Coleco Vision 2492 User manual

OWNERS MANUAL
MODEL NO. 2492
Guide No. 91950
ROLLER CONTROLLER
Exciting High-Speed Action on Your
ColecoVision™ Game System!
For Ages 8to Adult
COLECO INDUSTRIES INC., AMSTERDAM. NEW YORK 12010
•1M3, Coltco Industrie*, Inc. Printed in U.S.A.

CONSUMERS PLEASE NOTE!
Please read the Owner's Manual carefully before using this
product. If amalfunction occurs, please refer to the Trouble-
shooting Checklist. If you cannot correct the malfunction,
please call Customer Service, Toll-Free nationwide:
1-800-842-1225
THIS PRODUCT SHOULD BE ASSEMBLED ONLY BY AN ADULT.
HOOKING UP YOUR ROLLER CONTROLLER
PLUG POWER SUPPLY INTO
POWER ADAPTER PLUG
PLUG POWER ADAPTER
PLUG INTO POWER
SUPPLY SOCKET
WYE CONNECTOR /*
CABLE JACKS '-
POWER
SUPPLY
CQLECOVISICW" CONSOLE
HAND
CONTROLLER
WELL
HAND
CONTROLLER
SOCKET KEYPAD
COLECOVISION'*
HAND CONTROLLER

1. Unplug and remove the Hand Controllers trom me ColecoVision'" Console
unil
2. Plug aHand Controller into the socket inside aHand Controller Well of the
Roller Controller.
3. Wind the Hand Controller Cord no ally inside the Well, then slide the bottom of
the Hand Controller Into the Well. When Hand Controller is In place, push the
top ot the Hand Controller dawn until it snaps into pi see Attach the other Hand
Controller to the Roller Controller in the same manner. The Hand Conlroller
lacks will lit only one way —DO NOT FORCE them into the controller sockets
.
4. The WYE Connector Cable lacks have the number 1molded on lop of one jack
and ihe number 2molded on lop ot the other jack Plug jack n1into the rear
socket, then plug jack a2Into the front socket ins*do the Hand Controller
storage compartments of your ColecoVision'11 Console unit as shown in illus-
tration Bo sure the numbers .ire facing up when you are plugging in Ihe lacks
5. Plug the Power Adapter Plug from tho Roller Controller unit into the Power
Supply socket in back of your ColecoVision'" Console unit
6. Plug the jack of tho AC Power Supply unit into the back ot the Power Adapter
Plug as shown in Illustration Plug the AC Power Supply unit Into a11/120 volt
household Hlectrieal outlet Make sure the Power Supply is fully inserted into
the etectneal outlet
7. MODE SWITCH: The function of the MODE SWITCH is to select between a
Joystick cartridge and acartridge designed exclusively 1or use with the Roller
Controller Slide the MODE SWITCH to the ROLLER Cartridge position when
playing roller-game cartridges The JOYSTICK Cartridge position can be used
with most games that require use of the hand controller Joystick Some Joy-
stick cartiidge games will be more challenging than others when played with
Roller Conlroller. Get the "feel" ol the game betore you decide to use Roller
Controller to play aJoystick cartridge gam«.
Now you are ready to begin playing your game' BE SURE THAT THE COLE-
COVISION'" UNIT IS OFF BEFORE INSERTING OR REMOVING CARTRIDGE.
Refer to your GAME CARTRIDGE Instruction Guide for game play instructions.
WARNING. ALWAYS UNPLUG THE POWER SUPPLY FROM THE 110/120 VOLT
OUTLET WHEW YOU HAVE FINISHED PLAYING.
CARE OF YOUR GAME
aTreat your COLECOVISION'" ROLLER CONTROLLER with care
LI Before inserting or removing GAME CARTRIDGE, always make sure that the
POWER SWITCH on CONSOLE unit it turned "OFF".
OAlways unplug the POWER SUPPLY from the 110/120 volt outlet when you
have finished playing IMPORTANT: ONLY CONNECT THE CONSOLE POWER
SUPPLY UNIT IMTO A110/120 VOLT HOUSEHOLD ELECTRICAL SERVICE.
OTHERWISE SERIOUS DAMAGE MAY OCCUR TO ELECTRICAL PARTS
OF THE SYSTEM
QDg ngt drop or bang ROLLER CONTROLLER. CONSOLE or HAND
CONTROLLERS
DDo not use sharp or pointed object to activate KEYPAD BUTTONS or GAME
ACTION BUTTONS
nDo not store or leave ROLLER CONTROLLER, CONSOLE and accessories
where they may be subfecl to heat build-up.

DKeep away from moisture. Do not immerse ROLLER CONTROLLER. CONSOLE
of HAND CONTROLLERS in water Use asolt. slightly damp cloth- to wipe clean
WARNING: Before cleaning POLLER CONTROLLER. CONSOLE and acces-
sories, turn POWER SWITCH to "OFF and disconnect the AC POWER SUP-
PLY unit from th e11'120 volt wall outlet
Do not attempl to repair ROLLER CONTROLLER. It does nol contain any owner
serviceable parts Reter to your TROUBLESHOOTING section, it not success-
ful refer to LIMITED WARRANTY
NOTICE
This game generates and uses radio frequency energy and It not installed and
used property, that is in strict accordance with the instructions, may cause inter-
ference to radio and television reception. It has been type tested and found to
comply with the limits lor aClass Bcomputing device maccordance with the
specifications in Subpart Jo! Pari 15 of FCC Rules, which are designed to provide
reasonable, protection against such Inler terence maresidential |nf taiiatlon How-
ever, there is no guarantee that interference will not occur in aparticular installa-
tion. It this game does cause interference to radio or television reception which
can be determined by turning the game off and on. the user is encouraged to try to
correct the interference by one or more at the following measures:
Reorient the TV antenna
Relocate the game with respect to the TV
Move the game away from the TV
Plug the game into a dilfereni outlet so that game and TV are on different
branch circuits.
It necessary, the user should consult the dealer or an experienced radio televi-
sion technician for additional suggestions The use' may 'ind the following Look
let prepared by the Federal Communications Commission helpful:
"How to Identify and Resolve Radio TV Interference Problems"
This booklet is available from the USGovernment Printing Olfice, Washington.
OC 20402, Stock No 004-000-00345-4
TROUBLESHOOTING
SYMPTOM REMEDY
DSnow CMake sure that both connections (er
the power supply are secured in
their proper ports
No Hand Controller Response UMake sure that Ihe switch on the
Roller Controller console is in the
"Joystick Cartridge'" mode
DRoller Response Backwards DMake sure that the controller plugs
are Inserted Into the correct ports on
the ColecoVision Main Console

LIMITED WARRANTY
C-oleeo warrants to the original consumer purchaser at its COLECOVISION'"
HOLLER CONTROLLER in the United States of America tnat the product will be
free ol" defects in material or workmanship for 90 -days from the date of purchase
under normal in-house use.
Coleco's sole and exclusive liability for detects in material and workmanship
shall be limited to repair or replacement at its authorized Coieco Service Station
Tins warranty does not obligate Coieco to bear the cost of transportation charges
in connection with the repair or replacement of defective parts.
This warranty is invalid if the damage or defect is caused by accident, act ol
God. consumer abuse, unauthorized alteration or repair, vandalism, or misuse.
Any Implied warranties arising out of the tale of the COLECOVISION™
ROLLER CONTROLLER Including the Implied warranties of merchantability and
fitness for aparticular purpose are limited to the above 90 day period. Coieco
shall In no event be liable for incidental, consequential, contingent or any other
damage*,
ThU warranty gives you specific legal rights, and you may have other rights
which vary Irom State to State Some states do not allow the exclusion or limitation
ol incidental or consequential damages or limitations on how long an implied
warranty lasts, so the above limitations or exclusions may not apply to you.
SERVICE POLICY
Please read the Owner's Manual carefully before using the product If your
ROLLER CONTROLLER fails to operate properly, please refer to the trouble-
shooting checklist in the Owner's Manual. If you cannot correct the malfunction
after consulting tho troubleshooting checklist, please call Customer Service on
Coleco's toll-free service hotline [phone] nationwide. This service Is In
operation from HOD a.m. to 5:00 p.m. Eastern Standard Time, Monday through
Friday.
If Customer Service advises you to return your ROLLER CONTROLLER;,
please return It postage prepaid and insured, with your name, address, proof of
Ihe date of purchase, and abrief description of the problem to the Service Station
you have been directed to return it fo by the toll-free service Information If your
unit is found to- be factory defective during the first 90 days, it wi" be repaired or
replaced at no cost to you. If the umf is found to have been consumer damaged or
abused and therefore not covered by the warranty, then you will be advised, in
advance, of repair costs.
If your game requires service after expiration of the 90 day Limited Warranty
period, please call Coleco's toll-free service- hotline lor instructions on how to
proceed 1-800-842- 1225 nationwide.

re^re^
im
^HhlnJ
ROLLER CONTROLLER
Exciting High-Speed Action on Your
ColecoVision™ Game System!
Package, Program and Audiovisual I1983 Coloco Indus
tries, Inc. Amsterdam. New York 12010
ColecoV Ision'" Is atrademark ot Coleco Industries, Inc.
CONSUMERS PLEASE NOTE!
Please read the Owner's Manual carefully be-
fore using this product. II amalfunction occurs,
pleaserefertotheTroubleshootingChocklist.il
you cannot correct the malfunction!, please call
Customer Service. Toil-Free nationwide:
1-800-842-1225
PLEASE RETAIN THIS GUIDE
AND ALL LITERATURE FOR FUTURE REFERENCE
H-1HH-I
COLECO INDUSTRIES INC.. AMSTERDAM, NEW YORK 12010

MODEL NO. 2492 Supplement No. 14310
SUPPLEMENT INSTRUCTIONS FOR
ROLLER CONTROLLER
HOOKING UP YOUR ROLLER CONTROLLER
TO YOUR ADAM'" FAMILY COMPUTER SYSTEM (Fig. 1)
1. NOTE: actor? attaching youi Roller Controller to the ADAM~ Computer
System, unplug the primer power cord from the electrtcal wall outlet.
2. Unplug and remove the Hand Controllers (torn the memory console.
3. Plug aHand Controller into the socket inside the Hand Controller Well of ihe
Roller Controller, (continued on following page)
SMARTWBITER-
PRINTER ADAM 'ADAPTER
PRINTER
-» \CABLE
—a %PLUI
ADAM "MEMORY
CONSOLE POWER
SOCKET
Fig. 1
WYE CONNECTOfl
CABLE JACKS
(r,.-/»,-.-.vw/.-w/*'/.v-;HW(.-n)f ,' •.••(.'fl^\i'.l ,.i' II
ROLLER
CONTROLLER
POWER
ADAPTER
PLUG
HAND
CONTROLLER
WELL
HAND
CONTROLLER
SOCKET
HAND CONTROLLER
H"li=^«l
COLECO INDUSTRIES INC .AMSTERDAM. NEW YORK 12010
81983. Coleco Industries, Inc. Printed in U.S.A.

4. Wind the Hand Controller Cord neatly inside the Well, then slide the Bottom
of the Hand Controller Into the Well When Hand Controller is in place, push
the top ot the Hand Controller down until it snaps into place. Attach the
other Hand Controller to the- Roller Controller in the some manner The Hand
Controller jacks will In only one way -DO MOT FORCE them into the con-
troller sockets.
5. Trie WYE Connector Coble jacks have the number 1molded on top ol one
jack and Ihe number 2molded on top o( the other jack Plug the jacks into the
corresponding "CONTROLLER" Sockets on the memory console, as shown
In Illustration. Be sure the numbers are facing up when you are plugging
in jacks.
6. Remove the Printer Cable Plug from the memory console "POWER' Socket.
7. Then inserl Ihe ADAM** Adapter Into the memory console "POWER" Socket.
B. Now insert Ihe Printer Cable Plug into the ADAM"" Adapter marked
"POWER".
9. insert ihe Power Adapter Plug from Ihe Roile* Controller unit two the ADAM"
Adapter morked •ACCESSORY.'
10. Plug the power cord on Ihe pnnter into the electrical wall outlel Now you are
ready to begin playing your game! BE SURE THAT COMPUTER IS OFF
BEFORE INSERTING OR REMOVING GAME CARTRIDGE. Refer to your
GAME CARTRIDGE Instruction Guide tor game play inslructions.
NOTE; The ADAM'" Adapter does nol have lo be removed trorn the memory
console after using your Roller Coniroller.
HOOKING UP YOUR ROLLER CONTROLLER
TO YOUR ADAM™ FAMILY COMPUTER MODULE (Fig. 2)
1. NOTE: Before attaching your Roller Controller to the ADAM "Computer Mod-
ule, unplug the printer power cord from Ihe electrical wall outlet
2. Unplug and remove the Hand Controllers from the ColecoVislon* Console
unit.
3. Plug aHand Controller into Ihe socket inside aHand Controller Well or the
Roller Controller
4. Wind Ihe Hand Controller Cord neatly inside the Well. then, slide Ihe bottom
of the Hand Controller into the Well. When Hand Controller is in place, push
the top of the Hand Controller down until it snaps into place. Attach the
Other Hand Controller to the Roller Controller In the same manner. The Hand
Controller jacks will fit only one way —DO NOT FORCE them into the con-
troller sockets.
5. The WYE Connector Cable jacks have the number imolded on iop of one
jack and the number 2molded on top ol the other jack. Plug jack #1 into the
rear socket, then plug jack #2 Into the Iront socket inside the Hand Con-

(roller storage compartments ot your CotecoVislon* Console unM as shown
in illustration. Bo sure the numbers are facing up when you are plugging in
the |ack&.
6. Remove the Printer Cable Plug irom the memory console "POWER" Socket.
7. Then insert the ADAM" Adapter into the memory console POWER" Socket
S. Now insert the Printer Cable Plug into the ADAM'" Adapter marked
"POWER'.
9. Insert the Power Adapter Plug from the Roller Controller* unit Into the ADAM'"
Adapter marked ACCESSORY
10. Plug the power cord on th« printer Into the electrical wall outlet Now you are
ready to begin playing your game" BE SURE THAT THE COLECOVISlON*
UNIT IS OFF BEFORE INSERTING OH REMOVING CARTRIDGE. Reler to
your GAME CARTRIDGE Instruction Guide tor game play instructions
NOTE: The ADAM" Adapter does not have- to be removed from the
ADAM -Computer Module after using your Roller Controller.
SMAHTWBITEH
PRINTER
ADAM-MEMOHV
CONSOLE POWEH COLECOVISlOMJ
SOCKET. CONSOLE
AOAM'" ADAPTER WVE CONNECTOR
CABLE JACKS
V PRINTER
\% \CABLE
J3. PLUG
ROLLER CONTROLLER
POWER ADAPTER
PLUG
HAND CONTROLLER
WELL
HANO CONTROLLER
SOCKET
Fig. 2
AOAM'-
COMPUTER
EXPANSION
MODULE
ROLLER CONTROLLER
HAND CONTROLLER

H»H=I«M
The Makers ol ColecoVision1"'
Adam™ and Coleco Vision ore trademarks of Coleco
Industries. Inc.
Package, Program and Audiovisual 1983 Coleco- Indus-
trial. Inc. Amsterdam, New "fork 12010
