Cobalt Digital Inc 9323 User manual

9323
9322
9321
2406 E. University Ave.
Urbana, IL 61802
Voice 217.344.1243 • Fax [phone]
www.cobaltdigital.com
Product Manual
9323G-OM (V4.6)
Cobalt Digital Inc.
HD/SD Video Proc and Embedder/De-Embedders
with Dolby®Decoding Option

Copyright
©Copyright 2013, Cobalt Digital Inc. All Rights Reserved.
Duplication or distribution of this manual and any information contained within is strictly prohibited without the express written
permission of Cobalt Digital Inc. This manual and any information contained within, may not be reproduced, distributed, or
transmitted in any form, or by any means, for any purpose, without the express written permission of Cobalt Digital Inc.
Reproduction or reverse engineering of software used in this device is prohibited.
Disclaimer
The information in this document has been carefully examined and is believed to be entirely reliable. However, no responsibility
is assumed for inaccuracies. Furthermore, Cobalt Digital Inc. reserves the right to make changes to any products herein to improve
readability, function, or design. Cobalt Digital Inc. does not assume any liability arising out of the application or use of any
product or circuit described herein.
Trademark Information
Cobalt®is a registered trademark of Cobalt Digital Inc.
COMPASS® and FUSION3G®are registered trademarks of Cobalt Digital Inc.
openGear®is a registered trademark of Ross Video Limited. DashBoard™ is a trademark of Ross Video Limited. Dolby®is a
registered trademark of Dolby Laboratories, Inc. Other product names or trademarks appearing in this manual are the property of
their respective owners.
Linear Acoustic®, AEROMAX®and UPMAX® are registered trademarks of Linear Acoustic, Inc. 2.0-to-5.1 audio upmixer
licensed feature uses the AutoMAX-II™ upmix algorithm provided under license from
Linear Acoustic Inc. Linear Acoustic, the "LA" symbol, AutoMAX, and AutoMAX-II are trademarks of Linear Acoustic Inc.
All Rights Reserved.
Congratulations on choosing the Cobalt®9323 group of HD/SD Video Proc and Embedder/De-Embedders with
Dolby®Decoding Option The 9323 group is part of a full line of modular processing and conversion gear for
broadcast TV environments. The Cobalt Digital Inc. line includes video decoders and encoders, audio
embedders and de-embedders, distribution amplifiers, format converters, remote control systems and much
more. Should you have questions pertaining to the installation or operation of this card, please contact us at the
contact information on the front cover.
Manual No.: 9323G-OM
Document Version: V4.6
Release Date: October 7, 2013
Applicable for
Firmware Version
(or greater): 3314
Description of
product/manual
changes:
- Update to add new Rear I/O Module.
- Revise manual for minor edits.
- Update manual to include latest available card
options.
9323G-OM (V4.6)

9323G-OM (V4.6) 9323 GROUP PRODUCT MANUAL i
Table of Contents
Chapter 1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Overview ................................................................................................................ 1-1
932X Card Software Versions and this Manual..................................................... 1-2
Cobalt Reference Guides........................................................................................ 1-2
Manual Conventions............................................................................................... 1-3
Warnings, Cautions, and Notes .................................................................. 1-3
Labeling Symbol Definitions...................................................................... 1-4
Safety Summary ..................................................................................................... 1-4
Warnings..................................................................................................... 1-4
Cautions...................................................................................................... 1-4
932X Functional Description.................................................................................. 1-5
932X Input/Output Formats........................................................................ 1-5
Video Processor Description ...................................................................... 1-6
Audio Processor Description...................................................................... 1-9
AES Audio Input Advanced Features (9321, 9323 Only)........................ 1-14
Dolby®Decoding Option (+DEC)............................................................ 1-15
User Control Interface .............................................................................. 1-17
932X Rear I/O Modules ........................................................................... 1-19
Audio and Video Formats Supported by the 932X Group....................... 1-20
Technical Specifications....................................................................................... 1-21
Warranty and Service Information ....................................................................... 1-24
Cobalt Digital Inc. Limited Warranty....................................................... 1-24
Contact Cobalt Digital Inc.................................................................................... 1-25
Chapter 2 Installation and Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Overview ................................................................................................................ 2-1
Setting I/O Switches for AES I/O (1-4) Ports (9321, 9323 Only).......................... 2-1
Installing the Card Into a Frame Slot...................................................................... 2-2
Installing a Rear I/O Module.................................................................................. 2-4
923X Group Rear I/O Modules .................................................................. 2-5
Setting Up Card Network Remote Control........................................................... 2-20

ii 9323 GROUP PRODUCT MANUAL 9323G-OM (V4.6)
Chapter 3 Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Overview................................................................................................................. 3-1
Control and Display Descriptions........................................................................... 3-1
Function Submenu/Parameter Submenu Overview .................................... 3-2
DashBoard™User Interface....................................................................... 3-3
Cobalt®Remote Control Panel User Interfaces .......................................... 3-4
Accessing the Card via Remote Control................................................................. 3-5
Accessing the Card Using DashBoard™.................................................... 3-5
Accessing the Card Using a Cobalt®Remote Control Panel ...................... 3-6
Checking Card Information..................................................................................... 3-7
Ancillary Data Line Number Locations and Ranges .............................................. 3-8
932X Group Function Submenu List and Descriptions.......................................... 3-9
Audio Input Controls ................................................................................ 3-10
Video Proc ................................................................................................ 3-13
AFD .......................................................................................................... 3-14
Embedded Audio Group 1/2 .................................................................... 3-15
Embedded Audio Group 3/4 .................................................................... 3-19
AES Audio Out Pairs 1-4 ......................................................................... 3-21
AES Audio Out Pairs 5-8 ......................................................................... 3-25
Timecode .................................................................................................. 3-26
Dolby Decoder ......................................................................................... 3-30
Dolby E Metadata .................................................................................... 3-33
Dolby D Metadata .................................................................................... 3-34
Audio Mixing ........................................................................................... 3-35
Tone Generator ......................................................................................... 3-40
Licensable Features .................................................................................. 3-40
Presets ...................................................................................................... 3-41
Dolby®E Processing and Routing Example (+DEC only) ....................... 3-43
Troubleshooting .................................................................................................... 3-45
Error and Failure Indicator Overview....................................................... 3-45
Basic Troubleshooting Checks.................................................................. 3-49
932X Group Processing Error Troubleshooting........................................ 3-50
Troubleshooting Network/Remote Control Errors.................................... 3-52
In Case of Problems .................................................................................. 3-52

9323G-OM (V4.6) 9323GROUPPRODUCTMANUAL 1-1
Chapter 1
Chapter 1 Introduction
Overview
This manual provides installation and operating instructions for the
9323 group of HD/SD Video Proc and Embedder/De-Embedders with Dolby®
Decoding cards (also referred to herein as the 932X or “card”).
Note: This manual covers the 9323 group, which consists of the 9323, 9322, and
9321 cards. These cards vary only in audio embedding/de-embedding capa-
bilities; the differences are described in detail later in this section.
All of the 9323 group cards are available with Dolby®decoding as an option.
Cards equipped with this option are identified by suffix “+DEC”in both part
numbers and this manual. Where applicable, descriptions related exclusively
to the either the 932X or the 932X+DEC are respectively denoted by
(932X only) or (932X+DEC only). In all other aspects, both the 932X and
932X+DEC cards function identically as described in this manual.
This manual consists of the following chapters:
•Chapter 1, “Introduction”–Provides information about this manual
and what is covered. Also provides general information regarding the
932X group.
•Chapter 2, “Installation and Setup”–Provides instructions for
installing this card in a frame, and optionally installing Rear I/O
Modules.
•Chapter 3, “Operating Instructions”–Provides overviews of
operating controls and instructions for using this card.
This chapter contains the following information:
•932X Card Software Versions and this Manual (p. 1-2)
•Manual Conventions (p. 1-3)
•Safety Summary (p. 1-4)
•932X Functional Description (p. 1-5)
•Technical Specifications (p. 1-21)
•Warranty and Service Information (p. 1-24)
•Contact Cobalt Digital Inc. (p. 1-25)

1932X Card Software Versions and this Manual
1-2 9323 GROUP PRODUCT MANUAL 9323G-OM (V4.6)
932X Card Software Versions and this Manual
When applicable, Cobalt Digital Inc. provides for continual product
enhancements through software updates. As such, functions described in this
manual may pertain specifically to cards loaded with a particular software
build.
The Software Version of your card can be checked by viewing the Card Info
menu in DashBoard™. See Checking Card Information (p. 3-7) in Chapter 3,
“Operating Instructions”for more information. You can then check our
website for the latest software version currently released for the card as
described below.
Check our website and proceed as follows if your card’s software does not
match the latest version:
Cobalt Reference Guides
From the Cobalt®web home page, go to Support>Documents>Reference
Guides for easy to use guides covering network remote control, card firmware
updates, and other topics.
Card Software earlier than
latest version Card is not loaded with the latest software. Not all
functionsand/orspecifiedperformancedescribedin
this manual may be available.
You can update your card with new Update
software by going to the Support>Firmware
Downloads link at www.cobaltdigital.com.
Download “Firmware Update Guide”, which
provides simple instructions for downloading the
latest firmware for your card onto your computer,
and then uploading it to your card through
DashBoard™.
Software updates are field-installed without any
need to remove the card from its frame.
Card Software newer than
version in manual A new manual is expediently released whenever a
card’s software is updated and specifications
and/or functionality have changed as compared
to an earlier version (a new manual is not
necessarily released if specifications and/or
functionality have not changed). A manual earlier
than a card’s software version may not completely
or accurately describe all functions available for
your card.
If your card shows features not described in this
manual, you can check for the latest manual (if
applicable) and download it by going to the
Support>Documents>Product Information and
Manuals link at www.cobaltdigital.com.

9323G-OM (V4.6) 9323 GROUP PRODUCT MANUAL 1-3
Introduction Manual Conventions
Manual Conventions
In this manual, display messages and connectors are shown using the exact
name shown on the card itself. Examples are provided below.
•Card-edge display messages are shown like this:
•Connector names are shown like this: SDI IN
In this manual, the terms below are applicable as follows:
•932X refers to the 9232 group of HD/SD Video Proc and Embedder/
De-Embedders with Dolby®Decoding Option cards.
•Frame refers to the 20-slot frame that houses the Cobalt®Compass®
and/or Fusion3G®cards.
•Device and/or Card refers to a Compass®card.
•System and/or Video System refers to the mix of interconnected
production and terminal equipment in which this card and other
Compass®cards operate.
•Functions and/or features that are available only as an option are
denoted in this manual like this:
Warnings, Cautions, and Notes
Certain items in this manual are highlighted by special messages. The
definitions are provided below.
Warnings
Warning messages indicate a possible hazard which, if not avoided, could
result in personal injury or death.
Cautions
Caution messages indicate a problem or incorrect practice which, if not
avoided, could result in improper operation or damage to the product.
Notes
Notes provide supplemental information to the accompanying text. Notes
typically precede the text to which they apply.
Ch01

1Safety Summary
1-4 9323 GROUP PRODUCT MANUAL 9323G-OM (V4.6)
Labeling Symbol Definitions
Safety Summary
Warnings
Cautions
Attention, consult accompanying documents.
Electronic device or assembly is susceptible to damage from an ESD
event. Handle only using appropriate ESD prevention practices.
If ESD wrist strap is not available, handle card only by edges and avoid
contact with any connectors or components.
Symbol (WEEE 2002/96/EC)
For product disposal, ensure the following:
•Do not dispose of this product as unsorted municipal waste.
•Collect this product separately.
•Use collection and return systems available to you.
! WARNING ! To reduce risk of electric shock do not remove line voltage service barrier cover on frame
equipment containing an AC power supply. NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION This device is intended for environmentally controlled use only in appropriate video
terminal equipment operating environments.
CAUTION This product is intended to be a component product of an openGear®frame. Refer to the
frame Owner's Manual for important safety instructions regarding the proper installation
and safe operation of the frame as well as its component products.
CAUTION Heat and power distribution requirements within a frame may dictate specific slot
placement of cards. Cards with many heat-producing components should be arranged to
avoid areas of excess heat build-up, particularly in frames using only convection cooling.
This card has a moderate power dissipation (15 W max.). As such, avoiding placing the
card adjacent to other cards with similar dissipation values if possible.
CAUTION If required, make certain Rear I/O Module(s) is installed before installing the card into the
frame slot. Damage to card and/or Rear I/O Module can occur if module installation is
attempted with card already installed in slot.
CAUTION If card resists fully engaging in rear I/O module mating connector, check for alignment and
proper insertion in slot tracks. Damage to card and/or rear I/O module may occur if
improper card insertion is attempted.

9323G-OM (V4.6) 9323 GROUP PRODUCT MANUAL 1-5
Introduction 932X Functional Description
932X Functional Description
The 932X group includes a full 16-channel audio processor/router and video
proc. A Dolby®decoder option is available for all 932X group cards.
Note: Some of the functions described below are available only when using the
DashBoard™, or Cobalt®OGCP-9000 or OGCP-9000/CC Control Panels
user interfaces. Refer to User Control Interface (p. 1-17) for user interface
descriptions.
932X Input/Output Formats
The 9321, 9322, and 9323 cards which comprise the 932X group vary only in
the input/output complement and embedding/de-embedding capabilities as
shown in Figure 1-1. Where functional or operating descriptions apply only to
specific cards, these differences are noted.
Figure 1-1 932X Group Input/Output Details
HD/SD-SDI IN
AN-AUD IN (1–8)
AES IN (PAIR 1–8) HD/SD-SDI RCK OUT (X4)
HD/SD-SDI OUT (X2)
AES OUT (PAIR 1–8)
9323
HD/SD-SDI IN
HD/SD-SDI RCK OUT (X4)
HD/SD-SDI OUT (X2)
AES OUT (PAIR 1–8)
9322
HD/SD-SDI IN
AN-AUD IN (1–8)
AES IN (PAIR 1–8) HD/SD-SDI RCK OUT (X4)
HD/SD-SDI OUT (X2)
9321
(Audio Embed/
De-Embed)
(Audio
De-Embed)
(Audio Embed)

1932X Functional Description
1-6 9323 GROUP PRODUCT MANUAL 9323G-OM (V4.6)
Video Processor Description
Video Processor
(See Figure 1-2.) The card provides full color processing control (luma gain
and lift, chroma saturation, and color phase) of the output video.
AFD Inserter
This function provides for assignment and insertion of AFD codes into the
SDI output video. Using this function, AFD codes in accordance with the
standard 4-bit AFD code designations can be applied to the output video.
This function checks for any existing AFD code within the received video
input. If a code is present, the code is displayed. When used in conjunction
with a separate downstream card capable of providing AFD-directed scaling,
the image can in turn be scaled in accordance with the AFD coding embedded
by this card.
The function also allows the selection/changing of the AFD code and
ancillary data line number for the outputted AFD code.

9323G-OM (V4.6) 9323 GROUP PRODUCT MANUAL 1-7
Introduction 932X Functional Description
Figure 1-2 932X Functional Block Diagram
Deserialize Audio
De-Embed
Differential Analog
Audio A/D
AES Decode
and SRC
Audio
Routing/
Gain
Control
Video
Processing
Audio
Embed
AES
Encode
Serializer/
Cable Drivers
HD/SD SDI IN
AN-AUD IN (1-8)
(9321, 9323 Only)
AES IN (5-8)
(9321, 9323 Only)
SDI OUT
AES OUT
(9322, 9323 Only) (5-8) (1-4)
Video Processor
Audio Processor
AES I/O (1-4)
(9321, 9323 Only)
[AES IN (1-4)]
[AES OUT (1-4)]
S11–S14
Dolby®Decode
(NOTE 2)
DOLBY META (NOTE 2)
Notes: 1. Signal connections shown depicts full card
input/outputcapability.Practicalinput/output signal availability is determined by Rear I/O Module used. Refer to “932X Rear I/O
Modules,”1-19 for more information.
2. Dolby®decode function applicable only for
+DEC models.
Reclock
EQ
RCK OUT
932XV4BD
TC
Processing Audio LTC
AFD
Processing

1932X Functional Description
1-8 9323 GROUP PRODUCT MANUAL 9323G-OM (V4.6)
Timecode Processor
(See Figure 1-3.) This function provides for extraction of timecode data from
the input video, and in turn re-insertion of timecode data into the output SDI.
The function can monitor analog and SDI video streams, and audio LTC over
a selected channel, for supported timecode formats and then select and
prioritize among analog VITC, SDI VITC, SDI ATC_VITC, SDI ATC_LTC,
and audio LTC timecode sources. Audio LTC can be received over a selected
balanced analog audio input, or as digital audio over a selected embedded or
AES input. If the preferred format is detected, the preferred format is used by
the card; if the preferred format is not detected, the card uses other formats
(where available) as desired.
The function also provides conversion between various timecode formats and
provides independent insertion and line number controls for each SDI
timecode output format.
Option +LTC allows bidirectional transfer and conversion
between VBI formats over SDI and audio LTC, as well as RS-485 LTC.
Audio LTC can be received or sent over a selected balanced analog audio
input, or as digital audio over a selected embedded or AES input.
Figure 1-3 Timecode Processor
SDI VITC
Detect/Extract
SDI ATC_LTC
Detect/Extract
SDI ATC_VITC
Detect/Extract
Priority/
Select
SDI
Video
Input
SDI VITC
Timecode
Proc/Embed
ATC_VITC
Timecode
Proc/Embed
ATC_LTC
Timecode
Proc/Embed HD/SD–SDI
Video Output
Insert
Control
Line
Number
Control
Buffer/
Format
HD/SD–SDI
(From Video Proc)
Audio LTC
Select/Extract
Audio/
RS-485 LTC Audio/RS-485
LTC Generate
Audio LTC Out
RS-485 LTC Out

9323G-OM (V4.6) 9323 GROUP PRODUCT MANUAL 1-9
Introduction 932X Functional Description
Audio Processor Description
(See Figure 1-2.) The audio processor operates as an internal audio router.
The router function chooses from the following inputs:
•16 channels of embedded audio from the SDI video
•16 channels (8 pairs) of discrete AES input (9321, 9323 only)
•8 channels of balanced analog audio input (9321, 9323 only)
•Four independent internal tone generators (described below)
•Digital silence (mute) setting
•Internal down mix and mono mixer outputs (described below)
•(+DEC only) Decoded Dolby®channels
The router function provides the following audio outputs:
•16 channels of embedded audio on the SDI output
•16 channels of discrete AES output on eight AES pairs (9322, 9323
only)
The router acts as a full audio cross point. Each of the output channels can
receive signal from any one of the input channel sources, four internal tone
generators, or the Down Mix Left and/or the Down Mix-Right mixer outputs.
Unused output channels can be mapped to a “Silence”source. Each output
also provides gain adjustment and selectable polarity inversion.
(+DEC only) In addition to the audio sources described above, the up to 10
decoded Dolby®channels are available as input sources.
Output audio rates are always 48 kHz locked to output video, but discrete
AES inputs can pass through the sample rate converters to align these inputs
with the output timing. (AES must be nominally 48 kHz input; 32, 44.1, 96,
and 192 kHz inputs are not compatible with the card.) The sample rate
converters are disabled by default. Output AES is always precisely
synchronized with the output video. The balanced analog audio input is
sampled at 48 kHz with a +24 dBu clipping level (+24 dBu => 0 dBFS).
Note: As shown in Figure 1-4, the 9322 and 9323 are equipped with eight discrete
AES input pair ports and eight discrete AES output pair ports. On Rear I/O
Modules having limited AES I/O capabilities, switches S11 thru S14 allow
available rear module BNC connectors to be allotted between AES inputs and
outputs as desired. Buffered copies of AES OUT (1-4) are available as dedi-
cated outputs and as respective outputs fed through S11 –S14 on the card.

1932X Functional Description
1-10 9323 GROUP PRODUCT MANUAL 9323G-OM (V4.6)
Figure 1-4 Default Embed/De-Embed Audio Routing
Audio Down Mixer and Mono Mixer Function
(See Figure 1-5.) The Audio Down Mixer function provides for the selection
of any five embedded, AES discrete, or analog audio sources serving as Left
(L), Right (R), Center (C), Left Surround (Ls), and Right Surround (Rs)
individual signals to be multiplexed into a stereo pair (Down Mix Left (DM-L)
and Down Mix Right (DM-R)). The resulting stereo pair DM-L and DM-R can in
turn be routed and processed just like any of the other audio sources described
earlier.
Figure 1-5 Audio Mixing Functional Block Diagram with Example Sources
Embed Ch 1
AES Ch 1
Embedded Audio
Group 1/2
Embed Ch 8
•
•
•
•
•
•
AES Ch 8
Embed Ch 9
AES Ch 9
Embedded Audio
Group 3/4
Embed Ch 16
•
•
•
•
•
•
AES Ch 16
AES Ch 1
AES Audio Out
Pairs 1-4
•
•
•
AES Ch 8
AES Ch 9
AES Audio Out
Pairs 5-8
•
•
•
AES Ch 16
DM-L
Ls
L
C
R
Rs
DM-R
Embedded Ch 1
Embedded Ch 2
AES Ch 6
Embedded Ch 4
Embedded Ch 5
AES Ch 1 - Ch 16
AN-AUD Ch 1- Ch 8
Embed Ch 1 - Ch 16

9323G-OM (V4.6) 9323 GROUP PRODUCT MANUAL 1-11
Introduction 932X Functional Description
The Mono Mixer function (Figure 1-6) generates an additional mono-mixed
channel from two selected embedded, AES discrete, or analog input channels
serving as left and right inputs. The resulting mono mix channel MONO can in
turn be routed and processed just like any of the other audio sources described
earlier.
Figure 1-6 Audio Mono Mix Functional Block Diagram with Example Sources
2.0-to-5.1 Upmix Function
Note: Upmix function is an optional licensable feature. This function and its controls
appear only when a license key is entered and activated. (This option (identi-
fied in Cobalt®price lists as +UM) can be purchased upon initial order, or
field-activated using a key string which is sent to you when this option is pur-
chased.)
The 2.0-to-5.1 upmixer function receives a normal PCM stereo pair from the
Audio Routing/Gain Control function and upmixes the pair to provide 5.1
channels (Left (L), Right (R), Center (C), Low Frequency Effects (LFE), Left
Surround (Ls), and Right Surround (Rs)). Whenever the upmixer is active, it
overwrites the six selected channels with the new 5.1 upmix signals
(including replacing the original source stereo Land Rinputs with new L and
R signals).
The 2.0-to-5.1 upmixer can be set to up mix in any of three modes: Always
upmix, Bypass upmix, or Auto enable/bypass upmixing. The Auto upmixing
mode looks at the signal levels on the selected channels and compares them to
a selectable level threshold. It then determines whether or not to generate 5.1
upmixing from the stereo pair as follows:
•If the upmixer detects signal level below a selected threshold on all
four of the selected channels designated as C, LFE, Ls, and Rs, this
indicates to the upmixer that these channels are not carrying 5.1. In
this case, the upmixer overwrites all six selected channels with the
new 5.1 content.
•If the upmixer detects signal level above a selected threshold on any
of the four selected channels designated as C, LFE, Ls, and Rs, this
indicates to the upmixer that the channel(s) are already carrying
viable 5.1 content. In this case, the upmixer is bypassed, allowing the
original channels to pass unaffected.
MONO
LΣ
R
Emb Ch 12
Emb Ch 16
AES Ch 1 - Ch 16
AN-AUD Ch 1- Ch 8
Emb Ch 1 - Ch 16

1932X Functional Description
1-12 9323 GROUP PRODUCT MANUAL 9323G-OM (V4.6)
The examples in Figure 1-7 show the automatic enable/disable up-mixing
function applied to example selected channels Emb Ch 1 thru Emb Ch 6. As
shown and described, the processing is contingent upon the signal levels of
the channels selected to carry the new 5.1 upmix relative to the selected
threshold (in this example, -60 dBFS). Note also that this function is applied
after the Audio Routing/Gain Control function. Because all audio inputs pass
through the Audio Routing/Gain Control function before the up mixer, the up
mixer can use embedded, AES discrete, and/or analog audio sources.
Figure 1-7 Up Mix Auto Enable/Bypass with Example Sources
Emb Ch 1 –Ch 16
>
From Audio
Routing/Gain
Control
Emb Ch 1
Emb Ch 2
Emb Ch 3
Emb Ch 4
Emb Ch 5
Emb Ch 6
L
R
(C)
(LFE)
(Ls)
(Rs)
L– Emb Ch 1
R– Emb Ch 2
C– Emb Ch 3
LFE– Emb Ch 4
Ls – Emb Ch 5
Rs – Emb Ch 6
To Audio
Embed
With alldetectedsignallevelson
EmbCh3–Ch 6 below
threshold, upmixer is active and
overwrites with new 5.1.
Threshold
Detect 5.1 Up Mix
Selected channels Emb Ch 1 –Ch 6
are overwritten with the new 5.1
upmix content.
Emb Ch 1 –Ch 16
>
From Audio
Routing/Gain
Control
Emb Ch 1
Emb Ch 2
Emb Ch 3
Emb Ch 4
Emb Ch 5
Emb Ch 6
L
R
(C)
(LFE)
(Ls)
(Rs)
To Audio
Embed
Threshold
Detect 5.1 Up Mix
Because the selected channels are
already carrying viable content,
upmixing is bypassed, allowing the
six original Emb Ch 1 –Ch 6 to pass
unaffected.
With any detected signal levels
on Emb Ch 3 –Ch 6 above
threshold, upmixer is bypassed.
X
X
X
Note: In either case shown here, the unselected
channels (in this example, Emb Ch 7 thru Ch
16) are not involved in this process and always
pass unaffected.
- 20 dBFS
- 60 dBFS
AboveThreshold
(Bypass)
C
LFE
Ls
Rs
- 20 dBFS
- 60 dBFS
Below Threshold
(Overwrite)
C
LFE
Ls
Rs

9323G-OM (V4.6) 9323 GROUP PRODUCT MANUAL 1-13
Introduction 932X Functional Description
Loudness Processor (Option +LP)
Note: Loudness processor function is an optional licensable feature. This function
and its controls appear only when a license key is entered and activated.
(This option (identified in Cobalt®price lists as +LP) can be purchased upon
initial order, or field-activated using a key string which is sent to you when this
option is purchased.)
If your card was purchased with option +LP, loudness processor manual
supplement “5.1 and Stereo Loudness Processing Options for Compass®
Cards (+LP51, +LP20) Manual Supplement”(OPT-SW-LP-MS) is included
in your documentation package. Supplement OPT-SW-LP-MS can be
downloaded from our website or requested using the Cobalt contact
information in this manual.
Tone Generator Function
The card contains four built-in tone generators (Tone Generator 1 thru Tone
Generator 4). Each of the four tone generators can be set to a different
frequency, and are available as audio sources for the embedded or AES audio
outputs.
18 discrete sine wave frequencies are available, ranging from 50 Hz to 16 kHz
(default frequency is 1.0 kHz).
Audio Routing Example
Figure 1-8 shows an example of using the 9323 audio embedding/
de-embedding and routing functions to de-embed audio, route the audio to
discrete outputs for post-production processing (in this example, a console
used for post-production EQ, levels, and monitor), and finally re-embed the
audio into the SDI video output. Additionally, the example shows how
external analog sources can be embedded into the SDI output (in this
example, a provision for local station ID voice-over analog).
Note that the source and destination correlations shown here are only
examples; any source can route to any destination.

1932X Functional Description
1-14 9323 GROUP PRODUCT MANUAL 9323G-OM (V4.6)
Figure 1-8 Audio Routing Example
AES Audio Input Advanced Features (9321, 9323 Only)
AES Sample Rate Converter
The card AES inputs have sample rate converters that can be independently
enabled for each AES pair to allow the card to interface with asynchronous
AES sources (sources in which AES timing does not match the video input
timing). The sample rate converters are set to disabled (bypassed) by default;
this is necessary when embedding undecoded, non-PCM audio such as
Dolby®E or Dolby®Digital™audio streams. When a valid Dolby®E or
Dolby®Digital™signal (in accordance with SMPTE 337M) is detected on an
AES or embedded audio signal, SRC is automatically bypassed along with
gain and polarity controls.
Embed Ch 1
AES IN 5
Embed Ch 2
AES Ch 9
AES Ch 10
Analog
Ch 1
SDI IN
Audio
De-Embed
Embed Ch 3
Embed Ch 4
AES Ch11
AES Ch 12
Audio Embed/
Routing
AES Ch 15
AES Ch 16
AES Ch 1
AES Ch 2
AES Ch 3
AES Ch 4
AES Ch 5
AES Ch 6
AN-AUD IN 1
Embed Ch 1
Embed Ch 2
Silence
Audio
Embed
SDI OUT
AN-AUD IN 2
AES IN 6
AES IN 8
AES OUT 1
AES OUT 2
AES OUT 3
Analog
Ch 2
9323
Post-Production Console
Post-Production
Video Feed
(with four
embedded audio
channels)
Analog
2-Channel
Voice-Over
Feed
OTA Video
Feed (with
six embedded
audio channels)
Embed Ch 3
Embed Ch 4
Embed Ch 5
Embed Ch 6
Embed Ch 7 –
EmbedCh 16

9323G-OM (V4.6) 9323 GROUP PRODUCT MANUAL 1-15
Introduction 932X Functional Description
Zero-Delay Audio Embedding
In cases where additional delay must be avoided, it may be desirable to embed
AES with minimum latency. Using zero-delay embedding, the video can then
be delayed by one frame to account for any remaining audio delay. In this
manner, any delay between video and audio can be cleanly contained and
managed within one frame period.
When zero-delay audio embedding is enabled for a given AES pair, the pair is
directly embedded into its corresponding group (for example, AES Pair 1 into
embedded channels 1 and 2; AES Pair 2 into embedded channels 3 and 4, and
so on) with the normal frame sync audio delay being bypassed.
This function overrides the audio routing system (for example if AES Pair 1 is
selected, then the controls to route AES Pair 1 into other embedded channels
will not apply). Gain and polarity control is not available when this option is
selected. Zero-delay audio embedding is set to Off by default.
Low-Latency AES Passthrough
This function is similar to zero-delay audio embedding. If low-latency AES
passthrough is selected for a given input pair, it causes the corresponding
AES output pair to act as a bit-for-bit copy of the corresponding AES input
pair. This control overrides the normal audio routing and delay. Gain and
polarity control is not available when this option is selected. Passthrough is
set to Off by default.
Dolby®Decoding Option (+DEC)
Note: Although the +DEC Dolby®decoder-equipped cards can provide Dolby®Digi-
tal™(AC-3) decoding, discussion and examples here describe only Dolby®E
decoding.
When Dolby®E or Dolby®Digital™is present on a discrete AES pair or an
embedded audio pair, the decoder produces up to 10 decoded channels
(according to the Dolby®sub-format received from the metadata). All
resulting channels are available as inputs to the audio router.

1932X Functional Description
1-16 9323 GROUP PRODUCT MANUAL 9323G-OM (V4.6)
Dolby®Identification and Metadata Output Processing
(See Figure 1-9.) All AES pairs and embedded channels are checked by the
+DEC card for valid Dolby®status. When a valid Dolby®encoded embedded
or discrete AES pair is detected, the channel pair carrying the Dolby®format
is displayed as “Present Dolby E”or “Present Dolby Digital”, as applicable.
(The decoder always uses the metadata associated with its respective AES or
embedded pair.) A selected encoded channel pair can then be directed to the
Dolby®decoder. The decoder then displays the Dolby®bitstream format and
program configuration (for example, “Dolby E 20-bit 5.1+2”indicating
5-channel surround with LFE channel and stereo monitor pair) for the
selected pair, as defined by its metadata.
The +DEC card can embed metadata on the SDI output, sourced from either
SDI input video or from the decoder as desired. Similarly, the DOLBY META
output can provide RS-485 metadata for downstream devices or systems.
Metadata on the DOLBY META RS-485 output can also be sourced from either
SDI input video or from the decoder as desired.
Audio Decoding
(See Figure 1-9.) Based on the channels carrying the Dolby®encoded pair and
the format defined within, the Dolby®decoder provides up to 10 decoded
audio channels (Dolby Ch 1 thru Dolby Ch 8; Dolby Mix 1, Dolby Mix 2). Each
channel can be routed just as any other audio channel described in this
section.
Figure 1-9 Dolby®Decoding and Metadata Output Processing
SDI IN
De-embed SMPTE 2020
De-mux
Discrete
AES IN Pair
Dolby®Encoded Channel/
Format/Program
Identification (User
Interface Display)
SDI OUT
DOLBY
META
SMPTE 2020
Mux
Dolby®
Decode
Dolby®Encoded Embedded
Pair (1+2)...(15+16)
Dolby®Encoded AES
Pair (1)...(8)
Ch 1
Mix 2
Dolby®
Decoded
Audio
Channels (Ch 1...Mix 2)
2X2 Mux
Input Select
Input Video
Metadata
Decoder
Metadata
