Advantech Network Device USB-4761 Installation and operation manual

1 Startup Manual
Packing List
Before installation, please make sure that you have received
the following:
• USB-4761 Module with DIN-rail mounting kit
• Shielded USB 2.0 Cable (1.8 m)
• Companion DVD (DLL driver included)
• Startup Manual
If anything is missing or damaged, contact your distributor or
sales representative immediately.
User Manual
For more detailed information on this product, please refer to
the USB-4761 User Manual on the DVD (PDF format). CD:\
Documents\Hardware Manuals\USB\USB-4761
Specications
Declaration of Conformity
FCC Class A
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential
area is likely to cause interference in which case the user is
required to correct interference at his own expense.
CE
This product has passed the CE test for environmental
specifications when shielded cables are used for external
wiring. We recommend the use of shielded cables. This kind
of cable is available from Advantech. Please contact your
local supplier for ordering information.
Notes
For more information on this and other Advantech products,
please visit our websites at:
http://www.advantech.com
For technical support and service:
http://www.advantech.com/support/
This startup manual is for USB-4761.
Part No: 2003476112 3rd Edition
February 2016
STARTUP MANUAL
Overview
USB-4761
8-ch Relay, 8-ch IDI USB Module
The Advantech USB-4761 is a powerful data acquisition
(DAS) module for the USB port. It features a unique circuit
design and complete functions for data acquisition and
control.
Isolated Digital Input
Number of Input Channels 8
Optical Isolation 2500 VDC
Optical Isolator response time 50 us
Input Voltage VIH(max.) = 30 VDC
VIH(min.) = 5 VDC
VIL(max.) = 2 VDC
Input Current 1.2 mA @ 5 VDC
3.3 mA @12 VDC
6.9 mA @24 VDC
8.7 mA @30 VDC
Relay Output
Channels 8
Rating (Resistive) 30 VDC @ 1A
110 VAC @0.3A
120 VAC @0.5A
240 VAC @0.25A
Max. Switching Power 62.5VA , 60W
Max. Switching Voltage 250 VAC , 220VDC
Max. Switching Current 5 A
Breakdown Voltage 1500V
Operation time 5 ms max
Release time 4 ms max
Life Expectancy Mechanical 1x108operations (typical)
Electrical 12V @ 10mA : 5X107
operations (typical)
30V @ 2000mA : 2X105
operations (typical)
General Specications
I/O Connector Type 10-pin screw terminal*5
Dimensions 132 x 80 x 32 mm
(5.2” x 3.2” x 1.3”)
Power Consumption Typical : 5V @60 mA
Max: 5V @400 mA
Temperature Operating: 0 ~ +60°C
(32 ~ 140°F)
Storage: -20 ~ +70°C
(-4 ~ 158°F)
Relative Humidity 5 – 95°% RH non-condens-
ing (refer to IEC 68-2-3)

Startup Manual 2
STARTUP MANUAL
Hardware Installation
Pin Assignments
1. Touch the metal part on the surface of your computer
to neutralize the static electricity that might be in your
body.
2. Plug your USB module into the selected USB port.
Hold the module only by its edges. Plug the module
firmly into place. Use of excessive force must be
avoided; otherwise the module might get damaged.
Signal
Name Description
NO<0~7> Normally open pin of relay output
COM<0~7> Common pin of relay output
NC<0~7> Normally close pin of relay output
IDInA <n=0~7> Isolated digital input A
IDInB <n=0~7> Isolated digital input B
Isolated Digital I/O Connections
LED Denitions
The USB Module is equipped with an LED indicator to
show the current status of the device. When you plug the
USB device into the USB port, the LED indicator will blink
five times and then stay lit to indicate that it is on. Please
refer to the following table for detailed LED indicator status
information
LED Status Description
ON Device ready to work
OFF Device not ready to work
Slow blinking (5 times) Device initializing
Fast Blinking Device working
Single-ended Channel Connections
USB-4761 has 8 isolated digital input channels. Each of
isolated digital input channel accepts 5~30 VDC voltage in-
puts, and accept bi-directional input. It means that you can
apply positive or negative voltage to an isolated input pin
(Vin ). The figure below shows how to connect an external
input source to one of the card's isolated input channels.
Relay Connections
After power on, the initial relay output status is shown as
below:
