Coleman COMFORTEERTM GM8S User manual

Comforteer™ GM8S Series 80% AFUE Efficiency
Mid-Efficiency Gas Furnaces
Every Moment Deserves Coleman® Comfort

A name that stands for reliability
The Coleman® nameplate on your product is your
best assurance of dependable performance. Our tough
manufacturing quality processes make sure that our
famous “rugged reliability” comes through for you
season after season. And trust our expert home-comfort
contractors for installation and support that leave you
with a good feeling.
Comfort with a conscience
These days, energy costs and environmental issues
concern everyone. All Comforteer™ models can reduce
energy costs at least 25% compared to most furnaces
that are 20 years old. Plus, Comforteer mid-efficiency
design uses an efficient multiple-speed blower to ensure
greater economy and comfort.
Easy service adds up to long-term savings
The Comforteer series makes service and maintenance
easy, too. So, you not only get economy, efficiency and
rugged dependability with this furnace, you get one
that’s less work to work on.
Comfort for all the times of your life C o l e m a n® C o m f o r t e e r ™ S e r i e s
Get a great feeling
Your special moments deserve to
be lived in full Coleman® Comfort.
From breakfast time to family
time to bed time, a new Coleman®
system makes every day feel great!

Rugged, reliable product design
Electronic hot surface ignitor
for dependable operation and
reduced energy costs
Multiple-speed, direct-drive
motor powers large, quiet
blower to keep you comfortable
Inducer fan quietly
regulates combustion for
improved efficiency
Aluminized steel tubular heat
exchanger for long life—backed
by a 20-year limited warranty
Integrated control provides
reliable, economical operation
Timed-on, adjustable-off
blower for maximum comfort
blower for maximum comfort
1
AFUE: The federal government has established Annual Fuel Utilization Efficiency (AFUE) ratings to allow you to
compare the efficiency of furnaces. The higher the AFUE percentage is (e.g. 95%), the more efficient the furnace.
Comfort for all the times of your life C o l e m a n® C o m f o r t e e r ™ S e r i e s
Example:
$1,596 – $1,297 = $299
(Your estimated annual savings)
That’s a 20% savings!
Example is based on the difference
between a 65% AFUE unit and
an 80% AFUE unit in zone 1.
Heating
Efficiencies
Approximate Annual Heating
Operating Costs
AFUE
1
Zone 1 Zone 2 Zone 3 Zone 4 Zone 5
65% $1,596 $1,418 $1,082 $957 $534
80% $1,297 $1,152 $875 $777 $474
92% $1,127 $1,002 $764 $676 $412
95% $1,091 $969 $740 $654 $399
Savings you can see
Advanced Comforteer gas furnaces
are far more efficient compared to
many older units. Factor in higher
reliability and reduced service
costs, and a Comforteer purchase
pays for itself fast.
To use the map and chart:
First, determine the AFUE
1
of your current
system. Then using the map, find your
zone. Cross-reference your zone and
AFUE in the table to determine your
approximate operating cost. Take the
difference between your current cost and
that of a new, more efficient system to
learn your estimated annual savings.


Coleman
®
and are registered trademarks of The Coleman Company, Inc., used under license. Manufactured by Johnson Controls, Inc., 5005 York Drive, Norman, OK 73069, www.colemanac.com.
© 2007 Johnson Controls, Inc. All rights reserved. Subject to change without notice. Form 344772-CCB-A-0807. Supersedes: 246460-CCB-A(1206). Printed in USA.
Warrantied for years of comfort
Every Coleman® system is backed with
the best limited warranties available:
Financing plans that feel right
Ask your Coleman® HVAC dealer
about easy financing options.
Applying is easy, and upon
approval, you'll enjoy low monthly payments,
special financing offers, and no annual fee!
Standard Warranty
(10 years on total parts and labor
coverage can be purchased separately)
5 years on parts,
20 years on heat exchanger
How comfortable is your wallet?
By matching your Coleman® system
with other Coleman® equipment,
you will maximize energy efficiency
and likely qualify for various rebates
and tax breaks. Ask your Coleman®
dealer about rebates offered in your
area. And, ask about Coleman® central
air conditioning systems, heat pumps, fans, filters, IAQ equipment
and advanced controls to complete your system. Talking to your
dealer will keep you informed, save you money and time, and
protect your family’s health — all part of Coleman® Comfort.
Visit our Website
Learn how Coleman® products can
improve your home comfort at
www.colemanac.com. Our website
is the perfect place to get acquainted
with our wide range of products.
Have your Coleman® dealer specify the system that performs best for your home
Comforteer™ GM8S Mid-Efficiency Gas Furnace
Nominal
CFM
MBH
Input
Width**
(inches)
Upflow/Horizontal Downflow/Horizontal
Model % AFUE Model % AFUE
Comforteer
™
GM8S Furnace
12 40 14-1/2 GM8S040A12UH11* 80.0 GM8S040A12DH11* 80.0
12 60 14-1/2 GM8S060A12UH11* 80.0 GM8S060A12DH11* 80.0
12 80 14-1/2 GM8S080A12UH11* 80.0 GM8S080A12DH11* 80.0
16 80 17-1/2 GM8S080B16UH11* 80.0 GM8S080B16DH11* 80.0
16 80 21 GM8S080C16UH11* 80.0 GM8S080C16DH11* –
22 80 21 GM8S080C22UH11* 80.0 – 80.0
12 100 17-1/2 GM8S100B12UH11* 80.0 GM8S100B12DH11* 80.0
16 100 17-1/2 GM8S100B16UH11* 80.0 – –
16 100 21 GM8S100C16UH11* 80.0 GM8S100C16DH11* 80.0
20 100 21 GM8S100C20UH11* 80.0 GM8S100C20DH11* 80.0
16 115 21 GM8S115C16UH11 80.0 GM8S115C16DH11* 80.0
20 115 21 GM8S115C20UH11* 80.0 GM8S115C20DH11* 80.0
20 130 24-1/2 GM8S130D20UH11* 80.0 GM8S130D20DH11* 80.0
*Models available with LoNox
**All units are 40” high x 28-1/2” deep.
