Code Alarm CA- 550 User manual

CA 550 Installation Instructions
Avoid mounting components or routing wires near
hot surfaces
Avoid mounting components or routing wires near
moving parts
Tape or loom wires under hood
for protection and appearance
Use grommets when routing wires through metal
surfaces
Use a Digital Multi Meter for testing and verifying
circuits. DO NOT USE A TEST LIGHT, OR
"COMPUTER SAFE PROBE" as these can set off air
bags or damage vehicle computers.
PROFESSIONAL INSTALLATION STRONGLYRECOMMENDED
Installation Precautions:
Roll down window to avoid locking keys in vehicle
during installation
FCC COMPLIANCE
This device complies with Part 15 of the FCC rules and with RSS-210 of Industry Canada.
Operationissubjecttothefollowingtwoconditions:
1.Thisdevicemaynotcauseharmful interference, and
2.Thisdevicemustaccept any interference received, including any interference that may cause
undesiredoperation.
Warning! Changesor modifications not expressly approved by the party responsible for
compliancecouldvoidtheuser’sauthoritytooperatetheequipment.
Technical Support
For Authorized Dealers - [phone]

ANTENNA / RECEIVER
SAFETY CONTROL SWITCH
3
4
Lt BLUE/GREEN
BLUE UNLOCK SENSE INPUT
TRUNK PIN INPUT(-)
5 6
7 8 9
10
11
12
13
14
15 16 17 18 19 20
BLUE/WHITE
WHITE/BLUE
GRAY
GRAY/BLACK GREEN BLACK BROWN
WHITE
PINK
Lt BLUE/BLACK
OPEN
PURPLE
BLACK/GRAY Lt GREEN/ORANGE
BROWN/WHITE
BROWN/BLACK
INSTANT TRIGGER INPUT (-)
REMOTE STARTACTIVATION (-)
HOOD PIN INPUT (-) PARKING BRAKE INPUT (-) NEGATIVE DOOR TRIGGER GROUND SIREN OUTPUT (-) PARKING LIGHT OUTPUT CHANNEL 1 (TRUNK) MANUAL DISARM INPUT OPEN
POSITIVE DOOR TRIGGER WAITTO START INPUT (-)
HEADLIGHT OUTPUT (-) SONGBIRD OUTPUT (-) HORN OUTPUT (-)
BLACK/YELLOW
BLACK/RED
Lt.BLUE
Lt GREEN/BLACK
(-) PULSE DURING CRANK
(-) PULSE AFTER SHUTDOWN
(-) PULSE AFTER START
(-) PULSE BEFORE START
PINK/RED PINK/BLUE
PINK/GREEN PINK/BLACK (-) CHANNEL 5 OUTPUT
(-) CHANNEL 4 OUTPUT
(-) CHANNEL 3 OUTPUT
(-) CHANNEL 2 OUTPUT
TRACKING PORT
TRANSPONDER PORT
ORANGE/WHITE
PINK/WHITE
BROWN/RED
BLUE/BLACK
(+) ACCESSORY 2 OUTPUT
(+) IGNITION 2 OUTPUT
(+) BRAKE INPUT
(-) ACTIVE OUTPUT
RED
ORANGE (+)12 VOLTS BATTERY
(+) ACCESSORY 1 OUTPUT
30 AMP
PURPLE
PINK (+) STARTER OUTPUT(MOTOR SIDE)
(+) IGNITION 1 INPUT/OUTPUT
RED
GREEN (+) 12 VOLTS BATTERY
(+) STARTER INPUT(KEY SIDE)
21 PURPLE/ WHITE TACH INPUT 22 ORANGE ARMED OUTPUT (-)
1 BLACK/WHITE DOME LIGHT OUTPUT
2 Lt BLUE/RED MANUAL ARM INPUT
BLUE/GREEN BLUE
GREEN
(-) 2ND STAGE UNLOCK
NEGATIVE UNLOCK/POSITIVE LOCK
NEGATIVE LOCK/POSITIVE UNLOCK
LED
VALET/ OVERRIDE
CA-550 SYSTEM LAYOUT
30 AMP
EXTERNAL SENSOR PORT

CA- 550 System Layout
22 Pin Base Harness
1TUPTUOTHGILEMODETIHW/KCALB
2TUPNIMRALAUNAMDER/EULB.TL
3TUPNIHCTIWSKCOLNUNEERG/EULB.TL
4NIPKNURTEULB
5REGGIRTTNATS
NIETIHW/EULB
6TRATSETOMER NOITAVITCA EULB/ETIHW
7TUPNINIPDOOHYARG
8EKARBGNIKRAPKCALB/YARG
9ROODEVITAGEN REGGIRT NE
ERG
01DNUORGKCALB
11TUPTUONERISEVITISOPNWORB
21STHGILGNIKRAPETIHW
311LENNAHCKNIP
41TUPNIMRASIDLAUNAMKCALB/EULB.TL
51
6
1REGGIRTROODEVITISOPELPRUP
71TRATSOTTIAWYARG/KCALB
81TUPTUOTHGILDAEHEGNARO/NEERG.TL
91TUPTUODRIBGNOSETIHW/NWORB
0
2TUPTUONROHKCALB/NWORB
12TUPNIHCATETIHW/ELPRUP
22TUPTUODEMRAEGNARO
4-Pin Tracking Port
(White)
4-Pin Receiver Port
(Black) 4-Pin External Sensor Port
(Tan)
4-Pin Auxilliary Port
(Green]) 2-Pin LED Port
(White)
2-Pin Valet Port
(Blue)
22-Pin Base Harness
4 Pin 2nd Sensor Port (TAN)
1NRAWERPEULB
2REGGIRTLLUFNEERG.KD
3DNUORGKCALB
4STLOV21DER
12LENNAHCKCALB/KNIP
23LENNAHCNEERG/KNIP
34LENNAHCEULB/KNIP
45LENNAHCDER/KNIP
4 Pin Auxiliary Harness (GREEN)

2 Pin Transponder Port (YELLOW)
6 Pin Remote Start Harness
3 Pin Door Lock Harness
1KCOLNUSOP/KCOLGENNEERG
2KCOLSOP/KCOLNUGENEULB
3KCOLNUEGATSDN2NEERG/EULB
1TUPTUODNUORGKCALB/EULB
2STLOV21DER
4 Pin Power Harness
1STLOV21+DER
2TUPNIRETRATS )edisyeK( NEERG
3RETRATS )ediSrotoM(TUPTUO ELPRUP
4tuptuO/tupnI1NGIKNIP
4-Pin Power Harness
6-Pin Remote Start Harness
Remote Start Switch
(Red)
4-Pin Interface Port
(White)
2-Pin Transponder Port
(Yellow)
3-Pin Door Lock Por
t
(White)
+++
---
Fuse Grid
Trunk Polarity
Parking Light Polarity
Dome Polarity
Recommend 15Amp
4 Pin Interface Harness (WHITE)
1TRATSEROFEBESLUP )MRASIDYROTCAF( KCALB/NEERG.TL
2TRATSRETFAESLUPEULB.TL
3RETFAESLUP NWODTUHS DER/KCALB
4KNARCG
NIRUDESLUPWOLLEY/KCALB
1STLOV21+DER
21YROSSECCAEGNARO
32YROSSECCAETIHW/EGNARO
42NOITINGIETIHW/KNIP
5TUPNIEKARBDER/NWORB
6TRATSETOMEREVITCA )
3NGI(TUPTUO)SR( KCALB/EULB

Programming Options
RF Programmer
The RF Programmer allows you to customize the system to fit the individual needs of the consumer, using
a handheld device capable of transmitting system settings directly to the system control module. The RF
Programmer is broken down into three different programming banks.
1. RF Programmer Bank- The system control module included with the CA-550 is known as a "Master
Module", which means that the control module is equipped with the ability to operate as one of
several different types of systems. The RF Programmer Bank allows you to set up the base
features of the system you are installing. It is very important to understand that the base features of
this system can only be programmed using the RF Programmer. Please refer to the chart below
showing factory default settings (bold) to determine what options need to be changed for your
system. When using the RF Programmer to select feature settings is very important to verify that the
correct base features remain at the default settings.
CA-550 RF Programmer Base Features
2. Feature Bank 1- Feature Bank 1 allows you to turn On/Off customer convenience features.
3. Feature Bank 2- Feature Bank 2 allows you to turn On/Off remote start features.
Manual Feature Programming
After installation is complete it will be necessary to program certain system characteristics that can't be
programmed using the RF Programmer (Shock Sensor settings and Tach Idle Speed). In addition all of
the customer convenience features and remote start features.
erutaeF tluafeD gnitteS
ytiruceS NO
tratSetomeR NO
XTyaW2/yaW1 XTyaW1

RF Programmer
Selecting Programmable Features
1. Press the POWER button to turn the system ON.
2. Once powered up the MENU screen will be displayed.
3. Use the UP & DN arrows to scroll through the programmable features. Once you locate the desired
feature to change, press the >arrow to advance to the next screen. You should see the default setting
of the system
4. Press the SET button to scroll through the available settings. Once the desired setting is shown on
the screen, press the <to return to the feature chart selectable options or press SEND to transmit to
the system you are installing.
NOTE: You must access the RF receive bank on Option programming to SEND the selected information
to the CA 660, please refer to the programming section on the next page.
Using the M1 function
The RF Programmer has a memory function that will allow you to store the 4 most common feature
settings.
Once you have selected the settings that you want to store press and hold M1 button for 3 seconds.A
menu will appear which will allow you to select the memory bank you wish to save the desired feature
setting into.
Press the SET button to store the setting into memory. The menu will display "Write to memory X"
To retrieve a stored feature setting, press and release the M1 button. Amenu will appear that will allow
you to select the desired memory bank.
Press SET to retrieve the desired stored memory bank. The menu will display "Read from memory X"

CA 550 Programming Guide
Feature Bank 0 - 3 Chirps Transmitter Programming
Feature Bank 1 - 4 Chirps RF Programmer Receive Bank
Feature Bank 2 - 5 Chirps Shock Sensor Programming (W/Transmitter Only)
Lite Touch Adjustment Lock increases sensitivity, Unlock decreases sensitivity
Full Trigger Adjustment Lock increases sensitivity, Unlock decreases sensitivity
Feature Bank 3 - 6 Chirps 1 LED Flash 2 LED Flashes 3 LED Flashes 4 LED Flashes
Extended Lock Pulse 1 Second 3.5 Seconds 1 Sec L, Dbl U/L 30 Sec Lk/1 Sec U/L
IgnitionControlled Lock ON OFF
IgnitionControlled Unlock UNLOCKALL Driver Door Only OFF
Headlights Active w/ARM Active w/DISARM Active w/BOTH OFF
Passive Locks Passive Active
Passive/Active Arming Passive Active
Siren/Horn Siren/Horn Siren Horn
HornOutput Timing 10mS 16mS 30mS 40mS
CustomCode ON OFF
2nd Step Unlock ON OFF
Chirp Delete from TX ON OFF
TrunkOutput Timing Push & Hold 20 Sec.
AUX1 Timing Push & Hold 10 Seconds 20 Seconds Latched
AUX2 Timing Push & Hold 10 Seconds 20 Seconds Latched
AUX3 Timing Push & Hold 10 Seconds 20 Seconds Latched
AUX4 Timing Push & Hold 10 Seconds 20 Seconds Latched
Feature Bank 4 - 7 Chirps 1 LED Flash 2 LED Flashes 3 LED Flashes 4 LED Flashes
RF Start Chirp OFF ON
RunTime 5 Minutes 10 Minutes 15 Minutes 20 Minutes
Running Lights ON Steady Flashing
Tach Mode Tachless Mode Tach Mode
Voltage Level >.5V B4 Start <.5V B4 Start
Crank Average/Crank Time Averaging Preset Time
CrankTime .8 Seconds 1.0 Seconds 1.5 Seconds 2.0Seconds
Gas/Diesel Gas 10 Sec Delay 15 Sec Delay 20 Sec Delay
Trans Bypass O/P while RS ON During Start UntilIGN OFF
Temp Controlled Start OFF ON
Single/Double Pulse Start Single BTN Press Double BTN Press

1. SETUP & PROGRAMMING
Transmitter Programming (3 Chirps)
1. With the door open turn the ignition ON
2. Pressand Hold thevalet/override button.
3. Within 10 Seconds the system will chirp (3) three Times
4. Press Button 1 of each transmitter you wish to program.
5. The system will respond with 1 chirp for each accepted transmitter.
Pressingthe overridebutton at anytimeduring programmingwill advance tothe nextbank.
Note: This system has 1 button programming which programs all channels of the system
RF Programmer Receive (4 Chirps)
Note: Using the RF Programmer, program all settings prior to following the steps below.
1. With the door open turn the ignition ON
2. Pressand Hold thevalet/override button.
3. Within 10 Seconds the system will chirp (3) three times (If in Transmitter programming simply press
thevalet/overridebutton oncetoadvanceto thedesiredfeature bank)
4. Pressthe valet/overridebutton again,The systemwill chirp(4) FourTimes
5. Press SEND on the RF Programmer to set all Features and Setting of this system.
6. The unit will flash the Parking lights and emit (2) Long chirps indicating a successful program.
Shock Sensor Programming (5 Chirps)
1. With the door open turn the ignition ON
2. Pressand Hold thevalet/override button.
3. Within 10 Seconds the system will chirp (3) three Times (If in RF programming simply press the
valet/overridebuttontoadvance to thedesiredfeaturebank)
4. Usethe valet/override buttonto advancethrougheach optionbank. For ShockSensor programming
advanceto shocksensor programming bank which is(5) Fivechirps.
5. Use the transmitter OPT button to scroll through the selections in each feature bank.
6. Press transmitter LOCK button to increase sensitivity and transmitter UNLOCK button to decrease
sensitivity
NOTE: Thereare 64levels of adjustmentfor eachoption. Oncethe highest/lowest sensitivityare
achieved, the sire/horn will sound an extended pulse to notify that you are at the end of the scale.
Decreasing sensitivity one more step from the lowest end of the scale will shut that zone off
Manual Feature Bank Programming 3 & 4 (6/7 Chirps) without RF programmer
1. With the door open turn the ignition ON
2. Pressand Hold thevalet/override button.
3. Within 10 Seconds the system will chirp (3) three Times (If in Shock Sensor programming simply
pressthevalet/override buttontoadvance to thedesiredfeature bank)
4. Usethevalet/override button toadvancethrough eachoptionbank. For featureprogrammingadvance
to Feature Bank 1 & 2 which is (6) six chirps and (7) seven chirps.
5. Use the transmitter OPT Button to scroll through the selections in each feature bank.
6. Press the transmitter LOCK Button to change the desired feature. The LED will flash indicating the
changedfeature.
The system will remain in programming mode as long as the ignition is on and the door is
opened, there is no time limit. To exit programming turn the IGNITION OFF

Programming Tach Rate
The unit will not operate unless tach is programmed or tachless option is turned ON. If an attempt is made to start
the vehicle via the remote start without first programming tach, the unit will flash the parking lights 7 times indicating
tach has not been learned and stored. If the tach rate is not properly programmed to the specific vehicle, the unit
may not realize that the vehicle is running in certain instances reengage the starter motor.
The Remote Start Unit will learn the tach rate of most vehicle's single coil, multiple coil packs, or single
injector. To learn tach.
1. Turn the ignition key to the On position.
2. Pressand releasethe valet/override button 3 times.
3. Immediatelyturn theignitionkey Off.
4. Press and hold the valet/override button, then start the vehicle using the key.
5. When the unit senses the tach signal, the parking lights will begin to flash.
6. Allow the vehicle to settle to a norman idle speed.
7. Release the valet/program push-button switch. The parking lights will stay ON Solid indicating that the
learned tach signal is stored and the unit has exited tach learn mode.
NOTE: Ifthe unit failsto learn tachrate due toan improper tachometerconnection or apoor tach source,the
parking lights will not flash. To correct this situation, locate and connect the VIOLET/WHITE wire to the
propertach signal,and thenrepeat thetach learn routine.
Tachless Mode
This unit has 2 types of tachless modes for your convenience:
1. Averaging -Averages the last 8 times the customer has cranked the vehicle and uses that value for the
crank output timing.
Note: When using this option you must crank the vehicle manually (1 Time) before the system will remote
start.
2. Preset time -Youcan select theamount of time theunit cranksthe vehicle.Refer to theCrank Average/
CrankTime
Battery Power (RED)
Locate the vehicle’s battery wire(s) at the ignition switch.
Verification: These wires will register voltage in all positions of the ignition switch.
Connect the RED wire to the vehicle’s battery wire.
Note: Remove all 30 Amp fuses until all connections are made
12 volts Ignition Input/Output (PINK)
Locate the vehicle’s Ignition wire at the ignition switch.
Verification: This wire registers voltage when the key is turned to the ON (or RUN) position. The voltage
does not drop out when the key is turned to the START(or CRANK) position.
Connect the PINK wire to the vehicle’s Ignition wire.
This wire is also used for Ignition 1 Output
1. 4 PIN MAIN POWER HARNESS

(+)
(-)
P
ositive Polarity Outp
ut
(+)
(-)
N
egative Polarity Outp
ut
2. BASIC INSTALLATION - 22 PIN BASE HARNESS
Starter Input (Key Side) (GREEN)
Starter Output (Motor Side) (PURPLE)
Locate the vehicle starter wire.
Verification: This wire registers voltage only when the key is turned to the START position. Cut the vehicle
starter wire in half.
Verification after starter wire is cut:
• KEY SIDE of starter wire registers voltage when the key is turned to the START position.
• MOTOR SIDE of starter wire registers no voltage.
Connect the GREEN wire to the KEY SIDE of the vehicle starter wire at the ignition switch harness.
Connect the PURPLE wire to the MOTOR SIDE of the vehicle starter wire.
Dome Light Supervision Output (+/-) (BLACK/WHITE)
Locate the vehicle’s dome light or pin switch wire
Verification: This wire will register positive voltage or ground when the vehicle's dome is turned ON. Typically
this wire is installed with the door trigger input wire. Refer to NEG/POS door input for reference.
To select Negative or Positive polarity output.:
Refer to Fuse Placement Diagram below

Negative Door Input (GREEN)
Locate the vehicle’s dome light or door pin switch wire.
Verification: This wire will register ground (NEG) when the door is opened and the interior light is on. This
wire will register positive voltage when the door is closed and the interior light is off.
Connect the GREEN wire to the vehicle’s negative door input wire(s).
Positive Door Input (PURPLE)
Locate the vehicle’s dome light or door pin switch wire.
Verification: This wire will register positive voltage(POS) when the door is opened and the interior light is on.
This wire will register ground or "0" Volts when the door is closed and the interior light is off.
Connect the PURPLE wire to the vehicle’s negative door input wire(s).
Chassis Ground Source (BLACK)
Connect the BLACK wire to a solid chassis ground point using a ring terminal and self tapping screw (not
supplied). Scrape away paint from the grounding point to ensure a good connection. The recommended
grounding point is a painted metal surface in the driver’s side kick panel area.
Note: Do not ground the BLACK wire with any other vehicle components.
Ground When Armed Output (ORANGE)
This wire will show Ground when the system is Armed
This wire is used for controlling window modules or additional sensors
Headlight Output (LT. GREEN/ORANGE)
Locate the vehicle’s headlight wire
Verification: This wire will register either positive voltage or ground when the headlights are turned on
Connect the LT. GREEN/ORANGE to the vehicles headlight wire if the system is negative. (LOW CURRENT
ONLY)
Connecting to a Positive Headlight Output
2. 22 PIN BASE HARNESS CONTINUED
30
87
87a
86 85
GREEN/ORANGE Headlight
Output From Control Module
To Vehicle Headlight
Wire
Fused +12 Volt
Battery Feed
Fused +12 Volt
Battery Feed

Hood Pin Input (GRAY)
Install a Hood Pin Switch and connect to the GRAY wire. This connections is required for Remote Start
Verification: This wire when connected will register ground when the vehicle hood is opened
Connect the GRAY wire to the hood pin.
Note: Be sure to loom the wire, and seal the grommet with 3M caulk.
Low Current Horn Output (BROWN/BLACK)
Locate the vehicle’s horn wire at the steering column.
Verification: This wire will rest at positive voltage and register ground when the horn switch is pressed.
Connect the BROWN/BLACK wire to the vehicle’s horn wire.
Instant Trigger Input (BLUE/WHITE)
This wire is a GROUND input for an external sensor or secondary pin switch
Verification: This wire when connected will trigger the security system
Siren Output (+) (BROWN)
Locate a suitable mounting location in the engine compartment for the siren, away from moving parts.
With the bell of the siren aiming downwards, secure the siren in place using self tapping screws, being
careful not do drill into any hoses, wiring or components.
Connect the BLACK siren wire to a chassis ground using a ring terminal and self tapping screw (not
supplied).
Route the BROWN siren output wire from the control module through the firewall and connect to the RED
wire on the siren.
Note: Be sure to loom the wire/wires, and seal the grommet with 3M caulk.
2. 22 PIN BASE HARNESS CONTINUED

Parking Light Output (+/-) (WHITE)
Locate the vehicle’s parking light wire at the vehicle light switch
Verification: This wire will register positive voltage or ground when the vehicle parking light switch is turned
to the ON position.
Positive Polarity Systems:
Connect the WHITE wire to the vehicle’s parking light wire at the light switch. Refer to Fuse Placement
Diagram below
Negative Polarity Systems:
Connect the WHITE wire to the vehicle’s parking light wire at the light switch. Refer to Fuse Placement
Diagram below
Manual ARM input (LT. BLUE/RED)
This wire will ARM the security system when a POS or NEG pulse is applied to it from an external device.
Manual DISARM Input (LT. BLUE/BLACK)
This wire will DISARM the security system when a POS or NEG pulse is applied to it from an external device.
Unlock Switch Sense (LT. BLUE/GREEN)
This wire will prevent the system from disarming the security system when a POS or NEG pulse is applied to it
from an external device. This will prevent the system from disarming if it is pulsed at the same time as the LT.
BLUE/BLACK (Manual Disarm Input) wire.
For example: To prevent the system from disarming from the switch on the door. Connect this wire to the unlock
switch or passenger unlock motor wire
NOTE: Only required if using the factory keyless entry transmitter to arm/disarm this system.
2. 22 PIN BASE HARNESS CONTINUED
(+)
(-)
P
ositive Polarity Outp
ut
(+)
(-)
N
egative Polarity Outp
ut

Song Bird Output (BROWN/WHITE) SB1 Accessory required
This wire controls the SB1 accessory (Not Included)
Connect this wire to one of the WHITE/BLACK wires from the SB1
Trunk Pin Switch Input (-) (BLUE)
Connect the BLUE wire to an optional grounding type trunk pin switch.
Trunk Release Output (+/-) (PINK)
Locate the vehicle’s trunk release wire at the trunk release switch.
Verification: This wire will register either positive voltage or ground when the trunk release is activated.
Positive Polarity Systems:
Connect the PINK wire to the vehicle’s trunk release wire. Refer to Fuse Placement Diagram below
Negative Polarity Systems:
Connect the PINK wire to the vehicle’s trunk release wire. Refer to Fuse Placement Diagram below
Vehicle Tach Signal (18 AWG) (VIOLET/WHITE)
Locate the vehicle’s ignition coil or fuel injector in the engine compartment.
Verification: Refer to Vehicle Wire Color and Location Chart for the wire color and location, or test using the
following procedure:
1. Set voltmeter toAC VOLTS.
2. Attach positive lead of a volt meter to a constant 12-volt source.
3. Attach negative lead of a volt meter to the wire to be tested.
4. Start the engine.
5. Have someone press on the gas pedal slightly as you monitor the meter. If connected to the correct wire,
the voltage reading will increase as the engine’s RPM increases.
Connect the VIOLET/WHITE wire to the negative side of the vehicle ignition coil or fuel injector.
2. 22 PIN BASE HARNESS CONTINUED
(+)
(-)
P
ositive Polarity Outp
ut
(+)
(-)
N
egative Polarity Outp
ut

Parking Brake Input (GRAY/BLACK)
NOTE: The following connection is only required for Turbo Timer.
Verification: This wire will register ground when the vehicle is in PARK or NEUTRAL or if the PARKING
BRAKE is engaged
This wire must see ground for the vehicle for Turbo Timer option to activate
External Start Trigger (WHT/BLUE)
NOTE: The following connection is only required on a REMOTE START installation
This wire will activate the Remote Start when a GROUND pulse is applied to it from an external device
Diesel Wait-To-Start Input (20 AWG) (BLACK/GRAY)
Locate the Diesel Wait-To-Start light wire at the instrument panel.
Verification: This wire registers positive or negative voltage when the wait-to-start light illuminates.
For negative switching circuits follow diagram 1 below. An SPDT relay is required (model HDRLY).
For Positive switching circuits follow diagram 2 below. Use Code Alarm part HDRLY (an SPDT relay, not
included).
2. 22 PIN BASE HARNESS CONTINUED
BLACK/GRAY Wait-To-Star
t
Wire
Vehicle Control Modul
e
Ignition
Wait-To-Start Bulb
At Instrument Panel
1N4004 Diode
30
87
87a
86 85
BLACK/GRAY Wait-To-Star
t
Wire
Vehicle Control Module
Ground
Chassis Ground
Wait-To-Start Bulb
At Instrument Panel

3. 6 PIN REMOTE START HARNESS
Battery Power 1 (12 AWG) (RED)
Locate the vehicle battery wire(s) at the ignition switch.
Verification: These wires will register POS voltage in all positions of the ignition switch.
Connect the RED wire to the vehicle’s battery wire.
Note: Remove all fuses until all connections are made
IMPORTANT!
Ifthevehicleis equipped with more than one battery wire at the ignition switch, connecttheRED
wirefromthe4-pinharnessandthe2ndREDwiretoseparatevehiclebatterywires.
Accessory 1 (Heater/AC) Output (12 AWG) (ORANGE)
Locate the vehicle’s accessory wire at the ignition switch.
Verification: This wire registers voltage when the key is turned to the ON (or RUN) position, but not the ACC
(Accessory) position. The voltage drops out when the key is turned to the START(or CRANK) position.
Connect the ORANGE wire to the vehicle’s accessory wire.
Accessory 2 (Heater/AC) Output (12 AWG) (ORANGE/WHITE)
Locate the vehicle’s accessory 2 wire at the ignition switch.
Verification: This wire registers voltage when the key is turned to the ON (or RUN) position, but not the ACC
(Accessory) position. The voltage drops out when the key is turned to the START(or CRANK) position.
Connect the ORANGE/WHITE wire to the vehicle’s accessory 2 wire.
Ignition 2 Output (12AWG) (PINK/WHITE)
Locate the vehicle’s ignition 2 wire at the ignition switch (if equipped).
Verification: This wire registers voltage when the key is turned to the ON (or RUN) position, but not the ACC
(Accessory) position. The voltage does not drop out when the key is turned to the START(or CRANK)
position.
Connect the PINK/WHITE wire to the vehicle’s ignition 2 wire.
Positive Shutdown, Brake Safety Switch Wire (18 AWG) (BROWN/RED)
Locate the vehicle’s brake light wire at the brake pedal mounted switch.
Verification: This wire registers positive voltage when the brake pedal is pressed.
Connect the BROWN/RED wire to the vehicle’s brake light wire.

Active Output (18 AWG) (BLUE/BLACK)
The Ignition 3 output wire provides a ground output when the remote start function is activated and remains
until 4 seconds after the remote start is shutdown. The Ignition 3 output wire can be used for several
functions listed below. If this wire will be used for multiple application's a 1 amp diode is required in-line
with the stripe facing the control module.
Factory transponder (coded key) bypass.
General Motors VATS bypass, see the diagram below. Use Code Alarm part HDRLY (an SPDT relay, not
included).
Ignition 3 output, see the diagram below. Use Code Alarm part HDRLY (an SPDT relay, not included).
Accessory 2/3 output, see the diagram below. Use Code Alarm part HDRLY (an SPDT relay, not included).
Fused +12 Volt
Battery Source
30
87
87a
86 85
BLUE/BLACK ActiveOutput
Wire
VATS Control Module
Matching Value
Resistor
Ignition Switch
VATS Wire #1, WHITE or WHITE/BLACK
VATS Wire #2, WHITE or VIOLET/WHITE
X CUT
Fused +12 Volt
Battery Source
30
87
87a
86 85
BLUE/BLACK ActiveOutpu
t
Wire
To Vehicle's2nd or 3rd
Accessory Wire
Jump To ORANGE
Accessory Output
Wire From
Control Module
3. 6 PIN REMOTE START HARNESS CONT.
Fused +12 Volt
Battery Source
30
87
87a
86 85
BLUE/BLACK ActiveOutpu
t
Wire
To Vehicle's2nd or 3rd
Ignition Wire
Jump To PINK
Ignition Output
Wire From
Control Module
Ignition 3 Output Accessory 2/3 Output
GMVATS

Pulse Before Start (20 AWG) (LIGHT GREEN/BLACK) 500mA Output
Locate the factory perimeter alarm disarm wire from the key cylinder inside the drivers door.
Verification: This wire registers ground if the key is turned to the unlock position in the driver’s door cylinder.
Connect the LIGHT GREEN/BLACK wire to the factory alarm disarm wire.
Pulse After Start (20AWG) (LIGHT BLUE) 500mA Output
This wire is usually used to re-lock the vehicle’s doors upon remote start if necessary. See section 6 to
determine what type of door lock system the vehicle has.
Pulse After Shutdown (20 AWG) (BLACK/RED) 500mA Output
This wire is usually used to re-lock the vehicle’s doors if they unlock upon remote start shutdown. It can
also be used to pulse a door pin-switch wire to prevent the vehicle’s accessories from remaining on after
remote start shutdown.
Pulse During Crank (20 AWG) (BLACK/YELLOW) 500mA Output
Locate the vehicle’s second starter (crank) wire at the ignition switch. (if equipped)
Verification: This wire registers voltage only in the start (crank) position of the ignition switch.
Connect the BLACK/YELLOW wire as shown in the diagram below. Use Code Alarm part HDRLY (an SPDT
relay, not included).
4. 4 PIN REMOTE START PULSED OUTPUTS
Fused +12 Volt
Battery Source
30
87
87a
86 85
BLACK/YELLOW Pulse
During Crank Wire
To Vehicle's2nd
Starter Wire
Jump To VIOLET
Starter Output
Wire From The
Control Module

Channel 2 (PINK/BLACK)
This wire provides a 500mA negative output capable of driving relays. For Control of optional accessories
(i.e. Power Window/Sunroof,etc.).
To Activate press and hold LOCK & TRUNK. Please refer to the selectable options for timing.
Selectable timing: Push & Hold/10 Seconds/20 Seconds/Press to Latch ON/Press to Latch OFF
Channel 3 / Defrost Output (PINK/GREEN)
Locate the vehicle’s rear window defrost wire.
Verification: This wire will register either positive voltage or ground when the rear defroster is turned on.
For Negative Polarity Systems:
Connect the PINK/GREEN wire to the vehicle defrost wire if the system
is negative.
For Positive Polarity Systems:
If the system is positive, connect the PINK/GREEN wire as shown below. Use Code Alarm part HDRLY (an
SPDT relay, not included).
Note: This output is controlled by press & holding OPT for 2 Seconds
Selectable timing: Push & Hold/10 Seconds/20 Seconds/Press to Latch ON/Press to Latch OFF
Channel 4 (PINK/BLUE)
This wire provides a 500mA negative output capable of driving relays. For Control of optional accessories
(i.e Power Window/Sunroof,etc.).
To Activate press and hold LOCK & OPT. Please refer to the selectable options for timing.
Selectable timing: Push & Hold/10 Seconds/20 Seconds/Press to Latch ON/Press to Latch OFF
Channel 5 (PINK/RED)
This wire provides a 500mA negative output capable of driving relays. For Control of optional accessories
(i.e Power Window/Sunroof,etc.).
To Activate press and hold UNLOCK & OPT. Please refer to the selectable options for timing.
Selectable timing: Push & Hold/10 Seconds/20 Seconds/Press to Latch ON/Press to Latch OFF
5. 4 PIN ADVANCE CHANNEL HARNESS
Fused +12 Volt
Battery Source
30
87
87a
86 85
ORANGE/RED Rear
Defrost Output Wire
To Rear Window
Defrost Grid
Rear Defrost
Control Relay
PINK/GREEN

Negative Lock Output / Positive Unlock Output (GREEN)
Negative Unlock Output / Positive Lock Output (BLUE)
Negative Second Door Unlock Output (BLUE/GREEN)
The door lock / unlock outputs are designed to control several different types of systems which may require
additional parts. Please review the wire and location chart to see which type of door lock system is in your
vehicle. The most common types are shown in the diagrams below.
Negative Switching and Negative Switching with 2-step unlock feature:
All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock / unlock switch.
Verification: These wires will register ground when the Lock and Unlock switches are activated.
Driver’s Door Unlock: Locate the unlock motor wire directly from the actuator inside the driver’s door.
Verification: This wire will rest at ground and register positive voltage when the driver’s door is unlocked.
Connect the GREEN and BLUE or BLUE/GREEN wires shown in diagram 6 below.
Note: When adding the 2 step unlock feature the BLUE/GREEN 2nd door unlock wire will be used to unlock
all vehicle doors on the second press of unlock. An additional SPDT relay (not supplied) (Code Alarm part
HDRLY) is required. Connect the relay as shown in diagram 7 to unlock the driver’s door on the first press
of unlock.
6. DOOR LOCKS
30
87
87a
86 85
BLUE (-) Unlock Outpu
t
To Unlock Side Of
Driver's Door Actuator
Fused +12 Volt
Battery Source
From Keyless Entry
Module Or Door
Lock/Unlock Relays CUT
X
Diagram 7
Lock
Unlock
Door Lock Switch
Vehicle Door Lock
Control Relays
GREEN (-) Lock Output
BLUE (-) Unlock Output Or BLUE/RED
(-) 2nd Door Unlock OutputWhen
InstallingThe 2-step Unlock Feature
Diagram 6
BLUE/GREEN
