TECHNICAL GUIDE
95.0% AFUE SINGLE STAGE ECM
RESIDENTIAL GAS FURNACES
MULTI-POSITION
MODELS: TM9E
NATURAL GAS
40 - 120 MBH INPUT
Due to continuous product improvement, specifications
are subject to change without notice.
Visit us on the web at
www.upgnet.com and www.colemanac.com
Additional rating information can be found at
www.ahridirectory.org
WARRANTY SUMMARY
A 20-year limited warranty on heat exchangers in residential
applications.
A 10-year warranty on the heat exchanger in commercial
applications.
Standard 5-year limited Parts warranty.
Extended lifetime heat exchanger and 10-year limited
parts warranty when product is registered online within
90 days of purchase for replacement or closing for new
home construction.
See Limited Warranty certificate in Users Information Manual for details.
1104559-CTG-B-0714
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
DESCRIPTION
These compact units employ induced combustion, reliable hot
surface ignition and high heat transfer aluminized tubular heat
exchangers. The units are factory shipped for installation in
upflow or horizontal applications and may be converted for down-
flow applications.
These furnaces are designed for residential installation in a base-
ment, closet, alcove, attic, recreation room or garage and are
also ideal for commercial applications. All units are factory
assembled, wired and tested to assure safe dependable and eco-
nomical installation and operation.
These units are Category IV listed and may be vented either
through side wall or roof applications using approved plastic com-
bustion air and vent piping.
FEATURES
• Easily applied in upflow, horizontal left or right, or downflow
installation with minimal conversion necessary.
• Compact, easy to install, ideal height 33" tall cabinet.
• Blower-off delay for cooling SEER improvement.
• Easy access to controls to connect power/control wiring.
• Built-in, high level self diagnostics with fault code displays
standard on integrated control module for reliable operation.
• Low unit amp requirement for easy replacement application.
• All models are convertable to use propane (LP) gas.
• Electronic Hot Surface Ignition saves fuel cost with
increased dependability and reliability.
• 100% shut off main gas valve for extra safety.
• 5 speed, direct drive Standard ECM style high efficiency DC
motor.
• 24V, 40 VA control transformer and blower relay supplied for
add-on cooling.
• Hi-tech tubular aluminized steel primary heat exchanger.
• Secondary heat exchanger made of corrosion resistant
stainless steel materials.
• Timed on, adjustable off blower capability for maximum com-
fort.
• Blower door safety switch.
• Solid removable bottom panel allows easy conversion.
• Airflow leakage less than 1% of nominal airflow at duct-
blaster conditions.
• No knockouts to deal with, making installation easier.
• Movable duct connector flanges for application flexibility.
• Quiet inducer operation.
• Inducer rotates for easy conversion of venting options.
• Fully supported blower assembly for easy access and
removal of blower.
• External air filters used for maximum flexibility in meeting
customers IAQ needs.
• Protection included from air intake, exhaust vent, or conden-
sate blockage.
• Patent pending self priming internal condensate trap design
for easy installation.
• Venting applications - may be installed as a either 2-pipe
(sealed combustion) or single-pipe vent (using indoor com-
bustion air.
• No special vent termination required.
• 1/4 turn knobs provided for easy door removal.
• High-efficiency blower motor for lower electrical power usage
and improved A/C SEER ratings.
• Insulated blower compartment for terminal and acoustic per-
formance.

1104559-CTG-B-0714
2Johnson Controls Unitary Products
NOTES:
Annual Fuel Utilization Efficiency (AFUE) numbers are determined in accordance with DOE Test procedures.
Wire size and over current protection must comply with the National Electrical Code (NFPA-70-latest edition) and all local codes.
The furnace shall be installed so that the electrical components are protected from water.
FRONT
33
A
LEFT SIDE
Combustion Air Inlet
Condensate Drain
(Downflow)
Vent Outlet
Thermostat
Wiring
28.5”
Gas Pipe
Entry
Electrical
Entry
Condensate
Drain
Thermostat
Wiring
RIGHT SIDE
Vent Outlet
Condensate Drain
(Downflow)
14”
1”
1.5”
23”
Combustion Air Inlet
Gas Pipe
Entry
Electrical
Entry
Condensate
Drain
Optional Return Air
Cutout (Either side)
29.5”
C
SUPPLY END
.56”
.56”
20”
B
3”
23.8”
.56”
Combustion
Air Inlet
Vent
Outlet
RETURN END
B
24.25”
Cabinet & Duct Dimensions
BTUH (kW)
Input Nominal
CFM (m3/min) Cabinet
Size Cabinet Dimensions (Inches) Approximate
Operating Weights
ABC Lbs
TM9E040A10MP11 1000 A 14-1/2 13-3/8 11-3/4 113
TM9E060B12MP11 1200 B 17-1/2 16-3/8 13-1/4 122
TM9E080B12MP11 1200 B 17-1/2 16-3/8 14-3/4 126
TM9E080C16MP11 1600 C 21 19-7/8 16-1/2 136
TM9E100C16MP11 1600 C 21 19-7/8 18-1/4 142
TM9E100C20MP11 2000 C 21 19-7/8 18-1/4 145
TM9E120D20MP11 2000 D 24-1/2 23-3/8 21-3/4 156
Ratings & Physical / Electrical Data
BTUH (kW)
Input Output Nominal
Airflow AFUE Air Temp. Rise Max. Outlet Air Temp Blower Blower
Size
Max
Over-Current
Protect
Total Unit
Amps
Min. wire Size
(awg) @ 75 ft
one way
MBH CFM %°F °F HP Amps
TM9E040A10MP11 38 1000 95.0 45-75 180 1/2 6.8 11x8 15 9.5 14
TM9E060B12MP11 57 1200 95.0 40-70 180 1/2 6.8 11x8 15 9.5 14
TM9E080B12MP11 76 1200 95.0 50-80 170 1/2 6.8 11x8 15 9.5 14
TM9E080C16MP11 76 1600 95.0 40-70 165 1/2 6.8 11x10 15 9.5 14
TM9E100C16MP11 95 1600 95.0 45-75 170 1/2 6.8 11x10 15 9.5 14
TM9E100C20MP11 95 2000 95.0 50-80 165 3/4 8.4 11x11 15 10.9 14
TM9E120D20MP11 114 2000 95.0 50-80 175 3/4 8.4 11x11 15 10.9 14

1104559-CTG-B-0714
Johnson Controls Unitary Products 3
FILTER PERFORMANCE
The airflow capacity data published in the “Blower Perfor-
mance” table shown represents blower performance WITHOUT
filters.
All applications of these furnaces require the use of field
installed air filters. All filter media and mounting hardware or
provisions must be field installed external to the furnace cabi-
net. DO NOT attempt to install any filters inside the furnace.
1. Air velocity through throwaway type filters may not exceed 300 feet per min-
ute (91.4 m/min). All velocities over this require the use of high velocity fil-
ters.
2. Do not exceed 1800 CFM using a single side return and a 16x25 filter. For
CFM greater than 1800, you may use two side returns or one side and the
bottom or one return with a transition to allow use of a 20x25 filter.
* - 24" clearance in front and 18" on side recommended for service access.
All furnaces approved for alcove and attic installation.
ACCESSORIES
Propane (LP) Conversion Kit - This accessory conversion kit
may be used to convert natural gas (N) units for propane (LP)
operation.
S1-1NP0347 - All Models
Concentric Vent Termination - For use through rooftop, side-
wall. Allows combustion air to enter and exhaust to exit through
single common hole. Eliminates unslightly elbows for a cleaner
installation.
S1-1CT0302 (2") & S1-1CT0302-636 (2")
S1-1CT0303 (3") & S1-1CT0303-636 (3")
Sidewall Vent Termination Kit - For use on sidewall, two-pipe
installations only. Provide a more attractive termination for loca-
tions where the terminal is visable on the side of the home.
S1-1HT0901 (3")
S1-1HT0902 (2")
Condensate Neutralizer Kit - Neutralizer cartridge has a 1/2"
plastic tube fittings for installation in the drain line. Calcium car-
bonate refill media is also available from the Source 1 Parts
(P/N 026-30228-000).
1NK0301
Side Return Filter Racks -
S1-1SR0200 - All Models
S1-1SR0402 - All Models
Bottom Return Filter Racks - 1BR05xx series are galvanized
steel filter racks. 1BR06xx are pre-painted steel filter racks to
match the appearance of the furnace cabinet.
S1-1BR0514 or 1BR0614 - For 14-1/2” cabinets
S1-1BR0517 or 1BR0617 - For 17-1/2” cabinets
S1-1BR0521 or 1BR0621 - For 21” cabinets
S1-1BR0524 or 1BR0624 - For 24-1/2” cabinets
Combustible Floor Base Kit - For installation of these fur-
naces in downflow applications directly onto combustible floor-
ing material, These kits are required to prevent potential
overheating situations.tible floor base kit provides access for
combustible airflow.
S1-1CB0514 - For 14-1/2” cabinets
S1-1CB0517 - For 17-1/2” cabinets
S1-1CB0521 - For 21” cabinets
S1-1CB0524 - For 24-1/2” cabinets
High Altitude Pressure Switches - For installation where the
altitude is less than 5,000 feet it is not required that the pres-
sure switch be changed. For altitudes above 5,000 feet, see kits
below.
S1-1PS3306 - 060
S1-1PS3307 - 040, 080
S1-1PS3302 - 100, 120
Thermostats - Compatible thermostat controls are available
through accessory sourcing. For optimum performance and
installation, refer to the UPGNET “Low Voltage Wiring Diagram”
document to select and apply controls.
Single side return above 1800 CFM is approved as long as
the filter velocity does not exceed filter manufacturer’s rec-
ommendation and a transition is used to allow use on a
20x25 filter.
Recommended Filter Sizes (High velocity 600 FPM)
CFM Cabinet
Size Side (in) Bottom (in)
1000 A 16 x 25 14 x 25
1200 B 16 x 25 16 x 25
1600 C 16 x 25 20 x 25
2000 C (2) 16 x 25 20 x 25
2000 D (2) 16 x 25 22 x 25
NOTES:
Unit Clearances to Combustibles
Application Upflow Downflow Horizontal
Top 1" 0" 0"
Vent 0" 0" 0"
Rear 0" 0" 0"
Side 0" 0" 1"
Front* 0" 0" 0"
Floor Combustible Combustible1
1.For combustible floors only when used with special sub-base.
Combustible
Closet Yes Yes Yes
Line Contact No No Yes
NOTES:
NOTICE

Subject to change without notice. Published in U.S.A. 1104559-CTG-B-0714
Copyright © 2014 by Johnson Controls, Inc. All rights reserved. Supersedes: 1104559-CTG-A-0214
York International Corp.
5005 York Drive
Norman, OK 73069
NOTES:
1. Airflow expressed in standard cubic feet per minute (SCFM).
2. Motor voltage at 115 V.
Blower Performance CFM - Any Position (without filter)
Models Speed
Bottom Airflow Data (SCFM)1,2
Ext. Static Pressure (in. H2O)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
TM9E040A12MP11
High 1290 1260 1220 1160 1100 1040 960 840 750 660
Medium High 1170 1140 1110 1070 1040 990 930 820 730 650
Medium 990 980 940 900 860 830 790 730 680 630
Medium Low 900 880 850 810 770 730 670 630 600 560
Low 730 710 690 650 620 590 540 510 480 450
TM9E060B12MP11
High 1402 1374 1354 1328 1299 1262 1222 1167 1107 1036
Medium High 1252 1233 1203 1182 1150 1125 1095 1064 1031 980
Medium 1076 1059 1029 1007 973 946 908 883 843 800
Medium Low 988 967 936 903 875 838 806 765 737 685
Low 798 769 727 695 650 619 574 517 485 443
TM9E080B12MP11
High 1445 1423 1397 1365 1339 1311 1283 1250 1204 1140
Medium High 1282 1266 1232 1211 1182 1157 1128 1097 1069 1013
Medium 1098 1084 1059 1027 998 967 939 910 879 822
Medium Low 1012 993 953 930 894 851 828 773 752 692
Low 865 810 763 730 689 628 594 520 496 448
TM9E080C16MP11
High 1713 1682 1643 1600 1558 1519 1480 1436 1385 1333
Medium High 1554 1519 1485 1439 1404 1368 1327 1280 1176 1130
Medium 1380 1351 1302 1263 1224 1171 1128 1085 1030 943
Medium Low 1177 1142 1083 1050 988 922 890 819 798 687
Low 951 841 650 588 457 418 355 227 203 N / A
TM9E100C16MP11
High 1734 1694 1650 1611 1570 1536 1485 1438 1392 1335
Medium High 1568 1537 1492 1453 1414 1373 1327 1279 1230 1118
Medium 1420 1380 1332 1294 1249 1196 1152 1100 981 938
Medium 1218 1169 1124 1067 1015 965 894 845 754 679
Low 979 846 647 580 464 427 345 220 195 N / A
TM9E100C20MP11
High 2143 2102 2065 2028 1989 1944 1892 1825 1733 1625
Medium High 1788 1749 1718 1672 1629 1587 1541 1500 1447 1355
Medium 1575 1539 1500 1456 1410 1363 1305 1246 1095 1030
Medium Low 1372 1325 1276 1225 1170 1111 1044 972 884 812
Low 1031 921 810 728 660 615 518 474 391 355
TM9E120D20MP11
High 2214 2173 2132 2086 2036 1994 1952 1907 1849 1777
Medium High 1841 1799 1749 1699 1659 1611 1567 1520 1471 1372
Medium 1605 1562 1514 1470 1416 1361 1310 1180 1119 1045
Medium Low 1405 1362 1303 1244 1189 1125 1054 986 876 826
Low 1135 1020 844 758 671 557 511 464 387 N / A
