Replacement Parts List
Item Part No. Description
1 9947-2321 Left Side Burner Table, Stainless
2 9947-6561 Cast Brass Side Burner
3 9947-1471 Side Burner Control Knob
4 9947-3271 Side Burner Electrode (Not Shown)
5 9947-1271 3 Black Control Knobs
6 9947-1591 3 Bezels
7 9947-2071 Right Side Table, Stainless
8 9947-5261 Hardware Kit - Cart (Not Shown)
9 9947-5281 Hardware Kit - Firebox (Not Shown)
10 9947-1481 Door Handles (2)
11 9947-1291 Doors (2)
12 9947-1321 Door Magnets (2)
13 9947-6481 Cast Brass Burner, Main Grill
14 9947-3761 Cooking Grates, Stainless
15 9947-1181 Burner Heat TentTM (3)
Item Part No. Description
16 9947-1051 Temperature Gauge
17 9947-3071 Leg Panel Assembly, Left, Stainless
18 9947-3081 Leg Panel Assembly, Right, Stainless
19 9947-4071 Back Cart Panel, Stainless
20 9947-4511 Bottom Cart Panel, Black
21 9947-1001 Tank Base, Black
22 9947-1101 Middle Divider, Black
23 9947-1171 Top Cart Panel, Stainless
24 9947A4581 Front Caster (1)
25 9947-0461 Grease Tray
26 9947-6061 Towel Hook/Tool Hook
27 9947-1571 Back Panel, Firebox
28 9947-5431 Warming Rack
29 9947-1691 Hinges for Grill Hood
30 9947-6981 Rotisserie Pack
31 9947-3281 Electrode Box
32 9947-3301 Regulator/Hose Assembly
33 9947-4301 Igniter Switch
34 9947-5071 HVR w/Side Burner Valve
35 9947-5081 Side Burner Valve
36 9947-5091 Main Burner Electrode
37 9947-0251 Side Burner Trivet
38 9947-0471 Grease Pan
39 9947-4551 Lid Assembly, Complete
