TD35 VS - TD50 VS
Technical specifications
Compressor for R134a 12/24V DC

1
Thank you for choosing the TD35 VS and TD50 VS R134a 12/24V DC compressor.
Please read this manual thoroughly before beginning operation.
1 Application range
Suitable for the cooling device with a power o f 12 or 24V DC power supply , Evaporating
Temperature at -35 -5 , especially for using in a mobile applications, the refrigerant is R134a.
2 Features
2.1.Easy start, High reliable.
2.2.Low noise, Low vibrancy , long use life.
2.3.Attached Controller, Few attachment, Easy to use.
2.4.Rotary speed at 2000 rpm 3500rpm adjustable.
3 Type
Hermetic reciprocating refrigeration compressor .
4 Technical Data
Table 1 Specification
Compressor Model
Displacement, cm
3
2.0
Applications LBP
Rotation, rpm
Capacity, W
Input Power, W
Operating Current, A
C.O.P, W/W 1.1
Sound Level, dB(A)
Vibrancy Acceleration, m/s
2
0.65
Operating Voltage, V DC
Cooling Static or Fan cooling
Lubricant Polyester
Lube Vol. , ml 5
Weight , kg 4.3
Weight of Controller, kg 0.40
Motor Type BLDCM
Refrigerant R134a
Throttling Device Capillary
Power, V D C 12/24
Test conditions Evaporating Temp -23.3 Suction. Temp. 32.2
Condensing Temp. 54.4 Sub-cooling Temp. 32.2
Ambient Temp. 32.2
Notes * base on the input power of 12V DC
COLDEX TD35 VS
PROCOLD S.r.l. - ITALY- 13043 CIGLIANO (VC)
C/so Umber o,58 - Tel [phone] Fax [phone]
www.procold.i info@proco ld.i
Rev. 2.0 27/02/2019
COLDEX TD50 VS
2.5
2.000 2.500 3.000 3.500
33 40 45 50
30 36 41 46
1.25/ 2.5* 1.5/ 3.0* 1.7/ 3.4* 1.92/ 3.8*
37 38
2.000 2.500 3.000 3.500
42 52 61 71
38.2 47.3 55.5 64.5
1.5/ 3.0* 1.9/ 3.8* 2.3/ 4.6* 2.7/ 5.4*
38 40
150
10.9V 17V (12V) , 22.7V 31.5V (24V)

2
5.1.1 The Controller is connected to the battery d irectly, wrong connect the poles doesn t destroy
the compressor and controller, but the compressor d o not work;
5.1.2 The fuse must be connected in the + cable to protect controller, which close to the power
supply, 15A fuse for 12VDC and 7.5A fuse for the 24VDC are recommended;
5.1.3 If a main switch is used, it should be rated to current of min. 20A;
5.1.4 To prevent voltage dropping, please avoid ex tra junction in the power supply system.
5.1.5 A Light Emitting Diode(LED) for compressor o peration monitoring can be connected
between the terminals + and D .
Operational errors will cause the LED to flash a nu mber of times. The number of flashes
depends on what kind of operational error was recor ded. Each flash will last 1/4 second and
each error will repeat every 4 seconds. Operational errors show by Table 5, please see it in
page 6.
5.1.6 If a cooling fan is used. It must be connect ed to electronic unit terminals + and F, only use
12VDC fan , no matter what power supply you are usi ng;
5.1.7 A Thermostat is connected between the termin al C and T of the electronic unit. It will start
or stop the running of compressor automatically;
5.1.8 A Resistor can be connected between terminal C and T, it allows you to adjust the speed of
the compressor, the relationship between the resist or and the compressor speed shown by
Table 3; please see it in page 3.
5.1.9 To ensure sufficient battery power for co mpr essor and avoid permanent damage to the
battery because heavy discharge. A battery protecti on resistor is connected between
terminal C and P, the different resistor will get t he different voltage protection, the details is
showed by Diagram 4;
PROCOLD S.r.l. - ITALY- 13043 CIGLIANO (VC)
C/so Umber o,58 - Tel [phone] Fax [phone]
www.procold.i info@proco ld.i
5 Controller
5.1 Wiring
The Compressors are equipped with a brushless direct current
motor which is controlled by an Attached Controller, the wiring is shown as following drawing:
TD35 VS and TD50 VS
1 Battery
2 Fuse
3 Main Switch (optional)
4 LED (optional)
5 12V DC Cooling Fan (optional)
6 Thermostat
7 Resistor for presetting speed (optional) C-T
8 Resistor for presetting battery protection
voltage (optional) C-P
Rev. 2.0 27/02/2019

3
5.2 The Technical Specification of controller is shown:
Table 2 Controller Data
Compressor Model TD35 VS - TD50 VS
Model 12/24V DC
Dimensions 116mm × 103mm × 50mm
Output Power W 20W~ 140W
Static Consumption
Power W 2
Max. Ambient Temp. 55
Max. Operating Current A 12A 12V , 6A(24V)
Controller
Startup Time S 6s to 1850rpm
5.3 Compressor Speed Setting:
The compressor s speed could be adjusted in range 2000rpm 3500rpm by adjusting the
resistor of presetting speed
5.4 Battery Protection Setting:
Table 4 Battery Protection Setting
Protect
Resistor
K
12V
cut-out
V
12V
cut-in
V
12V Max.
Voltage
V
24V
cut-out
V
24V
cut-in
V
24V Max.
voltage
V
0 9.6 10.9 17.0 21.3 22.7 31.5
1.6 9.7 11.0 17.0 21.5 22.9 31.5
2.4 9.9 11.1 17.0 21.8 23.2 31.5
3.6 10.0 11.3 17.0 22.0 23.4 31.5
4.7 10.1 11.4 17.0 22.3 23.7 31.5
6.2 10.2 11.5 17.0 22.5 23.9 31.5
8.2 10.4 11.7 17.0 22.8 24.2 31.5
11 10.5 11.8 17.0 23.0 24.5 31.5
14 10.6 11.9 17.0 23.3 24.7 31.5
18 10.8 12.0 17.0 23.6 25.0 31.5
24 10.9 12.2 17.0 23.8 25.2 31.5
33 11.0 12.3 17.0 24.1 25.5 31.5
47 11.1 12.4 17.0 24.3 25.7 31.5
82 11.3 12.5 17.0 24.6 26.0 31.5
PROCOLD S.r.l. - ITALY- 13043 CIGLIANO (VC)
C/so Umber o,58 - Tel [phone] Fax [phone]
www.procold.i info@proco ld.i
220 9.6 10.9 Photovoltaic soalr appli cation 31.5
Table 3 Speed Setting (Terminal C-T)
Resistor Speed rpm
0 2000
277 2500
692 3000
1523 3500
White Resistor
Black Resistor
Red Resistor
+/-
0.1 V (Terminal C-P)
Rev. 2.0 27/02/2019

Controller calibrator to the applied voltage automa tically, when the battery voltage is lower
than 17 VDC, The controller consider it is working in a 12 V DC system, and When the voltage is
higher than 17 VDC The controller consider it is wo rking in a 24 V DC system.
resistor is connected between C - P , the operating voltage range could be
9.6V 31.5V, this means
TD35 VS and TD50 VS are very suitable for
application.
5.5 Error Indication
If the start failed, the controller will attempt r estarting every 60s, until a successful start is
achieved. The following Table shows the Error Type and reason.
Table 5 LED Error Indications
Number of
flashes Error Type
5
Thermal cut-out of controller
If the refrigeration system has been too heavily loaded, or if the
ambient temperature is high than 55 ,the controller will run too hot
4
Minimum motor speed error
if the refrigeration system is too heavily loaded ,the motor speed is
lower than 1850 rpm
3 Motor start error
The rotor is blocked or the system pressure is too high
2 Fan over-current cut-out
The operating current of cooling fan is more than 1A
1 Battery protection cut-out
Battery Voltage is outside the setting range shown in Table 4
6 Accessories
Table 6 Accessories
No. Title Pieces Model Comments
1 Controller 1 12 - 24 Volt AUTO
2 1
Screw of
controller (M4 x 8)
3 Rubber grommet 4 RU HC 35-50-80
4 Grommet sleeve 4 SL HC 35-50-80
If a 220K
extended between
photovoltaic solar power
PROCOLD S.r.l. - ITALY- 13043 CIGLIANO (VC)
C/so Umber o,58 - Tel [phone] Fax [phone]
www.procold.i info@proco ld.i
4
Rev. 2.0 27/02/2019

5
7.3 More than two layer package of compressors is no t available, and avoid any rolling during
loading and unloading.
7.4 After consignment, it is better store the compres sors not more than 6 months.
8 Precautions
8.1 The compressor is only allowed to be connect ed to a 12/24VDC system, it is forbidden to
connect compressor directly with an AC power supply.
8.2 The back gas tube on refriger ation system must be connected with the suction tube on
compressor, not the process tube on compressor; otherwise the compressor can t work in gear.
8.3 Please mount the compressor into the refrigerat ion system quickly in 10 minutes after uninstall
the tubes of the compressor (suggest to uninstall the process tube first).
8.4 The maximum ambient temperature of the compress or operation is 55 .When continuously
operating under the maximum ambient temperature 55 , the max condensing pressure and the
peak pressure should not exceed 1.75MPa and 2.17MPa.
8.5 Balance pressure 55 start the compressor the pressure in the compressor could not more
than 0.49MPa.
8.6 Do not operate the compressor before polyester is charged.
8.7 The refrigerant charge should be less than 200g
8.8 The interval of compressor operation Operation is more than 3 minutes, and the stoppage is
more than 3 minutes too.
8.9 Special attention Do not use the compressor as a vacu um pump, and do not start it under
vacuum status too.
8.10 The refrigeration system should minimize the c ontent of chlorines and moisture, and must be
free of paraffin and silicon.
8.11 In order to make the compressor work prope rly, the following cable dimensions must be
observed.
Table 7 Cable requirements
Max. Length between battery and
Controller m
Cross-section
mm
2
12V DC 24V, DC
2.5 2.5 5
4 4 8
6 6 12
10 10 20
PROCOLD S.r.l. - ITALY- 13043 CIGLIANO (VC)
C/so Umber o,58 - Tel [phone] Fax [phone]
www.procold.i info@proco ld.i
7 Transportation and storage
7.1 Please keep perpendicularity, can not be turn ed upside down and avoid vibration and shocks
during transportation.
7.2 Please ensure to store the compressors under dr y and well-ventilated condition to avoid the
package getting wet.
Rev. 2.0 27/02/2019

C
T
P
D
F
+
+
-
CO LDEX
12-24 Volt DC
RoHS
COLDEX
TD35 VS - TD50 VS
PROCOLD S.r.l. - ITALY- 13043 CIGLIANO (VC)
C/so Umber o,58 - Tel [phone] Fax [phone]
6
www.procold.i info@procold.i
CONTROLLER
COMPRESSOR
PROCESS Ø 6.20
SUCTION Ø 6.20
DISCHARGE Ø 5.15
DIMENSIONS COMPRESSOR
