CLIMASTAR OPTIMAX User manual

USER’R GUIDE
OPTIMAX

3
INDEX
1.- GENERAL INFORMATION _____________________________________________________________4
2.-DESCRIPTION_________________________________________________________________________6
2.1- LIST OF COMPONENTS _________________________________________________________6
3.- BEFORE STARTING YOUR DEVICE _____________________________________________________7
4.- ASSEMBLY ___________________________________________________________________________7
5.- USING THE RADIATOR ________________________________________________________________8
5.1- STARTING THE DEVICE __________________________________________________________8
5.2- THERMOSTAT REGULATION _____________________________________________________8
5.3- FROST FUNCTION ________________________________________________________________8
6.- USAGE RECOMMENDATIONS __________________________________________________________8
7.- TECHNICAL SPECIFICATIONS _________________________________________________________9
8.- FAQs________________________________________________________________________________10
9.- GUARANTEE ________________________________________________________________________10

4

1.- GENERAL INFORMATION
Read carefully this user’s guide before installing your
device.
Climastar Heating System must only be destined for
heating.
Make sure the supply voltage corresponds with that on
the nameplate (located on the left side of the device).
The Schuko plug must be connected to a compatible
Shuko socket.
Do not place the device right under an electrical
outlet.
If the supply cord is damaged, it must be replaced by
the manufacturer, its after sales service agents or any
other qualified person.
Not intended for children under the age of 3 unless
duly supervised.
Children over 3 and below the age of 8 must only turn
on/off the device whenever it has been duly placed or
installed, has been given supervision or instructions
concerning use of the appliance. Children from 3 to 8
must not plug, regulate and clean the device, nor carry
out any maintenance activity.

5
Not intended for use by persons (including children
over 8) with reduced, physical, sensory or mental
capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety. Children must not play
with the device. Cleaning and maintenance must not
be carried out by children without prior supervision.
WARNING: some parts of this device may overheat
and cause burns. Pay special attention when children
and vulnerable people are around.
All models are supplied with an electrical interrupt
cut-out. This will switch off the heater if, for any
reason, it overheats. Should the cut-out operate, turn
the heater off and remove the cause for the
overheating, the cut-out will be reset automatically. If
this happens again, being not covered in any way the
heat outlet slots, please contact the Technical Service.
WARNING: to avoid possible overheating,
NEVER cover or obstruct in any way the heat
outlet slots at the top or the air inlet slots at the
base of the heater.
Do not use the device near the bath, shower or
swimming pool.

6
Press the buttons softly to avoid any damage, do not
manipulate the device with ball pens or similar to
avoid scratches.
2.-DESCRIPTION
2.1- LIST OF COMPONENTS
Make sure the following elements are included. If any is missing,
please contact your distributor:
1 x 2 x 4 x
Handle
Thermostat knob
Power Switches
1000W+1000W
Wheels

7
3.- BEFORE STARTING YOUR DEVICE
Before connecting the heater check that the supply voltage is the
same as that stated on the heater.
Neither the connecting cable nor any other must come into contact
with the hot unit.
If the heater is installed in a room containing a bath or shower, it
should be so installed that switches and other controls cannot be
touched by a person using a bath or shower, in compliance with the
regulation in force in each country.
The use of these heaters is forbidden in any area where there is a
presence of gases, explosives or inflammable objects.
4.- ASSEMBLY
Place the heater upside down.
Screw the wheels as shown below:

8
5.- USING THE RADIATOR
5.1- STARTING THE DEVICE
Connect the power cable to a mains power outlet and turn the
thermostat knob clockwise to its maximum position (plus).
Select the power by pressing the power switches:
Pressing one switch: 1000W
Pressing both switches: 2000W
The indicator light of the switches will be activated.
5.2- THERMOSTAT REGULATION
When the room reaches the desired temperature, turn the thermostat
knob anti-clockwise until the indicator or indicator lights of the
switches switch off, this indicates that the thermostat has been
disconnected.
Leave it in that position and the thermostat will maintain the
selected temperature.
5.3- FROST FUNCTION
Turn the thermostat control knob in the position * and activate
maximum power.
6.- USAGE RECOMMENDATIONS
The Climastar range of heating products needs no maintenance.
Only certain preventive measures may be necessary:
Do not cover the air exits. Do not place clothing over them.

9
Keep floors clean to avoid staining on the wall.
At the beginning of the year’s heating season, vacuum the
interior of the equipment. After being switched off for some
time, dust may accumulate on the element.
Do not place the equipment under a ventilation grill or near any
location that may generate a draught.
Install the equipment so that nothing prevents the circulation of
air generated (furniture, curtains…). Otherwise, a loss of
temperature control and output may occur.
Avoid installing the device in cavity walls to avoid loss of
temperature and output.
To prevent loss of heat and wasting electricity, if possible,
improve insulation of the windows with draught excluders,
double gazing or thermal breaks.
The DUAL KHERR can be cleaned with a damp cloth, alcohol,
even nitric acid (for difficult stains). Due it durability, it will
not be degraded by the use of any type of substance (standards
EN99 and EN202). Due to its composition, direct sunlight can
shine directly on the equipment without altering its appearance
(standard EN 51094)
The cover can be cleaned with a damp cloth.
7.- TECHNICAL SPECIFICATIONS
DIMENSIONS AND WEIGHT
Description: PORTABLE
Power: 2000 W
Dimensions (mm) 560 x 540 x 100
Weight (kg) 16,4
ELECTRICAL DATA
Voltage: 230 V
Frequency: 50 Hz
Plug: Bipolar 10-15 A/250 VAC
COMPONENTS
Back cover: High quality stainless steel
Front: Dual Kherr

10
8.- FAQs
PROBLEM PROBABLE CAUSE SOLUTION
The room does not
reach the desired
temperature
Incorrect setting of the set
temperature Check the set temperature of the thermostat.
Improper sizing The power rating of the heater is not adequate for the place in which it
has been installed.
Heat outlet slots at the top
or air inlet slots at the base
are obstructed
Neither place anything on top of the radiator nor install it inside a hole
made in a cavity wall
Set temperature below the
room temperature
Rise the set temperature until it is 1 degree above the room
temperature
The radiator does
not work
Control panel switch and
protection down
Check that the automatic control is not down. If it down, put it up.
Make sure the installation is correct and that there are independent
lines for the heating System with a 2.5 mm2 cable gauge and a
maximum power of 3500W
The switch is turned to
the off position Press at least one switch of the heater.
9.- GUARANTEE
WARNING ABOUT CORRECT DISPOSAL OF THE PRODUCT ACCORDING TO THE EUROPEAN DIRECTIVE 2002/96/CE.
Environmental information for customers within the European Union. The EU Directive 2002/96/CE declares that equipment carrying this symbol on it and/or
its packaging must not be disposed of alongside ordinary household waste. The symbol indicates that the product in question must be separated from
conventional household waste for disposal. It is the responsibility of the customer to dispose of this equipment and any other electrical and electronic apparatus
through collection points designated by the government and/or local authorities. By correctly disposing of and recycling this apparatus, you will be avoiding
possible negative consequences for the environment and human health. For more detailed information on safe disposal of this apparatus, consult your local
authority, the collection service and waste disposal in your area or ask in the shop where you bought the product.
CLIMASTAR guarantees that in the moment of its purchase the product is free of any defect in the materials and in the work force (limited guarantee). CLIMASTAR offers a
commercial and voluntary guarantee; conditions included are similar to those of the legal guarantee, being CLIMASTAR responsible for the non-conformities arisen in the
terms and conditions mentioned below. Moreover, CLIMASTAR offers a total warranty of 2 years in the spare parts.
CLIMASTAR is responsible for the non-conformities arisen within the 6 months following the date of sale. If the non-conformity arises after those 6 months, the user shall
prove that the non-conformity already existed when delivered. The user must inform CLIMASTAR of said non-conformity in a period inferior to two months.
To obtain the service under the terms of this warranty it is important to detail the device’s purchasing date because the warranty period starts with the purchase invoice of the
system customer. However, in no case this warranty will be liable for defects that may arise after thirty-six months from the manufacture date.
This warranty is strictly limited to the repairing in the factory of the manufacturing defect part or parts of the device, or to the complete replacement of the system when, in
the opinion of the manufacturer, it is not possible or is uneconomical. This does not include any other type of expenditure as an installation, assembly, disassembly or
transport.
This warranty does not cover defects and / or malfunction caused by accidents, misuse, negligence, wears, breakage, an incorrect installation and poor electricity supply to the
system. This warranty is also excluded if it is used with another purpose other than heating, for an alteration, modification, tampering or unauthorized repairing of the
product, and by other different causes beyond the manufacturer’s reach after the delivery of the product.
The warranty does not cover the costs and expenses incurred to access the device or installation, such as in hidden locations, heights, non-practicable ceilings.. Neither does it
include the costs derived from removing or replacing any structural element to access the device or the installation.
No heating system will be returned to CLIMASTAR without a previous codified and official MERCHANDISE RETURN AUTHORIZATION. CLIMASTAR assumes no
liability for any equipment that is returned without the previously mentioned MERCHANDISE RETURN AUTHORIZATION.
CLIMASTAR and/or its agents have the right to decide whether to replace the system or to repair the damaged components. None of these options will extend the original
warranty period.
Any reparation must be done by the Technical Service and authorized by the manufacturer and/or any of its agents; any manipulation done by unauthorized personal will void
this warranty. In case of substitution of the device the buyer must go to the selling centre which will be in charge of receiving the system.
RESPONSIBILITY LIMITATION: CLIMASTAR as a manufacturer is not responsible for any personal or material damage that directly or indirectly might result of a non
proper installation, from an improper handling or neither for the lack of technical qualified staff, nor for the installation costs which are expressly excluded from this
warranty.
None of the present conditions may be extended or modified without the express consent of CLIMASTAR.

11

12
Optimax Rev 240616
CLIMASTAR GLOBAL COMPANY S.L.
Carretera AS-266 OVIEDO-PORCEYO/ Km.7 Pruvia
33192 - Llanera (Asturias)- SPAIN
Phone: [phone] / Fax: [phone]
www.climastar.es
