Code Blue CB 9 Series Service manual

800.205.7186 •www.codeblue.com
Administrator Guide
Installation | Configuration | Operation | Troubleshooting
CB 9 Series

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-159-Npage 2 of 39
CB 9 Series
Administrator Guide
WARNING
ONLY QUALIFIED PERSONNEL SHOULD INSTALL THESE UNITS. THE INSTALLATION
SHOULD CONFORM TO ALL LOCAL CODES. IN SOME COUNTRIES, A CERTIFIED ELECTRI-
CIAN MAY BE REQUIRED.
NOTICE TO USERS
Copyright © Code Blue Corporation. All rights reserved. This guide or software described herein, in
whole or part, shall not be reproduced, translated or reduced to any machine-readable form without
prior written approval from Code Blue Corporation.
CODE BLUE CORPORATION PROVIDES NO WARRANTY WITH REGARD TO THIS GUIDE, THE
SOFTWARE OR OTHER INFORMATION CONTAINED HEREIN AND HEREBY EXPRESSLY DIS-
CLAIMS ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY PARTICU-
LAR PURPOSE WITH REGARD TO THIS GUIDE, THE SOFTWARE OR SUCH OTHER INFORMA-
TION. IN NO EVENT SHALL CODE BLUE CORPORATION BE LIABLE FOR ANY INCIDENTAL,
CONSEQUENTIAL, OR SPECIAL DAMAGES, WHETHER BASED ON TORT, CONTRACT, OR
OTHERWISE, ARISING OUT OF OR IN CONNECTIONS WITH THIS GUIDE, THE SOFTWARE
OR OTHER INFORMATION CONTAINED HEREIN OR THE USE THEREOF.
Code Blue Corporation reserves the right to make any modications to this guide or the information
contained herein at any time without notice. The software described herein may also be governed
by the terms of a separate user license agreement.
Code Blue®is a registered trademark of Code Blue Corporation.

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-159-Npage 3 of 39
CB 9 Series
Administrator Guide
Table of Contents
(NOTE: Phone programming instructions can be found in the IP5000 and IA4100 Guides.)
Section Page
2 Introduction............................................................................................. 4
3 Getting Started......................................................................................... 5
4 Spare Parts................................................................................................. 6
5 Power Requirements..................................................................................7
6 Legacy Power Requirements...................................................................10
7 Software Conguration............................................................................12
8 CB 9-s Low Voltage Exploded View.........................................................13
9 CB 9-s High Voltage Exploded View........................................................14
10 CB 9-s with Dual Faceplates Low Voltage Exploded View....................15
11 CB 9-s with Dual Faceplates High Voltage Exploded View...................16
12 How to Replace LED Light Connectors..................................................17
13 CB 9 Series Installation Instructions......................................................19
14 CB 9 Series Tower Base Gasket Installation Instructions....................21
15 CB 9 Optional WM-180 Installation Instructions....................................23
16 CB 9 Series Anchor Bolt Installation Instructions.................................26
17 Remote Mount Beacon/Strobe Installation Instructions.......................27
18 PoE Installation Instructions...................................................................28
19 CB 9 Series Deck Mount Installation Instructions.................................29
20 CB 9 Series 24V Standard Wiring (prior to 2015) (with Multi-tap Power Brick)...........30
21 CB 9 Series 24V Standard Wiring (after 2015) (with 24V Fuse Block).................... 31
22 CB 9 Series 120V Standard Wiring (prior to 3/2013) (with Hammond Transformer).....32
23 CB 9 Series 120V Standard Wiring Diagram (after 2015) (with Triad Transformer).33
24 Multi-Tap Transformer Wiring...................................................................34
25 Maintenance Schedule..............................................................................35
26 Locating Unit Serial Numbers.................................................................. 37
27 Warranty......................................................................................................38
28 Download Information...............................................................................39

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-159-Npage 4 of 39
CB 9 Series
Administrator Guide
2 Introduction
Thank you for choosing the CB 9 Series for your Code Blue application.
The CB 9 Series is a versatile freestanding pedestal that is intended for gated entries where cars
and semi-trucks require access and communication. Available in a variety of con gurations, it allows
for the installation of additional safety products, including cameras, card readers or other security
devices. The CB 9 Series can withstand a high rate of abuse and is ideal for parking entry points
and other gatekeeper applications.
The exclusive analog InterAct and VoIP speakerphones are designed for maximum reliability, vandal
resistance, auxiliary functions, mass noti cation control, and fault monitoring and reporting capability
(see IA4100 or IP5000 guides for more information).
Our unmistakable craftsmanship makes our Help Points®the most rugged on the market,
withstanding the punishment of natural and man-made disasters. With durable construction, our
pedestal units can meet any requirement or purpose. CB 9 Series units have a rugged steel
construction, industrial engineering grade re ective graphics and weather, UV and graf ti resistant
paint.
Other options include:
• IP and analog phones
• Low power consumption LED faceplate light
• Car and truck heights
• NightCharge®
• PoE power
• Custom colors and graphics
• Remote Mount LED Beacon/Strobe Kit
This guide contains all of the CB 9 Series information for the CB
9-s and the CB 9-s Dual. This guide contains a general overview of
the CB 9 Series options and its application, installation and wiring.
CB 9-s CB 9-s with
Dual Faceplates

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-159-Npage 5 of 39
CB 9 Series
Administrator Guide
3 Getting Started
Basic Install Instructions
1. EIA/TIA, ANSI, CSA and BICSI cabling or similar standards shall be adhered to for proper
operation of Code Blue communication devices connected to copper or ber infrastructures.
Communications cable and electrical cable in the same conduit is not an acceptable instal-
lation and shall not be supported. Analog phones require a minimum of 23mA for proper
operation (26-29mA recommended).
2. Each analog speakerphone requires its own phone line or PBX extension. Multiple units
shall not be supported.
3. Speakerphones require programming before operation. Consult the User Guide or Admin-
istrator Guide enclosed with the unit or visit www.codeblue.com > Support > Downloads to
read or download manuals.
4. If you are installing IP speakerphones, please read the appropriate manuals and consult
with your Network Administrator.
5. Size electrical wiring based on length of run.
6. Consult the enclosed document packet for internal wiring instructions.
What’s Included
Quantity Part Description
1 Anchor Bolt Kit (4 L-Bolts, 8 Washers, 4 Hex Nuts, 1 Cardboard Template)
1 Security Bit
1 Enclosure
2 Access Door Screws
1 URL listing sheet of Installation, Programming, Wiring & Warranty locations
CB 9 Series Tools Required
1. Ladder to reach the top of the dual units
2. Drill and security bit for removing and inserting security screws on phone, dome top and
access door
3. 11/8 socket set and extension for installing anchor bolts or Deck Mount Kits
4. Phillips head screwdriver and at head screwdriver

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-159-Npage 6 of 39
CB 9 Series
Administrator Guide
4 Spare Parts
CB 9 Series
Part Part Number
LED Faceplate Light 40196
Faceplate Screws 41544 (6pk)
Access Door Screws 41545 (2pk)
Manifold R/B 5-way 40101
Analog Surge Suppressor 41471
IP Surge Suppressor 41421
Blank Lexan Plate Assembly 40067
CB 9 Series Additional Options
Part Part Number
Multi Tap Transformer (powers accessories) 120V, 240V, 277V 40104
Blank Lexan Plate Assembly 40067
Service Plate - Lexan w/graphics (This Location Being Serviced) 40208
Deck Mount Kit 40215
Triad Transformer 40V A 120V (will not power accessories) 41246
S-1000 or S-1050 LED Remote Beacon/Strobe Kit 40542
PoE Power Splitter Kit Assembly 41574
IP5000 Speakerphone FP1 50101
IP5000 Speakerphone FP2 50102
Keypad IP5000 Speakerphone 50103
IA4100 Speakerphone FP1 50001
IA4100 Speakerphone FP2 50002
Keypad IA4100 Speakerphone 50003
IP Color Camera Assembly 41420
Directory Plate Assembly 40057
Custom Cutout Stainless Steel Plates Drawing needed for part#
PAS WM-180 Color Needed for part#

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-159-Npage 7 of 39
CB 9 Series
Administrator Guide
5 Power Requirements (2020)
(The following power requirements include the 9 Series and also ALL OTHER Code Blue units.)
Component Specs
Faceplates Voltage Max Current Max Watts Norm Current Norm Watts KWHrs
High Votage AC Components Voltage Current Watts KWHrs
IA4100 24V AC 0.40 9.60 0.22 5.28 0.13
Multi-Tap Power Supply 120V AC 1.75A/210VAC 210 5.04
12V DC 0.90 10.80 0.39 4.68 0.11
Din Rail Power Supply 120V AC 1.2A/115VAC 115 2.76
24V DC 0.90 21.60 0.39 9.36 0.22
Heater -AED 120V AC 1.6 192 4.61
IP5000 24V AC 0.10 2.40 0.07 1.68 0.04
DC - PS AED 120V AC 2.6 312 7.49
12V DC 0.19 2.28 0.15 1.8 0.04
PAS Amp 120V AC 3.83 459.6 11.03
24V DC 0.19 4.56 0.15 3.6 0.09
Centry®12V DC 0.50 6.00 0.38 4.56 0.11
Lights Voltage Max Current Max Watts Norm Current Norm Watts KWHrs
High Voltage Models Voltage Current Watts KWHrs
S-1000 LED Strobe 24V AC 2.80 67.20 0.22 5.28 0.13
CB 1 AED 120V AC 3.35 402 9.6
12V DC 0.26 3.12 0.24 2.88 0.07
CB 2 AED 120V AC 3.35 402 9.6
24V DC 0.26 6.24 0.24 5.76 0.14
CB 1 PAS 120V AC 3.83 460 11
A-700 Area Light 24 VAC 1.80 43.20 0.83 19.92 0.48
CB 5 PAS 120V AC 3.33 400 9.6
12V DC 2.68 32.16 0.38 4.56 0.11
CB 1-s w/ NightCharge®120V AC 2.5 300 2.4
24V DC 2.68 64.32 0.38 9.12 0.22
CB 4-u w/ NightCharge®120V AC 2.5 300 2.4
S-1050 LED Strobe w/ Photocell 24V AC 2.80 67.20 0.22 5.28 0.13
12V DC 2.68 32.16 0.38 4.56 0.11
24V DC 2.68 64.32 0.38 9.12 0.22
LED Light Bar 24V AC 0.04 0.96 0.04 0.96 0.02
12V DC 0.04 0.48 0.04 0.48 0.01
24V DC 0.04 0.96 0.04 0.96 0.02
WM-180 PAS with LED Strobe 24V AC 7.30 175.20 2.10 50.4 1.21
Common Configurations
Models With IA4100 Faceplate Voltage Current Watts KWHrs Models With IP5000 Faceplate Voltage Current Watts KWHrs
CB 1-e 24V AC 0.48 11.52 0.28 CB 1-e 24V AC 0.33 7.92 0.19
12V DC 0.67 8.04 0.19 12V DC 0.43 5.16 0.12
24V DC 0.67 16.08 0.39 24V DC 0.43 10.32 0.25
CB 1-s 24V AC 1.31 31.44 0.75 CB 1-s 24V AC 1.16 27.84 0.67
12V DC 1.05 12.60 0.30 12V DC 0.81 9.72 0.23
24V DC 1.05 25.20 0.60 24V DC 0.81 19.44 0.47
CB 5-s/5-p 24V AC 0.48 11.52 0.28 CB 5-s/5-p 24V AC 0.33 7.92 0.19
12V DC 0.67 8.04 0.19 12V DC 0.43 5.16 0.12
24V DC 0.67 16.08 0.39 24V DC 0.43 10.32 0.25
CB 9-s 24V AC 0.26 6.24 0.15 CB 9-s 24V AC 0.11 2.64 0.06
12V DC 0.43 5.16 0.12 12V DC 0.19 2.28 0.05
24V DC 0.43 10.32 0.25 24V DC 0.19 4.56 0.11
CB 2-e 24V AC 0.44 10.56 0.25 CB 2-e 24V AC 0.29 6.96 0.17
12V DC 0.63 7.56 0.18 12V DC 0.39 4.68 0.11
24V DC 0.63 15.12 0.36 24V DC 0.39 9.36 0.22
CB 2-a 24V AC 0.48 11.52 0.28 CB 2-a 24V AC 0.33 7.92 0.19
12V DC 0.67 8.04 0.19 12V DC 0.43 5.16 0.12
24V DC 0.67 16.08 0.39 24V DC 0.43 10.32 0.25
CB 2-s 24V AC 1.31 31.44 0.75 CB 2-s 24V AC 1.16 27.84 0.67
12V DC 1.05 12.60 0.30 12V DC 0.81 9.72 0.23
24V DC 1.05 25.20 0.60 24V DC 0.81 19.44 0.47
CB 2-e W/ PAS 24V AC 6.44 154.56 3.71 CB 2-e / PAS 24V AC 6.44 154.56 3.71
CB 4-s 24V AC 0.22 5.28 0.13 CB 4-s 24V AC 0.07 1.68 0.04
12V DC 0.39 4.68 0.11 12V DC 0.15 1.8 0.04
24V DC 0.39 9.36 0.22 24V DC 0.15 3.6 0.09
CB 4-r 24V AC 0.26 6.24 0.15 CB 4-r 24V AC 0.11 2.64 0.06
12V DC 0.43 5.16 0.12 12V DC 0.19 2.28 0.05
24V DC 0.43 10.32 0.25 24V DC 0.19 4.56 0.11
CB 4-u 24V AC 0.26 6.24 0.15 CB 4-u 24V AC 0.11 2.64 0.06
12V DC 0.43 5.16 0.12 12V DC 0.19 2.28 0.05
24V DC 0.43 10.32 0.25 24V DC 0.19 4.56 0.11
Surface Mount/Flush Mount 24V AC 0.22 5.28 0.13 Surface Mount/Flush Mount 24V AC 0.07 1.68 0.04
12V DC 0.39 4.68 0.11 12V DC 0.15 1.8 0.04
24V DC 0.39 9.36 0.22 24V DC 0.15 3.6 0.09
CB RT 24V AC 1.10 26.33 0.63 CB RT 24V AC 1.21 28.96 0.70
12V DC 0.81 9.75 0.23 12V DC 1.03 12.37 0.30
24V DC 1.61 38.57 0.93 24V DC 1.13 27.10 0.65
Component Specs
Faceplates Voltage Max Current Max Watts Norm Current Norm Watts KWHrs
High Votage AC Components Voltage Current Watts KWHrs
IA4100 24V AC 0.40 9.60 0.22 5.28 0.13
Multi-Tap Power Supply 120V AC 1.75A/210VAC 210 5.04
12V DC 0.90 10.80 0.39 4.68 0.11
Din Rail Power Supply 120V AC 1.2A/115VAC 115 2.76
24V DC 0.90 21.60 0.39 9.36 0.22
Heater -AED 120V AC 1.6 192 4.61
IP5000 24V AC 0.10 2.40 0.07 1.68 0.04
DC - PS AED 120V AC 2.6 312 7.49
12V DC 0.19 2.28 0.15 1.8 0.04
PAS Amp 120V AC 3.83 459.6 11.03
24V DC 0.19 4.56 0.15 3.6 0.09
Centry®12V DC 0.50 6.00 0.38 4.56 0.11
Lights Voltage Max Current Max Watts Norm Current Norm Watts KWHrs
High Voltage Models Voltage Current Watts KWHrs
S-1000 LED Strobe 24V AC 2.80 67.20 0.22 5.28 0.13
CB 1 AED 120V AC 3.35 402 9.6
12V DC 0.26 3.12 0.24 2.88 0.07
CB 2 AED 120V AC 3.35 402 9.6
24V DC 0.26 6.24 0.24 5.76 0.14
CB 1 PAS 120V AC 3.83 460 11
A-700 Area Light 24 VAC 1.80 43.20 0.83 19.92 0.48
CB 5 PAS 120V AC 3.33 400 9.6
12V DC 2.68 32.16 0.38 4.56 0.11
CB 1-s w/ NightCharge®120V AC 2.5 300 2.4
24V DC 2.68 64.32 0.38 9.12 0.22
CB 4-u w/ NightCharge®120V AC 2.5 300 2.4
S-1050 LED Strobe w/ Photocell 24V AC 2.80 67.20 0.22 5.28 0.13
12V DC 2.68 32.16 0.38 4.56 0.11
24V DC 2.68 64.32 0.38 9.12 0.22
LED Light Bar 24V AC 0.04 0.96 0.04 0.96 0.02
12V DC 0.04 0.48 0.04 0.48 0.01
24V DC 0.04 0.96 0.04 0.96 0.02
WM-180 PAS with LED Strobe 24V AC 7.30 175.20 2.10 50.4 1.21
Common Configurations
Models With IA4100 Faceplate Voltage Current Watts KWHrs Models With IP5000 Faceplate Voltage Current Watts KWHrs
CB 1-e 24V AC 0.48 11.52 0.28 CB 1-e 24V AC 0.33 7.92 0.19
12V DC 0.67 8.04 0.19 12V DC 0.43 5.16 0.12
24V DC 0.67 16.08 0.39 24V DC 0.43 10.32 0.25
CB 1-s 24V AC 1.31 31.44 0.75 CB 1-s 24V AC 1.16 27.84 0.67
12V DC 1.05 12.60 0.30 12V DC 0.81 9.72 0.23
24V DC 1.05 25.20 0.60 24V DC 0.81 19.44 0.47
CB 5-s/5-p 24V AC 0.48 11.52 0.28 CB 5-s/5-p 24V AC 0.33 7.92 0.19
12V DC 0.67 8.04 0.19 12V DC 0.43 5.16 0.12
24V DC 0.67 16.08 0.39 24V DC 0.43 10.32 0.25
CB 9-s 24V AC 0.26 6.24 0.15 CB 9-s 24V AC 0.11 2.64 0.06
12V DC 0.43 5.16 0.12 12V DC 0.19 2.28 0.05
24V DC 0.43 10.32 0.25 24V DC 0.19 4.56 0.11
CB 2-e 24V AC 0.44 10.56 0.25 CB 2-e 24V AC 0.29 6.96 0.17
12V DC 0.63 7.56 0.18 12V DC 0.39 4.68 0.11
24V DC 0.63 15.12 0.36 24V DC 0.39 9.36 0.22
CB 2-a 24V AC 0.48 11.52 0.28 CB 2-a 24V AC 0.33 7.92 0.19
12V DC 0.67 8.04 0.19 12V DC 0.43 5.16 0.12
24V DC 0.67 16.08 0.39 24V DC 0.43 10.32 0.25
CB 2-s 24V AC 1.31 31.44 0.75 CB 2-s 24V AC 1.16 27.84 0.67
12V DC 1.05 12.60 0.30 12V DC 0.81 9.72 0.23
24V DC 1.05 25.20 0.60 24V DC 0.81 19.44 0.47
CB 2-e W/ PAS 24V AC 6.44 154.56 3.71 CB 2-e / PAS 24V AC 6.44 154.56 3.71
CB 4-s 24V AC 0.22 5.28 0.13 CB 4-s 24V AC 0.07 1.68 0.04
12V DC 0.39 4.68 0.11 12V DC 0.15 1.8 0.04
24V DC 0.39 9.36 0.22 24V DC 0.15 3.6 0.09
CB 4-r 24V AC 0.26 6.24 0.15 CB 4-r 24V AC 0.11 2.64 0.06
12V DC 0.43 5.16 0.12 12V DC 0.19 2.28 0.05
24V DC 0.43 10.32 0.25 24V DC 0.19 4.56 0.11
CB 4-u 24V AC 0.26 6.24 0.15 CB 4-u 24V AC 0.11 2.64 0.06
12V DC 0.43 5.16 0.12 12V DC 0.19 2.28 0.05
24V DC 0.43 10.32 0.25 24V DC 0.19 4.56 0.11
Surface Mount/Flush Mount 24V AC 0.22 5.28 0.13 Surface Mount/Flush Mount 24V AC 0.07 1.68 0.04
12V DC 0.39 4.68 0.11 12V DC 0.15 1.8 0.04
24V DC 0.39 9.36 0.22 24V DC 0.15 3.6 0.09
CB RT 24V AC 1.10 26.33 0.63 CB RT 24V AC 1.21 28.96 0.70
12V DC 0.81 9.75 0.23 12V DC 1.03 12.37 0.30
24V DC 1.61 38.57 0.93 24V DC 1.13 27.10 0.65

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-159-Npage 8 of 39
CB 9 Series
Administrator Guide
Power Requirements continued
Component Specs
Faceplates Voltage Max Current Max Watts Norm Current Norm Watts KWHrs High Votage AC Components Voltage Current Watts KWHrs
IA4100 24V AC 0.40 9.60 0.22 5.28 0.13 Multi-Tap Power Supply 120V AC 1.75A/210VAC 210 5.04
12V DC 0.90 10.80 0.39 4.68 0.11 Din Rail Power Supply 120V AC 1.2A/115VAC 115 2.76
24V DC 0.90 21.60 0.39 9.36 0.22 Heater -AED 120V AC 1.6 192 4.61
IP5000 24V AC 0.10 2.40 0.07 1.68 0.04 DC - PS AED 120V AC 2.6 312 7.49
12V DC 0.19 2.28 0.15 1.8 0.04 PAS Amp 120V AC 3.83 459.6 11.03
24V DC 0.19 4.56 0.15 3.6 0.09
Centry®12V DC 0.50 6.00 0.38 4.56 0.11
Lights Voltage Max Current Max Watts Norm Current Norm Watts KWHrs High Voltage Models Voltage Current Watts KWHrs
S-1000 LED Strobe 24V AC 2.80 67.20 0.22 5.28 0.13 CB 1 AED 120V AC 3.35 402 9.6
12V DC 0.26 3.12 0.24 2.88 0.07 CB 2 AED 120V AC 3.35 402 9.6
24V DC 0.26 6.24 0.24 5.76 0.14 CB 1 PAS 120V AC 3.83 460 11
A-700 Area Light 24 VAC 1.80 43.20 0.83 19.92 0.48 CB 5 PAS 120V AC 3.33 400 9.6
12V DC 2.68 32.16 0.38 4.56 0.11
CB 1-s w/ NightCharge®120V AC 2.5 300 2.4
24V DC 2.68 64.32 0.38 9.12 0.22
CB 4-u w/ NightCharge®120V AC 2.5 300 2.4
S-1050 LED Strobe w/ Photocell 24V AC 2.80 67.20 0.22 5.28 0.13
12V DC 2.68 32.16 0.38 4.56 0.11
24V DC 2.68 64.32 0.38 9.12 0.22
LED Light Bar 24V AC 0.04 0.96 0.04 0.96 0.02
12V DC 0.04 0.48 0.04 0.48 0.01
24V DC 0.04 0.96 0.04 0.96 0.02
WM-180 PAS with LED Strobe 24V AC 7.30 175.20 2.10 50.4 1.21
Common Configurations
Models With IA4100 Faceplate Voltage Current Watts KWHrs
Models With IP5000 Faceplate Voltage Current Watts KWHrs
CB 1-e 24V AC 0.48 11.52 0.28
CB 1-e 24V AC 0.33 7.92 0.19
12V DC 0.67 8.04 0.19
12V DC 0.43 5.16 0.12
24V DC 0.67 16.08 0.39
24V DC 0.43 10.32 0.25
CB 1-s 24V AC 1.31 31.44 0.75
CB 1-s 24V AC 1.16 27.84 0.67
12V DC 1.05 12.60 0.30
12V DC 0.81 9.72 0.23
24V DC 1.05 25.20 0.60
24V DC 0.81 19.44 0.47
CB 5-s/5-p 24V AC 0.48 11.52 0.28
CB 5-s/5-p 24V AC 0.33 7.92 0.19
12V DC 0.67 8.04 0.19
12V DC 0.43 5.16 0.12
24V DC 0.67 16.08 0.39
24V DC 0.43 10.32 0.25
CB 9-s 24V AC 0.26 6.24 0.15
CB 9-s 24V AC 0.11 2.64 0.06
12V DC 0.43 5.16 0.12
12V DC 0.19 2.28 0.05
24V DC 0.43 10.32 0.25
24V DC 0.19 4.56 0.11
CB 2-e 24V AC 0.44 10.56 0.25
CB 2-e 24V AC 0.29 6.96 0.17
12V DC 0.63 7.56 0.18
12V DC 0.39 4.68 0.11
24V DC 0.63 15.12 0.36
24V DC 0.39 9.36 0.22
CB 2-a 24V AC 0.48 11.52 0.28
CB 2-a 24V AC 0.33 7.92 0.19
12V DC 0.67 8.04 0.19
12V DC 0.43 5.16 0.12
24V DC 0.67 16.08 0.39
24V DC 0.43 10.32 0.25
CB 2-s 24V AC 1.31 31.44 0.75
CB 2-s 24V AC 1.16 27.84 0.67
12V DC 1.05 12.60 0.30
12V DC 0.81 9.72 0.23
24V DC 1.05 25.20 0.60
24V DC 0.81 19.44 0.47
CB 2-e W/ PAS 24V AC 6.44 154.56 3.71
CB 2-e / PAS 24V AC 6.44 154.56 3.71
CB 4-s 24V AC 0.22 5.28 0.13
CB 4-s 24V AC 0.07 1.68 0.04
12V DC 0.39 4.68 0.11
12V DC 0.15 1.8 0.04
24V DC 0.39 9.36 0.22
24V DC 0.15 3.6 0.09
CB 4-r 24V AC 0.26 6.24 0.15
CB 4-r 24V AC 0.11 2.64 0.06
12V DC 0.43 5.16 0.12
12V DC 0.19 2.28 0.05
24V DC 0.43 10.32 0.25
24V DC 0.19 4.56 0.11
CB 4-u 24V AC 0.26 6.24 0.15
CB 4-u 24V AC 0.11 2.64 0.06
12V DC 0.43 5.16 0.12
12V DC 0.19 2.28 0.05
24V DC 0.43 10.32 0.25
24V DC 0.19 4.56 0.11
Surface Mount/Flush Mount 24V AC 0.22 5.28 0.13
Surface Mount/Flush Mount 24V AC 0.07 1.68 0.04
12V DC 0.39 4.68 0.11
12V DC 0.15 1.8 0.04
24V DC 0.39 9.36 0.22
24V DC 0.15 3.6 0.09
CB RT 24V AC 1.10 26.33 0.63
CB RT 24V AC 1.21 28.96 0.70
12V DC 0.81 9.75 0.23
12V DC 1.03 12.37 0.30
24V DC 1.61 38.57 0.93
24V DC 1.13 27.10 0.65

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-159-Npage 9 of 39
CB 9 Series
Administrator Guide
Power Requirements continued
Component Specs
Faceplates Voltage Max Current Max Watts Norm Current Norm Watts KWHrs High Votage AC Components Voltage Current Watts KWHrs
IA4100 24V AC 0.40 9.60 0.22 5.28 0.13 Multi-Tap Power Supply 120V AC 1.75A/210VAC 210 5.04
12V DC 0.90 10.80 0.39 4.68 0.11 Din Rail Power Supply 120V AC 1.2A/115VAC 115 2.76
24V DC 0.90 21.60 0.39 9.36 0.22 Heater -AED 120V AC 1.6 192 4.61
IP5000 24V AC 0.10 2.40 0.07 1.68 0.04 DC - PS AED 120V AC 2.6 312 7.49
12V DC 0.19 2.28 0.15 1.8 0.04 PAS Amp 120V AC 3.83 459.6 11.03
24V DC 0.19 4.56 0.15 3.6 0.09
Centry®12V DC 0.50 6.00 0.38 4.56 0.11
Lights Voltage Max Current Max Watts Norm Current Norm Watts KWHrs High Voltage Models Voltage Current Watts KWHrs
S-1000 LED Strobe 24V AC 2.80 67.20 0.22 5.28 0.13 CB 1 AED 120V AC 3.35 402 9.6
12V DC 0.26 3.12 0.24 2.88 0.07 CB 2 AED 120V AC 3.35 402 9.6
24V DC 0.26 6.24 0.24 5.76 0.14 CB 1 PAS 120V AC 3.83 460 11
A-700 Area Light 24 VAC 1.80 43.20 0.83 19.92 0.48 CB 5 PAS 120V AC 3.33 400 9.6
12V DC 2.68 32.16 0.38 4.56 0.11
CB 1-s w/ NightCharge®120V AC 2.5 300 2.4
24V DC 2.68 64.32 0.38 9.12 0.22
CB 4-u w/ NightCharge®120V AC 2.5 300 2.4
S-1050 LED Strobe w/ Photocell 24V AC 2.80 67.20 0.22 5.28 0.13
12V DC 2.68 32.16 0.38 4.56 0.11
24V DC 2.68 64.32 0.38 9.12 0.22
LED Light Bar 24V AC 0.04 0.96 0.04 0.96 0.02
12V DC 0.04 0.48 0.04 0.48 0.01
24V DC 0.04 0.96 0.04 0.96 0.02
WM-180 PAS with LED Strobe 24V AC 7.30 175.20 2.10 50.4 1.21
Common Configurations
Models With IA4100 Faceplate Voltage Current Watts KWHrs
Models With IP5000 Faceplate Voltage Current Watts KWHrs
CB 1-e 24V AC 0.48 11.52 0.28
CB 1-e 24V AC 0.33 7.92 0.19
12V DC 0.67 8.04 0.19
12V DC 0.43 5.16 0.12
24V DC 0.67 16.08 0.39
24V DC 0.43 10.32 0.25
CB 1-s 24V AC 1.31 31.44 0.75
CB 1-s 24V AC 1.16 27.84 0.67
12V DC 1.05 12.60 0.30
12V DC 0.81 9.72 0.23
24V DC 1.05 25.20 0.60
24V DC 0.81 19.44 0.47
CB 5-s/5-p 24V AC 0.48 11.52 0.28
CB 5-s/5-p 24V AC 0.33 7.92 0.19
12V DC 0.67 8.04 0.19
12V DC 0.43 5.16 0.12
24V DC 0.67 16.08 0.39
24V DC 0.43 10.32 0.25
CB 9-s 24V AC 0.26 6.24 0.15
CB 9-s 24V AC 0.11 2.64 0.06
12V DC 0.43 5.16 0.12
12V DC 0.19 2.28 0.05
24V DC 0.43 10.32 0.25
24V DC 0.19 4.56 0.11
CB 2-e 24V AC 0.44 10.56 0.25
CB 2-e 24V AC 0.29 6.96 0.17
12V DC 0.63 7.56 0.18
12V DC 0.39 4.68 0.11
24V DC 0.63 15.12 0.36
24V DC 0.39 9.36 0.22
CB 2-a 24V AC 0.48 11.52 0.28
CB 2-a 24V AC 0.33 7.92 0.19
12V DC 0.67 8.04 0.19
12V DC 0.43 5.16 0.12
24V DC 0.67 16.08 0.39
24V DC 0.43 10.32 0.25
CB 2-s 24V AC 1.31 31.44 0.75
CB 2-s 24V AC 1.16 27.84 0.67
12V DC 1.05 12.60 0.30
12V DC 0.81 9.72 0.23
24V DC 1.05 25.20 0.60
24V DC 0.81 19.44 0.47
CB 2-e W/ PAS 24V AC 6.44 154.56 3.71
CB 2-e / PAS 24V AC 6.44 154.56 3.71
CB 4-s 24V AC 0.22 5.28 0.13
CB 4-s 24V AC 0.07 1.68 0.04
12V DC 0.39 4.68 0.11
12V DC 0.15 1.8 0.04
24V DC 0.39 9.36 0.22
24V DC 0.15 3.6 0.09
CB 4-r 24V AC 0.26 6.24 0.15
CB 4-r 24V AC 0.11 2.64 0.06
12V DC 0.43 5.16 0.12
12V DC 0.19 2.28 0.05
24V DC 0.43 10.32 0.25
24V DC 0.19 4.56 0.11
CB 4-u 24V AC 0.26 6.24 0.15
CB 4-u 24V AC 0.11 2.64 0.06
12V DC 0.43 5.16 0.12
12V DC 0.19 2.28 0.05
24V DC 0.43 10.32 0.25
24V DC 0.19 4.56 0.11
Surface Mount/Flush Mount 24V AC 0.22 5.28 0.13
Surface Mount/Flush Mount 24V AC 0.07 1.68 0.04
12V DC 0.39 4.68 0.11
12V DC 0.15 1.8 0.04
24V DC 0.39 9.36 0.22
24V DC 0.15 3.6 0.09
CB RT 24V AC 1.10 26.33 0.63
CB RT 24V AC 1.21 28.96 0.70
12V DC 0.81 9.75 0.23
12V DC 1.03 12.37 0.30
24V DC 1.61 38.57 0.93
24V DC 1.13 27.10 0.65

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-159-Npage 10 of 39
CB 9 Series
Administrator Guide
6 Legacy Power Requirements
(The following power requirements include the 9 Series and also ALL OTHER Code Blue units.)

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-159-Npage 11 of 39
CB 9 Series
Administrator Guide

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-159-Npage 12 of 39
CB 9 Series
Administrator Guide
7 Software Configuration
Blue Alert® MNS Software
Blue Alert MNS (Mass Notication Software) lls a need in the marketplace for an incident response
solution that is both comprehensive and cost-effective, while also providing an efcient way to detect
and respond. The advanced mass notication system allows responders to deliver multi-layered
emergency notications via a wide range of platforms, including email, text message (SMS), emer-
gency phones, public address speakers, social media, desktop alerts and more, quickly informing
and directing people in emergency situations.
Blue Alert® EMS
Blue Alert EMS is an advanced software solution that handles all incoming events effectively by re-
motely controlling emergency communication devices with an easy-to-use Graphical User Interface
(GUI). You also will have the ability to open gates and AED access doors, turn LED beacon/strobes
on or off, transfer calls to Public Address Systems to make area wide announcements and incor-
porate other ancillary devices and applications while the system securely archives data for future
reference.
ToolVox®
A sophisticated emergency management platform for your blue light phone network, ToolVox offers
unique real-time monitoring and provisioning options for emergency phones and public address
speakers, effectively acting as a hub for connecting Help Points®and other Code Blue devices. Us-
ing our proprietary incident response software, Blue Alert®MNS and EMS, you can send alerts via
outdoor platforms, such as blue light phones and public address speakers. It also provides connec-
tions to PBX, public telephone (PSTN) and Internet (ISP) networks, in addition to third party security
platforms.

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-159-Npage 13 of 39
CB 9 Series
Administrator Guide
8 CB 9-s Low Voltage Exploded View
DISCLAIMER: Product design and component use subject to change without notice. Product shown reasonably represents current offering and
is intended to assist in component identi cation. Reference the model and serial number from the unit ID tag and contact manufacturer to con rm
replacement part version and availability.
BALL # PART # DESCRIPTION
1 CALL Standard / Custom Graphic
2 41471 Analog Surge Suppressor
2 41421 IP Surge Suppressor
3 41700 24V Fuse Block
4 41545 Access Door Screws (2 pk)
5 41548 LED Faceplate Light
6 50001 Single Button IA4100 Analog Phone – PUSH FOR HELP
6 50002 Double Button IA4100 Analog Phone – PUSH FOR HELP
6 50003 Keypad IA4100 Analog Phone – PUSH FOR HELP
6 50004 Single Button IA4100 Analog Phone – EMERGENCY
6 50005 Double Button IA4100 Analog Phone – EMERGENCY
6 50006 Keypad IA4100 Analog Phone – EMERGENCY
BALL # PART # DESCRIPTION
6 50101 Single Button IP5000 VoIP Phone – PUSH FOR HELP
6 50102 Double Button IP5000 VoIP Phone – PUSH FOR HELP
6 50103 Keypad IP5000 VoIP Phone – PUSH FOR HELP
6 50104 Single Button IP5000 VoIP Phone – EMERGENCY
6 50105 Double Button IP5000 VoIP Phone – EMERGENCY
6 50106 Keypad IP5000 VoIP Phone – EMERGENCY
7 41544 Faceplate Security Screw 10x24 (6 pk)
8 40357 Bezel Assembly IA4100 Analog Phone – PUSH FOR HELP
8 40407 Bezel Assembly IA4100 Analog Phone – EMERGENCY
8 40313 Bezel Assembly IP5000 VoIP Phone – PUSH FOR HELP
8 40405 Bezel Assembly IP5000 VoIP Phone – EMERGENCY
1
2
4
3
6
5
7
8

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-159-Npage 14 of 39
CB 9 Series
Administrator Guide
3
6
5
7
8
2
4
1
3
9 CB 9-s High Voltage Exploded View
DISCLAIMER: Product design and component use subject to change without notice. Product shown reasonably represents current offering and
is intended to assist in component identication. Reference the model and serial number from the unit ID tag and contact manufacturer to conrm
replacement part version and availability.
BALL # PART # DESCRIPTION
1 CALL Standard Graphic
1 CALL Custom Graphic
2 41471 Analog Surge Suppressor
2 41421 IP Surge Suppressor
3 40104 Power Brick 120V, 240V, 277V, 347V Option
3 45003 NightCharge®Option
4 41545 Access Door Screws (2 pk)
5 41548 LED Faceplate Light
6 50001 Single Button IA4100 Analog Phone – PUSH FOR HELP
6 50002 Double Button IA4100 Analog Phone – PUSH FOR HELP
6 50003 Keypad IA4100 Analog Phone – PUSH FOR HELP
6 50004 Single Button IA4100 Analog Phone – EMERGENCY
6 50005 Double Button IA4100 Analog Phone – EMERGENCY
6 50006 Keypad IA4100 Analog Phone – EMERGENCY
BALL # PART # DESCRIPTION
6 50101 Single Button IP5000 VoIP Phone – PUSH FOR HELP
6 50102 Double Button IP5000 VoIP Phone – PUSH FOR HELP
6 50103 Keypad IP5000 VoIP Phone – PUSH FOR HELP
6 50104 Single Button IP5000 VoIP Phone – EMERGENCY
6 50105 Double Button IP5000 VoIP Phone – EMERGENCY
6 50106 Keypad IP5000 VoIP Phone – EMERGENCY
7 41544 Faceplate Security Screw 10x24 (6 pk)
8 40357 Bezel Assembly IA4100 Analog Phone – PUSH FOR HELP
8 40407 Bezel Assembly IA4100 Analog Phone – EMERGENCY
8 40313 Bezel Assembly IP5000 VoIP Phone – PUSH FOR HELP
8 40405 Bezel Assembly IP5000 VoIP Phone – EMERGENCY

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-159-Npage 15 of 39
CB 9 Series
Administrator Guide
DISCLAIMER: Product design and component use subject to change without notice. Product shown reasonably represents current offering and
is intended to assist in component identi cation. Reference the model and serial number from the unit ID tag and contact manufacturer to con rm
replacement part version and availability.
BALL # PART # DESCRIPTION
1 CALL Standard / Custom Graphic
2 41471 Analog Surge Suppressor
2 41421 IP Surge Suppressor
3 41700 24V Fuse Block
4 41545 Access Door Screws (2 pk)
5 41548 LED Faceplate Light
6 50001 Single Button IA4100 Analog Phone – PUSH FOR HELP
6 50002 Double Button IA4100 Analog Phone – PUSH FOR HELP
6 50003 Keypad IA4100 Analog Phone – PUSH FOR HELP
6 50004 Single Button IA4100 Analog Phone – EMERGENCY
6 50005 Double Button IA4100 Analog Phone – EMERGENCY
6 50006 Keypad IA4100 Analog Phone – EMERGENCY
6 50101 Single Button IP5000 VoIP Phone – PUSH FOR HELP
6 50102 Double Button IP5000 VoIP Phone – PUSH FOR HELP
6 50103 Keypad IP5000 VoIP Phone – PUSH FOR HELP
BALL # PART # DESCRIPTION
6 50104 Single Button IP5000 VoIP Phone – EMERGENCY
6 50105 Double Button IP5000 VoIP Phone – EMERGENCY
6 50106 Keypad IP5000 VoIP Phone – EMERGENCY
7 41544 Faceplate Security Screw 10x24 (6 pk)
8 40357 Bezel Assembly IA4100 Analog Phone – PUSH FOR HELP
8 40407 Bezel Assembly IA4100 Analog Phone – EMERGENCY
8 40313 Bezel Assembly IP5000 VoIP Phone – PUSH FOR HELP
8 40405 Bezel Assembly IP5000 VoIP Phone – EMERGENCY
9 40066 Blank Plate Assembly
9 40067 Directory Assembly
9 40130 Color Camera Assembly
9 40131 Card Reader Assembly
9 40157 Color Camera and Card Reader Assembly
1
2
4
3
6
7
8
5
9
10 CB 9-s with Dual Faceplates Low Voltage Exploded View

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-159-Npage 16 of 39
CB 9 Series
Administrator Guide
DISCLAIMER: Product design and component use subject to change without notice. Product shown reasonably represents current offering and
is intended to assist in component identication. Reference the model and serial number from the unit ID tag and contact manufacturer to conrm
replacement part version and availability.
BALL # PART # DESCRIPTION
1 CALL Standard / Custom Graphic
2 41471 Analog Surge Suppressor
2 41421 IP Surge Suppressor
3 40104 Power Brick 120V, 240V, 277V, 347V Option
3 45003 NightCharge®Option
4 41545 Access Door Screws (2 pk)
5 41548 LED Faceplate Light
6 50001 Single Button IA4100 Analog Phone – PUSH FOR HELP
6 50002 Double Button IA4100 Analog Phone – PUSH FOR HELP
6 50003 Keypad IA4100 Analog Phone – PUSH FOR HELP
6 50004 Single Button IA4100 Analog Phone – EMERGENCY
6 50005 Double Button IA4100 Analog Phone – EMERGENCY
6 50006 Keypad IA4100 Analog Phone – EMERGENCY
6 50101 Single Button IP5000 VoIP Phone – PUSH FOR HELP
6 50102 Double Button IP5000 VoIP Phone – PUSH FOR HELP
6 50103 Keypad IP5000 VoIP Phone – PUSH FOR HELP
BALL # PART # DESCRIPTION
6 50104 Single Button IP5000 VoIP Phone – EMERGENCY
6 50105 Double Button IP5000 VoIP Phone – EMERGENCY
6 50106 Keypad IP5000 VoIP Phone – EMERGENCY
7 41544 Faceplate Security Screw 10x24 (6 pk)
8 40357 Bezel Assembly IA4100 Analog Phone – PUSH FOR HELP
8 40407 Bezel Assembly IA4100 Analog Phone – EMERGENCY
8 40313 Bezel Assembly IP5000 VoIP Phone – PUSH FOR HELP
8 40405 Bezel Assembly IP5000 VoIP Phone – EMERGENCY
9 40066 Blank Plate Assembly
9 40067 Directory Assembly
9 40130 Color Camera Assembly
9 40131 Card Reader Assembly
9 40157 Color Camera and Card Reader Assembly
3
6
7
8
5
2
4
1
9
3
11 CB 9-s with Dual Faceplates High Voltage Exploded View

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-159-Npage 17 of 39
CB 9 Series
Administrator Guide
12 How to Replace LED Light Connectors
As of 2020, Code Blue strobe, area and faceplate lights come with Wago connectors. These con-
nectors provide ease of use and a much stronger connection. Below are the steps needed to
change to the new connectors. Each new LED light should come with both the plug-and-socket
Wago connectors.
Example:
Cut off both wires.
Wago socket
connectors to
add to your wires.

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-159-Npage 18 of 39
CB 9 Series
Administrator Guide
Strip all wires and twist tight.
Place small screwdriver into square hole and push down. Insert cut wire into
round hole and remove screwdriver. Repeat on the rest of the connectors.
Once all connectors have been switched, you are ready to apply power to the
LED.
This will work on strobe, area and faceplate lights.
Please contact [email protected] if you need further assistance.

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-159-Npage 19 of 39
CB 9 Series
Administrator Guide
13 CB 9 Series Installation Instructions
1.0 FOUNDATION – (see Anchor Bolt Installation Instructions)
2.0 SET THE UNIT
2.1 Screw one set of nuts and washers onto the anchor bolts – After the foundation has
set, screw one set of nuts followed by one set of washers onto the anchor bolts. Set the
nuts such that the lowest washer is about 2½ inches above the concrete and at an even
height. To accomplish this, use a small level and check all three directions. These nuts
are not adjustable after the unit is in place. The bottom edge of the Code Blue unit will be
½-inch above the concrete when installed.
IMPORTANT: The leveling of the bottom nuts is crucial to the leveling of the unit. A small
error in the adjustment of these will be magnied after installation.
IMPORTANT: A ½-inch air gap is required between the foundation and the unit. Moisture
problems may result if this condition is not complied with.
2.2 Set the unit on the anchor bolts – Align the phone plate in the desired direction and lift
the Code Blue unit over the anchor bolts. Note that the unit weighs 190-420 pounds. Use
appropriate lifting materials and methods to avoid possible injury and/or damage.
2.3 Secure the unit – Access the mounting studs through the door on the side of the unit.
Place the second washer and nut and then tighten the mounting nuts onto the anchor
bolts. This may be more convenient if a long socket, extension and universal joint is used
to tighten the hardware.
3.0 WIRING
3.1 Ground – The ground (green) wire should be stripped and fastened to the supplied ground-
ing lug.
3.2 24V AC supply – Run power directly into the 5 nger manifold
3.3 120/240V AC supply – Connect the labeled Molex connectors inside the unit to the cor-
responding Molex connectors on the Power Brick.
See diagrams next page
All wiring must be installed and connected by experienced and certied personnel to meet
local and national electrical codes, and will include a service disconnect.

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-159-Npage 20 of 39
CB 9 Series
Administrator Guide
Figure 1
All wiring must be installed and connected by experienced and certied personnel to meet
local and national electrical codes, and will include a service disconnect.
