the + P key
combination) and select the appropri-
ate attached display mode.
Time Zone
Clicking the Time Zone button will
access the Date and Time Windows
control panel.
Desktop Background
Clicking the Desktop Background
button will allow you to change the
desktop background picture.
K/B LED
Click to access the keyboard setting
control to configure the keyboard
LED.
TouchPad/PC Camera/Wireless
LAN Module /Bluetooth Module
(Win 7 Only)
Click any of these buttons to toggle
the Touchpad or module’s power sta-
tus. A crossed out icon will appear
over the top left of the icon when
it is off. Note that the power status of a
module, and Touchpad power, is also
effected by the Power Mode selected.
TouchPad/PC Camera Module
(Win 8 Only)
Click any of these buttons to toggle
the Touchpad or module’s power sta-
tus. A crossed out icon will appear
over the top left of the icon when
it is off. Note that the power status of a
module, and Touchpad power, is also
effected by the Power Mode selected.

13
English
System Map: Front, Left, Right & Rear Views (Models A & B)
5
8
67
1
23
Front
Left
Right
10 11 13
12

USB
The USB 3.0 ports are colored blue. USB 3.0 will transfer data much faster than USB 2.0,
and is backwards-compatible with USB 2.0. When the powered USB 3.0 port is on it will
supply power (for charging devices only, not for operating devices) when the system is
off but still powered by the AC/DC adapter plugged into a working outlet, or powered by the
battery with a capacity level above 20% (this may not work with certain devices - see
page 35). Toggle power to this port by using Fn + power button.
4
9
4
15
17
14
16 20
Rear
18 19
Figure 7
Front, Left, Right & Rear
Views (Models A & B)
1. LED Power Indicators
2. Mini-IEEE 1394a Port
3. RJ-45 LAN Jack
4. Powered USB 3.0 Port
(See Below)
5. USB 3.0 Port
6. Combined eSATA/ USB 3.0
Port
7. Multi-in-1 Card Reader
8. Optical Device Drive Bay
9. Emergency Eject Hole
10. Headphone Jack
11. Microphone Jack
12. S/PDIF-Out Jack
13. Line-In Jack
14. USB 2.0 Port
15. Security Lock Slot
16. Vent
17. DisplayPort
18. HDMI-Out Port
19. DVI-Out Port
20. DC-In Jack
16

14
English
System Map: Front, Left, Right & Rear Views (Model C)
Front Figure 8
Front, Left, Right & Rear
Views (Model C)
1. LED Power Indicators
2. Mini-IEEE 1394a Port
3. RJ-45 LAN Jack
4. Powered USB 3.0 Port (See
Below)
5. USB 3.0 Port
6. Combined eSATA/ USB 3.0
Port
7. Multi-in-1 Card Reader
8. Optical Device Drive Bay
9. Emergency Eject Hole
10. Headphone Jack
11. Microphone Jack
12. S/PDIF-Out Jack
13. Line-In Jack
14. USB 2.0 Port
15. Security Lock Slot
16. Vent
17. DisplayPort
18. HDMI-Out Port
19. DVI-Out Port
20. DC-In Jack
57
8
1
23
10 12
11
4
14
16
13
15 20
17 18 19
Front
Left
Right
Rear

USB
The USB 3.0 ports are colored blue. USB 3.0 will transfer data much faster than USB 2.0, and
is backwards-compatible with USB 2.0. When the powered USB 3.0 port is on it will supply
power (for charging devices only, not for operating devices) when the system is off but
still powered by the AC/DC adapter plugged into a working outlet, or powered by the battery
with a capacity level above 20% (this may not work with certain devices -see page 35).Toggle
power to this port by using Fn + power button.
4
6
9
16
