Cobalt NASRaQ
™
User Manual

©1999 Cobalt Networks, Inc. All rights reserved.
Cobalt Networks and Cobalt NASRaQ are trademarks of Cobalt Networks, Inc. All other company,
brand, and product names may be registered trademarks or trademarks of their respective companies
and are hereby recognized.
This publication and the information herein is furnished AS IS, subject to change without notice, and
should not be construed as a commitment by Cobalt Networks, Inc. Furthermore, Cobalt Networks,
Inc., assumes no responsibility or liability for any errors or inaccuracies, makes no warranty of any
kind (express, implied or statutory) with respect to this publication, and expressly disclaims any and
all warranties of merchantability, Þtness for particular purposes and noninfringement of third party
right.
The majority of the software used within the Cobalt NASRaQ can be freely distributed under the
terms of the BSD copyright and the GNU Public License. See ÒLicensesÓ on page 49 for more
information. However, some applications remain the property of their owners, and require their
permission to redistribute. For a complete listing of the software used within the Cobalt NASRaQ,
and the terms under which it can be distributed, refer to the Cobalt web site at www.cobaltnet.com.
This product includes software developed by the University of Michigan, and its contributors.
Copyright © 1990,1996 Regents of The University of Michigan. All Rights Reserved.
Permission to use, copy, modify, and distribute this software and its documentation for any
purpose and without fee is hereby granted, provided that the above copyright notice appears in
all copies and that both that copyright notice and this permission notice appear in supporting
documentation, and that the name of The University of Michigan not be used in advertising or
publicity pertaining to distribution of the software without speciÞc, written prior permission.
This software is supplied as is without expressed or implied warranties of any kind.
Research Systems Unix Group, The University of Michigan c/o Wesley Craig, 535 W. William Street,
Ann Arbor, Michigan, [phone], [email protected]
This product includes software developed by the University of California, Berkeley and its
contributors.
ModiÞcations to Appleshare IP are under the following copyright:
Copyright © 1997,1998 Adrian Sun ([e-mail]). All Rights Reserved.
Permission to use, copy, modify, and distribute this software and its documentation for any
purpose and without fee is hereby granted, provided that the above copyright notice appears in
all copies and that both that copyright notice and this permission notice appear in supporting
documentation. This software is supplied as is without expressed or implied warranties of any
kind.
The Cobalt NASRaQ includes software developed by the Apache Group for use in the Apache HTTP
server project (http://www.apache.org/).
Cobalt Networks, Inc.
555 Ellis Street
Mountain View, CA 94043
www.cobaltnet.com
In the U.S.A.:
Phone (888) 70-COBALT
[phone]
Fax [phone]
Outside the U.S.A.:
Phone [phone]
Fax [phone]

iii
Important Safeguards
For your protection, please read all these instructions regarding your Cobalt NASRaQª
and retain for future reference.
Read Instructions
All the safety and operating instructions should be read and understood before the
appliance is operated.
Ventilation
The Cobalt NASRaQ Ôs vents (on the front) and the fan opening (on the back panel) are
provided for ventilation and reliable operation of the product and to protect it from
overheating. These openings must not be blocked or covered. This product should not be
placed in a built-in installation unless proper ventilation is provided.
Lithium Battery
The lithium battery on the system board provides power for the real-time clock and CMOS
RAM. The battery has an estimated useful life expectancy of 5 to 10 years. If your system no
longer keeps accurate time and date settings, it may be time to change the battery. Contact
Cobalt for service information. No operator serviceable parts inside.
Warning: There is a danger of explosion if the battery is incorrectly
replaced or replaced with the wrong type of battery. Replace only with
the same or equivalent type recommended by the equipment
manufacturer. Dispose of used batteries according to manufacturer’s
instructions.
Attention: Il y a danger d’explosion s’il a remplacement incorrect de la
betterie. Remplacer uniquement avec une batterie du meme type ou
d’un type equivalent recommande par le constructeur. Mettre au rebut
les batteries usagées conformement aux instructions du fabricant.
Achtung: Explosionsgefahr wenn die Battery in umgekehrter Polaritat
eingesetzt wird. Nur mit einem gleichen oder ahnlichen, vom Hersteller
empfohlenen Typ, ersetzen.Verbrauchte Batterien mussen per den
Instructionen des Herstellers verwertet werden.
English
French
German

iv
Power Cord
!
Caution: The power supply cord is used as the main disconnect
device.Ensure that the socket-outlet is located/installed near the
equipment and is easily accessible.
!
Attention:Le cordon d’alimentation est utilisé comme interrupteur
général.La prise de courant doit etre située or installée a proximité du
matérial et etre facile d’accés.
!
Achtung: Zur sicheren Trennung des Gerates vom Netz ist der
Netzstecker zu ziehen.Vergewissern Sie sich, daß die Steckdose leicht
zuganglich ist.
Electrical Shock
To reduce the risk of electrical shock, do not disassemble this product. Opening or
removing covers may expose you to dangerous voltage and incorrect reassembly can cause
electrical shock. This product should be serviced by a qualiÞed technician.
Using Equipment Racks
If you plan to operate the Cobalt NASRaQ in an equipment rack, take the following
precautions:
¥ Verify the ambient temperature around the Cobalt NASRaQ (which may be
higher than the room temperature) is within the limits speciÞed in ÒPhysical
DataÓ on page 46.
¥ Ensure there is sufÞcient air ßow around the unit
¥ Check that electrical circuits are not overloaded Ñ consider the nameplate
ratings of all the connected equipment, and make sure there is over current
protection.
¥ Check that equipment is properly grounded Ñ particularly any equipment
connected to a power strip.
¥ Do not place any objects on top of the Cobalt NASRaQ.
English
French
German

v
Browsers
When using a web browser to interact with your Cobalt NASRaQ, you may experience a
browser failure. Some releases of Netscape Navigator¨ and Microsoft¨ Internet Explorer
may contain errors that can cause intermittent, unexplained failures. These failures,
however, should not adversely affect the NASRaQÕs data. For reliability, Cobalt
recommends using the latest released version of a web browser. The Cobalt NASRaQ has
been tested with both Netscape Navigator and Microsoft Internet Explorer, version 4.
Regulations and Information
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
¥ Re-orient or re-locate the receiving antenna.
¥ Increase the separation between the equipment and receiver.
¥ Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
¥ Consult the dealer or an experienced radio/TV technician for help.
In order to maintain compliance with FCC regulations, shielded cables must be used with
this equipment. Operation with non-approved equipment or unshielded cables is likely to
result in interference to radio and TV reception. The user is cautioned that changes and
modiÞcations made to the equipment without the approval of manufacturer could void the
userÕs authority to operate this equipment.
This equipment is in compliance with Underwriters Laboratories (UL) and is UL listed.

vi

vii
1 Introduction 1
Overview 2
Front View 2
Back View 3
Requirements 3
Who Uses the NASRaQ 4
How This Guide is Organized 4
Customer Service and Technical Support 5
2 Setting Up the NASRaQ 7
Establishing a Connection 7
Installing the NASRaQ 7
Connecting to the Network 9
Connecting the Power Cord 9
Powering On the NASRaQ 9
Configuring the Network 10
Automatic Configuration using a DHCP Server 10
Manual Configuration using Control Buttons 11
Setting Up With the Web Browser 14
Active Assist Ñ Online Help 14
Configuring the NASRaQ with the Setup Wizard 15
3 NASRaQ Administration 25
NT Domain Versus Local Authentication 26
Users 26
User Management 27
Group Management 28
Groups 29
Shares 30
Contents

viii
Control Panel 31
Services 32
Network 33
Access Rights 34
Time 34
Simple Network Management Protocol (SNMP) 34
NT Domain 34
RAID 35
Maintenance 35
Backup 35
Restore 36
Install Software 36
Reboot 36
Shutdown 36
System Status 37
Disk Usage 38
RAID 38
Memory 38
CPU 38
Service Status 39
File Services 39
SNMP 39
Active Monitor 39
A Using the LCD Console 41
Changing Network Configuration 42
Rebooting 42
Powering Down 43
Resetting Network Configuration 44
B Product Specifications 45
Technical Data for the Cobalt NASRaQ 45
Hardware Specifications 45
Software Specifications 45
Physical Data 46

Contents
ix
C Advanced Information 47
Resetting the Admin Password 47
Changing the Admin Password from the Browser 48
Telnet Access 48
D Licenses 49
E Glossary 55

x

1
Chapter 1
Introduction
The Cobalt NASRaQª delivers high capacity storage, cross-
platform Þle sharing services, and remote administration
capabilities all packaged in a single rack unit height, industry
standard enclosure.
These services include:
¥ Microsoft, Macintosh and UNIX compatible Þle services
¥ RAID 0 (striping) and RAID 1 (mirroring) support
¥ Integration into an existing NT domain
¥ User, group and share based security
¥ Network-based backup (Legato compatible)
¥ SNMP management support
¥ Advanced management using Telnet
¥ Web-based performance and usage reporting

Chapter 1
2
Overview
The following diagrams show the NASRaQ front and rear
views including controls, indicators, and connectors.
Front View
¥ The Status Indicators signal Ethernet, hard drive, and
Web activities:
Tx/Rx (Transmit/Receive) blinks with network
trafÞc
Link solid light indicates the network connection
Col blinks when collisions are detected on the
network
100 M solid light indicate that 100 Mbit Ethernet is
being used
Disk indicates hard disk activity
Web light indicates web activity
¥ The Logo Badge glows when the NASRaQ is powered on
¥ The LCD Screen displays messages and entered values
when you use the LCD control buttons for network
conÞguration, shutting down, and rebooting
¥ Use the Reset Password port if you forget the NASRaQ
administrator password. (See ÒResetting the Admin
PasswordÓ on page 47.)
¥ The LCD Control Buttons allow you to enter network
conÞguration information, shut down, and reboot.
Logo
Badge LCD Control
Status
Indicators Reset Password
Port Buttons
LCD
Screen
Web
Light

Introduction
3
Back View
¥ The Serial Connector allows for serial port console
connection.
¥ The Cooling Fan maintains proper thermal parameters.
¥ The Network Connector accepts a 10/100 Base-T
network cable.
¥ The Network Status Indicators signal network activity
and information.
¥ The SCSI Port enables connection to external SCSI
devices.
¥ The OK to Power Off light indicates when the NASRaQ
is ready to be powered down.
¥ The Power Switch toggles the power on or off.
¥ The Power Socket is where you attach the AC cord that is
provided.
Requirements
To use the NASRaQ, you need the following:
¥ A 10 Base T, 10/100 Base-T, or 100 Base-T, TCP/IP-based
local area network.
¥ A personal computer (attached to the network) that uses
a Web browser (Netscape Navigator or Microsoft Internet
Explorer, versions 4.0 or later).
¥ Network parameters, which you can obtain from your
system or network administrator, or from a DHCP server
Ñ these include the NASRaQÕs assigned IP address, the
subnet mask of your network, and a gateway/router
address (if communicating with other networks).
Serial
Connector
Cooling
Fan
OK to
Power Off
Network
Connector Power Socket
Serial
100 - 240 VAC 50/60 Hz
1.0 A 40W max
Tx/Rx
Link
100 M
Col
OK to
Power Off
Cobalt Networks and Cobalt NASRaQ
are trademarks of Cobalt Networks, Inc.
Network 1
www.cobaltnet.com
SCSI
Network
Status
Indicators
Power
Switch
SCSI Port

Chapter 1
4
Who Uses the NASRaQ
Users include the system administrator and general users.
For security reasons, the administrator sets up and maintains
the NASRaQ.
General users can attach to the NASRaQ as they would any
other shared volume(s) via their desktop computers to store
or access data.
How This Guide is Organized
This guide is organized:
Chapter 1 ÒIntroductionÓ on page 1 discusses the
NASRaQÕs function and features.
Chapter 2 ÒSetting Up the NASRaQÓ on page 7,
describes the hardware setup of the
NASRaQ and the network integration
process.
Chapter 3 ÒNASRaQ AdministrationÓ on page 25,
describes the NASRaQ administratorÕs
functions.
Appendix A ÒUsing the LCD ConsoleÓ on page 41,
describes the LCD console functions Ñ
conÞguring the NASRaQÕs network
settings, rebooting, and powering down.
Appendix B ÒProduct SpeciÞcationsÓ on page 45,
contains the NASRaQÕs technical
speciÞcations.
Appendix C ÒAdvanced InformationÓ on page 47
provides information on development
tools, conÞguration Þles, and the
directory structure of the NASRaQ disk.
Appendix D ÒLicensesÓ on page 49 provides
licensing information.
Appendix E ÒGlossaryÓ on page 55 provides
deÞnitions for NASRaQ-related
terminology.

Introduction
5
Customer Service and Technical Support
For Cobalt product information, visit the support section of
the Cobalt Web site at http://www.cobaltnet.com/support/ . The
site includes a list of Frequently Asked Questions (FAQs) that
provide additional information.
For General Cobalt Information
In the U.S.A. , call (888) 70-COBALT or [phone], or
send e-mail to [email protected].
Outside the U.S.A. , call [phone], or send e-mail
to [email protected].
In Europe , call [phone], or send e-mail to
[email protected].
In Japan , send e-mail to [email protected].
For Cobalt Technical Support and Service
In the U.S.A. , call (888) 70-COBALT or [phone], or
send e-mail to [email protected].
Outside the U.S.A. , call [phone], or send e-mail
to [email protected].
In Europe , send e-mail to
[email protected].
In Japan , send e-mail to [email protected].

Chapter 1
6

7
Chapter 2
Setting Up the NASRaQ
This chapter is intended for the NASRaQ administrator and
describes connecting and conÞguring the NASRaQ for your
network.
If the NASRaQ has been previously conÞgured for a different
network, refer to ÒChanging Network ConÞgurationÓ on
page 42.
The setup process includes the following steps:
¥ ÒEstablishing a ConnectionÓ on page 7 discusses the
physical setup and connection of the NASRaQ to a power
source and the network.
¥ ÒSetting Up With the Web BrowserÓ on page 14 covers
the network integration process and allows the
administrator to select services and create users and
groups using any browser-enabled computer.
Establishing a Connection
Connecting the NASRaQ includes the following procedures:
¥ Installing the NASRaQ
¥ Connecting to the network
¥ Connecting the power cord
¥ Powering on the NASRaQ
¥ ConÞguring DHCP and manual network settings
Installing the NASRaQ
The NASRaQ can either be placed on a ßat surface Ñ for
example, a desk, shelf, or table top Ñ or it can be installed in
an equipment rack.

Chapter 2
8
!
Caution:If you operate the NASRaQ in an equipment rack, see
the precautions described in “Using Equipment Racks” on
page iv.
If you plan to use the NASRaQ on a ßat surface, attach the
rubber feet to the Þve indentations in the bottom of the case.
Figure 1 Attaching rubber feet
If you plan to operate the NASRaQ in an equipment rack,
Þrst connect the mounting ears to the sides of the NASRaQ
(as shown in Figure 2) near either the front or the rear of the
case. Ensure the supporting lip is placed under the unit to
provide additional support and attach the ears to the
equipment rack.
Figure 2 Installing NASRaQ into a standard rack
Rubber feet
Supporting Lip

Setting Up the NASRaQ
9
Connecting to the Network
Connect one end of a Category 5 Ethernet cable to the 10/100
Base-T network connector on the back of the NASRaQ (see
Figure 3). Connect the other end to an existing network
socket.
Figure 3 NASRaQ Rear View
Connecting the Power Cord
Connect the power supply cord to an electrical outlet (100-
240 volts AC, 50/60 Hz, as listed in ÒProduct SpeciÞcationsÓ
on page 45).
Powering On the NASRaQ
Turn on the power by pressing the On/Off switch on the back
of the NASRaQ.
The hard disk starts up, the fan turns on, and the LCD screen
lights up and displays the message
Starting Up
.
Status messages are displayed on the LCD screen as the
NASRaQ completes its boot process.
!
Caution: It’s important to follow the proper power-down
procedure before turning off the NASRaQ. Refer to “Powering
Down” on page 43.
Serial
100 - 240 VAC 50/60 Hz
1.0 A 40W max
Tx/Rx
Link
100 M
Col
OK to
Power Off
Cobalt Networks and Cobalt NASRaQ
are trademarks of Cobalt Networks, Inc.
Network 1
www.cobaltnet.com
SCSI
Network
Connector Power
Socket
SCSI
Connector

Chapter 2
10
Configuring the Network
Now that youÕve made the network and power connections,
youÕre ready to conÞgure the network settings.
The NASRaQ requires speciÞc network information to
properly function. The information can be entered
automatically or manually.
Depending on the network environment, the NASRaQ may
be able to obtain the necessary information from a DHCP
server on your network. If so, it will attempt an automatic
conÞguration. If not, you need to enter the necessary
information manually, using the LCD console on the front
panel. See ÒUsing the LCD Console to ConÞgure the
NetworkÓ on page 11 for more information.
Automatic Configuration using a DHCP Server
When the NASRaQ is powered on, it checks to see whether a
DHCP server is present on the network. If thereÕs a
functioning DHCP server thatÕs set up to serve leased IP
addresses, the NASRaQ conÞgures itself automatically.
If the network information can be conÞgured automatically,
the LCD displays the NASRaQÕs assigned IP Address upon
completion of the boot process.
IMPORTANT:To function properly over long periods of time, the
NASRaQ’s IP address must remain the same, i.e., the DHCP
server must not assign it to a different machine at a later date.
Unfortunately, some DHCP servers do not honor requests for
permanent IP addresses.As a result, the system or network
administrator may need to assign a different (and permanent)
IP address to the NASRaQ. If so, change the network
configuration information.You should coordinate any changes
to the IP address, subnet mask, or gateway address with your
network administrator.
