Code Blue CB 2 Series Manual

800.205.7186 • www.codeblue.com
CB 2 Series
Model: ENBS06, ENBS07, ENBS08, ENBS09, ENBS10, ENBS15
Admin Guide
Installation | Configuration | Support | Maintenance | Use

Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com page 2 of 43 GU-149-Z1
CB 2 Series
Administrator Guide
WARNING
ONLY QUALIFIED PERSONNEL SHOULD INSTALL THESE UNITS. THE INSTALLATION
SHOULD CONFORM TO ALL LOCAL CODES. IN SOME COUNTRIES, A CERTIFIED
ELECTRICIAN MAY BE REQUIRED.
NOTICE TO USERS
Copyright © Code Blue Corporation. All rights reserved. This guide or software
described herein, in whole or part, shall not be reproduced, translated or reduced to any
machine-readable form without prior written approval from Code Blue Corporation.
CODE BLUE CORPORATION PROVIDES NO WARRANTY WITH REGARD TO THIS
GUIDE, THE SOFTWARE OR OTHER INFORMATION CONTAINED HEREIN AND HEREBY
EXPRESSLY DISCLAIMS ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR ANY PARTICULAR PURPOSE WITH REGARD TO THIS GUIDE, THE
SOFTWARE OR SUCH OTHER INFORMATION. IN NO EVENT SHALL CODE BLUE
CORPORATION BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, OR SPECIAL
DAMAGES, WHETHER BASED ON TORT, CONTRACT, OR OTHERWISE, ARISING OUT
OF OR IN CONNECTIONS WITH THIS GUIDE, THE SOFTWARE OR OTHER
INFORMATION CONTAINED HEREIN OR THE USE THEREOF.
Code Blue Corporation reserves the right to make any modifications to this guide or the
information contained herein at any time without notice. The software described herein
may also be governed by the terms of a separate user license agreement.
Code Blue® is a registered trademark of Code Blue Corporation. The names of actual
companies and products mentioned herein may be the trademarks of their respective
owners.

Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com page 3 of 43 GU-149-Z1
CB 2 Series
Administrator Guide
Section
Section Title
Page #
2
Introduction
4
Model Photos
4
3
Dimensions
5
4
Safety Information
10
5
Installation Instructions
11
Tools Needed
11
CB 2-a Installation Instructions
12
CB 2-e Installation Instructions
14
CB 2-s Installation Instructions
16
CB 2-ap (Audio Paging) Installation Instructions
18
6
Alternative Mounting Options
20
7
How to Update Connectors
21
8
Remote Mount Beacon/Strobe Installation
23
Strobe Management Instructions
24
Strobe Programming
25
9
AED Access and Maintenance Guide
26
10
Power Requirements
27
11
Wiring Diagrams
31
CB 2-a & CB 2-e 24-277V AC DIN Rail Power System
31
CB 2-s 110-347V AC Standard Wiring with Multi-Tap Transformer (Power Brick)
32
CB 2-s 24V DC Standard Wiring
33
CB 2-a & CB 2-e PoE Standard DIN Rail Wiring
34
CB 2-s PoE Standard Wiring
35
CB 2-ap Audio Paging Standard DIN Rail Wiring
36
CB 2-ap Audio Paging Amplifier Wiring & Volume Control
37
12
Locating Unit Serial Numbers
38
13
Maintenance Schedule
39
14
Warranty
41
15
Download Information
42
16
Legal & Regulatory Information
43
Table of Contents

CB 2 with
Audio Paging
(CB 2-ap)
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com page 4 of 43 GU-149-Z1
Thank you for choosing the CB 2 Series wall mount for your Code Blue application.
The CB 2 Series has a rugged steel construction, shatterproof Lexan Lens, industrial
engineering grade reflective graphics and weather, UV and graffiti resistant paint, and
is illuminated by a high-powered, 270 lumens/92 candela LED blue beacon/strobe.
The CB 2 Series is a good fit for any indoor or outdoor application, including parking
facilities.
Our unmistakable craftsmanship makes our Help Points® the most rugged on the
market, withstanding the punishment of natural and manmade disasters.
Other options include:
IP and analog phones
Audio Paging Speaker Option
Cellular Communication
Long-life LED area light
Camera & card reader openings
Temperature Controlled automated external defibrillator(AED)
CB 2-a CB 2-e CB 2-e with
AED Housing
CB 2-s
CB 2 Series
Administrator Guide
2 Introduction

Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com page 5 of 43 GU-149-Z1
CB 2 Series
Administrator Guide
3 Dimensions
CB 2-a

Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com page 6 of 43 GU-149-Z1
CB 2 Series
Administrator Guide
CB 2-ap
29.80
3.34
11.75
8.50
11.90
1.50
1.45
2.29
26.00
9.00
.44 TYP
2.00
3.70
23.99
4.00
FRONT VIEW BACK VIEW SIDE VIEW
3.64

Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com page 7 of 43 GU-149-Z1
CB 2 Series
Administrator Guide
CB 2-e

Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com page 8 of 43 GU-149-Z1
CB 2 Series
Administrator Guide
CB 2-s

Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com page 9 of 43 GU-149-Z1
CB 2 Series
Administrator Guide
CB 2 with AED
46.72
3.36
22.31
1.73
5.11
5.00
11.75
18.00
8.50
FRONT VIEW
8.00
15.50
BOTTOM VIEW
3.88
5.00
1.13
39.16
4 .86
SIDE VIEW
11.24
39.00
3.00
24.00
3.375
3.25
8.00
9.00
BACK VIEW
.44
1.13

Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com page 10 of 43 GU-149-Z1
CB 2 Series
Administrator Guide
Indicates a hazardous situation which, if not avoided, will result in
death or serious injury.
Indicates a hazardous situation which, if not avoided, could result in
death or serious injury.
CAUTION
Indicates a hazardous situation which, if not avoided, could result in
minor or moderate injury.
NOTICE
Indicates a situation which, if not avoided, could result in damage to
property.
IMPORTANT
Indicates significant information that is essential for proper product
functionality.
NOTE
Indicates useful information that helps get the most out of a
product.
4 Safety Information
HAZARD LEVELS LEGEND
WARNING
DANGER
Safety Instructions
Code Blue products shall be installed by trained professionals. The installation should
conform to all local codes. In some countries, a certified electrician may be required.
When transporting a Code Blue product, use the original packaging or equivalent to
prevent damage to the product.
Code Blue products shall be used in compliance with local laws and regulations.
Store the Code Blue product in a dry and ventilated environment.
Do not install the product on unstable brackets, surfaces or walls.
Use only applicable tools when installing Code Blue products.
Do not use chemicals, caustic agents, steel wool or aerosol cleaners other than those
tested and recommended by Code Blue.
Use only accessories that comply with technical specifications of the product. These
can be provided by Code Blue or a third party.
Use only spare/replacement parts provided by or recommended by Code Blue.
Transportation
When transporting a Code Blue product, use the original packaging or equivalent to
prevent damage to the product.
WARNING
NOTICE
NOTICE

Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com page 11 of 43 GU-149-Z1
CB 2 Series
Administrator Guide
Important Notes:
Getting Started
EIA/TIA, ANSI, CSA and BICSI cabling or similar standards shall be adhered to
for proper operation of Code Blue communication devices connected to
copper or fiber infrastructures communications cable and electrical cable in
the same conduit is not an acceptable installation and shall not be supported.
Analog phones require a minimum of 23mA for proper operation (26-29mA
recommended).
Each analog speakerphone requires its own phone line or PBX extension.
Multiple units shall not be supported.
Speakerphones require programming before operation. Consult the
speakerphone’s Administrator Guide for instructions.
If you are installing IP speakerphones, please read the appropriate manuals
and consult with your Network Administrator.
Size electrical wiring based on length of run.
5 Installation Instructions
Tools Needed
All CB 2-s Units:
Drill
Drill bit (5/8” Masonry bit for concrete; 1/2” standard bit for wood)
3/8” Hex head driver bit (Security Bit)
Level
3/8” Socket set
Ladder - For remote audio paging or remote beacon/strobe only

Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com page 12 of 43 GU-149-Z1
1. Unscrew security screw from bottom of unit. Lift and open unit.
2. Disconnect wire connections from strobe, faceplate light and phone. Lift up on black locking
tab on each connector to separate.
3. Unscrew the nut from the stud to release safety cable from back plate. Place nut back on stud.
4. Lift up on front of unit and remove. Set aside.
5. Using back plate of unit as template, level and mark the four mounting holes.
6. Drill all marked holes with appropriate drill bit.
7. If attaching to concrete or brick, insert one 3/8” anchor into each drilled hole.
8. If attaching to wood, 3/8” lag bolt is required.
9. On one 3/8x3” lag bolt, add one 3/8” flat stainless steel washer followed by one 3/8” flat
rubber washer.
10. Slide lag bolt through top left mounting hole.
11. Add one 3/8” flat rubber washer, followed by one 3/8” flat stainless steel washer to end of
screw.
12. Drill lag bolt into mounting hole.
13. Repeat previous steps for three remaining mounting holes.
14. Slide front of unit back onto bottom tabs of back plate.
15. Reattach safety cable.
16. Reconnect strobe, faceplate light and phone to power system.
17. Connect incoming power to appropriate tap (high voltage or low voltage).
18. Connect incoming communication line (CAT6) to phone using its WAN port.
19. Close unit.
20. Replace security screw into bottom of unit.
CB 2 Series
Administrator Guide
CB 2-a Installation Instructions

Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com page 13 of 43 GU-149-Z1
2.21
28.21
26.00
9.00
1.25
1.30 1.30
10.30 10.30
1.80 9.80
CB 2 Series
Administrator Guide
CB 2-a Mounting Schematic
DISCLAIMER: The dimensions above are intended as guidelines only. For specific installation
requirements, reference your local codes.
All wiring must be installed and connected by experienced and certified personnel to meet local and national
electrical codes, and will include a service disconnect.

Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com page 14 of 43 GU-149-Z1
CB 2 Series
Administrator Guide
CB 2-e Installation Instructions
1. Unscrew security screw from bottom of unit. Lift and open unit.
2. Disconnect wire connections from strobe, faceplate light and phone. Lift up on
black locking tab on each connector to separate.
3. Unscrew the nut from the stud to release safety cable from back plate. Place nut
back on stud.
4. Lift up on front of unit and remove. Set aside.
5. Using back plate of unit as template, level and mark the four mounting holes.
6. Drill all marked holes with appropriate drill bit.
7. If attaching to concrete or brick, insert one 3/8” anchor into each drilled hole.
8. If attaching to wood, 3/8” lag bolt is required.
9. On one 3/8x3” lag bolt, add one 3/8” flat stainless steel washer followed by one
3/8” flat rubber washer.
10. Slide lag bolt through top left mounting hole.
11. Add one 3/8” flat rubber washer, followed by one 3/8” flat stainless steel washer to
end of screw.
12. Drill lag bolt into mounting hole.
13. Repeat previous steps for three remaining mounting holes.
14. Slide front of unit back onto bottom tabs of back plate.
15. Reattach safety cable.
16. Reconnect strobe and phone to power system.
17. Connect incoming power to appropriate tap (high voltage or low voltage).
18. Connect incoming communication line (CAT6) to phone using its WAN port.
19. Close unit.
20. Replace security screw into bottom of unit.

Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com page 15 of 43 GU-149-Z1
2.21
28.21
26.00
9.00
1.25
1.30 1.30
10.30 10.30
1.80 9.80
CB 2 Series
Administrator Guide
CB 2-e Mounting Schematic
DISCLAIMER: The dimensions above are intended as guidelines only. For specific installation
requirements, reference your local codes.
All wiring must be installed and connected by experienced and certified personnel to meet local and national
electrical codes, and will include a service disconnect.

Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com page 16 of 43 GU-149-DD
CB 2 Series
Administrator Guide
CB 2-s Installation Instructions
1. Unscrew security screw from top of unit. Lift and open unit.
2. Open or remove the unit shell.
Open: Allow top of shell to fall open while base of the shell remains in
contact with base of backplate. Unit will prop open to the length of the
safety cable so you can continue hands-free installation of the unit.
Remove: Allow unit shell to fall open to the length of the safety cable.
Unplug the area light and strobe light, and disconnect the safety cable to
fully detach the front face. Set aside for easier access to mounting holes.
3. Using a level and measuring tape, mark the appropriate height and mounting
hole placement by referring to the wall mounting diagram on page 8, or holding
the the unit against the wall as a template.
4. Using a 3/8” drill bit , drill the pilot holes
5. Insert anchors into pilot holes. (For concrete walls only: If mounting to wood
wall, skip this step)
6. Pre-assemble bolts into unit mounting holes with washers placed on the bolt in
order of:
Steel washer
Rubber washer
Unit backplate
Rubber washer
Steel washer
7. Holes in the back and bottom of the unit have been provided for running
conduit. If conduit is prepared, lift the unit up to the wall and run wires into the
unit:
through the two backplate conduit holes (if conduit is coming from the wall
behind), or
through the two bottom conduit holes (if conduit is external coming from
below the unit).
8. Using a 3/8 drill bit or ratchet, secure the bolts to affix unit to the wall.
9. Reattach Light Bracket.
10. Reattach the outer shell: Holding the shell perpendicular to the base of the
backplate, hook the bottom hinge into the bottom of the back plate. Swing the
shell up and fasten the safety cable to the eyehook.
11. While the unit shell is propped open on the safety cable, connect electrical
wiring to incoming power supply
12. Push the shell closed and fasten the outer shell to the back plate using two #10
countersunk security screws.
NOTE: In order to comply with the Americans with Disabilities Act (ADA) of
1990, the speakerphone button(s) should be positioned between 34 and 48
inches from grade level. (Consult an ADA specialist in your area to verify local
and federal guidelines.)

Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com page 17 of 43 GU-149-DD
CB 2 Series
Administrator Guide
Suggested installation dimensions shown from ground to lower right mounting hole are
for single button faceplates.
• For dual button faceplate, deduct 3.25 inches.
• For keypad faceplate, deduct 4.5 inches.
• For wheelchair direct facing access only, deduct 6 inches.
42 REF 2 X Ø1-1/8
(KNOCKOUTS FOR
Ø3/4 CONDUIT)
12 REF
6
9
2 9/16
8 5/16 REF
1 1/2 REF
1 1/2
43
30 3/4
4 X Ø7/16 MOUNTING HOLES
GROUND/FLOOR
DISCLAIMER: The dimensions above are intended as guidelines only. For specific installation
requirements, reference your local codes.
All wiring must be installed and connected by experienced and certified personnel to meet local and national
electrical codes, and will include a service disconnect.
CB 2-s Mounting Schematic

Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com page 18 of 43 GU-149-Z1
CB 2 Series
Administrator Guide
CB 2-ap (Audio Paging) Installation Instructions
1. Unscrew security screw from bottom of unit. Lift and open unit.
2. Disconnect wire connections from strobe, faceplate light and phone. Lift up on
black locking tab on each connector to separate.
3. Unscrew the nut from the stud to release safety cable from back plate. Place nut
back on stud.
4. Lift up on front of unit and remove. Set aside.
5. Using back plate of unit as template, level and mark the four mounting holes.
6. Drill all marked holes with appropriate drill bit.
7. If attaching to concrete or brick, insert one 3/8” anchor into each drilled hole.
8. If attaching to wood, 3/8” lag bolt is required.
9. On one 3/8x3” lag bolt, add one 3/8” flat stainless steel washer followed by one
3/8” flat rubber washer.
10. Slide lag bolt through top left mounting hole.
11. Add one 3/8” flat rubber washer, followed by one 3/8” flat stainless steel washer to
end of screw.
12. Drill lag bolt into mounting hole.
13. Repeat previous steps for three remaining mounting holes.
14. Slide front of unit back onto bottom tabs of back plate.
15. Reattach safety cable.
16. Reconnect strobe and phone to power system.
17. Connect incoming power to appropriate tap (high voltage or low voltage).
18. Connect incoming communication line (CAT6) to phone using its WAN port.
19. Close unit.
20. Replace security screw into bottom of unit.

Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com page 19 of 43 GU-149-Z1
CB 2 Series
Administrator Guide
CB 2 with Audio Paging (CB 2-ap) Mounting Schematic
DISCLAIMER: The dimensions above are intended as guidelines only. For specific installation
requirements, reference your local codes.
All wiring must be installed and connected by experienced and certified personnel to meet local and national
electrical codes, and will include a service disconnect.

Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com page 20 of 43 GU-149-Z1
6 Alternative Mounting Options
CB 2 Series
Administrator Guide
Pole Mounting Kit Installation Instructions
THREAD MOUNTING STRAPS THROUGH SLOTS
Thread mounting straps(4) through slots on pole mount bracket(1).
HOLD BRACKET TO POLE
Set the height of the bracket(1) so that the speakerphone push button(s) on the unit will
be at desired height (please check with local codes for ADA compliance).
BAND THE BRACKET TO THE POLE AT DESIRED HEIGHT
To eliminate waste, pull band(4) from carton as needed. With ears of buckle(5) away
from operator, slide the buckle on the banding. Lace banding around the object being
clamped and again through buckle.
Bend end of band under buckle.
Slide band into banding tool nose slot.
When maximum tension has been reached, roll tool over buckle. At same time reversing
handle carefully approximately ¾ turn to avoid breakage. The band that is released will
be used in the bend and therefore there is no loss of tension.
Lift cutter lever and band will be cut to correct length. While holding the stub of the
band with your thumb, hammer flat over bridge of buckle.
Complete application by hammering the buckle ears over the stub.
ATTACH ENCLOSURE TO BRACKET
Align & place the back plate of the unit over the 2 studs located on the bottom of the
pole mount bracket.
First place a rubber washer(2), followed by a steel washer(3) over each stud.
Secure in place with a nylock nut(6).
Place a button head(7) hex drive screw through each top hole in the back plate,
followed by a rubber washer(2) between the back plate and the pole mount bracket(1).
Tighten the button head hex drive screws to secure in place.
Prior to re-attaching the front cover of the unit, apply two pieces of foam(8) to the
back of the strobe light bracket as shown below in order to prevent the unit from
rattling when finished.
IMPORTANT NOTE: Minimum Pole Diameter: 4.0"
7
6
5
4
2
3
2
1
8
8
CB 2 Back Plate
NOTE: Banding tool required. Sold
separately, part #41441.
