Cobra PRO 7080 User manual

PRO 7080
6 BAND®
RADAR/LASER DETECTOR WITH
EXTRA SENSORY DETECTION
Nothing comes close to a Cobra®English
Operating Instructions
Printed in China
Part No. 480-131-P

Important Information And
Customer Assistance
Introduction
A1 English
Important Information •
Federal Laws Governing The Use Of Radar Detectors
It is not against federal law to receive radar transmissions with your Cobra radar/
laser detector. The Communications Act of 1924 guarantees your right to receive
radio transmissions on any frequency. Local laws that contravene this Act, while
illegal, may be enforced by your local law enforcement officials until and unless
they are prohibited from doing so by federal court action.
Safety Alert
Use of this product is not intended to, and does not, ensure that motorists or
passengers will not be involved in traffic accidents. It is only intended to alert
the motorist that an emergency vehicle equipped with a Cobra Safety Alert
transmitter is within range as defined by that product. Please call local fire
and police departments to learn if coverage exists in your area.
Safe Driving
Motorists, as well as operators of emergency or service vehicles, are expected to
exercise all due caution while using this product, and to obey all applicable traffic laws.
Security Of Your Vehicle
Before leaving your vehicle, always remember to conceal your radar detector
in order to reduce the possibility of break-in and theft.
Customer Assistance •

Nothing comesclosetoaCobra®1
Table Of Contents
Introduction
Introduction
Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A1
Customer Assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A1
Controls, Indicators And Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . A2
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A3
Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A3
Your Detector
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Highway/City Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Muting An Alert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Auto Mute Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Signals Detected . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Audio Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Visual Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Instant-On Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Responding To Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Understanding Radar And Laser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Warranty
Limited 1-Year Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Customer Assistance
Product Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Trademark Acknowledgement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Optional Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Order Form . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Display And Product Features
Introduction
Nothing comesclosetoaCobra®A3
Detection And Separate Alerts For:
Radar signals (X, K and Ka bands,
with signal strength indicated),
laser and VG-2 signals
LaserEye
For 360° detection of laser and
strobe signals
Instant-On Ready
Detects radar guns with “instant-on”
(very fast) speed monitoring capabilities
Tone Alerts
With adjustable volume
UltraBright Data Display
Easy-to-read with adjustable brightness
City Or Highway
Modes to reduce false alerts
Safety Alert
Traffic warning system distinguishes
important safety alerts from other
K band signals
Manual Mute Or Auto Mute
A mute function of audio alerts
Mounting
Mounts easily on windshield
or dashboard
Product Features •
Congratulations! You’ve made a smart choice by purchasing the PRO 7080
radar/laser detector from Cobra. Just look at some of the sophisticated
features and capabilities your new unit includes:
Display •
This booklet describes the simple steps for mounting and setting up your detector.
It also provides helpful information about how radar and laser guns are used and
how you can interpret the alerts you receive.
Laser
Indicator
VG-2 And Safety
Indicators
Radar
Indicators
Power
Indicator City/ Highway Mode Indicators
NOTE: In This Manual
When steady,
the display will
be shown:
•
X
K
⁄ Ka L
V
⁄ S Cty
•
XK⁄Ka LV⁄S Cty
Controls, Indicators
And Connections
Introduction
A2 English
Controls, Indicators And Connections •
12V DC
Power Jack
On-Off/
Volume
Control
Allows you
to adjust the
volume of the
tone alerts.
City Button
For City or Highway
modes to reduce
false alerts.
LaserEye
For 360° detection of
laser and strobe signals.
Windshield Bracket
Release Button
Speaker
Mute Button
For manual mute or auto
mute of audio alerts.
Windshield
Bracket Mount
WARNING
Modificationsorpartssubstitutionsnotapproved
byCobraElectronicsCorporationmayviolate
FCCRulesandvoidyourauthoritytooperate
thisequipment.

Nothing comesclosetoaCobra®
Installation
Your Detector
3
Installation
Your Detector
2English
Installation •
Where To Mount Your Unit
You will get optimum performance from your detector if you Mount it at a
point approximately in the center of the vehicle, as low as possible on the
front windshield without obstructing the unit’s view of the road either to
the front or rear. You can also mount it directly on the dashboard.
The unit’s lens must not be blocked and the LaserEye should have a clear view
out the back window to allow 360° detection.
Radar and laser signals pass through glass but not through other materials
and objects. Objects that can block or weaken incoming signals include:
nWindshield wiper blades
nMirrored sun screens
nDark tinting at the top of the windshield
nHeated windshields currently available on some vehicles
(Instaclear for Ford, Electriclear for GM.) Consult your dealer
to see if you have this option.
1. Attach the rubber
cups to the bracket.
2. Make sure the rubber cups and your windshield are clean.
3. Push the bracket firmly
onto the windshield.

To Turn On The Unit And Adjust The Audio Volume
Rotate the On-Off/
Volume control
clockwise (away
from you).
Tone Visual Display
Three (3) beeps The power indicator will light
up in the display indicating
that the power is On.
Getting Started
Getting Started •
Your Detector
Nothing comesclosetoaCobra®5
Installation
Your Detector
4English
1. Place the detector on the dashboard to find a location
where the unit has a clear, level view of the road.
The angle can NOT be adjusted after mounting.
2. Remove the paper backing
from one (1) side of the
hook-and-loop fastener.

Settings
Your Detector
Nothing comesclosetoaCobra®7
Settings
Your Detector
6English
Settings •
When changing the Settings on your detector, please keep in mind:
nAll settings will be stored in memory when the power is
turned Off and recalled when the power is turned back On.
Highway/City Mode
Setting your detector to City mode delays all X band audio alerts at lower
signal strength levels. (A single beep will sound when the signal is first
detected.) This will reduce false alerts while you are driving in, or near,
urban areas where there are many sources for conflicting X band signals
such as microwave towers and automatic door openers.
To change settings, follow the procedure listed below, which indicates
what you will see and hear as you complete each step. The factory setting
is Highway mode.

Detection
Your Detector
Nothing comesclosetoaCobra®9
Detection •
Signals Detected
The tables on the following pages show you the types of Signals your
detector will detect, as well as the visual alerts it provides for each of them.
Audio Alerts
A distinctly different Alert tone is used for each type of signal detected
(including separate tones for each laser signal). For X, K and Ka band
radar signals, the tones will repeat faster as you approach the signal
source. The repeat rate of the tones gives you useful information about
the signal detected. (See responding to alerts on page 11.)
Visual Display
An indication of the type of signal detected will appear in the UltraBright
data Display.
During radar alerts the letters X or K⁄Ka will appear.
During laser alerts the letter L will appear.
During VG-2 and Safety Alerts, the letters
V⁄S
will appear.
Detection
Your Detector
8English
K Signal DetectedX Signal Detected
•
X
K
⁄ Ka L
V
⁄ S Cty
X Signal Detected
•
X
K
⁄ Ka L
V
⁄ S Cty
Laser Signal Detected
•
X
K
⁄ Ka L
V
⁄ S Cty
•
X
K
⁄ Ka L
V
⁄ S Cty
•
X
K
⁄ Ka L
V
⁄ S Cty
Ka Signal Detected
•
X
K
⁄ Ka L
V
⁄ S Cty
Ka Signal Detected
•
X
K
⁄ Ka L
V
⁄ S Cty
K Signal Detected
•
X
K
⁄ Ka L
V
⁄ S Cty
VG-2 Alert Signal Detected
•
X
K
⁄ Ka L
V
⁄ SCty
Safety Alert Signal Detected
•
X
K
⁄ Ka L
V
⁄ SCty
Radar Signals And Visual Displays
Type of Signal Visual Display
X Band Radar Xis Steady
K Band Radar K⁄Ka is Steady
Ka Band Radar K⁄Ka is Steady
Laser Signal Detected
Laser Signals And Visual Displays
Type of Signal Visual Display
LTI 20-20* Lis Steady
LTI Ultra-Lyte* Lis Steady
Kustom Signals ProLaser* Lis Steady
Kustom Signals ProLaser III* Lis Steady
* Your detector provides 360˚ detection of these signals.

Detection
Your Detector
Nothing comesclosetoaCobra®11
Detection
Your Detector
10 English
Safety Alert Signals And Visual Displays
Type of Signal Visual Display
Emergency Vehicles V⁄Sis Steady
Road Hazards V⁄Sis Steady
Trains V⁄Sis Steady
VG-2 Alert Signal And Visual Display
Type of Signal Visual Display
Interceptor VG-2 V⁄Sis Steady
Description Interpretation Recommended
Response
Tone repeats slowly at
first, then speeds up
rapidly.
Probably police radar FULL ALERT
Tone sounds one (1)
time only. Probably a false alarm, but possibly pulsed radar
or VG-2 nearby
Exercise caution
Tone instantly begins
repeating rapidly. Radar or VG-2 nearby has been activated
suddenly
FULL ALERT
Tone repeats slowly as you
approach a hill or bridge,
then speeds up sharply as
you reach it.
Probably police
radar beyond the
hill or bridge
FULL ALERT
Tone repeats slowly
for a short period. Probably a false alarm Exercise caution
Any type of laser alert. Laser alerts are
never false alarms FULL ALERT
Any Safety Alert. You are nearing an
emergency vehicle,
Yxercise caution

Understanding Radar And Laser
Your Detector
Nothing comesclosetoaCobra®13
Understanding Radar And Laser •
Radar Speed Monitoring Systems
Three (3) band frequencies have been approved by the Federal Communications
Commission (FCC) for use by speed monitoring radar equipment:
X band 10.525 GHz
K band 24.150 GHz
Ka band 33.400 – 36.00 GHz
Your detector detects signals in all three (3) radar bands.
VG-2
VG-2 is a “detector detector” that works by detecting low-level signals
emitted by most radar detectors. Your detector does not emit signals that
can be detected by VG-2, but does detect VG-2 signals and will alert you
when a device is in use near your vehicle.
Safety Alert Traffic Warning System
FCC-approved Safety Alert transmitters emit microwave radar signals that
indicate the presence of a safety-related concern. Depending on the frequency
of the signal emitted, it can indicate a speeding emergency vehicle or train,
or a stationary road hazard.
Because these microwave signals are within the K band frequency, most
conventional radar detectors will detect Safety Alert signals as standard
K band radar. Your detector, however, is designed to differentiate between
standard K band and Safety Alert signals, and give separate alerts for each.
Safety Alert technology is relatively new. Safety Alert transmitters can
be found in limited numbers in all 50 states, but the number is growing.
Depending on your location, you may not receive these alerts regularly
and may often encounter emergency vehicles, trains and road hazards
without being alerted. As the number of transmitters increases,
these alerts will become more common.
When you receive such an alert, please watch for emergency vehicles ahead
of you, on cross streets and behind you. If you see an emergency vehicle
approaching, please pull over to the right side of the road and allow it to pass.
Understanding Radar And Laser
Your Detector
12 English
LIDAR (Laser)
The correct name for the technology that most people refer to as
laser is actually LIDAR, which stands for Light Detection and Ranging.
LIDAR operates much like radar. Its signal spreads out like a radar
signal, though not as widely. Unlike radar, LIDAR must have a clear
line of sight to its target vehicle throughout the entire measurement
interval. Obstructions such as sign posts, utility poles, tree branches,
etc., will prevent valid speed measurement.
Some common questions about LIDAR include:
nDoes weather have any affect on LIDAR?
Yes. Rain, snow, smoke, fog, or airborne dust particles will reduce the
effective range of LIDAR and can, if dense enough, prevent its operation.
nCan LIDAR operate through glass?
Yes. Newer LIDAR guns can obtain readings through most types of glass.
However, the laser pulse also can be received through glass to trigger
an alarm by your detector.
nCan LIDAR operate while in motion?
No. Because LIDAR operates by line of sight, the person using it cannot
drive the vehicle, aim and operate the gun all at the same time.
nIs LIDAR legal to use?
Yes. It is legal in all 50 states.

Warranty And Product Service
Nothing comesclosetoaCobra®15
Maintenance And Specifications
14 English
Maintenance •
Maintenance Of Your Radar Detector
Your detector is designed and built to give you years of trouble-free
performance without the need for service. No routine Maintenance is required.
If your unit does not appear to be operating properly, please follow these
troubleshooting steps:
nMake sure the power cord is properly connected.
nMake sure the socket of your vehicle’s cigarette lighter is clean
and free of corrosion.
nMake sure the power cord’s cigarette lighter adapter is firmly
seated in your cigarette lighter.
nCheck the power cord fuse. (Unscrew the ribbed end cap
of the cigarette lighter adapter and examine the fuse. If required,
replace it with a 2-amp fuse only.)
Specifications •
Band And Frequencies
Band Frequencies
X Band 10.525 ± 0.050 GHz
K Band 24.125 ± 0.125 GHz
Safety Alert 24.070 ± 0.010 GHz
Traffic Warning 24.110 ± 0.010 GHz
System 24.190 ± 0.010 GHz
24.230 ± 0.010 GHz
Ka Band 34.700 ± 1.300 GHz
Laser 910 ± 50 nm
Unit Dimensions And Weight
Dimensions* Weight*
11⁄4" x 23⁄4" x 37⁄8" 4.26 oz.
(33 mm x 70 mm x 98 mm) (121 g)
* Dimensions and weight measurements are approximate.
This radar detector is covered by one or more of the following U.S. patents: 5,497,148; 5,594,432;
5,612,685; 6,078,279; 6,094,148. Additional patents may be listed inside the product or pending.
Limited 1-Year Warranty •
For Products Purchased In The U.S.A.
Cobra Electronics Corporation warrants that its Cobra 6 Band Radar/Laser Detectors, and the
component parts thereof, will be free of defects in workmanship and materials for period of one (1)
year from the date of first consumer purchase. This warranty may be enforced by the first consumer
purchaser, provided that the product is utilized within the U.S.A.
Cobra will, without charge, repair or replace, at its option, defective 6 Band Radar/Laser Detectors,
products or component parts upon delivery to the Cobra Factory Service Department, accompanied
by proof of the date of first consumer purchase, such as a duplicated copy of a sales receipt.
You must pay any initial shipping charges required to ship the product for warranty service, but the
return charges will be at Cobra’s expense, if the product is repaired or replaced under warranty.
This warranty gives you specific rights, and you may also have other rights which vary from state to state.
Exclusions: This limited warranty does not apply: 1) To any product damaged by accident.
2) In the event of misuse or abuse of the product or as a result of unauthorized alterations or repairs.
3) If the serial number has been altered, defaced or removed. 4) If the owner of the product resides
outside the U.S.A.
All implied warranties, including warranties of merchantability and fitness for a particular purpose
are limited in duration to the length of this warranty.
Cobra shall not be liable for any incidental, consequential or other damages; including,
without limitation, damages resulting from loss of use or cost of installation.
Some states do not allow limitations on how long an implied warranty lasts and/or do not allow the exclusion
or limitation of incidental or consequential damages, so the above limitations may not apply to you.
Product Service •
If you have any questions about operation or installing your new Cobra product, or if you are
missing parts…
Please call Cobra first! DO NOT RETURN THIS PRODUCT TO THE STORE!
See customer assistance on page A1.
If you suspect that your unit requires service, please call 773-889-3087 BEFORE shipping
it to Cobra. This will ensure that you receive service as quickly as possible.
If you are asked to send your unit to the Cobra factory, please follow these steps: 1) Send the
complete unit, including power cord. (It is not necessary to include the mounting bracket.) 2) For
warranty repair, enclose some form of proof-of-purchase, such as a photocopy or carbon copy of
a sales receipt. If you send the original receipt, it cannot be returned. 3) Enclose a typed or clearly
written description of the problem you are having with your unit, plus the name and address where
you want the unit returned. 4) Pack the unit securely to prevent damage during transit. If possible,
use the original packing materials. 5) Ship prepaid and insured using a traceable carrier such as
United Parcel Service (UPS), Federal Express, or Priority mail with delivery confirmation. Ship to:
Cobra Factory Service, Cobra Electronics Corporation, 6500 West Cortland Street, Chicago, IL 60707
U.S.A. 6) Please allow three (3) to four (4) weeks before contacting us about the status of your
service. Call 773-889-3087 for assistance. If your unit is under warranty, it will either be repaired
or replaced upon receipt, depending on the model. If your unit is out of warranty, you will receive
a letter informing you of the repair or replacement charge.
Your Detector Warranty
Customer Assistance

Order Form
Nothing comesclosetoaCobra®17
Customer Assistance
Order Form •
Name
Address(NoP.O.Boxes)
City State/Province Zip Country
Telephone
CreditCardNumber Type: rVisa rMasterCard rDiscover Exp.Date
CustomerSignature
Item # Description U.S.Cost Each Qty Amount
420-030-N-001 Straight12VPower Cord
420-026-N-001 Coiled12VPower Cord
545-139-N-001 WindshieldMountingBracket
CLP-2B DualPortPower Adapter
U.S. Subtotal
(Tax if Applicable)
Shipping/Handling
Total
Ordering From U.S.A.
Call 773-889-3087 for pricing or visit www.cobra.com.
For Credit Card Orders
Complete and return this order form to fax number 773-622-2269. Or call 773-889-3087
[Press one (1) from the main menu] 8:00 a.m. to 6:00 p.m. CT, Monday through Friday.
Make Check or Money Order Payable To
Cobra Electronics, Attn: Accessories Dept.,
6500 West Cortland Street, Chicago, IL 60707 U.S.A.
To Order Online
Please visit our website: www.cobra.com
Amount Shipping/Handling*
$10.00 or less . . . . . $3.00
$10.01-$25.00 . . . . . $5.50
$25.01-$50.00 . . . . . $7.50
$50.01-$90.00 . . . . $10.50
$90.01-$130.00 . . . $13.50
$130.01-$200.00 . . $16.50
$200.01 plus . . . . . 10% of
purchase
Tax Table
Wisconsin add 5%
Indiana, Michigan,
Ohio add 6%
California add 7.25%
Illinois add 8.75%
*For AK, HI and PR add additional $26.95 for FedEx Next Day or
$10.95 for FedEx 2nd Day. Excludes weekends and holidays shipments.
Please allow two (2) to three (3) weeks for delivery in the U.S.A.
Prices subject to change without notice.

Nothing comes close to a Cobra®English
For more information or to
order any of our products,
please visit our website:
www.cobra.com
CB Radios
microTALK®Radios
Radar/Laser Detectors
Safety Alert®Traffic Warning Systems
Accessories
GPS (Global Positioning System)
HighGear®Accessories
CobraMarine™VHF Radios
Power Inverters
The Cobra line of quality products includes:
