Cobra S3840V User manual

1
MODEL: S3840V (DYM420101)
COBRA LAWN
SCARIFIER/AERATOR
OWNER’S MANUAL
WARNING!
When using the machine the safety rules must be followed. For your own safety and bystanders please read these
instructions before operating the machine. Please keep the instructions safe for later use.
Cobra Garden Machinery
Henton and Chattell Ltd., London Road, Nottingham NG2 3HW UK
www.cobragarden.co.uk

2
LAWN SCARIFIER/AERATOR INTENDED USE
The lawn scarifier is intended for non-commercial use, i.e. for use in home and gardening
environments. The scarifier is designed for extracting moss and weeds out of the soil and for
loosening the soil.
Scarifying your lawn will help nutrients be better absorbed, promote healthy root and plant
growth. It is recommended to scarify your lawn in the spring and autumn for best results.
The aerator attachment scores the surface of the lawn, helping water to drain off more easily as
well as promoting oxygen intake. Aeration may be completed throughout the growing period,
but avoiding dry periods.
This machine is designed for the homeowner to scarify small-scale, residential lawns and
gardens. Public facilities, sporting halls, and agricultural / forestry applications are excluded.
The operating instructions as supplied by the manufacturer must be kept and referred to in
order to ensure that the equipment is properly used and maintained. the instructions contain
valuable information on operating, maintenance and servicing conditions.
Warning! :Always clear twigs, stones, hedge clippings, branches and other debris from
the lawn before operating. The rotating action of the scarifier may cause debris to be ejected
from the machine.
Do not use the equipment as a power cultivator to level areas of lawn. Do not attempt to flatten
mole hills with the machine. The scarifier should not used as a drive unit for other equipment or
tools.
Please note that the scarifier has not been designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the machine is used in commercial, trade or
industrial businesses or for equivalent purposes.

3
CONTENT
SECTION 1 SYMBOLS MARKED ON THE PRODUCT ……………..………….….4
SECTION 2 GENERAL SAFETY RULES……………… ……………..….………….5
SECTION 3 GENERAL IDENTIFICATION ……………………………..…………10
SECTION 4 TECHNICAL DATA ................ ………………………………………..10
SECTION 5 ASSEMBLY ........................... ………………………………………..11
SECTION 6 ADJUSTING THE WORKING DEPTH ……………………..…….14
SECTION 7 OPERATING INSTRUCTION……………………………………..15
SECTION 8 REPLACEMENT OF THE ROLLER………………………………….16
SECTION 9 CLEANING AND MAINTENANCE ………………………….……….17
SECTION 10 STORAGE AND TRANSPORT………………………………..……18
SECTION 11 TROUBLESHOOTING…………………………………………...…..18
SECTION 12 WARRANTY …………………………….……..……….……..…....19
SECTION 13 ENVIRONMENTALLY FRIENDLY DISPOSAL ……….……..…....19
SECTION 14 EC-DECLARATION OF CONFORMITY ………………………..20

4
1. SYMBOLS MARKED ON THE PRODUCT
Read this instruction book carefully before using the lawn mower
and keep it in a safe place for future reference.
Keep bystanders away.
Beware of sharp blades. Blades continue to rotate after the motor is switched off.
Switch off isolator key before adjusting, cleaning and before leaving the
product unattended for any period.
CE Marking
The product meets demands and regulations set by the European
Community.
The charger is intended for indoor use only.
Wear hearing and eye protection
The machine is protected against ingress of water drops from a vertical
direction
Do not expose to rain or damp conditions.
Do not operate on inclines greater than 15
°
. Mow across the face of
slopes,never up and down.
Electric shock hazard.
Wait until all machine components have completely stopped before
touching them.

5
Battery Disposal:
Old Accumulators and batteries must not be added to household waste, but should be
disposed of in accordance with the applicable legislation.
Take unusable rechargeable batteries to the dealer’s or community’s battery collection point.
Disposing of the packaging:
The packaging is made of cardboard and separately labeled foil which is also recyclable.
Take these materials to a recycling centre.
Disposing of the packaging:
The packaging is made of cardboard and separately labeled foil which is also recyclable. Take
these materials to a recycling centre.
Battery packs/batteries:
Li-lon
Do not dispose of batteries into household waste, water or fire. Battery packs/batteries
must be collected, recycled or disposed of in an environmentally -friendly way.
Only for EC countries:
Defective or dead batteries must be recycled according to the directive 2006/66/EC
SAFETY ALERT SYMBOL: Indicates caution or warning may be used in conjunction with other
symbols or pictures.
2. GENERAL SAFETY RULES
2.1 General safety regulations for this electrical tool
●The equipment should never be allowed to be used by children, persons with reduced physical,
sensory or mental capacities or insufficient experience and knowledge, or persons who are not
familiar with the instructions.
●Children should be supervised so that they do not play with the equipment. Children are not
allowed to carry out the cleaning or maintenance.
2.2 Safety information for scarifiers and aerators
●Check the equipment for damage each time before use. The equipment must never be used if
damaged and must be placed out of service until completion of repairs by an authorized repair
specialist.
●If the equipment vibrates excessively during operation, switch it off immediately and pull-out the
Noise level marking
Your tool noise is not more than 92dB.
WEEE Marking
CAUTION! Unusable power tools do not belong with domestic waste. They
must be taken to a communal collecting point for environmentally friendly
disposal in accordance with local regulations.

6
on-off button. Tilt the equipment and examine the scarifier and aerator roller for anything which may
have caused imbalance and remove it if necessary -always wear heavy duty gloves whilst
completing this work to protect yourself against injury. If this is not the cause have the equipment
repaired by an authorized specialist reapairer.
●Or examine the equipment for damage and carry out any necessary repairs to damaged parts.
And examine the equipment for loose parts and ensure they are tightened securely.
●Both hands must be on the handle when you start the equipment, and the equipment must be
stood on the ground and must not be tilted.
●Safety components must be checked each time before use and must be replaced by an
authorized service agent if damaged.
WARNING:
Do not touch the spring tines / aeration blades before the equipment is disconnected from the
power supply and the rotating spindle has reached a complete standstill.
Always disconnect from the power supply (e.g. pull out the on-off button).
●Whenever you leave the equipment unattended.
●Before unblocking a blocked tool.
●Before checking, cleaning or carrying out any other work on the equipment.
●If a foreign body has been struck and/or whenever the equipment vibrates abnormally examine
immediately. Disconnect the power first.
2.3 Starting up safely for scarifiers and aerators
2.3.1 Instruction
●Read the instructions carefully. Familiarize yourself with the operator controls and proper use of
the equipment.
●Never allow children or anyone who is not familiar with these instructions to use the equipment.
Local regulations may set minimum age requirements for the user.
●It should be noted that the user of the equipment is personally responsible for accidents or
hazards involving other persons or their property.
2.3.2 Preparation
●Always wear ear protection and protective goggles when using the equipment.
●Always wear sturdy, non-slip footwear and long trousers when using the equipment. Never use
the equipment barefoot or in sandals. Avoid wearing loosely fitting clothes or clothing with
hanging belts or ties.
●Carefully check the ground on which the equipment will be used and remove all objects that
could be caught up by the equipment and projected out.
●Only use the equipment in the recommended position and only on a firm, level surface.
●Do not use the equipment on paved or graveled surfaces where material that could be
projected out and cause injuries or damage.
●Before switching on the equipment, always check all screws, nuts bolts and other fastenings to
ensure that they are secure and that all safety devices and protective features are in position.
Worn or damaged stickers must be replaced.
●Never use the equipment in the direct vicinity of persons – especially children or animals.
2.3.3 Operation
●Work only in broad daylight or in well-lit conditions.
●Do not use the equipment on wet grass.

7
●Always maintain a good footing, especially on inclines.
●Walk, do not run.
●Always guide the equipment across slopes, i.e. never straight up or straight down.
●Be particularly careful when you change direction on a slope.
●Do not scarify or aerate on overly steep inclines.
●Be particularly careful when you turn the equipment around or pull it toward yourself.
●Stop the blades whenever the machine has to be tilted for transporting over areas other than
lawns and whenever it has to be moved from or to the area you want to work on.
●Never use the equipment if the safety devices or safety features are damaged, or without the
attached safety devices, e.g. deflectors and/or catcher baskets.
●Start the motor with caution in accordance with the operating instructions and ensure that your
feet are far enough away from the blades/spring tines.
●Do not tilt the equipment when you start the motor unless the equipment must be raised off of
the ground a little in order to start it. ln this case, tilt it as little as absolutely necessary and only
raise the side opposite to that of the user. Always make sure that both hands are in the working
position before the equipment returns to the ground.
●Never transport the equipment while the drive is running.
●Never move your hands or feet toward or under any rotating parts. Keep clear of the chute
opening at all times.
●Switch off the motor and pull the on-off button. Make sure that all moving parts have reached a
complete standstill:
1) whenever you leave the equipment unattended;
2) before you remove any blockages or clogs in the chute;
3) before carrying out any checks, cleaning or other work on the equipment;
4) after the equipment strikes a foreign body. Inspect the equipment for damage and carry out
any necessary instructions repairs before you restart and use the equipment;
if the equipment begins to experience exceptionally strong;
vibrations, switch it off immediately and check it;
5) search for damage;
6) repair the damaged parts as required;
7) examine the equipment for loose parts and tighten them securely.
Never operate the equipment in poor weather conditions, especially if there is a risk of lightning.
Avoid abnormal working postures and always keep your balance so that you maintain a steady
foothold on inclines at all times.
WARNING:
Do not touch any dangerous moving parts before you have pulled out the safety plug and the
dangerous moving parts have come to a complete standstill.
WARNING:
Risk of injury from dangerous moving parts!
2.3.4 Maintenance and storage
●Make sure that all nuts, bolts and screws are tightened securely and that the equipment is in a
safe working condition.
●Routinely check the catch basket for signs of wear and impaired functionality.

8
●For your own safety, replace worn or damaged parts without delay.
●Remember that on equipments with blades or spring tines, the movement of one unit may result
in the other element starting to rotate.
●While you are adjusting the equipment, take care not to jam your fingers between moving
blades/spring tines and stationary parts of the equipment.
●Allow the motor to cool before you put the equipment away for any extended period of time.
●While you are carrying out maintenance work on the blades/spring tines, it is important to
remember that the blades can still be moved even if the drive has been switched off.
●For your own safety, replace worn or damaged parts without delay. Use only original
replacement parts and original accessories.
●If the equipment is stopped for maintenance, inspection or storage purposes or in order to
replace an accessory, you must switch off the drive, pull the safety plug from the equipment and
make sure that all moving parts have come to a complete standstill. Allow the equipment to cool
before carrying out any inspections, adjustment,etc. Treat the equipment with care and keep
it clean.
●keep the equipment where it is out of children's reach.
Service
Have your power tool repaired only by trained personnel using only genuine replacement parts.
This will ensure that your power tool remains safe to use.
CAREFUL HANDLlNG AND USE OF CORDLESS EQUIPMENT
●Ensure that the equipment is switched off before you insert the battery. Inserting a battery into
an electric tool that is switched on can cause accidents.
●Only charge the batteries in chargers that are recommended by Cobra. A charger that ís
designed for a certain type of batteries may pose a fire risk if it is used with other types of
batteries.
●Use only the correct batteries in the electric tools. The use of other batteries may result in
injuries and a fire risk.
●Keep unused batteries away from paper clips, coins, keys, nails, screws and other metallic
objects that could cause a short circuit between the contacts. A short circuit between the battery
contacts may cause burns or a fire.
●In case of incorrect use, fluid may escape from the battery. Avoid contact with it. If you touch it
by mistake, rinse the affected area with water. lf you get the fluid in your eyes, also seek
medical advice. Leaking battery fluid can cause skin irritation or burns.
Additional safety instructions
Cobra design every battery pack to ensure that we supply you with batteries which feature
maximum power density, durability and safety. The battery cells have a wide range of safety
devices. Despite all the safety precautions, caution must always be exercised when handling
batteries. The following points must be completed at all times to ensure safe use. Safe use can
only be guaranteed if undamaged cells are used. Incorrect handling can cause cell damage.
Important: Incorrect use and poor care are the main causes of the damage caused by high
performance batteries.
Safety Advice for Rechargeable Battery and Charger
Use only the battery provided with the scarifier and the provided charger.
Protect the battery and battery charger from humidity.

9
Do not operate the battery charger outdoors.
When it is not in use or before cleaning and servicing, disconnect the battery charger from the
power supply.
Take special care of the battery.
Avoid dropping it onto any hard surface and do not subject it to pressure or any other form of
mechanical stress.
Keep the battery away from extreme heat and cold.
Do not open or attempt to repair the battery or the battery charger. If any parts are defective, have
them repaired by a qualified technician or send them to our service department for repair.
Only charge the battery at an ambient (surrounding air) temperature between 0ºC and +50ºC.
A charged battery can be used to power the machine under ambient temperature conditions
between -20ºC and +70ºC.
When not in use, store the battery in a dry place between 10ºC and 30ºC.
The battery should be recharged when it fails to produce sufficient power on jobs which were
easily done previously. DO NOT CONTINUE using product with its battery in a depleted
condition.
The battery is not fully charged at the factory. Before attempting to use it, it must be fully
charged firstly.
Important! Danger!
Never short-circuit the battery or expose it to moisture. Do not store it together with any metal
parts which could short-circuit the contacts. The battery could overheat, start burning or explode.
If any person comes into contact with acid or similar internal fluids or substances contained in the
battery, wash off these substances immediately with plenty of water. If these substances make
contact with the eyes, rinse with plenty of water and seek medical assistance immediately.
WARNING:
Do not open the battery pack to get the battery out by yourself.
Do not place the rechargeable battery into fire or water. It can explode. The Rechargeable
Battery should not be discarded to domestic refuse, regardless of whether used or unused. You
should return it to a local battery collection point in accordance with Battery Regulations or return
them to us suitably marked “Used Battery”.

10
3. GENERAL IDENTIFICATION
Fig.1
1. Upper handle 2. On-off button 3. Switch box
4. Locking Lever 5. Grass catcher 6. Cable clamp
7. Depth adjusting knob 8. Battery door 9. Rear cover
10. Lower handle 11.Middle handle 12. LED display
13. Brake control handle
4. TECHNICAL DATA
Model S3840V (DYM420101)
Rated Voltage
40V dc
No Load Speed
3200min-1
Grass catcher capacity
45L
Working Width
380mm
Net weight 14.5kg
Depth adjustment -10-+5mm
Model S3840V (DYM420101)
Sound pressure level at the operator’s position
77.6dB(A) K=3 dB(A)
Measured sound power level 89dB(A) K=2.46dB(A)
Guaranteed sound power level 92dB(A)
Vibration 0.98m/s² K=1.5 m/s²

11
Battery Lithium-ion
Model number
DYMA71E
DYMA72E
DYMA84
DYMA81
DYMA151
DYMA154
Rated voltage
40Vd.c.
40Vd.c.
40Vd.c.
40Vd.c.
40Vd.c.
40Vd.c.
Capacity
108Wh
144Wh
144Wh
90Wh
90Wh
144Wh
Number of battery
20pcs
20pcs
20pcs
10pcs
10pcs
20pcs
Battery charger
Model number DYMA73E DYMA82 DYMA83 DYMA85
Input 220-240V~,
50Hz,1A
220-240V~,
50Hz, 0.6A
220-240V~,
50Hz,1A
220-240V~,
50Hz,2A
Output
40Vd.c,2A
40Vd.c.,1A
40Vd.c.,2A
40Vd.c.,4A
Allowable charging
temperature range
0-50℃0-50℃0-50℃0-50℃
5. ASSEMBLY
5.1 ASSEMBLE THE HANDLE
1. Insert the lower handle into the brackets(Fig.2A).
2. Fix the lower handle into the unit body with locking levers, bolts and washers (Fig.2B).
3. Connect the middle handle and the lower handle with locking levers, bolts and washers (Fig.2C)
4. Connect the upper handle and the middle handle with locking levers, bolts and washers (Fig.2D)
5. Attach the cable clamp to the position shown and then attach the cable. (Fig.2E)
Fig.2A Fig.2B
Fig.2C Fig.2D

12
Fig.2E
5.2 ASSEMBLE THE OPTIONAL GRASS CATCHER
1. Push both metal frame parts into each other .(Fig.2F)
2. Pull the cloth bag over the metal frame. (Fig.2G)
3. Pull the rubber clips over the metal frame. (Fig.2H)
To fit: Raise the rear cover and hitch the grass catcher on rear of mower. (Fig.2I/Fig.2J/Fig.2K).
To remove: Grasp and lift the rear cover, remove grass catcher.
WARNING: Before you fit the grass catcher to the scarifier you must ensure that the motor is switched off
and the cutting unit is not rotating.
Fig.2FFig.2G
Fig.2HFig.2I
Cable clamp

13
Fig.2JFig.2K
5.3 INSTALLING THE BATTERY
Please Note: Fully charge the battery before using for the first time.
1. Make sure the On-off button is pulled out. (Fig. 2L)
2. Open the battery door. (Fig. 2M)
3. Insert the battery pack into battery holder (Fig. 2N).
4. Make sure the latch on bottom of battery pack snaps in place and that battery pack is fully seated.
5. Close the battery door (Fig.2O).
Fig.2L Fig.2M
Fig.2N Fig.2O
5.4 REMOVE THE BATTERY
1. Open the battery door.
2. Press and hold the battery latch button at the bottom of the battery pack .(Fig. 2P)
3. Remove battery pack from the product. (Fig. 2Q)

14
Fig.2PFig.2Q
5.5 ADJUSTMENT FOR AN APPROPRIATE HEIGHT
1.Pull the locking lever opening;
2.Rotating the upper handle centered of the angle, adjusting the gear for the appropriate between 0º to 16º as
the Fig.2R shown;
3.Push the locking lever closed to connect the lower handle and the unit body.
Fig.2R
6. ADJUSTING THE WORKING DEPTH
The working depth is set with depth adjusting knob, the depth can be adjusted from -10mm to +5mm.
(Fig.3A/ Fig.3B)
Fig.3A Fig.3B
WARNING: Make this adjustment only when the blade has stopped.
The angle adjusting gear
Latch
button

15
7. OPERATING INSTRUCTIONS
7.1. STARTING
Insert the On-off button. (Fig.4A)
Start the motor as follows :
1. Press the On-off button. (Fig.4B)
2. And grasp the brake control handle and keep it held in. (Fig.4C).
3. After the motor is running, then release the On-off button (Fig.4D).
4. Releasing the brake control handle will stop the motor.
Fig.4AFig.4B
Fig.4C Fig.4D
CAUTION! The blade starts turning as soon as the motor is started.
WARNING! Cutting elements continue to rotate after the motor is switched off.
7.2. LED
Please refer to the following table for the meaning of LED display.(Fig.4E)
Lawn mower status Battery pack capacity indicator status(Press “POWER”
button（1）
Green light（2）
The battery pack capacity is between 75%~100%. Four LEDs ON
The battery pack capacity is between 50%~75%. Three LEDs ON
The battery pack capacity is between 25%~50%. Two LEDs ON
The battery pack capacity is between 0%~25%.
One LED ON

16
Fig.4E
7.3. RECOMMENDED TIPS FOR SCARIFYING
It is recommended that you overlap scarifying paths a little.
Try to scarify in straight lines for a nice, clean look. In so doing, the aeration swaths should always overlap
each other by a few centimeters in order to avoid bare strips.
If you use the grass catcher which is available as an option, it should be emptied as soon as moss/debris
clippings start to trail behind during scarifying.
Danger! Before taking off the grass catcher, switch off the motor and wait until the
blade/sping tines come to a stop.
To remove the grass catcher, lift up the rear cover with one hand, while unhooking the grass catcher with the
other.
How frequently you should scarify your lawn is determined primarily by the condition of the lawn and soil. Keep
the underside of the equipment clean and remove soil and grass build-up. Deposits make it more difficult to
start the aerator and decrease the quality of the scarifying.
Always scarify along inclines (not up and down).
Switch off the motor before doing any checks on the blades/spring tines.
Danger!
The blades rotate for a few seconds after the motor is switched off. Never attempt to stop the blades. In the
event that the rotating blades strike an object, immediately switch off the equipment and wait for the blades to
come to a complete stop. Then inspect the condition of the blades/tines.
Always follow these safety instructions and notes on working practice.
8. REPLACEMENT OF THE BLADES & SPRING TINES
WARNING: Be sure to wear work gloves.
The equipment can be assembled with the scarifying assembly or the aerator attachment.
Only replace the roller with an original Cobra assembley, as this will ensure top performance and safety
under all conditions.
To change the scarifying tines or the aerator assembly (part number 2425200001), proceed as follows.
Remove the roller
1. Remove the two screws. (Fig.5A)
2. Lift the roller on this side and pull out in the direction of the arrow. (Fig.5B)
2
1

17
Fig.5A Fig.5B
Fit the Assembly – Remove the battery first
1.Slide the assembly in the direction of the arrow onto the square-ended drive and press into the holder
(Fig.5C/ Fig.5D).
2. Refasten the assembly with the two screws.
Apply grease to the square-ended drive from time to time so that the assembly can be changed easily.
Fig.5C Fig.5D
WARNING: Remove the battery from the machine.
9. CLEANING AND MAINTENANCE
DANGER: Always pull out the on-off button and remove the battery before performing any adjustment,
repair, maintenance or cleaning work on the equipment. Make sure that the cutting assembly is not rotating.
9.1 Cleaning
• Keep all safety devices, air vents and the motor housing free of dirt and dust as far as possible. Wipe the
equipment with a clean cloth or blow it with compressed air at low pressure.
• We recommend that you clean the device immediately each time you have finished using it.
• Clean the equipment regularly with a moist cloth and some soft soap. Do not use cleaning agents or solvents;
these could attack the plastic parts of the equipment. Ensure that no water can seep into the device. The
ingress of water into an electric tool increases the risk of an electric shock.
9.2 Maintenance
• A worn out or damaged cutting unit should be replaced by an authorised expert.
• Take care that all fastening elements (screws. nuts, etc.) are firmly tightened, so that you can work safely with

18
the scarifier and aerator.
• Store the scarifier and aerator in a dry place.
• For longer life, all screw-fastened parts, such as wheels and axles should be cleaned and subsequently oiled.
• Regular servicing of the scarifier and aerator not only secures longer life and performance, but ensures
accurate and optimum scarification of your lawn.
• At the end of the season, carry out a general check of the scarifier/aerator, and remove all residue collected.
Before the start of every season, it is absolutely necessary to check the state of the scarifier / aerator. Contact
your local Cobra repair agent if repair work is necessary.
10. STORAGE AND TRANSPORT
Storage
Store the equipment and accessories out of children’s reach in a dark and dry place which is frost protected.
The ideal storage temperature is between 5 and 30℃. Store the machine in its originalpackaging.
Transport
•Switch the machine off and remove the battery before transporting it.
•Fit the shipping protectors if any.
•Protect the machine from damage and the strong vibrations that can occur particularly when transporting in
vehicles.
•Secure the machine against slipping and tipping over.
11.TROUBLESHOOTING
Fault Possible causes Rectification
Motor does not start. a) Internal terminals disconnected.
b) Safety lock-off defective.
c) Blades/tines housing clogged.
d) On-off button is not connected.
e) Battery is not correctly inserted.
a) See your local Cobra dealer.
b) See your local Cobra dealer.
c) Change the Scarifier/aerator depth
if necessary and clean the housing.
d) Connect On-off button.
e) Remove battery and insert again.
Motor performance drops. a) Soil is too firm.
b) Housing is clogged.
c) Blades badly worn.
a) Change working depth.
b) Clean housing.
c) Replace the blade assembly.
Imprecise working result. a) Blades worn.
b) Wrong working depth.
a) Replace assembly.
b) Correct working depth.
Motor is running blades
are not rotating.
a) Toothed belt is torn. a)See your local Cobra dealer.
Important notice! To protect the motor it is equipped with a thermal overload switch which
cuts out when overloaded, release the brake control handle, restart the machine after a
short cooling-down period.

19
12. WARRANTY
This product is warranted in accordance with legal regulations for a 24 month period effective from the date of
purchase by the first user.
This product will not be covered if used in a commercial application.
This warranty covers all material or production failures, it does not include: defects from normal wear and tear,
parts such as, bearings, brushes, cables, air cleaning elements, brake pad, clutch disc, tyre, wheel, recoil
starter rope, belts, cutter blades, plugs, lubricant oils and grease or accessories. Damage or defects resulting
from abuse, accidents or alterations, natural fading of painted or plated surfaces, sheet peeling and other
natural deterioration.
Any damage that occurs from the use of non-genuine Cobra parts will not be covered.
We reserve the right to reject any claim where the purchase cannot be verified or when it is clear that the
product was not maintained properly. (Clean ventilation slots, carbon brushes and serviced regularly)
Expenses incidental to the warranty claim that are not covered;
-Compensation for loss of time, commercial loss or rental costs of substitute product.
-Costs incurred for transportation to and from the dealership.
Any damage that occurs from the following will not be covered; exposure of the product to smoke and soot,
chemical agents, bird droppings or other animal waste, seawater, sea breeze, salt or other environmental
phenomena.
Any damage resulting from operating methods other than those indicated in the owner’s manual will not be
covered.
Your purchase receipt must be kept as proof for date of purchase. Your un-dismantled Cobra must be returned
to your dealer in an acceptably clean state, accompanied by your proof of purchase.
Please Register Your Cobra
Please take a few minutes and register your purchase with Cobra. You can register by completing the
registration by going online to:
www.cobragarden.co.uk and clicking on Product Registration.
13. ENVIRONMENTALLY FRIENDLY DISPOSAL
According to EU directive 2012/19/EU on electric and electronic equipment and its
implementation into national law, all electric tools must be separately collected and
environmentally friendly recycled. Alternative disposal: If the owner of the power tool does not
return the tool to the manufacturer, he is responsible for proper disposal at a designated
collection point that prepares the device for recycling according to national recycling laws and
regulations. This does not include accessories and tools without electric or electronic components.

20
14. EC-DECLARATION OF CONFORMITY
EC Declaration of Conformity
We herewith declare, Cobra Garden Machinery
Henton & Chattell Ltd, London Road, Nottingham NG2 3HW UK
That the following machine complies with the appropriate basic safety and health requirements of the EC
Directive based on its design and type, as brought into circulation by us.
In case of alteration of the machine, not agreed upon by us, this declaration will lose its validity
Product
Cordless Lawn Scarifier And Aerator
Machine Type S3840V (DYM420101)
Rated voltage/power 40V d.c.
Measured sound power level 89dB(A)
Guaranted sound power level 92dB(A)
Notified Body for EC Directive 2000/14/EC:0036
TüV SüD Industrie Service GmbH
Westendstrasse 199 . 80686 München . Deutschland
Applicable EC Directives: 2014/30/EU
2006/42/EC
2000/14/EC
2011/65/EU
Applicable Harmonized Standards EN 60335-1 EN 50636-2-92 EN 62233
EN 55014-1 EN 55014-2
Authorized Signature/Date/ Place
Cobra Garden Machinery Henton & Chattell Ltd, London Road,
Nottingham NG2 3HW UK
2019-09-23
Title of Signatory Managing Director
Name and address of the person
authorised to compile the technical
file
Cobra Garden Machinery Henton & Chattell Ltd, London Road,
Nottingham NG2 3HW UK
