CA 310 Owners Manual

128-6530
2 of 10
Page 2
Your system has many features and available options some of which are
selected at time of installation. Consult your installing dealer for options that
may have been installed and are not listed.
ARMINGTHESYSTEM:
1. Turn the engine OFF, exit the vehicle, and close all doors, hood and trunk.
2. Press and release the LOCK button of your Factory (OEM) transmitter one
time.
The parking lights will flash once, the siren will chirp once, and the dash
mounted LED will begin to flash slowly confirming the system is armed.
NOTE: If the siren/horn sounds 3 chirps, then you have left a door, trunk, or
hood lid ajar. Simply close the opened entry point to provide full protection.
PASSIVEARMINGTHESYSTEM:
If the passive arming feature has been selected:
Turn the engine OFF, exit the vehicle, and close all doors, hood and trunk.
The dash mounted LED will begin to flash rapidly indicating that the 30
second passive arming timer has begun. If the LED does not begin to flash
rapidly, then you have left a door, hood, or trunk ajar. Closing this entry point
will allow the arming cycle to begin. If any entry point is opened during the 30
second arming cycle, arming will be suspended. When all entry points are
closed, the arming cycle will begin again. At the end of the 30 seconds, the
parking lights will flash once, the siren will chirp once, and the dash mounted
LED will begin to flash slowly confirming the system is armed.
PROTECTIONWHILETHE SYSTEM ISARMED:
Opening any protected entry point, hood, trunk, or doors will cause the alarm
to trigger immediately. The siren will sound and the parking lights will flash
for 30 seconds, then stop and continue to monitor all protected entry points. If
the thief left the door opened, the system will sound for six 30 second cycles
then shut down, isolate the triggered zone and continue to protect all other
zones. Whenever the system is armed, the dash mounted LED will slowly
flash. This serves as a visual deterrent to a potential thief. This LED is a very
low current light emitting diode, and will not cause the battery to drain even if
left unattended for long periods of time.

128-6530
3 of 10
Whenever the system is triggered, the vehicle's parking lights will flash for the
full siren sounding period. Optional - whenever the system is triggered, the
interior courtesy light will flash for the full siren sounding period. Optional-
whenever the system is armed, the vehicle starter circuit is disabled, and the
vehicle will not start with the ignition key. Whenever the system is armed, any
strong impact to the vehicle will cause the shock sensor to trigger the alarm.
Any lesser impact will cause the pre-detect stage of the shock sensor to emit
a few short series of warning tones from the siren.
DISARMINGTHESYSTEM:
As you approach the vehicle, press and release the UNLOCK button on your
Factory (OEM) transmitter. The parking lights will flash 2 times, the siren will
chirp 2 times, and the dash mounted LED will turn off.
NOTE: If the passive arming mode was selected at time of installation, the
dash mounted LED will start flashing rapidly indicating that the system is
rearming. Opening any door will suspend the automatic arming.
If the parking lights flashed 3 times, and the siren chirps 4 times, this
indicates that the alarm system was triggered during your absence. Before
turning on the ignition key, examine the dash mounted LED's flash pattern.
The number of flashes identifies the triggered zone. For additional
information, refer to INTRUSION WARNING SIGNALS found later in this
manual.
INTRUSIONWARNINGSIGNAL:
This system will inform you if an intrusion attempt has occurred while you
were away from the vehicle. Upon disarm, the siren will chirp 4 times and the
parking lights will flash 3 times. Enter the vehicle and before turning on the
ignition switch, observe the LED flash pattern.
If the LED flashes 2 times...pause, 2 times...pause etc., then an intrusion
attempt was made to open the hood, trunk, or by an accessory triggering
device. Check the vehicle for indications of forced entry to these openings.
If the LED flashes 3 times...pause, 3 times...pause etc., then an intrusion
attempt was made to the vehicle doors. Check all doors for indications of
forced entry.
Page 3

128-6530
4 of 10
Page 4
If the LED flashes 4 times...pause, 4 times...pause etc., then an intrusion
attempt was made by impact or a strong vibration that the shock sensor
detected. Check the vehicle for possible damage to the glass or body panels.
NOTE: The LED intrusion warning indications are stored in the system's
memory and will be erased when the ignition switch is turned on.
VALET/OVERRIDE SWITCH:
The valet switch allows you to temporarily bypass all alarm functions,
eliminating the need to hand your transmitter to parking attendants or garage
mechanics. When the system is in valet mode, all alarm functions are
bypassed, however the remote panic feature and remote door locks will
remain operational.
1. Enter the vehicle, and turn the ignition key to the ON position.
2. Press and hold the valet pushbutton switch until the dash mounted LED
turns on solid. The system will remain in the valet mode.
3. To return to normal operation, press and release the push button switch
any time the ignition is on.
NOTE: Always remember to return the vehicle to the valet OFF position. This
will ensure that the vehicle remains protected at all times.
MANUALLYOVERRIDINGYOURSYSTEM:
USINGTHEVALET/OVERRIDESWITCH:
Your Security system can be disarmed without the use of the OEM transmitter.
This is necessary, since you will need the ability to operate your vehicle if the
transmitter is lost or its battery fails. To Bypass the system:
1. Open the vehicle door. The system will sound.
2. Turn the ignition key to the ON position.
3. Within 5 seconds, press and release the valet pushbutton switch.
The system will stop sounding and enter the (by-passed) mode. You can now
start and operate the vehicle normally.
Typically this override mode is used only if the Factory (OEM) transmitter has
become inoperative.

128-6530
5 of 10
Page 5
ELIMINATING/RETURNINGTHE NORMALARM/DISARMCHIRPS
You can selectively eliminate the normal arm & disarm chirps using the valet/
override switch, following these steps.
1) Turn the ignition key ON the OFF.
2) Within 10 seconds of turning the ignition key OFF, press and release the
valet/override switch 3 times.
3) If, before step 1,the chirps were ON, then you will hear 2 short chirps,
which indicates the chirps are turned OFF.
4) If, before step 1, the chirps were OFF. then you will hear 1 short chirp,
which indicates the chirps are turned ON.
5) Whenever the system's power has been disconnected, the chirps will be
ON when power is reconnected.
ALARMDASHLED INDICATORS
RAPIDFLASHING = PASSIVEARMING
SLOWFLASHING = ARMED
OFF = DISARMED
ON SOLID = VALETMODE
4FLASH...PAUSE = INTRUSION SHOCK SENSOR
3FLASH...PAUSE = INTRUSION DOOR
2FLASH...PAUSE = INTRUSION HOOD OR TRUNK
ALARMSIREN CHIRPINDICATION
1 CHIRP* = ARM
2 CHIRPS* = DISARMED
3 CHIRPS = ARMINGWITHENTRY POINT OPENED
4 CHIRPS = DISARMAFTERINTRUSION
CONTINUOUS = ALARMTRIGGERED
ALARMPARKING LAMPINDICATIONS
1 FLASH = ARM
2 FLASH = DISARM
3 FLASH = DISARMAFTERINTRUSION
CONTINUOUS FLASH = TRIGGERED
CA-310
SYSTEM FUNCTIONS AT A GLANCE

128-6530
6 of 10
Code Systems, Inc. Limited Lifetime Warranty
Code Systems Inc. (“CODE”) warrants to the ORIGINAL PURCHASER of this CODE
vehicle security product (the “Product”), purchased from an authorized CODE dealer, that (except as
provided below) should this Product under normal use and conditions, be proven defective in material
or workmanship DURING THE LIFETIME OF THE VEHICLE IN WHICH IT WAS ORIGINALLY
INSTALLED, such defect(s) will be repaired or replaced (at CODE’s option) without charge for parts
directly related to repairs of the defect(s).
Switches, indicator lights, and transmitter cases are similarly warranted to the original
purchaser for a period of one (1) year from the date of purchase of the Product.
CODE accessories, sold separately, are covered by the applicable warranty accompany-
ing the accessory.
This warranty is non-transferable, non-assignable and is voided when: (1) the Product is
removed from the vehicle in which it was originally installed; or (2) the vehicle in which the Product
was originally installed is transferred to another party.
This warranty does not apply to any product damaged by accident, physical or electrical
abuse, improper installation, alteration, or use contrary to its intended function, fire, flood, or other
natural acts.
In order for the Product to be repaired or replaced under the terms of this warranty, the
defective Product must be returned to an authorized CODE dealer and accompanied by a copy of the
retail sales receipt. The date of purchase and year, make and model of the vehicle in which the
Product was originally installed must be clearly indicated on the sales receipt.
This warranty is exclusive and CODE MAKES NO OTHER WARRANTIES EXPRESSED
OR IMPLIED. ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MER-
CHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE
DURATION OF THIS WRITTEN WARRANTY. IN NO CASE SHALL CODE BE LIABLE FOR ANY
CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER WAR-
RANTY, EXPRESS OR IMPLIED, WHATSOEVER.
CODE does not warrant that the Product cannot be compromised or circumvented. THE EXTENT OF
CODE’S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT
PROVIDED ABOVE AND, IN NO EVENT SHALL CODE’S LIABILITY EXCEED THE PURCHASE
PRICE PAID BY THE ORIGINAL PURCHASER OF THE PRODUCT WITHOUT INSTALLATION
LABOR.
Some states do not allow the exclusion or limitation of incidental or consequential dam-
ages, so the above limitation may not apply to you. This warranty gives you specific legal rights and
you may also have other rights which vary from state to state

128-6530
7 of 10
CODE-SYSTEM, INC. Theft Protection Program
The Theft Protection Program is designed to provide the retail purchaser of a
security system provided by CODE-ALARM, INC. (“CODE”) an additional
benefit, at no additional cost to the purchaser, should their vehicle be stolen
while protected by a CODE-ALARM security system. While CODE has created
this program as a way of showing appreciation to its customers, CODE RE-
SERVESTHE RIGHT TO UNILATERALLY CHANGE,ALTER, MODIFY, OR
DISCONTINUEALLOR PART OF THIS THEFT PROTECTION PROGRAM
WITHOUTPRIOR NOTICE.THIS THEFTPROTECTION PROGRAM IS NOTAN
INSURANCE POLICY AND SHOULD NOT REPLACE AN AUTOMOBILE OR
HOMEOWNERSINSURANCEPOLICY.THISTHEFTPROTECTIONPROGRAM
DOESNOTCOVER LOSSESARISING FROMTHETHEFTOFITEMS WITHIN
THEAUTOMOBILE ORANY DAMAGESARISING FROM, RELEATED TO,AND/
OR INCIDENTAL OR A CONSEQUENCE OF A VEHICLE THEFT EXCEPT AS
SPECIFICALLY DELINEATED BELOW.

128-6530
8 of 10
How to file a request for payment:
If the above conditions are met, make your request for payment by submitting the
following to CODE. The request for payment must be received by CODE no later than
sixty (60) days after the vehicle is reported stolen.
1. Copy of the retail sales receipt for the purchase of the security system, clearing
showing the model of system purchased and the year, make and model of the
vehicle in which the system was installed.
2. A copy of the police report for the stolen vehicle.
3. A copy of the paid insurance claim and reimbursement check from the insurance
company.
*The Theft Protection Program is not available in all states please contact
dealer for more information.
CODE SYSTEMS, INC.
1-800-421-3209
Plan duration: 3 Years from the date of installation.
Plan amount: Maximum allowable value equal to insurance deductible or up to
$2,500 whichever is less.
Conditions of the Theft Protection Program:
1. The Theft Protection Program is non-transferable and non-assignable.
2. The system must be installed by an authorized CODE dealer.
3. Vehicle must be less than three (3) model years old at the time of installation.
4. The security system must have been fully armed at the time of the vehicle theft.
5. The vehicle in which the system is installed must be insured for theft by a licensed
insurance underwriter in the state in which the vehicle is registered.
Terms of payment:
1. The vehicle must first be considered a total loss due to theft by your insurance
company.
2. Your insurance company has settled all claims arising from this theft and there are
no other pending legal actions as a result of this theft.
