Cobalt Boats OUTBOARDS Series User manual

Outboards Owner’s Manual i
Outboards Owner’s Manual
FUEL SYSTEMS
Boats manufactured for use in California for
model year 2018 and after meet the California
EVAP Emissions regulation for spark-ignition
marine watercraft. Boats meeting this
requirement will have a label affixed near the
helm.
The fuel system in this boat complies with U.S.
EPA mandated evaporative emission standards
at time of manufacture using certified
components.
AWARNING
Operating, servicing and maintaining
a recreational marine vessel can
expose you to chemicals including
engine exhaust, carbon monoxide,
phthalates, and lead, which are
known to the State of California to
cause cancer and birth defects or
other reproductive harm. To
minimize exposure, avoid breathing
exhaust, service your vessel in a
well-ventilated area and wear gloves
or wash your hands frequently when
servicing this vessel. For more
information go to:
www.P65warnings.ca.gov/marine.

ii Outboards Owner’s Manual
COBALT O UTBOARDS S ERIES

Outboards Owner’s Manual iii
TABLE OF CONTENTS
Outboards Owner’s Manual
FUEL SYSTEMS............................................................................................i
GENERAL INFORMATION
WELCOME................................................................................................. 1-1
CERTIFICATE OF LIMITED WARRANTY................................................. 1-2
ADDENDUM A – SERVICE ASSIST SERVICE AGREEMENT................. 1-3
CALIFORNIA EVAPORATIVE EMISSIONS CONTROL SYSTEM
WARRANTY STATEMENT .................................................................. 1-4
Your Warranty Rights and Obligations................................................. 1-4
INTRODUCTION........................................................................................ 1-6
Intended Use ........................................................................................ 1-6
Craft Design Category.......................................................................... 1-6
OWNER RESPONSIBILITY/WARRANTY PROCEDURE ......................... 1-7
Before Operating .................................................................................. 1-7
Warranty Service Requirements .......................................................... 1-7
If You Sell Your Cobalt Boat................................................................. 1-7
CERTIFICATIONS ..................................................................................... 1-7
NMMA .................................................................................................. 1-7
FEATURES/CONSTRUCTION .................................................................. 1-8
Amenities.............................................................................................. 1-8
Construction Standards/Certifications .................................................. 1-8
Serial Number Locations ...................................................................... 1-8
WARNING LABELS ................................................................................... 1-9
PUBLICATIONS....................................................................................... 1-12
NAUTICAL TERMS.................................................................................. 1-12
SYMBOLS................................................................................................ 1-15
SPECIFICATIONS ................................................................................... 1-16
LAYOUT................................................................................................... 1-17
23SC .................................................................................................. 1-17
25SC .................................................................................................. 1-18
30SC .................................................................................................. 1-19

iv Outboards Owner’s Manual
COBALT O UTBOARDS S ERIES
PROPELLER APPLICATION CHART ..................................................... 1-20
23SC .................................................................................................. 1-20
25SC .................................................................................................. 1-20
30SC .................................................................................................. 1-20
ALPHABETICAL INDEX .......................................................................... 1-21
RESPONSIBILITIES AND SAFETY
OWNER/OPERATOR RESPONSIBILITIES .............................................. 2-1
Registration/Documentation................................................................. 2-1
Required Safety Equipment ................................................................. 2-2
Recommended Safety Equipment ....................................................... 2-2
Recommended Spare Parts................................................................. 2-3
Education Opportunities....................................................................... 2-3
Insurance ............................................................................................. 2-3
BOAT THEORY ......................................................................................... 2-3
Outboards ............................................................................................ 2-3
Remote Control System ....................................................................... 2-4
Steering System................................................................................... 2-4
Fuel System ......................................................................................... 2-4
Freshwater System (Optional) ............................................................. 2-4
DC Electrical System ........................................................................... 2-4
Bilge ..................................................................................................... 2-5
Seaworthiness Inspection .................................................................... 2-5
Operation Checklist.............................................................................. 2-5
Environmental Considerations ............................................................. 2-5
Components, Maintenance and Repairs.............................................. 2-7
Emergency Considerations .................................................................. 2-7
Lifesaving Equipment......................................................................... 2-10
SAFETY ................................................................................................... 2-12
Signal Words/Definitions .................................................................... 2-12
General Safety ................................................................................... 2-13
Water Sports Safety ........................................................................... 2-18
Safety Alert From August 28, 2001: ................................................... 2-20
Navigation ......................................................................................... 2-20
Aids to Navigation .............................................................................. 2-22
OPERATING INFORMATION
PRECAUTIONS ......................................................................................... 3-1
Before You Start................................................................................... 3-1
Fire/Explosion ...................................................................................... 3-1
FIRST-TIME OPERATION......................................................................... 3-1
FUEL .......................................................................................................... 3-2
Fuel Requirements............................................................................... 3-2
Fueling ................................................................................................. 3-2
LAUNCHING.............................................................................................. 3-5
Launching Checklist ............................................................................. 3-5
On the Water........................................................................................ 3-5
Boarding............................................................................................... 3-5
Loading ................................................................................................ 3-5
Shipshape ............................................................................................ 3-5

Outboards Owner’s Manual v
T ABLE OF C ONTENTS
GETTING UNDERWAY ............................................................................. 3-6
Before Starting Checklist...................................................................... 3-6
Handling Dock and Mooring Lines ....................................................... 3-7
Starting/Shifting/Steering/Stopping ...................................................... 3-8
Basic Maneuvering............................................................................. 3-13
Environmental Considerations ........................................................... 3-17
Entertainment System ........................................................................ 3-18
23SC / 25SC FEATURES AND OPTIONS
HELM AND INSTRUMENTATION ............................................................. 4-1
CAPTAIN’S CHAIR ADJUSTMENTS AND OPERATION.......................... 4-5
FLIP DOWN SWIM STEP .......................................................................... 4-6
Boat in the Water.................................................................................. 4-6
Boat on a Trailer................................................................................... 4-6
WINDSHIELD LATCH................................................................................ 4-7
COCKPIT DINETTE TABLE - OPTIONAL ................................................. 4-7
ICE CHEST ................................................................................................ 4-7
AIR COMPRESSOR - OPTIONAL............................................................. 4-8
ANCHOR LIGHT ........................................................................................ 4-8
CRUISE CONTROL - OPTIONAL.............................................................. 4-8
AUTOMATIC CHARGING RELAY (ACR).................................................. 4-9
BATTERY SWITCH ................................................................................... 4-9
BATTERY CHARGER - OPTIONAL .......................................................... 4-9
WATER SYSTEM ...................................................................................... 4-9
MARINE TOILET (HEAD) AND MACERATOR - OPTIONAL .................... 4-9
Instructions ........................................................................................... 4-9
Porta Potti........................................................................................... 4-10
Electrically Operated Head................................................................. 4-10
Macerator Pump................................................................................. 4-11
Dockside Waste Disposal................................................................... 4-11
Waste Disposal with Optional Macerator ........................................... 4-11
BOW TONNEAU COVER - OPTIONAL................................................... 4-12
COCKPIT TONNEAU COVER - OPTIONAL ........................................... 4-12
PREMIUM BIMINI TOP - OPTIONAL ...................................................... 4-13
PREMIUM BIMINI TOP WITH EASY FOLD - OPTIONAL ....................... 4-13
FOLDING ARCH W/BIMINI...................................................................... 4-14
ELECTRIC ARCH WITH BIMINI .............................................................. 4-14
SPORT TOP WITH RETRACTABLE SHADE.......................................... 4-15
Installation .......................................................................................... 4-15
SKI TOW PYLON (OPTIONAL) ............................................................... 4-15
TIE-DOWN LOCATIONS ......................................................................... 4-16
TOOL KIT - OPTIONAL ........................................................................... 4-16
30SC FEATURES AND OPTIONS
HELM AND INSTRUMENTATION ............................................................. 5-1
CAPTAIN’S CHAIR ADJUSTMENTS AND OPERATION.......................... 5-5

vi Outboards Owner’s Manual
COBALT O UTBOARDS S ERIES
FLIP DOWN SWIM STEP.......................................................................... 5-5
Boat in the Water ................................................................................. 5-5
Boat on a Trailer................................................................................... 5-5
EXTENDED SWIM PLATFORM/BOARDING LADDER (OPTIONAL)....... 5-6
BOW / COCKPIT DINETTE TABLE - OPTIONAL ..................................... 5-6
BOW CUSHION INSERTS - OPTIONAL ................................................... 5-6
AIR COMPRESSOR .................................................................................. 5-6
BATTERY SWITCHES............................................................................... 5-7
Remote Battery Switches..................................................................... 5-7
BATTERY CHARGER - OPTIONAL .......................................................... 5-8
AUTOMATIC CHARGING RELAY (ACR).................................................. 5-8
WATER SYSTEM ...................................................................................... 5-8
HEAD SHOWER AND SINK ...................................................................... 5-8
TRANSOM SHOWER WASHDOWN......................................................... 5-8
MARINE TOILET........................................................................................ 5-9
Instructions........................................................................................... 5-9
Porta Potti ............................................................................................ 5-9
VacuFlush Toilet System (Optional)..................................................... 5-9
MACERATOR (OPTIONAL)....................................................................... 5-9
Manual Discharge Pump Operation ..................................................... 5-9
Dockside Pump-out............................................................................ 5-10
MACERATOR PUMP - OPTIONAL ......................................................... 5-10
BOW TONNEAU COVER - OPTIONAL................................................... 5-10
COCKPIT TONNEAU COVER - OPTIONAL ........................................... 5-11
PREMIUM BIMINI TOP WITH EASY FOLD - OPTIONAL ....................... 5-11
HARDTOP WITH MANUAL SURESHADE .............................................. 5-12
Transporting Your Boat ...................................................................... 5-12
Winter Storage ................................................................................... 5-13
Recommissioning the Manual Sunshade System.............................. 5-13
Cleaning ............................................................................................. 5-13
HARDTOP WITH AUTOMATED SURESHADE ...................................... 5-13
Transporting Your Boat ...................................................................... 5-13
Winter Storage ................................................................................... 5-14
Recommissioning the Automated Sunshade System ........................ 5-14
Cleaning ............................................................................................. 5-14
SKI TOW PYLON - REMOVABLE ........................................................... 5-14
TIE-DOWN LOCATIONS ......................................................................... 5-15
TOOL KIT - OPTIONAL ........................................................................... 5-15
SYSTEMS
INTRODUCTION........................................................................................ 6-1
FUEL ROUTING ........................................................................................ 6-2
23SC / 25SC ........................................................................................ 6-2
30SC .................................................................................................... 6-3

Outboards Owner’s Manual vii
T ABLE OF C ONTENTS
WATER/PLUMBING .................................................................................. 6-4
23SC Fresh Water................................................................................ 6-4
25SC Fresh Water................................................................................ 6-5
30SC Fresh Water................................................................................ 6-6
30SC Gray Water ................................................................................. 6-7
30SC ELECTRICAL ................................................................................... 6-8
30SC STEERING HYDRAULICS............................................................... 6-9
Water System..................................................................................... 6-10
FIRE EXTINGUISHER ............................................................................. 6-10
ELECTRICAL SYSTEM ........................................................................... 6-10
CIRCUIT BREAKER PANEL.................................................................... 6-10
FUSES ..................................................................................................... 6-10
BATTERY CONNECTIONS ..................................................................... 6-10
INTERIOR/EXTERIOR CARE
VINYL INTERIOR AND UPHOLSTERY..................................................... 7-1
Care and Cleaning of Vinyl................................................................... 7-1
SEA GRASS FLOOR COVERING CLEANING INSTRUCTIONS.............. 7-2
General Maintenance Instructions........................................................ 7-2
Maintenance Techniques ..................................................................... 7-2
Spot and Stain Removal....................................................................... 7-4
CABINETRY AND WOOD ......................................................................... 7-5
Cabinetry .............................................................................................. 7-5
Woodgrain Dash................................................................................... 7-5
Teak Swim Platform ............................................................................. 7-5
Cedar.................................................................................................... 7-5
CARPET..................................................................................................... 7-5
DECK AND HULL ...................................................................................... 7-5
Cleaning Deck and Hull........................................................................ 7-5
Deck and Hull Care .............................................................................. 7-6
Swim Platform Mat Care and Maintenance.......................................... 7-6
STAINLESS STEEL AND CHROME ......................................................... 7-7
Preventive Steps .................................................................................. 7-7
Cleaning Stainless Steel ...................................................................... 7-7
CORROSION PROTECTION .................................................................... 7-7
CorrosionX ........................................................................................... 7-7
Topside................................................................................................. 7-7
Inside the Bulkhead.............................................................................. 7-8
Other Areas .......................................................................................... 7-8
Galvanic Corrosion............................................................................... 7-8
Salt Water............................................................................................. 7-8
CANVAS .................................................................................................... 7-9
Cleaning Canvas .................................................................................. 7-9
Special Cleaning Problems .................................................................. 7-9
OTHER CANVAS COMPONENTS .......................................................... 7-10
Clear Vinyl “Isinglass”......................................................................... 7-10
Zippers ............................................................................................... 7-10
Snap Fasteners .................................................................................. 7-10

viii Outboards Owner’s Manual
COBALT O UTBOARDS S ERIES
WINDSHIELD........................................................................................... 7-10
BILGE....................................................................................................... 7-10
MARINE GROWTH.................................................................................. 7-10
STATIONARY ARCH WITH AWLGRIP TOPCOAT................................. 7-11
MAINTENANCE AND TROUBLESHOOTING
SCHEDULED MAINTENANCE AND SERVICE ........................................ 8-1
Maintenance Schedule......................................................................... 8-1
Break-In................................................................................................ 8-2
Before Each Use .................................................................................. 8-2
Every 50 Hours .................................................................................... 8-2
Every 100 Hours .................................................................................. 8-2
Quarterly .............................................................................................. 8-2
UNSCHEDULED MAINTENANCE............................................................. 8-2
Outboard .............................................................................................. 8-3
Electrical System.................................................................................. 8-3
Fuel System ......................................................................................... 8-3
Freshwater System (if equipped) ......................................................... 8-3
LIFTING THE BOAT .................................................................................. 8-4
Using Lifting Slings............................................................................... 8-4
Storage Cradle ..................................................................................... 8-4
STORAGE/WINTERIZATION .................................................................... 8-4
Reactivating the Boat After Storage..................................................... 8-5
TROUBLESHOOTING ............................................................................... 8-5
Engine .................................................................................................. 8-6
Electrical............................................................................................... 8-7
Plumbing .............................................................................................. 8-7
REFERENCE AND FORMS
OPERATION QUICK REFERENCE .......................................................... 9-1
Before Launching ................................................................................. 9-1
Pre-Operation....................................................................................... 9-1
Starting Engine..................................................................................... 9-2
Casting Off ........................................................................................... 9-2
During Operation.................................................................................. 9-2
Returning to Port .................................................................................. 9-2
Stopping the Engine............................................................................. 9-2
After Boating ........................................................................................ 9-2
SERVICE LOG........................................................................................... 9-3
FUEL LOG ................................................................................................. 9-4
FLOAT PLAN ............................................................................................. 9-5
BOAT INFORMATION ............................................................................... 9-6
WARRANTY TRANSFER FORM............................................................... 9-7

Outboards Owner’s Manual 1-1
Outboards Owner’s Manual
S ECTION 1
GENERAL
INFORMATION
WELCOME
Dear New Cobalt Owner,
From all of us at the factory and from your authorized Cobalt dealer, thank you for
purchasing a Cobalt boat.We greatly appreciate your business and look forward
to a long and enjoyable relationship with you as part of the Cobalt family.
This manual is designed to help you maximize the enjoyment of your Cobalt
boat, and to acquaint you with proper operation, care, storage and maintenance
of your investment.
Even if you’re a seasoned boater and have previously owned a Cobalt boat, I
recommend you take time to read through this Owner’s manual.As you read this
manual, please remember that “common sense” and “courtesy” are the most
valuable traits you can have to fully enjoy safe boating. It is also to your personal
advantage to become well acquainted with the rules and general “know how” of
boating.
For service and for assistance, contact your authorized Cobalt dealer.The
dealership staff will be happy to answer questions concerning maintenance,
warranty or any other operational questions you may have about your Cobalt
boat.
All the best in boating,
The Cobalt Team

1-2Outboards Owner’s Manual
COBALT O UTBOARDS S ERIES S ECTION 1
CERTIFICATE OF LIMITED WARRANTY
Subject to the terms, conditions, and exclusions in this warranty, Cobalt Boats, LLC, a Delaware limited
liability corporation doing business as Cobalt Boats (“Cobalt”), warrants to the original retail purchaser (and
any subsequent owner) (“Owner”) of a new Cobalt boat purchased from an authorized Cobalt dealer for
personal, non-racing and non-commercial use, as follows:
Ten (10) Year Limited Transferable Warranty on Hull and Deck. Cobalt warrants to the Owner that the
hull and deck including floor, stringers, bulkheads, motor mounts, transom and deck/hull joints of a new
Cobalt boat are free from structural defects in material and workmanship under normal, non-racing and
non-commercial use for a period of ten (10) years from the date of delivery to the original retail purchaser.
Five (5) Year Limited Transferable Bow to Stern Component Warranty. Cobalt warrants that the
upholstery, canvas, components (excluding hull and deck structural components), whether purchased or
manufactured by Cobalt, with respect to a new Cobalt boat are free from structural defects in material and
workmanship under normal, non-racing and non-commercial use for a period of five (5) years from the date
of delivery to the original retail purchaser.
Three (3) Year Limited Transferable Warranty on Gelcoat Finish. Cobalt warrants that the gelcoat finish,
with respect to a new Cobalt boat are free from defects in material and workmanship under normal,
non-racing and non-commercial use for a period of three (3) years from the date of delivery of such Cobalt
boat to the original retail purchaser. Because local area operating conditions and customer care have an
effect on gelcoat finishes, the gelcoat finish warranty does not cover (1) damage or deterioration (for
example: fading, oxidation, discoloration) due to in-water storage or improper care of the gelcoat surface; or
(2) deterioration (for example: fading, oxidation, discoloration) to the gelcoat finish of any Cobalt boat with
colored (non-white) gelcoat located below the static waterline; or (3) blisters due to in-water storage without
the proper application of a marine barrier coating to the bottom of the hull.
THERE ARE NO EXPRESS WARRANTIES OTHER THAN THE ABOVE LIMITED EXPRESS
WARRANTIES. TO THE EXTENT APPLICABLE, ANY IMPLIED WARRANTIES, INCLUDING ANY
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR PARTICULAR PURPOSE, WILL
NOT EXTEND BEYOND THE DURATION OF THESE EXPRESS WRITTEN WARRANTIES.
Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not
apply to you.
Exclusions. The above described limited warranties do not apply (1) if such Cobalt boat has been used at
any time commercially, industrially, for racing or other competition or for revenue producing purposes; (2) to
engines, outdrives, propellers, controls (each of which may be separately warranted by the engine
manufacturer thereof); (3) engines, outdrives, propellers, controls, batteries, trailers, equipment or
accessories installed by persons or parties other than Cobalt or an authorized Cobalt dealer; (4) windshield
leakage, rainwater leakage, windshield or window damage or breakage; (5) deterioration or damage, fading
or shrinkage of upholstery, carpet or canvas; (6) damage related to the alteration or modification of such
Cobalt boat with any structurally affecting addition, component or accessory not specifically in accordance
with Cobalt’s specifications or offered as an option by Cobalt; (7) damage, deterioration (for example: fading,
oxidation, corrosion) of surface finishes, vinyls, fabrics, aluminum and stainless steel finishes; (8) damage or
failures caused by operation of the Cobalt boat outside of the maximum horsepower specifications
recommended by Cobalt; (9) damage or failure related to repairs made by any service provider not approved
by Cobalt; (10) damage (for example: scratches, fading, oxidation, discoloration) to the gelcoat finish; (11)
deterioration (for example: fading, oxidation, discoloration) to the gelcoat finish of any Cobalt boat with
colored (non-white) gelcoat located below the static waterline; or (12) damage or failure related to alteration,
modification, misuse, neglect, negligence, accident or failure to provide reasonable care and maintenance of
such Cobalt boat.

Outboards Owner’s Manual 1-3
G ENERAL I NFORMATION
Remedies.
General. During the applicable limited warranty period, as set forth above, covered warranty repairs shall be
made and any replacement parts or components used as part of such warranty repairs shall be provided
without charge by an authorized Cobalt dealer or, at the option of Cobalt, by Cobalt at its plant in Neodesha,
Kansas or at a facility specifically authorized by Cobalt. All warranty repairs and replacement parts or
components shall be subject to the authorization of factory trained personnel of Cobalt. Transportation to
and from an authorized Cobalt dealer, and/or to and from the Cobalt plant in Neodesha, Kansas, for
warranty repairs, shall be at Owner’s expense.
Service Assist Service Agreement (see Addendum A).Service Assist is not covered under this limited
warranty. Service Assist is covered under the separate Service Assist Service Agreement.
The rights and benefits granted under the above described limited warranty extend to (1) the original retail
purchaser of a new Cobalt boat, and (2) any owner of such Cobalt boat during the applicable warranty
period, commencing with the date of delivery of such Cobalt boat to the original retail purchaser, provided
that such limited warranty is validated, as set forth herein. COBALT’S ONLY RESPONSIBILITY, AND THE
OWNER’S ONLY REMEDY, IS AS DESCRIBED IN THIS WARRANTY. COBALT SHALL NOT BE LIABLE
FOR INCIDENTAL, CONSEQUENTIAL, INDIRECT OR SPECIAL DAMAGES.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have other
legal rights which vary from state to state.
How to obtain Warranty Service. To validate the above described limited warranty, (1) the authorized
Cobalt dealer must complete the warranty registration process with Cobalt Boats at 1715 N. 8th Street,
Neodesha, KS 66757, within ten (10) days after purchase of a new Cobalt boat, and (2) any subsequent
owner of a Cobalt boat during the applicable limited warranty period must give written notice of the
acquisition of a Cobalt boat to Cobalt within ten (10) days after such purchase. Notification of any warranty
claim arising within the applicable warranty period, as set forth above, must be made in writing by the owner
of such Cobalt boat or by an authorized Cobalt dealer to Cobalt within thirty (30) days after the discovery of
the alleged basis for any warranty claim. With respect to any condition for validating a limited warranty or
obtaining any remedy, the authorized Cobalt dealer is Owner’s agent, and Owner is solely responsible for
and bears the risk for the authorized Cobalt dealer’s failures.
ADDENDUM A – SERVICE ASSIST SERVICE AGREEMENT
In consideration of the purchase of a new Cobalt boat from an authorized Cobalt dealer for personal,
non-racing, and non-commercial use, for the term of this agreement Cobalt Boats, LLC (“Cobalt”) agrees to
provide to the original retail purchaser or any subsequent owner (each an “Owner”) of such Cobalt boat, for
which the registration process under Cobalt’s Certificate of Limited Warranty has been completed, the
services described in this agreement.
Obligation. Subject to the conditions and limitation of this agreement, if (1) Owner makes a valid claim under
either the Cobalt Five (5) Year Bow to Stern Component Warranty or any express warranty made by the
engine manufacturer with respect to the engine or powertrain of such new Cobalt boat (the “Applicable
Warranties”); (2) Owner incurs costs for on-water towing, hoist/lift-out, haul-out, or dockside repair call
(“Covered Services”) in association with such claim; and (3) the Applicable Warranties claim is made and
Covered Services costs are processed through an authorized Cobalt dealer (“Dealer”), then Cobalt will
reimburse Owner for or pay such costs.

1-4Outboards Owner’s Manual
COBALT O UTBOARDS S ERIES S ECTION 1
Conditions. As a condition for Cobalt’s obligations under this agreement, if Covered Services are provided by
anyone other than a Dealer, Owner must provide the following documentation (as applicable) to the Dealer
prior to the time the Dealer submits the Applicable Warranty claim:
• Copy of Towing, Hoist/Lift out, Haul-Out or Dockside Repair bill
• Copy of warranty claim to the engine manufacturer
Limitations. Cobalt’s liability under this agreement will not exceed a maximum of $100 per claim. EXCEPT
AS PROHIBITED BY APPLICABLE LAW, COBALT MAKES NO WARRANTIES, EXPRESS OR IMPLIED,
UNDER THIS AGREEMENT OR REGARDING THE SERVICES, INCLUDING WITHOUT LIMITATION, THE
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
COBALT WILL NOT BE LIABLE FOR INCIDENTAL, CONSEQUENTIAL, INDIRECT OR SPECIAL
DAMAGES. Some states do not allow the exclusion or limitation of implied warranties or limitation of
remedies for their breach, so the above provision may not apply to you. This agreement gives you specific
legal rights, and you may also have other legal rights which vary from state to state.
Term. This agreement begins on the original purchaser delivery date of the new Cobalt boat and is effective
through the end of the warranty periods for the Applicable Warranties.
Assignment. This agreement is transferable to subsequent Owners within the term of this agreement.
Otherwise, Owner may not transfer or assign any of Owner’s right, title, or interest under this agreement.
General. This agreement embodies the entire understanding of the parties. This agreement cannot be
changed or modified except in writing signed by an authorized officer of Cobalt. This agreement is governed
by the laws of the State of Kansas, ignoring the rules on conflicts of law. No failure or delay by Cobalt to
exercise any right or remedy will operate as a continuing waiver. Headings used in this agreement will have
no legal significance. This agreement will not be construed against a party simply because the party may
have drafted such provision.
CALIFORNIA EVAPORATIVE EMISSIONS CONTROL SYSTEM
WARRANTY STATEMENT
Your Warranty Rights and Obligations
The California Air Resources Board is pleased to explain the evaporative emission control system’s warranty
on your 2019 Boat. In California, new spark-ignition marine watercraft (SIMW) must be designed, built, and
equipped to meet the State’s stringent anti-smog standards. Cobalt Boats, LLC must warrant the evaporative
emission control system on your boat for the period listed below provided there has been no abuse, neglect
or improper maintenance of your SIMW.
Your evaporative emissions control system may include parts such as: canisters, carburetors, clamps,
connectors, filters, fuel caps, fuel lines, fuel tanks, valves, vapor hoses, and other associated evaporative
emissions control system components.
MANUFACTURER’S WARRANTY COVERAGE:
This evaporative emission control system is warranted for two years. If any evaporative emission-related part
on your SIMW is defective, the part will be repaired or replaced by Cobalt Boats, LLC.

Outboards Owner’s Manual 1-5
G ENERAL I NFORMATION
OWNER’S WARRANTY RESPONSIBILITIES:
• As the boat owner, you are responsible for performance of the required maintenance listed in your owner’s
manual. Cobalt Boats, LLC recommends that you retain all receipts covering maintenance on your boat,
but Cobalt Boats, LLC cannot deny warranty solely for the lack of receipts.
• As the boat owner, you should however be aware that Cobalt Boats, LLC may deny you warranty coverage
if your spark-ignition marine watercraft or a part has failed due to abuse, neglect, or improper
maintenance or unapproved modifications.
• You are responsible for presenting your boat to a Cobalt Boat, LLC distribution center or service center as
soon as the problem exists.The warranty repairs should be completed in a reasonable amount of time,
not to exceed 30 days. If you have a question regarding your warranty coverage, you should contact
Cobalt Boats, LLC at 1-[phone].
The California evaporative emissions control system warranty covers the following list of components:
* Your craft may or may not be equipped with these components.
(1) Canister Mounting Brackets (11) Fuel Line
(2) Carbon Canister (12) Fuel Line Fittings
(3) Carburetor Purge Port Connector (13) Fuel Tank
(4) Clamps* (14) Liquid/Vapor Separator
(5) Control Cables* (15) Pressure Relief Valves*
(6) Control Linkages* (16) Purge Valves
(7) Control Solenoids* (17) Vacuum Control Diaphragms*
(8) Control Valves* (18) Vapor Hoses
(9) Electronic Controls* (19) All other parts not listed that may affect the evapora-
tive emissions control system
(10) Fuel Cap

1-6Outboards Owner’s Manual
COBALT O UTBOARDS S ERIES S ECTION 1
INTRODUCTION
This manual was created following International
Organization for Standards (ISO) 10240:2004 as a
guideline. Not all information to conform to the
standards set forth by ISO can be included in this
manual without certain manufacturer’s consent of
the equipment included on your boat.
This owner’s manual contains information that is
necessary to run the boat properly, safety topics,
and operation and maintenance hints.
Even if everything has been planned and designed
for the safety of the boat and its users, boating is
highly dependent on the weather conditions, the
sea state, and the experience and physical shape
of the crew, and one can never ensure full safety. It
is your responsibility as the owner or user to know
the boat’s equipment, its capabilities and the boat’s
intended use.
The specific information on the operation of the
equipment and systems your boat is supplied with
or fitted with should be supplied by that
manufacturer. Read, understand and keep all the
information supplied, and familiarize yourself and
all users with the boat before you put it into use.
All persons should wear a suitable life
preserver/personal flotation device when on deck.
In some countries it is a legal requirement to wear a
suitable life preserver/personal flotation device that
complies with those countries’ regulations at all
times.
Intended Use
Your Cobalt boat is intended for use as a pleasure
and sport craft.
Craft Design Category
Significant Wave Height – is the mean height of the
highest one-third of the waves, which
approximately corresponds to the wave height
estimated by an experienced observer. Some
waves will be double this height.
OCEAN – Category A
Craft designed to operate in winds that may exceed
wind Beaufort force 8 and in significant wave
heights of 13' 1.44" (4 m) and above, and is largely
self-sufficient. Abnormal conditions such as
hurricanes are excluded. Such conditions may be
encountered on extended voyages, for example
across oceans, or inshore when unsheltered from
the wind and waves for several hundred nautical
miles.
AWARNING
Avoid serious injury or death.
• Children, disabled people and
non-swimmers should wear a personal
flotation device at all times. Children
and non-swimmers need special
instruction in the use of life
preservers. Inform all passengers on
the proper use of personal flotation
devices and of the location of safety
equipment, man overboard recovery
equipment, and the location and
deployment of the ladder.
• Avoid contact with any running
machinery moving parts, such as an
engine, generator or propeller. Contact
can result in loss of body parts,
strangulation, burns and/or severe
loss of blood. Keep all machinery
guards in place when machinery is
operating.

Outboards Owner’s Manual 1-7
G ENERAL I NFORMATION
OFFSHORE – Category B
Craft designed to operate in winds up to Beaufort
force 8 and the associated wave heights and in
significant wave heights up to 13' 1.44" (4 m). Such
conditions may be encountered on offshore
voyages of sufficient length, or on coastal waters
when unsheltered from the wind and waves for
several dozens of nautical miles. These conditions
may also be experienced on inland seas of
sufficient size for the wave height to be generated.
INSHORE – Category C
Craft designed to operate in winds up to Beaufort
force 6 and the associated wave heights and
significant wave heights up to 6' 6.7" (2 m). Such
conditions may be encountered in exposed inland
waters, in estuaries and in coastal waters in
moderate weather conditions.
SHELTERED WATERS – Category D
Craft designed to operate in winds up to Beaufort
force 4 and the associated wave heights
(occasional maximum waves of 1' 7.7" [0.5 m]
height). Such conditions may be encountered in
sheltered inland waters, and in coastal waters in
fine weather.
OWNER RESPONSIBILITY/
WARRANTY PROCEDURE
Before Operating
Before operating your new Cobalt boat, it is
necessary that you read and understand this
manual. Also, take the time to read the other
component manuals supplied to you in your
owner’s packet.
Warranty Service Requirements
All Cobalt warranty service must be completed by
an authorized Cobalt dealer. If you are not able to
return your boat to your selling dealership, you
must contact him so he may assist you in
coordinating the warranty repairs. Any claims
against Cobalt Boats without prior approval from
Cobalt Boats on repairs completed by an
unauthorized dealership may be denied.
If You Sell Your Cobalt Boat
Your warranties are transferable. If you sell your
Cobalt boat to anyone other than an authorized
Cobalt dealer, please refer to the Warranty Transfer
Form on the last page of this manual. If the proper
transfer procedures are not followed, future
warranty may be denied.
CERTIFICATIONS
NMMA
Cobalt Boats is a member of the National Marine
Manufacturers Association (NMMA). This
independent organization’s members include boat,
engine and marine equipment manufacturers that
are focused on the improvement and safety of
boating.
Your new Cobalt boat is NMMA certified. An NMMA
certification not only satisfies the U.S. Coast Guard
(USCG) regulations but also the more rigorous
equipment and system standards based on those
established by the American Boat and Yacht
Council, Inc. (ABYC).Your Cobalt boat meets or
exceeds NMMA safety-based certifications.

1-8Outboards Owner’s Manual
COBALT O UTBOARDS S ERIES S ECTION 1
FEATURES/CONSTRUCTION
Amenities
Your Cobalt boat incorporates classic styling with
the long, clean lines that have defined Cobalt
design for over 40 years.
Performance features include a hand-laid
reinforced Kevlar with an all-fiberglass stringer
system and AME 1000 vinylester resins used on
the deck and hull for superior strength, toughness
and weight savings.
Construction Standards/Certifications
A Warranty Statement explaining terms and
conditions is supplied in this section. Please
familiarize yourself with this statement. Failure to
follow operating instructions and proper
maintenance can void the warranty.
Construction Standards detailing industry
standards followed in building your Cobalt boat are
explained in this section. Please contact your
authorized Cobalt dealer for additional construction
information.
Serial Number Locations
Your Cobalt boat, its engines and propulsion units,
and other equipment onboard will have a serial
number for identification. It is a good practice to
prepare a list of all serial number items and store it
in a safe place other than onboard the boat. A page
is supplied at the end of this manual for this
purpose. The Hull Identification Number (HIN) is
located on the upper starboard side of the transom.
Please refer to the equipment operator’s manuals
supplied in your owner’s packet for location of serial
numbers.

Outboards Owner’s Manual 1-9
G ENERAL I NFORMATION
WARNING LABELS
The warning labels on your Cobalt boat must
remain legible. If a label is damaged or you suspect
a label is missing, contact your authorized Cobalt
dealer for immediate replacement.
There are several labels used to point out hazards.
All of these labels shown may not be included on
your boat. The general location of the labels is as
follows:
!
WARNING
PROPELLER LOCATED BEHIND THIS BOAT.
CONTACT MAY CAUSE SEVERE
INJURY OR FATALITY.
DO NOT APPROACH OR USE LADDER AND
PLATFORM WHEN THE ENGINE IS RUNNING.
Transom of Boat
Helm
Helm (U.S. Only)
COB_0529_A
Transom of Boat
COBALT BOATS “MEET U.S. EPA EVAP
STANDARDS USING CERTIFIED COMPONENTS”
WARNING
This tower is designed to tow a wakeboarder. Do not tow other boats,
tubes, parasails, etc. Do not climb, jump or dive off the tower. Do not sit
behind the tower where you could come in contact with the rope. Do not
allow loose ropes to hang from the tower. Do not trailer the boat with
boards or skis in the racks. Before and during each use make sure all bolts
and fasteners are tight. Make sure you have sufficient clearance above the
tower when it is up. Watch for bridges, power lines, tree limbs and other
low hanging obstacles. Failure to follow these instructions can lead to
serious injury or death.
Eclipse Arch
!WARNING
AVOID SERIOUS INJURY OR DEATH
FROM FIRE, EXPLOSION OR
ELECTRICAL SHOCK.
• This device must be connected to a Ground Fault
Circuit Interrupter (GFCI) Protected AC outlet.
• When using an extension cord, connect charger
AC plug before connecting to the GFCI protected
AC outlet.
• Make connection in an open atmosphere free of
explosive fumes.
• Make connection in a secure manner that will
avoid contact with water.
Battery Charger
Engine Compartment
Transom of Boat
WARNING
Keep hands
and feet
away from
drive unit
when tilting.
!
Near Windlass, Where Applicable
NOTE: ON OCCASION, YOU MAY HAVE TO CLEAR
THE PILE OF ROPE FROM UNDER THE HAWSE
PIPE TO MAKE ROOM FOR THE REMAINING RODE.
Engine Compartment
(All models except 302, 336 and A40)

1-10 Outboards Owner’s Manual
COBALT O UTBOARDS S ERIES S ECTION 1
Helm
Helm
(actual capacity varies by model)
Helm (California Only)
COB_0530_A
COBALT CHECK LIST
For maximum enjoyment and safety, check each of these items
BEFORE you start your engine:
— DRAIN PLUG (securely in Place?)
— LIFE-SAVING DEVICES (One for every person on board?)
— STEERING SYSTEM (Working smoothly and properly?)
— FUEL SYSTEM (Adequate fuel? Leaks? Fumes?)
— BATTERY (Fully charged? Proper water level)
— ENGINE (In neutral?)
— CAPACITY PLATE (Are you overloaded or overpowered?)
— WEATHER CONDITIONS (Safe to go out)
— ELECTRICAL EQUIPMENT (Lights, horn, pump, etc?)
— EMERGENCY GEAR (Fire extinguisher, bailer, paddle,anchor and line,
signaling device, tool kit, etc?)
RECOMMENDED SAFETY RULES
— REMAIN SEATED WHILE UNDERWAY
— AVOID USING REAR PAD OR SUNDECK WHILE ENGINE IS RUNNING
— DO NOT USE BOARDING LADDER WHILE ENGINE IS RUNNING
— TURN OFF ENGINE AND ALL ELECTRICAL SYSTEMS WHILE RE-FUELING
— TURN OFF ENGINE WHEN SWIMMERS ARE NEAR BOAT
Storage Area
Helm Area
P/N 451160
ROTATING PROPELLER MAY CAUSE
SERIOUS INJURY OR DEATH.
SHUT OFF ENGINE WHEN
NEAR PERSONS IN THE WATER.
NW-207-15
!
WARNING
SKI TOW MAXIMUM LOAD - 1,000 POUNDS
REMOVE TOW POLE BEFORE OPENING ENGINE HATCH
Ski Tow
P/N 450797

Outboards Owner’s Manual 1-11
G ENERAL I NFORMATION
COB_0531_A
Cockpit Area
P/N 451397
!WARNING
BIMINI AND ATTACHED ANCHOR LIGHT
MUST BE INSTALLED FOR NIGHTTIME
BOATING
Bimini
P/N 452937
WARNING
FUEL TANK LOCATED IN THIS AREA
FUEL LEAK, FIRE, OR EXPLOSION CAN CAUSE SERIOUS INJURY OR DEATH
DO NOT PUNCTURE, DRILL INTO OR DAMAGE THIS AREA.
Fuel Tank Area
P/N 451459
WARNING
SKI TOW MAXIMUM LOAD – 1,000 POUNDS
REMOVE SKI PYLON BEFORE TILTING ENGINE UP
Ski Area
P/N 453064
WARNING
SKI TOW MAXIMUM LOAD – 1,000 POUNDS
REMOVE SKI PYLON BEFORE TILTING ENGINE UP
Ski Area
P/N 453029
WARNING
AVOID DAMAGE OR INJURY. DO NOT EXCEED
TOW POINT MAXIMUM LOAD OF 1000 POUNDS.
Ski Area
P/N 451078
WARNING
AVOID DAMAGE OR INJURY. DO NOT USE
AS A TOW POINT.
Ski Area
P/N 452695
EMISSIONS CONTROL SYSTEM INFORMATION
MEETS U.S. EPA EVAP STANDARDS USING CERTIFIED COMPONENTS
AND MEETS 2019 MY CALIFORNIA EVAP EMISSIONS REGULATIONS
FOR SPARK-IGNITION MARINE WATERCRAFT
MANUFACTURER: COBALT BOATS, LLC
CALIFORNIA EVAP FAMILY: KCOBCVSSL001
EMISSIONS CONTROL SYSTEM: CP
2
Helm Area
P/N 453120

1-12 Outboards Owner’s Manual
COBALT O UTBOARDS S ERIES S ECTION 1
PUBLICATIONS
Your owner’s packet includes information about
onboard systems and equipment furnished by
suppliers other than Cobalt Boats. Please refer to
these manufacturer’s manuals for additional
operation and maintenance instructions not
covered in this manual.
NAUTICAL TERMS
ABOARD – On or in the boat.
ABYC – American Boat and Yacht Council, Inc.
AFLOAT – On the water.
AFT – Toward the rear or stern of the boat.
AGROUND – Touching bottom.
AMIDSHIP – Center or middle of the boat.
ANCHOR – (1) An iron casting shaped to grip the
lake bottom to hold the boat. (2) The act of setting
the anchor.
ASHORE – On the shore.
ASTERN – Toward the stern.
BAIL – To remove water from the bottom of the
boat with a pump, bucket, sponge, etc.
BEAM – The widest point on the boat.
BEARING – Relative position or direction of an
object from the boat.
BILGE – The lowest interior section of the boat hull.
BOARDING – To enter the boat.
BOUNDARY WATERS – A body of water between
two areas of jurisdiction; i.e., a river between two
states.
BOW – The front of the boat.
BULKHEAD – Vertical partition (wall) in a boat.
BUNKS – Carpeted trailer hull supports.
BURDENED BOAT – Term for the boat that must
“give-way” to boats with the right-of-way.
CAPACITY PLATE – A plate that provides
maximum weight capacity and engine horsepower
rating information. It is located in full view of the
helm.
CAPSIZE – To turn over.
CAST-OFF – To unfasten mooring lines in
preparation for departure.
CENTER LINE – A lengthwise imaginary line which
runs fore and aft with the boat’s keel.
CHINE – The point on a boat where the side
intersects (meets) the bottom.
CLEAT – A deck fitting with ears to which lines are
fastened.
CONSOLE – Also called helm. The steering wheel
area of the boat.
CRANKING BATTERY – The main battery used for
engine starting and electrical circuits.
CURRENT – Water moving in a horizontal
direction.
DECK – The open surface on the boat where the
passengers walk.
DEEP CYCLE BATTERIES – Special long-running
batteries which can be repeatedly discharged and
recharged without significant loss of power.
DOLLY WHEEL – A rolling jack assembly at the
front of the trailer used for positioning the coupler
during trailer hookup.
DRAFT – The depth of the boat below the water
line, measured vertically to the lowest part of the
hull.
ELECTROLYSIS – The break-up of metals due to
the effects of galvanic corrosion.
EPIRB – Emergency Position Indicating Radio
Beacon.
FATHOM – Unit of depth or measure; 1 fathom
equals 6 feet.
FENDERS – Objects placed alongside the boat for
cushioning. Sometimes called bumpers.
