Cobra Microtalk Series Operating instructions

How to Use Your Cobra
MicroTalk 2-Way Radio
1
Featuresof ThisProduct
• UHFFMFrequencies
• NoAir-timeFees
• Upto3km(2-mile)Range
• 2User-selectableChannels
• TalkConfirmationTone
• Call/RingButton
• RechargingPads
• RetractableAntenna
• BatterySaverCircuity
• AutoSquelch
• WristStrap/BeltClip
Contents
Section A - English:
Features.....................................................................................1
The PMR Story........................................................................A1
Included Accessories
Controls & Indicators..........................................................A2
Our Thanks to You................................................................A3
Operating your MicroTalk
Battery Installation............................................................2
Turning On............................................................................4
Auto Squelch.......................................................................4
Maximum Range Extender.............................................4
Select Channel....................................................................5
Auto Battery Save ..............................................................5
Calling Another Party.......................................................6
Talking To Another Party.................................................7
Talk Confirmation Tone....................................................8
Listening For Another Party...........................................8
MicroTalk Range................................................................9
Making Life Easier And Safer..............................................10
External Microphone/Speaker Jack.................................12
Caring for Your MicroTalk ................................................13
MicroTalk Specifications..................................................14
Accessories..............................................................................16
Deutsch..........................................................Abschnitt B
Español.............................................................SecciónC
Français..............................................................SectionD
Italiano..............................................................Sezione E
PMR100-UK.qx copy 6/17/99 9:36 AM Page 1

Pulllock tab down
and lift door up
(towards you) to
remove battery
cover.
Insertfour“AAA”
batteries.Position
batteries according
to polaritymarkings.
Remove belt clip by (A.) pulling tab out and
(B.) sliding belt clip up and off unit.
Operation
3
Operation
2
Note
Batteriesnotincludedwith
MicroTalk2-wayradio.
Note
Alwaysusehigh-quality
alkalineorNiMHbatteries.
Incorrectpositioningcan
damageboththebatteries
andtheunit.
Onlythe CobraNiMH
batterypack (Part no.
PMR-BP)can be
rechargedvia thedesk-
topcharger (Partno.
PMR-CH).
SeeAccessoriesonpage16.
Chargeportsforrecharging
NiMH(NickelMetal
Hydride)batterypackare
locatedonbackofunit.
Note
Whenbatteriesarelowor
needchargingthe
BATTLOWindicatorwill
blinkred. Replacealkaline
batteriesorrechargeNiMH
batterypack.
Install Batteries
Battery
Installation
Clearantenna.
1
2
3 4
A. B.
PMR100-UK.qx copy 6/17/99 9:36 AM Page 2

Select channel by moving the channel button
up or down. Select either Channel A or B for
optimum clarity.
Select Channel
Turn on the MicroTalk 2-Way Radio.
Turning On Your MicroTalk
Rotate ON - OFF Volume Control clockwise.
An audible“tone”will indicate the unit is on and
the TX/RX indicator on the front of the unit
will illuminate green.
Operation
5
Note
Unitsmustbeonsame
channeltocommunicate.
ChooseChannelAorB.
Note
Youcanalsocommunicate
withother2-wayradios
(somehaveasmanyas
eightchannels).
ChannelA=Channel3on
otherunits
Frequencyis446.03125 MHz
ChannelB=Channel5on
otherunits
Frequencyis446.05625MHz
Note
TheAutoBatterySave
Circuitdoesnoteffectthe
unit’sabilitytoreceive
incomingtransmissions.
Select
Channel
Operation
4
Note
Tolearnmoreaboutthe
rangeofyourMicroTalk,
seepage9.
Rangeisdependenton
batteryconditionand
geographicterritory.
Note
Whenevertheunitisonyou
canreceivecommunications.
Turning
On Your
MicroTalk
Auto Squelch
Maximum
Range
Extender
2
1
Auto Squelch
Your MicroTalk is equipped with Auto Squelch,
which automatically shuts off weak transmissions
and unwanted noise due to terrain conditions or
if you have reached your range limit.
Maximum Range Extender
Auto squelch can be temporarily removed
to allow all signals to enter by pressing the
M button (Maximum Range Extender).
1
Auto Battery Save
Your MicroTalk has a unique circuit designed to
extend battery life. If there are no transmissions
within 10 seconds, the unit will automatically
switch to battery save mode.
Auto Battery
Save
Pushandhold
the M/RANGE
EXTENDER button
to allow all signals
toenter.
PMR100-UK.qx copy 6/17/99 9:36 AM Page 4

Operation
7
Note
WhilePTTbuttonis
depressedyoucannot
receiveincomingcalls.
Note
Yourincoming“Call”signal
levelisdependentonyour
unitvolume setting.
Talking To
Another Party
Operation
6
Note
Unitsmustbeonsame
channeltocommunicate.
ChooseChannelAorB.
Note
Youcanalsocommunicate
withother2-wayPMR
radios(somehaveasmany
aseightchannels).
ChannelA=Channel3on
otherunits
Frequencyis446.03125MHz
ChannelB=Channel5on
otherunits
Frequencyis446.05625MHz
Calling Another Party
To alert another party that you wish to
communicate:
Turnon your MicroTalk 2-way radio.
An audible“tone”will indicate the unit is on
and the TX/RX indicator on the front of the
unit will illuminate green.
Place antenna in full
upright position. Select Channel A or
ChannelBbymoving
the CHANNEL button
up or down.
Pushandrelease CALL button.The unit you are
calling will hear a two second ring/tone.
Talking To Another Party
To send your outgoing message:
Calling
Another
Party
Hold mic about
2 inches from
mouth. Speak in
a normal voice.
Release PTT
button and listen
for response.
Pushand hold
PTT button. The TX/RX indicator will illuminate red.
1 2
3 4
1
2 3
4
PMR100-UK.qx copy 6/17/99 9:36 AM Page 6

MicroTalkRange
9
MicroTalk Range
YourMicroTalk Radio has a rangeof up to 3 km
(2miles).This effective range may be shortened
under some conditions.
Toachievemaximum
rangetheautosquelch
canbeoverridden.
RefertoMaximum
RangeExtendersection
onpage4.
MicroTalk
Range
1. Under flat,open
conditions you will
experience the
MicroTalk’s maxi-
mum range.
2. Range can be
reduced by buildings
and foliage in the
path of the signal.
3. Range willbe
further reduced by
dense foliage and
hillyterrain.
Operation
8
Talk
Confirmation
Tone
Listening For Another Party
When you have finished talking:
Listening For
Another Party
Release button to receive incoming
transmissions.
Your MicroTalk is always in listening mode when
the PTT button is not pressed.
1
Note
WhilePTTbuttonis
depressedyoucannotreceive
incomingcommunications.
Your listener will hear an
audible tone when you
release the PTT button.
This alerts the other party
that youhave finished talking
and it’sOK for themto begin
talking.
Talk Confirmation Tone
Listening
mode.
PMR100-UK.qx copy 6/17/99 9:36 AM Page 8

MicroTalk 2-Way Radio Can Make Life
Easier and Safer continued
Making Life Easier and Safer
11
5. Checking on
travelling compan-
ions in another car.
6. Agreeing on a
meeting spot after
an event.
3. Communicating
between different
floors of a building.
4. Talking to a
neighbour or a
friend.
MicroTalk
2-WayRadio
Can Make
Life Easier
and Safer
Note
Insomecountriesitmay
beillegaltouseahand
heldradiowhilstdrivinga
motorvehicle.
Making Life Easier and Safer
10
MicroTalk 2-Way Radio Can Make Life
Easier and Safer
As you become familiar with your MicroTalk
Radio you will find many of your own uses for
the unit.
Some suggestions include:
MicroTalk
2-Way Radio
Can Make
Life Easier
and Safer
1. Talking with fellow
hikers. 2. Keeping track of your family and
friends in a
shopping centre.
continued
PMR100-UK.qx copy 6/17/99 9:36 AM Page 10

13
3. Never place the
unit in water or in
a damp place.
4. Avoid exposure
to extreme
temperatures.
Caring forYour MicroTalk Radio
The MicroTalk 2-Way Radio will give you years
of service if cared for properly.
Here are some suggestions:
Caring for Your MicroTalk Radio
Caring
for Your
MicroTalk
Radio
1. Handle unit
gently. 2. Keep away from dust.
External Microphone/Speaker Jack
12
External Microphone/Speaker Jack
Your MicroTalk 2-Way Radio can be fitted with
an external microphone/speaker (not included),
freeing your hands for other tasks.
To attach the external microphone/speaker:
External
Microphone/
Speaker Jack
Insert plug into the Mic/Spkr jacks.
Open Mic/Spkr tab on top of unit.
1
2
Note
Externalmicrophone/
speaker(itemno.PMR-SMis
notincludedwiththisunit.
SeeAccessoriessectionon
page16foravailableunits.
PMR100-UK.qx copy 6/17/99 9:36 AM Page 12

C.TRANSMITTER UNIT
1. EFFECTIVE RADIATED POWER mW 500
2. CARRIER FREQ.STABILITY Hz 500
3. MODULATION LIMITING kHz 2.5
4. CARRIER ATTACK TIME ms 80
5. AUDIO FREQUENCY RESPONSE
@ 300 HZ dB -6
@ 3000 HZ dB -6
6. AUDIO DISTORTION % 3
7. HUM and NOISE dB 45
8. TRANSIENT FREQ.BEHAVIOR
a) TX ON ms 30
b)TXOFF ms 5
D.POWER SUPPLY
1. BATTERY LIFE (1:1:18 RATIO) HR 24
2.BATTERY V 4.8 - 6.0
MicroTalk Specifications
15
The use of this 2-way radioproduct
involves the public airways and its use may
be subject to local laws,regulations, and
ordinances. Before using the product you
should check to see that the contemplated
use does not violate any local law, regula-
tion or ordinance that may be applicable.
MicroTalk Specifications
14
I.GENERAL SPECIFICATIONS
A. FREQUENCY
A 446.03125
B 446.05625
B.RECEIVER UNIT
1. SENSITIVITY
FOR 12 DB SINAD µV 0.25
FOR CALL SIG.DETECTION µV 0.2
2. MAX. AUDIO OUTPUT @10% THD mW 100
3. MAX.S/N RATIO @ 1mV RF INPUT dB 45
4. SQUELCH
a) SENS. µV 0.2
b) ATTACK TIME ms 120
c) CLOSING TIME ms 200
5. AUDIO FREQUENCY RESP.
@ 300 HZ dB -6
@ 3000 HZ dB -6
6. SIGNAL DISPLACEMENT BW +/-kHz 5
7. ADJACENT CH.REJECTION dB 55
8. INTERMODULATION REJECTION dB 55
9. SPURIOUS RESPONSE REJECTION dB 65
Channel
PMR Frequency
Channel In MHz
PMR100-UK.qx copy 6/17/99 9:36 AM Page 14

Notes
VoxMic
VOX(VoiceOperated
Transmitter)adapterallows
youhands-freeoperation.
PMR-VOX
You Can Find These High-Quality Accessories
AtYour Local Cobra Dealer.
EarBud MicwithPTT
Integratedspeaker/micadapter
thatfitsinyourear. Includes
shirtclip. PMR-EBM
(1)NiMHRechargeable
Battery Pack
HighperformanceNickel
MetalHydridebatterypackfor
multiplerecharging
PMR-BP
2PortDesktopCharger
ChargesyourMicroTalkRadio
and(1)NiCadbatterypack
PMR-CH
LapelMicrophone
Remotemicrophone/speaker
connection.
PMR-40
Replacement BeltClip
PMR-BC
CarryingCase
Durable caseperfectlyfitsyour
MicroTalk radio
PMR-CCB
16
Accessories
17
PMR100-UK.qx copy 6/17/99 9:37 AM Page 16

The Private Mobile Radio Story
A1
The Private Mobile Radio Story
Ever wish you could talk to someone who wasn’t
within earshot? Like contacting ski partners back
at the lodge? Or letting a friend know how to find
you in a busy shopping centre? Cobra’s MicroTalk
radios are a great way for friends or family to
increase their fun - and safety - by staying in touch
while on the go and they are perfectfor business
use as well,such as office to warehouse communi-
cations.
The ERC (European Radiocommunications
Committee) has created 8 channels,called Private
Mobile Radio (PMR). These channels are in the
UHF (Ultra High Frequency) band which means
great penetration through buildings,thick forests,
hills,and other dense structures.They are also FM
(Frequency Modulation) signals which means
crystal-clear reception even in crowded noisy
environments.
Included with your MicroTalk
1. Removable Belt Clip
2. Wrist Strap
2
1
The Private Mobile Radio Story
PMR100-UK.qx copy 6/17/99 9:37 AM Page 18

A3
12
54
3
6
Thank you for purchasing the Cobra MicroTalk
2-way Radio. Properly used,this Cobra product
will give you many years of reliable service.
CobraontheWorldWide
Web: FrequentlyAsked
Questions(FAQ)canbe
foundon-lineat:
www.cobraelec.com
Controls and Indicators
A2
Controls and Indicators
1. RetractableAntenna
2. BeltClip
3. On/OffVolumeControl
4. MicrophoneJack
5. SpeakerJack
6. BatteryChargePads
7. TX (talk/Batt Low
(batteriesarelow)
Indicator
8. Call/RingButton
9. ChannelSelectButtons
10. Microphone
11. MaximumRange
ExtenderButton
12. PTT(PushToTalk)Key
13. BatteryChamber
10
1
7
8
9
11
13
12
PMR100-UK.qx copy 6/17/99 9:37 AM Page 20

“IngeniousProducts for Easier Communication.”
Private Mobile Radio
2-Way Radio
Cobra MicroTalk PMR 100
Betriebsfunkgerät für
Gegensprechbetrieb
Radio móvil privada
bidireccional
Cobra MicroTalk
PMR 100
Appareil de
radiocommunications
à usage privé
Ricetrasmettitore
portatile per
uso privato
© 1999 Cobra Electronics Corporation
6500 West Cortland Street
Chicago, Illinois 60707 USA
www.cobraelec.com
PMR100-UK.qx copy 6/17/99 9:37 AM Page 22
