Code Alarm caSEC Installation and operating manual

12017 Voxx Electronics Corporation. All rights reserved.
PROFESSIONAL
SERIES
caSEC
2 Way Security and Keyless Entry
Installation and Reference Guide

2caSEC revB
Before You Begin.........................................................................................3
Wire Connection Guide............................................................................... 4
5 Pin Main Harness ................................................................................... 6
9 Pin Input / Output Harness ..................................................................... 7
4 Pin AUX Output Harness........................................................................ 9
3 Pin Door Lock Output Harness............................................................. 11
Additional Ports.........................................................................................15
Antenna / LED / Programming Port........................................................ 15
DBI Port...................................................................................................15
FLCART Cartridge Port ........................................................................... 15
FLCART 4 Pin Programming Port ........................................................... 15
FLCART Harness Port............................................................................. 15
Set Up & Programming ............................................................................. 16
Transmitter Programming........................................................................ 16
Manual Feature Programming................................................................. 16
Programming Feature Banks .................................................................. 17
PC Based Feature Programming / Firmware Updates - (Optional)......... 20
Adjusting the Shock Sensor .................................................................... 21
Testing the Shock Sensor........................................................................ 21
Chirp Delete - User Accessible................................................................ 21
User Selectable LED ............................................................................... 21
Dome Light Delay / Theater Dimming ..................................................... 22
Feature Descriptions................................................................................. 23
Transmitter Button Functions .................................................................. 29
Security Trigger Zones.............................................................................. 31
System Layout...........................................................................................32
Table of Contents

32017 Voxx Electronics Corporation. All rights reserved.
Before You Begin
Thank you for trusting Code Alarm products! If you are a consumer, please note:
Professional installation is strongly recommended.
This manual assumes the installer has adequate knowledge of the following
expertise, and as such, it does not cover these topics in detail:
12-volt electronics
Testing and verifying circuits
Making safe and lasting wiring connections
Factory ignition, power, lighting, data bus and sensing systems
Factory systems and components to avoid
Safe wire routing, circuit protection and product placement
  Accesstovehicle-specictechnicalinformation
In addition, this manual assumes the installer has the proper tools, skill and
facilities to perform a professional installation.
Performing an improper installation could void your vehicle warranty and/or
result in damage to the vehicle or its components, improper system function,
unsafe vehicle operation or physical injury.
If you are an authorized Code Alarm installation technician, please use this
manual as a more detailed addendum to the Installation Quick Reference Guide
that accompanies the Code Alarm system. You can download a printable PDF of the
quick reference guide at voxxuniversity.com.
Technical Support [phone]
or go to
www.voxxuniversity.com

4caSEC revB
DBI PORT
CASEC
# 4360713
FLCART PROGRAMMING PORT
FLCART PORT
FLCART HARNESS PORT
WHITE/RED PARKING LIGHT INPUT
WHITE PARKING LIGHT OUTPUT
BLACK GROUND
BROWN SIREN OUTPUT ( + )
RED BATTERY 12V ( + )
SHOCK SENSOR PORT
BLUE/WHITE INSTANT TRIGGER INPUT ( - )
GREEN DOOR TRIGGER INPUT ( - )
ORANGE GROUND WHEN ARMED ( - )
PURPLE DOOR TRIGGER INPUT ( + )
YELLOW IGNITION INPUT ( + )
RED/WHITE TRUNK RELEASE OUTPUT ( - )
BROWN/BLACK HORN OUTPUT ( - )
VIOLET/BLACK AUX 1 ( - )
LT GREEN/BLACK FACTORY DISARM OUTPUT ( - )
BLUE UNLOCK OUTPUT ( - )
OPEN
GREEN LOCK OUTPUT ( - )
PINK/BLACK AUX 5 OUTPUT ( - )
ORANGE/BLACK AUX 4 OUTPUT ( - )
GRAY/BLACK AUX 3 OUTPUT ( - )
WHITE/BLACK AUX 2 OUTPUT ( - )
#1032368
#1031421
#4120184
#1031423
RED BATTERY 12V ( + )
BLACK
GROUND WHEN ARMED ( - )
BLUE FULL TRIGGER ( - )
GREEN WARN AWAY TRIGGER ( - )
SHOCK SENSOR & HARNESS
#4700023
ORANGE 86 - ARMED OUTPUT ( - )
RED 85 - IGNITION ( + )
BLACK 87A - STARTER OUTPUT - MOTOR SIDE
WHITE / BLACK 30 - STARTER INPUT - KEY SIDE
OPEN 87 - OPEN
STARTER INTERUPT RELAY & HARNESS
86 85
30
87
87a
#1024405
Programming Note:
P
The default wire function settings are listed next
to the wire color. Wires shown with can be
programmed to perform different functions.
Refer to the Feature Programming section to
change the default setting.
P
P
P
P
P
P
P
P
P
P
P
P
Replacement Part
Notification Harness
(4-Pin)
Replacement Part
Input / Output
Harness
(9-Pin)
Aux Output
Harness
(4-Pin)
Replacement Part
ANTENNA
LED
VALET
** RF KITS SOLD SEPERATELY **
Replacement Parts
1-Way # 4180065
2-Way # 4180064
Harness (4-Pin)
# 4120388
ANTENNA PORT
Replacement Part
Door Lock Harness (3-Pin)
Wire Connection Guide
System Layout
This diagram shows the available harnesses and connections for the caSEC. Note that
you may not use all connections and modules in your installation.

52017 Voxx Electronics Corporation. All rights reserved.
3 Pin Lock Output Harness
9 Pin Input / Output Harness
5 Pin Main Harness
4 Pin AUX Output Harness
1WHITE/REDPARKING LIGHT INPUT
2WHITE PARKING LIGHT OUTPUT
3BLACKGROUND
4BROWNSIREN OUTPUT ( + )
5REDBATTE RY 12V ( + )
5 PIN MAIN
1BLUE/WHITE INSTANT TRIGGER INPUT ( - )
2GREEN DOOR TRIGGER INPUT ( - )
3ORANGE GROUND WHEN ARMED OUTPUT ( - )
4PURPLE DOOR TRIGGER INPUT ( + )
5YELLOWIGNITION INPUT ( + )
6RED/WHITETRUNK RELEASE OUTPUT ( - )
7BROWN/BLACKHORN OUTPUT ( - )
8VIOLET/BLACK AUX 1 ( - )
9LT GREEN/BLACK FACTORY DISARM OUTPUT ( - )
9 PIN INPUT / OUTPUT
1PINK/BLACK AUX 5 OUTPUT ( - )
2ORANGE/BLACK AUX 4 OUTPUT ( - )
3GRAY/BLACKAUX 3 OUTPUT ( - )
4WHITE/BLACKAUX 2 OUTPUT ( - )
4 PIN AUX
OUTPUT
1BLUE UNLOCK ( - )
2OPEN
3GREEN LOCK ( - )
3 PIN
LOCK

6caSEC revB
3 BLACK GROUND
Connect the BLACK wire to a solid chassis ground point using a ring terminal and
self tapping screw (not supplied). Scrape away paint from the grounding point to
ensure a good connection. The recommended grounding point is a metal surface in
the driver’s side kick panel area.
NOTE: Do not ground the BLACK wire with any other vehicle components.
5 Pin Main Harness
1 WHITE/RED PARKING LIGHT INPUT
2 WHITE PARKING LIGHT OUTPUT
Locate the parking light output wire at the vehicle’s light switch.
  Verication: This wire registers positive voltage when the parking lights are
turned on.
Positive switching Parking Lights:
Connect the WHITE/RED wire to a 15 Amp max fused battery source.
Connect the WHITE wire to the parking light output wire.
Negative switching Parking Lights:
Connect the WHITE/RED wire to a good chassis ground.
Connect the WHITE wire to the parking light output wire.
4 BROWN SIREN OUTPUT ( + )
Locate a suitable mounting location in the engine compartment for the siren, away
from moving parts.
With the bell of the siren aiming downwards, secure the siren in place using self
tapping screws, being careful not do drill into any hoses, wiring or components.
Connect the BLACK siren wire to a chassis ground using a ring terminal and self
tapping screw (not supplied).
 RoutetheBROWNsirenoutputwirefromthecontrolmodulethroughtherewalland
connect to the RED wire on the siren.
NOTE: Be sure to loom the siren wires, and seal the grommet.

72017 Voxx Electronics Corporation. All rights reserved.
3 ORANGE GROUND WHEN ARMED OUTPUT ( - )
This wire will have a continuous ( - ) 500mA output when the system is Armed. This
wire is typically used for controlling window modules or additional sensors.
 Thisoutputiscongurableinoptionprogramming.
5 RED BATTERY 12V ( + )
Locate 1 of the vehicle’s constant 12 Volt battery wires at the ignition switch.
 Verication:This wire will register ( + ) voltage in all positions of the ignition
switch.
Connect the RED wire to the constant 12 Volt battery wire.
NOTE: Remove all fuses until all connections are made.
9 Pin Input / Output Harness
1 BLUE/WHITE INSTANT TRIGGER INPUT ( - )
This wire is a GROUND input for an external sensor or secondary pin switch.
 Verication:This wire when connected will trigger the security system.
2 GREEN DOOR TRIGGER INPUT ( - )
Locate the vehicle’s dome light or door pin switch wire.
 Verication:This wire will register ground (NEG) when the door is opened
and the interior light is on. This wire will register positive voltage when the
door is closed and the interior light is off.
Connect the GREEN wire to the vehicle’s negative door input wire(s).
NOTE: Certain vehicles may require multiple connections. Refer to vehicle
application guide

8caSEC revB
6 RED/WHITE TRUNK RELEASE OUTPUT ( - )
Locate the vehicle’s trunk release wire at the trunk release switch.
 Verication:This wire will register either positive voltage or ground when
the trunk release is activated.
 Thiswirewillsupplya(-)200mAoutputandcanbeconguredinoption
programming.
4 PURPLE DOOR TRIGGER INPUT ( + )
Locate the vehicle’s dome light or door pin switch wire.
 Verication:This wire will register positive voltage (POS) when the door is
opened and the interior light is on. This wire will
register ground or “0” Volts when the door is closed and the interior light is
off.
Connect the PURPLE wire to the vehicle’s positive door input wire(s).
NOTE: Certain vehicles may require multiple connections. Refer to vehicle
application guide
5 YELLOW IGNITION INPUT ( + )
Locate the vehicle’s ignition wire at the ignition switch.
   Verication:This wire registers voltage when the key is turned to the ON (or
RUN) position. The voltage does not drop out when the key is turned to the
START (or CRANK) position.
Connect the YELLOW wire to the vehicle’s Ignition wire.
7 BROWN/BLACK HORN OUTPUT ( - )
Locate the vehicle’s horn wire.
 Verication:This wire will register at positive voltage and register
ground when the horn switch is pressed.
Connect the BROWN/BLACK wire to the vehicle’s horn wire. This is a low current
output, 200mA.

92017 Voxx Electronics Corporation. All rights reserved.
8 VIOLET/BLACK AUX 1
This wire provides a ( - ) 200mA output capable of driving relays. For Control of
optional accessories (i.e. Power Window/Sunroof, etc.).
 Toactivaterefertothetransmitterbuttoncongurationchart.Pleaserefertothe
selectable options for timing.
9 LT GREEN/BLACK FACTORY DISARM OUTPUT ( - )
This wire will supply a ( - ) 200mA pulse upon disarming the system. Locate the
factory perimeter alarm disarm wire from the key cylinder inside the drivers door.
  Verication: This wire registers ground if the key is turned to the unlock
position in the driver’s door cylinder.
Connect the LT GREEN/BLACK wire to the factory alarm disarm wire.
4 Pin AUX Output Harness
1 PINK/BLACK AUX 5
This wire provides a ( - ) 200mA output capable of driving relays. For Control of
optional accessories (i.e. Power Window/Sunroof, etc.).
 Toactivaterefertothetransmitterbuttoncongurationchart.Pleaserefertothe
selectable options for timing.
2 ORANGE/BLACK AUX 4
This wire provides a ( - ) 200mA output capable of driving relays. For Control of
optional accessories (i.e. Power Window/Sunroof, etc.).
 Toactivaterefertothetransmitterbuttoncongurationchart.Pleaserefertothe
selectable options for timing.

10 caSEC revB
3 GRAY/BLACK AUX 3
This wire provides a ( - ) 200mA output capable of driving relays. For Control of
optional accessories (i.e. Power Window/Sunroof, etc.).
 Toactivaterefertothetransmitterbuttoncongurationchart.Pleaserefertothe
selectable options for timing.
4 WHITE/BLACK AUX 2
This wire provides a ( - ) 200mA output capable of driving relays. For Control of
optional accessories (i.e. Power Window/Sunroof, etc.).
 Toactivaterefertothetransmitterbuttoncongurationchart.Pleaserefertothe
selectable options for timing.

112017 Voxx Electronics Corporation. All rights reserved.
3 Pin Lock Output Harness
1 BLUE UNLOCK ( - )
3 GREEN LOCK ( - )
The door lock / unlock outputs are designed to control several different types of
systems which may require additional parts. Please review the wire and location
chart to see which type of door lock system is in your vehicle. The most common
types are shown in the following diagrams.
These wires supply a ( - ) 500mA output.
Negative Switching Locks
All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock / unlock
switch.
  Verication: These wires will register ground when the Lock and Unlock
switches are activated.
Connect the GREEN and BLUE wires shown in the diagram below.
Lock
Unlock
Vehicle Door Lock
Control Relays
GREEN ( - ) Lock Output
BLUE ( - ) Unlock Output
Negative Locks:

12 caSEC revB
Positive Switching Locks
All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock / unlock
switch.
  Verication: These wires will register positive voltage when the Lock and
Unlock switches are activated.
Connect the GREEN and BLUE wires shown in the diagram below.
Reverse Polarity Locks (5-Wire Door locks)
All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock / unlock
switch.
  Verication: These wires will rest at ground and register positive
voltage when the Lock and Unlock switches are activated.
Connect the GREEN and BLUE or BLUE/GREEN wires shown in the diagram below
using (2) SPDT relays (not supplied).
Lock
Unlock
87
87a
86 85
30
87
87a
86 85
30
Vehicle Door Lock
Control Relays
Fused +12 Volt
Battery Souce
Fused +12 Volt
Battery Souce
GREEN ( - ) Lock Output
BLUE ( - ) Unlock Output
Positive Locks:
Lock
Unlock
87
87a
86 85
30
87
87a
86 85
30
Fused +12 Volt
Battery Souce
Fused +12 Volt
Battery Souce
GREEN ( - ) Lock Output
BLUE ( - ) Unlock Output
Reverse Polarity Locks:
X
Cut
X
Cut
To Door Lock Motor
To Door Lock Motor

132017 Voxx Electronics Corporation. All rights reserved.
Negative Multiplexed Locks
All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock / unlock
switch.
  Verication: This wire will show variable ground when the switch is activated.
 Pleaseconsultthewireandlocationchartforspecicresistorvaluesfor
your vehicle.
Connect the GREEN and BLUE or BLUE/GREEN wires shown in the diagram below
using (2) SPDT relays (not supplied).
Positive Multiplexed Locks
All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock / unlock
switch.
  Verication: This wire will show variable positive voltage when the switch is
 activated.Pleaseconsultthewireandlocationchartforspecicresistor
values for your vehicle.
Connect the GREEN and BLUE or BLUE/GREEN wires shown in the diagram below
using (2) SPDT relays (not supplied).
Lock
Unlock
Vehicle Door Lock
Control Relays
GREEN ( - ) Lock Output BLUE ( - ) Unlock Output
Multiplex Locks:
87
87a
86
30
87
87a
86
30
85 85
Fused +12 Volt
Battery Source
Ground
Resistor
Lock
Unlock
Vehicle Door Lock
Control Relays
GREEN ( - ) Lock Output BLUE ( - ) Unlock Output
Multiplex Locks:
87
87a
86
30
87
87a
86
30
85 85
Fused +12 Volt
Battery Source
Resistor

14 caSEC revB
Adding Aftermarket Actuators
After installing aftermarket actuators, (not supplied). Connect the GREEN and BLUE
wires shown in the diagram below using (2) SPDT relays (not supplied).
30
87
87a
86 85
Fused +12 Volt
Battery Source
Door Lock
Actuator
30
87
87a
86 85
Chassis
Ground
Chassis
Ground
GREEN ( - ) Lock Output
BLUE ( - ) Unlock Output
Fused +12 Volt
Battery Source
M

152017 Voxx Electronics Corporation. All rights reserved.
Antenna / LED / Programming Port
Mount the supplied antenna/receiver to a clear spot on the vehicle’s windshield that
will not block the driver’s vision. A good location is usually high on the windshield
near the rear view mirror. Be careful not to mount the antenna/receiver on any
metallicwindowlm,asthiswilleffectsystemrange.Routetheantenna/receiver
cable to the control module and plug into the antenna port.
Additional Ports
DBI Port - 4 Pin Data Bus Interface
The DBI port is used for external Flashlogic data immobilizer & door lock Interface
modules to communicate with the vehicle’s databus. When using the DBI port to
control Flashlogic modules please refer to the D2D (Data to Data) function list
availablepervehiclermwareonthetechservicewebsite.
FLCART Cartridge Port
This port is for installing the Flashlogic FLCART data immobilizer & door lock
interface cartridge used to communicate with the vehicle’s databus.
FLCART 4 Pin Programming Port
This 4 port is used for programming the Flashlogic FLCART interface cartridge via
the FLPROG Weblink Updater. Refer to the Flashlogic website for more details.
FLCART Harness Port
This port is for the harness included with the FLCART interface cartridge. Refer to the
Flashlogic website for more details.

16 caSEC revB
Set Up & Programming
Transmitter Programming - Feature Bank 1
1. Turn the ignition ON.
2. Press and hold the valet/override button.
3. Within 10 seconds the system will chirp (3) three times.
4. Press 1 button of each transmitter you wish to program.
5. The system will respond with 1 chirp for each accepted transmitter.
6. Pressing the override button at anytime during programming will advance to
the next bank.
NOTE: The system will exit transmitter programming after 15 seconds of inactivity.
NOTE: This system has 1 button programming which programs all channels of the
system.
NOTE: The system will hold up to 4 transmitters in memory, programming a 5th
transmitter will erase the oldest transmitter in memory.
NOTE:ThissystemhasPTN-ProgrammedTransmitterNotication.Eachtimethe
ignitionisturnedON,theLEDwillashthenumberoftransmittersprogrammedtothe
system.
Transmitter programming for 2 Car Mode *2 way transmitter only:
1. Enter the transmitter into 2 Car Mode. (Refer to transmitter operation in
the owners manual for 2 car operation)
2. Follow the steps above for transmitter programming.
NOTE: 2 car mode requires an additional security system installed in a second
vehicle.

172017 Voxx Electronics Corporation. All rights reserved.
Defaulting All Features: Pressing the button anytime while in any of the feature
banks will default all features and return you to feature bank 2 - 4 chirps.
NOTE: The system will remain in feature programming mode as long as the ignition
is on, there is no time limit. To exit programming turn the IGNITION OFF.
Manual Feature Programming - Feature Bank 2 & 3
1. Turn the ignition ON.
2. Press and hold the valet/override button.
3. Within 10 seconds the system will chirp (3) three times.
4. Use the valet/override button to advance through each option bank. For
feature programming advance to Feature Bank 2 or 3, which is (4) four and
 (5)vechirps.
5. Use the transmitter button to scroll through the selections in each
feature bank, the system will chirp to match the feature number.
6. Press the transmitter button to change the desired feature. The LED will
 ashindicatingthechangedfeature.

18 caSEC revB
Refer to transmitter programming.
Feature Bank 1 - 3 Chirps
Transm itter Programming
Feature Bank 2 - 4 Chirps
Security Control 1 LED Flash 2 LED Flash 3 LED Flash 4 LED Flash 5 LED Flash 6 LED Flash
1Silent Choice ON OFF
2Door Locks Active Passive
3System ArmingActive Passive
4System Notifications Siren & Horn Siren Only Horn Only
5Alarm Duration 30 Seconds 60 Seconds
6SecurityON OFFON w/ OEM
Remote Start
7Anti-Hijack Mode OFFON
8Ground While Armed
Orange ( - ) Output
Ground While
Armed
Ground While
Disarmed
9DBI Port ProtocolDBI ADS
10 Arm / Disarm Chirps
Standard:
2 - Arm
1 - Disa rm
Inve rted:
1 - Arm
2 - Disarm
11 LED IndicatorON OFF
12 Auto Re-lock OFFLock Only Arm & Lock
13 Extended Parking Lights OFF After Unlock After Lock After Lock &
Unlock
14 Parking Light Relay / Trunk ( - )
Output Standard Inve rted

192017 Voxx Electronics Corporation. All rights reserved.
F
eature Bank 3 - 5 Chirps
Ou
tput Control 1 LED Flash 2 LED Flash 3 LED Flash 4 LED Flash 5 LED Flash 6 LED Flash
1Lock / Unlock Timing 1 Sec. 3.5 Sec. 1 Sec. Lock,
2x Unlock
30 Sec. Lock,
2x Unlock
2x Lock,
1 Sec. Unlock 0.5 Sec.
2Factory Disarm
Lt Green / Black
Factory
Disa rm 2nd Unlock Factory Disarm 2x 500mS
Factory Disarm
350mS
Factory Disarm
500mS
Factory Disarm
w/ Unlock
Timing
3 Ignition Locks OFFLock / Unlock Lock Only Unlock Only
4Trunk Output Timing1 Sec. 10 Sec.20 Sec. Latched until
IGN ON
Latched ON
until Button
Press
5Horn Output Timing16mS 10mS 30mS 40mS 50mS
6Real Panic ON OFF
7AUX 1
Violet / Black Output 1 Sec. LatchedLatched until
IGN ON
Dome Light
Output
8AUX 2
White / Black Output 1 Sec. LatchedLatched until IGN ON
10 Sec.
w/ Arm
10 Sec.
w/ DisarmL.E.D. Output
9AUX 3
Gray / Black Output 1 Sec. LatchedLatched until IGN ON
10 Sec.
w/ Arm
10 Sec.
w/ DisarmL.E.D. Output
10 AUX 4
Orange / Black Output 1 Sec. LatchedLatched until IGN ON
10 Sec.
w/ Arm
10 Sec.
w/ DisarmL.E.D. Output
11 AUX 5
Pink / Black Output 1 Sec. LatchedLatched until IGN ON
10 Sec.
w/ Arm
10 Sec.
w/ DisarmL.E.D. Output

20 caSEC revB
Code Alarm Utility App
Feature Programming / Firmware Updates (optional)
The new Code Alarm Utility App is able to set feature options, save frequently used
featurecongurationsaswellasupdatemodulermware.
PC System Requirements:
Windows XP SP3 or above
Min 1GB RAM
Net Framework 4.0 or above
Screen Resolution - Suggested 1280x1024 or above
Required Accessory & PC Software:
VEPROG Programmer Accessory
CA Utility App
VEPROG drivers
Download and Install the Required Drivers:
1. To download the Code Alarm Utility App visit the Voxx University website at
voxxuniversity.com (registration/login required).
2. Select VOXXTECH and locate the utility app under the heading Software
Downloads.
3. The Code Alarm Utility App download includes both the CA Utility app and
necessary VEPROG drivers.
4. Install both items before attempting to update modules.
Use a PC and VEPROG tool for Feature Programming or Firmware Updates:
1. Launch the Code Alarm Utility App.
2. Connect the VEPROG to your PC via the USB port.
3. Connect the VEPROG to the Code Alarm Module.
 4. Selectthefeaturesyouwishtochangeorupdatermwareifneeded.
