Code Blue CB RT Series Manual

CB RT Series
800.205.7186 • www.codeblue.com
Model: ENTM01
Admin Guide
Installation | Configuration | Support | Maintenance | Use

page 2 of 25
GU-163-D
CB RT Series
Administrator Guide
WARNING
ONLY QUALIFIED PERSONNEL SHOULD INSTALL THESE UNITS. THE INSTALLATION
SHOULD CONFORM TO ALL LOCAL CODES. IN SOME COUNTRIES, A CERTIFIED
ELECTRICIAN MAY BE REQUIRED.
NOTICE TO USERS
Copyright © Code Blue Corporation. All rights reserved. This guide or software
described herein, in whole or part, shall not be reproduced, translated or reduced to any
machine-readable form without prior written approval from Code Blue Corporation.
CODE BLUE CORPORATION PROVIDES NO WARRANTY WITH REGARD TO THIS
GUIDE, THE SOFTWARE OR OTHER INFORMATION CONTAINED HEREIN AND HEREBY
EXPRESSLY DISCLAIMS ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR ANY PARTICULAR PURPOSE WITH REGARD TO THIS GUIDE, THE
SOFTWARE OR SUCH OTHER INFORMATION. IN NO EVENT SHALL CODE BLUE
CORPORATION BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, OR SPECIAL
DAMAGES, WHETHER BASED ON TORT, CONTRACT, OR OTHERWISE, ARISING OUT
OF OR IN CONNECTIONS WITH THIS GUIDE, THE SOFTWARE OR OTHER
INFORMATION CONTAINED HEREIN OR THE USE THEREOF.
Code Blue Corporation reserves the right to make any modifications to this guide or the
information contained herein at any time without notice. The software described herein
may also be governed by the terms of a separate user license agreement.
Code Blue® is a registered trademark of Code Blue Corporation. The names of actual
companies and products mentioned herein may be the trademarks of their respective
owners.
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com

Section
Section Title
Page #
2
Introduction
4
CB RT Model Photo
4
3
Dimensions
5
3
Safety Information
6
4
Installation Instructions
7
Getting Started
7
Tools Needed
7
CBRT Installation Instructions
8
Anchor Bolt Installation
8
Set the Unit
9
Install Combination Beacon/Strobe
9
Incoming Power Wiring
9
Overhead Camera Mount Installation
10
Line Power Installation
11
S-1000 & S-1050 Strobe Operation
12
S-1000 & S-1050 Strobe Programming
13
5
Power Requirements
14
6
Wiring Diagrams
18
CB RT 24-277V AC DIN Rail Power System
18
CB RT PoE DIN Rail Power System
19
7
Locating Unit Serial Numbers
20
8
Maintenance Schedule
21
9
Warranty
23
10
Download Information
24
11
Legal & Regulatory Information
25
page 3 of 25
Table of Contents
GU-163-D
CB RT Series
Administrator Guide
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com

page 4 of 25
This guide contains all of the CB RT tower information. This
manual contains a general overview of the Code Blue CB RT
Tower options and its application, installation and wiring.
IP and analog phones
Overhead Camera Mount
Thank you for choosing the CB RT for your Code Blue application.
The CB RT is an economical pedestal Help Point® highlighted by a high intensity LED
beacon/strobe light that provides exceptional visibility and acts as a deterrent to
potential crime. This blue light emergency tower provides direct communication with first
responders and can extend security efforts to walkways, parking lots, open campus areas
and more.
CB RT towers are easily recognized throughout a full 360-degree area. The user
friendly lighted faceplate and the integral LED combo strobe ensures rapid location in
an open environment and easily identifiable by security when activated.
The exclusive analog InterAct and VoIP speakerphones are designed for maximum
reliability, vandal resistance, auxiliary functions, mass notification control, and fault
monitoring and reporting capability. (See IA4100 or LS1000 guides for more informat
guides for more information.)
Our unmistakable craftsmanship makes our Help Points® the most rugged on the market,
withstanding the punishment of natural and man-made disasters. With durable
construction, our pedestal units can meet any requirement or purpose. CB RT tower units
have a rugged steel construction, engineering grade reflective graphics and weather, UV
and graffiti resistant paint. Lighting with a high-powered, 270 lumens / 92 candela LED
blue beacon/strobe.
Other options include:
2 Introduction
CB RT
GU-163-D
CB RT Series
Administrator Guide
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com

page 5 of 25
3 Dimensions
GU-163-D
CB RT Series
Administrator Guide
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
CB RT

page 6 of 25
GU-163-D
CB RT Series
Administrator Guide
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
Indicates a hazardous situation which, if not avoided, will result in
death or serious injury.
Indicates a hazardous situation which, if not avoided, could result in
death or serious injury.
CAUTION
Indicates a hazardous situation which, if not avoided, could result in
minor or moderate injury.
NOTICE
Indicates a situation which, if not avoided, could result in damage to
property.
IMPORTANT
Indicates significant information that is essential for proper product
functionality.
NOTE
Indicates useful information that helps get the most out of a
product.
4 Safety Information
HAZARD LEVELS LEGEND
WARNING
DANGER
Safety Instructions
Code Blue products shall be installed by trained professionals. The installation should
conform to all local codes. In some countries, a certified electrician may be required.
When transporting a Code Blue product, use the original packaging or equivalent to
prevent damage to the product.
Code Blue products shall be used in compliance with local laws and regulations.
Store the Code Blue product in a dry and ventilated environment.
Do not install the product on unstable brackets, surfaces or walls.
Use only applicable tools when installing Code Blue products.
Do not use chemicals, caustic agents, steel wool or aerosol cleaners other than those
tested and recommended by Code Blue.
Use only accessories that comply with technical specifications of the product. These
can be provided by Code Blue or a third party.
Use only spare/replacement parts provided by or recommended by Code Blue.
Transportation
When transporting a Code Blue product, use the original packaging or equivalent to
prevent damage to the product.
WARNING
NOTICE
NOTICE

page 7 of 25
GU-163-D
CB RT Series
Administrator Guide
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
5 Installation Instructions
Important Notes:
Getting Started
EIA/TIA, ANSI, CSA and BICSI cabling or similar standards shall be adhered to
for proper operation of Code Blue communication devices connected to
copper or fiber infrastructures communications cable and electrical cable in
the same conduit is not an acceptable installation and shall not be supported.
Analog phones require a minimum of 23mA for proper operation (26-29mA
recommended).
Each analog speakerphone requires its own phone line or PBX extension.
Multiple units shall not be supported.
Speakerphones require programming before operation. Consult the
speakerphone’s Administrator Guide for instructions.
If you are installing IP speakerphones, please read the appropriate manuals
and consult with your Network Administrator.
Size electrical wiring based on length of run.
Tools Needed
Ladder to reach the top of the unit.
Drill & Security Bit for removing & inserting security screws on
phone, dome top, & access door.
1-1/8” Socket set & extension
Phillips and flat head screwdrivers
All CB RT Units Require:

page 8 of 25
GU-163-D
CB RT Series
Administrator Guide
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
FOUNDATION - ANCHOR BOLT INSTALLATION INSTRUCTIONS
Conduit – Electrical and communication line conduit should be run through the
center of the foundation hole with a maximum combined diameter of three
inches. A minimum of four inches and a maximum of six inches of conduit is
required above the finished grade level. To ensure proper grounding, a ½-inch x
8-foot copper rod should be inserted in the center of the foundation and tied to
the steel enclosure. (Note: Follow all national and local codes governing this
installation.)
Pour the foundation – The foundation should be at least 18 inches in diameter
and the correct depth for the frost line in your area, with a minimum depth of at
least three feet. (Follow your local building codes for foundations.)
Set the anchor bolts in the wet foundation – Four 24-inch L-shaped anchor
bolts and an aligning template are supplied for anchoring the unit. The bolts
should be set into the foundation so that six inches are showing above the
finished grade level. The anchor bolts should be aligned using the supplied
template so the faceplate on the unit will face the desired direction.
Wiring – Pull power and phone line up through the conduits. A minimum of two
feet of wire must be available from the conduit for electrical and
communications wiring.
CBRT Installation Instructions

page 9 of 25
All wiring must be installed and connected by experienced and certified personnel to meet local
and national electrical codes, and will include a service disconnect.
GU-163-D
CB RT Series
Administrator Guide
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
SET THE UNIT
Screw one set of nuts and washers onto the anchor bolts – After the foundation
has set, screw one set of nuts followed by one set of washers onto the anchor bolts.
Set the nuts so the lowest washer is about 2½ inches above the concrete and at an
even height. To accomplish this, use a small level and check all three directions.
These nuts are not adjustable after the unit is in place. The bottom edge of the unit
will be ½-inch above the concrete when installed.
Set the unit on the anchor bolts – Align the faceplate in the desired direction, then
lift the unit over the anchor bolts. Note that the unit weighs approximately 225
pounds. Use appropriate lifting materials and methods to avoid possible injury
and/or damage.
Secure the unit – Access the mounting studs through the door on the side of the
unit and tighten the mounting nuts onto the anchor bolts. This may be more
convenient if a long socket, extension and universal joint is used to tighten the
hardware.
INSTALL COMBINATION BEACON/STROBE
Gasket – Place the strobe gasket on top of the enclosure.
Connect the cords – Plug the wires from the beacon-strobe into the mating plug at
the top of the enclosure.
Fasten the beacon/strobe – Using the supplied screws, fasten the beacon-strobe to
the top of the enclosure.
WIRING
Ground – The ground (green) wire should be stripped and fastened to the supplied
grounding lug.
24V AC supply – Using the proper crimping tool, attach a #8 fork to each of the
incoming power wires and fasten them to the terminal screws labeled “24V AC.”
120/240V AC supply – Using the proper crimping tool, attach a #8 fork to each of
the incoming power wires and fasten them to the correct terminals as labeled on
the transformer. After completing the wire connections, install the supplied terminal
covers.
IMPORTANT: The leveling of the bottom nuts is crucial to the leveling of the unit. A small
error will be magnified after installation.
IMPORTANT: A ½-inch air gap is required between the foundation and the unit. Moisture
problems may result if this condition is not complied with
CBRT Installation Instructions (continued)

page 10 of 25
DRILL ONE
2” DIA HOLE
FOR WIRING
IN LINE WITH PIPE
Camera and wiring (supplied by others) is installed into the male 1½ NPT.
Place the bracket over the mounting holes and insert the four 3/8-16 X 1 stainless
bolts. (The 3/8” stainless steel bolts should have one stainless steel washer and one
rubber washer.)
Verify the camera mount is evenly positioned to ensure the gasket seal is properly
seated.
Tighten the bolts with your 3/8” wrench in a crisscross pattern to ensure even
pressure until it is snug against the outside of the enclosure.
The camera mount will come with a gasket already mounted to the bracket on the arm.
Overhead Camera Mount Installation
Installing the Camera
All wiring must be installed and connected by experienced and certified personnel to meet local and national
electrical codes, and will include a service disconnect.
GU-163-D
CB RT Series
Administrator Guide
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
All CB RT Overhead Camera Mounts Require:
• Ladder to reach the top of the unit.
• 3/8" Wrench
Installing the Overhead Camera Mount

page 11 of 25
Line Power Installation Instructions
GU-163-D
CB RT Series
Administrator Guide
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
SUPPLY WIRING
Pulling the power wires – Wire should be a minimum of 14 AWG and be pulled
into the unit, leaving a minimum of two feet of wire from the opening of the
conduit.
Pulling the communications wire (if needed) – Communications wire must be
shielded phone line. The phone line must be pulled into the unit using a separate
conduit from the power, and be run so as to extend a minimum of two feet out
of the phone opening.
CONNECT THE POWER WIRES
Make the connections – Locate the grounding lug and connect the ground wire.
Using 115V AC supply – Connect the colored (hot) wire to the black wire, and
connect the white or gray (neutral) wire to the white wire.
Higher voltage supply – If the unit was ordered for a higher voltage, a pre-wired
power brick will be located on the top of the electrical panel with a 24 volt
secondary to supply the low voltage manifold and power brick to supply the
area light. Connect the colored (hot) wire and the white or gray (neutral) wire to
the white wire in the junction box.
CONNECT THE PHONE LINE (if required) – See phone Installation Instructions.
APPLY POWER – The unit should become operational immediately after the power
is energized.
IMPORTANT: All wiring shall comply with national and local codes governing this
installation. It is the responsibility of the installer to ensure these conditions are
complied with.

page 12 of 25
GU-163-D
CB RT Series
Administrator Guide
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
CAUTION
The Steadyburn Mode will be ON in dark or night ambient environments and OFF in
bright or daylight ambient environments. The S-1050 LED Beacon/Strobe has two
built-in photo response features: (a) dawn/dusk transition delay of 15-30 minutes
and (b) transient light acknowledgement delay of at least 3 minutes.
To activate the LEDs in the PRIMARY-STEADYBURN MODE, connect the BLACK and
RED wires to 12-24 volts AC or DC.
When in PRIMARY-STEADYBURN MODE, to change the LEDs to SECONDARY-FLASH
MODE, connect both YELLOW control wires together (i.e., CLOSED = ON).
DRY CONTACT
CLOSED = "ON"
RED
BLACK
YELLOW
YELLOW
(FLASH MODE)
(FLASH MODE)
COMMON (GROUND)
POSITIVE (12-24V DC or AC)
S-1000 & S-1050 Strobe Operation
OPERATION
PHOTOCELL FEATURE (S-1050 MODEL)
REMOVE ALL POWER FROM UNIT BEFORE SERVICING.
NOTE: Instructions pertain to:
Model S-1000 LED Beacon/Strobe and
Model S-1050 LED Beacon/Strobe only.

page 13 of 25
SECONDARY-FLASH MODE
GU-163-D
CB RT Series
Administrator Guide
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
Mode Number
Primary-Steadyburn Mode
Secondary-Flash Mode
1
High
Single - 60 FPM
2
OFF
Single - 60 FPM
3
Low
Single - 60 FPM
4
High
Single - 150 FPM
5
OFF
Single - 150 FPM
6
Low
Single - 150 FPM
7
High
Single - 375 FPM
8
OFF
Single - 375 FPM
9
Low
Single - 375 FPM
10
High
Neobe - 75
11
OFF
Neobe - 75
12
Low
Neobe - 75
13
High
Neobe - 150
14
OFF
Neobe - 150
15
Low
Neobe - 150
16
High
Double - 125
17
OFF
Double - 125
18
Low
Double - 125
19
High
Double - 250
20
OFF
Double - 250
24
Low
Double - 250
INPUT VOLTAGE RANGE: 12-24V AC or DC
TEMPERATURE RATING: -40°C to +65°C (-40°F to 149°F)

TYPICAL POWER CONSUMPTION AT 25°C
Voltage Flash Mode
Steady Mode - High
12V DC
0.24 A Max
0.24 A
24V DC
0.12 A Max
0.12 A
12V AC
1.1 A rms Max
0.53 A rms
24V AC
0.22 A rms Max
0.22 A rms
NOTE: Average current draw in Flash Mode will vary by selected Flash mode. The above maximum amperage draw is
stated at Single 60 FPM.
PROGRAMMING PRIMARY & SECONDARY MODES
1. Remove power from unit.
2. Short the Yellow wires together.
3. Restore power to the unit and wait until the unit begins to flash. Once the unit begins to flash, remove the short. The unit will
alternately demonstrate the Secondary-Flash Mode and Primary-Steadyburn Mode that will be displayed during operation. For
approximately 4 seconds the Secondary-Flash Mode will be demonstrated, followed by the Primary-Steadyburn Mode.
4. To select the next mode of operation, momentarily short the yellow wires. The unit will cycle to the next mode in the list above.
5. There are seven Flash Modes and three Steadyburn Modes combinations to choose from.
6. When you reach the desired mode of operation, remove power from the unit. You MUST leave power disconnected for 20 seconds
BEFORE reapplying. When power is reapplied, the unit will operate as programmed above.
NOTE: If you do not leave power disconnected for 20 seconds before reapplying power, the light will default to Program Mode.

page 14 of 25
GU-163-D
CB RT Series
Administrator Guide
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
6 Power Requirements
The following tables on pages 14-17 include CB RT and ALL OTHER Code Blue devices &
enclosures for reference.

page 15 of 25
GU-163-D
CB RT Series
Administrator Guide
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com

page 16 of 25
GU-163-D
CB RT Series
Administrator Guide
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com

page 17 of 25
GU-163-D
CB RT Series
Administrator Guide
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com

page 18 of 25
7 Wiring Diagrams
GU-163-D
CB RT Series
Administrator Guide
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
Mating connector
supplied for source
termination by
qualified technician.
24V AC Input
Customer supplied 24V AC harness to be used
when 24V AC incoming power is present.
85-277V AC Input
CB RT 24-277V AC DIN Rail Power System
Standard CB RT - No Cellular Communication
CB RT with Cellular Communication
For installations with 24-277V AC incoming power on site. Provides
flexibility for future power updates.
Used in the following configurations:
DIN Rail Layout

page 19 of 25
GU-163-D
CB RT Series
Administrator Guide
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
1 2 3
3 2 1 2 1 2 1 2 1
1 2 1 2 1 2
12/24V DC Output
Voltage Selector
PoE Voltage
37-57V DC
Faceplate
Speakerphone
Faceplate Light
Beacon Strobe
Incoming PoE >>>
Data to WAN Port of VoIP Speakerphone >>>
CB RT PoE DIN Rail Power System
Standard CB RT - No Cellular Communication
For installations with PoE incoming power on site.
Used in the following configurations:
DIN Rail Layout
Connect Lighting & Communication devices to power system via Wago plug & socket
connectors.
Connect RJ45 ethernet cable (Cat5e or Cat6) from “Data” port on PoE splitter to the
WAN port of the VoIP speakerphone.
Plug incoming PoE ethernet RJ45 cable (Cat5e or Cat6) into “Data + PoE” port on PoE
splitter. Splitter will light up accordingly indicating passing of DC voltage.
Order of Connection
1.
2.
3.
IMPORTANT NOTE: LS1000 speakerphones operate on 12V DC only. If the 24V DC output is selected on the
PoE splitter, the use of a 24V to 12V DC step-down transformer must be installed prior to connecting the
power system to the speakerphone.

page 20 of 25
Remove the access plate cover with the special security bit. The serial number will be
listed on the manufacturer’s label located on the backside of the access plate cover (1).
1
8 Locating Unit Serial Numbers
GU-163-D
CB RT Series
Administrator Guide
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
