Cocosie T58 User manual

USER MANUAL
MODEL T58
Congratulations! You just bought yourself a Cocosie. That means more comfort and
more fun, for you and your little one. To ensure you get the best and safest use out
of your Cocosie, we included this instruction manual. Start reading, assembling and
strolling!
Your guide to safe strolling
Maximum weight: 15kg
Applicable age: 0-36 months

WARNING
First things fi rst
Please read this instruction manual very carefully to install and use your new
stroller correctly. We advise to keep it with you for future reference.
Caution - Safety fi rst for your baby
Make sure you understand everything written in this instruction manual to
avoid any kind of dangerous situation. Follow all instructions to use your stroller
correctly, and reduce the possibility of damaging the stroller or injuring your
child. Not following directions properly, could affect your child’s safety.
IMPORTANT NOTES
• Do not exceed the maximum load of 15kg on the seat or carrying basket.
• Do not exceed the maximum load of 3kg on the shopping bag.
• Only use the carrying basket for babies up to 6 months
• Only use the seat for children aged 6 to 36 months.
• Do not run while using the stroller. Always walk at a normal speed.
• Remove all plastic bags and other packaging materials before using the stroller.
• Do not use the stroller for babies up to 6 months, when the backrest and seat
surface is tilted less than 150 degrees.
2

Product Structure
You’re almost ready to start assembling your stroller. For an easy and
ef cient assembly, take a look at this structure overview of your Cocosie,
with the seat, carrying basket and all accessories.
Front wheels
Sun canopy
Car Seat Adapters (L+R)
Stroller chassis
Back wheels
Bumper bar
Stroller chassis
Frame
Blanket
Carrying basket
Car seat
Seat
3
Mattress

Step 3: Adjusting the height
Before attaching the frame onto the chassis,
make sure to adjust the height of the handle
bar. Gently pull the clip on the side to unlock
it. Press the button on top of the handle bar,
and push it up or down to adjust the height to
your needs.
Before Your First Use
4
Step 1: Unfolding the stroller chassis
To set up the stroller chassis in the right position, press the
small button as indicated. Push the frame down, until you
hear a clear click. The chassis is now locked, and ready to
carry other parts.
Step 2: Attaching the wheels
Attach the front and back wheels at the bottom of
the chassis. A clear click means that the wheels are
secured and ready to go.
Tip: Set the brake in place before proceeding with the
installation of your stroller, to prevent it from moving.
Check step 12 on how to do this.
To set up the stroller chassis in the right position, press the
small button as indicated. Push the frame down, until you
hear a clear click. The chassis is now locked, and ready to

Step 4: Attaching the frame
Attach the frame onto the chassis,
as shown on the image. Click it into
the tubes until it’s locked properly. A
clear click means it’s secured.
Tip: It’s possible to attach the frame
in two seperate positions: facing the
handle bar, or the other way around.
Keep this in mind when attaching it
properly. You can easily adjust this
afterwards. Check Step 9 on how to
do this.
Attach the carrying basket or seat
onto the frame. Wrap the cloth (from
either the carrying basket or the seat)
around the frame.
- Preparing the basket
When using the carrying basket, put
the mattress into place, and attach
the blanket afterwards. To make sure
the blanket is attached  rmly, secure
the velcro on the sides of the cloth.
Don’t forget to tie the small elastic
ropes onto the tubes of the bumper
bar on both ends.
5
Do this by  ipping it over from the inside
out. It’s best to start at the gap of the
tilting handle. Finally, pull the zipper to
attach the cloth onto the basket or seat.
Step 5: Attaching the seat or basket onto the frame

- Preparing the seat
When using the seat, make sure to close
the belt at the bottom. Also, always
secure the seat belt correctly. Insert
the pins into the buckle to lock. A clear
click means it’s locked properly. Press
the button to unlock the buckle and pull
out the pins.
Step 6: Attaching the bumper bar
Attach the bumper bar onto the frame of
the basket or seat, until it’s secured with
a click. Use the buttons on both sides to
attach or detach the bumper bar when
needed.
Step 7:
Attaching the sun canopy
Attach the sun canopy onto the
carrying basket or seat as shown
on the image. Do not forget to
stick the velcro.
Step 8: Adjusting the height
Press the button on top of the handle
bar, and push it up or down to adjust the
height to your needs.
Step 9: Adjusting the position
The seat and basket can either be faced
towards the handle bar, or the other way
around. Attach the item of your choice
6
During Your Use

7
in the desired position before using the
stroller. Detach the the seat or basket, by
pressing
the buttons on both sides. To attach it
the other way around, simply insert the
frame into the tubes of the chassis.
A clear click means it’s been locked
properly.
Step 10:
Adjusting the angle
To adjust the angle of the
seat or carrying basket, pull
the handle at the back of
the frame. Do not adjust the
angle when carrying a baby
in the stroller.
Step 11:
Adjusting the sun canopy
To close the sun canopy, push
it back to its lowest position. To
open the sun canopy and protect
your child from the sun, pull it up
to the desired position. Open the
ventilation window at the back of
the sun canopy when needed.
Step 12: Using the brake
To lock the back wheels and prevent the
stroller from moving, push down the
brake on the middle of the frame with
your foot. Push it up again to unlock, and
continue strolling.

Step 13: (Un)locking the wheels
To unlock the front wheels and rotate freely,
push up both buttons as shown on the image.
To lock the front wheels and prevent them from
rotating, push down the same buttons.
After Your Use
Step 1: Detaching all items
Detach all items (the bumper bar and the basket or seat on the frame)
from the stroller. Keep the chassis and wheels together.
Step 2: Adjusting the height
Adjust the height of the handle bar to its lowest
position. Press the button on the middle to push
it down.
Step 3: Folding the stroller chassis
Press the small button on the left side of the
stroller chassis to unlock it. Fold the chassis
together and change the stroller into standing
status.
Step 4: Setting aside for future use
Set aside all items, including the chassis, in a
secure, but easy accessible place until your next
use.
8

Disassembling method
Step 1: Removing the bumper bar
Push the buttons on both sides to unlock the bumper bar and remove it
from the frame.
Step 2: Detaching the frame
Remove the frame of the basket or seat from the stroller chassis. Push
the buttons on the left and the right at the same time, to detach the
item.
Step 3: Removing the sun canopy, mattress and blanket
Remove the sun canopy from the seat or basket by detaching the velcro.
When using the basket, do the same thing for the blanket. Do not forget
to remove the mattress from the basket.
Step 4: Removing the seat or basket from the frame
Loosen the velcro, open the zipper and remove the cloth of the basket
or seat from the frame. When using the basket, remove the small elastic
ropes from the frame. When using the seat, unlock the belt at the
bottom.
Step 5: Adjusting the height
Press the button in the middle of the handle bar to push it down to its
lowest position.
Step 6: Detaching the wheels
Detach the front and back wheels from the stroller chassis. Push the
buttons on both ends.
Step 7: Folding the stroller chassis
Push the small button on the left to unlock the stroller chassis, and fold
the stroller into standing status.
9

Safe travelling with your Cocosie
car seat
Attaching the car seat
Your stroller also comes with a car seat,
safe to use in the car, as well as a part of
your stroller. You can easily attach the
car seat onto the stroller, by using the
appropriate adapters that come with it.
Attach the adapters on both sides (left
and right) of the chassis, by clicking it in.
Make sure that the buttons
on the adapters are facing outwards
while doing this. Your car seat is now
ready to be used as a part of your stroller. Attach it, onto the
adapters on the chassis, in the same way that you would do this
with the basket and seat.
Adjusting the position
You can easily adjust the position of the car
seat to your preferences afterwards: facing
you, or the other way around. Just press
the buttons on the sides of the adapters to
detach it from the stroller chassis.
Adjusting the handle
The handle on the car seat allows you to
safely carry your baby from your car to the stroller, without hav-
ing to add another item to your stroller-collec-
tion. You can easily adjust the position of the
handle, by pressing the red buttons on both
sides of the car seat at the same time. Push the
handle back simultaneously, while pressing the
buttons.
10

Detaching the car seat
Press the buttons on both sides of the adapters to detach it from
the chassis.
To remove the adapters from your car
seat, press the red buttons above the
adapters, underneath the fabric of the
car seat. Pull the adapters one at a time
while pressing the red button.
Whenever your car seat needs to be
cleaned, unbutton the sun canopy from
the seat, on the left, on the right and
in the middle. You can also remove the
rest of the fabric when it’s necessary.
Make sure that you regularly clean all fabric items with a mild
detergent.
The placement in your car
To ensure the safety of your baby during
traveling, make sure to always place the
seat in the opposite direction of traf c.
The best place for the car seat depends
on who you’re travelling with. If it’s just
you and the baby, it’s best to put the
seat in the passenger seat next to you in
the front of the car. This allows you to always keep an eye on your
baby. Make sure to deactivate the frontal airbag when doing so.
When you have another grown-up passenger with you, it’s best to
place the car seat in the back of the car, next to your passenger,
so that he or she can watch the baby while travelling.
11

Securing the seat belts
Always push the handle of the car seat
back completely until it clicks, and
secure the seat belt correctly. You
can  nd instructions on the car seat,
showing you how to wrap the seatbelt
around the right way. Put the seat in
the approved position in your car and
wrap the belt around as shown in the
instructions. Pay extra attention to the
back of the seat: attach the seat belt
onto the provided hook at the back of
the seat for additional stability. Buckle
the seat belt correctly, and test if the
car seat is secure and stable.
No matter if your destination is 5
minutes or 5 hours away: always use
the provided safety belts for your baby.
Pull the two belts at the top of the seat
on the shoulders of your baby, and put
the fabric at the bottom of the seat
between the legs of your child. Now you
should be able to bring the top and the
bottom parts together.
Turn the two pins into one, by placing
the left pin beneath the right one,
and clicking it in. Insert the pins into
the buckle until you hear a clear click.
Have you arrived at your destination?
Unbuckle the seat belt by pressing the
red button, and pulling out the pins at
the same time.
12

Maintentance for your stroller
A Cocosie stroller has many moving parts to ensure a comfortable and
exible use. Overtime, it’s possible that the surfaces of these parts
become dry or slightly stiff. It’s therefore advised to clean your stroller
regularly and use a suitable spray or lubricant, to ensure a longer service
life. Fold your Cocosie stroller correctly and set aside in a secure place
when not using it.
Changes in your environment and certain weather conditions can impact
the state of your Cocosie stroller. A sandy subsurface, or wet and snowy
weather can have damaging effects over time, and increase the chance
of corrosion of certain parts. When using the stroller in these conditions,
make sure to clean your stroller with a suitable cleanser afterwards, and
treat it with a lubricant. This way you’ll extend the overall lifecycle of
your stroller.
When using the stroller, all moving parts are in a locked state and secured
rmly. In this state, your Cocosie stroller can easily carry up to 15kg of
weight. In a closed and folded state, however, the locking mechanism
is automatically lifted. Therefore, you can not use the stroller in this
position. You should avoid any kind of pressure on the frame to prevent
deformation and other damage.
You can not use the frame to hang your bags or other items, since it
increases the risk of tilting over, deformation of the frame, and other
types of damage. Use the extra shopping basket at the bottom of the
stroller chassis to ensure safety at all times.
All fabric of your Cocosie stroller is treated with a waterproof product.
To prolong the waterproof effect, and extend the overall lifecycle of your
stroller, follow these directions with care:
• Avoid folding the fabric.
• Do not use strong thermal drying.
• Use a mild detergent when cleaning.
13

14
• Make sure that your stroller is installed correctly before you start using it.
• Ensure that all handles are locked properly before using your stroller.
• Do not fold your stroller incorrectly or use any incorrect parts.
• Always stay present when carrying a baby or child in your stroller.
• Never let children stand or play on the stroller.
• The stroller is not designed to carry two or more children at the same time.
• Always set the brake in place to prevent the stroller from moving when you’re not
walking.
• Keep children at a safe distance when adjusting the stroller or any accessories.
• Only change the angle of the seat or basket when it’s completely empty.
• Do not use the seat for newborn babies below the age of 6 months.
• Always use the seat belts correctly and and tighten them appropriately to protect
your child.
• When using the carrying basket for newborn babies, always use it in a completely  at
angle.
• To expand the lifetime of your stroller, never overload the basket, seat or shopping
bag.
• The carrying basket can not carry weight over 15kg. When used in a  at angle, it can
only hold up to 9kg.
• The seat can not carry weight over 15kg.
• The shopping bag at the bottom of the stroller chassis can not carry weight over 3kg.
• Do not use the frame to hang your bags or any other items, to avoid instability, tilting
over, and deformation.
• Do not use the stroller on stairs or any rugged terrain.
• Keep the stroller away from  re and other hazards.
WARNING
Safety standards and testing methods vary depending on country and region according to national safety standards.
The standard for your product is: GB14748-2006

WWW.COCOSIE.COM
