CNC4PC C34HS User manual

USER’S
MANUAL
VER. 1
C34HS BOARD
Rev. 1
OCTOBER, 2018

User’s Manual Page i
USER'S MANUAL
TABLE OF CONTENTS
Contents Page #
1.0 OVERVIEW.....................................................................................................................1
2.0 FEATURES.....................................................................................................................1
3.0 BOARD DESCRIPTION..................................................................................................1
4.0 JUMPER TO SELECT THE ENABLE.............................................................................2
5.0 ALARM TERMINAL........................................................................................................2
6.0 WIRING SAMPLE...........................................................................................................3
7.0 PINOUT...........................................................................................................................4
8.0 DIMENSION....................................................................................................................5

User’s Manual Page 1
1.0 OVERVIEW
This board interface is used for the connection between C82, C76, M16D and
LEADSHINE HYBRID SERVO DRIVE.
2.0 FEATURES
•RJ45 Driver Input Connector
•Select Jumper for Hard Enable or Soft Enable.
•Alarm terminal
3.0 BOARD DESCRIPTION

User’s Manual Page 2
4.0 JUMPER TO SELECT THE ENABLE
Use Software Enable to keep the driver active only while the system is active.
Set of jumpers as shown in the image.
SOFT ENABLE
Use Hardware Enable to keep the driver enabled all the time.
Set of jumpers as shown in the image.
HARD ENABLE
5.0 ALARM TERMINAL

User’s Manual Page 3
6.0 WIRING SAMPLE

User’s Manual Page 4
7.0 PINOUT
C34HS CONNECTOR RJ45
RJ45 Pins
Function
1
NOT USED
2
PUL+
3
NOT USED
4
GND
5
ERR
6
DIR+
7
NOT USED
8 (5V)
EN+

User’s Manual Page 5
8.0 DIMENSION
All dimensions are in Millimeters.
DISCLAIMER
Use caution. CNC machines can be dangerous machines. Neither DUNCAN USA, LLC
nor Arturo Duncan are liable for any accidents resulting from the improper use of these
devices. This product is not a fail-safe device and it should not be used in life support
systems or in other devices where its failure or possible erratic operation could cause
property damage, bodily injury or loss of life.
