Coby CS-MP125 User manual

INSTRUCTION MANUAL
Please read this manual carefully before operation.
CS-MP125
Dual Alarm Clock Radio with
Universal Dock for iPod

Page 2 Coby Electronics Corporation
Precautions
For Customer Use:
Enter below the serial number that is located on the unit.
Retain this information for future reference.
Model No. CS-MP
Serial No.
The lightning ash with arrowhead symbol within an equilateral triangle is intended to
alert the user to the presence of uninsulated “dangerous voltage” within the product’s
enclosure that may be of sucient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operation and servicing instructions in the literature accompa-
nying the appliance.
WARNING:
To prevent re or shock hazard, do not expose this device to rain or moisture. Dangerous high voltage
is present inside the enclosure. Do not open the cabinet.
Should any trouble occur, remove the power source and refer servicing to qualied personnel.
CAUTION:
To prevent electric shock, match wide blade of plug to wide slot of outlet and fully insert.
PROTECT YOUR HEARING:
Hearing experts advise against the constant use of personal stereos played at high volume. Constant
exposure to high volumes can lead to hearing loss. If you should experience ringing in the ears or hear-
ing loss, discontinue use and seek medical advice.
For recycling or disposal information about this product, please contact your local authori-
ties or the Electronics Industries Alliance: www.eiae.org.

www.cobyusa.com Page 3
Precautions
FCC Statement:
This device complies with Part  of the FCC Rules. Operation is subject to the following two conditions:
() This device may not cause harmful interference, and
() This device must accept any interference received, including interference that may cause undesired
operation.
Note:
This equipment has been tested and found to comply with the limits for Class B digital devices, pursu-
ant to Part  of the FCC rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that to which the receiver is con-
nected.
- Consult the dealer or an experienced radio/TV technician for help
Use of shielded cable is required to comply with Class B limits in Subpart B of Part  of the FCC rules.

Page 4 Coby Electronics Corporation
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in accordance with the manufac-
turer’s instructions.
Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including ampliers) that produce heat.
Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade or the third
prong are provided for your safety. If the provided plug does not t into your
outlet, consult an electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the ap-
paratus.
Only use attachments/accessories specied by the manufac-
turer.
Use only with the cart, stand, tripod, bracket, or table specied
by the manufacturer, or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination t o
avoid injury from tip-over.
Unplug this apparatus during lightning storms or when unused for long periods
of time.
Refer all servicing to qualied service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
This system is manufactured with delicate electronic components; avoid drop-
ping the system or other strong impacts.
Avoid installing this system adjacent to a CRT television set.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
Important Safety Instructions

www.cobyusa.com Page 5
Table of Contents
PRECAUTIONS........................................................................................................................................2
TABLE OF CONTENTS ..........................................................................................................................5
PACKAGE CONTENTS ..........................................................................................................................7
FEATURES ................................................................................................................................................8
CSMP125 AT A GLANCE.....................................................................................................................9
Top View ..................................................................................................................................................9
Front View............................................................................................................................................ 10
Rear View.............................................................................................................................................. 10
CONNECTIONS ....................................................................................................................................11
Power......................................................................................................................................................11
Battery Backup....................................................................................................................................11
iPod..........................................................................................................................................................12
Auxiliary Device ..................................................................................................................................13
GETTING STARTED .............................................................................................................................14
Basic CS-MP125 Controls.................................................................................................................14
Power On/O ..............................................................................................................................14
Changing the Mode..................................................................................................................14
Adjusting the Volume ..............................................................................................................14
Adjusting the Backlight (Dimmer).......................................................................................14
TIME & ALARM FUNCTION ..............................................................................................................15
Setting the Time.................................................................................................................................15
Setting the Alarm ...............................................................................................................................15
Alarm Timer .................................................................................................................................15
Alarm Timer Activation .......................................................................................................... 16
Snooze and Alarm O.......................................................................................................................17
Nap ..........................................................................................................................................................17
Sleep .......................................................................................................................................................17
IPOD MODE ......................................................................................................................................... 18
Listening to an iPod.......................................................................................................................... 18
iPod Controls....................................................................................................................................... 18

Page 6 Coby Electronics Corporation
RADIO MODE .......................................................................................................................................19
Basic Operation...................................................................................................................................19
Tuning............................................................................................................................................19
Reception .....................................................................................................................................19
AUX MODE........................................................................................................................................... 20
Basic Operation.................................................................................................................................. 20
TROUBLESHOOTING......................................................................................................................... 21
SPECIFICATIONS................................................................................................................................. 22
Table of Contents

www.cobyusa.com Page 7
Package Contents
Congratulations on your purchase of the Coby CS-MP125 Dual Alarm Clock
Radio with Universal Dock for iPod®.
Please make sure the following items are included in the package. If any items
are missing, contact your local dealer.
CS-MP125 Digital Dual Alarm Clock Radio (Main Unit)
AC/DC Power Adapter
Auxiliary Line-in Cable




Page 8 Coby Electronics Corporation
Features
iPod Docking System charges and plays your favorite iPod music
Full-Range Stereo Speakers
Digital LCD Time Display with Dimmable Backlight
Dual Alarm Clock with Snooze/Sleep/Nap Function
Wake to your iPod, radio, or buzzer
Digital AM/FM Radio
3.5mm Audio Line-In Jack for use with any portable audio device








www.cobyusa.com Page 9
CS-MP125 at a Glance
Top View
13
4
6
5
2
Tuning/Set Dial
iPod Dock
Volume Dial
Control Buttons (Top Row)
Alarm1 / Alarm2
Alarm Mode
Alarm Set
Time Set
1.
2.
3.
4.
Control Buttons (Bottom Row)
Power
Dimmer
Sleep
Mode
Snooze/Nap
5.
6.

Page 10 Coby Electronics Corporation
CS-MP125 at a Glance
Front View
1
2
LCD Display
Battery Backup Compartment
(located on the bottom of the unit)
Rear View
23 1
DC 12V Power In Jack
3.5mm Auxiliary In Jack
FM Antenna Lead
1.
2.
1.
2.
3.

www.cobyusa.com Page 11
Power
This adapter should be used with 100-240V 50/60Hz AC wall outlets.
Plug the supplied AC adapter into an appropriate electrical wall outlet and
connect the other end to your device’s DC 12V Power In jack.
When power is connected for the rst time, the LCD Display should read
“12:00”.
Do not connect the AC adapter to a power outlet other than that
which is indicated here or on the label as this may result in the
risk of re or electric shock.
Do not handle the AC adapter with wet hands. Doing so may
cause electric shock.
Do not use an AC adapter other than the one included with the device.
Use of any other adapter may case a re or damage the device.
Battery Backup
The battery backup compartment is located on the bottom of the unit. Load
2 x “AA” batteries (not included) into the battery compartment.
When loading batteries, make sure that the positive (+) and negative (-)
ends are facing in the correct directions as indicated by the markings in
the battery compartment.
Do not mix used and new batteries (replace all batteries at the
same time). Do not mix alkaline batteries with any other type of
battery (carbon zinc, nickel cadmium, etc). Do not mix different
brands of batteries.
The battery backup function will maintain the time and display,
only. Other functions will not be available during power failure.



Connections

Page 12 Coby Electronics Corporation
iPod
If you have a compatible iPod, you can play your iPod through the speakers of
the CS-MP125.
This unit supports the following models:
Connections

www.cobyusa.com Page 13
Connections
Auxiliary Device
If you have an audio device with a 3.5mm headphone out or line-out jack, you
can play the device through the speakers of the CS-MP125.
To connect your audio device with the Auxiliary Line-in Cable:
Connect one end of the cable to the headphone out or line-out jack of the
audio device.
Connect the other end of the cable to the 3.5mm Auxiliary Line-In jack of
the CS-MP125.



Page 14 Coby Electronics Corporation
Basic CS-MP Controls
Power On/O
To turn your player on or off, press .
Changing the Mode
To change the mode of the player, press . The available modes are:
iPod: Listen to audio from an iPod connected to the iPod dock.
FM Radio: Listen to FM radio broadcasts.
AM Radio: Listen to AM radio broadcasts.
Aux: Listen to audio from a device connected to the Auxiliary In Jack.
For more information about these modes, please refer to their respective sec-
tions in this manual.
The iPod mode will not be available if a compatible iPod is not
connected to the iPod dock.
Adjusting the Volume
Rotate the volume dial to adjust the volume level.
Rotate the dial clockwise to turn the volume up.
Rotate the dial counterclockwise to turn the volume down.
Adjusting the Backlight (Dimmer)
Press to change the brightness level of the LCD Display backlight.






Getting Started

www.cobyusa.com Page 15
Time & Alarm Function
Setting the Time
Set the clock time of your player.
Enter time set mode:
Press to begin setting the time—the “hour” digit will start ashing.
Set the hour value:
Rotate the TUNING/SET dial to adjust the hour value. Press
when you are nished—the “minutes” digits will start ashing.
Set the minutes value:
Rotate the TUNING/SET dial to adjust the minutes value. Press
when you are nished.
Setting the Alarm
Alarm Timer
Set the Alarm 1 timer or Alarm 2 timer.
Choose which alarm timer to set (Alarm 1 or Alarm 2):
To choose Alarm 1, press until
1
appears at the bottom of
the LCD Display.
To choose Alarm 2, press until
2
appears at the bottom of
the LCD Display.
Choose the type of alarm to wake to (Alarm Mode):
To wake to iPod, press until appears on the
LCD Display.
To wake to the Radio, press until appears
on the LCD Display.
To wake to a beeper, press until appears on
the LCD Display.
1.
2.
3.
1.


2.




Page 16 Coby Electronics Corporation
Set when the alarm timer will sound:
Press once; the current alarm time will be displayed
with the “hour” digit ashing.
Press again; the “minute” digits will start ashing.
Rotate the TUNING/SET dial to adjust the minute value.
Press once more to nish setting the alarm timer.
The iPod alarm mode will not be available if a compatible iPod
is not connected to the iPod dock.
If you are waking to the radio, make sure to tune to the desired
station prior to setting the alarm.
Alarm Timer Activation
Press to change which alarm timers are active.
To activate Alarm 1, press until
1
appears at the bottom of the
LCD Display.
To activate Alarm 2, press until
2
appears at the bottom of the
LCD Display.
To activate both Alarm 1 and Alarm 2, press until
1
and
2
both
appear at the bottom of the LCD Display.
After the alarms have been activated, turn off the player. The
alarms cannot sound if the player is already on.
The alarms will sound at the volume level the player is set to
before it is turned off.
3.






Time & Alarm Function

www.cobyusa.com Page 17
Snooze and Alarm O
When an alarm turns on, press to delay the alarm timer. The
alarm will sound again automatically after 9 minutes.
To stop the alarm completely, press .
Nap
The Nap function allows you to set an alarm quickly to take a nap.
Turn the player off.
Press . Each successive press of the button will change the
Nap timer duration. An alarm will sound 15, 30, 45, or 60 minutes later.
Sleep
The Sleep function turns off the player after a set amount of time to allow you
to sleep to music.
While the player is on, press to set the Sleep Timer period. Each
successive press of the button will change the Sleep Timer period (the
player will turn off 15, 30, 45, or 60 minutes later).





Time & Alarm Function

Page 18 Coby Electronics Corporation
iPod Mode
Listen to your favorite iPod music when a compatible iPod is docked to your
CS-MP125.
The iPod dock will charge and play your iPod. Please see the documentation
provided with your iPod for more information about iPod play features.
Listening to an iPod
Connect a compatible iPod to the dock and turn on the CS-MP125.
To enter iPod mode, press until appears on the LCD
Display.
iPod playback will start.
iPod Controls
To control iPod playback, use the controls on the iPod.
Turn the Volume dial of the CS-MP125 to adjust the volume to
the desired level.
1.
2.
3.

www.cobyusa.com Page 19
Listen to AM/FM radio broadcasts.
Basic Operation
Turn the player on. To enter FM radio mode, press until “Radio”
and “fm” appear on the LCD Display.
To enter AM radio mode, press once more. “Radio” and “am” will
appear on the LCD Display
Tuning
To tune to a higher station frequency, rotate the TUNING/SET dial clock-
wise.
To tune to a lower station frequency, rotate the TUNING/SET dial counter-
clockwise.
Reception
For FM broadcasts, extend the FM wire antenna and adjust its position for
best reception.
For AM broadcasts, the unit should be positioned manually for best signal
strength (the AM antenna is built into the unit).
1.
2.




Radio Mode

Page 20 Coby Electronics Corporation
Play any external audio device with a 3.5mm headphone out or line-out jack
through the speakers of your CS-MP125 (e.g., MP3, CD player, etc.).
Basic Operation
Use the Line-In cable to connect an external auxiliary audio device to your
CS-MP125’s Auxiliary Audio Line-In jack.
Turn the player on. To enter AUX mode, press until “AUX” ap-
pears on the LCD Display.
Use the controls on your external device to start playback.
You must use the external audio device to control playback.
To avoid distortion, do not set the volume from the external audio
device to very high levels.
For optimal volume control and audio delity, set the volume
level on the external device to approximately 80%, and then
turn the Volume dial of the CS-MP125 to adjust the volume to
the desired level.
1.
2.
3.


AUX Mode
