Fujitsu ETERNUS DX S4 Series User manual

FUJITSU Storage
ETERNUS DX, ETERNUS AF
Configuration Guide -Server Connection-
(Fibre Channel) ETERNUS DX S4/S3 series Hybrid Storage Systems,
ETERNUS AF series, ETERNUS DX200F All-Flash Arrays Settings
P3AM-7962-15ENZ0

This page is intentionally left blank.

Preface
This manual briefly explains the operations that need to be performed by the user in order to connect an
ETERNUS DX/AF to a server running Solaris OS, HP-UX, AIX, Windows®, Linux, VMware ESX, PAN Manager, Cit-
rix® XenServer®, Oracle Linux, or Oracle VM Server for x86 via a Fibre Channel interface.
This manual should be used in conjunction with any other applicable user manuals, such as those for the
ETERNUS DX/AF, server, OS, Fibre Channel cards, and drivers.
Refer to "Configuration Guide -Server Connection- Notations" for the notations used in this manual such as
product trademarks and product names. For storage systems that are supported by the OS, refer to the Server
Support Matrix of the ETERNUS DX/AF.
15th Edition
December 2017
The Contents and Structure of this Manual
This manual is composed of the following two chapters.
•"Chapter 1 Workflow" (page 6)
This chapter describes the workflow when setting up a storage system.
•"Chapter 2 Setting Up the ETERNUS DX/AF" (page 8)
This chapter describes how to set up a storage system.
3
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection-
Copyright 2017 FUJITSU LIMITED
P3AM-7962-15ENZ0

Table of Contents
Chapter 1 Workflow 6
Chapter 2 Setting Up the ETERNUS DX/AF 8
2.1 Common Settings ........................................................................................................................... 8
2.1.1 Setting the To-Server Connection Type (Setting the FC Port Parameters)..............................................................8
2.1.2 Creating the Server Accessible LUN Groups (Setting the LUN Groups)...................................................................9
2.1.3 Setting the Host Responses ................................................................................................................................10
2.1.4 Setting the CA Port Groups..................................................................................................................................12
2.1.5 Registering the WWNs of the Accessing Fibre Channel Cards (Setting FC Host)...................................................12
2.1.6 Allocating LUN Groups (Setting the Host Affinity)...............................................................................................12
2.2 Specific Settings ........................................................................................................................... 13
2.2.1 Setting the CA Reset Groups................................................................................................................................13
2.2.2 Setting the Subsystem Parameters .....................................................................................................................14
2.3 Checking the WWNs ..................................................................................................................... 14
4
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection-
Copyright 2017 FUJITSU LIMITED
P3AM-7962-15ENZ0

List of Tables
Table 2.1 Combinations of the transfer rates and the connection types (when using direct connections to Fibre
Channel cards) ...........................................................................................................................................8
Table 2.2 Combinations of the transfer rates and the connection types (when connecting to Fibre Channel
switches)....................................................................................................................................................8
Table 2.3 FC port parameter settings (when the connection type is FC-AL) ...............................................................9
Table 2.4 FC port parameter settings (when the connection type is Fabric)...............................................................9
Table 2.5 Host response settings .............................................................................................................................10
5
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection-
Copyright 2017 FUJITSU LIMITED
P3AM-7962-15ENZ0

Chapter 1
Workflow
This manual is used when performing the setup procedures described in the "Setting Up the ETERNUS DX/AF"
section of the "Configuration Guide -Server Connection- (Fibre Channel)" for each OS.
Required Documents
•"Configuration Guide -Server Connection- (Fibre Channel) Fibre Channel Switch Settings"
•"Fabric OS Administrator's Guide Supporting Fabric OS"
•"Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris"
•"ETERNUS Web GUI User's Guide"
Workflow
Setting the FC Port Parameters
Set the to-server connection type.
•"2.1.1 Setting the To-Server Connection Type (Setting the FC Port Parameters)" (page 8)
Setting the LUN Groups
Set the server accessible LUN groups.
•"2.1.2 Creating the Server Accessible LUN Groups (Setting the LUN Groups)" (page 9)
Setting the Host Responses
Set the host responses to match the connection configuration.
•"2.1.3 Setting the Host Responses" (page 10)
6
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection-
Copyright 2017 FUJITSU LIMITED
P3AM-7962-15ENZ0

Setting the CA Port Groups
Create a group of ports for each CA type.
•"2.1.4 Setting the CA Port Groups" (page 12)
Setting the FC Host
Register the WWNs of the accessing Fibre Channel cards.
•"2.1.5 Registering the WWNs of the Accessing Fibre Channel Cards (Setting FC Host)" (page 12)
Setting the Host Affinity
Define the relationship between the FC host, the CA port group, and the LUN group.
•"2.1.6 Allocating LUN Groups (Setting the Host Affinity)" (page 12)
Setting the Specific Parameters
Set the required parameters according to the OS and the connection configuration.
•"2.2 Specific Settings" (page 13)
Checking the WWNs
Check information that is necessary for connecting to the server.
•"2.3 Checking the WWNs" (page 14)
After completing all the required procedures in this manual, follow the procedures in "Configuration
Guide -Server Connection- (Fibre Channel)" for each OS.
Chapter 1 Workflow
7
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection-
Copyright 2017 FUJITSU LIMITED
P3AM-7962-15ENZ0

Chapter 2
Setting Up the ETERNUS DX/AF
2.1 Common Settings
This section explains the settings required for all server OSs, regardless of the connection configuration.
See the "ETERNUS Web GUI User's Guide" for details of how to set up and operate ETERNUS Web GUI.
2.1.1 Setting the To-Server Connection Type (Setting the FC Port Parameters)
Select a combination of the transfer rate and connection type from the following table according to the con-
nection environment.
Table 2.1 Combinations of the transfer rates and the connection types (when using direct connections to Fibre
Channel cards)
Fibre Channel
card maximum
speed
Transfer rate and connection type setting values
32Gbit/s CA 16Gbit/s CA 8Gbit/s CA
Transfer rate Connection Transfer rate Connection Transfer rate Connection
32Gbit/s 32Gbit/s Fabric 16Gbit/s Fabric 8Gbit/s FC-AL
16Gbit/s 16Gbit/s (*1) Fabric 16Gbit/s (*1) Fabric 8Gbit/s FC-AL
8Gbit/s 8Gbit/s FC-AL 8Gbit/s FC-AL 8Gbit/s FC-AL
4Gbit/s — — 4Gbit/s FC-AL 4Gbit/s FC-AL
*1: Specify "Auto Negotiation" for direct connections to 16Gbit/s Brocade Fibre Channel cards.
Table 2.2 Combinations of the transfer rates and the connection types (when connecting to Fibre Channel
switches)
Fibre Channel
switch maxi-
mum speed
Transfer rate and connection type setting values
32Gbit/s CA 16Gbit/s CA 8Gbit/s CA
Transfer rate Connection Transfer rate Connection Transfer rate Connection
32Gbit/s 32Gbit/s Fabric 16Gbit/s Fabric 8Gbit/s Fabric
16Gbit/s 16Gbit/s Fabric 16Gbit/s Fabric 8Gbit/s Fabric
8Gbit/s 8Gbit/s Fabric 8Gbit/s Fabric 8Gbit/s Fabric
4Gbit/s — — 4Gbit/s Fabric 4Gbit/s Fabric
8
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection-
Copyright 2017 FUJITSU LIMITED
P3AM-7962-15ENZ0

For each connection configuration, set the indicated items only. All other parameters should be left on their
default values.
Table 2.3 FC port parameter settings (when the connection type is FC-AL)
Parameter Solaris OS
HP-UX, AIX, Windows®, Linux, VMware
ESX, PAN Manager, Citrix XenServer,
Oracle Linux, Oracle VM Server for x86
Connection FC-AL
Set Loop ID Manual
Loop ID Values from 0x10 upwards
(Except 0x7D)
0x00
Transfer Rate Transfer rate that is selected in Table 2.1.
Frame Size 2048
Reset Scope I_T_L
Release Reservation if Chip is Reset Disable
Table 2.4 FC port parameter settings (when the connection type is Fabric)
Parameter Setting value
Connection Fabric
Transfer Rate Transfer rate that is selected in Table 2.1 or Table 2.2.
Frame Size 2048
Reset Scope I_T_L
Release Reservation if Chip is Reset Disable
Make sure to prepare and set up Fibre Channel switches for Fibre Channel connections. For setting details,
refer to "Configuration Guide -Server Connection- (Fibre Channel) Fibre Channel Switch Settings" or "Fabric
OS Administrator's Guide Supporting Fabric OS".
2.1.2 Creating the Server Accessible LUN Groups (Setting the LUN Groups)
Create LUN groups for the server to access. Refer to "Connectivity Management" in "ETERNUS Web GUI User's
Guide" for details, and set the LUN groups.
Depending on the OS version, the server may not recognize the ETERNUS DX/AF unless a LUN group is as-
signed from LUN0. In this case, assign a LUN group starting from LUN0 in ascending order.
Chapter 2 Setting Up the ETERNUS DX/AF
2.1 Common Settings
9
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection-
Copyright 2017 FUJITSU LIMITED
P3AM-7962-15ENZ0

2.1.3 Setting the Host Responses
The host response parameters for the ETERNUS DX/AF must be set to match the way the server processes the
responses to requests from the ETERNUS DX/AF. Setting of the host response must be done before connecting
the ETERNUS DX/AF to the server.
Set the parameters that are described below for each OS.
Retain the default values for all of the parameters that are not described below.
When setting the access path using the ETERNUS SF Storage Cruiser, the host responses for FC host will be
set to default values. Set the host responses after setting the access path using the ETERNUS SF Storage
Cruiser.
Table 2.5 Host response settings
OS Conditions Host response selection
Solaris (*1) When using PRIMECLUSTER (regardless of the
multipath software type)
Default
When using the OS standard Multipath Driver
(MPxIO)
Solaris MPxIO
Other cases Default
Windows®
Linux
VMware ESX
Citrix XenServer
Oracle VM Server for x86
– Default
HP-UX – HP-UX
AIX When using Veritas InfoScale AIX VxVM
Other cases AIX
IBM SVC – SVC
*1: An Oracle-brand Fibre Channel card driver may be used for Fujitsu Fibre Channel cards.
To confirm which driver should be used, check the "Notes" and "Fibre Channel Cards that Require an Ora-
cle-brand Driver" sections in "Configuration Guide -Server Connection- (Fibre Channel) for Oracle So-
laris".
Chapter 2 Setting Up the ETERNUS DX/AF
2.1 Common Settings
10
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection-
Copyright 2017 FUJITSU LIMITED
P3AM-7962-15ENZ0

[For a Cluster Configured With Veritas InfoScale]
If all the following conditions are met, instead of selecting the host response, configure new settings ac-
cording to the table below. All other parameters should be left on their default values.
•The firmware version is V10L50 or later
•Thin Provisioning is used
OS Parameter Setting value
Solaris
Linux
Reservation Conflict Response
(Write Exclusive)
GOOD
HP-UX LUN Addressing FLAT
Peripheral Device Type
(Flat Space Addressing)
Controller Device (0Ch)
NACA Enable
Reservation Conflict Response
(Write Exclusive)
GOOD
AIX LUN Addressing FLAT
NACA Enable
Reservation Conflict Response
(Write Exclusive)
GOOD
[For IBM SVC]
If all the following conditions are met, instead of selecting the host response, configure new settings ac-
cording to the table below. Follow the values of "SVC" for all the parameters that are not described.
•The ETERNUS DX8700 S3/DX8900 S3 is used
•The number of LUNs exceeds 256
Parameter Setting value
LUN Expand Mode
(Peripheral Device Addressing)
Enable
[For VMware]
If all the following conditions are met, instead of selecting the host response, configure new settings ac-
cording to the table below. All other parameters should be left on their default values.
•The firmware version is V10L61 or earlier
•VMware ESXi 6.0 Update 2 or later, or VMware ESXi 6.5 or later is used
•VMware vSphere Virtual Volumes (VVOL) is used
Parameter Setting value
Sense Data Conversion 5/25/00 g 5/20/00
Chapter 2 Setting Up the ETERNUS DX/AF
2.1 Common Settings
11
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection-
Copyright 2017 FUJITSU LIMITED
P3AM-7962-15ENZ0

2.1.4 Setting the CA Port Groups
Create new FC port groups and register the ports as members of the groups. A port group is a group of ports
that access the same LUN group (ports that are used for multipath connection to the server or for connecting
to the cluster configuring server). Configure the host affinity setting for each FC port group.
2.1.5 Registering the WWNs of the Accessing Fibre Channel Cards (Setting FC Host)
Register the physical or virtual WWN of each Fibre Channel card installed in the server that will access the
ETERNUS DX/AF. In addition, set the host response numbers registered in "2.1.3 Setting the Host Responses"
(page 10) to accept these WWNs.
Registering the FC host WWNs and setting up Host Affinities as described elsewhere, allows limits to be set
on which servers are allowed to access which ETERNUS DX/AF LUNs.
2.1.6 Allocating LUN Groups (Setting the Host Affinity)
Allocate the relationship between registered FC hosts (WWN), CA port groups, and LUN groups using the Host
Affinity setting function to specify which LUNs to be accessed. This sets access restrictions to the ETERNUS
DX/AF from each server.
Refer to "Connectivity Management" in "ETERNUS Web GUI User's Guide" for details, and set the LUN groups.
Chapter 2 Setting Up the ETERNUS DX/AF
2.1 Common Settings
12
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection-
Copyright 2017 FUJITSU LIMITED
P3AM-7962-15ENZ0

[When allowing multiple ports in a multipath configuration or a cluster configuration to recognize
the same LUNs]
Create a LUN Group, and set this same LUN Group to all of the ports.
[If the number of CA ports that connect to the same FC host exceeds eight and the connection target
of the host affinity is Host Group - CA Port Group when connecting to IBM SVCs]
Multiple CA port groups must be created. In this case, a single host group cannot configure host affinity
with multiple CA port groups. Therefore, create host groups with the same settings for the number of CA
port groups that are to be connected when configuring host affinity.
The following is a configuration example of a host affinity that allows FC Host1 and FC Host2 to connect to
16 CA ports and access LunGroup1.
Create two host groups with
identical configurations
Create two CA port groups
consisting of eight CA ports
[If the one-to-one relationship between the WWNs and Fibre Channel cards cannot be determined]
The host affinity may not be set correctly. In this case, various settings may need to be tried until the serv-
er is able to recognize the ETERNUS DX/AF logical disks.
2.2 Specific Settings
The required settings vary according to the OS and the connection configuration.
Check the various cases described below, and perform any required settings.
2.2.1 Setting the CA Reset Groups
Because all of the ports are configured to be members of one CA reset group in the initial setting, the reset
group settings do not need to be changed.
Chapter 2 Setting Up the ETERNUS DX/AF
2.2 Specific Settings
13
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection-
Copyright 2017 FUJITSU LIMITED
P3AM-7962-15ENZ0

2.2.2 Setting the Subsystem Parameters
2.2.2.1 Load Balance (for HP-UX Only)
For HP-UX connection, select "Disable" for "Load Balance" in the "Setup Subsystem Parameters" function. This
prevents sense responses that require access retries from being issued when the ETERNUS DX/AF is overloa-
ded.
For HP-UX server, improper logs may be recorded unless sense response is restricted. Therefore, "Load Bal-
ance" should be disabled. (Sense response should be restricted.)
Note that changing the "Load Balance" setting has no affect on non-HP-UX servers.
2.2.2.2 Reject INQUIRY from Unauthorized Host
Select "Enable" only when the Veritas Volume Manager Dynamic Multipathing (VxVM DMP) function is used.
2.3 Checking the WWNs
Use ETERNUS Web GUI to check the WWN of each ETERNUS DX/AF. They are required for connecting the ETER-
NUS DX/AF to the server.
Chapter 2 Setting Up the ETERNUS DX/AF
2.3 Checking the WWNs
14
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection-
Copyright 2017 FUJITSU LIMITED
P3AM-7962-15ENZ0

FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection-
(Fibre Channel) ETERNUS DX S4/S3 series Hybrid Storage Systems, ETERNUS AF series, ETERNUS
DX200F All-Flash Arrays Settings
P3AM-7962-15ENZ0
Date of issuance: December 2017
Issuance responsibility: FUJITSU LIMITED
•The content of this manual is subject to change without notice.
•This manual was prepared with the utmost attention to detail. However, Fujitsu shall assume no responsibility for any
operational problems as the result of errors, omissions, or the use of information in this manual.
•Fujitsu assumes no liability for damages to third party copyrights or other rights arising from the use of any information
in this manual.
•The content of this manual may not be reproduced or distributed in part or in its entirety without prior permission from
Fujitsu.
