Cobra ACA-013 User manual

Cobra ACA-013 10 Way Effects Power Supply
© Cobra I ter atio al Tradi g Ltd
®
The Cobra Acoustic Professio al effect pedal power supply has bee desig ed to be reliable, cost effective a d built for
co ti uous, trouble-free operatio u der rigorous use. Cobra Acoustics u ique degree of commitme t to research, quality-
co trol a d testi g results i co ti uous improveme t of the product. If you eed special assista ce beyo d the scope of
this ma ual, please co tact our tech ical support departme t.
War i g
To preve t damage to the product or electric shock do ot expose this device or its power supply to rai or moisture.
Before Use
• Before you start usi g this u it, please check if there’s o tra sportatio damage. Should there be a y, do ot use the
device a d co sult your dealer first.
• Importa t: This device left our factory i perfect co ditio a d well packaged. It is absolutely ecessary for the user to
strictly follow the safety i structio s a d war i gs i this user ma ual. A y damage caused by misha dli g is ot subject
to warra ty. The dealer will ot accept respo sibility for a y resulti g defects or problems caused by disregardi g this
user ma ual.
• Keep this booklet i a safe place for future co sultatio . If you sell the amplifier, be sure to add this user ma ual.
• To protect the e viro me t, please try to recycle the packi g material as much as possible.
Safety I structio s:
Caution: To reduce the risk of electric shock, do ot remove the top cover. No user-serviceable parts i side. Refer
servici g to qualified service perso el o ly.
• To avoid co de satio formi g i side, allow the u it to adapt to the surrou di g temperatures whe bri gi g it
i to a warm room after tra sport.
• This u it is for i door use o ly.
• Do ’t place metal objects or spill liquid i side the u it. If a foreig object e ters the u it, immediately disco ect the
mai s power.
• No aked flame sources, such as lighted ca dles, should be placed o the applia ce.
• Keep the u it away from childre .
• I experie ced perso s should ot operate this device.
• Maximum safe ambie t operati g temperature is 40 degrees. Do ’t use this u it at higher ambie t temperatures.
• Always u plug the u it whe it is ot used for a lo g time or before you start servici g.
• The power supply should always be i perfect co ditio . Switch the u it immediately off whe the power supply cable is
squashed or damaged, or there is a y damage to the power supply casi g.
• I order to preve t electric shock, do ot ope the cover, there are o user serviceable parts i side.
• I the eve t of serious operati g problems, stop usi g the applia ce a d co tact your dealer immediately.
• Due to safety reaso s it is prohibited to make u authorized modificatio s to the u it.
• Always use the power supply that is supplied with the product. If the power supply eeds to be replaced always use o e
with the correct power, voltage a d co ector.
Descriptio
This is a professio al multi output power supply for effects pedals. There are eight 9v DC outputs, o e 12v DC a d o e 18v
DC outputs. All the outputs are rated at 100mA apart from output umber 8, this is rated at 500mA. This is a ce tre pi
mi us power supply so will be suitable for most pedals, keep this i mi d whe co ecti g your equipme t. The supply is
robust, perfect for o the road use a d comes with its ow power supply a d cable. Each output has short circuit
protectio , over curre t protectio a d is desig ed to reduce hum. The blue LEDs ca be tur ed o a d off via a small
switch, these also show the status of the output, so if there is a short circuit, or the curre t draw is to high the
correspo di g cha el will tur off a d the LED will ot light.

Importa t Precautio s & I structio s
2
Features
• 10 Outputs for Effects Pedals
• Eight 9 Volt Outputs, Seve at 100mA a d O e at 500mA
• O e 12 Volt Output at 100mA
• O e 18 Volts at 100mA
• Short Circuit Protectio
• Over Curre t Protectio
• Supplied with Co ecti g Cables
• Supplied with 18v Power Supply
Specificatio
Output Voltage: 8 x 9v, 1 x 12v, 1 x 18v
Power Supply: 18v DC 1000mA
Dime sio s: 150mm x 53 x 34mm
Weight: 0.362kg
Fu ctio s
1. 18 Volt power supply i put.
2. LED o /off switch.
3. 9-volt outputs x 7 (100mA)
4. 9-volt output x 1 (500mA)
5. 12-volt output (100mA)
6. 18-volt output (100mA)
7. Status LEDs. These tur off if there is a short circuit or curre t overload a d if the LED o /off switch is tur ed off.
Operatio
• Check the effects pedals you wish to use have a suitable voltage a d power requireme t for this power supply.
• Plug i the effects u its you wish to power.
• Plug i the supplied 18-volt adapter.
• You are ready to go.
• If tur ed o the blue status LEDs will let you ow if there are a y faults.
❶❷
❹❺❻
❼
❸
