CNX Mini User manual

GENERAL SAFETY 2
GENERAL INFORMATION 3
I.UNPACKING 3
II.FEATURES 3
III. REMOTE CONTROL UNIT (RCU) 4
IV. FRONT PANEL 7
V. REAR PANEL 8
INSTALLING EQUIPMENT 9
CHANNEL LIST GUIDE 0
MENU GUIDE 2
MAIN PAGE 2
I.CHANNEL MANAGER 2
II. INSTALLATION 4
III. OPTIONS 7
IV. UTILITY 9
TROUBLESHOOTING 20
SPECIFICATIONS 2
BRAND LIST 23
1
TABLE OF CONTENTS

2
GENERAL SAFETY
Please read the following recommended instructions carefully to avoid the risk of your physical
Injury before the product is operated.
Do not cover the receiver and keep clear space around the receiver for sufficient
Check the receiver’s operation voltage 9 ~25 V, 5 Hz~6 Hz Max, 4 W
Keep liquid away from the receiver.
The receiver shall not be exposed to dripping or splashing and no objects that filled with liquid
shall not be placed on the receiver.
Unplug the receiver from the wall outlet before cleaning.
Use a soft cloth and a mild solution of washing-up liquid to clean the casing.
Do not block the receiver’s ventilation slots which are provided for ventilation and
protection from overheating.
Please maintain the receiver in a free airflow.
Do not allow the receiver to be exposed to hot, cold or humid condition.
Do not use any cable and attachment that are not recommended as these may damage your
equipment.
Please unplug the receiver from the wall outlet and disconnect the cable between the receiver
and the antenna when you will not use it for long time.
Do not remove the cover to reduce the risk of electric shock.
Do not attempt to service the receiver yourself.
Refer all serving to qualified service personnel.
Manual may be updated as new features.
WARNING
3
GENERAL INFORMATION
Please ensure that the following items are included with the receiver in your
packing.
1) Remote Control Unit (RCU)
2) Batteries (2EA)
3) User’s Manual
4) A/V Cable
∙MPEG-2 Digital & Fully DVB-S compatible.
∙DiSEqC 1.0, 1.2 and USALS Compatible.
∙5,000 Channels Programmable.
∙Blind scan (Power Scan) & Powerful EPG.
∙Picture In Graphic (PIG).
∙Electronic Program Guide (EPG) for On Screen Channel Information.
∙On-Screen Display with 65,536 Color.
∙Dolby Digital Bitstream Out through S/PDIF.
∙CVBS Video & Audio Output via RCA .
∙Component Y/Pb/Pr Output via RCA.
∙S-Video Output.
∙"Upgrade Software & Update Channel Database through USB and RS232".
∙MP3/JPEG File Play via USB.
I. UNPACKING
II. FEATURES

4
III. REMOTE CONTROL UNIT (RCU)
5
GENERAL INFORMATION
III. REMOTE CONTROL UNIT (RCU)
1. MUTE Enables or disables the audio.
2. POWER Swithches the receiver between operation and standby mode.
3. TV Tv mode
4. STB STB mode
5. VCR VCR mode
6. DVD DVD mode
7. Numeric buttons Selects the TV or Radio service channels and individual menu.
8. FAV Toggles the selected favorite mode.
9. SAT Toggles the selected Satellite list.
1 . EPG
(Electronic Program Guide) Displays the TV or Radio program guide.
11. Enables subtitle and teletext mode.
12. Audio Changes the audio languages.
13. Selects the sound mode(LEFT/RIGHT/STEREO).
14. ▲▼ Changes channels or moves to the item in the menu.
15.◀▶ Adjusts the volume or moves to left or move item in the menu.
16. MENU Displays the main menu on screen.
17. EXIT Returns to the previous menu or normal viewing mode from a menu.
18. INFO Displays the program information box on the screen and edit the name of favorite channel list.
19. V+/V- Turns volume up or down.
2 . P+/P- Changes channels up or down on normal mode.
21. Moves up a page in the channel list. (Selects zoom in/out)
22. Moves down a page in the channel list.
23. Stop Stops recording or playing
24. AUSE Pauses the playing picture or go to normal mode.
25. Record Record the program
26. Enables subtitle and teletext mode.
27. Rewind Starts reverse play back and changes teh speed of reverse playback.
28. F/F Starts fast forward or fast motion playback and changes the speed of forward playback.
29. Position Displays position bar on the screen to adjust the antenna.
3 . AV/TV Selects the TV or AV mode.
31. TV/RADIO Switches between TV and Radio.
32. ←PR Selects the previously viewed channel.
33. Fn Reserved
34. STB/DivX Switches STB or DivX
35. UHF Switches to UHF turning mode.
36 PAL/NTSC Switches PAL or NTSC mode.
GENERAL INFORMATION

6
. POWER Switches the receiver power On and Standby.
2.CH Up/Down Channel up / down or selects the item of Menu.
3. VOL Up/Down Volume up/down or selects the item of Menu.
4. USB PORT To upgrade firmware
IV. FRONT PANEL
①②③④
“All USB 2. flash drive may not be compatible with the product”
7
GENERAL INFORMATION
III. REMOTE CONTROL UNIT(RCU)
GENERAL INFORMATION
Setting Method

8
INSTALLING EQUIPMENT
This section explains several ways of connecting the receiver to your existing
TV, VCR and Hi-Fi system.
You can choose one of the following setups that we recommend.
If you have any problem or need help, consult your dealer or service provider.
Please ensure that the following items are included with the receiver in your packing.
I- . Connecting the receiver to TV with the CINCH cable
Connect one end of the CINCH cable to the Audio-R(Red), the Audio-L(White) and the
Video(Yellow) socket on the rear panel of the receiver and the other end to the Audio-
R(Red), the Audio-L(White) and the VIDEO (Yellow) socket on the TV.
II- .Connecting the receiver to TV and VCR with RF cable
Connect one end of the RF cable TV/VCR socket on the rear panel of the receiver and
the other end to the ANT IN on the TV.
Connect one end of the RF cable to the ANT socket on the rear panel of the receiver and
the other end to the ANT OUT on the VCR.
I. CONNECTING THE RECEIVER TO TV AND VCR WITH CINCH CABLE
II. CONNECTING THE RECEIVER TO TV AND VCR WITH RF CABLE
9
GENERAL INFORMATION
V. REAL PANEL
. LNB IN Connects to Satellite antenna cable.
2. LNB OUT Connects to another STB.
3. DIGITAL AUDIO Output for connecting to a digital amplifier.
4. AUDIO-R Connects to AUDIO RIGHT to TV or other equipment.
5. VIDEO Connects VIDEO to the TV or other equipment.
6. AUDIO-L Connects to AUDIO LEFT to TV or other equipment.
7. YUV Connects to TV the YUV jack of TV.
8. DIGITAL AUDIO Output for connecting to a digital amplifier.
9. S-VIDEO Connects to teh S-VHS jack of TV or VCR
0. TV/VCR Connects to TV or VCR.
. ANT Connects to TV antenna input.
2. RS 232 Connects to personal computer for software upgrade.
3. POWER SUPPLY 9 ~25 V AC, 5 /6 Hz, 4 W.
4. POWER BUTTON Turns On/Off.

10
CHANNEL LIST GUIDE
4. EPG (Electronic Program Guide)
a) Press EPG button on the live mode.
b) EPG of the current channel appears on the screen.
c) Select the channel that you want to watch program.
d) To reserve program with recording function,
press REC(●) button.(PVR model only)
e) It will be appear like rightside picture.f)
If you reserve program, then it will be record
automatically at reserved time.(PVR model only)
g) Press Select button twice to return to current
live channel.
5. ZOOM IN/OUT
a) By selecting page up key ( ) in a normal live
mode you can use Zoom In/Out function.
b) From the Pop-Up Window of Zoom function you
can select(*2*3*4)by page up key( ), for Zoom
out press page down key.
c) When you move cursor of Zoom focus by key (◀
▶▲▼
) then you can select Zoom In/Out on the
focused point by pressing page up/down keys.
Press Pause key then live mode will be paused
on the mode of Zoom.
11
CHANNEL LIST GUIDE
. Normal Live Mode
a) When you select one channel, information bar
appears automatically on the screen for few
seconds. This bar provides you the current channel
information.
b) Press INFO button to see the information during
normal live mode.
2. Simple Channel List
a) Press OK on the normal live mode to go to the
channel list.
b) When detail channel list is displayed on screen
press RED button to go to simple channel list.
3. Detail Channel List
a) Press OK on the normal live mode to go to the
channel list.
b) When simple channel list is displayed on screen
press RED button to go to detail channel list.
c) Press ◀▶ and ▲▼ to sort by Alphabet.
d) Press SAT button to sort by Satellite and FAV
button for Favorite 1~8.
e) Press GREEN button to return to All Channel or
EXIT to return to the current live channel.
f) Press the SAT key to show Satellite Pop-UP Window
then select satellite. Channel list of selected
satellite will be displayed.
g) Press the FAV key to show Favorite Pop-UP
Window then select FAV list. Channel list of
selected FAV will be displayed.
h) Press the Green key then all searched channel list
will be displayed.
i) Press MENU key then cursor will move to ALL,
placed on the left.
j) Sort Key (Yellow Key)~A~Z/Z~A/FAT/CAS.
k) Press Yellow key for sorting A~Z/Z~A/FAT/CAS. If you want to go back to unsort from
the selected CAS go back to Pop-UP Window then select unsort.

12
MENU GUIDE
I. Channe Manager
I-2. Rename
1. Using ◀▶ go to the Rename mode.
2. Select the channel that you want to rename using ▲▼ and
then press OK.
3. Keypad Dialog displays on the screen.
4. Edit the name entering NUMBERS and / or WORDS in the
Keypad Dialog.
5. Press YELLOW button to rename Favorite 1~8 and press
BLUE button to rename Satellite.
6. Press EXIT to return to the previous menu or press MENU
to go to the current live channel.
I-3. Move
1. Using ◀▶ go to the Move mode.
2. Select channels which you want to move by pressing OK key.
3. Move cursor that you want to place on than press GREEN
button.
4. Press EXIT to return to the previous menu or press MENU
to go to the current live channel.
I-4. Lock
1. Using ◀▶ go to the Lock mode.
2. Select the channel that you want to lock and then press
OK. will be marked at the end of the selected channel
name bar. To delete press OK again.
3. Press EXIT to go to Main Page or press MENU to go to the
current live channel.
I-5. Delete
1. Using ◀▶ go to the Delete mode.
2. Select the channel that you want to delete and then press
OK. will be marked on the selected channel number.
To delete press Blue button again.
3. Press YELLOW button to delete TP. Select one channel and
press Blue button. All channels of that TP will be
automatically selected.
4. Press YELLOW button to delete Satellite. Select one
channel and press Blue button. All channels of that the
Satellite will be automatically selected.
5. Press EXIT to return to the previous menu or press MENU
to go to the current live channel.
6. Message Box displays on the screen.
7. Select OK on the Message Box and then press OK to delete
the marked channels.
13
Press the MENU button on the RCU to open Main
Page on the screen. Main Page will be displayed.
1. You can move into the main page using ▲▼◀ ▶
on the RCU.
2. Press OK to confirm your selection.
3. Press EXIT to return to the previous menu or
press MENU to go to the current live channel.
I. Channel Manager
II. Installations
III. Options
IV. Utility
V. Accessory
This section may help you to organize channels according to your preference.
1. Select Channel Manager in the Main Page with ▲▼ and press OK.
2. TV Channel Manager Page displays on the screen.
3. Select the mode that you want using ◀▶.
4. To see the channel that you choose, go to the channel and then press RED botton.
5. Press EXIT to return to the previous menu or press MENU to go to the current live channel.
I- . Favorite
I-2. Rename
I-3. Move
I-4. Lock
I-5. Delete
I- . Favorite
1. Using ◀▶go to the Favorite mode then
press YELLOW button to choose Favorite 1~8.
2. Press OK on the channel that you want to add
or delete.
3. will be marked at the end of selected channel
name bar. To delete press OK again.
4. Selected channels will be automatically saved.
5. If you want to check the saved Favorite Channel
List go to other mode(Rename~Delete) except Favorite
and then press FAV button to check Favorite 1~8.
6. Press EXIT to return to the previous menu or press
MENU to go to the current live channel.
MENU GUIDE
Main Page
I. Channe Manager

MENU GUIDE
14
II-2. DiSEqC Switch
. Select Channel Search in Installation using
▲▼ and press OK.
a) If you select DiSEqC Switch and press OK on the
menu will be, DiSEqC Switch Page will be displayed.
b) Select the proper Satellite of each DiSEqC port
(A~D) using ◀▶and ▲▼ and press SEARCH.
Selected Satellites will be searched
automatically.
II-3 Motor Setup
.You can move the cursor using ▲▼ and press OK
when you select the value that you want.
a) Motor Type : DiSEqC 1.2, USAL
- Press OK to display Motor Type
- Select the proper Motor Type and then press OK.
b) Satellite
- Press OK to Display the Satellite List Box
- Select the proper Satellite and then press OK.
c) Switch & LNB
- Press OK to Display the LNB frequency list or
Switch Setting
- Select proper LNB & proper Switch.
d) Frequency
- Press OK to Display the Frequency List.
- Select the proper Frequency and then press OK.
e) Motor Movement
- Search the appropriate position of the selected
Satellite using ◀▶.
II. Insta ation (Sate ite)
15
MENU GUIDE
This section may help you to set up antenna and
scan satellite or transponder, etc. Select
Installations in Main Page using ▲▼ and press OK.
Press EXIT to return to the previous menu or press
MENU to go to the current live channel.
II- Channel Search
II-2. DiSEqC Switch
II-3. Motor Setup
II- Channel Search
.You can move the cursor using ▲▼ and press OK
when you select the value that you want.
a) Satellite
- Press OK to display the Satellite List Box.
- Select the proper Satellite and then press OK.
b) DiSEqC
- Press OK to display the DiSEqC Port List.
- Select the proper DiSEqC port and then press OK.
c) Frequency
- Press OK to display the Frequency List.
- Select the proper Frequency and then press OK.
d) LNB
- Press OK to display the LNB Frequency List.
- Select the proper LNB Frequency and then press OK.
- You can also input directly the numbers using
NUMBER KEY on the RCU.
e) 22KHz Tone
- Select the one among None, KHz or 22 KHz
depending on the user’s antenna switch box.
f) Search Option
- Press OK to display the Search Option list.
- Select the Search Option that you want and then
press OK.
g) Search
- Press Search to start scan channels.
- Selected Satellite displays on the screen.
- Press ▶to select more Satellite or ◀to cancel
the selected Satellites.
- Press OK to start scanning.
※TP EDIT : To Edit TP, Press the RED button
on the RCU.
II. Insta ation (Sate ite)

This section may help you to set up OSD language,
time , etc. Select Options in Main Page using ▲▼
and press OK.
Press EXIT to return to the previous menu or
press MENU to go to the current live channel.
III- . OSD Setup
III-2. Control Panel
III-3. Time Adjust
III-4. Parental Lock
III- . OSD Setup
. Select OSD Setup in Options using ▲▼ and
press OK.
a) OSD Language
- Press OK to display OSD Language list.
- Select the language that you want and then
press OK.
b) Audio Language
- Press OK to display Audio Language list.
- Select the language that you want and then
press OK.
c) Display Info Bar
- Press OK to display Display Info Bar time list.
- Select the second that you want to display and then press OK.
d) OSD Position
- Press OK to change Horizontal and Vertical Position of the OSD.
- OSD Position box displays on the screen.
- Select Hor Position / Ver Position using ▲▼.
- Move the OSD Position to right/left or up/down using ◀▶.
- Select OK on the OSD Position box and then press OK.
e) Screen format
- Press OK to display screen format list.
- Select the format that you want and then press OK.
2. Press EXIT to return to the previous menu or press MENU to go to the current live channel.
III. Options
16
MENU GUIDE
17
MENU GUIDE
II. Insta ation (Sate ite)
e) Motor Control
Select the position using ◀▶and then press OK.
Message box displays on the screen.
- Store Sat position : Stores the current position
of the motor for the selected satellite.
- Goto Sat Position : Moves the motor to the
stored position of the selected satellite.
- Goto : Goes to the center of the motor.
- Reset Position : Resets all stored position of the motor.
f) Satellite Position
- Input directly the position using NUMBER KEY
on the RCU
- Select the direction using ◀▶(WEST / EAST).
h) Search
- Press Search to start scan channels.
- Press OK to start scanning.
2. Edit my local position
- Press Green Button to edit local Position.
b) Latitude
- Input directly the Latitude using UNMBER KEY
on the RCU.
- Select the direction using ◀▶(NORTH/SOUTHd).
g) Search Option
- Press OK to display the Search Option list.
- Select the Search Option that you want
and then press OK.
※TP EDIT : To Edit TP Press the RED
button on the RCU.
a) Longitude
- Input directly the Longitude using NUMBER
KEY on the RCU.
- Select the direction using ◀▶(WEST / EAST).
3. Press EXIT to return to the previous menu or press MENU to go to the current live channel.

19
MENU GUIDE
Ⅵ.Uti ity
This section may help you to use USB, etc.
Select Utility in Main Page using ▲▼ and press OK.
∙VI - . System Information
∙VI -2. USB
∙VI -3. Factory Default
VI - . System Information
This option help you to know the current S/W and
H/W version. Also provides you the product name.
1. Select System Information in Options using ▲▼
and pres OK.
2. Press EXIT to return to the previous menu.
VI -2 USB
The receiver is equipped with host.
1. Select USB in Utility with ▲▼ and press OK.
2. If you want to change mode(S/W Upgrade,
BootLoader Upgrade), press RED button on the
RCU.
3. Select the file which you want to upgrade using
▲▼ and press OK.
4. After downloading the selected file, the receiver
will reboot automatically.
18
VI -3 Factory Default
Use Factory Default function only when you want
to return the receiver to the condition of factory
default. All settings and channels will be deleted.
1. Select Factory Default in Installations using
▲▼ and press OK.
2. Message box displays on the screen.
3. Select OK to return the receiver to the condition
of factory default and then press OK.
4. Press EXIT to return to the previous menu or
press MENU to go to the current live channel.
MENU GUIDE
III. Options
III-2. Control Panel
1. Select TV Setup in Options using ▲▼ and press OK.
a) Video Output
- Press OK to display Video Output list.
- Select RGB if your SCART supports RGB control
and then press OK.
- Select CVBS if your SCART does not support
RGB control and the press OK.
b) TV Type
- Press OK to display TV Type list.
- Select the proper mode according to your TV type and press OK.
c) UHF Channel
- Press OK to display UHF Channel list.
- Select the proper channel and then press OK.
d) UHF Standard
- Press OK to display UHF Standard list.
- Select the proper mode and then press OK.
2. Press EXIT to return to the previous menu or
press MENU to go to the current live channel.
III-3. Time Adjust
Set your local time according to your location.
1. Select Time Setup in Options using ◀▶ and press OK.
2. Time Adjust page displays on the screen.
3. Move the cursor using
◀▶ , ▲▼and press OK when you
select the value that you want. (Input Hour directly
using number keys on the RCU)
4. Press EXIT to return to the previous menu or press
MENU to go to the current live channel.
III-4. Parental Lock Setup
1. Select Parental Lock Setup in Options using ◀▶ and press OK.
2. Parental Lock Page displays on the screen.
3. You can lock and unlock Parental Lock selecting ON or
OFF using ▲▼ (For Channels).
4. You can lock and unlock Install Lock selecting ON or OFF
using▲▼ (For Installation Settings).
5. Enter new password if you want to change the current password.
6. Confirm your new password entering new password again.
7. Press EXIT to return to the previous menu or press
MENU to go to the current live channel.
Note. DEFAULT PASSWORD IS 0000

2120
∙Check that the power cable is plugged into the power
socket.
∙Check the dish and adjust it.
∙Check the cable connection and correct it.
∙Get out of UHF mode.
∙Check channel and video output.
∙Check the volume level of the TV and receiver.
∙Check the mute status of TV and receiver.
∙Check the cable connection and correct.
∙Replace batteries.
∙Aim the remote control unit directly to the receiver.
∙Checking that nothing blocks the front panel.
∙Check the Conditional Access Module and smart
card are appropriate for the selected service.
∙Check the Conditional Access Module and smart
card are correctly inserted or not.
∙Check the signal strength and the signal quality
in the menu.
∙Check the LNB and replace the LNB if necessary.
∙Check the LNB cable.
∙Check the Dish and adjust it.
∙Go to the Option and select System Information.
∙Contact your Service Provider.
Problem
Nothing appears on the Front
Panel or No power supply
No Picture
No Sound
Remote Control Unit dose not
work
Service is not running or
scrambled
”No Signal” on the screen
Tuner Defective Check
You have forgotten your
secret PIN Code
Solution
TROUBLESHOOTING

2322

2524

2726

2928

30 31
